Goodman SX14 R-410A Use and care manual

*SX14 R-410A Remote
Condensing Unit
REPAIR PARTS
RP-536E
This manual is to be used by qualified technicians only.
www.goodmanmfg.com www.amana-hac.com
This manual replaces RP-536D
© 2009-2010 Goodman Manufacturing Company, L.P. ◊5151 San Felipe, Suite 500 ◊Houston, TX 77056
November 2010
A
SX140181B
A
A
SX140181CA
A
SX140241B
A
A
SX140241CA
A
SX140301B
A
A
SX140301CA
A
SX140361B
A
A
SX140361CA
A
SX140421CA
A
SX140421DA
A
SX140481B
A
A
SX140481CA
A
SX140601B
A
SSX140181B
A
SSX140241B
A
SSX140301B
A
SSX140361B
A
SSX140421CA
SSX140481B
A

Important Information
For assistance within the U.S.A. contact:
International Division
Goodman Company, L.P.
7401 Security Way
Houston, Texas 77040
713-861-2500-Telephone
713-863-2382-Facsimile
For assistance outside the U.S.A. contact:
Index
Functional Parts List
Revision E: Added model SSX140481BA.
Illustration and Parts
...................................................................................................
...................................................................................................
Views shown are for parts illustrations only, not servicing procedures.
AR - As Required
NA - Not Available
NS - Not Shown
00000000 - See Note
QTY - Quantity Example (QTY 3) (If Quantity not shown, Quantity = 1)
M - Model Example (M1) (If M Code not shown, then part is used on all Models)
Text Codes:
Example
M1 - Model#1
M2 - Model#2
M3 - Model#3
Expanded Model Nomenclature:
Goodman Manufacturing Company, L.P. is not responsible for personal injury or property damage resulting from
improper service. Review all service information before beginning repairs.
Warranty service must be performed by an authorized technician, using authorized factory parts. If service is
required after the warranty expires, Goodman Manufacturing Company, L.P. also recommends contacting an
authorized technician and using authorized factory parts.
Goodman Manufacturing Company, L.P. reserves the right to discontinue, or change at any time, specifications
or designs without notice or without incurring obligations.
2
Consumer Affairs Department
Goodman Manufacturing Company, L.P.
7401 Security Way
Houston, Texas 77040
877-254-4729-Telephone
713-863-2382-Facsimile
International Division
Goodman Manufacturing Company, L.P.
7401 Security Way
Houston, Texas 77040
713-861-2500-Telephone
713-863-2382-Facsimile
www.goodmanmfg.com www.amana-hac.com
4 - 11
3
RP-536E

Functional Parts
Part
No: Description:
0151R00002P 3/4" SERVICE VALVE OPEN LEFT (M1, M2,
M3, M4, M5, M6, M7, M8, M14, M15, M16, M17)
B12825171 3/8” SERVICE VALVE
0151R00003P 7/8" SERVICE VALVE OPEN LEFT (M9, M10,
M11, M12, M13, M18, M19)
CAP050300440RSS CAPACITOR 5/30/370V (M1, M2, M14)
CAP050350440RSS CAPACITOR 5/35/440V (M3, M4, M15)
CAP050400440RT CAPACITOR 5/40/440V (M5, M6, M16)
CAP050450440RT CAPACITOR 5/45/440V (M7, M8, M9, M10,
M11, M12, M17, M18, M19)
CAP050700440RTS CAPACITOR 5/70/440V (M13)
543001001 COMFORT ALERT MODULE (M2, M4, M6, M8,
M10, M11, M12, M13)
543001000S COMFORT ALERT MODULE (M1, M3, M5, M7,
M9)
ZP20K5EPFV130 COMPRESSOR 20000, 208/230/60/1 (M3, M4,
M15)
ZP24K5EPFV130 COMPRESSOR 24000, 208/230/60/1 (M5, M6,
M16)
ZP29K5EPFV130 COMPRESSOR 29000, 208/230/60/1 (M7, M8,
M17)
ZP31K5EPFV830 COMPRESSOR 31100, 208/230/60/1 (M9,
M10, M18)
ZP38K5EPFV130 COMPRESSOR 37500, 208/230/60/1 (M11,
M12, M19)
ZP51K5EPFV830 COMPRESSOR 51000, 208/230/60/1 (M13)
ZP16K5EPFV130 COMPRESSOR15500, 208/230/60/1 (M1, M2,
M14)
0131M00019P COND MOTOR 1/12 HP, 1 SP, 8 PL (M15)
0131M00027 COND MOTOR 1/12 HP, 2 SP, 8 PL (M3, M4)
0131M00061S COND MOTOR 1/4 HP, 1 SP, 8 PL (M19)
0131M00015PS COND MOTOR 1/4 HP, 2 SP, 8 PL (M11, M12,
M13)
0131M00060S COND MOTOR 1/6 HP, 1 SP, 8 PL (M14, M16,
M17, M18)
0131M00017PS COND MOTOR 1/6 HP, 2 SP, 8 PL (M1, M2,
M5, M6, M7, M8, M9, M10)
CONT1P025024VS CONTACTOR 25 AMP, 1P, 24V (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M14, M15, M16,
M17, M18)
CONT1P030024VS CONTACTOR 30 AMP, 1P, 24V (M11, M12,
M13, M19)
0150M00001P FAN BLADE 20 INCH (M3, M4, M15)
0150M00012S FAN BLADE 20" CCW (M1, M2, M14)
0150M00008S FAN BLADE 22" TNT2203-25 (M7, M8, M9,
M10, M17)
10625738S FAN BLADE 26" ALUM CCW (M11, M12, M13,
M19)
B1086764S FAN BLADE TYPE 2 (M5, M6, M16, M18)
20322603 HIGH PRESSURE SWITCH
0130M00011P LOW AMBIENT THERMOSTAT, SPDT (M1,
M2, M3, M4, M5, M6, M7, M8, M9, M10, M11,
M12, M13)
0130M00082 LOW PRESSURE SWITCH (M12, M19)
0130R00001 LOW PRESSURE SWITCH (M1, M2, M3, M4,
M5, M6, M7, M8, M9, M10, M11, M13, M14,
M15, M16, M17, M18)
SPECIAL PARTS
0161R00008P AMANA LOGO CAP (M1, M2, M3, M4, M5, M6,
M7, M8, M9, M10, M11, M12, M13)
0161R00010P AMANA NAMEPLATE (M1, M2, M3, M4, M5,
M6, M7, M8, M9, M10, M11, M12, M13)
IO-258J INSTRUCTION, INST
0161R00009P NAMEPLATE (M14, M15, M16, M17, M18, M19)
Expanded Model Nomenclature
M1 - ASX140181BA
M2 - ASX140181CA
M3 - ASX140241BA
M4 - ASX140241CA
M5 - ASX140301BA
M6 - ASX140301CA
M7 - ASX140361BA
M8 - ASX140361CA
M9 - ASX140421CA
M10 - ASX140421DA
M11 - ASX140481BA
M12 - ASX140481CA
M13 - ASX140601BA
M14 - SSX140181BA
M15 - SSX140241BA
M16 - SSX140301BA
M17 - SSX140361BA
M18 - SSX140421CA
M19 - SSX140481BA
3
RP-536E www.goodmanmfg.com www.amana-hac.com

Top Panel Assembly
4RP-536
E
www.goodmanmfg.com www.amana-hac.com

Top Panel Assembly
Ref.
No: Part No: Description: Ref. No: Part No: Description:
Image 1: VENTURI TOP PANEL 26" (M1, M2, M3, M4)0121R00009PDG11
VENTURI TOP PANEL 29" (M5, M6, M7, M8, M9,
M10)
0121R00011PDG11
VENTURI TOP PANEL 35" (M11, M12, M13)0121R00013PDG11
WIRE GRILL 26" (M1, M2, M3, M4)0152R00000P21
WIRE GRILL 29" (M5, M6, M7, M8, M9, M10)0152R0000821
WIRE GRILL 35" (M11, M12, M13)0152R0000921
COND MOTOR 1/12 HP, 1 SP, 8 PL (M15)0131M00019P31
COND MOTOR 1/12 HP, 2 SP, 8 PL (M3, M4)0131M0002731
COND MOTOR 1/4 HP, 1 SP, 8 PL (M19)0131M00061S31
COND MOTOR 1/4 HP, 2 SP, 8 PL (M11, M12, M13)0131M00015PS31
COND MOTOR 1/6 HP, 1 SP, 8 PL (M14, M16, M17,
M18)
0131M00060S31
COND MOTOR 1/6 HP, 2 SP, 8 PL (M1, M2, M5,
M6, M7, M8, M9, M10)
0131M00017PS31
HEX NUT (M1, M2, M3, M4, M5, M6, M7, M8, M9,
M10, M11, M12, M13)
M028080141
FAN BLADE 20 INCH (M3, M4, M15)0150M00001P51
FAN BLADE 20" CCW (M1, M2, M14)0150M00012S51
FAN BLADE 22" TNT2203-25 (M7, M8, M9, M10,
M17)
0150M00008S51
FAN BLADE 26" ALUM CCW (M11, M12, M13, M19)10625738S51
FAN BLADE TYPE 2 (M5, M6, M16, M18)B1086764S51
AMANA LOGO CAP (M1, M2, M3, M4, M5, M6, M7,
M8, M9, M10, M11, M12, M13)
0161R00008P61
SCREW #10 X 1/2, A, SLOT, SR, BLACK (M1, M2,
M3, M4, M5, M6, M7, M8, M9, M10, M11, M12, M13)
0163M00003P71
TOP PANEL 26" (M14, M15)0121R00008PDG111
TOP PANEL 29" (M16, M17, M18)0121R00010PDG111
TOP PANEL 35" (M19)0121R00012PDG111
CONDUIT (M1, M2, M3, M4)0161R00000P121
CONDUIT (M14, M15)0161R00001P121
CONDUIT (M5, M6, M7, M8, M9, M10, M17)0161R00002P121
CONDUIT (M16, M18)0161R00003P121
CONDUIT (M11, M12, M13, M19)0161R00004P121
VENTURI RING 22" (M17)0161L00000131
VENTURI RING 35" (M19)0161R00007P131
ACORN NUT 5/16 HEX BLACK (M14, M15, M16,
M17, M18, M19)
0163M00006P141
Expanded Model Nomenclature
M1 - ASX140181BA
M2 - ASX140181CA
M3 - ASX140241BA
M4 - ASX140241CA
M5 - ASX140301BA
M6 - ASX140301CA
M7 - ASX140361BA
M8 - ASX140361CA
M9 - ASX140421CA
M10 - ASX140421DA
M11 - ASX140481BA
M12 - ASX140481CA
M13 - ASX140601BA
M14 - SSX140181BA
M15 - SSX140241BA
M16 - SSX140301BA
M17 - SSX140361BA
M18 - SSX140421CA
M19 - SSX140481BA
5
RP-536E www.goodmanmfg.com www.amana-hac.com

Louvered Panels
6RP-536
E
www.goodmanmfg.com www.amana-hac.com

Louvered Panels
Ref.
No: Part No: Description: Ref. No: Part No: Description:
Image 1: LOUVERED SIDE PANEL [LT OF CNTL PNL] (M11,
M13)
4400464PLGB111
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M5,
M6, M7, M8)
0121R00200PLGB111
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M9,
M10)
0121R00202PLGB111
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M1,
M2)
0121R00207PLGB111
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M3,
M4)
0121R00208PLGB111
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M12)0121R00239PLGB111
LOUVERED SIDE PANEL (M1, M2)0121R00198PLGB121
LOUVERED SIDE PANEL (M3, M4)0121R00199PLGB121
LOUVERED SIDE PANEL (M5, M6, M7, M8)0121R00204PLGB121
LOUVERED SIDE PANEL (M9, M10)0121R00205PLGB121
LOUVERED SIDE PANEL (M12)0121R00243PLGB121
LOUVERED SIDE PANEL (M11, M13)4400466PLGB121
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M5,
M6, M7, M8)
0121R00193PLG131
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M9,
M10)
0121R00194PLG131
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M1,
M2)
0121R00196PLG131
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M3,
M4)
0121R00197PLG131
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M12)0121R00247PLG131
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M11,
M13)
4400468PLG131
Image 2: LOUVERED SIDE PANEL [LT OF CNTL PNL] (M14)0121R00102PDGB112
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M16,
M17)
0121R00125PDGB112
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M18)0121R00127PDGB112
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M15)0121R00171PDGB112
LOUVERED SIDE PANEL [LT OF CNTL PNL] (M19)0121R00228PDGB112
LOUVERED SIDE PANEL (M14)0121R00109PDGB122
LOUVERED SIDE PANEL (M16, M17)0121R00132PDGB122
LOUVERED SIDE PANEL (M18)0121R00134PDGB122
LOUVERED SIDE PANEL (M15)0121R00172PDGB122
LOUVERED SIDE PANEL (M19)0121R00231PDGB122
LOUVERED SIDE PANEL [RT OF CNTL PNL]
(M16, M17)
0121R00139PDG132
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M14)0121R00116S132
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M18)0121R00141PDG132
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M15)0121R00173PDG132
LOUVERED SIDE PANEL [RT OF CNTL PNL] (M19)0121R00234PDG132
Expanded Model Nomenclature
M1 - ASX140181BA
M2 - ASX140181CA
M3 - ASX140241BA
M4 - ASX140241CA
M5 - ASX140301BA
M6 - ASX140301CA
M7 - ASX140361BA
M8 - ASX140361CA
M9 - ASX140421CA
M10 - ASX140421DA
M11 - ASX140481BA
M12 - ASX140481CA
M13 - ASX140601BA
M14 - SSX140181BA
M15 - SSX140241BA
M16 - SSX140301BA
M17 - SSX140361BA
M18 - SSX140421CA
M19 - SSX140481BA
7
RP-536E www.goodmanmfg.com www.amana-hac.com

Control Box and Cover
8RP-536
E
www.goodmanmfg.com www.amana-hac.com

Control Box and Cover
Ref.
No: Part No: Description: Ref. No: Part No: Description:
Image 1: LOWER ACCESS PANEL (M1, M2, M14)0121R00094PDG11
LOWER ACCESS PANEL (M3, M4, M5, M6, M7,
M8, M15, M16, M17)
0121R00096PDG11
LOWER ACCESS PANEL (M9, M10, M12, M18,
M19)
0121R00098PDG11
LOWER ACCESS PANEL (M11, M13)4400205PDG11
CONTROL COVER0121R00053PDG21
CONTACTOR 25 AMP, 1P, 24V (M1, M2, M3, M4,
M5, M6, M7, M8, M9, M10, M14, M15, M16, M17,
M18)
CONT1P025024VS71
CONTACTOR 30 AMP, 1P, 24V (M11, M12, M13,
M19)
CONT1P030024VS71
CAPACITOR 5/30/370V (M1, M2, M14)CAP050300440RSS81
CAPACITOR 5/35/440V (M3, M4, M15)CAP050350440RSS81
CAPACITOR 5/40/440V (M5, M6, M16)CAP050400440RT81
CAPACITOR 5/45/440V (M7, M8, M9, M10, M11,
M12, M17, M18, M19)
CAP050450440RT81
CAPACITOR 5/70/440V (M13)CAP050700440RTS81
CAPACITOR STRAP440006591
COMFORT ALERT MODULE (M1, M3, M5, M7, M9)543001000S101
COMFORT ALERT MODULE (M2, M4, M6, M8,
M10, M11, M12, M13)
543001001101
LOW AMBIENT THERMOSTAT, SPDT (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M11, M12, M13)
0130M00011P111
AMANA NAMEPLATE (M1, M2, M3, M4, M5, M6,
M7, M8, M9, M10, M11, M12, M13)
0161R00010PNS
NAMEPLATE (M14, M15, M16, M17, M18, M19)0161R00009PNS
Expanded Model Nomenclature
M1 - ASX140181BA
M2 - ASX140181CA
M3 - ASX140241BA
M4 - ASX140241CA
M5 - ASX140301BA
M6 - ASX140301CA
M7 - ASX140361BA
M8 - ASX140361CA
M9 - ASX140421CA
M10 - ASX140421DA
M11 - ASX140481BA
M12 - ASX140481CA
M13 - ASX140601BA
M14 - SSX140181BA
M15 - SSX140241BA
M16 - SSX140301BA
M17 - SSX140361BA
M18 - SSX140421CA
M19 - SSX140481BA
9
RP-536E www.goodmanmfg.com www.amana-hac.com

Condenser Coil and Tubing Assembly
10 RP-536
E
www.goodmanmfg.com www.amana-hac.com

Condenser Coil and Tubing Assembly
Ref.
No: Part No: Description: Ref. No: Part No: Description:
Image 1: TUBING ASSY, COND COIL (M11)0201R00134S11
TUBING ASSY, COND COIL (M13)0201R00137S11
TUBING ASSY, COND COIL (M5, M6, M16)0201R00230S11
TUBING ASSY, COND COIL (M3, M4, M15)0201R00251S11
TUBING ASSY, COND COIL (M1, M2, M14)0201R00271S11
TUBING ASSY, COND COIL (M7, M8, M17)0201R0027911
TUBING ASSY, COND COIL (M12, M19)0201R0031211
TUBING ASSY, COND COIL (M9, M10, M18)0201R0031511
COMPRESSOR 20000, 208/230/60/1 (M3, M4, M15)ZP20K5EPFV13021
COMPRESSOR 24000, 208/230/60/1 (M5, M6, M16)ZP24K5EPFV13021
COMPRESSOR 29000, 208/230/60/1 (M7, M8, M17)ZP29K5EPFV13021
COMPRESSOR 31100, 208/230/60/1 (M9, M10,
M18)
ZP31K5EPFV83021
COMPRESSOR 37500, 208/230/60/1 (M11, M12,
M19)
ZP38K5EPFV13021
COMPRESSOR 51000, 208/230/60/1 (M13)ZP51K5EPFV83021
COMPRESSOR15500, 208/230/60/1 (M1, M2, M14)ZP16K5EPFV13021
BASE PAN 26" (M1, M2, M3, M4, M14, M15)0121R00005PDG31
BASE PAN 29" (M5, M6, M7, M8, M9, M10, M16,
M17, M18)
0121R00006PDG31
BASE PAN 35" (M11, M12, M13, M19)0121R00007PDG31
TF SHOULDER SCREW (QTY 4)M022164141
COMPRESSOR GROMMET (QTY 4)B133953351
3/4" SERVICE VALVE OPEN LEFT (M1, M2, M3,
M4, M5, M6, M7, M8, M14, M15, M16, M17)
0151R00002P61
7/8" SERVICE VALVE OPEN LEFT (M9, M10, M11,
M12, M13, M18, M19)
0151R00003P61
3/8” SERVICE VALVEB1282517171
FILTER DRIER0162R0000991
HIGH PRESSURE SWITCH20322603101
LOW PRESSURE SWITCH (M12, M19)0130M00082111
LOW PRESSURE SWITCH (M1, M2, M3, M4, M5,
M6, M7, M8, M9, M10, M11, M13, M14, M15, M16,
M17, M18)
0130R00001111
COMPRESSOR SOUND BLANKET (M11, M12,
M13, M19)
B1488806141
COMPRESSOR SOUND BLANKET (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M14, M15, M16,
M17, M18)
B1488810141
COMPRESSOR SCROLL HARNESS (M1, M2, M3,
M4, M14, M15)
0159R00000PNS
COMPRESSOR SCROLL HARNESS (M5, M6, M7,
M8, M9, M10, M16, M17, M18)
0159R00001PNS
COMPRESSOR SCROLL HARNESS (M11, M12,
M13, M19)
0159R00002PNS
FLOW CHECK PISTON KIT .052 (M1, M2, M14)B1789852NS
FLOW CHECK PISTON KIT .055 (M3, M4, M15)B1789855NS
FLOW CHECK PISTON KIT .065 (M5, M6, M16)B1789865NS
FLOW CHECK PISTON KIT .068 (M7, M8, M17)B1789868NS
FLOW CHECK PISTON KIT .070 (M9, M10, M18)B1789870NS
Image 1: FLOW CHECK PISTON KIT .078 (M12, M19)B1789878NS
FLOW CHECK PISTON KIT .079 (M11)B1789879NS
FLOW CHECK PISTON KIT .088 (M13)B1789888NS
Expanded Model Nomenclature
M1 - ASX140181BA
M2 - ASX140181CA
M3 - ASX140241BA
M4 - ASX140241CA
M5 - ASX140301BA
M6 - ASX140301CA
M7 - ASX140361BA
M8 - ASX140361CA
M9 - ASX140421CA
M10 - ASX140421DA
M11 - ASX140481BA
M12 - ASX140481CA
M13 - ASX140601BA
M14 - SSX140181BA
M15 - SSX140241BA
M16 - SSX140301BA
M17 - SSX140361BA
M18 - SSX140421CA
M19 - SSX140481BA
11
RP-536E www.goodmanmfg.com www.amana-hac.com

THIS PAGE INTENTIONALLY LEFT BLANK
12 RP-536E
