Goodmans GSPK29iP User manual

Portable Speaker System with
Universal Dock for iPod
2008
Issue1-January2008
www.goodmans.co.uk
Helpline:0871 230 1777
USER GUIDE
GSPK29iP

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
Contents
Important safety instructions
What's included 2
Getting Started
Using the system
Troubleshooting
Specifications 8
1
1-2
3-4
Placing a correct dock insert 3
Connection to power via Power Adapter 3
Connection to power via battery 3
Connection of other audio devices by audio cable 4
4-5
6-7
WARNING: To reduce the risk of fire or electrical shock, do not expose the product to rain or moisture.
The apparatus should not be exposed to dripping or splashing, and objects filled with
liquids. Liquids can cause a failure and/or a fire hazard.
WARNING:
The lightning flash with arrowhead symbol, within an equilateral triangle, alerts the user to the
presence of un-insulated dangerous voltage within the system enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle alerts the user to the presence of important
operating and maintenance instructions in this owner's guide.
WARNING: No naked flame sources, such as lighted candles, should be placed on the apparatus.
Note: This product is intended to be used only with the power supply provided.
Note: Where the mains plug is used as the disconnect device, such disconnect device shall
remain readily operable.
Note: This product must be used in doors, It is neither designed or tested for use outdoors, in
recreation vehicles, or on boats.
WARNING: may
heat
above replaced.
Keep the battery away from children since batteries are a choke hazard. It
cause a fire or chemical burn if mishandled. Do not recharge, disassemble,
100 C, or incinerate. Danger of explosion if battery is incorrectly
0
WARNING: The socket-outlet shall be installed near the equipment and shall be easily accessible.
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your local authority for recycling advice.
12
WHAT'S INCLUDED
IMPORTANT SAFETY INSTRUCTIONS
Figure 1: What's included in the carton
Power AdapterRemote control
and User's manual
3.5mm audio cable
Universal Dock
Inserts
Check the carton for the parts shown in Figure 1.
Thanks for choosing the GSPK29iP Music Station. This GSPK29iP is
designed specially to work with your iPod, providing a high quality audio performance
for your enjoyment. Just listen to it now!
GSPK29iP Music
system
Mute
Menu Enter
Bass Treble
Reset
1. Read these instructions - for all components before using this product.
2. Keep these instructions - for future reference.
3. Heed all warnings - on the product and in the owner's guide.
4. Follow all instructions.
5. Do not use this apparatus near water or moisture - Do not use this product
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, near a
swimming pool, or anywhere else that water or moisture are present.
6. Clean only with a dry cloth - Unplug this product from the Electrical socket
before cleaning.
7. Do not block any ventilation openings. Install in accordance with the
manufacture's instructions
-To ensure reliable operation of the product and to protect it from overheating,
put the product in a position and location that will not interfere with its proper
ventilation. For example, do not place the product on a bed, sofa, or similar
surface that may block the ventilation openings, Do not put it in a built-in
system, such as a bookcase or a cabinet that may keep air from flowing
through its ventilation openings.
8. Do not install near any heat sources, such as radiators, heat registers, stoves
or other apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched, particularly at plugs,
and the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Refer all servicing to qualified service personnel - Do not attempt to service
this product yourself. Opening or removing covers may expose you to
dangerous voltages or other hazards.
12. Do not let objects or liquids enter the product - as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock.
13. See product enclosure for safety related markings.
14. Use proper power sources - Plug the product into a proper power source, as
described in the operating instructions or as marked on the product.
PortableSpeaker System with
UniversalDock for iPod
Pleasekeep this manual in a convenient place for future reference.
USER GUIDE
GSPK29IP

4. Connection of other audio devices by audio cable
You can connect other audio device, like MP3 player or any iPod without a dock
connector by using the included 3.5mm audio cable to the audio in jack.
Note: When iPod is docked and audio in is connected with other device; other
device will be the priority sound source.
Figure 5
GSPK29iP Music system
The GSPK29iP Digital Music System can be put to use after connecting the power
supply, the indicator will light up, then after connecting your iPod, just set the music
you want to listen to the iPod and plug the iPod on the docking station.
Switch on at your back of your GSPK29iP to turn it on.
hear the music immediately. If you do not, please refer
to "Troubleshooting".
Once your iPod is docked, power is recharged automatically until
it's fully charged. (Only when mains powered).
The system has an inbuilt audio in port and can connect other
audio devices or iPods directly.
You can increase or decrease the volume by pressing " "
and " " button respectively.
To turn off the system, remove your iPod from the dock. Then switch the power
button off or unplug the system from the outlet.
USING THE SYSTEM
Music and Video systemGSPK29iP
Before enjoying music, please follow the connections step below to set up your system.
Choose a correct dock inserts from No.8,9 or 10(details below) for your iPod model
and put the insert to the dock.(figure 2)
GETTING STARTED
1. Selecting a correct dock insert
Note: For older generation iPod, please refer to Apple store for insert purchase.
Note: This docking station only supports iPod model with a dock connector.
Insert NO.
iPod Model
8910
iPod nano (1st and
2nd Generation)
iPod with Video
(30GB)
iPod with Video
(60GB & 80GB)
2. Using with mains power
Universal Dock
Adapters
Connect the AC Adapter into the DC in jack and plug the AC Adapter into the wall outlet.
Then switch on with the on/off switch on the rear of the unit (Figure 3)
Power pack
Power supply
Figure 3
Figure 3: System connections
3. Using batteries (not included)
Please open the battery compartment cover at the bottom of the unit, and install 4 pcs AA
batteries (not included). Check the polarity of the batteries to match the "+" "-" markings
inside the battery compartment. (Figure 4)
Figure 4
3
Figure2 insertsGSPK29iP
Note: During music playback by using audio in, it's suggested to adjust your
audio device loud enough to ensure the best sound quality. Then adjust the
GSPK29iP volume buttons on top to control the volume level.
4
Please note: it will not charge your iPod when battery powered
USING THE SYSTEM
MP3

USING THE SYSTEM
Using the Remote Control
Volume
Up/Down
Play/Pause
Treble +/-
Menu
Bass
Treble
Power
on/off
Previous
/Next
Menu Up
/Down
Menu
Enter
Bass +/-
Turn the audio source on/off.
Mute
Play and Pause iPod.
Increase or decrease the bass level.
steps -10 to +10
Increase or decrease the treble level.
steps -10 to +10
Increase or decrease the music volume when the audio
source is playing.
steps 0-30
To confirm the chosen menu item, or to confirm the
selected song/photo/video when iPod is used .
Shuffle
Repeat
Press to skip press to go previous song;
press and hold to rewind through the
current track.
Quick press to skip to next/previous track,
or hold to fast forward/rewind
during play back."
Press or hold to scroll though iPod menus
Cuts the sound, press again to resume.
To go back to the previous menu.
Reset's the bass and treble to 0
Play songs/album in a shuffled order, or to turn off the shuffle function.
Repeat one song, all songs in the album, or to turn off the repeat
function.
Reset
Reset
5
TROUBLESHOOTING
In case of malfunction, please power off the system immediately and check the unit according
to following table. If the problem still exists, please contact the dealer.
- Press the "Power" button, if there is no change
on the indicator of the iPod, please press the
"Power" button again.
Power cable is not
connected
- Make sure the GSPK29iP is plugged in and the
LED is illuminated.
- Make sure the GSPK29iP is with battery and the
battery is working if GSPK29iP is not plugged in.
Power isn't turned on
No Sound
Volume Level too low - The volume level might be too low, press
"Volume" button on the panel to adjust.
- Please ensure proper insert is placed for your
iPod. (Refer to "Selecting the correct insert" on
page 3).)
- Unplug the iPod from the docking station to see
any obstructions in the connector or in your iPod.
Solution
Symptom Problem
iPod / Audio source
is not responding
iPod does not dock
properly
3.5mm headphone cable
isn't connected properly
- Connect 3.5mm headphone cable to the audio
source. Make sure the signal cable is inserted
firmly into the correct jack & is fully connected
in the "line-out", "audio-out", or the headphone
jack on your sound card or other audio source.
Your iPod navigation controls are fully functional while it is docked in the system.
Your iPod volume jog wheel changes the headphone volume only. It has no effect on
the Sound Dock system.
Changing the remote control battery is the only regular maintenance that is
required. You may also clean the system as needed.
Replace the remote control battery when it stops operating (normally every year or two), or its range
seems reduced. Use only a Lithium Cell CR2025, Duracell, Eveready, Energizer, Maxell, Toshiba, or
Shun Wo Cr2032 3-volt lithium battery. Keep in mind that lighting and other room conditions, in
addition to battery age, can affect the operating range of an infrared remote control.
To replace the remote control battery
Figure 6: Inserting a new battery
6
Mute
Menu Enter
Bass Treble
Reset
USING THE SYSTEM
GSPK29IP
CR2025X1
OPEN
CR2025

SPECIFICATIONSTROUBLESHOOTING
- Decrease volume level by pressing on front
panel or on remote control.
Sound distortion
Volume level too high
- Distortion and noise are easily noticed with
high-powered speakers when playing poor
quality audio source, esp. WAV and MID files.
Try a different audio source such as a music CD
or change better quality audio player.
Sound source is distorted
System is not
Responding Malfunction
- If the volume buttons on the top of the unit
work, then check the remote control battery.
To reset: unplug the power and remove
batteries, after 1 minute plug back in
- Please contact customer service .
Solution
Symptom Problem
No Sound
- Make sure your iPod is on, and a track is
selected for playback.
No playable file on iPod
Your iPod is not charging
- Make sure the power cable is securely plugged
in to a functioning wall socket. The symbol on
the small connector is matched with that on rear
panel of the . (Refer to Figure 4 on
page 4.)
- Make sure your iPod is firmly seated in the dock.
GSPK29iP
After quickly undocking
or docking your iPod
- Remove your iPod from the dock, wait for 5
seconds, and return it to the dock.
- Unplug the power cable for 1 minute, then plug
it back to reset the system.
iPod does not dock
properly
- Remove your iPod from the dock, wait briefly,
then reset it. You may need to do this for
few times.
Audio power(THD=10%): 3W RMS X 2
Speaker Units: 2'' 2
Frequency range: 120Hz 20kHz
Rated Load Impedance: 4 (Max 7W)
Notes:
1) The specifications listed above are for reference only.
2) The technical specifications of this device are subject to changes
without prior notice.
Power Rating: 100-240V 50/60Hz
Product Dimension : 250 45 mm
Net Weight: 530g
7
8
UMA0360A
