Goldair GCPF315 User manual

Operating Instructions
40cm DC Pedestal Fan with WiFi
Item: GCPF315

General Care and Safety Guide
Thank you for choosing this Goldair product. This Goldair appliance has been designed
and manufactured to high standards of engineering and with proper use and care, as
described in this leaflet, will give you years of useful service. Please read these
instructions carefully and keep them for future reference.
1. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
4. Use only the voltage specified on the rating plate of the appliance.
5. Keep all objects at least 1 Metre from the front, sides and rear of the appliance
6. This appliance is intended for household use only and not for commercial or
industrial use.
7. Use this appliance only as described in this manual. Any other use is not
recommended by the manufacturer and may cause fire, electric shock or injury.
8. The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
9. Always unplug appliance when not in use.
10. When the appliance has been unpacked, check it for transport damage and ensure
all parts have been delivered. If parts are missing or the appliance has been
damaged, contact the Goldair Customer Services Team.
11. If your appliance does not work, or is not working properly, contact the place of
purchase. Repair work on the appliance by unqualified persons can cause serious
risk to the user.
12. Ensure hands are dry before handling the plug or the main unit.
13. Carry out regular checks of the supply cord to ensure no damage is evident.
14. Ensure that the cord is fully extended (not coiled) while in use.
15. Avoid contact with the moving parts. Keep hands, hair, clothing, away from blade
of the fan during operation to reduce the risk of injury to person and/or damage
to the unit.
16. Switch off and use handles provided when moving.
17. It is recommended that this fan is plugged directly into the wall socket.
18. A correctly specified, undamaged extension cord may be used with this fan
provided it is used in a safe manner.

TECHNICAL SPECIFICATION
Model: GCPF315
Supply: 240VAC 50Hz
Wattage: 40W
General Care and Safety Guide
19. Never place appliance close to radiant heat source.
20. Never operate in areas where petrol, paint or other flammable liquids are used or
stored.
21. Never use the appliance to dry clothes.
22. Never insert or allow foreign objects to enter any ventilation or exhaust opening,
as this may cause an electric shock, fire or damage to the appliance.
23. Never use abrasive cleaning products on this appliance. Clean with a damp cloth
(not wet) rinsed in hot soapy water only. Always remove plug from the mains
supply before cleaning.
24. Never connect the appliance to mains supply until completely assembled and
adjusted.
25. Never remove plug from power socket until the appliance has been switched off.
26. Never remove plug from power socket by pulling cord –always grip plug.
27. Never twist, kink or wrap the cord around the appliance, as this may cause the
insulation to weaken and split. Always ensure that all cord has been removed from
any cord storage area and is unrolled before use.
28. Never use this appliance in the immediate surrounds of a bath, a shower, or a
swimming pool or other liquids. The appliance must not be immersed in any
liquids.
29. Due to the risk of injury, never use this appliance for any purpose other than its
intended use. This appliance is intended for use in household and similar
applications such as staff kitchen areas in shops, offices and other working
environments; farm houses, by clients in hotels, motels, bed and breakfast type
environments and other residential type environments
30. Never use this appliance outdoors.
31. Never operate the appliance with a damaged cord or plug, after it malfunctions, or
if it has been damaged in any manner. Have the appliance checked and repaired
by a qualified electrician if repair is necessary.
32. Never place the unit in wardrobes or other enclosed spaces as this may cause fire
hazards.

Components
Description
1. Centre Cap
2. Front Guard
3. Circular ring
4. Blade Lock Nut
5. Blade
6. Rear Guard Retaining Nut
7. Rear Guard
8. Motor Body
9. Column
10. Base
11. Base Weight
12. Column Washer
13. Column Connecting Bolt
14. Remote control
COLUMN ASSEMBLY INSTRUCTIONS
1. Take the base and column parts from the
packing box and loosen the plastic nut.
2. ix the column on the base plate using the
plastic nut.
3. Unscrew the height adjusting knob.
4. Move the extension pole to the desired
height.
5. Then screw the height adjusting knob to
tighten the extension pole.
FAN BODY ASSEMBLY INSTRUCTIONS
1. Unscrew the spinner clockwise and the nut
counter-clockwise to remove both of them.
2. Set the rear guard in the proper position with
handle up.
3. Screw on plastic nut tightly to attach rear
guard.
4. Discard plastic sleeve on motor shaft.
5. Install the blade onto the motor shaft until it
reaches the retaining pin.
6. Screw spinner onto motor shaft counter
clockwise to blade.
7. Press the rim of the rear guard onto the front
guard until the rear guard is properly fitted.
8. Secure both guards firmly by tightening the
fan guard then close easy clip.

Operating your Fan
Always choose a safe location for the fan, keeping in mind the safety precautions outlined.
Ensure all packaging has been removed from the unit before use. This appliance requires no
installation, it should be used solely as a portable appliance.
FAN OPERATING INSTRUCTION
WARNING: Keep all objects at least 1 metre from the front, sides and
rear of the appliance
Once the fan has been assembled correctly, connect the mains plug to the mains
socket.To turn the fan on, press “ ON/OFF “on the control panel or on the remote.
When the fan start working, indicating light will be on accordingly. press “ ” to
increase the speed; press “ ”to decrease the speed accordingly. Choose the speed
you prefer.
To turn the fan off press on the control box or on the remote.
To make / stop the fan oscillate press “ SWING ” repeatedly.
Tilt adjusting: To adjust the air flow upward or downward, push the guard lightly to
the desired direction.
WIND MODE
Press button on remote to select the desired wind mode. There are three kinds of
wind mode: normal, nature and sleep. When normal wind is selected, indicating light
“NOR” in the control panel will be on; when nature wind is selected, indicating
light “NAT” in the control panel will be on; when sleep wind is selected, indicating
light “SLP” will be on. Under the normal mode “NOR”, speed can be change from
1 to 12.
TIMER
You can set the fan to automatically turn itself off within a desired time period from
0.5 to 7.5 hours.When the fan is on. Repeatedly press “ ” on the remote to select
the fan to automatically turn itself off within a desired time period from 0.5 to 7.5
hours. On the control panel, the corresponding light will show on the panel. When
the fan is off. Repeatedly press “ ” on the remote to select the fan to
automatically turn itself on within a desired time period from 0.5 to 7.5 hours. on the
control panel, corresponding light will show on the panel.

WiFi –Downloading and Setting up APP
This APP is supported only on 2.4GHz WiFi channels. Please ensure your phone is
2.4GHz capable.
Note this fan will only work within your home WIFI system.
This does not operate on 3G or 4G internet connections.
You will need a connection to your home WiFi.
•Select your country code
•Enter your cellphone number
•Tap “Next”
You will then receive a text message with a verification
code.
Tap REGISTER near the bottom of the screen.
Download Goldair fan mobile APP
•Open the APP Store or Google Play on your mobile phone.
•Open “Search” and enter “Goldair fan"
•Click “GET” and begin to download and install.
Once downloaded to your phone open the APP

WiFi –Downloading and Setting up APP
•Enter the verification code from your text message
•Create a password.
•Then tap confirm.
If you haven’t received a verification code via text
message. Tap the resend button and when the
verification code is received follow above steps.
Your APP is now registered and ready for pairing to your
fan.
Pairing APP to FAN
Plug the fan into the mains power and make sure the
mains power switch is on.

Pairing APP to fan
On your phone tap open the Goldair app. Then tap “ADD
DEVICE” to connect to the fan.
Press and hold the ON/OFF button on the fan for 5 seconds.
A beep will sound indicating the fan is trying to connect to
the WiFI and to the app on the phone. The WiFI LED on the
control panel of the fan will blink 3x every second
indicating its in the WiFi connecting mode.
Tap ‘Next Step” on the phone.

Pairing APP to Fan
When the phone interface shows the addition is
successful, and the WIFI indicator on the fan
will stop flashing.
The fan pairing is complete and the main
control screen on your phone will appear showing
the fan as OFF.
If the phone and fan fail to connect, then you will need to try to connect again as per the above process.
Choose/confirm which WiFi to connect to.
Note: your phone may pick up other WiFi signals (e.g.
neighbours) so you will need to choose.
Enter your WiFi password
XXXXXX
The phone will then connect to the fan.
Ensure you have a good strong signal from your WiFi
router.
Note: The WiFi indicator on the fan may go off during this
pairing process.
Once complete the screen showing the device has been
successfully added will appear.
Rename the fan if desired.
Tap “Done” to continue.

Operating your Fan from the APP
You can rename the fan.
Tap the 3 dots on the top right of the control screen of
the APP to take you to the next page.
Click “Modify Device Name” and rename the fan.
Example: Bedroom 1, Dining Room etc. and tap save.
DEVICE SHARING SET UP
The person you add will need to have the Goldair fan APP installed on their
phone.
Open the “GOLDAIR APP” and tap the 3 dots in the top right of the screen.
Tap "Add Sharing" to enter the number of the person you want to include or tap
the phone icon to select the persons phone number.
Tap “Confirm” to complete the addition.
DEVICE SHARING CANCELLATION
Open the “GOLDAIR APP” and tap the 3 dots in the top right of the screen. Tap
“Add Sharing” and delete the phone numbers of shared members to cancel the
device sharing.
NOTE: There can only be one user operating the fan at a time. The APP needs to
be closed on all other devices to enable the sharing to work.
NOTE: If someone else sets up their phone on the same fan without using the
“Device Sharing” the original phone will be disconnected and the fan will
disappear from the device list.

Operating your Fan from the APP
Mobile phone remote operation (connect fan power and
turn on the side switch, so that the fan is in standby
mode).
POWER
Open the “GOLDAIR" APP to select the fan (when using
one mobile phone to control multiple fans, you need to
select the fan to be operated).
•Select the fan to be operated and enter the operation
interface.
If the graphic of the fan blade is the color is grey, this
indicates that the fan is in the OFF standby setting.
•Tap the Power icon and the fan will turn on.
The graphic of the fan blade will now turn the colour
white.
•You can now control the fan.
•To turn the fan off again tap the Power icon and the
fan blade graphic will revert to the grey colour.
MODE
There are 3 modes the fan can go into. To select the
mode press the Mode icon.
NORMAL –this is the standard and default mode of the
fan. 12 Speed settings
NATURAL –this mode attempts to mimic the outdoor
natural wind type of by constantly changing the wind
speed. 3 speed settings
SLEEP –this mode is very similar to natural mode where
the wind speed will change every few seconds. 3 speed
settings
OSCILLATION (OSC)
In any mode you can select the fan to oscillate from side
to side by pressing the OSC icon
Grey icon –fan Off White icon –fan On

WIND SPEED
To select different cooling powers tap the WindSpeed
icon.
In the default mode of Normal you can select speed
settings from 1-12 (1) quiet and low speed, (12) high
speed.
Tap the speed setting that feels the most comfortable to
you.
In Sleep and Natural mode select speed settings from 1 to
3.
Note in the speed setting 3 this will allow the fan to cycle
up to the fans most powerful wind speed setting.
Operating your Fan from the APP
TIMER
To set the timer press the clock icon in the bottom left of
the screen –above the Wind Speed icon.
When the fan is ON you can set it to turn OFF after a
number of hours (0.5-7.5 hours) has elapsed.
•In the APP, tap the fan to be operated and enter the
operation interface.
•With the power icon on the lower left corner of the
mobile phone interface is displaying ON and the fan
is turned ON.
•Tap the timer button and scroll to select the number
of hours before the fan will turn OFF and tap OK to
return to the fan operation interface.
•The timer icon on the lower right will display how
long before the timer will turn the fan OFF.
To cancel the timer, touch the timer button again and the
numbers will disappear and just show timer.
When the fan is OFF the timer can be set to come on
after 0.5 to 7.5 hrs.

Adding Additional Fans
Choose/confirm which WiFi to connect to.
Note: your phone may pick up other WiFi signals (eg.
neighbours) so you will need to choose.
Enter your WiFi password
XXXXXX
From the “Devices” page of the APP press “Add Device”
and follow the steps below to pair the new fan.

Adding Additional Fans
Your Devices list will then show the additional fans that
you have paired
The phone will then connect to the fan.
Ensure you have a good strong signal from your WiFi
router.
Note: The WiFi indicator on the fan screen may disappear
during this pairing process.
Once complete the screen showing the device has been
successfully added will appear.
Rename the fan if desired.
Tap “Done” to continue.
Troubleshooting
Please refer to the Goldair website
http://www.goldair.co.nz/product-catalogue/heating/wifi-fans
Or free phone [phone] (NZ Only)
http://www.goldair.com.au/product-catalogue/heating/panel-fans
Or free phone 1300 GOLDAIR (1300 465 324) (Australia Only)

Cleaning
Remote Control
The remote control buttons perform the same
functions as those on the control panel of the
unit.
To replace the batteries in the remote control,
use a screwdriver to unscrew and lift the
battery cover. Replace all batteries with 2 x AAA
type batteries. Ensure you insert new batteries
with the polarities in the correct direction.
Replace the battery cover and tighten the
screw.
Remove batteries when unit is not being used
for prolonged periods. Do not dispose of
batteries in fire as batteries may leak or
explode. Do not recharge non-rechargeable
batteries.
Operating your Fan
Proof of purchase
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).
Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]z
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected].au
SUPPORT AND TECHNICAL ADVICE
To avoid risk of electric shock, before cleaning,
you MUST ALWAYS switch off and unplug the
fan before cleaning.
Ensure that the fan is switched off from the
supply mains before removing the guard.
Use only a soft, damp cloth to gently wipe the
fan and dry well.
To access the fan blade , remove the front
guard and securing screw.
Do not immerse the fan in water and never
allow water to enter the motor housing.
Do not use harsh chemicals to clean the fan.

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal
domestic use for a period of one year. In non-domestic use Goldair limits the voluntary warranty to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone
other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits to you given by this warranty are in addition to other rights and remedies available to you under a law in relation to
the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
One Year Warranty
Goldair One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair –New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland, 0745
Phone [phone]
Phone [phone]
www.goldair.co.nz
Goldair –Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone [phone]
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au
