gofanco Prophecy PRO-4Ksplit2P User manual

PRO-4Ksplit2P
4K HDR 1x2 splier
®
Made in Taiwan
User‘s Guide

®
PRO-4Ksplit2P
Congratulaons for owning a gofanco product. Our products
aim to meet all your connecvity needs wherever you go.
Have fun with our products!
Please read this manual carefully before rst use.
If you need more informaon about our products, please visit
www.gofanco.com.
For technical support, please email us at
[e-mail].
For drivers/manuals download, please go to
hp://www.gofanco.com/download.

®
PRO-4Ksplit2P
• HDMI2.0acompliant
• Supports4K2K@604:4:48bits
• SupportsHDR*,whichis4K2K@604:2:010bits**
• HDCP2.2and1.4compliant
• Widefrequencyrange:25MHz~600MHz
• Videobandwidth:18Gbps
• SupportsdefaultEDIDandEDIDlearningfromdisplay
• SupportsxvYCC,x.v.Color&DeepColor
2. Features
1. Introduction
3
ThePRO-4Ksplit2P1x2HDMI2.0aSplitterwithBuilt-in&
UserAdjustableEDIDManagementprovidesthemostcost
eectiveandadvancedHDMIsplittersolutiononthemar-
ket,bywhichthehighdenitionvideoandhighqualityau-
diocanbetransmittedto2dierentlocationswithoutlo-
singquality.PRO-4Ksplit2PsupportsHDRandthetrue4K2K
video!
Withbuilt-inUSBrmwareupdatemechanism,thecompa-
tibilityamongcountlessHDMIsourcesandreceiverscanbe
furtherguaranteed.WiththeupmostHDR/4K2K@604:4:4
8bits and high denition audio support, PRO-4Ksplit2P is
suitableforhighqualityHDMIbroadcasting,digitalsignage
andeducationapplications!

®
PRO-4Ksplit2P
• 1xPRO-4Ksplit2P
• 1xDC5Vwallwart
• 1xUserManual
3. Package Contents
HDR = High Dynamic Range.
The video bandwidth of 4K2K@60 4:2:0 10bits (HDR) is 384 MHz,
and the 4K2K@60 4:4:4 8bits is 594MHz.
*
**
• Mini-USBfirmwareupdateforexpandingcompatibility
• SupportsDolbyDigital,DTS-HDandDolbyTrueHDaudio
• Easyinstallation
4

®
PRO-4Ksplit2P
4. Specications
Item Description
Roleofusage 1x2DistributionAmplier(Splitter)
HDMIcompliance HDMI2.0a
HDCPcompliance HDCP2.2/1.4
Videobandwidth Single-link600MHz[18Gbps]
Videosupport HDR4K2K@60(4:2:010bits)/4K2K@60(4:4:48bits)
Audiosupport DTS-HDMasterAudio,DolbyTrueHDDolbyDigital,
DTS,DVD-Audio,LPCM,SACD,MPCM
ESDprotection Humanbodymodel—±15kV[air-gapdischarge]&
±8kV[contactdischarge]
PCBstack-up 4-layerboard[impedancecontrol—
dierential100Ω;single50Ω]
Firmwareupdate FeasibleviaMini-USBport
Input 1xHDMI
Output 2xHDMI
HDMIconnector TypeA[19-pinfemale]
Dipswitch EDIDModeselection
Mechanical
Housing Metalenclosure
Dimensions
[LxDxH]
Model 124x61x21mm[4.9"x2.5"x0.8"]
Package 198x137x74mm[7.8"x5.39"x2.91"]
Carton 420x400x300mm[16.53"x15.75"x11.81"]
Weight Model 189g[6.6oz]
Package 341g[0.8lbs]
Fixedness Wall-mountingcase
Powersupply 5V2ADC
Powerconsumption 10Watts[max]
Operationtemperature 0~40°C[32~104°F]
Storagetemperature -20~60°C[-4~140°F]
Relativehumidity 20~90%RH[nocondensation]
5

®
PRO-4Ksplit2P
5. Connection Diagram
6

®
PRO-4Ksplit2P
6. Panel Description
FrontPanel
RearPanel
1. Mini-USB:Fortechnicalsupportonly[rmwareupdate]
2. Function Button:ForF/Wupdate(pleasereferto“Notice”abouttheFWupdate)
3. Power LED:Lightsonwhendeviceisready
4. Signal LED: InputsignalLEDindicator
5. Signal LED: Output1-2signalLEDindicator
6. EDID MODE:
7. HDMI OUT1: HDMIoutputstoHDMIdisplays
8. HDMI IN:ConnecttoaHDMIinputsource
9. HDMI OUT2: HDMIoutputstoHDMIdisplays
10. +5V DC:Connecttothe+5VDC2Apowersupplyunit
7
2 3 5
7
4
8
6
109
1
iAutomac EDID learning will detect all the connected HDMI equipped monitors
and analyze all the content of EDID. The EDID with minimal resoluon support
will be the reference EDID for incoming HDMI source players
0-UltraHD(4K2K@60)–8/10/12bit3DHDRvideo&7.1chaudio
1-UltraHD(4K2K@60)–8/10/12bit3DHDRvideo&2chaudio
2-UltraHD(4K2K@30)(4K2K@60420)–8bit3DHDRvideo&7.1chaudio
3-UltraHD(4K2K@30)(4K2K@60420)–8bit3DHDRvideo&2chaudio
4-Full-HD(1080p@60)–12bit3Dvideo&7.1chaudio
5-FullHD(1080p@60)–8bit2Dvideo&2chaudio
6-LearningEDIDfromoutput1
7-AutoEDIDanalysislearningmode*

®
PRO-4Ksplit2P
8
7. Installation
• Switchoalldevices,includingmonitors.
• Connecttothedisplays.
• ConnectanHDMIsource(suchasaBlu-rayDiscplayer)
totheHDMIIn.
• Plugin5VDCpowersupply.
• PowerontheHDMImonitors.
• PowerontheHDMIsource.
Broadcasts HDMI signal to 2 HDMI displays!

®
PRO-4Ksplit2P
Ifsomehowusercannotgetvideooutput,pleasetry
toadjustEDIDrotaryswitchtoMode5or6fortrouble
shooting.UnderMode5,therewillbevideooutput.The
onlyrequirementisthatthedisplayhastosupportat
leastFullHD.IfdefaultFull-HDEDIDstillcannotwork,
usercanswitchtoMode6tolearntheEDIDfromoutput
1tocustomizetheEDIDinformation.(Pleasenotethat
thedisplaywithlowestresolutionmustbeconnectedto
output1)
8. Notice
9
Select to Mode 5 - Full-HD(1080p@60) – 8bit 2D video &
2ch audio
1) Poweronthedevice
2) Settherotaryswitchto“5”
Select to Mode 6 - Learning EDID from output 1)
1) Poweronthedevice
2) Settherotaryswitchto“6”
3) ItwillautomaticallylearnEDIDfromoutput1
1.
2. 
Whileconnectinganewmonitortothesplitterunder
mode7(underautoEDIDanalysislearningmode),expe-
riencingashortperiodoftimewithoutdisplayingmight
beexpected.ThesplitterwilldoAutomaticEDIDlearning
andgeneratethebestEDIDamongallconnectedmoni-
tors
If the user wants to re-learn EDID from output1, please set
the rotary switch to other mode and then come back to “6”
to trigger the Learning Mode
i

®
PRO-4Ksplit2P
10
TheSELLERwarrantsthePRO-4Ksplit2P 1x2 HDMI 2.0a Splitter with
Built-in & User Adjustable EDID Managementfreefromdefectsinthema-
terialandworkmanshipfor1yearfromthedateofpurchasefromtheSEL-
LERoranauthorizeddealer.Shouldthisproductfailtobeingoodworking
orderwithin1yearwarrantyperiod,TheSELLER,atitsoption,repairor
replacetheunit,providedthattheunithasnotbeensubjectedtoaccident,
disaster,abuseoranyunauthorizedmodicationsincludingstaticdischar-
geandpowersurge.ThiswarrantyisoeredbytheSELLERforitsBUYER
withdirecttransactiononly.Thiswarrantyisvoidifthewarrantysealon
themetalhousingisbroken.
Unitthatfailsunderconditionsotherthanthosecoveredwillberepaired
atthecurrentpriceofpartsandlaborineectatthetimeofrepair.Such
repairsarewarrantedfor90daysfromthedayofreshipmenttotheBUY-
ER.Iftheunitisdeliveredbymail,customersagreetoinsuretheunitor
assumetheriskoflossordamageintransit.Undernocircumstanceswilla
unitbeacceptedwithoutareturnauthorizationnumber.
Thewarrantyisinlieuofallotherwarrantiesexpressedorimplied,inclu-
dingwithoutlimitations,anyotherimpliedwarrantyortnessormerchan-
tabilityforanyparticularpurpose,allofwhichareexpresslydisclaimed.
Proofofsalemayberequiredinordertoclaimwarranty.Customersout-
sideTaiwanareresponsibleforshippingchargestoandfromtheSELLER.
Cablesandpoweradaptersarelimitedtoa30daywarrantyandmustbe
freefromanymarkings,scratches,andneatlycoiled.
Thecontentofthismanualhasbeencarefullycheckedandisbelievedto
beaccurate.However,TheSELLERassumesnoresponsibilityforanyin-
accuraciesthatmaybecontainedinthismanual.TheSELLERwillNOTbe
liablefordirect,indirect,incidental,special,orconsequentialdamages
resultingfromanydefectoromissioninthismanual,evenifadvisedof
thepossibilityofsuchdamages.Also,thetechnicalinformationcontained
hereinregardingthePRO-4Ksplit2Pfeaturesandspecicationsissubject
tochangewithoutfurthernotice.
9. Limited Warranty

®
PRO-4Ksplit2P
11
The product name and brand name may be registered trademarks of related manufacturers. TM and ®
may be omied on the user‘s guide. The pictures on the user‘s guide are just for reference, and there
may be some slight dierences with the actual products.
We reserve the rights to make changes without prior noce to a product or system described herein to
improve reliability, funcon, or design.
Disclaimer

Thank you for choosing gofanco
®
www.gofanco.com
Oct, 2018 Ver. A Copyright © 2018 by gofanco, LLC. All rights reserved.
