Gold's Gym MAXX Trainer 685 User manual

Serial Number Decal
CAUT ON
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
QUEST ONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
DO NOT CONTACT THE STORE;
please contact Customer Care.
MPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-877-776-4777
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.workoutwarehouse.com
Model No. GGTL58608.0
Serial No.
Write the serial number in the space
above for reference.
www.workoutwarehouse.com

TABLE OF CONTENTS
WARNINGDECALPLACEMENT..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................5
ASSEMBLY...............................................................................6
OPERATIONANDADJUSTMENT ............................................................11
OWTOFOLDANDMOVET ETREADMILL ..................................................19
TROUBLES OOTING .....................................................................21
EXERCISEGUIDELINES ...................................................................24
PARTLIST ..............................................................................26
EXPLODEDDRAWING ....................................................................28
ORDERINGREPLACEMENTPARTS ..................................................BackCover
LIMITEDWARRANTY ..............................................................BackCover
2
This drawing shows the locations of the
warning decals. f a decal is missing or
illegible, call the telephone number on
the front cover of this manual and re-
quest a free replacement decal. Apply
the decal in the location shown. Note:
The decals may not be shown at actual
size.
WARN NG DECAL PLACEMENT
This product is manufactured and distributed under license from Gold's Gym Merchandising, Inc.

1. Before beginning this or any exercise pro-
gram, consult your physician. This is espe-
cially important for persons over age 35 or
persons with pre-existing health problems.
Read all instructions before using.
2. t is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
3. Use the treadmill only as described.
4. Place the treadmill on a level surface, with at
least 8 ft. (2.4 m) of clearance behind it and 2
ft. (0.6 m) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
5. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
6. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
7. Keep children under age 12 and pets away
from the treadmill at all times.
8. The treadmill should be used only by persons
weighing 300 lbs. (136 kg) or less.
9. Never allow more than one person on the
treadmill at a time.
10. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended
for both men and women. Always wear ath-
letic shoes. Never use the treadmill with bare
feet, wearing only stockings, or in sandals.
11. When connecting the power cord (see page
11), plug the power cord into a surge sup-
pressor (not included) and plug the surge
suppressor into a grounded circuit capable of
carrying 15 or more amps. No other appliance
should be on the same circuit. Do not use an
extension cord.
12. Use only a single-outlet surge suppressor
that meets all of the specifications described
on page 11. To purchase a surge suppressor,
see your local GOLDʼS GYM dealer or call the
telephone number on the front cover of this
manual and order part number 146148, or see
your local electronics store.
13. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. f the control sys-
tem is damaged, the walking belt may slow,
accelerate, or stop unexpectedly, which may
result in a fall and serious injury.
14. Keep the power cord and the surge suppres-
sor away from heated surfaces.
15. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See TROU-
BLESHOOT NG on page 21 if the treadmill is
not working properly.)
16. Read, understand, and test the emergency
stop procedure before using the treadmill (see
HOW TO TURN ON THE POWER on page 13).
17. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
18. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
19. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
WARN NG: To reduce the risk of serious injury, read all important precautions and in-
structions in this manual and all warnings on your treadmill before using your treadmill. CON as-
sumes no responsibility for personal injury or property damage sustained by or through the use of
this product.
MPORTANT PRECAUT ONS
3

4
20. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and switch the reset/off cir-
cuit breaker to the off position when the
treadmill is not in use. (See the drawing on
page 5 for the location of the circuit breaker.)
21. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADM LL on page 19.)
You must be able to safely lift 45 lbs. (20 kg)
to raise, lower, or move the treadmill.
22. When folding or moving the treadmill, make
sure that the storage latch is holding the
frame securely in the storage position.
23. Never insert any object into any opening on
the treadmill.
24. nspect and properly tighten all parts of the
treadmill regularly.
25. DANGER: Always unplug the power
cord immediately after use, before cleaning the
treadmill, and before performing the mainte-
nance and adjustment procedures described in
this manual. Never remove the motor hood un-
less instructed to do so by an authorized ser-
vice representative. Servicing other than the
procedures in this manual should be performed
by an authorized service representative only.
26. This treadmill is intended for in-home use
only. Do not use this treadmill in a commer-
cial, rental, or institutional setting.
SAVE THESE NSTRUCT ONS

5
Thank you for selecting the revolutionary GOLDʼS
GYM MAXX™ TRAINER 685 treadmill. The TRAINER
685 treadmill offers an impressive array of features de-
signed to make your workouts at home more enjoyable
and effective. And when youʼre not exercising, the
unique treadmill can be folded up, requiring less than
half the floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
To avoid a registration fee for any service needed
under warranty, you must register the treadmill at
www.workoutwarehouse.com/registration.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEG N
andrail
Upright
Storage Latch
Key/Clip
Reset/Off
Circuit Breaker
Walking Belt
Isolator
Foot Rail
Power Cord
Rear Roller
Adjustment Bolts
Console
*No water bottle is included
Fan
Water Bottle older*
andgrip Pulse Sensor

1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its left side as shown. Partially
fold the Frame (26) so that the treadmill is more
stable. Do not fully fold the Frame until the
treadmill is completely assembled.
Identify the Right Upright (76), which has a
RIG T sticker. old the Right Upright near the
Base (81). Insert the Upright Wire (75) into the
Right Upright until the Upright Wire is extending
from the upper end of the Right Upright. See the
inset drawing. Make sure that the Upright Wire
is extending from the side of the post as shown.
Remove the tie from the Upright Wire.
Attach the Right Upright (76) to the Base (81)
with a 2 3/4" Upright Bolt (85), a 1" Upright Bolt
(84), and two 3/8" Star Washers (83); do not
fully tighten the Upright Bolts yet.
6
ASSEMBLY
To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480.
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to
the top of the walking belt or the shipping carton. This is a normal condition. If there is lubricant on top of the
walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex key and your own Phillips screwdriver .
Use the drawings below to identify the hardware used during assembly. Note: f a part is not in the hardware
kit, check to see if it has been preattached to one of the parts to be assembled. To avoid damaging plas-
tic parts, do not use power tools for assembly.
26
75
76
85
84
83
81
3/4" Screw (23)–6
Cover Screw (52)–4
3/8" Star
Washer (83)–4
Console Screw (67)–4
Pulse Bar Star
Washer (65)–4
Silver Pulse Bar
Screw (64)–4 Endcap Screw
(79)–2
1 1/4" Tek Screw (49)–2
1" Tek Screw (77)–4
1" Upright Bolt (84)–2 1 1/4" Bolt (63)–4 2 3/4" Upright Bolt (85)–2
1
75
Post
76

7
2. Slide a Front Endcap (80) onto the Base (81).
Partially tighten an Endcap Screw (79) into the
Front Endcap and the Base.
Slide a Wheel ousing (86) onto the Base (81).
Attach the Wheel ousing with a 1" Tek Screw
(77), a Base Pad (89), and a 1 1/4" Tek Screw
(49) as shown.
Attach an additional Base Pad (89) to the Base
(81) with a 1" Tek Screw (77). 89
89
86
79
77
8180
2
3. With the help of a second person, carefully tip
the treadmill onto its right side as shown.
Partially fold the Frame (26) so the treadmill is
more stable. Do not fully fold the Frame until
the treadmill is completely assembled.
old the Left Upright (70) against the Base (81).
Then, thread a 2 3/4" Upright Bolt (85) and a 1"
Upright Bolt (84) with two 3/8" Star Washers (83)
into the Base (81) and the bottom of the Left
Upright; do not fully tighten the Upright Bolts
yet.
26
85
70
81
83
3
4. Slide a Front Endcap (80) onto the Base (81).
Partially tighten an Endcap Screw (79) into the
Front Endcap and the Base.
Slide a Wheel ousing (86) onto the Base (81).
Attach the Wheel ousing with a 1" Tek Screw
(77), a Base Pad (89), and a 1 1/4" Tek Screw
(49) as shown.
Attach an additional Base Pad (89) to the Base
(81) with a 1" Tek Screw (77).
86
77
80 79
89
89
4
77
84
49 77
81
49

8
5. With the help of a second person, carefully raise
the Left Upright (70) and the Right Upright (not
shown) to a vertical position.
Locate the Latch Pin Assembly (73). Remove the
knob from the pin. Make sure that the collar and
the spring are on the pin. (Note: If there are two
collars, place one on each side of the spring.)
Then, insert the pin into the Latch ousing (71),
and tighten the knob onto the pin.
See steps 2 and 4. Fully tighten the two
Endcap Screws (79).
70
Pin
Collar
Spring
Knob
5
71
6. Slide a andrail (62) onto the post on the Left
Upright (70). Partially tighten two 1 1/4" Bolts
(63) into the andrail and the post; do not fully
tighten the Bolts yet.
Attach the other andrail (62) to the Right
Upright (76) in the same way.
70
Post
62
62
63
63
76
6
7. Make sure that the Upright Wire (75) is posi-
tioned at the side of the post on the Right
Upright (76) as shown.
Set the Pulse Bar (66) on the Left and Right
Uprights (70, 76). Attach the Pulse Bar with four
Silver Pulse Bar Screws (64) and four Pulse Bar
Star Washers (65). Start all four Silver Pulse
Bar Screws before fully tightening any of
them.
Firmly tighten the four 1 1/4" Bolts (63).
70
64
65
65
64
65
63
76
66
63
7
75
73

9
8. ave a second person hold the console assem-
bly near the Pulse Bar (66). Connect the
Console Ground Wire (102) on the Pulse Bar to
the ground wire from the console assembly.
Connect the console wire to the Upright Wire
(75). See the inset drawing. The connectors
should slide together easily and snap into
place. If they do not, turn one connector and
then try again. F THE CONNECTORS ARE
NOT CONNECTED PROPERLY, THE CON-
SOLE MAY BE DAMAGED WHEN THE
POWER S TURNED ON. Lay the wires inside
the bottom of the Pulse Bar (66).
75
Console
Assembly
Console Wire
76
102
8
75
9. Set the console assembly on the Left and Right
Uprights (70, 76). Be careful not to pinch any
wires.
Attach the console assembly to the Pulse Bar
(66) with six 3/4" Screws (23). Start all six
Screws before fully tightening any of them.
23
Console Assembly
23 23
70 76
9
Ground
Wire
66
66
10. Identify the Left andrail Cover (68), which has
a LEFT sticker on it. Slide the Left andrail
Cover onto the left andrail (62) and hold it
against the console assembly. Tighten two
Cover Screws (52) into the Left andrail Cover
and the Left Upright (70); be careful not to
overtighten the Cover Screws.
Attach the Right andrail Cover (74) in the
same way.
Console
Assembly
52
68
70
76
74
52
10
62
62

10
12. See the inset drawing. Push the Uprights (70,
76) sideways so that the treadmill Frame (26) is
centered between the Uprights.
Firmly tighten the Upright Bolts (84, 85) on each
side of the treadmill.
With the help of a second person, carefully raise
the Uprights (70, 76) to a vertical position.
76
70, 76
26
26
70
View From Above
Side View
12
85
84
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Note: Extra hardware may be included. Keep the included hex key in a secure place; the hex key is used
to adjust the walking belt (see pages 22 and 23).
11. Lower the Uprights (70, 76) as shown.
Start the two indicated Console Screws (67) into
the Left and Right Uprights (70, 76) and the con-
sole assembly. If necessary, pull back on the
console assembly slightly to align the holes in
the Uprights with those on the console assem-
bly. Start the other two Console Screws (67)
before tightening all four Console Screws;
do not overtighten the Console Screws.
Console
Assembly
67
70
76
11Start First
Start
First
67
