gofanco PRO-MSTDP3DP User manual

PRO-MSTDP3DP
1x3 DisplayPort 1.2 MST Hub/Splier
with Pigtail Cable
®
Made in Taiwan
User‘s Guide

®
PRO-MSTDP3DP
Congratulaons for owning a gofanco product. Our products
aim to meet all your connecvity needs wherever you go.
Have fun with our products!
Please read this manual carefully before rst use.
If you need more informaon about our products, please visit
www.gofanco.com.
For technical support, please email us at
[e-mail].
For drivers/manuals download, please go to
hp://www.gofanco.com/download.

®
PRO-MSTDP3DP
• DisplayPort 1.2 compliant
• HDCP 1.3 compliant
• Video bandwidth: 21.6Gbps
• Supports SST or MST (Multi-Stream Transport)
• Supports xvYCC, x.v.Color & Deep Color
• Easy installation
2. Features
1. Introduction
3
The PRO-MSTDP3DP 1x3 DisplayPort 1.2 MST Hub/Splitter with
Pigtail Cable provides the most cost eective and advanced
DisplayPort splitter solution on the market, by which the high
denition video and high quality audio can be transmitted to 3
dierent locations without losing quality. PRO-MSTDP3DP can
extend the laptop or desktop to additional displays and stre-
am independent content to each individual display to make
multitasking easier and increase your productivity. Besides,
PRO-MSTDP3DP can mirror the same image or split an image
to multiple displays for digital signage applications.
• 1x PRO-MSTDP3DP
• 1x Micro-USB to USB cable
• 1x User Manual
3. Package Contents

®
PRO-MSTDP3DP
4. Specications
Item Description
Role of usage 1x3 MST Hub/Distribution Amplier (Splitter)
DP compliance DisplayPort 1.2
HDCP compliance HDCP 1.3
Video bandwidth 21.6Gbps
Video support See bandwidth resolution distribution on page 6
Audio support LPCM, AC3, DTS
ESD protection Human body model — ±15kV [air-gap discharge] &
±8kV [contact discharge]
PCB stack-up 4-layer board [impedance control —
dierential 100Ω; single 50Ω]
Input 1x DP
Output 3x DP
DP connector Standard DisplayPort
Mechanical
Housing Metal enclosure
Dimensions
[L x D x H]
Model 105 x 73 x 17mm [4.1 x 2.9" x 0.7"]
Package 165 x 111 x 42mm [6.4" x 4.4" x 1.7"]
Carton 490 x 426 x 352mm [1'6" x 1'4" x 13.8"]
Weight Model 115g [4 oz]
Package 203g [7.2 oz]
Power supply 5V 1A DC
Power consumption 2 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
4

®
PRO-MSTDP3DP
5. Connection Diagram
5
PRO-MSTDP3DP allows user to connect three displays to the Dis-
playPort enabled laptop, Ultrabook, or PC. Congure these added
monitors anyway you want; works as a splitter with the same con-
tent on each monitor, extended mode with independent monitors,
or video wall mode joining multiple monitors together as one dis-
play.
PRO-MSTDP3DP

®
PRO-MSTDP3DP
1. Total bandwidth is 21.6Gbps*(under MST mode)
2. Supports UHD video resolutions up to 3840x2160@30, and
7.1ch surround audio to deliver high quality video and au-
dio.
3. Driver or software is NOT required.
4. Existing video card can be used to minimize the use of sys-
tem resources.
5. MacOS does NOT support MST technology and will only mir-
ror each display
6
Resolution % of total bandwidth(21.6Gbps)
3840x2160@60 80%
3840x2160@30 40%
1920x1200@60 30%
1920x1080@60 22%
The total combined bandwidth among all connected displays
must NOT exceed 21.6Gbps
Notes
*

®
PRO-MSTDP3DP
6. Panel Description
1. DisplayPort output 1
2. DisplayPort output 2
3. DisplayPort output 3
7
1
2
3
4
5
4. DisplayPort input
5. +5V power (Micro-USB)

®
PRO-MSTDP3DP
7. Notice
1. It is limited to two displays under mirror mode using Windows
Display Utility & NVIDIA Utility.
2. It requires either an AMD Eyenity, Intel, or NVIDIA Surround
technology graphics adapter under Video Wall mode (e.g., Pan-
oramic).
3. Intel CPUs with HD Graphics are limited to three external
monitors altogether.
4. A DisplayPort v1.2 output or later is recommended to enable
full functionality. If the source DisplayPort output doesn’t
support DP 1.2, the MST function is disabled and becomes a
Splitter, mirroring your video source across all displays.
1. Systems with an available DisplayPort (DisplayPort v1.2 or la-
ter recommended)
2. Compatible OS: Windows 10 / 8.1 & 8 / 7
3. MacOS does NOT support MST technology and will only mirror
each display
Notes
About Compatible Device
8

®
PRO-MSTDP3DP
9
11. Limited Warranty
The SELLER warrants the PRO-MSTDP3DP 1x3 DisplayPort 1.2 MST Hub/Split-
ter with Pigtail Cable free from defects in the material and workmanship for
1 year from the date of purchase from the SELLER or an authorized dealer.
Should this product fail to be in good working order within 1 year warranty
period, The SELLER, at its option, repair or replace the unit, provided that the
unit has not been subjected to accident, disaster, abuse or any unauthorized
modications including static discharge and power surge. This warranty is of-
fered by the SELLER for its BUYER with direct transaction only. This warranty
is void if the warranty seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at
the current price of parts and labor in eect at the time of repair. Such repairs
are warranted for 90 days from the day of reshipment to the BUYER. If the unit
is delivered by mail, customers agree to insure the unit or assume the risk of
loss or damage in transit. Under no circumstances will a unit be accepted wi-
thout a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including
without limitations, any other implied warranty or tness or merchantability
for any particular purpose, all of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside
Taiwan are responsible for shipping charges to and from the SELLER. Cables
and power adapters are limited to a 30 day warranty and must be free from
any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be
accurate. However, The SELLER assumes no responsibility for any inaccura-
cies that may be contained in this manual. The SELLER will NOT be liable for
direct, indirect, incidental, special, or consequential damages resulting from
any defect or omission in this manual, even if advised of the possibility of
such damages. Also, the technical information contained herein regarding
the PRO-MSTDP3DP features and specications is subject to change without
further notice.

®
