Goodman DSXC16 User manual
DRAFT
SS-DSXC16 www.goodmanmfg.com 3/14
Supersedes 2/14
DSXC16
Split SyStem Air ConDitioner
Upto 16 Seer
Cooling CApACity:
24,000 - 57,000 BtU/h
Contents
Nomenclature ....................................... 2
Product Specications .......................... 3
Expanded Cooling Data ........................ 4
AHRI Ratings........................................ 20
Dimensions ......................................... 30
Wiring Diagram................................... 31
Accessories .......................................... 32
Standard Features
• R-410A chlorine-free refrigerant
• Two-Stage Copeland® UltraTech™
scroll compressor
• High-density foam compressor sound blanket
• ComfortNet™ Communications
System compatible
• Expanded ComfortAlert™ diagnostics
• Set-up capable with 2 low-
voltage wires to outdoor unit
• Diagnostic indicator lights and
storage of 6 fault codes
• Color-coded terminal strip for
non-communicating set-up
• High- and low-pressure switches
• Factory-installed lter drier
• Coil and ambient temperature sensors
• Two-speed, quiet condenser fan motor
• AHRI Certied; ETL Listed
Cabinet Features
• Wire fan discharge grille
• Steel louver coil guard
• Baked-on powder paint nish
• Top and side maintenance access
• Single-panel access to controls with space
provided for eld-installed accessories
• When properly anchored, meets 2010
Florida Building Code unit integrity
requirements for hurricane-type winds
(Anchor bracket kits available.)
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive
the Lifetime Compressor Limited Warranty (good for as long as you own your home), 10-Year Unit
Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be
completed within 60 days of installation. Online registration is not required in California or Québec.
2 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
nomenClAtUre
C
4
Brand Engineering *
D
Goodman
®
Brand Minor Revision
Product Category Engineering *
S Split System Major Revision
Unit Type Electrical
C
Condenser R-22
1 208/230 V, 1 Phase, 60 Hz
X Condenser R-410A 2220/240 V, 1 Phase, 50 Hz
H
Heat Pump R-22
3 208/230 V, 3 Phase, 60 Hz
Z
Heat Pump R-410A
4 460 V, 3 Phase, 60 Hz
5 380/415 V, 3 Phase, 50 Hz
Communication Feature
C ComfortNet 4-wire communications ready Nominal Capacity
018
1½Tons 048 4 Tons
Efficiency 024 2 Tons 060 5 Tons
13 13 SEER 16 SEER 030
2½Tons 090 7½tons
14 14 SEER 18 SEER 036 3 Tons 120 10 Tons
042
3½Tons
* Neither used for order entry
or inventory management.
036
7,8,9
12
A
10
1
11
A
16
5,6
16
18
S
2
1
D
X
3
SS-DSXC16 www.goodmanmfg.com 3
Product SPecificationS
SpeCifiCAtionS
DSXC16
0241AA/B
DSXC16
0241AC
DSXC16
0361AA/B
DSXC16
0361AC
DSXC16
0481B*
DSXC16
0601B*
Nominal Cooling (BTU/h) 24,000 24,000 36,000 36,000 48,000 60,000
Decibels 71 71 70.4/70.9 70.4/70.9 74 75
RLA 10.3 11.7 16.7 15.3 21.2 28.8
LRA 52.0 58.0 82.0 83.0 104.0 152.9
Horsepower (RPM) 1/6 1/6 1/6 1/6 1/6 1/6
FLA 1.1 1.1 0.9 0.9 1.2 1.0
Refrigerant Line Size¹
Liquid Line Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Line Size (“O.D.) ¾" ¾" ⅞" ⅞" 1⅛" 1⅛"
Refrigerant Connecon Size
Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Valve Size (“O.D.) ¾" ¾" ¾" ¾" ⅞" ⅞"
Valve Connecon Type Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 97 97 107 107 132 197
Voltage-Hz 208/230-60 208/230-60 208/230-60 208/230-60 208/230-60 208/230-60
Minimum Circuit Ampacity ² 14.0 15.7 21.8 20.0 27.7 37.2
Max. Overcurrent Protecon ³ 20 20 35 35 45 60
Min / Max Volts 197/253 197/253 197/253 197/253 197/253 197/253
Power Supply ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾"
181 181 184 184 219 279
198 198 202 202 241 301
¹ Tested and rated in accordance with ARI Standard 210/240
² Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as noted.
• Always check the S&R plate for electrical data on the unit being installed.
• Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.
• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installaon Instrucons Final Charge Procedure.
• Installaon of these units requires the specied TXV Kit to be installed on the indoor coil. THE SPECI-
FIED TXV IS DETERMINED BY THE OUTDOOR UNIT, NOT THE INDOOR COIL.
4 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
675
MBh 18.0 18.7 20.4 - 17.6 18.2 20.0 - 17.2 17.8 19.5 - 16.7 17.4 19.0 - 15.9 16.5 18.1 - 14.7 15.3 16.7 -
S/T 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.80 0.66 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
kW 1.10 1.12 1.16 - 1.19 1.21 1.25 - 1.26 1.29 1.34 - 1.33 1.37 1.41 - 1.39 1.43 1.48 - 1.44 1.48 1.53 -
Amps 4.5 4.6 4.7 - 4.8 4.9 5.1 - 5.2 5.3 5.5 - 5.6 5.7 5.9 - 5.9 6.1 6.3 - 6.3 6.4 6.6 -
HI PR 228 245 248 - 258 277 281 - 293 315 319 - 334 359 364 - 375 404 409 - 420 452 458 -
Lo PR 122 125 137 - 125 129 141 - 129 133 146 - 133 137 150 - 135 140 153 - 139 143 156 -
600
MBh 17.5 18.1 19.8 - 17.1 17.7 19.4 - 16.7 17.3 18.9 - 16.3 16.8 18.5 - 15.4 16.0 17.5 - 14.3 14.8 16.2 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
∆T 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
kW 1.09 1.11 1.15 - 1.18 1.20 1.24 - 1.25 1.28 1.33 - 1.32 1.35 1.40 - 1.38 1.41 1.46 - 1.43 1.47 1.52 -
Amps 4.4 4.5 4.7 - 4.8 4.9 5.0 - 5.2 5.3 5.5 - 5.5 5.7 5.8 - 5.9 6.0 6.2 - 6.2 6.4 6.6 -
HI PR 226 243 246 - 255 274 278 - 290 312 316 - 330 355 360 - 372 400 405 - 416 447 454 -
Lo PR 120 124 136 - 124 128 140 - 128 132 144 - 132 136 148 - 134 138 151 - 137 142 155 -
525
MBh 16.1 16.7 18.3 - 15.8 16.3 17.9 - 15.4 15.9 17.5 - 15.0 15.6 17.0 - 14.3 14.8 16.2 - 13.2 13.7 15.0 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 1.08 1.10 1.14 - 1.17 1.19 1.23 - 1.24 1.27 1.31 - 1.31 1.34 1.39 - 1.37 1.40 1.45 - 1.42 1.45 1.50 -
Amps 4.4 4.5 4.6 - 4.7 4.8 5.0 - 5.1 5.3 5.4 - 5.5 5.6 5.8 - 5.8 6.0 6.2 - 6.2 6.3 6.5 -
HI PR 223 240 244 - 252 271 275 - 287 309 313 - 327 352 357 - 368 396 401 - 412 443 449 -
Lo PR 119 123 134 - 123 127 138 - 127 131 143 - 130 134 147 - 133 137 150 - 136 140 153 -
75
675
MBh 18.3 18.8 20.4 21.9 17.9 18.4 19.9 21.4 17.5 18.0 19.4 20.9 17.0 17.5 19.0 20.4 16.2 16.7 18.0 19.3 15.0 15.4 16.7 17.9
S/T 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.87 0.66 0.43
∆T 21 20 16 11 21 20 16 11 22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10
kW 1.10 1.12 1.16 1.20 1.19 1.21 1.25 1.30 1.26 1.29 1.34 1.38 1.33 1.37 1.41 1.46 1.39 1.43 1.48 1.53 1.44 1.48 1.53 1.58
Amps 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
HI PR 228 245 248 254 258 277 281 287 293 315 319 326 334 359 364 372 375 404 409 418 420 452 458 468
Lo PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166
600
MBh 17.8 18.3 19.8 21.3 17.4 17.9 19.3 20.8 16.9 17.4 18.9 20.3 16.5 17.0 18.4 19.8 15.7 16.2 17.5 18.8 14.5 15.0 16.2 17.4
S/T 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.38 0.89 0.80 0.60 0.39 0.92 0.83 0.63 0.40 0.93 0.83 0.63 0.41
∆T 22 20 17 12 22 21 17 12 22 21 17 12 23 21 17 12 22 20 17 12 21 19 16 11
kW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.29 1.25 1.28 1.33 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.47 1.52 1.57
Amps 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 226 243 246 251 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 447 454 464
Lo PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 137 142 155 165
525
MBh 16.4 16.9 18.3 19.6 16.0 16.5 17.9 19.2 15.6 16.1 17.4 18.7 15.3 15.7 17.0 18.2 14.5 14.9 16.2 17.3 13.4 13.8 15.0 16.1
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11
kW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.39 1.44 1.37 1.40 1.45 1.50 1.42 1.45 1.50 1.56
Amps 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8
HI PR 223 240 244 249 252 271 275 281 287 309 313 320 327 352 357 364 368 396 401 410 412 443 449 459
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160241**/ CA*f3636C6C*+tXV/ mBVC1200** low StAge
SS-DSXC16 www.goodmanmfg.com 5
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
675
MBh 18.6 19.0 20.3 21.7 18.2 18.6 19.9 21.2 17.8 18.1 19.4 20.7 17.3 17.7 18.9 20.2 16.5 16.8 18.0 19.2 15.2 15.6 16.6 17.8
S/T 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.81 0.61 1.00 1.00 0.82 0.61
∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 23 20 16 21 21 19 15
kW 1.10 1.12 1.16 1.20 1.19 1.21 1.25 1.30 1.26 1.29 1.34 1.38 1.33 1.37 1.41 1.46 1.39 1.43 1.48 1.53 1.44 1.48 1.53 1.58
Amps 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
HI PR 228 245 248 254 258 277 281 287 293 315 319 326 334 359 364 372 375 404 409 418 420 452 458 468
Lo PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166
600
MBh 18.1 18.5 19.7 21.1 17.7 18.1 19.3 20.6 17.2 17.6 18.8 20.1 16.8 17.2 18.4 19.6 16.0 16.3 17.4 18.7 14.8 15.1 16.2 17.3
S/T 0.89 0.84 0.68 0.51 0.92 0.87 0.70 0.53 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58
∆T 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 17 24 24 21 17 23 22 19 15
kW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.29 1.25 1.28 1.33 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.47 1.52 1.57
Amps 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 226 243 246 251 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 447 454 464
Lo PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 137 142 155 165
525
MBh 16.7 17.1 18.2 19.5 16.3 16.7 17.8 19.0 15.9 16.3 17.4 18.6 15.5 15.9 17.0 18.1 14.8 15.1 16.1 17.2 13.7 14.0 14.9 15.9
S/T 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.92 0.75 0.56
∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 25 21 17 25 24 21 17 24 23 20 16
kW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.39 1.44 1.37 1.40 1.45 1.50 1.42 1.45 1.50 1.56
Amps 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8
HI PR 223 240 244 249 252 271 275 281 287 309 313 320 327 352 357 364 368 396 401 410 412 443 449 459
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
85
675
MBh 19.0 19.3 20.2 21.6 18.5 18.9 19.8 21.1 18.1 18.4 19.3 20.6 17.6 18.0 18.8 20.1 16.8 17.1 17.9 19.1 15.5 15.8 16.6 17.7
S/T 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.97 0.79 1.00 1.00 0.98 0.79
∆T 25 25 23 20 25 25 24 21 25 25 24 21 24 24 24 21 23 23 24 20 21 22 22 19
kW 1.10 1.12 1.16 1.20 1.19 1.21 1.25 1.30 1.26 1.29 1.34 1.38 1.33 1.37 1.41 1.46 1.39 1.43 1.48 1.53 1.44 1.48 1.53 1.58
Amps 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
HI PR 228 245 248 254 258 277 281 287 293 315 319 326 334 359 364 372 375 404 409 418 420 452 458 468
Lo PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166
600
MBh 18.4 18.8 19.6 21.0 18.0 18.3 19.2 20.5 17.5 17.9 18.7 20.0 17.1 17.4 18.3 19.5 16.3 16.6 17.4 18.5 15.1 15.4 16.1 17.2
S/T 0.93 0.90 0.81 0.66 0.97 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.93 0.75 1.00 1.00 0.93 0.76
∆T 26 26 24 21 27 26 25 21 27 26 25 21 26 26 25 22 25 25 25 21 23 24 23 20
kW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.29 1.25 1.28 1.33 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.47 1.52 1.57
Amps 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 226 243 246 251 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 447 454 464
Lo PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 137 142 155 165
525
MBh 17.0 17.3 18.1 19.3 16.6 16.9 17.7 18.9 16.2 16.5 17.3 18.4 15.8 16.1 16.9 18.0 15.0 15.3 16.0 17.1 13.9 14.2 14.8 15.8
S/T 0.90 0.87 0.78 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.90 0.73
∆T 26.8 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 26 26 25 22 24 25 23 20
kW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.39 1.44 1.37 1.40 1.45 1.50 1.42 1.45 1.50 1.56
Amps 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8
HI PR 223 240 244 249 252 271 275 281 287 309 313 320 327 352 357 364 368 396 401 410 412 443 449 459
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160241**/ CA*f3636C6C*+tXV/ mBVC1200** low StAge (Cont.)
6 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
900
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.76 0.63 0.44 - 0.78 0.66 0.45 - 0.80 0.67 0.47 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
kW 1.50 1.53 1.58 - 1.62 1.65 1.71 - 1.72 1.76 1.82 - 1.81 1.86 1.92 - 1.89 1.94 2.00 - 1.96 2.01 2.07 -
Amps 5.9 6.0 6.2 - 6.4 6.5 6.7 - 6.9 7.1 7.3 - 7.4 7.5 7.8 - 7.8 8.0 8.3 - 8.3 8.5 8.7 -
HI PR 237 255 258 - 268 288 292 - 304 327 332 - 347 373 378 - 390 419 425 - 437 470 476 -
Lo PR 122 125 137 - 125 129 141 - 129 134 146 - 133 137 150 - 136 140 153 - 139 143 156 -
800
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
kW 1.49 1.52 1.57 - 1.61 1.64 1.69 - 1.71 1.75 1.80 - 1.80 1.84 1.90 - 1.88 1.92 1.98 - 1.94 1.99 2.06 -
Amps 5.9 6.0 6.2 - 6.3 6.5 6.7 - 6.8 7.0 7.2 - 7.3 7.5 7.7 - 7.8 7.9 8.2 - 8.2 8.4 8.7 -
HI PR 234 252 256 - 265 285 289 - 301 324 329 - 343 369 374 - 386 415 421 - 432 465 471 -
Lo PR 120 124 136 - 124 128 140 - 128 132 144 - 132 136 148 - 134 138 151 - 138 142 155 -
700
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
kW 1.48 1.51 1.56 - 1.59 1.63 1.68 - 1.69 1.73 1.79 - 1.78 1.82 1.89 - 1.86 1.90 1.97 - 1.93 1.97 2.04 -
Amps 5.8 5.9 6.1 - 6.3 6.4 6.6 - 6.8 6.9 7.2 - 7.2 7.4 7.6 - 7.7 7.9 8.1 - 8.1 8.3 8.6 -
HI PR 232 249 253 - 262 282 286 - 298 321 325 - 340 365 370 - 382 411 417 - 428 460 467 -
Lo PR 119 123 134 - 123 127 138 - 127 131 143 - 130 134 147 - 133 137 150 - 136 140 153 -
75
900
MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4
S/T 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.91 0.82 0.62 0.40 0.94 0.84 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.88 0.67 0.43
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 1.50 1.53 1.58 1.63 1.62 1.65 1.71 1.77 1.72 1.76 1.82 1.88 1.81 1.86 1.92 1.98 1.89 1.94 2.00 2.07 1.96 2.01 2.07 2.15
Amps 5.9 6.0 6.2 6.5 6.4 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.7 9.1
HI PR 237 255 258 264 268 288 292 298 304 327 332 339 347 373 378 386 390 419 425 435 437 470 476 487
Lo PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
800
MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.82 0.73 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.94 0.84 0.64 0.41
∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 11 21 19 16 11
kW 1.49 1.52 1.57 1.62 1.61 1.64 1.69 1.75 1.71 1.75 1.80 1.87 1.80 1.84 1.90 1.97 1.88 1.92 1.98 2.05 1.94 1.99 2.06 2.13
Amps 5.9 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.5 7.7 8.0 7.8 7.9 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 234 252 256 261 265 285 289 295 301 324 329 336 343 369 374 382 386 415 421 430 432 465 471 482
Lo PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
700
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.79 0.71 0.54 0.34 0.82 0.73 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11
kW 1.48 1.51 1.56 1.61 1.59 1.63 1.68 1.74 1.69 1.73 1.79 1.85 1.78 1.82 1.89 1.95 1.86 1.90 1.97 2.04 1.93 1.97 2.04 2.11
Amps 5.8 5.9 6.1 6.3 6.3 6.4 6.6 6.8 6.8 6.9 7.2 7.4 7.2 7.4 7.6 7.9 7.7 7.9 8.1 8.4 8.1 8.3 8.6 8.9
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 382 411 417 426 428 460 467 477
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160241**/ CA*f3636C6C*+tXV/ mBVC1200** high StAge
SS-DSXC16 www.goodmanmfg.com 7
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
900
MBh 24.3 24.9 26.6 28.4 23.8 24.3 26.0 27.7 23.2 23.7 25.3 27.1 22.6 23.1 24.7 26.4 21.5 22.0 23.5 25.1 19.9 20.4 21.8 23.3
S/T 0.94 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62
∆T 23 22 20 16 24 23 20 16 24 23 20 16 23 24 20 16 22 22 20 16 20 21 18 15
kW 1.50 1.53 1.58 1.63 1.62 1.65 1.71 1.77 1.72 1.76 1.82 1.88 1.81 1.86 1.92 1.98 1.89 1.94 2.00 2.07 1.96 2.01 2.07 2.15
Amps 5.9 6.0 6.2 6.5 6.4 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.7 9.1
HI PR 237 255 258 264 268 288 292 298 304 327 332 339 347 373 378 386 390 419 425 435 437 470 476 487
Lo PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
800
MBh 23.6 24.1 25.8 27.6 23.1 23.6 25.2 26.9 22.5 23.0 24.6 26.3 22.0 22.5 24.0 25.7 20.9 21.3 22.8 24.4 19.3 19.8 21.1 22.6
S/T 0.90 0.84 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.97 0.79 0.59
∆T 24 23 20 16 25 24 21 16 25 24 21 16 25 24 21 17 24 24 21 16 22 22 19 15
kW 1.49 1.52 1.57 1.62 1.61 1.64 1.69 1.75 1.71 1.75 1.80 1.87 1.80 1.84 1.90 1.97 1.88 1.92 1.98 2.05 1.94 1.99 2.06 2.13
Amps 5.9 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.5 7.7 8.0 7.8 7.9 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 234 252 256 261 265 285 289 295 301 324 329 336 343 369 374 382 386 415 421 430 432 465 471 482
Lo PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
700
MBh 21.8 22.3 23.8 25.5 21.3 21.8 23.3 24.9 20.8 21.3 22.7 24.3 20.3 20.7 22.2 23.7 19.3 19.7 21.0 22.5 17.9 18.2 19.5 20.8
S/T 0.87 0.81 0.66 0.50 0.90 0.84 0.69 0.51 0.92 0.87 0.70 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.75 0.56 1.00 0.93 0.76 0.57
∆T 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 19 16
kW 1.48 1.51 1.56 1.61 1.59 1.63 1.68 1.74 1.69 1.73 1.79 1.85 1.78 1.82 1.89 1.95 1.86 1.90 1.97 2.04 1.93 1.97 2.04 2.11
Amps 5.8 5.9 6.1 6.3 6.3 6.4 6.6 6.8 6.8 6.9 7.2 7.4 7.2 7.4 7.6 7.9 7.7 7.9 8.1 8.4 8.1 8.3 8.6 8.9
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 382 411 417 426 428 460 467 477
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
85
900
MBh 24.8 25.2 26.4 28.2 24.2 24.7 25.8 27.6 23.6 24.1 25.2 26.9 23.0 23.5 24.6 26.2 21.9 22.3 23.4 24.9 20.3 20.7 21.6 23.1
S/T 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.80 1.00 1.00 0.99 0.80
∆T 25 25 23 20 25 25 24 20 24 25 24 20 24 24 24 21 22 23 23 20 21 21 22 19
kW 1.50 1.53 1.58 1.63 1.62 1.65 1.71 1.77 1.72 1.76 1.82 1.88 1.81 1.86 1.92 1.98 1.89 1.94 2.00 2.07 1.96 2.01 2.07 2.15
Amps 5.9 6.0 6.2 6.5 6.4 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.7 9.1
HI PR 237 255 258 264 268 288 292 298 304 327 332 339 347 373 378 386 390 419 425 435 437 470 476 487
Lo PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
800
MBh 24.0 24.5 25.7 27.4 23.5 23.9 25.1 26.8 22.9 23.4 24.5 26.1 22.4 22.8 23.9 25.5 21.2 21.7 22.7 24.2 19.7 20.1 21.0 22.4
S/T 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.94 0.77
∆T 26 26 24 21 26 26 25 21 26 26 25 21 26 26 25 21 24 25 24 21 23 23 23 20
kW 1.49 1.52 1.57 1.62 1.61 1.64 1.69 1.75 1.71 1.75 1.80 1.87 1.80 1.84 1.90 1.97 1.88 1.92 1.98 2.05 1.94 1.99 2.06 2.13
Amps 5.9 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.5 7.7 8.0 7.8 7.9 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 234 252 256 261 265 285 289 295 301 324 329 336 343 369 374 382 386 415 421 430 432 465 471 482
Lo PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
700
MBh 22.2 22.6 23.7 25.3 21.7 22.1 23.1 24.7 21.2 21.6 22.6 24.1 20.6 21.0 22.0 23.5 19.6 20.0 20.9 22.3 18.2 18.5 19.4 20.7
S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
∆T 26.5 26 25 21 27 26 25 22 27 26 25 22 27 27 25 22 26 26 25 21 24 24 23 20
kW 1.48 1.51 1.56 1.61 1.59 1.63 1.68 1.74 1.69 1.73 1.79 1.85 1.78 1.82 1.89 1.95 1.86 1.90 1.97 2.04 1.93 1.97 2.04 2.11
Amps 5.8 5.9 6.1 6.3 6.3 6.4 6.6 6.8 6.8 6.9 7.2 7.4 7.2 7.4 7.6 7.9 7.7 7.9 8.1 8.4 8.1 8.3 8.6 8.9
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 382 411 417 426 428 460 467 477
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160241**/ CA*f3636C6C*+tXV/ mBVC1200** high StAge (Cont.)
8 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
904
MBh 24.9 25.8 28.3 - 24.3 25.2 27.6 - 23.8 24.6 27.0 - 23.2 24.0 26.3 - 22.0 22.8 25.0 - 20.4 21.1 23.2 -
S/T 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.45 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
kW 1.50 1.53 1.58 - 1.61 1.65 1.70 - 1.72 1.75 1.81 - 1.81 1.85 1.91 - 1.88 1.93 1.99 - 1.95 2.00 2.06 -
Amps 5.8 6.0 6.2 - 6.3 6.4 6.6 - 6.8 7.0 7.2 - 7.3 7.4 7.7 - 7.7 7.9 8.1 - 8.2 8.3 8.6 -
HI PR 220 237 240 - 249 268 271 - 283 304 309 - 322 347 352 - 348 374 380 - 413 444 450 -
Lo PR 119 123 134 - 123 127 138 - 127 131 143 - 130 135 147 - 133 137 150 - 136 141 153 -
800
MBh 24.2 25.1 27.5 - 23.6 24.5 26.8 - 23.1 23.9 26.2 - 22.5 23.3 25.5 - 21.4 22.2 24.3 - 19.8 20.5 22.5 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
kW 1.49 1.52 1.57 - 1.60 1.64 1.69 - 1.70 1.74 1.80 - 1.79 1.83 1.89 - 1.87 1.91 1.97 - 1.93 1.98 2.04 -
Amps 5.8 5.9 6.1 - 6.2 6.4 6.6 - 6.7 6.9 7.1 - 7.2 7.4 7.6 - 7.6 7.8 8.1 - 8.1 8.3 8.5 -
HI PR 218 234 238 - 246 265 269 - 280 301 306 - 319 343 348 - 345 371 376 - 409 439 446 -
Lo PR 118 122 133 - 122 125 137 - 126 130 142 - 129 133 145 - 132 136 148 - 135 139 152 -
696
MBh 22.3 23.1 25.3 - 21.8 22.6 24.8 - 21.3 22.1 24.2 - 20.8 21.5 23.6 - 19.7 20.4 22.4 - 18.3 18.9 20.8 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.76 0.63 0.44 -
∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 1.47 1.51 1.55 - 1.59 1.62 1.67 - 1.69 1.73 1.78 - 1.78 1.82 1.88 - 1.85 1.89 1.96 - 1.92 1.96 2.03 -
Amps 5.7 5.9 6.0 - 6.2 6.3 6.5 - 6.7 6.8 7.1 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.0 8.2 8.5 -
HI PR 216 232 235 - 244 262 266 - 277 298 303 - 316 340 345 - 341 367 372 - 404 435 441 -
Lo PR 117 121 132 - 120 124 136 - 125 128 140 - 128 132 144 - 130 134 147 - 134 138 150 -
75
904
MBh 25.3 26.1 28.2 30.3 24.7 25.5 27.6 29.6 24.2 24.9 26.9 28.9 23.6 24.3 26.3 28.2 22.4 23.0 24.9 26.8 20.7 21.4 23.1 24.8
S/T 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.77 0.59 0.38 0.89 0.80 0.60 0.39 0.93 0.83 0.63 0.40 0.93 0.84 0.63 0.41
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 1.50 1.53 1.58 1.63 1.61 1.65 1.70 1.76 1.72 1.75 1.81 1.87 1.81 1.85 1.91 1.97 1.88 1.93 1.99 2.06 1.95 2.00 2.06 2.13
Amps 5.8 6.0 6.2 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.4 7.3 7.4 7.7 7.9 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9
HI PR 220 237 240 245 249 268 271 277 283 304 309 315 322 347 352 359 348 374 380 388 413 444 450 460
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 153 163
800
MBh 24.6 25.3 27.4 29.4 24.0 24.7 26.8 28.7 23.5 24.1 26.1 28.0 22.9 23.6 25.5 27.4 21.7 22.4 24.2 26.0 20.1 20.7 22.4 24.1
S/T 0.78 0.69 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 12 21 19 16 11
kW 1.49 1.52 1.57 1.62 1.60 1.64 1.69 1.74 1.70 1.74 1.80 1.86 1.79 1.83 1.89 1.96 1.87 1.91 1.97 2.04 1.93 1.98 2.04 2.11
Amps 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4 8.1 8.3 8.5 8.9
HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455
Lo PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
696
MBh 22.7 23.4 25.3 27.2 22.2 22.8 24.7 26.5 21.6 22.3 24.1 25.9 21.1 21.7 23.5 25.3 20.1 20.7 22.4 24.0 18.6 19.1 20.7 22.2
S/T 0.75 0.67 0.51 0.33 0.78 0.69 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.56 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.37
∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11
kW 1.47 1.51 1.55 1.60 1.59 1.62 1.67 1.73 1.69 1.73 1.78 1.84 1.78 1.82 1.88 1.94 1.85 1.89 1.96 2.02 1.92 1.96 2.03 2.10
Amps 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 341 367 372 380 404 435 441 451
Lo PR 117 121 132 140 120 124 136 144 125 128 140 149 128 132 144 153 130 134 147 156 134 138 150 160
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160361** / CA*f3743*6A* +tXV / mBVC1600** low StAge
SS-DSXC16 www.goodmanmfg.com 9
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
904
MBh 25.8 26.3 28.1 30.1 25.2 25.7 27.5 29.4 24.6 25.1 26.8 28.7 24.0 24.5 26.2 28.0 22.8 23.3 24.9 26.6 21.1 21.6 23.0 24.6
S/T 0.89 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 0.96 0.78 0.58
∆T 23 22 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 21 18 15
kW 1.50 1.53 1.58 1.63 1.61 1.65 1.70 1.76 1.72 1.75 1.81 1.87 1.81 1.85 1.91 1.97 1.88 1.93 1.99 2.06 1.95 2.00 2.06 2.13
Amps 5.8 6.0 6.2 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.4 7.3 7.4 7.7 7.9 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9
HI PR 220 237 240 245 249 268 271 277 283 304 309 315 322 347 352 359 348 374 380 388 413 444 450 460
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 153 163
800
MBh 25.0 25.6 27.3 29.2 24.4 25.0 26.7 28.5 23.9 24.4 26.1 27.9 23.3 23.8 25.4 27.2 22.1 22.6 24.1 25.8 20.5 20.9 22.4 23.9
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
∆T 24 23 20 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 16 23 22 19 15
kW 1.49 1.52 1.57 1.62 1.60 1.64 1.69 1.74 1.70 1.74 1.80 1.86 1.79 1.83 1.89 1.96 1.87 1.91 1.97 2.04 1.93 1.98 2.04 2.11
Amps 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4 8.1 8.3 8.5 8.9
HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455
Lo PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
696
MBh 23.1 23.6 25.2 27.0 22.6 23.1 24.6 26.3 22.0 22.5 24.1 25.7 21.5 22.0 23.5 25.1 20.4 20.9 22.3 23.8 18.9 19.3 20.6 22.1
S/T 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.87 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.88 0.71 0.53 0.94 0.88 0.72 0.54
∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 25 21 17 25 24 21 17 24 23 20 16
kW 1.47 1.51 1.55 1.60 1.59 1.62 1.67 1.73 1.69 1.73 1.78 1.84 1.78 1.82 1.88 1.94 1.85 1.89 1.96 2.02 1.92 1.96 2.03 2.10
Amps 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 341 367 372 380 404 435 441 451
Lo PR 117 121 132 140 120 124 136 144 125 128 140 149 128 132 144 153 130 134 147 156 134 138 150 160
85
904
MBh 26.2 26.7 28.0 29.9 25.6 26.1 27.4 29.2 25.0 25.5 26.7 28.5 24.4 24.9 26.1 27.8 23.2 23.6 24.8 26.4 21.5 21.9 22.9 24.5
S/T 0.94 0.90 0.82 0.66 0.97 0.94 0.84 0.69 0.99 0.96 0.87 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.94 0.76
∆T 25 25 23 20 25 25 24 20 25 25 24 20 25 25 24 21 24 24 23 20 22 22 22 19
kW 1.50 1.53 1.58 1.63 1.61 1.65 1.70 1.76 1.72 1.75 1.81 1.87 1.81 1.85 1.91 1.97 1.88 1.93 1.99 2.06 1.95 2.00 2.06 2.13
Amps 5.8 6.0 6.2 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.4 7.3 7.4 7.7 7.9 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9
HI PR 220 237 240 245 249 268 271 277 283 304 309 315 322 347 352 359 348 374 380 388 413 444 450 460
Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 153 163
800
MBh 25.5 26.0 27.2 29.0 24.9 25.4 26.6 28.3 24.3 24.8 25.9 27.7 23.7 24.2 25.3 27.0 22.5 22.9 24.0 25.6 20.8 21.3 22.3 23.7
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
∆T 26 26 24 21 26 26 25 21 26 26 25 21 27 26 25 21 26 26 24 21 24 24 23 20
kW 1.49 1.52 1.57 1.62 1.60 1.64 1.69 1.74 1.70 1.74 1.80 1.86 1.79 1.83 1.89 1.96 1.87 1.91 1.97 2.04 1.93 1.98 2.04 2.11
Amps 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4 8.1 8.3 8.5 8.9
HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455
Lo PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
696
MBh 23.5 24.0 25.1 26.8 23.0 23.4 24.5 26.2 22.4 22.8 23.9 25.5 21.9 22.3 23.3 24.9 20.8 21.2 22.2 23.7 19.2 19.6 20.5 21.9
S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.78 0.63 0.91 0.88 0.80 0.65 0.94 0.91 0.82 0.67 0.98 0.95 0.85 0.69 0.99 0.95 0.86 0.70
∆T 26.7 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 27 26 25 22 25 25 23 20
kW 1.47 1.51 1.55 1.60 1.59 1.62 1.67 1.73 1.69 1.73 1.78 1.84 1.78 1.82 1.88 1.94 1.85 1.89 1.96 2.02 1.92 1.96 2.03 2.10
Amps 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 341 367 372 380 404 435 441 451
Lo PR 117 121 132 140 120 124 136 144 125 128 140 149 128 132 144 153 130 134 147 156 134 138 150 160
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160361** / CA*f3743*6A* +tXV / mBVC1600** low StAge (Cont.)
10 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1356
MBh 33.9 35.1 38.5 - 33.1 34.3 37.6 - 32.3 33.5 36.7 - 31.5 32.7 35.8 - 30.0 31.1 34.0 - 27.8 28.8 31.5 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
∆T 17 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 16 13 10 -
kW 2.14 2.18 2.25 - 2.31 2.36 2.43 - 2.45 2.51 2.59 - 2.58 2.64 2.73 - 2.69 2.76 2.85 - 2.79 2.85 2.95 -
Amps 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.5 9.7 10.0 - 10.1 10.4 10.7 - 10.8 11.1 11.4 - 11.4 11.7 12.1 -
HI PR 232 249 253 - 262 282 286 - 298 321 325 - 340 365 370 - 367 394 400 - 435 467 474 -
Lo PR 116 120 131 - 119 123 135 - 124 127 139 - 127 131 143 - 129 133 146 - 133 137 149 -
1200
MBh 32.9 34.1 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.6 - 30.6 31.7 34.8 - 29.1 30.2 33.0 - 26.9 27.9 30.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.79 0.66 0.45 -
∆T 17 15 11 - 17 15 11 - 18 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
kW 2.12 2.17 2.24 - 2.29 2.34 2.41 - 2.43 2.49 2.57 - 2.56 2.62 2.71 - 2.67 2.73 2.82 - 2.77 2.83 2.93 -
Amps 8.0 8.2 8.5 - 8.7 8.9 9.2 - 9.4 9.6 10.0 - 10.1 10.3 10.6 - 10.7 11.0 11.3 - 11.3 11.6 12.0 -
HI PR 230 247 250 - 260 279 283 - 295 317 322 - 336 362 367 - 363 390 396 - 430 463 469 -
Lo PR 115 119 129 - 118 122 133 - 122 126 138 - 126 130 141 - 128 132 144 - 131 135 148 -
1043
MBh 30.4 31.5 34.5 - 29.7 30.8 33.7 - 29.0 30.0 32.9 - 28.3 29.3 32.1 - 26.9 27.8 30.5 - 24.9 25.8 28.2 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.70 0.59 0.41 - 0.72 0.61 0.42 - 0.75 0.63 0.44 - 0.76 0.63 0.44 -
∆T 18 15 12 - 18 15 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
kW 2.10 2.15 2.22 - 2.27 2.32 2.39 - 2.41 2.47 2.55 - 2.54 2.60 2.68 - 2.65 2.71 2.80 - 2.74 2.81 2.90 -
Amps 8.0 8.2 8.4 - 8.6 8.8 9.1 - 9.3 9.6 9.9 - 10.0 10.2 10.5 - 10.6 10.9 11.2 - 11.2 11.5 11.9 -
HI PR 227 244 248 - 257 276 280 - 292 314 319 - 333 358 363 - 360 387 392 - 426 458 465 -
Lo PR 114 117 128 - 117 121 132 - 121 125 136 - 124 128 140 - 127 131 143 - 130 134 146 -
75
1356
MBh 34.5 35.5 38.4 41.2 33.7 34.7 37.5 40.3 32.9 33.8 36.6 39.3 32.1 33.0 35.7 38.4 30.5 31.4 34.0 36.4 28.2 29.1 31.5 33.8
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
∆T 19 18 14 10 19 18 15 10 19 18 15 10 19 18 15 10 19 18 14 10 18 17 14 9
kW 2.14 2.18 2.25 2.33 2.31 2.36 2.43 2.51 2.45 2.51 2.59 2.68 2.58 2.64 2.73 2.82 2.69 2.76 2.85 2.95 2.79 2.85 2.95 3.05
Amps 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.1 11.4 11.9 11.4 11.7 12.1 12.6
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 367 394 400 409 435 467 474 484
Lo PR 116 120 131 139 119 123 135 143 124 127 139 148 127 131 143 152 129 133 146 155 133 137 149 159
1200
MBh 33.5 34.5 37.3 40.0 32.7 33.7 36.4 39.1 31.9 32.9 35.6 38.2 31.1 32.1 34.7 37.2 29.6 30.5 33.0 35.4 27.4 28.2 30.5 32.8
S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.89 0.79 0.60 0.39 0.89 0.80 0.61 0.39
∆T 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 19 15 10 19 17 14 10
kW 2.12 2.17 2.24 2.31 2.29 2.34 2.41 2.49 2.43 2.49 2.57 2.66 2.56 2.62 2.71 2.80 2.67 2.73 2.82 2.92 2.77 2.83 2.93 3.03
Amps 8.0 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 11.0 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 230 247 250 256 260 279 283 289 295 317 322 329 336 362 367 375 363 390 396 405 430 463 469 480
Lo PR 115 119 129 138 118 122 133 142 122 126 138 147 126 130 141 151 128 132 144 154 131 135 148 157
1043
MBh 30.9 31.8 34.4 37.0 30.2 31.1 33.6 36.1 29.5 30.3 32.8 35.2 28.7 29.6 32.0 34.4 27.3 28.1 30.4 32.7 25.3 26.0 28.2 30.3
S/T 0.75 0.67 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.38
∆T 20 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 14 10
kW 2.10 2.15 2.22 2.29 2.27 2.32 2.39 2.47 2.41 2.47 2.55 2.63 2.54 2.60 2.68 2.78 2.65 2.71 2.80 2.90 2.74 2.81 2.90 3.00
Amps 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.9 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 227 244 248 253 257 276 280 286 292 314 319 326 333 358 363 371 360 387 392 401 426 458 465 475
Lo PR 114 117 128 136 117 121 132 140 121 125 136 145 124 128 140 149 127 131 143 152 130 134 146 156
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160361** / CA*f3743*6A* +tXV / mBVC1600** high StAge
SS-DSXC16 www.goodmanmfg.com 11
Product SPecificationS
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1356
MBh 35.1 35.9 38.3 41.0 34.3 35.0 37.4 40.0 33.5 34.2 36.5 39.0 32.6 33.4 35.6 38.1 31.0 31.7 33.9 36.2 28.7 29.4 31.4 33.5
S/T 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.73 0.54 1.00 0.92 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.96 0.78 0.59
∆T 21 20 18 14 22 21 18 14 22 21 18 14 22 21 18 14 21 21 18 14 19 19 17 13
kW 2.14 2.18 2.25 2.33 2.31 2.36 2.43 2.51 2.45 2.51 2.59 2.68 2.58 2.64 2.73 2.82 2.69 2.76 2.85 2.95 2.79 2.85 2.95 3.05
Amps 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.1 11.4 11.9 11.4 11.7 12.1 12.6
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 367 394 400 409 435 467 474 484
Lo PR 116 120 131 139 119 123 135 143 124 127 139 148 127 131 143 152 129 133 146 155 133 137 149 159
1200
MBh 34.1 34.8 37.2 39.8 33.3 34.0 36.3 38.8 32.5 33.2 35.5 37.9 31.7 32.4 34.6 37.0 30.1 30.8 32.9 35.1 27.9 28.5 30.4 32.5
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.68 0.50 0.91 0.85 0.69 0.52 0.94 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
∆T 22 21 19 15 23 22 19 15 23 22 19 15 23 22 19 15 22 21 19 15 21 20 17 14
kW 2.12 2.17 2.24 2.31 2.29 2.34 2.41 2.49 2.43 2.49 2.57 2.66 2.56 2.62 2.71 2.80 2.67 2.73 2.82 2.92 2.77 2.83 2.93 3.03
Amps 8.0 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 11.0 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 230 247 250 256 260 279 283 289 295 317 322 329 336 362 367 375 363 390 396 405 430 463 469 480
Lo PR 115 119 129 138 118 122 133 142 122 126 138 147 126 130 141 151 128 132 144 154 131 135 148 157
1043
MBh 31.4 32.1 34.3 36.7 30.7 31.4 33.5 35.8 30.0 30.6 32.7 35.0 29.3 29.9 31.9 34.1 27.8 28.4 30.3 32.4 25.7 26.3 28.1 30.0
S/T 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.94 0.88 0.72 0.53 0.95 0.89 0.72 0.54
∆T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 16 23 22 19 15 21 21 18 14
kW 2.10 2.15 2.22 2.29 2.27 2.32 2.39 2.47 2.41 2.47 2.55 2.63 2.54 2.60 2.68 2.78 2.65 2.71 2.80 2.90 2.74 2.81 2.90 3.00
Amps 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.9 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 227 244 248 253 257 276 280 286 292 314 319 326 333 358 363 371 360 387 392 401 426 458 465 475
Lo PR 114 117 128 136 117 121 132 140 121 125 136 145 124 128 140 149 127 131 143 152 130 134 146 156
85
1356
MBh 35.7 36.4 38.1 40.7 34.9 35.6 37.2 39.7 34.0 34.7 36.3 38.8 33.2 33.9 35.5 37.8 31.6 32.2 33.7 35.9 29.2 29.8 31.2 33.3
S/T 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.96 0.87 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.94 0.76
∆T 23 22 21 18 23 23 21 19 23 23 21 19 23 23 22 19 21 22 21 18 20 20 20 17
kW 2.14 2.18 2.25 2.33 2.31 2.36 2.43 2.51 2.45 2.51 2.59 2.68 2.58 2.64 2.73 2.82 2.69 2.76 2.85 2.95 2.79 2.85 2.95 3.05
Amps 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.1 11.4 11.9 11.4 11.7 12.1 12.6
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 367 394 400 409 435 467 474 484
Lo PR 116 120 131 139 119 123 135 143 124 127 139 148 127 131 143 152 129 133 146 155 133 137 149 159
1200
MBh 34.7 35.3 37.0 39.5 33.9 34.5 36.1 38.6 33.1 33.7 35.3 37.6 32.2 32.9 34.4 36.7 30.6 31.2 32.7 34.9 28.4 28.9 30.3 32.3
S/T 0.90 0.86 0.78 0.63 0.93 0.90 0.81 0.66 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.73
∆T 24 23 22 19 24 24 22 19 24 24 22 19 24 24 23 20 23 24 22 19 22 22 21 18
kW 2.12 2.17 2.24 2.31 2.29 2.34 2.41 2.49 2.43 2.49 2.57 2.66 2.56 2.62 2.71 2.80 2.67 2.73 2.82 2.92 2.77 2.83 2.93 3.03
Amps 8.0 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 11.0 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 230 247 250 256 260 279 283 289 295 317 322 329 336 362 367 375 363 390 396 405 430 463 469 480
Lo PR 115 119 129 138 118 122 133 142 122 126 138 147 126 130 141 151 128 132 144 154 131 135 148 157
1043
MBh 32.0 32.6 34.2 36.4 31.3 31.9 33.4 35.6 30.5 31.1 32.6 34.7 29.8 30.3 31.8 33.9 28.3 28.8 30.2 32.2 26.2 26.7 28.0 29.8
S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.78 0.63 0.92 0.89 0.80 0.65 0.95 0.91 0.82 0.67 0.98 0.95 0.86 0.69 0.99 0.96 0.86 0.70
∆T 24 24 23 20 25 24 23 20 25 24 23 20 25 24 23 20 24 24 23 20 23 22 21 18
kW 2.10 2.15 2.22 2.29 2.27 2.32 2.39 2.47 2.41 2.47 2.55 2.63 2.54 2.60 2.68 2.78 2.65 2.71 2.80 2.90 2.74 2.81 2.90 3.00
Amps 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.9 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 227 244 248 253 257 276 280 286 292 314 319 326 333 358 363 371 360 387 392 401 426 458 465 475
Lo PR 114 117 128 136 117 121 132 140 121 125 136 145 124 128 140 149 127 131 143 152 130 134 146 156
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160361** / CA*f3743*6A* +tXV / mBVC1600** high StAge (Cont.)
12 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160481B* / CA*f4860*6**+tXV/mBVC2000** low StAge
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1238
MBh 34.3 35.5 38.9 - 33.5 34.7 38.0 - 32.7 33.9 37.1 - 31.9 33.1 36.2 - 30.3 31.4 34.4 - 28.1 29.1 31.9 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 16 13 - 18 15 12 -
kW 2.04 2.08 2.15 - 2.20 2.25 2.32 - 2.34 2.39 2.47 - 2.46 2.52 2.60 - 2.57 2.63 2.71 - 2.66 2.72 2.81 -
Amps 9.8 10.0 10.2 - 10.4 10.6 10.9 - 11.2 11.4 11.8 - 11.9 12.1 12.5 - 12.5 12.8 13.2 - 13.2 13.4 13.8 -
HI PR 216 232 245 - 242 261 275 - 275 296 313 - 314 337 356 - 353 380 401 - 390 419 443 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 133 142 155 -
1100
MBh 33.3 34.5 37.8 - 32.5 33.7 36.9 - 31.7 32.9 36.1 - 31.0 32.1 35.2 - 29.4 30.5 33.4 - 27.3 28.3 31.0 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
kW 2.02 2.07 2.13 - 2.18 2.23 2.30 - 2.32 2.37 2.45 - 2.44 2.50 2.58 - 2.55 2.60 2.69 - 2.64 2.70 2.79 -
Amps 9.7 9.9 10.2 - 10.4 10.6 10.9 - 11.1 11.3 11.7 - 11.8 12.0 12.4 - 12.4 12.7 13.0 - 13.1 13.3 13.7 -
HI PR 214 230 243 - 240 258 272 - 273 293 310 - 310 334 353 - 349 376 397 - 386 415 439 -
LO PR 106 112 123 - 112 119 130 - 116 123 135 - 122 130 142 - 128 136 148 - 132 141 153 -
963
MBh 30.7 31.9 34.9 - 30.0 31.1 34.1 - 29.3 30.4 33.3 - 28.6 29.6 32.5 - 27.2 28.2 30.8 - 25.2 26.1 28.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
∆T 20 17 13 - 20 18 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -
kW 1.97 2.02 2.08 - 2.13 2.17 2.24 - 2.26 2.31 2.39 - 2.38 2.43 2.51 - 2.48 2.54 2.62 - 2.57 2.63 2.71 -
Amps 9.5 9.7 9.9 - 10.1 10.3 10.6 - 10.8 11.1 11.4 - 11.5 11.7 12.1 - 12.1 12.4 12.7 - 12.7 13.0 13.4 -
HI PR 207 223 235 - 232 250 264 - 264 285 300 - 301 324 342 - 339 365 385 - 374 403 425 -
LO PR 102 109 119 - 108 115 126 - 113 120 131 - 118 126 137 - 124 132 144 - 128 136 149 -
75
1238
MBh 34.9 35.9 38.9 41.7 34.1 35.1 38.0 40.7 33.3 34.2 37.1 39.8 32.4 33.4 36.2 38.8 30.8 31.7 34.4 36.9 28.6 29.4 31.8 34.2
S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 11 21 19 16 11
kW 2.06 2.10 2.17 2.24 2.22 2.27 2.34 2.42 2.36 2.41 2.49 2.57 2.48 2.54 2.62 2.71 2.59 2.65 2.74 2.83 2.68 2.74 2.83 2.93
Amps 9.9 10.0 10.3 10.6 10.5 10.7 11.0 11.4 11.3 11.5 11.8 12.2 11.9 12.2 12.6 13.0 12.6 12.9 13.3 13.7 13.3 13.6 14.0 14.4
HI PR 218 235 248 258 245 263 278 290 278 299 316 330 317 341 360 375 356 383 405 422 394 424 447 467
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167
1100
MBh 33.9 34.9 37.7 40.5 33.1 34.1 36.9 39.6 32.3 33.2 36.0 38.6 31.5 32.4 35.1 37.7 29.9 30.8 33.3 35.8 27.7 28.5 30.9 33.2
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 18 12 23 21 17 12 21 20 16 11
kW 2.04 2.08 2.15 2.22 2.20 2.25 2.32 2.40 2.34 2.39 2.47 2.55 2.46 2.52 2.60 2.69 2.57 2.63 2.71 2.81 2.66 2.72 2.81 2.91
Amps 9.8 10.0 10.2 10.6 10.4 10.6 10.9 11.3 11.2 11.4 11.8 12.1 11.9 12.1 12.5 12.9 12.5 12.8 13.2 13.6 13.2 13.4 13.8 14.3
HI PR 216 232 245 256 242 261 275 287 275 296 313 326 314 338 356 372 353 380 401 418 390 420 443 462
LO PR 107 114 124 132 113 120 131 139 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165
963
MBh 31.3 32.2 34.8 37.4 30.5 31.4 34.0 36.5 29.8 30.7 33.2 35.6 29.1 29.9 32.4 34.8 27.6 28.4 30.8 33.0 25.6 26.3 28.5 30.6
S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39
∆T 23 21 17 12 23 22 18 12 24 22 18 12 24 22 18 12 23 21 18 12 22 20 16 11
kW 1.99 2.03 2.10 2.17 2.14 2.19 2.26 2.34 2.28 2.33 2.41 2.49 2.40 2.45 2.54 2.62 2.50 2.56 2.64 2.73 2.59 2.65 2.74 2.83
Amps 9.6 9.7 10.0 10.3 10.2 10.4 10.7 11.0 10.9 11.2 11.5 11.8 11.6 11.8 12.2 12.6 12.2 12.5 12.8 13.3 12.8 13.1 13.5 14.0
HI PR 209 225 238 248 235 253 267 278 267 287 304 317 304 327 346 361 342 368 389 406 378 407 430 448
LO PR 104 110 120 128 109 116 127 135 114 121 132 141 119 127 139 148 125 133 145 155 129 138 150 160
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
SS-DSXC16 www.goodmanmfg.com 13
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160481B* / CA*f4860*6**+tXV/mBVC2000** low StAge (Cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1238
MBh 35.5 36.3 38.8 41.4 34.7 35.4 37.9 40.5 33.8 34.6 37.0 39.5 33.0 33.7 36.1 38.5 31.4 32.1 34.2 36.6 29.1 29.7 31.7 33.9
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.81 0.61
∆T 24 23 20 16 25 24 21 16 25 24 21 16 25 24 21 17 23 24 20 16 22 22 19 15
kW 2.07 2.12 2.19 2.26 2.24 2.28 2.36 2.44 2.38 2.43 2.51 2.60 2.50 2.56 2.65 2.74 2.61 2.67 2.76 2.85 2.70 2.77 2.86 2.96
Amps 9.9 10.1 10.4 10.7 10.6 10.8 11.1 11.5 11.4 11.6 11.9 12.3 12.0 12.3 12.7 13.1 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6
HI PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168
1100
MBh 34.5 35.2 37.6 40.2 33.7 34.4 36.8 39.3 32.9 33.6 35.9 38.4 32.1 32.8 35.0 37.4 30.5 31.1 33.3 35.5 28.2 28.8 30.8 32.9
S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
∆T 25 24 21 17 26 25 21 17 26 25 21 17 26 25 22 17 25 25 21 17 24 23 20 16
kW 2.06 2.10 2.17 2.24 2.22 2.27 2.34 2.42 2.36 2.41 2.49 2.57 2.48 2.54 2.62 2.71 2.59 2.65 2.74 2.83 2.68 2.74 2.83 2.93
Amps 9.9 10.0 10.3 10.6 10.5 10.7 11.0 11.4 11.3 11.5 11.8 12.2 12.0 12.2 12.6 13.0 12.6 12.9 13.3 13.7 13.3 13.6 14.0 14.4
HI PR 218 235 248 258 245 263 278 290 278 299 316 330 317 341 360 375 356 384 405 422 394 424 447 467
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167
963
MBh 31.8 32.5 34.7 37.1 31.1 31.7 33.9 36.3 30.3 31.0 33.1 35.4 29.6 30.2 32.3 34.5 28.1 28.7 30.7 32.8 26.0 26.6 28.4 30.4
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
∆T 26 25 22 17 26 25 22 17 26 25 22 17 26 25 22 18 26 25 22 17 24 23 20 16
kW 2.01 2.05 2.11 2.18 2.16 2.21 2.28 2.36 2.30 2.35 2.43 2.51 2.42 2.48 2.56 2.64 2.52 2.58 2.67 2.76 2.61 2.67 2.76 2.86
Amps 9.6 9.8 10.1 10.4 10.3 10.5 10.8 11.1 11.0 11.2 11.6 11.9 11.7 11.9 12.3 12.7 12.3 12.6 12.9 13.4 12.9 13.2 13.6 14.1
HI PR 211 228 240 251 237 255 270 281 270 290 307 320 307 331 349 364 346 372 393 410 382 411 434 453
LO PR 105 111 121 129 110 118 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162
85
1238
MBh 36.1 36.8 38.6 41.1 35.3 36.0 37.7 40.2 34.4 35.1 36.8 39.2 33.6 34.2 35.9 38.3 31.9 32.5 34.1 36.4 29.6 30.1 31.6 33.7
S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
∆T 26 26 24 21 26 26 25 21 26 26 25 21 25 25 25 21 24 24 24 21 22 22 23 20
kW 2.09 2.13 2.20 2.28 2.25 2.30 2.38 2.46 2.40 2.45 2.53 2.62 2.53 2.58 2.67 2.76 2.63 2.69 2.78 2.88 2.73 2.79 2.88 2.98
Amps 10.0 10.2 10.5 10.8 10.7 10.9 11.2 11.6 11.5 11.7 12.0 12.4 12.1 12.4 12.8 13.2 12.8 13.1 13.5 13.9 13.5 13.8 14.2 14.7
HI PR 222 239 253 264 249 268 284 296 284 305 322 336 323 348 367 383 364 391 413 431 402 432 456 476
LO PR 110 117 128 136 116 124 135 144 121 128 140 149 127 135 147 157 133 141 154 164 137 146 160 170
1100
MBh 35.1 35.7 37.4 39.9 34.3 34.9 36.6 39.0 33.4 34.1 35.7 38.1 32.6 33.3 34.8 37.2 31.0 31.6 33.1 35.3 28.7 29.3 30.6 32.7
S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
∆T 27 27 25 22 27 27 26 22 28 27 26 22 27 27 26 22 26 26 25 22 24 24 24 21
kW 2.07 2.12 2.19 2.26 2.24 2.28 2.36 2.44 2.38 2.43 2.51 2.60 2.50 2.56 2.65 2.74 2.61 2.67 2.76 2.85 2.70 2.77 2.86 2.96
Amps 9.9 10.1 10.4 10.7 10.6 10.8 11.1 11.5 11.4 11.6 11.9 12.3 12.0 12.3 12.7 13.1 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6
HI PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168
963
MBh 32.4 33.0 34.6 36.9 31.6 32.2 33.8 36.0 30.9 31.5 32.9 35.1 30.1 30.7 32.1 34.3 28.6 29.2 30.5 32.6 26.5 27.0 28.3 30.2
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
∆T 28 27 26 22 28 27 26 22 28 28 26 23 28 28 26 23 27 27 26 22 25 26 24 21
kW 2.02 2.07 2.13 2.20 2.18 2.23 2.30 2.38 2.32 2.37 2.45 2.53 2.44 2.50 2.58 2.67 2.55 2.60 2.69 2.78 2.64 2.69 2.79 2.88
Amps 9.7 9.9 10.2 10.5 10.4 10.6 10.9 11.2 11.1 11.3 11.7 12.0 11.8 12.0 12.4 12.8 12.4 12.7 13.0 13.5 13.1 13.3 13.7 14.2
HI PR 214 230 243 253 240 258 272 284 273 293 310 323 310 334 353 368 349 376 397 414 386 415 438 457
LO PR 106 112 123 131 112 119 130 138 116 123 135 143 122 130 141 151 128 136 148 158 132 140 153 163
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
14 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160481B* / CA*f4860*6**+tXV/mBVC2000** high StAge
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1800
MBh 46.1 47.7 52.3 - 45.0 46.6 51.1 - 43.9 45.5 49.9 - 42.8 44.4 48.7 - 40.7 42.2 46.2 - 37.7 39.1 42.8 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
kW 3.03 3.10 3.19 - 3.27 3.34 3.45 - 3.48 3.55 3.67 - 3.66 3.74 3.87 - 3.82 3.90 4.03 - 3.95 4.04 4.18 -
Amps 14.6 14.9 15.3 - 15.5 15.9 16.3 - 16.7 17.0 17.5 - 17.6 18.0 18.5 - 18.6 19.0 19.5 - 19.5 20.0 20.5 -
HI PR 235 253 267 - 264 284 300 - 300 323 341 - 341 367 388 - 384 413 437 - 424 457 482 -
LO PR 104 111 121 - 110 117 128 - 114 122 133 - 120 128 140 - 126 134 146 - 130 139 151 -
1600
MBh 44.7 46.3 50.8 - 43.7 45.3 49.6 - 42.6 44.2 48.4 - 41.6 43.1 47.2 - 39.5 41.0 44.9 - 36.6 37.9 41.6 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
kW 3.01 3.07 3.17 - 3.24 3.31 3.42 - 3.45 3.52 3.64 - 3.63 3.71 3.83 - 3.78 3.87 4.00 - 3.92 4.01 4.14 -
Amps 14.5 14.8 15.1 - 15.4 15.7 16.2 - 16.5 16.9 17.3 - 17.5 17.8 18.4 - 18.4 18.8 19.4 - 19.4 19.8 20.4 -
HI PR 233 250 264 - 261 281 297 - 297 319 337 - 338 364 384 - 380 409 432 - 420 452 478 -
LO PR 103 110 120 - 109 116 127 - 113 120 132 - 119 127 138 - 125 133 145 - 129 137 150 -
1400
MBh 41.3 42.8 46.9 - 40.3 41.8 45.8 - 39.4 40.8 44.7 - 38.4 39.8 43.6 - 36.5 37.8 41.4 - 33.8 35.0 38.4 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
kW 2.93 3.00 3.09 - 3.16 3.23 3.33 - 3.36 3.44 3.55 - 3.54 3.62 3.74 - 3.69 3.77 3.90 - 3.82 3.90 4.04 -
Amps 14.2 14.4 14.8 - 15.1 15.4 15.8 - 16.1 16.5 16.9 - 17.1 17.4 17.9 - 18.0 18.4 18.9 - 18.9 19.3 19.9 -
HI PR 226 243 256 - 253 272 288 - 288 310 327 - 328 353 373 - 369 397 419 - 408 439 463 -
LO PR 100 106 116 - 106 112 123 - 110 117 128 - 115 123 134 - 121 129 140 - 125 133 145 -
75
1800
MBh 46.8 48.2 52.2 56.0 45.7 47.1 51.0 54.7 44.7 46.0 49.8 53.4 43.6 44.9 48.6 52.1 41.4 42.6 46.1 49.5 38.3 39.5 42.7 45.9
S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 20 19 15 11 20 19 15 11 20 19 15 11 21 19 16 11 20 19 15 11 19 17 14 10
kW 3.06 3.12 3.22 3.33 3.29 3.37 3.48 3.59 3.51 3.58 3.70 3.83 3.69 3.77 3.90 4.03 3.85 3.94 4.07 4.21 3.99 4.08 4.21 4.36
Amps 14.7 15.0 15.4 15.9 15.7 16.0 16.4 16.9 16.8 17.1 17.6 18.2 17.8 18.1 18.6 19.3 18.7 19.1 19.7 20.3 19.7 20.1 20.7 21.4
HI PR 237 255 270 281 266 287 303 316 303 326 344 359 345 371 392 409 388 418 441 460 429 461 487 508
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163
1600
MBh 45.5 46.8 50.7 54.4 44.4 45.7 49.5 53.1 43.4 44.6 48.3 51.9 42.3 43.6 47.1 50.6 40.2 41.4 44.8 48.1 37.2 38.3 41.5 44.5
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 20 16 11 20 18 15 10
kW 3.03 3.10 3.20 3.30 3.27 3.34 3.45 3.56 3.48 3.55 3.67 3.79 3.66 3.74 3.87 4.00 3.82 3.90 4.03 4.17 3.95 4.04 4.18 4.32
Amps 14.6 14.9 15.3 15.7 15.5 15.9 16.3 16.8 16.7 17.0 17.5 18.0 17.6 18.0 18.5 19.1 18.6 19.0 19.5 20.2 19.5 20.0 20.5 21.2
HI PR 235 253 267 278 264 284 300 312 300 323 341 355 342 368 388 405 384 413 437 455 424 457 482 503
LO PR 104 111 121 129 110 117 128 136 114 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161
1400
MBh 42.0 43.2 46.8 50.2 41.0 42.2 45.7 49.0 40.0 41.2 44.6 47.9 39.0 40.2 43.5 46.7 37.1 38.2 41.3 44.4 34.4 35.4 38.3 41.1
S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39
∆T 21 20 16 11 22 20 16 11 22 20 16 11 22 20 16 11 22 20 16 11 20 19 15 10
kW 2.96 3.02 3.12 3.22 3.19 3.26 3.36 3.47 3.39 3.46 3.58 3.70 3.57 3.65 3.77 3.90 3.72 3.80 3.93 4.06 3.85 3.94 4.07 4.21
Amps 14.3 14.5 14.9 15.4 15.2 15.5 15.9 16.4 16.3 16.6 17.1 17.6 17.2 17.6 18.1 18.6 18.1 18.5 19.1 19.7 19.1 19.5 20.0 20.7
HI PR 228 245 259 270 256 275 291 303 291 313 331 345 331 356 376 393 373 401 423 442 412 443 468 488
LO PR 101 108 117 125 107 114 124 132 111 118 129 137 117 124 135 144 122 130 142 151 126 134 147 156
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
SS-DSXC16 www.goodmanmfg.com 15
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160481B* / CA*f4860*6**+tXV/mBVC2000** high StAge (Cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1800
MBh 47.7 48.7 52.0 55.6 46.6 47.6 50.8 54.3 45.5 46.4 49.6 53.0 44.3 45.3 48.4 51.8 42.1 43.0 46.0 49.2 39.0 39.9 42.6 45.5
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.81 0.61
∆T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 22 22 19 15 20 20 18 14
kW 3.08 3.15 3.25 3.35 3.32 3.39 3.51 3.62 3.53 3.61 3.73 3.86 3.72 3.81 3.93 4.07 3.88 3.97 4.10 4.24 4.02 4.11 4.25 4.40
Amps 14.8 15.1 15.5 16.0 15.8 16.1 16.5 17.1 16.9 17.3 17.8 18.3 17.9 18.3 18.8 19.4 18.9 19.3 19.8 20.5 19.9 20.3 20.9 21.6
HI PR 240 258 272 284 269 289 306 319 306 329 348 363 348 375 396 413 392 422 445 465 433 466 492 513
LO PR 106 113 123 131 112 119 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164
1600
MBh 46.3 47.3 50.5 54.0 45.2 46.2 49.4 52.8 44.1 45.1 48.2 51.5 43.1 44.0 47.0 50.2 40.9 41.8 44.7 47.7 37.9 38.7 41.4 44.2
S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15
kW 3.06 3.12 3.22 3.33 3.29 3.37 3.48 3.59 3.51 3.58 3.70 3.83 3.69 3.77 3.90 4.03 3.85 3.94 4.07 4.21 3.99 4.08 4.21 4.36
Amps 14.7 15.0 15.4 15.9 15.7 16.0 16.4 16.9 16.8 17.1 17.6 18.2 17.8 18.1 18.7 19.3 18.7 19.1 19.7 20.3 19.7 20.1 20.7 21.4
HI PR 237 255 270 281 266 287 303 316 303 326 344 359 345 371 392 409 388 418 441 460 429 461 487 508
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163
1400
MBh 42.7 43.6 46.6 49.9 41.7 42.6 45.6 48.7 40.7 41.6 44.5 47.5 39.7 40.6 43.4 46.4 37.8 38.6 41.2 44.1 35.0 35.7 38.2 40.8
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 22 19 15
kW 2.98 3.05 3.14 3.24 3.21 3.28 3.39 3.50 3.42 3.49 3.61 3.73 3.60 3.68 3.80 3.93 3.75 3.84 3.96 4.10 3.88 3.97 4.11 4.25
Amps 14.4 14.6 15.0 15.5 15.3 15.6 16.0 16.5 16.4 16.7 17.2 17.7 17.3 17.7 18.2 18.8 18.3 18.7 19.2 19.8 19.2 19.6 20.2 20.9
HI PR 230 248 262 273 258 278 294 306 294 316 334 348 335 360 380 397 376 405 428 446 416 448 473 493
LO PR 102 109 119 126 108 115 125 133 112 119 130 139 118 125 137 146 123 131 143 153 128 136 148 158
85
1800
MBh 48.5 49.4 51.8 55.2 47.4 48.3 50.6 54.0 46.2 47.1 49.4 52.7 45.1 46.0 48.2 51.4 42.9 43.7 45.8 48.8 39.7 40.5 42.4 45.2
S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
∆T 24 24 22 19 24 24 23 20 24 24 23 20 23 23 23 20 22 22 23 19 20 21 21 18
kW 3.11 3.17 3.27 3.38 3.35 3.42 3.53 3.65 3.56 3.64 3.76 3.89 3.75 3.84 3.97 4.10 3.92 4.00 4.14 4.28 4.05 4.15 4.29 4.44
Amps 14.9 15.2 15.6 16.1 15.9 16.2 16.7 17.2 17.0 17.4 17.9 18.5 18.0 18.4 18.9 19.6 19.0 19.4 20.0 20.7 20.0 20.4 21.0 21.8
HI PR 242 261 275 287 272 292 309 322 309 332 351 366 352 379 400 417 396 426 450 469 437 471 497 518
LO PR 107 114 125 133 113 121 132 140 118 125 137 146 124 132 144 153 130 138 151 161 134 143 156 166
1600
MBh 47.1 48.0 50.3 53.6 46.0 46.9 49.1 52.4 44.9 45.8 47.9 51.1 43.8 44.7 46.8 49.9 41.6 42.4 44.4 47.4 38.5 39.3 41.2 43.9
S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
∆T 25 25 23 20 25 25 24 20 25 25 24 20 25 25 24 21 24 24 23 20 22 23 22 19
kW 3.08 3.15 3.25 3.35 3.32 3.39 3.51 3.62 3.53 3.61 3.73 3.86 3.72 3.81 3.93 4.07 3.88 3.97 4.10 4.24 4.02 4.11 4.25 4.40
Amps 14.8 15.1 15.5 16.0 15.8 16.1 16.5 17.1 16.9 17.3 17.8 18.3 17.9 18.3 18.8 19.4 18.9 19.3 19.8 20.5 19.9 20.3 20.9 21.6
HI PR 240 258 272 284 269 289 306 319 306 329 348 363 348 375 396 413 392 422 445 465 433 466 492 513
LO PR 106 113 123 131 112 119 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164
1400
MBh 43.5 44.3 46.4 49.5 42.5 43.3 45.3 48.4 41.4 42.2 44.2 47.2 40.4 41.2 43.2 46.0 38.4 39.2 41.0 43.7 35.6 36.3 38.0 40.5
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
∆T 25 25 24 21 26 25 24 21 26 25 24 21 26 26 24 21 25 25 24 21 23 24 22 19
kW 3.01 3.07 3.17 3.27 3.24 3.31 3.42 3.53 3.45 3.52 3.64 3.76 3.63 3.71 3.83 3.96 3.78 3.87 4.00 4.13 3.92 4.01 4.14 4.28
Amps 14.5 14.7 15.1 15.6 15.4 15.7 16.2 16.7 16.5 16.9 17.3 17.9 17.5 17.8 18.3 18.9 18.4 18.8 19.4 20.0 19.4 19.8 20.4 21.0
HI PR 233 250 264 276 261 281 296 309 297 319 337 352 338 364 384 401 380 409 432 451 420 452 477 498
LO PR 103 110 120 128 109 116 127 135 113 120 132 140 119 127 138 147 125 133 145 154 129 137 150 159
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
16 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160601B* / CA*f4961*6A*+tXV / mBVC2000**-1** low StAge
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1350
MBh 39.3 40.7 44.6 - 38.3 39.7 43.5 - 37.4 38.8 42.5 - 36.5 37.8 41.5 - 34.7 36.0 39.4 - 32.1 33.3 36.5 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 2.43 2.49 2.57 - 2.63 2.69 2.78 - 2.81 2.87 2.97 - 2.96 3.03 3.14 - 3.09 3.17 3.28 - 3.21 3.28 3.40 -
Amps 9.9 10.1 10.4 - 10.7 10.9 11.3 - 11.6 11.9 12.3 - 12.4 12.7 13.1 - 13.2 13.5 14.0 - 14.0 14.3 14.8 -
HI PR 214 231 244 - 241 259 273 - 274 294 311 - 312 335 354 - 351 377 398 - 387 417 440 -
LO PR 107 114 124 - 113 120 132 - 118 125 137 - 124 132 144 - 130 138 150 - 134 143 156 -
1217
MBh 38.7 40.1 43.9 - 37.8 39.2 42.9 - 36.9 38.2 41.9 - 36.0 37.3 40.9 - 34.2 35.4 38.8 - 31.7 32.8 35.9 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -
∆T 21 18 13 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
kW 2.42 2.47 2.56 - 2.62 2.68 2.77 - 2.79 2.85 2.95 - 2.94 3.01 3.12 - 3.07 3.15 3.26 - 3.19 3.26 3.38 -
Amps 9.8 10.0 10.4 - 10.6 10.9 11.2 - 11.5 11.8 12.2 - 12.3 12.6 13.0 - 13.1 13.4 13.9 - 13.9 14.2 14.7 -
HI PR 213 229 242 - 239 257 271 - 272 292 309 - 309 333 352 - 348 375 396 - 385 414 437 -
LO PR 106 113 124 - 112 120 131 - 117 124 136 - 123 131 143 - 129 137 149 - 133 142 155 -
1050
MBh 35.7 37.0 40.5 - 34.9 36.1 39.6 - 34.0 35.3 38.6 - 33.2 34.4 37.7 - 31.5 32.7 35.8 - 29.2 30.3 33.2 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.78 0.65 0.45 -
∆T 21 18 14 - 21 19 14 - 21 19 14 - 22 19 14 - 21 18 14 - 20 17 13 -
kW 2.36 2.41 2.49 - 2.55 2.61 2.69 - 2.72 2.78 2.88 - 2.87 2.93 3.03 - 2.99 3.06 3.17 - 3.10 3.18 3.29 -
Amps 9.5 9.8 10.1 - 10.3 10.6 10.9 - 11.2 11.5 11.8 - 12.0 12.3 12.7 - 12.7 13.0 13.5 - 13.5 13.8 14.3 -
HI PR 207 222 235 - 232 249 263 - 264 284 299 - 300 323 341 - 338 363 384 - 373 401 424 -
LO PR 103 110 120 - 109 116 127 - 113 121 132 - 119 127 138 - 125 133 145 - 129 137 150 -
75
1350
MBh 39.92 41.10 44.49 47.75 38.99 40.14 43.45 46.64 38.06 39.19 42.42 45.52 37.13 38.23 41.38 44.41 35.28 36.32 39.31 42.19 32.68 33.64 36.42 39.08
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11
kW 2.45 2.51 2.59 2.68 2.65 2.72 2.81 2.90 2.83 2.90 3.00 3.10 2.99 3.06 3.16 3.27 3.12 3.19 3.31 3.42 3.24 3.31 3.43 3.55
Amps 10.0 10.2 10.5 10.9 10.8 11.0 11.4 11.8 11.7 12.0 12.4 12.8 12.5 12.8 13.2 13.7 13.3 13.6 14.1 14.6 14.1 14.4 14.9 15.5
HI PR 217 233 246 257 243 262 276 288 276 297 314 328 315 339 358 373 354 381 402 420 391 421 445 464
LO PR 108 115 126 134 114 122 133 142 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
1217
MBh 39.3 40.5 43.8 47.0 38.4 39.6 42.8 45.9 37.5 38.6 41.8 44.9 36.6 37.7 40.8 43.8 34.8 35.8 38.7 41.6 32.2 33.1 35.9 38.5
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40
∆T 24 22 18 12 24 22 18 13 24 22 18 13 24 22 18 13 24 22 18 12 22 21 17 12
kW 2.44 2.49 2.58 2.67 2.64 2.70 2.79 2.89 2.81 2.88 2.98 3.08 2.97 3.04 3.14 3.25 3.10 3.17 3.28 3.40 3.22 3.29 3.41 3.53
Amps 9.9 10.1 10.5 10.9 10.7 11.0 11.3 11.7 11.6 11.9 12.3 12.8 12.4 12.7 13.1 13.6 13.2 13.5 14.0 14.5 14.0 14.4 14.8 15.4
HI PR 215 231 244 255 241 260 274 286 274 295 312 325 313 336 355 370 352 378 400 417 389 418 442 461
LO PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166
1050
MBh 36.3 37.4 40.5 43.4 35.5 36.5 39.5 42.4 34.6 35.6 38.6 41.4 33.8 34.8 37.6 40.4 32.1 33.0 35.8 38.4 29.7 30.6 33.1 35.5
S/T 0.77 0.69 0.52 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.88 0.79 0.60 0.38
∆T 24 23 18 13 25 23 19 13 25 23 19 13 25 23 19 13 25 23 19 13 23 21 17 12
kW 2.38 2.43 2.51 2.60 2.57 2.63 2.72 2.81 2.74 2.80 2.90 3.00 2.89 2.96 3.06 3.17 3.02 3.09 3.20 3.31 3.13 3.20 3.32 3.43
Amps 9.6 9.9 10.2 10.6 10.4 10.7 11.0 11.4 11.3 11.6 12.0 12.4 12.1 12.4 12.8 13.3 12.9 13.2 13.6 14.1 13.6 14.0 14.4 15.0
HI PR 209 224 237 247 234 252 266 277 266 286 303 316 303 326 345 359 341 367 388 404 377 406 428 447
LO PR 104 111 121 129 110 117 128 136 115 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
SS-DSXC16 www.goodmanmfg.com 17
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160601B*/CA*f4961*6A*+tXV / mBVC2000**-1** low StAge (Cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1350
MBh 40.63 41.51 44.35 47.41 39.68 40.55 43.32 46.31 38.74 39.58 42.29 45.21 37.79 38.62 41.26 44.11 35.90 36.69 39.20 41.90 33.26 33.98 36.31 38.81
S/T 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.98 0.79 0.59 1.00 0.98 0.80 0.60
∆T 25 24 21 17 26 25 21 17 26 25 21 17 26 25 22 17 24 24 21 17 23 23 20 16
kW 2.47 2.53 2.62 2.70 2.68 2.74 2.83 2.93 2.86 2.92 3.02 3.13 3.01 3.08 3.19 3.30 3.15 3.22 3.33 3.45 3.26 3.34 3.46 3.58
Amps 10.1 10.3 10.6 11.0 10.9 11.1 11.5 11.9 11.8 12.1 12.5 13.0 12.6 12.9 13.4 13.9 13.4 13.8 14.2 14.8 14.2 14.6 15.1 15.6
HI PR 219 235 249 259 245 264 279 291 279 300 317 331 318 342 361 377 358 385 406 424 395 425 449 468
LO PR 109 116 127 135 116 123 134 143 120 128 139 149 126 134 147 156 132 141 154 164 137 145 159 169
1217
MBh 40.0 40.9 43.7 46.7 39.1 39.9 42.7 45.6 38.2 39.0 41.7 44.5 37.2 38.0 40.6 43.5 35.4 36.1 38.6 41.3 32.8 33.5 35.8 38.2
S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.94 0.77 0.57
∆T 26 25 22 18 27 26 22 18 27 26 22 18 27 26 23 18 27 26 22 18 25 24 21 17
kW 2.46 2.52 2.60 2.69 2.66 2.72 2.81 2.91 2.84 2.90 3.00 3.11 3.00 3.07 3.17 3.28 3.13 3.20 3.31 3.43 3.24 3.32 3.44 3.56
Amps 10.0 10.2 10.6 11.0 10.8 11.1 11.4 11.8 11.7 12.0 12.4 12.9 12.5 12.8 13.3 13.8 13.3 13.7 14.1 14.7 14.1 14.5 15.0 15.5
HI PR 217 234 247 257 244 262 277 289 277 298 315 329 316 340 359 374 355 382 404 421 392 422 446 465
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 152 162 136 144 158 168
1050
MBh 36.9 37.8 40.3 43.1 36.1 36.9 39.4 42.1 35.2 36.0 38.5 41.1 34.4 35.1 37.5 40.1 32.6 33.4 35.6 38.1 30.2 30.9 33.0 35.3
S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.67 0.50 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.97 0.91 0.74 0.55
∆T 27 26 23 18 28 26 23 18 28 27 23 18 28 27 23 19 27 26 23 18 26 25 21 17
kW 2.40 2.45 2.53 2.62 2.59 2.65 2.74 2.84 2.77 2.83 2.93 3.03 2.92 2.99 3.09 3.20 3.05 3.12 3.23 3.34 3.16 3.23 3.35 3.46
Amps 9.7 10.0 10.3 10.7 10.5 10.8 11.1 11.5 11.4 11.7 12.1 12.5 12.2 12.5 12.9 13.4 13.0 13.3 13.7 14.3 13.7 14.1 14.6 15.1
HI PR 211 227 239 250 236 254 269 280 269 289 306 319 306 330 348 363 345 371 392 408 381 410 433 451
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 122 129 141 150 127 135 148 158 132 140 153 163
85
1350
MBh 41.34 42.14 44.13 47.08 40.38 41.16 43.11 45.99 39.41 40.18 42.08 44.89 38.45 39.20 41.05 43.80 36.53 37.24 39.00 41.61 33.84 34.49 36.13 38.54
S/T 0.96 0.92 0.83 0.68 0.99 0.96 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78
∆T 27 27 25 22 27 27 25 22 27 27 25 22 26 27 26 22 25 25 25 22 23 23 24 20
kW 2.50 2.55 2.64 2.73 2.70 2.76 2.86 2.96 2.88 2.95 3.05 3.16 3.04 3.11 3.22 3.33 3.18 3.25 3.36 3.48 3.29 3.37 3.49 3.61
Amps 10.1 10.4 10.7 11.1 11.0 11.2 11.6 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 14.9 14.4 14.7 15.2 15.8
HI PR 221 238 251 262 248 267 282 294 282 303 320 334 321 346 365 381 361 389 411 428 399 430 454 473
LO PR 110 118 128 137 117 124 136 144 121 129 141 150 127 136 148 158 134 142 155 165 138 147 160 171
1217
MBh 40.7 41.5 43.5 46.4 39.8 40.5 42.5 45.3 38.8 39.6 41.5 44.2 37.9 38.6 40.4 43.1 36.0 36.7 38.4 41.0 33.3 34.0 35.6 38.0
S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.74
∆T 28 28 26 23 29 28 27 23 29 28 27 23 29 28 27 23 27 28 26 23 25 26 25 21
kW 2.48 2.54 2.62 2.71 2.68 2.75 2.84 2.94 2.86 2.93 3.03 3.14 3.02 3.09 3.20 3.31 3.16 3.23 3.34 3.46 3.27 3.35 3.47 3.59
Amps 10.1 10.3 10.7 11.1 10.9 11.2 11.5 12.0 11.8 12.1 12.5 13.0 12.7 13.0 13.4 13.9 13.5 13.8 14.3 14.8 14.3 14.6 15.1 15.7
HI PR 219 236 249 260 246 265 280 292 280 301 318 332 319 343 362 378 359 386 408 425 396 427 450 470
LO PR 110 117 127 136 116 123 135 143 120 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170
1050
MBh 37.6 38.3 40.1 42.8 36.7 37.4 39.2 41.8 35.8 36.5 38.3 40.8 35.0 35.6 37.3 39.8 33.2 33.9 35.5 37.8 30.8 31.4 32.9 35.0
S/T 0.88 0.85 0.77 0.63 0.92 0.88 0.80 0.65 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 0.98 0.88 0.72
∆T 29 29 27 23 29 29 27 24 30 29 27 24 30 29 28 24 29 29 27 24 27 27 25 22
kW 2.42 2.47 2.56 2.64 2.62 2.67 2.77 2.86 2.79 2.85 2.95 3.05 2.94 3.01 3.12 3.22 3.07 3.15 3.25 3.37 3.19 3.26 3.38 3.49
Amps 9.8 10.0 10.4 10.8 10.6 10.9 11.2 11.6 11.5 11.8 12.2 12.6 12.3 12.6 13.0 13.5 13.1 13.4 13.9 14.4 13.9 14.2 14.7 15.3
HI PR 213 229 242 252 239 257 271 283 272 292 309 322 309 333 352 367 348 374 395 412 385 414 437 456
LO PR 106 113 124 132 112 120 131 139 117 124 136 145 123 131 143 152 129 137 149 159 133 142 155 165
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
18 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160601B* / CA*f4961*6A*+tXV / mBVC2000**-1** high StAge
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
2025
MBh 55.9 57.9 63.4 - 54.6 56.5 62.0 - 53.3 55.2 60.5 - 52.0 53.9 59.0 - 49.4 51.2 56.1 - 45.7 47.4 51.9 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 16 12 - 18 15 12 -
kW 3.57 3.65 3.77 - 3.86 3.95 4.09 - 4.12 4.22 4.36 - 4.35 4.45 4.61 - 4.55 4.65 4.82 - 4.71 4.83 4.99 -
Amps 14.1 14.4 14.9 - 15.2 15.6 16.2 - 16.6 17.0 17.6 - 17.8 18.2 18.9 - 19.0 19.4 20.1 - 20.1 20.6 21.3 -
HI PR 231 248 262 - 259 279 294 - 295 317 335 - 336 361 381 - 377 406 429 - 417 449 474 -
LO PR 104 111 121 - 110 117 128 - 114 122 133 - 120 128 140 - 126 134 146 - 130 139 151 -
1800
MBh 54.2 56.2 61.6 - 53.0 54.9 60.1 - 51.7 53.6 58.7 - 50.4 52.3 57.3 - 47.9 49.7 54.4 - 44.4 46.0 50.4 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 3.54 3.62 3.74 - 3.83 3.92 4.05 - 4.09 4.18 4.33 - 4.31 4.41 4.57 - 4.51 4.61 4.77 - 4.67 4.78 4.95 -
Amps 13.9 14.3 14.8 - 15.1 15.5 16.0 - 16.5 16.9 17.4 - 17.6 18.1 18.7 - 18.8 19.2 19.9 - 19.9 20.4 21.1 -
HI PR 229 246 260 - 256 276 291 - 292 314 331 - 332 357 377 - 374 402 425 - 413 444 469 -
LO PR 103 110 120 - 109 116 127 - 113 120 132 - 119 127 138 - 125 133 145 - 129 137 150 -
1575
MBh 50.1 51.9 56.8 - 48.9 50.7 55.5 - 47.7 49.5 54.2 - 46.6 48.3 52.9 - 44.2 45.8 50.2 - 41.0 42.5 46.5 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
∆T 20 17 13 - 20 17 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -
kW 3.45 3.53 3.65 - 3.73 3.82 3.95 - 3.98 4.07 4.21 - 4.20 4.30 4.45 - 4.39 4.49 4.65 - 4.55 4.66 4.82 -
Amps 13.6 13.9 14.4 - 14.7 15.0 15.6 - 16.0 16.4 16.9 - 17.1 17.5 18.1 - 18.2 18.7 19.3 - 19.4 19.8 20.5 -
HI PR 222 239 252 - 249 268 283 - 283 304 321 - 322 347 366 - 363 390 412 - 401 431 455 -
LO PR 100 106 116 - 106 112 123 - 110 117 128 - 115 123 134 - 121 129 140 - 125 133 145 -
75
2025
MBh 56.80 58.48 63.30 67.94 55.48 57.12 61.83 66.36 54.16 55.76 60.36 64.78 52.84 54.40 58.89 63.20 50.20 51.68 55.94 60.04 46.50 47.87 51.82 55.62
S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 22 20 16 11 22 20 17 11 22 20 17 12 22 20 17 12 22 20 17 11 20 19 15 11
kW 3.60 3.68 3.81 3.94 3.90 3.99 4.12 4.27 4.16 4.26 4.40 4.56 4.39 4.49 4.65 4.81 4.59 4.70 4.86 5.03 4.76 4.87 5.04 5.22
Amps 14.2 14.6 15.0 15.6 15.4 15.8 16.3 16.9 16.8 17.2 17.8 18.5 18.0 18.4 19.0 19.8 19.1 19.6 20.3 21.1 20.3 20.8 21.5 22.4
HI PR 233 251 265 276 262 282 297 310 298 320 338 353 339 365 385 402 381 410 433 452 421 453 479 499
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163
1800
MBh 55.1 56.8 61.5 66.0 53.9 55.5 60.0 64.4 52.6 54.1 58.6 62.9 51.3 52.8 57.2 61.4 48.7 50.2 54.3 58.3 45.1 46.5 50.3 54.0
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11
kW 3.57 3.65 3.78 3.90 3.87 3.95 4.09 4.23 4.12 4.22 4.36 4.52 4.35 4.45 4.61 4.77 4.55 4.65 4.82 4.99 4.71 4.83 5.00 5.17
Amps 14.1 14.4 14.9 15.5 15.3 15.6 16.2 16.8 16.6 17.0 17.6 18.3 17.8 18.2 18.9 19.6 19.0 19.4 20.1 20.9 20.1 20.6 21.3 22.2
HI PR 231 248 262 274 259 279 294 307 295 317 335 349 336 361 381 398 378 406 429 447 417 449 474 494
LO PR 104 111 121 129 110 117 128 136 114 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161
1575
MBh 50.9 52.4 56.7 60.9 49.7 51.2 55.4 59.5 48.5 50.0 54.1 58.1 47.3 48.8 52.8 56.6 45.0 46.3 50.1 53.8 41.7 42.9 46.4 49.8
S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39
∆T 23 21 17 12 23 22 18 12 23 22 18 12 24 22 18 12 23 21 18 12 22 20 16 11
kW 3.48 3.56 3.68 3.80 3.77 3.85 3.98 4.12 4.02 4.11 4.25 4.40 4.24 4.34 4.49 4.64 4.43 4.53 4.69 4.85 4.59 4.70 4.86 5.03
Amps 13.7 14.0 14.5 15.0 14.8 15.2 15.7 16.3 16.1 16.5 17.1 17.8 17.3 17.7 18.3 19.0 18.4 18.9 19.5 20.3 19.5 20.0 20.7 21.5
HI PR 224 241 254 265 251 270 286 298 286 308 325 339 326 350 370 386 366 394 416 434 405 435 460 480
LO PR 101 108 117 125 107 114 124 132 111 118 129 137 117 124 135 144 122 130 142 151 126 134 147 156
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
SS-DSXC16 www.goodmanmfg.com 19
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160601B*/CA*f4961*6A*+tXV / mBVC2000**-1** high StAge (Cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
2025
MBh 57.81 59.07 63.11 67.47 56.47 57.70 61.65 65.90 55.12 56.33 60.18 64.33 53.78 54.95 58.71 62.76 51.09 52.20 55.77 59.62 47.32 48.36 51.66 55.23
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.81 0.61
∆T 24 23 20 16 25 24 21 16 25 24 21 16 24 24 21 17 23 24 20 16 21 22 19 15
kW 3.63 3.72 3.84 3.97 3.93 4.02 4.16 4.30 4.20 4.29 4.44 4.60 4.43 4.53 4.69 4.86 4.63 4.74 4.90 5.08 4.80 4.91 5.09 5.27
Amps 14.3 14.7 15.2 15.8 15.5 15.9 16.5 17.1 16.9 17.3 17.9 18.6 18.1 18.6 19.2 20.0 19.3 19.8 20.5 21.3 20.5 21.0 21.7 22.6
HI PR 236 253 268 279 264 284 300 313 301 323 342 356 342 368 389 406 385 414 438 457 426 458 484 504
LO PR 106 113 123 131 112 119 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164
1800
MBh 56.1 57.4 61.3 65.5 54.8 56.0 59.9 64.0 53.5 54.7 58.4 62.5 52.2 53.4 57.0 60.9 49.6 50.7 54.2 57.9 45.9 46.9 50.2 53.6
S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
∆T 25 24 21 17 26 25 21 17 26 25 21 17 26 25 22 17 25 24 21 17 23 23 20 16
kW 3.60 3.68 3.81 3.94 3.90 3.99 4.12 4.27 4.16 4.26 4.40 4.56 4.39 4.49 4.65 4.81 4.59 4.70 4.86 5.03 4.76 4.87 5.04 5.22
Amps 14.2 14.6 15.1 15.6 15.4 15.8 16.3 16.9 16.8 17.2 17.8 18.5 18.0 18.4 19.0 19.8 19.1 19.6 20.3 21.1 20.3 20.8 21.5 22.4
HI PR 233 251 265 276 262 282 297 310 298 320 338 353 339 365 385 402 381 410 433 452 421 453 479 499
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163
1575
MBh 51.8 52.9 56.6 60.5 50.6 51.7 55.2 59.1 49.4 50.5 53.9 57.6 48.2 49.2 52.6 56.2 45.8 46.8 50.0 53.4 42.4 43.3 46.3 49.5
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
∆T 26 25 21 17 26 25 22 17 26 25 22 17 26 25 22 18 26 25 22 17 24 23 20 16
kW 3.51 3.59 3.71 3.84 3.80 3.88 4.02 4.16 4.05 4.15 4.29 4.44 4.28 4.38 4.53 4.69 4.47 4.57 4.73 4.90 4.63 4.74 4.91 5.08
Amps 13.8 14.2 14.6 15.2 15.0 15.3 15.9 16.5 16.3 16.7 17.3 17.9 17.4 17.9 18.5 19.2 18.6 19.1 19.7 20.5 19.7 20.2 20.9 21.7
HI PR 226 243 257 268 254 273 288 301 289 311 328 342 329 354 374 390 370 398 420 438 409 440 464 484
LO PR 102 109 119 126 108 115 125 133 112 119 130 139 118 125 137 146 123 131 143 153 128 136 148 158
85
2025
MBh 58.82 59.96 62.80 67.00 57.45 58.57 61.34 65.44 56.09 57.17 59.88 63.88 54.72 55.78 58.42 62.32 51.98 52.99 55.50 59.21 48.15 49.08 51.41 54.84
S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
∆T 26 26 24 21 26 26 24 21 25 26 24 21 25 25 25 21 24 24 24 21 22 22 23 20
kW 3.66 3.75 3.87 4.01 3.97 4.06 4.20 4.34 4.23 4.33 4.48 4.64 4.47 4.57 4.73 4.90 4.67 4.78 4.95 5.12 4.84 4.96 5.13 5.31
Amps 14.5 14.8 15.3 15.9 15.7 16.1 16.6 17.3 17.1 17.5 18.1 18.8 18.3 18.8 19.4 20.2 19.5 20.0 20.7 21.5 20.7 21.2 22.0 22.8
HI PR 238 256 270 282 267 287 303 316 304 327 345 360 346 372 393 410 389 419 442 461 430 463 488 509
LO PR 107 114 125 133 113 121 132 140 118 125 137 146 124 132 144 153 130 138 151 161 134 143 156 166
1800
MBh 57.1 58.2 61.0 65.0 55.8 56.9 59.6 63.5 54.5 55.5 58.1 62.0 53.1 54.2 56.7 60.5 50.5 51.4 53.9 57.5 46.7 47.7 49.9 53.2
S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
∆T 27 27 25 22 27 27 25 22 27 27 25 22 27 27 26 22 26 26 25 22 24 24 24 20
kW 3.63 3.72 3.84 3.97 3.93 4.02 4.16 4.30 4.20 4.29 4.44 4.60 4.43 4.53 4.69 4.86 4.63 4.74 4.90 5.08 4.80 4.91 5.09 5.27
Amps 14.3 14.7 15.2 15.8 15.5 15.9 16.5 17.1 16.9 17.3 17.9 18.6 18.1 18.6 19.2 20.0 19.3 19.8 20.5 21.3 20.5 21.0 21.7 22.6
HI PR 236 253 268 279 264 284 300 313 301 323 342 356 342 368 389 406 385 414 438 457 426 458 484 504
LO PR 106 113 123 131 112 119 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164
1575
MBh 52.7 53.7 56.3 60.0 51.5 52.5 55.0 58.6 50.3 51.2 53.7 57.2 49.0 50.0 52.3 55.8 46.6 47.5 49.7 53.1 43.1 44.0 46.1 49.1
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
∆T 27 27 26 22 28 27 26 22 28 27 26 22 28 28 26 23 27 27 26 22 25 25 24 21
kW 3.54 3.62 3.74 3.87 3.83 3.92 4.05 4.19 4.09 4.18 4.33 4.48 4.31 4.41 4.57 4.73 4.51 4.61 4.77 4.94 4.67 4.78 4.95 5.13
Amps 13.9 14.3 14.8 15.3 15.1 15.5 16.0 16.6 16.4 16.9 17.4 18.1 17.6 18.1 18.7 19.4 18.8 19.2 19.9 20.7 19.9 20.4 21.1 21.9
HI PR 228 246 260 271 256 276 291 304 292 314 331 346 332 357 377 394 374 402 425 443 413 444 469 489
LO PR 103 110 120 128 109 116 127 135 113 120 132 140 119 127 138 147 125 133 145 154 129 137 150 159
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
20 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
See Notes on Page 29.
AHRI RAtIngs
Outdoor
Unit
Indoor Units Cooling Ratings CFM AHRI #
Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³
DSXC16
0241A*
AVPTC30C14A* 23,000 16,800 16.00 12.50 830 5924460
CA*F3636*6D*+EEP+TXV 24,000 17,600 14.50 12.00 820 5357193
CA*F3636*6D*+MBVC1200**-1A*+TXV 24,000 17,600 16.00 13.00 820 4392752
CA*F3636*6D*+TXV G*VC80604B*B* 24,000 17,600 16.00 13.00 820 5038827
CA*F3636*6D*+TXV A*VC80604B*B* 24,000 17,600 16.00 13.00 820 5039091
CA*F3636*6D*+TXV G*VC950453BXB* 24,000 17,600 16.00 13.00 820 5620613
CA*F3636*6D*+TXV G*VC950704CXB* 24,000 17,600 16.00 13.00 800 5620620
CA*F3636*6D*+TXV A*VC950714CXB* 24,000 17,600 16.00 13.00 800 5620626
CA*F3636*6D*+TXV G*VC950714CXB* 24,000 17,600 16.00 13.00 800 5620627
CA*F3636*6D*+TXV G*VM960603BXB* 24,000 17,600 16.00 13.00 820 5620630
CA*F3636*6D*+TXV A*VM960604CXB* 24,000 17,600 16.00 13.00 800 5620635
CA*F3636*6D*+TXV G*VM960604CXB* 24,000 17,600 16.00 13.00 800 5620636
CA*F3636*6D*+TXV A*VC950453BXB* 24,000 17,600 16.00 13.00 820 6497619
CA*F3636*6D*+TXV A*VC950704CXB* 24,000 17,600 16.00 13.00 800 6497620
CA*F3636*6D*+TXV A*VM960603BXB* 24,000 17,600 16.00 13.00 820 6497621
CA*F3636*6D*+TXV ADVC80603B*B* 24,000 17,600 16.00 13.00 810 6497622
CA*F3642*6D*+EEP+TXV 24,000 17,600 14.50 12.00 820 5357194
CA*F3642*6D*+TXV A*VC80604B*B* 24,000 17,600 16.00 13.00 820 5039010
CA*F3642*6D*+TXV G*VC80604B*B* 24,000 17,600 16.00 13.00 820 5039220
CA*F3642*6D*+TXV G*VC950453BXB* 24,000 17,600 16.00 13.00 820 5620614
CA*F3642*6D*+TXV G*VC950704CXB* 24,000 17,600 16.00 13.00 800 5620621
CA*F3642*6D*+TXV A*VC950714CXB* 24,000 17,600 16.00 13.00 800 5620628
CA*F3642*6D*+TXV G*VC950714CXB* 24,000 17,600 16.00 13.00 800 5620629
CA*F3642*6D*+TXV G*VM960603BXB* 24,000 17,600 16.00 13.00 820 5620631
CA*F3642*6D*+TXV A*VM960604CXB* 24,000 17,600 16.00 13.00 800 5620637
CA*F3642*6D*+TXV G*VM960604CXB* 24,000 17,600 16.00 13.00 800 5620638
CA*F3642*6D*+TXV A*VC950704CXB* 24,000 17,600 16.00 13.00 800 6497623
CA*F3642*6D*+TXV A*VC950905CXB* 24,000 17,600 16.00 13.00 800 6497624
CA*F3642*6D*+TXV A*VC950915DXB* 24,000 17,600 16.00 13.00 800 6497625
CA*F3642*6D*+TXV A*VM960805CXB* 24,000 17,600 16.00 13.00 800 6497626
CA*F3642*6D*+TXV A*VM960805DXB* 24,000 17,600 16.00 13.00 800 6497627
CA*F3642*6D*+TXV G*VC950905CXB* 24,000 17,600 16.00 13.00 800 6497628
CA*F3642*6D*+TXV G*VC950915DXB* 24,000 17,600 16.00 13.00 800 6497629
CA*F3642*6D*+TXV G*VM960805CXB* 24,000 17,600 16.00 13.00 800 6497630
CA*F3642*6D*+TXV G*VM960805DXB* 24,000 17,600 16.00 13.00 800 6497631
CHPF3636B6C*+EEP+TXV 24,000 17,600 14.50 12.00 820 5357195
CHPF3636B6C*+MBVC1200**-1A*+TXV 24,000 17,600 16.00 13.00 820 3653937
CHPF3636B6C*+TXV G*VC80604B*B* 24,000 17,600 16.00 13.00 820 5039090
CHPF3636B6C*+TXV A*VC80604B*B* 24,000 17,600 16.00 13.00 820 5039103
CHPF3636B6C*+TXV G*VC950453BXB* 24,000 17,600 16.00 13.00 820 5620615
CHPF3636B6C*+TXV G*VM960603BXB* 24,000 17,600 16.00 13.00 820 5620632
CHPF3636B6C*+TXV A*VM960604CXB* 24,000 17,600 16.00 12.50 800 5620639
CHPF3636B6C*+TXV G*VM960604CXB* 24,000 17,600 16.00 12.50 800 5620640
CHPF3636B6C*+TXV A*VC950453BXB* 24,000 17,600 16.00 13.00 820 6497632
CHPF3636B6C*+TXV A*VC950704CXB* 24,000 17,600 16.00 12.50 800 6497633
Table of contents
Other Goodman Air Conditioner manuals
Goodman
Goodman CONDENSING UNIT User manual
Goodman
Goodman GPC15 SEER User manual
Goodman
Goodman AIR CONDITIONING CONDENSING UNIT 1 THRU 5 TON and GAS FIRED... Quick reference guide
Goodman
Goodman PACKAGE TERMINAL AIR CONDITIONER/HEAT PUMP Service manual
Goodman
Goodman MSG-12CRN1N Use and care manual
Goodman
Goodman AVPTC183014AA Use and care manual
Goodman
Goodman GSX Series Installation instructions
Goodman
Goodman GSX13 User manual
Goodman
Goodman APG14 M Series Manual
Goodman
Goodman GPH16 User manual
Goodman
Goodman GSX Series User manual
Goodman
Goodman PC Series User manual
Goodman
Goodman GSC13 Series Quick start guide
Goodman
Goodman GPC SERIES Manual
Goodman
Goodman SS-CPC36-72 User manual
Goodman
Goodman Aurora Series User manual
Goodman
Goodman MSH 9,000 User manual
Goodman
Goodman SSX16 Installation instructions
Goodman
Goodman AC 18 Manual
Goodman
Goodman GPC13H User manual
Popular Air Conditioner manuals by other brands
Mitsubishi Electric
Mitsubishi Electric City Multi PKFY-WL NLMU-E Series installation manual
Airwell
Airwell XLM17RCA Operation and installation instructions
Trane
Trane A4AC3018B1000B Installer's guide
Samsung
Samsung AM KN4DCH Series installation manual
Fujitsu
Fujitsu AOU9RLF installation manual
Mitsubishi Electric
Mitsubishi Electric Mr. Slim MXZ-3B24NA installation manual
Midea
Midea MSV1-18HRN1 user manual
Trane
Trane Tracker Version 12 Hardware installation
Johnson Controls Unitary Products
Johnson Controls Unitary Products TC3B1821S Technical guide
Frigidaire
Frigidaire FAC089L7A2 Factory parts catalog
Kasanova
Kasanova BAC000212NOC instruction manual
Kinghome
Kinghome KU21-FCU18-3 instruction manual
