Gorenje PWM110WIT Operating and maintenance manual

EN
DETAILED
INSTRUCTIONS
HOW TO USE YOUR
WASHING MACHINE
PWM110WIT
www.pelgrim.com

We thank you for your trust
and the purchase of our washing
machine.
Your new washing machine complies
with the requirements of modern
laundry care. Your laundry will
be impeccably white even at low
temperatures, owing to special
washing programs like Ultra White.
SensoCare technology allows simple
control of the washing machine.
Your washing machine is highly
economical when it comes to use of
power, water, and detergent.
The washing machine is intended
exclusively for use in households, for
washing the laundry that is indicated
as machine washable.

3
TABLE OF CONTENTS
409016
STEPS OF THE
WASHING
PROCESS
CLEANING &
MAINTENANCE
OF THE
APPLIANCE
INTRODUCTION
TROUBLE-
SHOOTING
PREPARING THE
APPLIANCE FOR
THE FIRST USE
OTHER
4 WASHING MACHINE
5 Technical information
6 Front panel
8 SAFETY PRECAUTIONS
10 INSTALLATION AND CONNECTION
10 Removal of transport brackets
11 Selecting the room
11 Installation
13 Water inlet connection
14 Aqua-stop
14 Total aqua - stop
15 Water outlet connection
16 Connect the appliance to the mains supply
17 Moving and transport
17 Subsequent transport
18 BEFORE THE USE
19 WASHING STEPS (1 - 7)
19 1. Step: Check the tags on your laundry
20 2. Step: Preparing the washing process
22 3. Step: Choosing a programme
25 4. Step: Choosing the settings
27 5. Step: Selecting additional functions
29 6. Step: Program start
29 7. Step: End of washing program
30 LEANING AND MAINTENANCE
30 Cleaning the detergent dispenser
31 Cleaning the dispenser housing, inlet hose screen and door
rubber gasket
32 Cleaning the filter
33 Cleaning the washing machine
34 INERRUPTING AND CHANCHING THE PROGRAM
35 What to do ...?
36 Troubleshooting table
38 RECOMMENDATIONS FOR WASHING AND ECONOMIC USE
YOUR WASHING MACHINE
40 Grandma's advice for natural stain removal
42 DISPOSAL
43 TYPICAL CONSUMPTION TABLE

4
WASHING MACHINE
(WASHING MACHINE DESCRIPTION)
2
1
3
4
1
2
3
4
4
4
4
409016
FRONT
1 Front panel
2 Dispenser
3 Door
4 Filter
BACK
1 Water inlet pipe
2 Power cord
3 Water discharge pipe
4 Adjustable feet

5
TECHNICAL INFORMATION
(DEPENDING ON THE MODEL)
TYPE: PS10/XXX
Art.No.: XXXXXX
AC 220-240V 50/60 Hz 10A Pmax.: 2400W
2000W XXX/min 0,05-0,8 MPa
MODEL: XXXXXX
Ser.No.: XXXXXX
X
kg
IPX4 MADE IN EU
Maximum load See rating plate See rating plate (SLIM)
Width 600 mm 600 mm
Height 850 mm 850 mm
Depth 600 mm 440 mm
Depth with door open 108 cm 92 cm
Washing machine weight x kg
(depending on the model)
x kg
(depending on the model)
Rated Voltage See rating plate See rating plate
Nominal power See rating plate See rating plate
Connection See rating plate See rating plate
Water pressure See rating plate See rating plate
Current See rating plate See rating plate
Frequency See rating plate See rating plate
409016
The rating plate with the basic information on the washing machine
is located under the washing machine door.
Rating plate

66
FRONT PANEL
409016
1Washing machine ON/ OFF and program
SELECTOR DIAL 2a , b, c WASHING
STYLE keys
(SensoCare)
2a ECOcare
2b ALERGYcare
2c TIMEcare
3WASHING TEMPERATURE key
3a SIGNAL LIGHTS for
indicating the WASHING
TEMPERATURE/ for COLD
WASH
OFF
1
2
2c
2b
2a
3a
3

77
409016
4SPINNING RPM / PUMP / STOP PUMP key
4a SIGNAL LIGHTS for
displaying the SPINNING
RPM/PUMP OPERATION/
PUMP STOP
5START DELAY key
5a START DELAY display, or
time remaining until the end
of the washing cycle
5b CHILD LOCK signal light
6a , b, c ADDITIONAL FUNCTION keys
6a Prewash
6b Extra water
6c SterilTub
7START/PAUSE key Use this key to start or
stop the program.
When the machine is turned
on, the signal light on the
key starts to flash; when the
program is started, it is lit
continuously.
START|PAUSE
4a
45
6c
6b
6a
7
h
5a
5b

8
SAFETY PRECAUTIONS
409016
Please, do not use the washing machine
without reading and understanding these
instructions or use first.
Be sure to remove transport brackets
prior first use of the appliance. Attempted
operation of the blocked machine may
result in irreparable damage which is not
covered by the manufacturer’s warranty!
When connecting your washing machine
to water supply, be sure to use the supplied
water inlet hose and sealing gaskets.
Failure to observe the instructions for
use or inappropriate use of the washing
machine may result in damage to the
laundry or machine, or injury to the user.
Keep the instructions for use handy, near
the washing machine.
Do not install the machine in a room where
temperature can drop below 0°C. Parts of
the machine may be damaged if the water
inside them freezes.
Install the washing machine in a perfectly
horizontal position, on solid flat (concrete)
floor.
Follow the instructions for correct
installation and water and mains
connections (see chapter "Installation and
connections").
Never immerse the end of the drain hose
into the draining water.
Prior starting the washing cycle lock the
door by pressing them at the designed
spot.
Door may not be open during the washing
cycle.
We recommend running the self-cleaning
program before the first wash in order to
remove any impurities from the washing
machine drum. (See chapter on” Selecting
additional functions”.
Use only detergents and softeners for
machine wash. Manufacturer may not
assume responsibility for any damage and
eventual discolouring of gaskets and plastic
components as a consequence of incorrect
use of bleach and/or colouring agents.
For removal of lime residues use such
agents with added anti-corrosion agents.
Follow the manufacturer’s instructions.
Finish the lime removal by multiple rinsing
to remove completely eventual acid
residues (e.g. vinegar etc.).
Never use detergents containing solvents,
since there is a danger of creating toxic
gasses which may damage the machine and
result in ignition or explosion.
This product does not release silver ions
during the washing cycle.
Upon completion of the washing cycle,
close the water faucet and unplug the
mains cord.
Before transporting the machine after it
has been used, block the drum by inserting
at least one transport blocking rod.
Disconnect the appliance from the mains
power before inserting the rod!

9
409016
BEFORE CONNECTING THE WASHING MACHINE:
Carefully read the instructions for use before connecting
the washing machine. Repair or any warranty claim
resulting from incorrect connection or use of the washing
machine shall not be covered by the warranty.
Rating plate with basic information is
located above the opening of the machine.
Leave any repairs and similar tasks
on the washing machine to an expert.
Unprofessional repair may result in an
accident or major malfunction.
The warranty shall not apply to
consumables, minor discoloration or
deviations of colour, increased noise level
as a consequence of appliance age, which
does not affect appliance functionality, and
aesthetical deficiencies which do not affect
appliance functionality or safety.
The appliance is intended exclusively
for use in households. If the appliance is
used for professional purposes, for profit,
or for purposes beyond regular use in a
household, or if appliance is used by a
person who is not a consumer, the warranty
period equals the shortest warranty period
possible as stipulated by the relevant
legislation.
THE APPLIANCE IS MANUFACTURED IN COMPLIANCE
WITH ALL RELEVANT SAFETY STANDARDS.
THIS APPLIANCE CAN BE USED BY CHILDREN
AGED FROM 8 YEARS AND ABOVE AND PERSONS
WITH REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES OR LACK OF EXPERIENCE AND
KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION
OR INSTRUCTION CONCERNING USE OF THE APPLIANCE
IN A SAFE WAY AND UNDERSTAND THE HAZARDS
INVOLVED. CHILDREN SHALL NOT PLAY WITH THE
APPLIANCE. CLEANING AND USER MAINTENANCE SHALL
NOT BE MADE BY CHILDREN WITHOUT SUPERVISION.

10
INSTALLATION AND CONNECTION
REMOVAL OF TRANSPORT BRACKETS
409016
Be careful to prevent personal injury.
In removing the wrapping be careful not to damage the
appliance with a sharp object.
Remove transport protection devices; as running the washing
machine with the blocking rods in place could result in
damage. Save transport brackets for eventual later use.
Warranty shall be void in cases of such damage.
1Move the pipes. Loosen screws
at the rear of the
machine.
2Remove the brackets.
3Slide brackets into the groove
on the blocking
rod - the right one
should be turned
around.
4Use the brackets to
rotate blocking rods
for 90° and pull
them out.
Close the openings with attached
plastic pegs.

11
INSTALLATION
SELECTING THE ROOM
409016
The appliance should be placed on a surface with concrete
base; the surface should be dry and clean in order to
prevent slipping. The adjustable feet should also be
cleaned before installation.
Vibrations, moving of the appliance and loud operation
due to incorrect setting of the adjustable feet shall not be
covered by this warranty.
1Put the appliance in horizontal
position by turning
the adjustable
legs. The legs are
adjustable up to +/-
1 cm.
2After the adjustment
tighten the nuts
firmly - towards
the bottom of the
machine!
Use a water scale and spanner No. 22 (for feet) and 17 (for the nut).

12
4X
409016
If you have a tumble dryer of the same dimensions, you can place
it on top of the washing machine by using the vacuum feet or side
by side.
Before connecting the appliance, let it warm up to room
temperature (wait at least two hours).

13
WATER INLET CONNECTION
409016
Insert the gasket with a filter net into the straight inlet hose attachment nut and screw the
nut onto the water tap (with some models, the gasket with filter net is already fitted and
any additional fitting into the nut on the straight attachment is not required).
To ensure correct operation of the appliance, water pressure inlet
must be between 0,05 and 0,8 MPa. Minimum water pressure can
be established by measuring the quantity of poured out water.
3 litres of water must be poured out from completely opened tap
in 15 seconds.
If your model has connections for both hot and cold water, then
connect one hose to the cold water supply (blue wing nut or blue
mark on the hose) and the other one to the hot water supply (red
wing nut or red mark on the hose), as indicated on the back wall
of the appliance (letters C and H) (C - cold; H – hot).
The inlet hose should be tightened manually, firmly enough to
prevent any leaks. After tightening the hose, check for any leaks.
Use of pliers, wrenches, or other similar tools is not allowed when
installing the hose, as these tools can damage the nut thread.
A
B
C
AAQUASTOP
BTOTAL AQUA- STOP
CREGULAR ATTACHMENT

14
AQUA-STOP (CERTAIN MODELS ONLY)
(CERTAIN MODELS ONLY)
TOTAL AQUA - STOP
409016
In case of damage on the interior pipe, leaking is prevented by automatic closing system
which stops water inlet to the machine. In such cases display (A) turns red. Inlet pipe must
be replaced.
Do not immerse the Aqua-stop system inlet pipe into the
water, because it contains the electric valve!
In case of damage on the interior pipe, leaking is prevented by automatic closing system
which stops water inlet to the machine. Protection system will also detect whether there
is any water leakage in the washing machine interior. In such cases, washing is suspended,
water supply is cut off, and machine switches on the pump and signals an error.
A

15
WATER OUTLET CONNECTION
409016
A
B
C
max 100 cm
min 60 cm
max 90 cm
max 100 cm
max 150 cm
A
B
C
max 100 cm
min 60 cm
max 30-40 cm
max 160 cm
max 90 cm
Fix the drain hose to run into the sink or the bathtub, or connect
it directly to the wall drain outlet (diameter min. 4 cm). The end
of outlet hose should be placed between minimum 60 cm and
maximum 100 cm above the floor level. It can be attached in three
ways (A, B, C).
AOutlet hose can be led into
a wash basin or a
bathtub. Use a string
to attach the hose
to the opening in
the elbow support
to prevent it from
slipping to the floor.
BDrain hose
can also be
attached directly to
the basin drain.
CDrain hose can also be
connected to a wall
drain with a trap
that is properly
installed to allow
cleaning.

16
CONNECT THE APPLIANCE TO THE MAINS
SUPPLY
2 h
409016
After it is installed for the first time, the washing machine should
be left to stand still for two hours before it is connected to the
power mains.
Use the power cord to connect the washing machine to the power
mains through a power outlet. The washing machine may not be
connected to the power mains through an extension cable (danger
of overheating and fire). Nominal voltage and other information is
given on the rating plate located under the door frame.
To prevent from damage by excess voltage on the mains due
to lightning strike we recommend to use a class I over-voltage
protector between the machine and the mains.
The wall socket must be accessible at all times and must be
equipped with an earth lead (in accordance with the local
safety regulations).
The permanent connection must be fitted by an authorized
personnel only.
To avoid hazard, damaged power cord may only be replaced
by the manufacturer, authorized service technician, or other
authorized person.
Never plug the appliance into the electric shaver socket or
hair dryer socket.

17
MOVING AND TRANSPORT
SUBSEQUENT TRANSPORT
409016
After transport, the washing machine should be left to stand
still for at least two hours before it is connected to the power
mains.
We recommend that installation and connection should be
done by a qualified person.
Before connecting the appliance, read the instructions for
use. Repair or any warranty claim resulting from incorrect
connection or use of the appliance shall not be covered by the
warranty.
Before transporting the washing machine, insert at lease one
blocking rod (transport protection) in order to avoid damage to
the washing machine.

18
BEFORE THE USE
409016
12
Clean the washing
machine drum
before using the
appliance for the
first time. Use a
damp cloth and a
mild cleaning agent,
or run the self-
cleaning program.
Open the door of the unplugged washing machine by pulling the
lever towards you.

19
WASHING STEPS (1 - 7)
409016
1. STEP: CHECK THE TAGS ON YOUR LAUNDRY
Normal wash
Delicate wash
Max.
washing
95°C
95
95
Max.
washing
60°C
60
60
Max.
washing
40°C
40
40
Max.
washing
30°C
30
30
Manual
washing
Washing
not
allowed
Whitening Whitening in cold water
c1
Whitening not allowed
Dry cleaning Dry cleaning in
all solvents
A
Perchloret-
yhlene R11, R113,
Petrolej
P
Dry cleaning in
kerosene, in pure
alcohol and in
R 113
F
Dry cleaning
not allowed
Ironing Hot iron max.
200°C
Hot iron max.
150°C
Hot iron max.
110°C
Ironing not
allowed
Drying Place on flat
surface
Hang wet
Hang
High temp.
Low temp.
Tumble drying
not allowed

20
2. STEP: PREPARING THE WASHING PROCESS
409016
1. Sort the laundry by type of fabric, colour, soiling, and allowed washing temperature
(see Program table).
2. Close the buttons and zippers, tie any ribbons, and turn the pockets inside-out;
remove any metal clips that could damage the laundry and washing machine interior,
or clog the drain.
3. Very delicate laundry should be put in a special protective sack.
