Goodman Gsx13 User manual

Standard Features

• Energy-ecient compressor

• Factory-installed lter drier

• Copper tube/aluminum n coil

• Service valves with sweat connecons

and easy-access gauge ports

• Contactor with lug connecon

• Ground lug connecon

• AHRI Cered; ETL Listed

Cabinet Features

• Heavy-gauge galvanized-steel cabinet

with louvered sound control top

• Aracve Architectural Gray powder-paint

nish with 500-hour salt-spray approval

• Steel louver coil guard

• Single-panel access to controls with space

provided for eld-installed accessories

• When properly anchored, meets the 2010

Florida Building Code unit integrity require-

ments for hurricane-type winds

(Anchor bracket kits available.)

SS-GSX13 www.goodmanmfg.com 12/15

Supersedes 11/15

Contents

Nomenclature ........................................ 2

Product Specicaons ........................... 3

Expanded Cooling Data ......................... 4

AHRI Rangs ........................................ 20

Wiring Diagrams ................................. 47

Dimensions .......................................... 48

Accessories .......................................... 48

* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the 10-

Year Parts Limited Warranty, online registraon must be completed within 60 days of installaon. Online

registraon is not required in California or Quebec.

Energy-Efficient

Split System Air Conditioner

13 SEER / 1½ to 5 Tons

Cooling Capacity:

18,000 - 60,000 BTU/h

GSX13

Nomenclature

2www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 3

 1 2 3 4,5 6,7,8 9

Brand Engineering

G Goodman®Brand Major&MinorRevisions

(notusedforinventoryorordering)

ProductCategory Electrical

S SplitSystem 1 208/230V,1Phase,60Hz

 2 220/240V,1Phase,50Hz

UnitType 3 208/230V,3Phase,60Hz

X CondenserR410A

HeatPumpR410A

NominalCapacity

0181½Tons 0302½Tons 0423½Tons

Efficiency 0191½Tons 0312½Tons 0433½Tons

13 13SEER 1616SEER 0242Tons 0363Tons 0484Tons

14 14SEER 1818SEER 0252Tons 0373Tons 0605Tons

036

Product Specifications

2www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 3

GSX13

0181E*

GSX13

0241E*

GSX13

0301B*

GSX13

0361E*

GSX13

0421B*

GSX13

0481B*

GSX13

0601B*

GSX13

0611A*

Capacities

Nominal Cooling (BTU/h) 18,000 23,000 30,000 36,000 42,000 48,000 60,000 60,000

SEER / EER 13 / 11 13 / 11 13 / 11 13 / 11 13 / 11 13 / 11 13 / 11 13/11

Decibels 75 75 73 74 75 76 77 72

Compressor

RLA 6.7 7.7 12.8 14.1 17.9 19.9 25.0 26.4

LRA 41 37 64 77 112 109 134 134

Condenser Fan Motor

Horsepower 1/8 1/8 1/8 1/4 1/4 1/4 1/4 1/4

FLA 0.7 0.7 0.7 1.5 1.5 1.5 1.5 1.5

Refrigeration System

Refrigerant Line Size ¹

Liquid Line Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"

Sucon Line Size (“O.D.) ¾" ¾" ¾" ⅞" 1⅛" 1⅛" 1⅛" ⅞"

Refrigerant Connecon Size

Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"

Sucon Valve Size (“O.D.) ⁴ ⁵ ¾" ¾" ¾" ¾" ⁴ ⅞" ⁵ ⅞" ⁵ ⅞" ⁵ ¾"

Valve Type Sweat Sweat Sweat Sweat Sweat Sweat Sweat Sweat

Refrigerant Charge 44 44 44 52 61 80 80 111

Shipped with Orice Size 0.051 0.055 0.061 0.070 0.076 0.080 0.086 0.086

Electrical Data

Voltage (60 Hz) 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230

Minimum Circuit Ampacity ² 9.1 10.3 16.7 19.1 23.9 26.4 32.8 34.5

Max. Overcurrent Protecon ³ 15 amps 15 amps 25 amps 30 amps 40 amps 45 amps 50 amps 60 amps

Min / Max Volts 197/253 197/253 197/253 197/253 197/253 197/253 197/253 197/253

Electrical Conduit Size ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾"

Equipment Weight (lbs) 102 103 115 118 171 175 184 211

Ship Weight (lbs) 117 120 132 135 189 193 202 233

¹ Line sizes denoted for 25’ line sets, tested and rated in accordance with AHRI Standard 210/240. For other line-set lengths or sizes, refer

to the installaon & Operang instrucons and/or the long line-set guidelines.

² Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require larger wire sizes

³ Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.

⁴ Installer will need to supply ¾” to ⅞” adapters for sucon line connecons.

⁵ Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.

Notes

• Always check the S&R plate for electrical data on the unit being installed.

• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installaon Instrucons Final Charge Procedure.

4www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 5

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

525

MBh 15.6 16.2 17.7 - 15.3 15.8 17.3 - 14.9 15.4 16.9 - 14.5 15.1 16.5 - 13.8 14.3 15.7 - 12.8 13.3 14.5 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

 19.3 16.7 12.7 - 19.5 16.9 12.8 - 19.5 16.9 12.8 - 19.6 17.0 12.9 - 19.4 16.8 12.7 - 18.1 15.7 11.9 -

kW 1.02 1.04 1.08 - 1.11 1.13 1.17 - 1.18 1.21 1.25 - 1.25 1.28 1.32 - 1.30 1.33 1.38 - 1.35 1.38 1.43 -

Amps 4.3 4.4 4.5 - 4.6 4.7 4.9 - 5.0 5.1 5.3 - 5.4 5.5 5.7 - 5.7 5.8 6.0 - 6.0 6.2 6.4 -

 203 219 231 - 228 245 259 - 259 279 294 - 295 318 335 - 332 357 377 - 367 395 417 -

 102 109 119 - 108 115 126 - 113 120 131 - 118 126 137 - 124 132 144 - 128 136 149 -

600

MBh 16.4 17.0 18.7 - 16.0 16.6 18.2 - 15.7 16.2 17.8 - 15.3 15.8 17.4 - 14.5 15.0 16.5 - 13.4 13.9 15.3 -

S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.69 0.47 -

 18.0 15.6 11.8 - 18.2 15.8 12.0 - 18.2 15.8 12.0 - 18.4 15.9 12.1 - 18.1 15.7 11.9 - 16.9 14.6 11.1 -

kW 1.03 1.06 1.09 - 1.12 1.14 1.18 - 1.19 1.22 1.27 - 1.26 1.29 1.34 - 1.32 1.35 1.40 - 1.37 1.40 1.45 -

Amps 4.3 4.4 4.6 - 4.7 4.8 4.9 - 5.1 5.2 5.4 - 5.4 5.6 5.7 - 5.8 5.9 6.1 - 6.1 6.3 6.5 -

 206 221 234 - 231 248 262 - 263 283 298 - 299 322 340 - 336 362 382 - 372 400 422 -

 104 110 121 - 110 117 127 - 114 121 132 - 120 127 139 - 126 134 146 - 130 138 151 -

650

MBh 16.9 17.6 19.2 - 16.5 17.1 18.8 - 16.1 16.7 18.3 - 15.8 16.3 17.9 - 15.0 15.5 17.0 - 13.9 14.4 15.7 -

S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -

 17.5 15.1 11.5 - 17.7 15.3 11.6 - 17.7 15.3 11.6 - 17.8 15.4 11.7 - 17.6 15.2 11.6 - 16.4 14.2 10.8 -

kW 1.05 1.07 1.11 - 1.14 1.16 1.20 - 1.21 1.24 1.29 - 1.28 1.31 1.36 - 1.34 1.37 1.42 - 1.39 1.42 1.47 -

Amps 4.4 4.5 4.6 - 4.7 4.9 5.0 - 5.2 5.3 5.5 - 5.5 5.6 5.8 - 5.9 6.0 6.2 - 6.2 6.4 6.6 -

 209 225 238 - 235 253 267 - 267 287 304 - 304 327 346 - 342 368 389 - 378 407 430 -

 106 112 123 - 112 119 130 - 116 123 135 - 122 130 142 - 128 136 148 - 132 141 153 -

525

MBh 15.9 16.4 17.7 19.0 15.5 16.0 17.3 18.6 15.2 15.6 16.9 18.1 14.8 15.2 16.5 17.7 14.0 14.5 15.7 16.8 13.0 13.4 14.5 15.6

S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40

 22.3 20.5 16.8 11.6 22.5 20.7 17.0 11.7 22.6 20.8 17.0 11.7 22.7 20.9 17.1 11.8 22.4 20.6 16.9 11.7 20.9 19.3 15.8 10.9

kW 1.03 1.05 1.09 1.13 1.12 1.14 1.18 1.22 1.19 1.22 1.26 1.31 1.26 1.29 1.33 1.38 1.32 1.35 1.39 1.44 1.36 1.40 1.45 1.50

Amps 4.3 4.4 4.6 4.7 4.7 4.8 4.9 5.1 5.1 5.2 5.4 5.6 5.4 5.5 5.7 5.9 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.7

 205 221 233 243 230 248 262 273 262 282 297 310 298 321 339 353 335 361 381 398 371 399 421 439

 104 110 120 128 109 116 127 135 114 121 132 141 119 127 139 148 125 133 145 155 129 138 150 160

600

MBh 16.7 17.2 18.6 20.0 16.3 16.8 18.2 19.5 15.9 16.4 17.8 19.1 15.5 16.0 17.3 18.6 14.8 15.2 16.5 17.7 13.7 14.1 15.2 16.4

S/T 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.38 0.89 0.80 0.60 0.39 0.92 0.83 0.63 0.40 0.93 0.83 0.63 0.41

 20.8 19.1 15.7 10.8 21.0 19.4 15.9 11.0 21.1 19.4 15.9 11.0 21.2 19.5 16.0 11.1 20.9 19.3 15.8 10.9 19.5 18.0 14.7 10.2

kW 1.04 1.07 1.10 1.14 1.13 1.16 1.20 1.24 1.21 1.23 1.28 1.32 1.27 1.30 1.35 1.40 1.33 1.36 1.41 1.46 1.38 1.41 1.46 1.52

Amps 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.2 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8

 208 224 236 246 233 251 265 276 265 285 301 314 302 325 343 358 340 366 386 403 376 404 427 445

 105 112 122 130 111 118 129 137 115 123 134 142 121 129 141 150 127 135 147 157 131 140 152 162

650

MBh 17.2 17.7 19.2 20.6 16.8 17.3 18.7 20.1 16.4 16.9 18.3 19.6 16.0 16.5 17.9 19.2 15.2 15.7 17.0 18.2 14.1 14.5 15.7 16.9

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

 20.2 18.6 15.2 10.5 20.4 18.8 15.4 10.7 20.5 18.8 15.4 10.7 20.6 19.0 15.5 10.7 20.3 18.7 15.3 10.6 19.0 17.5 14.3 9.9

kW 1.06 1.08 1.12 1.16 1.15 1.17 1.21 1.26 1.22 1.25 1.30 1.34 1.29 1.32 1.37 1.42 1.35 1.38 1.43 1.48 1.40 1.44 1.49 1.54

Amps 4.4 4.5 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9

 211 228 240 251 237 255 270 281 270 290 307 320 307 331 349 364 346 372 393 410 382 411 434 453

 107 114 124 132 113 120 131 139 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165

  

 

Expanded Cooling Data — GSX130181E* / CAPF1824B6DB

4www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 5

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

525

MBh 16.2 16.5 17.7 18.9 15.8 16.1 17.3 18.4 15.4 15.8 16.8 18.0 15.0 15.4 16.4 17.6 14.3 14.6 15.6 16.7 13.2 13.5 14.5 15.5

S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.01 0.94 0.77 0.57

 24.8 23.8 20.7 16.5 25.2 24.1 21.0 16.7 25.2 24.1 21.0 16.8 25.4 24.3 21.1 16.9 25.0 24.0 20.8 16.6 23.4 22.4 19.5 15.5

kW 1.04 1.06 1.10 1.14 1.13 1.15 1.19 1.23 1.20 1.23 1.27 1.32 1.27 1.30 1.35 1.39 1.33 1.36 1.41 1.46 1.38 1.41 1.46 1.51

Amps 4.3 4.4 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.2 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8

 207 223 235 246 232 250 264 276 264 285 300 313 301 324 342 357 339 365 385 402 374 403 425 444

 105 111 121 129 110 118 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162

600

MBh 17.0 17.4 18.6 19.8 16.6 17.0 18.1 19.4 16.2 16.6 17.7 18.9 15.8 16.2 17.3 18.5 15.0 15.4 16.4 17.5 13.9 14.2 15.2 16.2

S/T 0.89 0.84 0.68 0.51 0.92 0.87 0.70 0.53 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58

 23.2 22.2 19.3 15.5 23.5 22.5 19.6 15.6 23.5 22.5 19.6 15.7 23.7 22.7 19.7 15.8 23.0 22.4 19.5 15.5 21.3 20.9 18.2 14.5

kW 1.05 1.08 1.11 1.15 1.14 1.17 1.21 1.25 1.22 1.25 1.29 1.33 1.28 1.32 1.36 1.41 1.34 1.38 1.42 1.48 1.39 1.43 1.48 1.53

Amps 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.9 6.1 5.9 6.0 6.2 6.5 6.2 6.4 6.6 6.9

 210 226 239 249 236 254 268 279 268 288 304 318 305 328 347 362 343 369 390 407 379 408 431 450

 106 113 123 131 112 119 130 138 116 124 135 144 122 130 142 151 128 136 149 158 132 141 154 164

650

MBh 17.5 17.9 19.1 20.5 17.1 17.5 18.7 20.0 16.7 17.1 18.2 19.5 16.3 16.7 17.8 19.0 15.5 15.8 16.9 18.1 14.3 14.7 15.7 16.7

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.80 0.60

 22.5 21.6 18.8 15.0 22.8 21.9 19.0 15.2 22.8 21.9 19.0 15.2 23.1 22.0 19.2 15.3 21.9 22.4 18.9 15.1 20.3 20.7 17.7 14.1

kW 1.07 1.09 1.13 1.17 1.16 1.18 1.22 1.27 1.24 1.26 1.31 1.36 1.30 1.34 1.38 1.43 1.36 1.40 1.45 1.50 1.42 1.45 1.50 1.55

Amps 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.4 5.6 5.8 5.6 5.8 5.9 6.2 6.0 6.1 6.3 6.6 6.3 6.5 6.7 7.0

 214 230 243 253 240 258 272 284 273 293 310 323 310 334 353 368 349 376 397 414 386 415 439 457

 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167

525

MBh 16.5 16.8 17.6 18.7 16.1 16.4 17.2 18.3 15.7 16.0 16.8 17.9 15.3 15.6 16.3 17.4 14.5 14.8 15.5 16.6 13.5 13.7 14.4 15.3

S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75

 26.5 26.1 24.6 21.3 26.8 26.4 24.9 21.6 26.9 26.4 25.0 21.6 26.8 26.6 25.1 21.8 25.5 26.0 24.8 21.5 23.6 24.1 23.2 20.0

kW 1.05 1.07 1.11 1.15 1.14 1.16 1.20 1.24 1.21 1.24 1.28 1.33 1.28 1.31 1.36 1.41 1.34 1.37 1.42 1.47 1.39 1.42 1.47 1.53

Amps 4.4 4.5 4.6 4.8 4.7 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.6 5.8 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8

 209 225 238 248 235 253 267 278 267 287 303 317 304 327 346 361 342 368 389 406 378 407 430 448

 106 112 123 131 112 119 130 138 116 123 135 143 122 130 141 151 128 136 148 158 132 140 153 163

600

MBh 17.3 17.6 18.5 19.7 16.9 17.2 18.0 19.2 16.5 16.8 17.6 18.8 16.1 16.4 17.2 18.3 15.3 15.6 16.3 17.4 14.2 14.4 15.1 16.1

S/T 0.93 0.90 0.81 0.66 0.97 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.93 0.75 1.00 1.00 0.93 0.76

 24.8 24.3 23.0 19.9 25.1 24.6 23.3 20.2 25.1 24.7 23.3 20.2 24.7 24.8 23.5 20.3 23.4 23.9 23.2 20.0 21.7 22.1 21.6 18.7

kW 1.06 1.08 1.12 1.16 1.15 1.18 1.22 1.26 1.23 1.26 1.30 1.35 1.30 1.33 1.37 1.42 1.36 1.39 1.44 1.49 1.41 1.44 1.49 1.54

Amps 4.4 4.5 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.7 6.9

 212 228 241 251 238 256 270 282 271 291 308 321 308 332 350 365 347 373 394 411 383 412 435 454

 107 114 124 132 113 120 131 140 118 125 136 145 123 131 143 153 129 138 150 160 134 142 155 166

650

MBh 17.8 18.2 19.0 20.3 17.4 17.8 18.6 19.8 17.0 17.3 18.2 19.4 16.6 16.9 17.7 18.9 15.8 16.1 16.8 18.0 14.6 14.9 15.6 16.6

S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.95 0.77

 24.1 23.7 22.4 19.4 24.3 23.9 22.6 19.6 24.1 24.0 22.7 19.6 23.5 23.9 22.8 19.7 22.3 22.7 22.5 19.5 20.6 21.0 21.0 18.2

kW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.28 1.25 1.28 1.32 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.46 1.51 1.57

Amps 4.5 4.6 4.8 4.9 4.9 5.0 5.2 5.4 5.3 5.4 5.6 5.8 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6 6.4 6.6 6.8 7.0

 216 232 245 256 242 261 275 287 275 296 313 326 314 337 356 372 353 380 401 418 390 419 443 462

 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168

  

Expanded Cooling Data — GSX130181E* / CAPF1824B6DB (cont.)

6www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 7

Expanded Cooling Data — GSX130241E* / CA*F3030*6D*

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

900

MBh 22.5 23.4 25.6 -22.0 22.8 25.0 -21.5 22.3 24.4 -21.0 21.7 23.8 -19.9 20.6 22.6 -18.4 19.1 21.0 -

S/T 0.73 0.61 0.42 -0.76 0.63 0.44 -0.78 0.65 0.45 -0.80 0.67 0.46 -0.83 0.69 0.48 -0.84 0.70 0.49 -

∆T 17 15 11 -17 15 11 -17 15 11 -17 15 11 -17 15 11 -16 14 10 -

kW 1.63 1.66 1.71 -1.75 1.78 1.83 -1.85 1.89 1.95 -1.94 1.98 2.04 -2.02 2.06 2.13 -2.09 2.13 2.20 -

Amps 5.8 6.0 6.2 -6.3 6.4 6.7 -6.8 7.0 7.2 -7.3 7.5 7.7 -7.8 8.0 8.2 -8.2 8.4 8.7 -

Hi PR 228 246 259 -256 276 291 -291 314 331 -332 357 377 -373 402 424 -413 444 469 -

Lo PR 105 112 122 -111 118 129 -115 123 134 -121 129 141 -127 135 147 -131 140 152 -

800

MBh 21.9 22.7 24.8 -21.4 22.2 24.3 -20.9 21.6 23.7 -20.4 21.1 23.1 -19.3 20.0 22.0 -17.9 18.6 20.3 -

S/T 0.70 0.58 0.40 -0.72 0.60 0.42 -0.74 0.62 0.43 -0.76 0.64 0.44 -0.79 0.66 0.46 -0.80 0.67 0.46 -

∆T 18 15 12 -18 15 12 -18 15 12 -18 15 12 -18 15 12 -16 14 11 -

kW 1.62 1.65 1.70 -1.73 1.77 1.82 -1.84 1.87 1.93 -1.93 1.97 2.03 -2.00 2.05 2.11 -2.07 2.11 2.18 -

Amps 5.8 5.9 6.1 -6.2 6.4 6.6 -6.8 6.9 7.2 -7.2 7.4 7.7 -7.7 7.9 8.1 -8.2 8.4 8.6 -

Hi PR 226 243 257 -254 273 288 -288 310 328 -329 354 373 -370 398 420 -408 440 464 -

Lo PR 104 111 121 -110 117 127 -114 121 132 -120 127 139 -126 134 146 -130 138 151 -

700

MBh 20.2 20.9 22.9 -19.7 20.4 22.4 -19.3 20.0 21.9 -18.8 19.5 21.3 -17.8 18.5 20.3 -16.5 17.1 18.8 -

S/T 0.67 0.56 0.39 -0.70 0.58 0.40 -0.71 0.60 0.41 -0.74 0.62 0.43 -0.76 0.64 0.44 -0.77 0.64 0.45 -

∆T 18 15 12 -18 16 12 -18 16 12 -18 16 12 -18 16 12 -17 14 11 -

kW 1.58 1.61 1.66 -1.69 1.73 1.78 -1.79 1.83 1.89 -1.88 1.92 1.98 -1.96 2.00 2.06 -2.02 2.06 2.13 -

Amps 5.6 5.7 5.9 -6.1 6.2 6.4 -6.6 6.7 7.0 -7.0 7.2 7.4 -7.5 7.7 7.9 -7.9 8.1 8.4 -

Hi PR 219 236 249 -246 265 280 -280 301 318 -319 343 362 -359 386 407 -396 426 450 -

Lo PR 101 107 117 -106 113 124 -111 118 129 -116 124 135 -122 130 141 -126 134 146 -

900

MBh 22.9 23.6 25.5 27.4 22.4 23.0 24.9 26.8 21.9 22.5 24.4 26.1 21.3 22.0 23.8 25.5 20.3 20.9 22.6 24.2 18.8 19.3 20.9 22.4

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.95 0.85 0.64 0.41 0.95 0.85 0.65 0.42

∆T 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 18 17 14 10

kW 1.64 1.67 1.72 1.77 1.76 1.79 1.85 1.91 1.86 1.90 1.96 2.02 1.96 2.00 2.06 2.13 2.04 2.08 2.15 2.21 2.10 2.15 2.22 2.29

Amps 5.9 6.0 6.2 6.4 6.3 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1

Hi PR 231 248 262 273 259 279 294 307 294 317 334 349 335 361 381 397 377 406 429 447 417 448 474 494

Lo PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164

800

MBh 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 21.2 21.8 23.6 25.4 20.7 21.3 23.1 24.8 19.7 20.2 21.9 23.5 18.2 18.8 20.3 21.8

S/T 0.79 0.71 0.54 0.34 0.82 0.73 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40

∆T 20 19 15 11 20 19 15 11 21 19 15 11 21 19 16 11 20 19 15 11 19 18 14 10

kW 1.63 1.66 1.71 1.76 1.75 1.78 1.84 1.89 1.85 1.89 1.95 2.01 1.94 1.98 2.04 2.11 2.02 2.06 2.13 2.20 2.09 2.13 2.20 2.27

Amps 5.8 6.0 6.2 6.4 6.3 6.4 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.5 7.7 8.0 7.8 8.0 8.2 8.5 8.2 8.4 8.7 9.1

Hi PR 228 246 260 271 256 276 291 304 291 314 331 345 332 357 377 393 373 402 424 443 413 444 469 489

Lo PR 105 112 122 130 111 118 129 137 115 123 134 143 121 129 141 150 127 135 147 157 131 140 152 162

700

MBh 20.5 21.1 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.2 21.8 23.4 19.1 19.7 21.3 22.9 18.2 18.7 20.2 21.7 16.8 17.3 18.7 20.1

S/T 0.76 0.68 0.52 0.33 0.79 0.71 0.54 0.34 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.88 0.78 0.59 0.38

∆T 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10

kW 1.59 1.62 1.67 1.72 1.71 1.74 1.79 1.85 1.81 1.84 1.90 1.96 1.90 1.94 2.00 2.06 1.97 2.01 2.08 2.14 2.04 2.08 2.15 2.22

Amps 5.7 5.8 6.0 6.2 6.1 6.3 6.5 6.7 6.6 6.8 7.0 7.3 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3 8.0 8.2 8.5 8.8

Hi PR 222 238 252 263 249 267 282 295 283 304 321 335 322 346 366 382 362 390 412 429 400 431 455 474

Lo PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan)

High and low pressures are measured at the liquid and sucon service valves. kW = Total system power

6www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 7

Expanded Cooling Data — GSX130241E* / CA*F3030*6D* (cont.)

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

900

MBh 23.3 23.8 25.5 27.2 22.8 23.3 24.9 26.6 22.2 22.7 24.3 26.0 21.7 22.2 23.7 25.3 20.6 21.1 22.5 24.1 19.1 19.5 20.8 22.3

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.80 0.60

∆T 22 21 18 14 22 21 18 15 22 21 18 15 22 21 18 15 21 22 18 15 20 20 17 14

kW 1.65 1.69 1.74 1.79 1.77 1.81 1.86 1.92 1.88 1.92 1.98 2.04 1.97 2.01 2.08 2.14 2.05 2.10 2.16 2.23 2.12 2.17 2.24 2.31

Amps 5.9 6.1 6.3 6.5 6.4 6.6 6.8 7.0 7.0 7.1 7.4 7.6 7.4 7.6 7.9 8.2 7.9 8.1 8.4 8.7 8.4 8.6 8.9 9.2

Hi PR 233 251 265 276 261 281 297 310 297 320 338 352 339 364 385 401 381 410 433 452 421 453 478 499

Lo PR 107 114 124 132 113 120 131 140 118 125 137 145 123 131 143 153 129 138 150 160 134 142 155 166

800

MBh 22.6 23.1 24.7 26.4 22.1 22.6 24.2 25.8 21.6 22.1 23.6 25.2 21.1 21.5 23.0 24.6 20.0 20.5 21.9 23.4 18.5 18.9 20.2 21.6

S/T 0.87 0.81 0.66 0.50 0.90 0.84 0.69 0.51 0.92 0.87 0.70 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.75 0.56 1.00 0.93 0.76 0.57

∆T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14

kW 1.64 1.67 1.72 1.78 1.76 1.79 1.85 1.91 1.86 1.90 1.96 2.02 1.96 2.00 2.06 2.13 2.04 2.08 2.15 2.21 2.10 2.15 2.22 2.29

Amps 5.9 6.0 6.2 6.4 6.3 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1

Hi PR 231 248 262 273 259 279 294 307 294 317 335 349 335 361 381 397 377 406 429 447 417 448 474 494

Lo PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164

700

MBh 20.9 21.4 22.8 24.4 20.4 20.9 22.3 23.8 19.9 20.4 21.8 23.3 19.4 19.9 21.2 22.7 18.5 18.9 20.2 21.6 17.1 17.5 18.7 20.0

S/T 0.84 0.79 0.64 0.48 0.87 0.81 0.66 0.50 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.96 0.90 0.73 0.55

∆T 23 22 19 15 23 22 19 15 23 22 19 16 23 22 20 16 23 22 19 15 22 21 18 14

kW 1.60 1.63 1.68 1.73 1.72 1.75 1.81 1.86 1.82 1.86 1.92 1.98 1.91 1.95 2.01 2.08 1.99 2.03 2.09 2.16 2.05 2.10 2.16 2.23

Amps 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.9 7.1 7.4 7.2 7.3 7.6 7.9 7.6 7.8 8.1 8.4 8.1 8.3 8.6 8.9

Hi PR 224 241 254 265 251 270 285 298 286 307 324 338 325 350 370 385 366 394 416 434 404 435 459 479

Lo PR 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159

900

MBh 23.7 24.2 25.3 27.0 23.2 23.6 24.8 26.4 22.6 23.1 24.2 25.8 22.1 22.5 23.6 25.1 21.0 21.4 22.4 23.9 19.4 19.8 20.7 22.1

S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.95 0.77

∆T 23 23 22 19 23 23 22 19 23 23 22 19 23 23 22 19 21 22 22 19 20 20 20 17

kW 1.66 1.70 1.75 1.80 1.79 1.82 1.88 1.94 1.89 1.93 1.99 2.06 1.99 2.03 2.09 2.16 2.07 2.11 2.18 2.25 2.14 2.18 2.25 2.33

Amps 6.0 6.1 6.3 6.6 6.5 6.6 6.8 7.1 7.0 7.2 7.4 7.7 7.5 7.7 7.9 8.2 8.0 8.2 8.5 8.8 8.5 8.7 9.0 9.3

Hi PR 235 253 267 279 264 284 300 313 300 323 341 356 342 368 389 405 385 414 437 456 425 457 483 504

Lo PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167

800

MBh 23.0 23.5 24.6 26.2 22.5 22.9 24.0 25.6 22.0 22.4 23.5 25.0 21.4 21.9 22.9 24.4 20.4 20.8 21.7 23.2 18.9 19.2 20.1 21.5

S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74

∆T 24 24 22 19 24 24 23 20 24 24 23 20 25 24 23 20 23 24 23 20 22 22 21 18

kW 1.65 1.69 1.74 1.79 1.77 1.81 1.86 1.92 1.88 1.92 1.98 2.04 1.97 2.01 2.08 2.14 2.05 2.10 2.16 2.23 2.12 2.17 2.24 2.31

Amps 5.9 6.1 6.3 6.5 6.4 6.6 6.8 7.0 7.0 7.1 7.4 7.6 7.4 7.6 7.9 8.2 7.9 8.1 8.4 8.7 8.4 8.6 8.9 9.2

Hi PR 233 251 265 276 261 281 297 310 297 320 338 352 339 364 385 401 381 410 433 452 421 453 478 499

Lo PR 107 114 124 132 113 120 131 140 118 125 137 145 123 131 143 153 129 138 150 160 134 142 155 166

700

MBh 21.3 21.7 22.7 24.2 20.8 21.2 22.2 23.7 20.3 20.7 21.7 23.1 19.8 20.2 21.1 22.5 18.8 19.2 20.1 21.4 17.4 17.7 18.6 19.8

S/T 0.88 0.85 0.76 0.62 0.91 0.88 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.97 0.88 0.71

∆T 25 24 23 20 25 24 23 20 25 24 23 20 25 25 23 20 25 24 23 20 23 23 21 19

kW 1.61 1.65 1.70 1.75 1.73 1.77 1.82 1.88 1.83 1.87 1.93 1.99 1.93 1.97 2.03 2.09 2.00 2.05 2.11 2.18 2.07 2.11 2.18 2.25

Amps 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.8 6.9 7.2 7.4 7.2 7.4 7.7 7.9 7.7 7.9 8.1 8.5 8.2 8.4 8.6 9.0

Hi PR 226 243 257 268 254 273 288 301 288 310 328 342 328 353 373 389 370 398 420 438 408 439 464 484

Lo PR 104 110 121 128 110 117 127 136 114 121 132 141 120 127 139 148 126 134 146 155 130 138 151 161

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI condions Amps = outdoor unit amps (comp.+fan)

High and low pressures are measured at the liquid and sucon service valves. kW = Total system power

8www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 9

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

945

MBh 26.2 27.2 29.8 - 25.6 26.6 29.1 - 25.0 25.9 28.4 - 24.4 25.3 27.7 - 23.2 24.0 26.3 - 21.5 22.3 24.4 -

S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -

 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

kW 2.01 2.05 2.11 - 2.15 2.20 2.26 - 2.28 2.33 2.40 - 2.39 2.44 2.51 - 2.48 2.54 2.62 - 2.57 2.62 2.70 -

Amps 6.9 7.1 7.3 - 7.5 7.7 8.0 - 8.2 8.4 8.7 - 8.7 9.0 9.3 - 9.3 9.5 9.9 - 9.9 10.1 10.5 -

 244 262 277 - 274 294 311 - 311 335 354 - 354 381 403 - 399 429 453 - 440 474 501 -

 104 110 120 - 109 116 127 - 114 121 132 - 119 127 139 - 125 133 145 - 129 138 150 -

1050

MBh 26.6 27.6 30.3 - 26.0 27.0 29.5 - 25.4 26.3 28.8 - 24.8 25.7 28.1 - 23.5 24.4 26.7 - 21.8 22.6 24.8 -

S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -

 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -

kW 2.04 2.08 2.14 - 2.18 2.23 2.29 - 2.31 2.36 2.43 - 2.42 2.47 2.55 - 2.52 2.57 2.65 - 2.60 2.66 2.74 -

Amps 7.0 7.2 7.5 - 7.6 7.8 8.1 - 8.3 8.5 8.8 - 8.9 9.1 9.4 - 9.5 9.7 10.0 - 10.0 10.3 10.6 -

 248 267 282 - 278 299 316 - 317 341 360 - 360 388 410 - 406 436 461 - 448 482 509 -

 105 112 122 - 111 118 129 - 116 123 134 - 122 129 141 - 127 135 148 - 132 140 153 -

1155

MBh 27.0 28.0 30.7 - 26.4 27.4 30.0 - 25.8 26.7 29.3 - 25.2 26.1 28.6 - 23.9 24.8 27.1 - 22.1 22.9 25.1 -

S/T 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.88 0.74 0.51 -

 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 14 11 - 16 13 10 -

kW 2.05 2.09 2.15 - 2.19 2.24 2.30 - 2.32 2.37 2.44 - 2.44 2.49 2.56 - 2.53 2.59 2.67 - 2.62 2.67 2.76 -

Amps 7.1 7.3 7.5 - 7.7 7.9 8.1 - 8.4 8.6 8.9 - 8.9 9.2 9.5 - 9.5 9.8 10.1 - 10.1 10.4 10.7 -

 250 269 284 - 280 302 318 - 319 343 362 - 363 391 413 - 408 439 464 - 451 486 513 -

 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 133 141 154 -

945

MBh 26.7 27.5 29.7 31.9 26.1 26.8 29.0 31.2 25.4 26.2 28.4 30.4 24.8 25.6 27.7 29.7 23.6 24.3 26.3 28.2 21.8 22.5 24.3 26.1

S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40

 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10

kW 2.03 2.07 2.13 2.19 2.17 2.21 2.28 2.35 2.30 2.34 2.42 2.49 2.41 2.46 2.53 2.61 2.50 2.56 2.64 2.72 2.59 2.64 2.72 2.81

Amps 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.2 8.5 8.7 9.1 8.8 9.0 9.3 9.7 9.4 9.6 10.0 10.3 10.0 10.2 10.6 11.0

 246 265 280 292 276 297 314 328 314 338 357 373 358 385 407 424 403 433 458 477 445 479 506 527

 105 111 121 129 111 118 128 137 115 122 133 142 121 128 140 149 126 135 147 156 131 139 152 162

1050

MBh 27.1 27.9 30.2 32.4 26.5 27.2 29.5 31.6 25.8 26.6 28.8 30.9 25.2 25.9 28.1 30.1 23.9 24.6 26.7 28.6 22.2 22.8 24.7 26.5

S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42

 20 18 15 10 20 19 15 10 20 19 15 10 20 19 15 11 20 18 15 10 19 17 14 10

kW 2.05 2.09 2.15 2.22 2.20 2.24 2.31 2.38 2.33 2.38 2.45 2.52 2.44 2.49 2.57 2.65 2.54 2.59 2.67 2.76 2.62 2.68 2.76 2.85

Amps 7.1 7.3 7.5 7.8 7.7 7.9 8.2 8.5 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.1 10.4 10.7 11.2

 251 270 285 297 281 303 319 333 320 344 363 379 364 392 414 432 410 441 466 486 453 487 514 536

 106 113 124 132 112 120 131 139 117 124 136 145 123 131 143 152 129 137 149 159 133 142 155 165

1155

MBh 27.5 28.3 30.6 32.9 26.9 27.7 29.9 32.1 26.2 27.0 29.2 31.4 25.6 26.3 28.5 30.6 24.3 25.0 27.1 29.1 22.5 23.2 25.1 26.9

S/T 0.88 0.78 0.59 0.38 0.91 0.81 0.61 0.40 0.93 0.83 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.89 0.67 0.43 1.00 0.90 0.68 0.44

 19 18 14 10 19 18 15 10 19 18 15 10 20 18 15 10 19 18 15 10 18 17 14 9

kW 2.06 2.10 2.16 2.23 2.21 2.25 2.32 2.39 2.34 2.39 2.46 2.54 2.45 2.51 2.58 2.67 2.55 2.61 2.69 2.77 2.64 2.69 2.78 2.87

Amps 7.2 7.3 7.6 7.9 7.8 7.9 8.2 8.5 8.4 8.6 8.9 9.3 9.0 9.2 9.6 9.9 9.6 9.9 10.2 10.6 10.2 10.5 10.8 11.2

 252 272 287 299 283 305 322 336 322 346 366 382 367 395 417 435 413 444 469 489 456 491 518 540

 107 114 124 133 113 120 131 140 118 125 137 146 124 131 144 153 130 138 150 160 134 143 156 166

Expanded Cooling Data — GSX130301B* / CA*F3030*6D*

8www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 9

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

945

MBh 27.2 27.8 29.6 31.7 26.5 27.1 29.0 31.0 25.9 26.5 28.3 30.2 25.3 25.8 27.6 29.5 24.0 24.5 26.2 28.0 22.2 22.7 24.3 25.9

S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.56 1.01 0.95 0.77 0.58 1.00 0.95 0.78 0.58

 23 22 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15

kW 2.04 2.08 2.14 2.21 2.19 2.23 2.30 2.37 2.31 2.36 2.43 2.51 2.43 2.48 2.56 2.64 2.52 2.58 2.66 2.74 2.61 2.66 2.75 2.83

Amps 7.1 7.2 7.5 7.8 7.7 7.8 8.1 8.4 8.3 8.5 8.8 9.2 8.9 9.1 9.4 9.8 9.5 9.7 10.1 10.4 10.1 10.3 10.7 11.1

 249 268 283 295 279 300 317 331 317 342 361 376 362 389 411 429 407 438 462 482 449 484 511 533

 106 112 123 131 112 119 130 138 116 123 135 144 122 130 142 151 128 136 148 158 132 141 153 163

1050

MBh 27.6 28.2 30.1 32.2 26.9 27.5 29.4 31.4 26.3 26.9 28.7 30.7 25.6 26.2 28.0 29.9 24.4 24.9 26.6 28.4 22.6 23.1 24.6 26.3

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.98 0.80 0.60 1.00 0.99 0.81 0.60

 22 21 18 15 22 22 19 15 22 22 19 15 22 22 19 15 21 21 19 15 20 20 17 14

kW 2.07 2.11 2.17 2.23 2.21 2.26 2.33 2.40 2.35 2.39 2.47 2.54 2.46 2.51 2.59 2.67 2.56 2.61 2.69 2.78 2.64 2.70 2.78 2.87

Amps 7.2 7.4 7.6 7.9 7.8 8.0 8.2 8.5 8.5 8.7 9.0 9.3 9.1 9.3 9.6 10.0 9.6 9.9 10.2 10.6 10.2 10.5 10.8 11.3

 253 272 288 300 284 306 323 337 323 348 367 383 368 396 418 436 414 445 470 490 457 492 520 542

 107 114 125 133 114 121 132 140 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166

1155

MBh 28.0 28.6 30.6 32.7 27.3 27.9 29.8 31.9 26.7 27.3 29.1 31.1 26.0 26.6 28.4 30.4 24.7 25.3 27.0 28.9 22.9 23.4 25.0 26.7

S/T 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63

 21 21 18 14 22 21 18 14 21 21 18 14 21 21 18 15 20 20 18 14 18 19 17 13

kW 2.08 2.12 2.18 2.25 2.23 2.27 2.34 2.41 2.36 2.41 2.48 2.56 2.47 2.53 2.60 2.69 2.57 2.63 2.71 2.80 2.66 2.71 2.80 2.89

Amps 7.2 7.4 7.7 7.9 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.3 9.7 10.0 9.7 9.9 10.3 10.7 10.3 10.6 10.9 11.3

 255 274 290 302 286 308 325 339 325 350 370 385 370 399 421 439 417 448 474 494 460 495 523 546

 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167

945

MBh 27.6 28.2 29.5 31.5 27.0 27.5 28.8 30.7 26.3 26.9 28.1 30.0 25.7 26.2 27.4 29.3 24.4 24.9 26.1 27.8 22.6 23.1 24.1 25.8

S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75

 25 25 23 20 25 25 24 20 25 25 24 20 25 25 24 21 24 24 23 20 22 22 22 19

kW 2.06 2.10 2.16 2.22 2.20 2.25 2.31 2.39 2.33 2.38 2.45 2.53 2.45 2.50 2.58 2.66 2.54 2.60 2.68 2.76 2.63 2.68 2.77 2.86

Amps 7.1 7.3 7.6 7.8 7.7 7.9 8.2 8.5 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.2 10.5 10.2 10.4 10.8 11.2

 251 270 286 298 282 303 320 334 321 345 364 380 365 393 415 433 411 442 467 487 454 489 516 538

 107 114 124 132 113 120 131 139 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165

1050

MBh 28.1 28.6 29.9 32.0 27.4 27.9 29.3 31.2 26.7 27.3 28.6 30.5 26.1 26.6 27.9 29.7 24.8 25.3 26.5 28.2 23.0 23.4 24.5 26.2

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78

 24 23 22 19 24 24 22 19 23 24 22 19 23 23 22 19 22 22 22 19 20 20 21 18

kW 2.08 2.12 2.19 2.25 2.23 2.28 2.35 2.42 2.36 2.41 2.49 2.56 2.48 2.53 2.61 2.69 2.58 2.63 2.72 2.80 2.66 2.72 2.81 2.90

Amps 7.2 7.4 7.7 8.0 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.4 9.7 10.1 9.7 10.0 10.3 10.7 10.3 10.6 10.9 11.4

 256 275 290 303 287 309 326 340 326 351 371 387 372 400 422 440 418 450 475 495 462 497 525 547

 109 116 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 140 152 162 136 144 158 168

1155

MBh 28.5 29.0 30.4 32.4 27.8 28.4 29.7 31.7 27.1 27.7 29.0 30.9 26.5 27.0 28.3 30.2 25.2 25.7 26.9 28.7 23.3 23.8 24.9 26.5

S/T 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.93 0.76 1.00 1.00 0.96 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82

 23 22 21 18 22 23 21 19 22 22 21 19 21 21 22 19 20 20 21 18 19 19 20 17

kW 2.09 2.13 2.20 2.26 2.24 2.29 2.36 2.43 2.38 2.43 2.50 2.58 2.49 2.55 2.62 2.71 2.59 2.65 2.73 2.82 2.68 2.74 2.82 2.91

Amps 7.3 7.5 7.7 8.0 7.9 8.1 8.4 8.7 8.6 8.8 9.1 9.5 9.2 9.4 9.7 10.1 9.8 10.0 10.4 10.8 10.4 10.7 11.0 11.4

 257 277 292 305 289 311 328 342 328 353 373 389 374 403 425 443 421 453 478 499 465 500 528 551

 109 116 127 135 116 123 134 143 120 128 139 148 126 134 146 156 132 141 153 163 137 145 159 169

Expanded Cooling Data — GSX130301B* / CA*F3030*6D* (cont.)

10 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 11

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1350

MBh 32.9 34.1 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.7 - 30.6 31.7 34.8 - 29.1 30.2 33.0 - 27.0 27.9 30.6 -

S/T 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.74 0.51 - 0.89 0.74 0.51 -

 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -

kW 2.44 2.49 2.55 - 2.61 2.65 2.73 - 2.75 2.80 2.88 - 2.88 2.94 3.02 - 2.99 3.05 3.14 - 3.08 3.14 3.24 -

 9.7 9.9 10.0 - 10.1 10.3 10.5 - 10.6 10.8 11.0 - 11.0 11.2 11.4 - 11.4 11.6 11.8 - 11.8 12.0 12.2 -

 183 197 208 - 205 221 234 - 234 252 266 - 266 286 302 - 299 322 340 - 331 356 376 -

 95 101 110 - 100 107 117 - 104 111 121 - 110 117 127 - 115 122 134 - 119 126 138 -

1200

MBh 32.0 33.1 36.3 - 31.2 32.4 35.5 - 30.5 31.6 34.6 - 29.7 30.8 33.8 - 28.2 29.3 32.1 - 26.2 27.1 29.7 -

S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -

 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

kW 2.42 2.47 2.54 - 2.59 2.64 2.71 - 2.73 2.78 2.86 - 2.86 2.91 3.00 - 2.96 3.02 3.11 - 3.06 3.12 3.21 -

 9.7 9.8 10.0 - 10.1 10.2 10.4 - 10.6 10.7 10.9 - 11.0 11.1 11.3 - 11.4 11.5 11.8 - 11.8 11.9 12.2 -

 181 195 206 - 203 219 231 - 231 249 263 - 264 284 299 - 296 319 337 - 328 353 372 -

 94 100 109 - 99 106 116 - 103 110 120 - 109 116 126 - 114 121 132 - 118 125 137 -

1050

MBh 29.5 30.6 33.5 - 28.8 29.9 32.7 - 28.1 29.2 31.9 - 27.4 28.4 31.2 - 26.1 27.0 29.6 - 24.2 25.0 27.4 -

S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -

 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

kW 2.37 2.42 2.48 - 2.53 2.58 2.65 - 2.67 2.72 2.80 - 2.79 2.85 2.93 - 2.90 2.96 3.04 - 2.99 3.05 3.14 -

 9.6 9.7 9.8 - 10.0 10.1 10.3 - 10.4 10.5 10.7 - 10.8 10.9 11.1 - 11.2 11.3 11.6 - 11.6 11.7 12.0 -

 176 189 200 - 197 212 224 - 224 242 255 - 256 275 291 - 288 309 327 - 318 342 361 -

 91 97 106 - 96 103 112 - 100 107 116 - 105 112 122 - 110 117 128 - 114 121 133 -

1350

MBh 33.5 34.5 37.3 40.0 32.7 33.7 36.4 39.1 31.9 32.9 35.6 38.2 31.1 32.1 34.7 37.3 29.6 30.5 33.0 35.4 27.4 28.2 30.5 32.8

S/T 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.93 0.84 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.90 0.68 0.44 1.00 0.90 0.68 0.44

 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 19 15 11 19 17 14 10

kW 2.46 2.50 2.57 2.65 2.62 2.67 2.75 2.83 2.77 2.82 2.91 2.99 2.90 2.96 3.04 3.14 3.01 3.07 3.16 3.26 3.10 3.17 3.26 3.36

 9.8 9.9 10.1 10.3 10.2 10.3 10.5 10.7 10.7 10.8 11.0 11.3 11.1 11.2 11.4 11.7 11.5 11.7 11.9 12.2 11.9 12.1 12.3 12.6

 185 199 210 219 208 223 236 246 236 254 268 280 269 289 306 319 303 326 344 359 334 360 380 396

 96 102 112 119 101 108 118 126 105 112 123 130 111 118 129 137 116 124 135 144 120 128 139 149

1200

MBh 32.5 33.5 36.2 38.9 31.8 32.7 35.4 38.0 31.0 31.9 34.5 37.1 30.2 31.1 33.7 36.2 28.7 29.6 32.0 34.4 26.6 27.4 29.7 31.8

S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42

 21 19 16 11 21 19 16 11 21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10

kW 2.44 2.49 2.56 2.63 2.61 2.66 2.73 2.81 2.75 2.80 2.89 2.97 2.88 2.94 3.02 3.11 2.99 3.05 3.14 3.23 3.08 3.14 3.24 3.34

 9.7 9.9 10.0 10.2 10.1 10.3 10.5 10.7 10.6 10.8 11.0 11.2 11.0 11.2 11.4 11.6 11.4 11.6 11.8 12.1 11.8 12.0 12.2 12.5

 183 197 208 217 206 221 234 244 234 252 266 277 266 287 303 316 300 322 340 355 331 356 376 392

 95 101 110 118 100 107 117 124 104 111 121 129 110 117 127 136 115 122 134 142 119 127 138 147

1050

MBh 30.0 30.9 33.4 35.9 29.3 30.2 32.7 35.1 28.6 29.5 31.9 34.2 27.9 28.7 31.1 33.4 26.5 27.3 29.6 31.7 24.6 25.3 27.4 29.4

S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40

 21 20 16 11 21 20 16 11 22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 2.39 2.43 2.50 2.57 2.55 2.60 2.67 2.75 2.69 2.74 2.82 2.90 2.81 2.87 2.95 3.04 2.92 2.98 3.07 3.16 3.01 3.07 3.16 3.26

 9.6 9.7 9.9 10.1 10.0 10.1 10.3 10.5 10.5 10.6 10.8 11.0 10.8 11.0 11.2 11.4 11.2 11.4 11.6 11.9 11.6 11.8 12.0 12.3

 178 191 202 211 199 215 227 236 227 244 258 269 258 278 293 306 291 313 330 344 321 345 365 380

 92 98 107 114 97 104 113 121 101 108 118 125 106 113 124 132 112 119 130 138 115 123 134 143

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan)

  

Expanded Cooling Data — GSX130361E* / CA*F3636*6D*

10 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 11



     



IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1350

MBh 34.1 34.8 37.2 39.8 33.3 34.0 36.3 38.8 32.5 33.2 35.5 37.9 31.7 32.4 34.6 37.0 30.1 30.8 32.9 35.1 27.9 28.5 30.5 32.6

S/T 0.96 0.90 0.74 0.6 1.00 0.94 0.76 0.57 1.00 0.96 0.78 0.6 1.00 1.00 0.81 0.60 1.00 1.00 0.84 0.6 1.00 1.00 0.84 0.63

 22 21 19 15 23 22 19 15 22 22 19 15 22 22 19 15 21 21 19 15 19 19 18 14

kW 2.48 2.52 2.59 2.7 2.64 2.69 2.77 2.85 2.79 2.85 2.93 3.0 2.92 2.98 3.07 3.16 3.03 3.09 3.19 3.3 3.13 3.19 3.29 3.39

 9.8 10.0 10.1 10.3 10.2 10.4 10.6 10.8 10.7 10.9 11.1 11.3 11.1 11.3 11.5 11.8 11.5 11.7 12.0 12.2 12.0 12.1 12.4 12.7

 187 201 212 221.5 210 226 238 249 238 257 271 282.7 272 292 309 322 306 329 347 362.2 338 363 384 400

 97 103 113 120.0 103 109 119 127 107 113 124 131.8 112 119 130 138 117 125 136 145.1 121 129 141 150

1200

MBh 33.1 33.8 36.1 38.6 32.3 33.0 35.3 37.7 31.5 32.2 34.4 36.8 30.8 31.4 33.6 35.9 29.2 29.9 31.9 34.1 27.1 27.7 29.6 31.6

S/T 0.92 0.86 0.70 0.5 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.6 1.00 0.95 0.77 0.58 1.00 0.98 0.80 0.6 1.00 0.99 0.81 0.60

 23 22 19 16 24 23 20 16 24 23 20 16 24 23 20 16 22 22 20 16 21 21 18 15

kW 2.46 2.50 2.57 2.6 2.62 2.67 2.75 2.83 2.77 2.82 2.91 3.0 2.90 2.96 3.05 3.14 3.01 3.07 3.16 3.3 3.10 3.17 3.26 3.36

 9.8 9.9 10.1 10.3 10.2 10.3 10.5 10.7 10.7 10.8 11.0 11.3 11.1 11.2 11.5 11.7 11.5 11.7 11.9 12.2 11.9 12.1 12.3 12.6

 185 199 210 219.3 208 223 236 246 236 254 268 279.9 269 289 306 319 303 326 344 358.6 334 360 380 396

 96 102 112 118.8 102 108 118 126 105 112 123 130.5 111 118 129 137 116 124 135 143.6 120 128 140 149

1050

MBh 30.5 31.2 33.3 35.6 29.8 30.5 32.6 34.8 29.1 29.8 31.8 34.0 28.4 29.0 31.0 33.2 27.0 27.6 29.5 31.5 25.0 25.5 27.3 29.2

S/T 0.89 0.83 0.68 0.5 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.5 0.97 0.91 0.74 0.55 1.01 0.95 0.77 0.6 1.02 0.95 0.78 0.58

 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 19 15

kW 2.41 2.45 2.52 2.6 2.57 2.62 2.69 2.77 2.71 2.76 2.84 2.9 2.84 2.89 2.98 3.07 2.94 3.00 3.09 3.2 3.03 3.10 3.19 3.29

 9.7 9.8 9.9 10.1 10.0 10.2 10.4 10.6 10.5 10.6 10.8 11.1 10.9 11.1 11.3 11.5 11.3 11.5 11.7 11.9 11.7 11.9 12.1 12.4

 179 193 204 212.7 201 217 229 239 229 246 260 271.5 261 281 296 309 293 316 333 347.8 324 349 368 384

 93 99 108 115.3 98 105 114 122 102 109 119 126.6 107 114 125 133 113 120 131 139.3 117 124 135 144

1350

MBh 34.7 35.3 37.0 39.5 33.9 34.5 36.2 38.6 33.1 33.7 35.3 37.7 32.3 32.9 34.4 36.7 30.6 31.2 32.7 34.9 28.4 28.9 30.3 32.3

S/T 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82

 24 23 22 19 23 24 22 19 23 23 22 19 22 22 23 20 21 21 22 19 19 20 21 18

kW 2.49 2.54 2.61 2.68 2.66 2.71 2.79 2.87 2.81 2.87 2.95 3.04 2.94 3.00 3.09 3.19 3.06 3.12 3.21 3.31 3.15 3.22 3.31 3.42

 9.9 10.0 10.2 10.4 10.3 10.4 10.6 10.8 10.8 10.9 11.1 11.4 11.2 11.4 11.6 11.8 11.6 11.8 12.0 12.3 12.0 12.2 12.5 12.7

 189 203 214 224 212 228 241 251 241 259 274 285 274 295 312 325 309 332 351 366 341 367 387 404

 98 104 114 121 104 110 120 128 108 114 125 133 113 120 131 140 118 126 138 147 123 130 142 152

1200

MBh 33.7 34.3 35.9 38.3 32.9 33.5 35.1 37.5 32.1 32.7 34.3 36.6 31.3 31.9 33.4 35.7 29.7 30.3 31.8 33.9 27.6 28.1 29.4 31.4

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78

 25 24 23 20 25 25 23 20 25 25 23 20 24 24 24 20 23 23 23 20 21 22 22 19

kW 2.48 2.52 2.59 2.67 2.64 2.69 2.77 2.85 2.79 2.85 2.93 3.02 2.92 2.98 3.07 3.16 3.03 3.09 3.19 3.28 3.13 3.19 3.29 3.39

 9.8 10.0 10.1 10.3 10.2 10.4 10.6 10.8 10.7 10.9 11.1 11.3 11.1 11.3 11.5 11.8 11.5 11.7 12.0 12.2 12.0 12.1 12.4 12.7

 187 201 212 221 210 226 238 249 238 257 271 283 272 292 309 322 306 329 347 362 338 363 384 400

 97 103 113 120 103 109 119 127 107 113 124 132 112 119 130 138 117 125 136 145 121 129 141 150

1050

MBh 31.1 31.7 33.2 35.4 30.3 30.9 32.4 34.6 29.6 30.2 31.6 33.7 28.9 29.5 30.9 32.9 27.5 28.0 29.3 31.3 25.4 25.9 27.2 29.0

S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75

 25 25 24 20 26 25 24 21 26 25 24 21 25 25 24 21 24 25 24 20 22 23 22 19

kW 2.42 2.47 2.54 2.61 2.59 2.64 2.71 2.79 2.73 2.78 2.86 2.95 2.86 2.91 3.00 3.09 2.96 3.02 3.11 3.21 3.06 3.12 3.21 3.31

 9.7 9.8 10.0 10.2 10.1 10.2 10.4 10.6 10.6 10.7 10.9 11.1 11.0 11.1 11.3 11.6 11.4 11.5 11.7 12.0 11.8 11.9 12.2 12.5

 181 195 206 215 203 219 231 241 231 249 263 274 263 284 299 312 296 319 337 351 327 352 372 388

 94 100 109 116 99 106 115 123 103 110 120 128 109 115 126 134 114 121 132 141 118 125 137 146

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI condions Amps = outdoor unit amps (comp.+fan)

Expanded Cooling Data — GSX130361E* / CA*F3636*6D* (cont.)

12 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 13

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1225

MBh 36.0 37.3 40.9 - 35.2 36.4 39.9 - 34.3 35.6 39.0 - 33.5 34.7 38.0 - 31.8 33.0 36.1 - 29.5 30.5 33.5 -

S/T 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -

 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

kW 2.78 2.84 2.92 - 2.98 3.04 3.13 - 3.15 3.21 3.31 - 3.30 3.37 3.47 - 3.43 3.50 3.61 - 3.54 3.61 3.73 -

Amps 10.7 10.9 11.2 - 11.5 11.8 12.1 - 12.5 12.7 13.2 - 13.3 13.6 14.0 - 14.1 14.5 14.9 - 14.9 15.3 15.8 -

 209 225 238 - 235 253 267 - 267 288 304 - 304 328 346 - 343 369 389 - 378 407 430 -

 101 107 117 - 106 113 124 - 111 118 129 - 116 124 135 - 122 130 141 - 126 134 146 -

1400

MBh 39.0 40.4 44.3 - 38.1 39.5 43.3 - 37.2 38.5 42.2 - 36.3 37.6 41.2 - 34.5 35.7 39.1 - 31.9 33.1 36.3 -

S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -

 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

kW 2.84 2.90 2.98 - 3.05 3.11 3.20 - 3.22 3.29 3.39 - 3.38 3.45 3.55 - 3.51 3.58 3.70 - 3.63 3.70 3.82 -

Amps 10.9 11.2 11.6 - 11.8 12.1 12.5 - 12.8 13.1 13.5 - 13.7 14.0 14.4 - 14.5 14.9 15.3 - 15.4 15.7 16.2 -

 216 232 245 - 242 261 275 - 276 297 313 - 314 338 357 - 353 380 401 - 390 420 443 -

 104 111 121 - 110 117 127 - 114 121 132 - 120 127 139 - 126 134 146 - 130 138 151 -

1575

MBh 40.2 41.6 45.6 - 39.2 40.7 44.6 - 38.3 39.7 43.5 - 37.4 38.7 42.4 - 35.5 36.8 40.3 - 32.9 34.1 37.3 -

S/T 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -

 18 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -

kW 2.87 2.92 3.01 - 3.07 3.13 3.22 - 3.25 3.31 3.41 - 3.41 3.48 3.58 - 3.54 3.61 3.73 - 3.66 3.73 3.85 -

Amps 11.0 11.3 11.7 - 11.9 12.2 12.6 - 12.9 13.2 13.6 - 13.8 14.1 14.6 - 14.6 15.0 15.5 - 15.5 15.9 16.4 -

 218 235 248 - 245 263 278 - 278 300 316 - 317 341 360 - 357 384 405 - 394 424 448 -

 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 147 - 131 140 152 -

1225

MBh 36.6 37.7 40.8 43.8 35.8 36.8 39.9 42.8 34.9 35.9 38.9 41.8 34.1 35.1 38.0 40.7 32.4 33.3 36.1 38.7 30.0 30.9 33.4 35.8

S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.90 0.80 0.61 0.39

 21 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 16 11 20 19 15 10

kW 2.80 2.86 2.94 3.03 3.00 3.06 3.15 3.24 3.17 3.24 3.33 3.44 3.33 3.39 3.50 3.61 3.46 3.53 3.64 3.75 3.57 3.64 3.76 3.88

Amps 10.8 11.0 11.3 11.8 11.6 11.9 12.2 12.7 12.6 12.9 13.3 13.8 13.4 13.7 14.2 14.7 14.2 14.6 15.1 15.6 15.1 15.4 15.9 16.5

 212 228 240 251 237 256 270 281 270 291 307 320 308 331 350 365 346 372 393 410 382 411 434 453

 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157

1400

MBh 39.7 40.8 44.2 47.4 38.7 39.9 43.2 46.3 37.8 38.9 42.2 45.2 36.9 38.0 41.1 44.1 35.1 36.1 39.1 41.9 32.5 33.4 36.2 38.8

S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40

 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 2.87 2.92 3.01 3.10 3.07 3.13 3.22 3.32 3.25 3.31 3.41 3.52 3.41 3.48 3.58 3.70 3.54 3.61 3.73 3.84 3.66 3.73 3.85 3.97

Amps 11.0 11.3 11.7 12.1 11.9 12.2 12.6 13.0 12.9 13.2 13.6 14.1 13.8 14.1 14.6 15.1 14.6 15.0 15.5 16.1 15.5 15.9 16.4 17.0

 218 235 248 259 245 263 278 290 278 300 316 330 317 341 360 376 357 384 405 423 394 424 448 467

 105 112 122 130 111 118 129 137 115 123 134 143 121 129 141 150 127 135 147 157 131 140 152 162

1575

MBh 40.9 42.1 45.5 48.9 39.9 41.1 44.5 47.7 39.0 40.1 43.4 46.6 38.0 39.1 42.4 45.5 36.1 37.2 40.2 43.2 33.4 34.4 37.3 40.0

S/T 0.85 0.76 0.57 0.37 0.88 0.79 0.60 0.38 0.90 0.81 0.61 0.39 0.93 0.83 0.63 0.41 0.97 0.86 0.65 0.42 0.97 0.87 0.66 0.42

 20 19 15 11 20 19 15 11 21 19 15 11 21 19 16 11 20 19 15 11 19 18 14 10

kW 2.89 2.94 3.03 3.12 3.09 3.15 3.25 3.35 3.27 3.34 3.44 3.55 3.43 3.50 3.61 3.72 3.57 3.64 3.76 3.87 3.68 3.76 3.88 4.00

Amps 11.1 11.4 11.8 12.2 12.0 12.3 12.7 13.2 13.0 13.3 13.8 14.3 13.9 14.2 14.7 15.2 14.8 15.1 15.6 16.2 15.6 16.0 16.5 17.2

 220 237 250 261 247 266 281 293 281 303 320 333 320 345 364 380 360 388 409 427 398 428 452 472

 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164

Expanded Cooling Data — GSX130421B* / CA*F3642*6B*

12 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 13

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1225

MBh 37.3 38.1 40.7 43.5 36.4 37.2 39.7 42.5 35.5 36.3 38.8 41.5 34.7 35.4 37.8 40.5 32.9 33.6 36.0 38.4 30.5 31.2 33.3 35.6

S/T 0.86 0.80 0.65 0.49 0.89 0.83 0.68 0.51 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.56 0.98 0.92 0.75 0.56

 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 22 19 15

kW 2.82 2.88 2.96 3.05 3.02 3.08 3.17 3.27 3.20 3.26 3.36 3.46 3.35 3.42 3.53 3.64 3.48 3.56 3.67 3.78 3.60 3.67 3.79 3.91

Amps 10.8 11.1 11.4 11.9 11.7 12.0 12.4 12.8 12.7 13.0 13.4 13.9 13.5 13.8 14.3 14.8 14.4 14.7 15.2 15.8 15.2 15.6 16.1 16.7

 214 230 243 253 240 258 273 284 273 294 310 323 311 334 353 368 350 376 397 414 386 416 439 458

 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159

1400

MBh 40.4 41.3 44.1 47.1 39.4 40.3 43.1 46.0 38.5 39.3 42.0 44.9 37.6 38.4 41.0 43.8 35.7 36.5 39.0 41.6 33.0 33.8 36.1 38.6

S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58

 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 22 21 18 15

kW 2.89 2.94 3.03 3.12 3.09 3.15 3.25 3.35 3.27 3.34 3.44 3.55 3.43 3.50 3.61 3.72 3.57 3.64 3.76 3.88 3.68 3.76 3.88 4.01

Amps 11.1 11.4 11.8 12.2 12.0 12.3 12.7 13.2 13.0 13.3 13.8 14.3 13.9 14.2 14.7 15.2 14.8 15.1 15.6 16.2 15.6 16.0 16.5 17.2

 220 237 250 261 247 266 281 293 281 303 320 333 320 345 364 380 360 388 410 427 398 428 452 472

 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164

1575

MBh 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.4 39.6 40.5 43.3 46.3 38.7 39.5 42.2 45.1 36.7 37.6 40.1 42.9 34.0 34.8 37.2 39.7

S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.74 0.55 1.00 0.93 0.75 0.56 1.00 0.96 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.82 0.61

 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 22 19 15 20 20 18 14

kW 2.91 2.96 3.05 3.14 3.11 3.18 3.27 3.37 3.30 3.36 3.47 3.58 3.46 3.53 3.64 3.75 3.60 3.67 3.79 3.91 3.71 3.79 3.91 4.04

Amps 11.2 11.5 11.9 12.3 12.1 12.4 12.8 13.3 13.1 13.5 13.9 14.4 14.0 14.4 14.8 15.4 14.9 15.3 15.8 16.4 15.8 16.2 16.7 17.3

 223 240 253 264 250 269 284 296 284 306 323 337 324 348 368 383 364 392 414 431 402 433 457 477

 107 114 124 132 113 120 131 140 118 125 137 145 123 131 143 153 129 138 150 160 134 142 155 166

1225

MBh 37.9 38.6 40.5 43.2 37.0 37.7 39.5 42.2 36.2 36.9 38.6 41.2 35.3 36.0 37.7 40.2 33.5 34.2 35.8 38.2 31.0 31.6 33.1 35.4

S/T 0.90 0.87 0.78 0.63 0.93 0.90 0.81 0.66 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 0.99 0.90 0.73

 26 25 24 21 26 25 24 21 26 25 24 21 26 26 24 21 25 25 24 21 23 24 22 19

kW 2.84 2.90 2.98 3.07 3.04 3.11 3.20 3.29 3.22 3.29 3.39 3.49 3.38 3.45 3.55 3.66 3.51 3.58 3.70 3.81 3.63 3.70 3.82 3.94

Amps 10.9 11.2 11.6 12.0 11.8 12.1 12.5 12.9 12.8 13.1 13.5 14.0 13.6 14.0 14.4 15.0 14.5 14.9 15.3 15.9 15.4 15.7 16.2 16.8

 216 232 245 256 242 261 275 287 276 297 313 327 314 338 357 372 353 380 401 418 390 420 443 462

 104 110 121 128 110 117 127 136 114 121 132 141 120 127 139 148 126 134 146 155 130 138 151 161

1400

MBh 41.1 41.9 43.9 46.8 40.1 40.9 42.8 45.7 39.2 39.9 41.8 44.6 38.2 39.0 40.8 43.5 36.3 37.0 38.8 41.3 33.6 34.3 35.9 38.3

S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75

 25 25 23 20 25 25 24 20 25 25 24 20 25 25 24 21 24 24 23 20 22 23 22 19

kW 2.91 2.96 3.05 3.14 3.11 3.18 3.27 3.37 3.30 3.36 3.47 3.58 3.46 3.53 3.64 3.75 3.60 3.67 3.79 3.91 3.71 3.79 3.91 4.04

Amps 11.2 11.5 11.9 12.3 12.1 12.4 12.8 13.3 13.1 13.5 13.9 14.4 14.0 14.4 14.8 15.4 14.9 15.3 15.8 16.4 15.8 16.2 16.7 17.3

 223 240 253 264 250 269 284 296 284 306 323 337 324 348 368 383 364 392 414 431 402 433 457 477

 107 114 124 132 113 120 131 140 118 125 137 145 123 131 143 153 129 138 150 160 134 142 155 166

1575

MBh 42.3 43.1 45.2 48.2 41.3 42.1 44.1 47.1 40.3 41.1 43.1 45.9 39.4 40.1 42.0 44.8 37.4 38.1 39.9 42.6 34.6 35.3 37.0 39.4

S/T 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.97 0.78 1.00 1.00 0.98 0.79

 24 24 22 19 24 24 23 20 24 24 23 20 23 23 23 20 22 22 23 20 20 21 21 18

kW 2.93 2.99 3.07 3.17 3.14 3.20 3.30 3.40 3.32 3.39 3.49 3.60 3.49 3.56 3.67 3.78 3.62 3.70 3.82 3.94 3.74 3.82 3.94 4.07

Amps 11.3 11.6 12.0 12.4 12.2 12.5 12.9 13.4 13.3 13.6 14.0 14.5 14.2 14.5 15.0 15.5 15.0 15.4 15.9 16.5 15.9 16.3 16.9 17.5

 225 242 255 266 252 271 287 299 287 309 326 340 327 352 371 387 368 396 418 436 406 437 462 481

 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167

Expanded Cooling Data — GSX130421B* / CA*F3642*6B* (cont.)

14 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 15

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1400

MBh 40.4 41.9 45.9 - 39.5 40.9 44.8 - 38.5 39.9 43.7 - 37.6 38.9 42.7 - 35.7 37.0 40.5 - 33.1 34.3 37.5 -

S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -

 19 16 12 - 19 16 12 - 19 16 13 - 19 17 13 - 19 16 12 - 18 15 12 -

kW 3.17 3.23 3.32 - 3.39 3.46 3.56 - 3.59 3.66 3.77 - 3.77 3.84 3.96 - 3.91 4.00 4.12 - 4.04 4.13 4.26 -

Amps 11.6 11.9 12.3 - 12.6 12.9 13.3 - 13.7 14.0 14.5 - 14.6 15.0 15.5 - 15.5 15.9 16.5 - 16.5 16.9 17.4 -

 215 231 244 - 241 259 274 - 274 295 311 - 312 336 354 - 351 377 399 - 388 417 440 -

 104 111 121 - 110 117 128 - 115 122 133 - 120 128 140 - 126 134 146 - 130 139 151 -

1600

MBh 43.8 45.4 49.7 - 42.7 44.3 48.5 - 41.7 43.2 47.4 - 40.7 42.2 46.2 - 38.7 40.1 43.9 - 35.8 37.1 40.7 -

S/T 0.73 0.61 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.48 - 0.84 0.70 0.49 -

 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

kW 3.24 3.30 3.40 - 3.47 3.54 3.65 - 3.67 3.75 3.87 - 3.86 3.94 4.06 - 4.01 4.09 4.22 - 4.14 4.23 4.36 -

Amps 12.0 12.3 12.7 - 12.9 13.2 13.7 - 14.1 14.4 14.9 - 15.0 15.4 15.9 - 16.0 16.4 16.9 - 16.9 17.4 17.9 -

 221 238 251 - 248 267 282 - 282 304 321 - 321 346 365 - 362 389 411 - 400 430 454 -

 108 114 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 138 151 - 134 143 156 -

1800

MBh 45.1 46.7 51.2 - 44.0 45.6 50.0 - 43.0 44.5 48.8 - 41.9 43.5 47.6 - 39.8 41.3 45.2 - 36.9 38.2 41.9 -

S/T 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.88 0.74 0.51 -

 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -

kW 3.26 3.33 3.42 - 3.50 3.57 3.67 - 3.70 3.78 3.90 - 3.89 3.97 4.09 - 4.04 4.13 4.26 - 4.18 4.26 4.40 -

Amps 12.1 12.4 12.8 - 13.0 13.4 13.8 - 14.2 14.5 15.0 - 15.2 15.5 16.0 - 16.1 16.5 17.1 - 17.1 17.5 18.1 -

 223 240 254 - 251 270 285 - 285 307 324 - 325 349 369 - 365 393 415 - 404 434 459 -

 109 116 126 - 115 122 133 - 119 127 139 - 125 133 146 - 131 140 152 - 136 144 158 -

1400

MBh 41.1 42.3 45.8 49.1 40.1 41.3 44.7 48.0 39.2 40.3 43.7 46.8 38.2 39.3 42.6 45.7 36.3 37.4 40.5 43.4 33.6 34.6 37.5 40.2

S/T 0.81 0.72 0.55 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40

 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 11

kW 3.19 3.25 3.35 3.45 3.42 3.49 3.59 3.70 3.62 3.69 3.80 3.92 3.79 3.87 3.99 4.12 3.95 4.03 4.15 4.29 4.08 4.16 4.29 4.43

Amps 11.7 12.0 12.4 12.9 12.7 13.0 13.4 13.9 13.8 14.1 14.6 15.1 14.7 15.1 15.6 16.2 15.7 16.1 16.6 17.2 16.6 17.0 17.6 18.3

 217 233 246 257 243 262 276 288 277 298 314 328 315 339 358 373 354 381 403 420 391 421 445 464

 105 112 122 130 111 118 129 138 116 123 134 143 122 129 141 150 127 136 148 158 132 140 153 163

1600

MBh 44.5 45.8 49.6 53.2 43.5 44.8 48.4 52.0 42.4 43.7 47.3 50.8 41.4 42.6 46.1 49.5 39.3 40.5 43.8 47.0 36.4 37.5 40.6 43.6

S/T 0.84 0.75 0.57 0.36 0.87 0.77 0.59 0.38 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42

 21 20 16 11 22 20 16 11 22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 3.26 3.33 3.42 3.53 3.50 3.57 3.68 3.79 3.70 3.78 3.90 4.02 3.89 3.97 4.09 4.22 4.04 4.13 4.26 4.39 4.18 4.26 4.40 4.54

Amps 12.1 12.4 12.8 13.2 13.1 13.4 13.8 14.3 14.2 14.5 15.0 15.6 15.2 15.5 16.1 16.7 16.1 16.5 17.1 17.7 17.1 17.5 18.1 18.8

 223 240 254 265 251 270 285 297 285 307 324 338 325 349 369 385 365 393 415 433 404 434 459 478

 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 162 136 145 158 168

1800

MBh 45.8 47.2 51.1 54.8 44.8 46.1 49.9 53.6 43.7 45.0 48.7 52.3 42.6 43.9 47.5 51.0 40.5 41.7 45.1 48.5 37.5 38.6 41.8 44.9

S/T 0.88 0.78 0.59 0.38 0.91 0.81 0.61 0.40 0.93 0.83 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.89 0.67 0.43 1.00 0.90 0.68 0.44

 21 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10

kW 3.29 3.35 3.45 3.55 3.52 3.59 3.70 3.82 3.73 3.81 3.93 4.05 3.92 4.00 4.12 4.26 4.07 4.16 4.29 4.43 4.21 4.30 4.44 4.58

Amps 12.2 12.5 12.9 13.4 13.2 13.5 13.9 14.5 14.3 14.7 15.1 15.7 15.3 15.7 16.2 16.8 16.3 16.7 17.2 17.9 17.3 17.7 18.3 19.0

 226 243 256 267 253 272 288 300 288 310 327 341 328 353 373 389 369 397 419 437 408 439 463 483

 110 117 127 136 116 123 135 143 120 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170

Expanded Cooling Data — GSX130481B* / CA*F4860*6B*

14 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 15

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1400

MBh 41.8 42.7 45.6 48.8 40.8 41.7 44.6 47.7 39.9 40.7 43.5 46.5 38.9 39.7 42.5 45.4 36.9 37.8 40.3 43.1 34.2 35.0 37.4 39.9

S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.01 0.94 0.77 0.57 1.01 0.95 0.77 0.58

 24 23 20 16 25 24 20 16 25 24 20 16 25 24 21 16 24 23 20 16 23 22 19 15

kW 3.21 3.28 3.37 3.47 3.44 3.51 3.62 3.73 3.65 3.72 3.83 3.95 3.82 3.90 4.03 4.15 3.98 4.06 4.19 4.32 4.11 4.20 4.33 4.47

Amps 11.9 12.1 12.5 13.0 12.8 13.1 13.6 14.1 13.9 14.3 14.7 15.3 14.9 15.2 15.8 16.3 15.8 16.2 16.8 17.4 16.8 17.2 17.8 18.5

 219 236 249 259 246 264 279 291 279 301 317 331 318 342 362 377 358 385 407 424 395 426 449 469

 106 113 124 132 112 120 131 139 117 124 136 145 123 131 143 152 129 137 149 159 133 142 155 165

1600

MBh 45.3 46.3 49.5 52.9 44.2 45.2 48.3 51.6 43.2 44.1 47.2 50.4 42.1 43.1 46.0 49.2 40.0 40.9 43.7 46.7 37.1 37.9 40.5 43.3

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.97 0.91 0.74 0.56 1.00 0.94 0.77 0.57 1.00 0.98 0.80 0.60 1.00 0.99 0.80 0.60

 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 21 19 15

kW 3.29 3.35 3.45 3.56 3.52 3.59 3.70 3.82 3.73 3.81 3.93 4.05 3.92 4.00 4.12 4.26 4.07 4.16 4.29 4.43 4.21 4.30 4.44 4.58

Amps 12.2 12.5 12.9 13.4 13.2 13.5 13.9 14.5 14.3 14.7 15.2 15.7 15.3 15.7 16.2 16.8 16.3 16.7 17.3 17.9 17.3 17.7 18.3 19.0

 226 243 256 267 253 272 288 300 288 310 327 341 328 353 373 389 369 397 419 437 408 439 463 483

 110 117 127 136 116 123 135 143 120 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170

1800

MBh 46.7 47.7 50.9 54.4 45.6 46.6 49.7 53.2 44.5 45.5 48.6 51.9 43.4 44.3 47.4 50.6 41.2 42.1 45.0 48.1 38.2 39.0 41.7 44.6

S/T 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63

 23 22 19 15 23 22 19 15 23 22 19 15 22 23 19 16 21 22 19 15 20 20 18 14

kW 3.31 3.38 3.48 3.58 3.55 3.62 3.73 3.85 3.76 3.84 3.96 4.08 3.95 4.03 4.16 4.29 4.11 4.19 4.33 4.47 4.24 4.33 4.47 4.62

Amps 12.3 12.6 13.0 13.5 13.3 13.6 14.1 14.6 14.4 14.8 15.3 15.9 15.4 15.8 16.4 17.0 16.4 16.8 17.4 18.1 17.4 17.9 18.5 19.2

 228 245 259 270 256 275 291 303 291 313 331 345 331 356 376 393 373 401 423 442 412 443 468 488

 111 118 129 137 117 125 136 145 122 129 141 151 128 136 148 158 134 143 156 166 139 147 161 171

1400

MBh 42.5 43.4 45.4 48.5 41.5 42.4 44.4 47.3 40.6 41.3 43.3 46.2 39.6 40.3 42.2 45.1 37.6 38.3 40.1 42.8 34.8 35.5 37.2 39.7

S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.93 0.75

 26 25 24 21 26 26 24 21 26 26 24 21 26 26 25 21 25 25 24 21 23 23 23 20

kW 3.24 3.30 3.40 3.50 3.47 3.54 3.65 3.76 3.67 3.75 3.86 3.99 3.85 3.94 4.06 4.19 4.01 4.09 4.22 4.36 4.14 4.23 4.36 4.50

Amps 12.0 12.2 12.6 13.1 12.9 13.2 13.7 14.2 14.0 14.4 14.9 15.4 15.0 15.4 15.9 16.5 16.0 16.4 16.9 17.6 16.9 17.4 17.9 18.6

 221 238 251 262 248 267 282 294 282 304 321 334 321 346 365 381 361 389 411 428 399 430 454 473

 108 114 125 133 114 121 132 140 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166

1600

MBh 46.1 47.0 49.2 52.5 45.0 45.9 48.1 51.3 43.9 44.8 46.9 50.1 42.9 43.7 45.8 48.8 40.7 41.5 43.5 46.4 37.7 38.5 40.3 43.0

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78

 25 25 24 20 26 25 24 21 25 25 24 21 25 25 24 21 23 24 24 21 22 22 22 19

kW 3.31 3.38 3.48 3.58 3.55 3.62 3.73 3.85 3.76 3.84 3.96 4.08 3.95 4.03 4.16 4.29 4.11 4.19 4.33 4.47 4.24 4.33 4.47 4.62

Amps 12.3 12.6 13.0 13.5 13.3 13.6 14.1 14.6 14.4 14.8 15.3 15.9 15.4 15.8 16.4 17.0 16.4 16.8 17.4 18.1 17.4 17.9 18.5 19.2

 228 245 259 270 256 275 291 303 291 313 331 345 331 356 376 393 373 401 423 442 412 443 468 488

 111 118 129 137 117 125 136 145 122 129 141 151 128 136 148 158 134 143 156 166 139 147 161 171

1800

MBh 47.5 48.4 50.7 54.1 46.4 47.3 49.5 52.8 45.3 46.1 48.3 51.6 44.2 45.0 47.1 50.3 42.0 42.8 44.8 47.8 38.9 39.6 41.5 44.3

S/T 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.93 0.76 1.00 1.00 0.96 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82

 24 24 23 20 24 24 23 20 23 24 23 20 23 23 23 20 21 22 23 20 20 20 21 18

kW 3.34 3.40 3.50 3.61 3.58 3.65 3.76 3.88 3.79 3.87 3.99 4.11 3.98 4.06 4.19 4.32 4.14 4.23 4.36 4.50 4.28 4.37 4.51 4.65

Amps 12.4 12.7 13.1 13.6 13.4 13.7 14.2 14.7 14.6 14.9 15.4 16.0 15.6 16.0 16.5 17.1 16.6 17.0 17.6 18.2 17.6 18.0 18.6 19.3

 230 248 262 273 258 278 294 306 294 316 334 348 335 360 380 397 376 405 428 446 416 448 473 493

 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 160 135 144 157 167 140 149 163 173

Expanded Cooling Data — GSX130481B* / CA*F4860*6B* (cont.)

16 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 17

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1500

MBh 50.1 51.9 56.8 - 48.9 50.7 55.5 - 47.7 49.5 54.2 - 46.6 48.3 52.9 - 44.2 45.8 50.2 - 41.0 42.5 46.5 -

S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.64 0.44 - 0.77 0.64 0.44 -

 21 18 13 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -

kW 3.87 3.95 4.07 - 4.16 4.24 4.38 - 4.41 4.50 4.65 - 4.63 4.73 4.89 - 4.82 4.93 5.09 - 4.99 5.10 5.26 -

Amps 14.4 14.8 15.3 - 15.6 16.0 16.5 - 17.0 17.4 18.0 - 18.2 18.6 19.2 - 19.3 19.8 20.5 - 20.5 21.0 21.7 -

 229 246 260 - 257 276 292 - 292 314 332 - 333 358 378 - 374 403 425 - 413 445 470 -

 101 108 118 - 107 114 125 - 111 119 129 - 117 125 136 - 123 130 142 - 127 135 147 -

1750

MBh 54.2 56.2 61.6 - 53.0 54.9 60.1 - 51.7 53.6 58.7 - 50.4 52.3 57.3 - 47.9 49.7 54.4 - 44.4 46.0 50.4 -

S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -

 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -

kW 3.96 4.04 4.17 - 4.26 4.35 4.48 - 4.52 4.62 4.76 - 4.75 4.85 5.01 - 4.95 5.05 5.22 - 5.12 5.23 5.40 -

Amps 14.8 15.2 15.7 - 16.1 16.4 17.0 - 17.5 17.9 18.5 - 18.7 19.1 19.8 - 19.9 20.4 21.1 - 21.1 21.6 22.4 -

 236 254 268 - 265 285 301 - 301 324 342 - 343 369 390 - 386 415 438 - 426 459 484 -

 105 111 122 - 111 118 128 - 115 122 133 - 121 128 140 - 126 135 147 - 131 139 152 -

2000

MBh 55.9 57.9 63.4 - 54.6 56.5 62.0 - 53.3 55.2 60.5 - 52.0 53.9 59.0 - 49.4 51.2 56.1 - 45.7 47.4 51.9 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

 19 16 12 - 19 16 12 - 19 16 12 - 19 16 13 - 19 16 12 - 18 15 12 -

kW 3.99 4.07 4.20 - 4.29 4.38 4.52 - 4.56 4.65 4.80 - 4.79 4.89 5.05 - 4.99 5.10 5.26 - 5.16 5.27 5.44 -

Amps 15.0 15.3 15.8 - 16.2 16.6 17.2 - 17.6 18.1 18.7 - 18.9 19.3 20.0 - 20.1 20.6 21.3 - 21.3 21.8 22.6 -

 238 256 271 - 267 288 304 - 304 327 346 - 346 373 394 - 390 419 443 - 430 463 489 -

 106 112 123 - 112 119 130 - 116 123 135 - 122 130 142 - 128 136 148 - 132 141 153 -

1500

MBh 50.9 52.4 56.7 60.9 49.7 51.2 55.4 59.5 48.5 50.0 54.1 58.1 47.3 48.8 52.8 56.6 45.0 46.3 50.1 53.8 41.7 42.9 46.4 49.8

S/T 0.76 0.68 0.51 0.33 0.79 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.75 0.56 0.36 0.87 0.77 0.59 0.38 0.87 0.78 0.59 0.38

 24 22 18 12 24 22 18 13 24 22 18 13 24 22 18 13 24 22 18 12 22 21 17 12

kW 3.90 3.98 4.10 4.23 4.19 4.28 4.41 4.55 4.45 4.54 4.68 4.84 4.67 4.77 4.93 5.09 4.86 4.97 5.13 5.30 5.03 5.14 5.31 5.48

Amps 14.6 14.9 15.4 16.0 15.8 16.1 16.7 17.3 17.1 17.6 18.1 18.8 18.3 18.8 19.4 20.2 19.5 20.0 20.7 21.5 20.7 21.2 21.9 22.8

 231 249 263 274 259 279 295 307 295 317 335 350 336 362 382 398 378 407 430 448 418 449 475 495

 103 109 119 127 108 115 126 134 113 120 131 139 118 126 137 146 124 132 144 153 128 136 149 159

1750

MBh 55.1 56.8 61.5 66.0 53.9 55.5 60.0 64.4 52.6 54.1 58.6 62.9 51.3 52.8 57.2 61.4 48.7 50.2 54.3 58.3 45.1 46.5 50.3 54.0

S/T 0.79 0.71 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.91 0.81 0.61 0.39

 23 21 17 12 23 21 17 12 23 21 17 12 23 21 18 12 23 21 17 12 21 20 16 11

kW 3.99 4.07 4.20 4.33 4.29 4.38 4.52 4.66 4.56 4.65 4.80 4.96 4.79 4.89 5.05 5.22 4.99 5.10 5.26 5.44 5.16 5.27 5.44 5.63

Amps 15.0 15.3 15.8 16.4 16.2 16.6 17.2 17.8 17.6 18.1 18.7 19.4 18.9 19.3 20.0 20.8 20.1 20.6 21.3 22.1 21.3 21.8 22.6 23.5

 238 256 271 282 267 288 304 317 304 327 346 360 346 373 394 411 390 419 443 462 431 463 489 510

 106 112 123 131 112 119 130 138 116 123 135 144 122 130 142 151 128 136 148 158 132 141 153 163

2000

MBh 56.8 58.5 63.3 67.9 55.5 57.1 61.8 66.4 54.2 55.8 60.4 64.8 52.8 54.4 58.9 63.2 50.2 51.7 55.9 60.0 46.5 47.9 51.8 55.6

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.59 0.38 0.91 0.81 0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

 22 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 16 11 20 19 15 11

kW 4.02 4.11 4.23 4.37 4.33 4.42 4.56 4.70 4.59 4.69 4.84 5.00 4.83 4.93 5.09 5.26 5.03 5.14 5.31 5.48 5.20 5.32 5.49 5.67

Amps 15.1 15.5 16.0 16.6 16.4 16.8 17.3 18.0 17.8 18.2 18.8 19.6 19.0 19.5 20.2 20.9 20.3 20.8 21.5 22.3 21.5 22.0 22.8 23.7

 241 259 274 285 270 291 307 320 307 331 349 364 350 376 398 415 394 424 447 466 435 468 494 515

 107 114 124 132 113 120 131 139 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165

Expanded Cooling Data — GSX130601B* / CA*F4961*6A*

16 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 17

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1500

MBh 51.8 52.9 56.6 60.5 50.6 51.7 55.2 59.1 49.4 50.5 53.9 57.6 48.2 49.2 52.6 56.2 45.8 46.8 50.0 53.4 42.4 43.3 46.3 49.5

S/T 0.83 0.78 0.64 0.48 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.96 0.90 0.73 0.55

 26 25 22 18 27 26 22 18 27 26 22 18 27 26 23 18 27 26 22 18 25 24 21 17

kW 3.93 4.01 4.13 4.26 4.22 4.31 4.45 4.59 4.48 4.58 4.72 4.88 4.71 4.81 4.97 5.13 4.90 5.01 5.17 5.34 5.07 5.18 5.35 5.53

Amps 14.7 15.1 15.6 16.1 15.9 16.3 16.8 17.5 17.3 17.7 18.3 19.0 18.5 19.0 19.6 20.4 19.7 20.2 20.9 21.7 20.9 21.4 22.2 23.0

 234 251 265 277 262 282 298 311 298 321 339 353 339 365 386 402 382 411 434 453 422 454 479 500

 104 110 120 128 109 116 127 135 114 121 132 141 119 127 139 148 125 133 145 155 129 138 150 160

1750

MBh 56.1 57.4 61.3 65.5 54.8 56.0 59.9 64.0 53.5 54.7 58.4 62.5 52.2 53.4 57.0 60.9 49.6 50.7 54.2 57.9 45.9 46.9 50.2 53.6

S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57

 25 24 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 21 17 24 23 20 16

kW 4.02 4.11 4.23 4.37 4.33 4.42 4.56 4.70 4.59 4.69 4.84 5.00 4.83 4.93 5.09 5.26 5.03 5.14 5.31 5.48 5.20 5.32 5.49 5.67

Amps 15.1 15.5 16.0 16.6 16.4 16.8 17.3 18.0 17.8 18.2 18.8 19.6 19.0 19.5 20.2 20.9 20.3 20.8 21.5 22.3 21.5 22.0 22.8 23.7

 241 259 274 285 270 291 307 320 307 331 349 364 350 377 398 415 394 424 447 467 435 468 494 515

 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165

2000

MBh 57.8 59.1 63.1 67.5 56.5 57.7 61.6 65.9 55.1 56.3 60.2 64.3 53.8 55.0 58.7 62.8 51.1 52.2 55.8 59.6 47.3 48.4 51.7 55.2

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.96 0.90 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.79 0.59

 24 23 20 16 24 23 20 16 24 23 20 16 25 24 20 16 23 23 20 16 22 22 19 15

kW 4.05 4.14 4.27 4.40 4.36 4.45 4.59 4.74 4.63 4.73 4.88 5.04 4.87 4.97 5.13 5.30 5.07 5.18 5.35 5.53 5.24 5.36 5.54 5.72

Amps 15.2 15.6 16.1 16.7 16.5 16.9 17.5 18.1 18.0 18.4 19.0 19.8 19.2 19.7 20.4 21.1 20.5 21.0 21.7 22.5 21.7 22.3 23.0 23.9

 243 262 276 288 273 294 310 323 310 334 353 368 353 380 402 419 398 428 452 471 439 473 499 521

 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167

1500

MBh 52.7 53.7 56.3 60.0 51.5 52.5 55.0 58.6 50.3 51.2 53.7 57.2 49.0 50.0 52.3 55.8 46.6 47.5 49.7 53.1 43.1 44.0 46.1 49.1

S/T 0.87 0.84 0.76 0.62 0.91 0.87 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.93 0.83 0.68 1.00 0.96 0.87 0.70 1.00 0.97 0.87 0.71

 28 28 26 23 29 28 27 23 29 28 27 23 29 28 27 23 28 28 26 23 26 26 25 21

kW 3.96 4.04 4.17 4.30 4.26 4.35 4.48 4.62 4.52 4.61 4.76 4.92 4.75 4.85 5.01 5.17 4.94 5.05 5.22 5.39 5.11 5.23 5.40 5.58

Amps 14.8 15.2 15.7 16.3 16.0 16.4 17.0 17.6 17.5 17.9 18.5 19.2 18.7 19.1 19.8 20.5 19.9 20.4 21.1 21.9 21.1 21.6 22.4 23.2

 236 254 268 280 265 285 301 314 301 324 342 357 343 369 390 406 386 415 438 457 426 459 484 505

 105 111 121 129 110 118 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162

1750

MBh 57.1 58.2 61.0 65.0 55.8 56.9 59.6 63.5 54.5 55.5 58.1 62.0 53.1 54.2 56.7 60.5 50.5 51.4 53.9 57.5 46.7 47.7 49.9 53.2

S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74

 27 27 25 22 28 27 26 22 28 27 26 22 28 27 26 22 27 27 25 22 25 25 24 21

kW 4.05 4.14 4.27 4.40 4.36 4.45 4.59 4.74 4.63 4.73 4.88 5.04 4.87 4.97 5.13 5.30 5.07 5.18 5.35 5.53 5.24 5.36 5.54 5.72

Amps 15.2 15.6 16.1 16.7 16.5 16.9 17.5 18.1 18.0 18.4 19.0 19.8 19.2 19.7 20.4 21.1 20.5 21.0 21.7 22.5 21.7 22.3 23.0 23.9

 243 262 276 288 273 294 310 323 310 334 353 368 353 380 402 419 398 428 452 471 439 473 499 521

 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167

2000

MBh 58.8 60.0 62.8 67.0 57.5 58.6 61.3 65.4 56.1 57.2 59.9 63.9 54.7 55.8 58.4 62.3 52.0 53.0 55.5 59.2 48.2 49.1 51.4 54.8

S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

 26 25 24 21 26 26 24 21 26 26 24 21 25 26 24 21 24 24 24 21 22 23 22 19

kW 4.09 4.17 4.30 4.44 4.39 4.49 4.63 4.78 4.67 4.77 4.92 5.08 4.91 5.01 5.18 5.35 5.11 5.22 5.39 5.57 5.29 5.40 5.58 5.77

Amps 15.4 15.8 16.3 16.9 16.7 17.1 17.6 18.3 18.1 18.6 19.2 19.9 19.4 19.9 20.6 21.3 20.7 21.2 21.9 22.7 21.9 22.5 23.2 24.1

 246 264 279 291 276 297 313 327 313 337 356 371 357 384 406 423 402 432 456 476 444 477 504 526

 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168

Expanded Cooling Data — GSX130601B* / CA*F4961*6A* (cont.)

18 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 19

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1500

MBh 53.8 55.7 61.0 - 52.5 54.4 59.6 - 51.3 53.1 58.2 - 50.0 51.8 56.8 - 47.5 49.2 53.9 - 44.0 45.6 50.0 -

S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.44 -

 22 19 14 - 22 19 14 - 22 19 14 - 22 19 14 - 22 19 14 - 20 18 13 -

kW 3.97 4.05 4.18 - 4.27 4.37 4.51 - 4.54 4.64 4.80 - 4.78 4.89 5.05 - 4.99 5.10 5.27 - 5.16 5.28 5.45 -

Amps 15.4 15.8 16.3 - 16.7 17.1 17.6 - 18.1 18.6 19.2 - 19.4 19.9 20.6 - 20.7 21.2 21.9 - 22.0 22.5 23.3 -

 228 245 259 - 256 275 291 - 291 313 331 - 331 357 377 - 373 401 424 - 412 443 468 -

 98 104 114 - 103 110 120 - 107 114 125 - 113 120 131 - 118 126 137 - 122 130 142 -

1750

MBh 55.4 57.4 62.9 - 54.1 56.1 61.4 - 52.8 54.7 59.9 - 51.5 53.4 58.5 - 48.9 50.7 55.6 - 45.3 47.0 51.5 -

S/T 0.69 0.57 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -

 20 17 13 - 20 18 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -

kW 4.00 4.09 4.21 - 4.31 4.40 4.54 - 4.58 4.68 4.84 - 4.82 4.93 5.09 - 5.03 5.14 5.31 - 5.20 5.32 5.50 -

Amps 15.5 15.9 16.4 - 16.8 17.2 17.8 - 18.3 18.8 19.4 - 19.6 20.1 20.8 - 20.9 21.4 22.2 - 22.2 22.7 23.5 -

 230 248 262 - 258 278 294 - 294 316 334 - 335 360 380 - 377 405 428 - 416 448 473 -

 99 105 115 - 104 111 121 - 108 115 126 - 114 121 132 - 119 127 139 - 124 131 143 -

2000

MBh 55.6 57.7 63.2 - 54.3 56.3 61.7 - 53.0 55.0 60.2 - 51.8 53.6 58.8 - 49.2 51.0 55.8 - 45.5 47.2 51.7 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -

 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

kW 4.03 4.12 4.25 - 4.34 4.44 4.58 - 4.62 4.72 4.88 - 4.86 4.97 5.13 - 5.07 5.18 5.36 - 5.25 5.37 5.55 -

Amps 15.7 16.0 16.6 - 17.0 17.4 18.0 - 18.5 18.9 19.6 - 19.8 20.3 21.0 - 21.1 21.6 22.4 - 22.4 22.9 23.7 -

 233 250 264 - 261 281 297 - 297 319 337 - 338 364 384 - 380 409 432 - 420 452 477 -

 100 106 116 - 105 112 122 - 110 117 127 - 115 122 134 - 121 128 140 - 125 133 145 -

1500

MBh 54.7 56.3 60.9 65.4 53.4 55.0 59.5 63.9 52.1 53.7 58.1 62.3 50.9 52.4 56.7 60.8 48.3 49.7 53.8 57.8 44.7 46.1 49.9 53.5

S/T 0.75 0.67 0.50 0.32 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.86 0.77 0.58 0.37

 25 23 19 13 25 23 19 13 25 23 19 13 26 23 19 13 25 23 19 13 23 22 18 12

kW 4.00 4.09 4.22 4.35 4.31 4.40 4.55 4.69 4.58 4.68 4.84 5.00 4.82 4.93 5.09 5.26 5.03 5.14 5.31 5.49 5.20 5.32 5.50 5.69

Amps 15.5 15.9 16.4 17.1 16.8 17.2 17.8 18.5 18.3 18.8 19.4 20.2 19.6 20.1 20.8 21.6 20.9 21.4 22.2 23.0 22.2 22.7 23.5 24.4

 230 248 262 273 258 278 294 306 294 316 334 348 335 360 380 397 377 405 428 446 416 448 473 493

 99 105 115 122 104 111 121 129 108 115 126 134 114 121 132 141 119 127 139 148 124 131 143 153

1750

MBh 56.3 58.0 62.7 67.3 55.0 56.6 61.3 65.8 53.7 55.3 59.8 64.2 52.4 53.9 58.4 62.6 49.8 51.2 55.5 59.5 46.1 47.5 51.4 55.1

S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39

 23 21 17 12 23 22 18 12 23 22 18 12 24 22 18 12 23 21 18 12 22 20 16 11

kW 4.03 4.12 4.25 4.39 4.34 4.44 4.58 4.73 4.62 4.72 4.88 5.04 4.86 4.97 5.14 5.31 5.07 5.18 5.36 5.54 5.25 5.37 5.55 5.74

Amps 15.7 16.1 16.6 17.2 17.0 17.4 18.0 18.7 18.5 18.9 19.6 20.3 19.8 20.3 21.0 21.8 21.1 21.6 22.4 23.2 22.4 22.9 23.7 24.7

 233 250 264 276 261 281 297 309 297 320 337 352 338 364 384 401 380 409 432 451 420 452 478 498

 100 106 116 123 105 112 122 130 110 117 127 136 115 122 134 142 121 128 140 149 125 133 145 154

2000

MBh 56.6 58.3 63.1 67.7 55.3 56.9 61.6 66.1 53.9 55.5 60.1 64.5 52.6 54.2 58.7 63.0 50.0 51.5 55.7 59.8 46.3 47.7 51.6 55.4

S/T 0.79 0.71 0.54 0.35 0.82 0.73 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40

 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10

kW 4.06 4.15 4.28 4.42 4.38 4.48 4.62 4.77 4.66 4.76 4.92 5.08 4.90 5.01 5.18 5.35 5.11 5.23 5.40 5.59 5.29 5.41 5.59 5.78

Amps 15.8 16.2 16.7 17.4 17.1 17.6 18.1 18.8 18.7 19.1 19.8 20.5 20.0 20.5 21.2 22.0 21.3 21.8 22.6 23.5 22.6 23.2 24.0 24.9

 235 253 267 278 264 284 300 312 300 323 341 355 341 367 388 405 384 413 437 455 424 457 482 503

 101 107 117 125 106 113 124 132 111 118 129 137 116 124 135 144 122 130 141 151 126 134 146 156

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan)

High and low pressures are measured at the liquid and sucon service valves. kW = Total system power

Expanded Cooling Data — GSX130611**/CA*F4961*6D*+EEP

18 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 19

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1500

MBh 55.6 56.9 60.7 64.9 54.3 55.5 59.3 63.4 53.0 54.2 57.9 61.9 51.8 52.9 56.5 60.4 49.2 50.2 53.7 57.4 45.5 46.5 49.7 53.2

S/T 0.82 0.77 0.62 0.47 0.85 0.80 0.65 0.48 0.87 0.82 0.66 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.94 0.88 0.72 0.54

 28 27 23 19 28 27 24 19 28 27 24 19 28 27 24 19 28 27 23 19 26 25 22 17

kW 4.03 4.12 4.25 4.39 4.35 4.44 4.58 4.73 4.62 4.72 4.88 5.04 4.86 4.97 5.14 5.31 5.07 5.18 5.36 5.54 5.25 5.37 5.55 5.74

Amps 15.7 16.1 16.6 17.2 17.0 17.4 18.0 18.7 18.5 18.9 19.6 20.3 19.8 20.3 21.0 21.8 21.1 21.6 22.4 23.2 22.4 22.9 23.7 24.7

 233 250 264 276 261 281 297 309 297 320 337 352 338 364 384 401 380 409 432 451 420 452 478 498

 100 106 116 123 105 112 122 130 110 117 127 136 115 122 134 142 121 128 140 149 125 133 145 154

1750

MBh 57.3 58.6 62.6 66.9 56.0 57.2 61.1 65.3 54.6 55.8 59.6 63.8 53.3 54.5 58.2 62.2 50.6 51.7 55.3 59.1 46.9 47.9 51.2 54.7

S/T 0.86 0.80 0.65 0.49 0.89 0.83 0.68 0.51 0.91 0.85 0.70 0.52 0.94 0.88 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.92 0.75 0.56

 26 25 22 17 26 25 22 17 26 25 22 17 26 25 22 18 27 25 22 17 25 23 20 16

kW 4.07 4.15 4.28 4.42 4.38 4.48 4.62 4.77 4.66 4.76 4.92 5.08 4.90 5.01 5.18 5.35 5.11 5.23 5.40 5.59 5.29 5.41 5.59 5.79

Amps 15.8 16.2 16.7 17.4 17.1 17.6 18.2 18.9 18.7 19.1 19.8 20.5 20.0 20.5 21.2 22.0 21.3 21.8 22.6 23.5 22.6 23.2 24.0 24.9

 235 253 267 279 264 284 300 313 300 323 341 355 342 368 388 405 384 414 437 455 425 457 482 503

 101 107 117 125 107 113 124 132 111 118 129 137 116 124 135 144 122 130 142 151 126 134 146 156

2000

MBh 57.6 58.8 62.9 67.2 56.2 57.5 61.4 65.6 54.9 56.1 59.9 64.1 53.6 54.7 58.5 62.5 50.9 52.0 55.6 59.4 47.1 48.2 51.5 55.0

S/T 0.87 0.82 0.66 0.50 0.90 0.85 0.69 0.51 0.92 0.87 0.71 0.53 0.95 0.89 0.73 0.54 1.00 0.93 0.76 0.56 1.00 0.94 0.76 0.57

 23 22 19 15 23 22 19 16 23 22 19 16 23 23 20 16 23 22 19 15 22 21 18 14

kW 4.10 4.19 4.32 4.46 4.42 4.51 4.66 4.81 4.70 4.80 4.96 5.12 4.94 5.06 5.22 5.40 5.16 5.27 5.45 5.63 5.34 5.46 5.64 5.84

Amps 16.0 16.4 16.9 17.6 17.3 17.7 18.3 19.0 18.8 19.3 20.0 20.7 20.2 20.7 21.4 22.2 21.5 22.0 22.8 23.7 22.8 23.4 24.2 25.1

 237 255 270 281 266 287 303 316 303 326 344 359 345 371 392 409 388 418 441 460 429 461 487 508

 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157

1500

MBh 56.6 57.7 60.4 64.5 55.3 56.4 59.0 63.0 54.0 55.0 57.6 61.5 52.7 53.7 56.2 60.0 50.0 51.0 53.4 57.0 46.3 47.2 49.5 52.8

S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.77 0.63 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.66 0.98 0.94 0.85 0.69 0.98 0.95 0.86 0.70

 30 29 28 24 30 30 28 24 30 30 28 24 30 30 28 24 30 29 28 24 28 28 26 23

kW 4.07 4.15 4.28 4.42 4.38 4.48 4.62 4.77 4.66 4.76 4.92 5.08 4.90 5.01 5.18 5.35 5.11 5.23 5.40 5.59 5.29 5.41 5.59 5.79

Amps 15.8 16.2 16.7 17.4 17.1 17.6 18.2 18.9 18.7 19.1 19.8 20.5 20.0 20.5 21.2 22.0 21.3 21.8 22.6 23.5 22.6 23.2 24.0 24.9

 235 253 267 279 264 284 300 313 300 323 341 355 342 368 388 405 384 414 437 455 425 457 482 503

 101 107 117 125 107 113 124 132 111 118 129 137 116 124 135 144 122 130 142 151 126 134 146 156

1750

MBh 58.3 59.4 62.2 66.4 56.9 58.1 60.8 64.9 55.6 56.7 59.4 63.3 54.2 55.3 57.9 61.8 51.5 52.5 55.0 58.7 47.7 48.7 51.0 54.4

S/T 0.90 0.87 0.78 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.90 0.73

 28 27 26 22 28 27 26 22 28 27 26 22 28 28 26 23 27 27 26 22 25 25 24 21

kW 4.10 4.19 4.32 4.46 4.42 4.51 4.66 4.81 4.70 4.80 4.96 5.12 4.95 5.06 5.22 5.40 5.16 5.27 5.45 5.63 5.34 5.46 5.64 5.84

Amps 16.0 16.4 16.9 17.6 17.3 17.7 18.3 19.0 18.8 19.3 20.0 20.7 20.2 20.7 21.4 22.2 21.5 22.0 22.8 23.7 22.8 23.4 24.2 25.1

 237 255 270 281 266 287 303 316 303 326 344 359 345 371 392 409 388 418 441 460 429 461 487 508

 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157

2000

MBh 58.6 59.7 62.5 66.7 57.2 58.3 61.1 65.2 55.9 56.9 59.6 63.6 54.5 55.6 58.2 62.1 51.8 52.8 55.3 59.0 48.0 48.9 51.2 54.6

S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74

 25 24 23 20 25 24 23 20 25 24 23 20 25 25 23 20 24 24 23 20 22 22 21 19

kW 4.13 4.22 4.35 4.50 4.45 4.55 4.70 4.85 4.74 4.84 5.00 5.17 4.99 5.10 5.27 5.45 5.20 5.32 5.49 5.68 5.38 5.50 5.69 5.89

Amps 16.1 16.5 17.1 17.7 17.5 17.9 18.5 19.2 19.0 19.5 20.1 20.9 20.4 20.9 21.6 22.4 21.7 22.2 23.0 23.9 23.0 23.6 24.4 25.4

 240 258 272 284 269 289 306 319 306 329 348 363 348 375 396 413 392 422 445 465 433 466 492 513

 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159

Expanded Cooling Data — GSX130611**/CA*F4961*6D*+EEP (cont.)

AHRI Ratings AHRI Ratings

20 www.goodmanmfg.com SS-GSX13 SS-GSX13 www.goodmanmfg.com 21

See Notes on Page 45.

Outdoor

Unit

Indoor Units Cooling Ratings CFM AHRI #

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

GSX13

0181E*

ACNF18XX16D* 16,800 12,800 13.0 10.8 600 5039733

ACNF24XX16D* 17,000 13,000 13.0 10.8 600 5039734

ARUF18B14A* 17,200 13,100 13.0 11.0 600 5360107

ARUF18B14A*+TXV 17,200 13,100 13.0 11.0 600 5378529

ARUF24B14C* 17,200 13,100 13.0 11.0 600 7084828

ARUF24B14C*+TXV 17,200 13,100 13.5 11.0 600 7084829

ARUF25B14A* 18,000 13,700 13.0 11.0 570 7984175

ASPT24B14A* 17,600 13,400 14.0 12.0 605 5722521

ASPT25B14A* 17,600 13,400 14.0 12.0 580 8242040

ASPT29B14A* 18,000 13,700 14.0 12.0 560 8242041

ASPT30C14A* 18,000 13,700 14.0 12.0 580 5722522

AVPTC24B14A* 17,600 13,400 14.0 12.0 600 5924342

AVPTC30C14A* 18,000 13,700 14.0 12.0 615 5924442

AWUF18XX16B* 17,200 13,100 13.0 11.0 600 5039739

AWUF24XX16B* 17,400 13,300 13.0 11.0 650 7487211

AWUF31XX16A* 17,200 13,100 14.0 11.3 600 5039740

CA*F1824*6D* A*VC80604B*B* 18,000 13,700 14.0 11.5 675 5039742

CA*F1824*6D* G*E80603B*B* 17,800 13,600 14.0 11.5 640 5039744

CA*F1824*6D* G*VC80604B*B* 18,000 13,700 14.0 11.5 670 5039746

CA*F1824*6D* A*EH800603B*A* 17,800 13,600 14.0 11.5 640 6944831

CA*F1824*6D* A*VC960403BNA* 17,800 13,600 14.0 11.5 625 7353494

CA*F1824*6D* A*VC960603BNA* 17,800 13,600 14.0 11.5 600 7353495

CA*F1824*6D* A*VC960803BNA* 17,800 13,600 14.0 11.5 630 7353496

CA*F1824*6D* A*VM970603BNA* 17,800 13,600 14.0 11.5 600 7353497

CA*F1824*6D* A*VM970803BNA* 17,800 13,600 14.0 11.5 630 7353498

CA*F1824*6D* G*VC960403BNA* 17,800 13,600 14.0 11.5 625 7353499

CA*F1824*6D* G*VC960603BNA* 17,800 13,600 14.0 11.5 600 7353500

CA*F1824*6D* G*VC960803BNA* 17,800 13,600 14.0 11.5 630 7353501

CA*F1824*6D* G*VM970603BNA* 17,800 13,600 14.0 11.5 600 7353502

CA*F1824*6D* G*VM970803BNA* 17,800 13,600 14.0 11.5 630 7353503

CA*F1824*6D* G*EC960302BNA* 17,800 13,600 14.0 11.5 600 7365224

CA*F1824*6D* G*EC960402BNA* 17,800 13,600 14.0 11.5 600 7365229

CA*F1824*6D* G*EC960603BNA* 17,400 13,300 14.0 11.5 550 7365234

CA*F1824*6D* G*EC960803BNA* 17,800 13,600 14.0 11.5 575 7365239

CA*F1824*6D* A*EC960302BNA* 17,800 13,600 14.0 11.5 600 7365330

CA*F1824*6D* A*EC960402BNA* 17,800 13,600 14.0 11.5 600 7365335

CA*F1824*6D* A*EC960603BNA* 17,400 13,300 14.0 11.5 550 7365340

CA*F1824*6D* A*EC960803BNA* 17,800 13,600 14.0 11.5 575 7365345

CA*F1824*6D*+EEP 17,800 13,600 13.0 11.0 650 5039750

CA*F1824*6D*+MBVC1200**-1A* 18,200 13,900 14.0 11.5 640 5039751

CA*F1824*6D*+TXV A*VC960403BNA* 17,800 13,600 14.0 11.5 625 7353504

CA*F1824*6D*+TXV A*VC960603BNA* 17,800 13,600 14.0 11.5 600 7353505

CA*F1824*6D*+TXV A*VC960803BNA* 17,800 13,600 14.0 11.5 630 7353506

CA*F1824*6D*+TXV A*VM970603BNA* 17,800 13,600 14.0 11.5 600 7353507

CA*F1824*6D*+TXV A*VM970803BNA* 17,800 13,600 14.0 11.5 630 7353508

CA*F1824*6D*+TXV G*VC960403BNA* 17,800 13,600 14.0 11.5 625 7353509

CA*F1824*6D*+TXV G*VC960603BNA* 17,800 13,600 14.0 11.5 600 7353510

CA*F1824*6D*+TXV G*VC960803BNA* 17,800 13,600 14.0 11.5 630 7353511

CA*F1824*6D*+TXV G*VM970603BNA* 17,800 13,600 14.0 11.5 600 7353512

CA*F1824*6D*+TXV G*VM970803BNA* 17,800 13,600 14.0 11.5 630 7353513

CA*F1824*6D*+TXV G*EC960302BNA* 17,800 13,600 14.0 11.5 600 7365225

CA*F1824*6D*+TXV G*EC960402BNA* 17,800 13,600 14.0 11.5 600 7365230

CA*F1824*6D*+TXV G*EC960603BNA* 17,400 13,300 14.0 11.5 550 7365235

CA*F1824*6D*+TXV G*EC960803BNA* 17,800 13,600 14.0 11.5 575 7365240

CA*F1824*6D*+TXV A*EC960302BNA* 17,800 13,600 14.0 11.5 600 7365331

CA*F1824*6D*+TXV A*EC960402BNA* 17,800 13,600 14.0 11.5 600 7365336

Other manuals for GSX13

Table of contents

Other Goodman Air Conditioner manuals

Goodman

Goodman SS-CKF50 Installation instructions

Goodman

Goodman GSC13018 User manual

Goodman

Goodman A/GPG13 M SERIES Manual

Goodman

Goodman AIR CONDITIONING CONDENSING UNIT 1 THRU 5 TON and GAS FIRED... Quick reference guide

Goodman

Goodman GSX14 0181L User manual

Goodman

Goodman SS-PGBC50 User guide

Goodman

Goodman SS-CPG36-72 User manual

Goodman

Goodman APG 13 Operating instructions

Goodman

Goodman CONDENSING AC UNIT User manual

Goodman

Goodman GPC1424H41AB Use and care manual

Goodman

Goodman GPG13M User manual

Goodman

Goodman PC50 Installation instructions

Goodman

Goodman SSX16 Installation instructions

Goodman

Goodman APG152407041A Series User manual

Goodman

Goodman RT6100004R13 Operating instructions

Goodman

Goodman CPC CONVERCIAL SS-CPC90-150 User manual

Goodman

Goodman MSG-12CRN1N Operating instructions

Goodman

Goodman GSX13 User manual

Goodman

Goodman DSXC16 User manual

Goodman

Goodman GSC130181A User manual

Goodman

Goodman SS-CPC36-72 User manual

Goodman

Goodman AVPTC183014AA Use and care manual

Goodman

Goodman APG14 M Series Manual

Goodman

Goodman GPC13 M Series Use and care manual

Popular Air Conditioner manuals by other brands

Mitsubishi Electric

Mitsubishi Electric City Multi PKFY-WL NLMU-E Series installation manual

Airwell

Airwell XLM17RCA Operation and installation instructions

Trane

Trane A4AC3018B1000B Installer's guide

Samsung

Samsung AM KN4DCH Series installation manual

Fujitsu

Fujitsu AOU9RLF installation manual

Mitsubishi Electric

Mitsubishi Electric Mr. Slim MXZ-3B24NA installation manual

Midea

Midea MSV1-18HRN1 user manual

Trane

Trane Tracker Version 12 Hardware installation

Johnson Controls Unitary Products

Johnson Controls Unitary Products TC3B1821S Technical guide

Frigidaire

Frigidaire FAC089L7A2 Factory parts catalog

Kasanova

Kasanova BAC000212NOC instruction manual

Kinghome

Kinghome KU21-FCU18-3 instruction manual

Impecca

Impecca ISAH-2418B1 user manual

Heat Controller

Heat Controller RADS-253A Replacement parts manual

ClimateRight

ClimateRight CR-2500 Assembly and instruction manual

Soleus Air

Soleus Air KC-15U owner's manual

mundoclima

mundoclima CL23420 installation manual

LG I27TTC owner's manual
