Goldrabbit Maunzi Classic Instruction Manual

©2018 Goldrabbit Co.,Ltd.
PRODUCT INSTRUCTIONS AND SAFETY WARNINGS

2
312 20
This user guide contains information helpful for using Maunzi. Please read closely before use.
Information on safety warnings and cautions are included (page 4) so make sure to read them and use the product for right purposes.
This user guide was written October 25, 2018. We are constantly making partial changes, modifications and improvements to Maunzi.
However, these changes are not reflected in this guide.
CONTENT
Product information
Customer service
Before use
Safety warnings and cautions
Note before charging
Charging
Details to check before use
Regarding errors
Cleaning
Storage
Disposal
GENERAL GUIDE
Window Cube
Bridge
Charger Cube
Motor Cube
Lighting Cube
Cannon Cube
Sub Cube
Angle Cube
Rotation Cube
Cube's operating process
Does Cube not move?
Cube + Lego
CUBE GUIDE
Nick
Willy
Cobi
CHARACTER GUIDE

3
Model No.
Window Cube
Motor Cube
Angle Cube
Rotation Cube
Lighting Cube
Cannon Cube
Bridge
Charger Cube
Sub Cube
Nick Brick Pack
Willy&Cobi Brick Pack
Wheel bar
Wheel
USB Cable
Adapter
Cannon Bombs
4X4 Block
MZ S 17 01 01
1
1
X
X
X
X
1
1
X
1
X
2
2
1
1
X
2
MZ S 17 01 02
1
2
1
X
1
X
3
1
X
1
1
4
4
1
1
X
6
MZ S 17 01 03
1
2
1
X
1
1
5
1
X
1
1
4
4
1
1
10
10
MZ S 17 01 04
1
2
2
2
2
1
6
1
2
X
X
4
4
1
1
20
12
Kit name Classic Kit Dynamic Wheeler Kit Burning Cannon Kit Full Performance Kit
Model No.
Bridge
Sub Cube
4X4 Blocks
Kit name
MZ S 17 01 05
5
4
10
Expansion Box
email
tel
site
[email protected]
070-8885-2237
www.maunzi.com
DEVELOPMENT & MANUFACTURING
PRODUCT NAME
KIT NAME
ADDRESS
CERTIFICATION
#104, 7 beon-gil, Yongso-ro, Nam-gu, Busan,
Korea
Maunzi
Korea
China
Europe
U.S
10-1605059
201711136991.6
003414838-0001
87/567443
Godlrabbit Co.,Ltd.
PRODUCT INFORMA-
TION
PRODUCT COMPOSITION
CUSTOMER SERVICE
Refer to product composition

4
1
2
1
2
3
1
2
SAFETY WARNINGS
AND CAUTIONS
This product is module assembly type toy
robot. This works in connection with
Window Cube.
Before use, Window Cube should be
charged. Follow the instructions in this
guide to work properly.
Control module Cube (hereinafter referred
to as Cube) can only be connected to
"Maunzi." Do not connect to other
manufacturer's products.
3
PREPARATION BEFORE USE
Get smart devices such as mobile or PC,
smart pad(hereinafter referred to as tablet)
ready. Maunzi is a robot that is remotely
controlled by Bluetooth Connection.
Install mobile or tablet exclusive applica-
tion(hereinafter referred to as app).
mobile
tablet
Maunzi RC
Maunzi LAB
Maunzi app is compatible with both
Android and iOS.
Make sure to store the product in a safe
place for safe use.
These are the safety alert symbols to
emphasize potential dangers or cautions.
This symbol is used to indicate serious
danger or potential risks. If ignored, it
can be life threatening and cause serious
injury.
Protect battery inside Window cube from
overheating and fire.
Power supply device ( page 7) and Charger
Cube should be used by adult or under
adult's supervision.
This product is not a simple toy. It contains
battery inside.
This symbol indicates fatal elements that
can cause danger to life or serious injury.
This symbol indicates elements that can
cause minor injury or wound.
This symbol indicates important information
or information that requires attention.
DANGER : HIGH SAFETY RISK
BEFORE USE
Ignoring the following instructions can cause
fatal dangers to life or sever injuries.

5
Lithium-polymer rechargeable battery is
built inside the window cube that cannot
be replaced.
External impact and battery overheating
can cause fire.
When window cube is damaged or
deformed, stop using immediately. Discard
according to appropriate methods.
Do not immerse it in water.
Do not contact it with heat directly.
Battery inside Window cube can be
damaged by external environment and
impact.
If possible, do not use it in a fire prone
areas or narrow and closed area.
In case of fire, do not extinguish with
water. Use blanket or fire extinguisher. Do
not touch the product with bare hands.
Instead use protective gloves and
equipment to put out fire.
This toy is very dangerous to children
under 3. Small components can cause
suocation.
When used by children under 6, use it
under adult's supervision
Pay attention to children's throwing the
product or breaking it with force.
When the product is deformed during
charging or storage and Cubes become
overheated, malfunctioning or damage
occurs, then immediately separate
power supply device from charring cube
to prevent fire or electric shock.
Make sure to use power supply device
provided.
WARNING : MID LEVEL DANGER
Ignoring the following instructions can cause life
threatening damage or sever injuries.

6
Maunzi is children's toy and can be used
for professional robot education
purposes.
Be advised to use it in relatively clean
indoor environment.
Do not immerse the product in water
Keep from actions such as assembling
essential parts of Cube with excessive
force or dropping from heights
For prolonged use, store Cube in clean
area without dirt.
Window Cube and lighting Cube have
built-in LED. Do not start at the light
directly. Do not look at the light using
microscope or magnifier. Staring at the
LED light can be harmful to your eyes.
Window cube should be connected to the
following power supply devices that are
compliant with protection grade 2.
Mode number and issued certifica-
tion content are indicated on the
back of charging adapter.
We call charging adapter and USB cable
combined together as power supply
device.
input
output
material
AC 100V-240V 0.26A
DC 5V 2A
PC+Metal(��)
Use power supply device in room tempera-
ture.
CAUTIONS : LOW LEVEL DANGER
Window cube should be disassembled by
professional.
Exposure to excessive humidity can
cause malfunctioning.
Ignoring the following instructions can cause
minor injury or wound.

FCC Interference Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part
15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to correct the
interference by one of the following
measures:
FCC Compliance Statement
This device complies with part 15 of the
FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
FCC Caution
Any changes or modifications not
expressly approved by the party
responsible for compliance could void
the user's authority to operate this
equipment. This transmitter must not be
co-located or operating in conjunction
with any other antenna or transmitter.
FCC Radiation Exposure Statement
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment. This
equipment should be installed and
operated with minimum distance 20 cm
between the radiator and your body.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from which the
receiver is connected. • Consult the
dealer or an experienced radio/TV
technician for help.
FCC ID : 2AWO3-MZFV1701
These are parts that contain
Bluetooth (BLE).

7
1
Use only Maunzi Charger Cube provided.
Do not use PC's or other manufacturer's
power supply devices
POWER SUPPLY DEVICE
Use power supply device in room temperature.
Protect Charger Cube from overheating.
Never break it. There is a risk of fire.
Obvious damage to or deformation
of Charger Cube or malfunction or
deformation by heat can cause fire or
electric shock. Upon finding relevant
symptoms, separate power supply from
Charger Cube.
Power supply device can be replaced by
same type of device.
Use power supply device and Charger Cube
by adult or under adult's supervision.
Do not connect Charger Cube and power
supply device to any devices other than
window cube.
WINDOW CUBE
CHARGER CUBE
When battery is low, battery indication
lamp on Window cube will display orange
light.
The combination of Charging adapter and USB
cable is called power supply device here.
Window Cube doesn’t have storage function.
Charging is possible only in Window Cube.
Do not charge other Cubes.
BEFORE CHARGING
CHARGING

8
4
5
6
23
Connect Adapter provided to USB
cable
Connect Adapter to an outlet.
Shape of plug can vary depending on the country.
1 window cube can be charged. If the
window cube is connected to other
cubes, disassemble all to leave Window
cube.
Connect USB cable with Charger Cube.
Turn off window cube by pressing power
button for 3 seconds.
Remove all cubes and blocks connected
to Window cube. 2

9
1
2
78
9
10
When finished with use, immediately
charge Window cube.
charging time : about 90 minutes1
Operating time : about 50 minutes2
Time that takes from completely discharged battery
to fully charged.
In case of fully charged Window connected to 6
cubes and then, continual running of Bluetooth
control using Maunzi RC app.
2
Connect Window cube onto Charger
Cube .
Press down until click sound.
78
Indication lamp will display purple light
as charging starts.
9
The purple light will disappear when
charging is finished.
10
63
Connect so that red side of window cube
is in contact with upper side of Charger
Cube.

10
Do not force motion cubes (motor cube,
angle cube, rotation cube) to move.
Forcibly turning by hand can cause
internal malfunction.
Do not stop modules in motion by force.
This can cause internal malfunction.
Bluetooth communication distance is up
to 15 meters when there is no obstacle.
Do not connect more than 6 cubes(ex-
cept bridge) to 1 Window cube to prevent
deformation. If more than 8 cubes are
connected, overload can occur and lead
to malfunction.
Make sure to turn o window cube's
power after use. Do not leave it with
power on to prevent damage to product
such as overheating
Remove power supply device when
charging is finished.
Most errors can be solved by installing latest
firmware. Check the homepage frequently to
update firmware regularly. Download relevant
app to update firmware and follow
instructions on the homepage and app.
SITE
DEFAULT APP
www.maunzi.com
Maunzi RC
KEEP YOUR DEVICE UP TO DATE
WITH THE LATEST FIRMWARE.
REGARDING ERRORS
Start using when its temperature matches
room temperature to prevent damage by
condensation of inner parts after a low
temperature shipping
DETAILS TO CHECK
BEFORE USE
Do not disassemble Window cube by force.

11
To minimize negative impacts on health
and environment, dispose of products in
accordance with each country's
guidelines for electronic and electrical
equipment.
Store in dry and cool area.
Avoid place over 40 �.
℃
STORAGE
When cube is overheated, the indication lamp
will blink red. Window cube will be turned off
for a few seconds automatically.
Automatic power control is built-in to
prevent damage to product in case of
overheating.
AUTOMATIC POWER CONTROL IN
CASE OF OVERHEATING
in case of repeated overheating,
disconnect Window cube and other cubes
and turn o power and cool down for 10-15
minutes
Use dry cloth or smooth brush for light
cleaning.
Do not use chemical, detergent or liquid
cleaning agent to prevent damage to product.
Use dry material to wipe exterior.
Always disconnect Window cube from
power supply device before cleaning.
CLEANING
DISPOSAL
Check charging status after 6 months and
charge product frequently.
Do not store more than 2 weeks in
temperature over 35 . �
℃
To prevent battery damage caused by full
discharge of battery, never store battery
in fully discharged state.

12
To prevent product deformation, do not
connect more than 6 cubes(except
bridge) to one Window cube. Connecting
to more than 8 cubes can cause
malfunction due to overheating.
Window Cube BRIDGE
Insert bridge to
connect each cube to
others.
CHARGER CUBE
Refer to Charging(page 7).
: State indication lamp
If error continues, window cube turns o
automatically to prevent overheating.
mic : Power switch
press once and state indication lamp will
blink white (indicating booting) and after a
few minutes, white light (power on) will last.
press about 3 minutes and then it turns o.
power on
power o
: Manual operation switch
If pressed once, connected cube starts
preset repetitive motion. Pressed once again,
it stops repetitive motion.
Power on
System is booting
manual operation
Maunzi LAB playing
Connecting to Bluetooth
No battery
Charging
Error/ malfunction
White
White blinking
Green
Green blinking
Blue
Orange
Purple blinking
Red blinking
