Gotting HG 71453-A User manual

Device Description HG 71453-A





Positioning and Identification
Antenna
— CANopen ® —
HG 71453-A
English, Revision 03 Dev. by: W.M.
Date: 12.07.2011 Author(s): RAD / L.S. / S.M.
Götting KG, Celler Str. 5, D-31275 Lehrte - Röddensen (Germany), Tel.: [phone] / 80 96 -0,
Fax: [phone] / 80 96 -80, E-Mail: [email protected], Internet: www.goetting.de

Contents HG 71453-A
English, Revision 03, Date: 12.07.2011 2
Contents
1 Identification Systems ...................................................... 4
1.1 Application Examples for the Automation................................. 4
1.2 System Components............................................................... 4
1.3 System Configuration.............................................................. 5
1.4 Functional Description ............................................................ 5
1.4.1 General Functional Description ...................................................... 5
1.4.2 Transmission Range and Function ................................................. 6
1.4.3 Signals and Timing ........................................................................7
2 Components and Operation .............................................. 8
2.1 Components in the Ground (Transponders) ............................. 8
2.2 Identifying Antenna HG 71453-A (CAN open®)........................ 8
2.2.1 Pin Allocations...............................................................................9
2.2.2 LEDs ........................................................................................... 10
2.2.3 Turn-on Characteristics ............................................................... 10
2.2.4 General Information.................................................................... 10
2.2.5 Data Interface CANopen®....................................................................................... 10
2.2.5.1 Description of the Process Data Objects (PDO) ....................... 10
2.2.5.2 Heartbeat ............................................................................... 11
2.2.5.3 Description of the Service Data Objects (SDOs) ...................... 12
2.2.5.4 Object Directory...................................................................... 12
2.2.5.5 Manufacture Parameters - Node Parameters ........................... 17
2.2.6 Node Address.............................................................................. 18
2.2.7 RS 232 - Interface ....................................................................... 18
2.2.8 Positioning Pulse......................................................................... 18
3 Mounting and Setup ........................................................19
3.1 Testing a Transponder.......................................................... 19
3.2 Mounting a Transponder ....................................................... 19
3.2.1 Mounting in very solid Ground (e. g. concrete) ............................. 20
3.2.2 Mounting in Tough Material (e. g. tar) .......................................... 20
3.3 Reading Antenna .................................................................. 20
3.3.1 Mounting Drills ............................................................................ 20
3.3.2 Connection .................................................................................. 21
3.4 Maintenance......................................................................... 21
4 Software .........................................................................22
4.1 Terminal program ................................................................. 22
4.1.1 Locate HyperTerminal / Add it to the system ............................... 22
4.1.2 Parameter Settings ...................................................................... 23

Contents HG 71453-A
English, Revision 03, Date: 12.07.2011 3
4.2 Monitor Program ................................................................... 24
4.2.1 Programming of a Transponder of Type HG 71325 ....................... 25
4.2.2 CAN Menu................................................................................... 26
4.2.3 Update of the Internal Software (Firmware) .................................. 27
5 Technical Data ................................................................29
6 EDS File .........................................................................30
7 List of Pictures ................................................................31
8 List of Tables ..................................................................32
9 Index ..............................................................................33
10 Handbook Conventions....................................................34
11 Copyright and Terms of Liability ......................................35
11.1 Copyright.............................................................................. 35
11.2 Exclusion of Liability ............................................................. 35
11.3 Trade Marks and Company Names........................................ 35

Identification Systems HG 71453-A
English, Revision 03, Date: 12.07.2011 4
1 Identification Systems
To ensure that the operating procedure is working properly, the data transmission be-
tween different objects (die carrier, tools, vehicles etc.) and the control system is de-
cisive. Mobile objects have to be identified and positioned fast and safely.
Thus identification systems provide a safe and economical solution, which can be in-
stalled easily. Using these systems it is possible to operate and control the process
flow.
Such a system is suitable for nearly all sectors in which production and transportation
processes have to be automated. For the realization of these automations, data has to
be recorded, collected and processed on the route of transport, at their final destina-
tion, at the premises and at the manufacturing site.
The low-cost antenna HG 71453-A offers identification as well as positioning.
1.1 Application Examples for the Automation
Automation can be realized within the following sectors:
-Storage
-Position fixing of vehicles and containers
-Production lines
-Control of material flow
-Identification of containers
-Control of loading and unloading processes
-Positioning of vehicles in industrial engineering
-Distance control of track guided vehicles
-Position fixing for public transport
Special advantages of the inductive identification system are a positioning accuracy
of up to one millimeter, identification and an insensitiveness to contamination.
1.2 System Components
In order to create a whole positioning and identification system, transponders are
needed. The antenna HG 71453-A can use the following types:
Transponder HG 71325 (free codable) / HG 71370 (switch transponder)
Frequency Antenna Transponder
125 kHz HG 71453YA HG 71325ZA (other types on demand)
409 kHz HG 71453ZA HG 71325YA, HG 71370-A (switch transponder)
Table 1 Available antennas and transponders

Identification Systems HG 71453-A
English, Revision 03, Date: 12.07.2011 5
1.3 System Configuration
Figure 1 System configuration
1.4 Functional Description
1.4.1 General Functional Description
When the antenna crosses a transponder it supplies it with energy by an alternating
electromagnetic field. As soon as there is enough energy available within the tran-
sponder, it starts to attenuate the magnetic field cyclically with its encoder. This atten-
uation is reflected to the antenna and generates an amplitude modulation (AM) of the
transmitting component.
Inside the receiver the signal will be regained from the AM, decoded and the data will
be put out serially via the CAN bus. The transponders HG 71325 can optionally be re-
configured with a new code by usage of the magnetic field.
Reading Station
Interpreter
Reading antenna
Serial output of the read
transponder code and the
positioning pulse
Data carrier

Identification Systems HG 71453-A
English, Revision 03, Date: 12.07.2011 6
1.4.2 Transmission Range and Function
The field intensity of the magnetic alternating field decreases with an increasing dis-
tance between transponders and reading antenna. Thus the information exchange is
only feasible within a certain area.
The field length L and the field width B of the transmission range (see Figure 2 on page
6) will be defined via the parallel centre line through the reading antenna (road). The
distance between reading antenna and the sectional plane is indicated as S.
A faultless function of the system is guaranteed if the transponders and the reading
antenna move towards each other with the distance specified by S and within the
range defined by L and B - provided that they are properly aligned. The transponder
(line C, max. offset) will even be detected in case of an offset (deviation from centre).
Then the positioning impulse will be output with an offset. D shows the data-free area
in which no telegrams are output. This area has a width of 25 to 30 mm at nominal
reading height.
Figure 2 Length and width of the interception area (view from above)
Positioning is carried out according to the field compensation method. In the center of
the reading antenna the resulting field for the transponder will be erased. At the inter-
section to this region (registration gap or data-free range) the position of the transpon-
der at the object will be detected accurately and indicated (see table 3 on page 7).
Direction of travel
L
Magnetic
field lines
Line C
(max. offset)
Offset (Z)
Line A
Transponder
Area II
Area I
(Registration
ranges of the
reading unit)
Activation of the positioning pulse (dependent on the direction of travel)
D
Reading
antenna
B

Identification Systems HG 71453-A
English, Revision 03, Date: 12.07.2011 7
1.4.3 Signals and Timing
With the transponders HG 71310, HG 71320 and HG 71325.
Figure 3 Signals and Timing
Initially the data are insecure and the signal strength is still small (range II). Approach-
ing further the signal becomes stronger and can be read completely. The loss of the
interception area is detected via the controller in that the thresholds are reached (3
and 4). Finally the internal interception range (range I) will be achieved.
Crossing the field border at point 4 releases the center signal. Passing the next detec-
tion ranges (5 to 8) the data are read again and will be indicated. At the field border,
point 8, no center signal will be released. The center signal will not even be set if the
vehicle stops and drives back after having passed point 1 to 4 within the interception
gap (4 and 5). The positioning signal for this transponder will only be sent again if an-
other transponder with a new code is read in the meantime or a reset is carried out via
the corresponding CAN bus command.
NOTE! If a vehicle stops before the central pulse ends and changes the
direction of travel, a wrong central pulse is generated on position
1 or 4. These positions can not be defined exactly. Thus the
identification system should only be used in installations
without any change in the direction of travel.
NOTE! Interfering signals in the areas between point 2 and 3 or 6 and 7
can lead to data errors. In this case positioning pulses are gener-
ated at the corresponding, wrong position.
Transponder (Data Carrier)
Zt: Positioning pulse time = 100 ms

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 8
2 Components and Operation
2.1 Components in the Ground (Transponders)
Transponders type HG 71325 (by Götting KG) are applied as reference markers within
the ground. The system is compatible to all transponders of type HG 713XX used so
far (depending on the installed version of the reading antenna).
By using the switchable transponder HG 71370 a simple point- to- point connection in
addition to the positioning is feasible. The transponder, e.g. installed within the ground,
signals an approaching vehicle to the system. Thus the system is able to transfer a
message to the vehicle by selecting one of 4 codes to choose from. Furthermore tran-
sponder version HG 71370-W is able to change the positioning mode.
The transponder code provides 16 Bit serially or parallel.
2.2 Identifying Antenna HG 71453-A (CAN open®)
The antenna system is in a 53 x 31 x 156.5 mm casing (polycarbonate). The antenna
is connected by 5-pole cables. The terminal connector is an M12 circular connector
(see Figure 4). As accessory elbow jacks with different cable lengths (standard 2 m)
and terminating resistors are available.
Figure 4 Antenna dimensions HG 71453-A
M12 x 1 circular connector
5-pin (female)
A-coded
M12 x 1 circular connector
5-pin (male)
A-coded
Position of ferrite rod
156.5 mm
CAN Address
A-coded
5-pin (male)
M12 x 1 circular connector

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 9
2.2.1 Pin Allocations
ST1 Pin Allocation
1+UB
2POSI out (20 mA)
3TxD (RS 232) *)
4RxD (RS 232) *)
5GND (Data and Supply)
*) TxD and RxD refer to the antenna.
Table 2 Pin alloc. of the 5-pin circular connector ST1 (male)
ST2 Pin Allocation
1n.c. *)
2n.c. *)
3CAN_GND
4CAN_H
5CAN_L
*) Pins 1 and 2 are interconnected between ST2 and ST3
Table 3 Pin alloc. of the 5-pin circular connector ST2 (female)
ST3 Pin Allocation
1n.c. *)
2n.c. *)
3CAN_GND
4CAN_H
5CAN_L
*) Pins 1 and 2 are interconnected between ST2 and ST3
Table 4 Pin alloc. of the 5-pin circular connector ST3 (male)

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 10
2.2.2 LEDs
5 LEDs are provided for function control
2.2.3 Turn-on Characteristics
Once power is supplied the positioning output is active as long as a reset is carried
out (approximately 500 ms). Additionally all LEDS, except for the BUS-LED, will be
turned on for 500 ms each in order to test their function. After approximately 2 s the
device is ready for operation.
2.2.4 General Information
The code supplied by the transponder has a sequence of 24 bits, 16 bits are encoded.
The serial interface is only used for the monitor programme as described in section 4.2
on page 24. For this antenna the data as well as one status byte will be output via the
CAN bus. The programming of transponders can also be performed via the CAN bus.
2.2.5 Data Interface CANopen®
The node ID and the transmission rate have to be set either with the help of the serial
monitor or the corresponding SDOs. The measured values of the system (code and
status) are transmitted via a so-called TxPDO. SDOs or the serial monitor are used for
parameter setting. The CAN identifiers are derived from the node address (1..127).
2.2.5.1 Description of the Process Data Objects (PDO)
Fixed places are allocated for the measured values. Dynamical mapping is not possi-
ble. PDO_1 is transmitted as a combination of the Identifier 0x180 and the node ad-
dress. It is either sent cyclically (event time > 10 ms) or only when the measured
values have changed (inhibit time > 10 ms). In order to avoid excessive bus usage, it
is possible to set the so-called Inhibit time within the CAN menu of the serial mon-
itor or with an SDO. PDO_1 consists of exactly 3 bytes containing of 16 bit transponder
code and the status. The latter is equal to the status as shown in the monitor program.
Please refer to Table 6 and Table 7 for an explanation of what these values mean.
LED Description
PWR Indicates that operating voltage is supplied, device is ON
CD Shines steadily, if a transponder is located in area I (see
Figure 2 on page 6)
DATA - Flickers, if a transponder approaches the reception
range (area II in Figure 2 on page 6)
- Shines steadily, once the transponder is read reliably
POS Corresponds to the positioning output
BUS - Shines steadily in „operational“ state
- Blinks in „pre-operational“ state
- Flashes in „stopped“ state
- Is off in case of CAN Bus errors
Table 5 Functions of the 5 LEDs

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 11
It is also possible to permanently deactivate a TxPDO by selecting the asynchronous
mode (255) with inhibit time = 0 and Event_time = 0, then store the parameters. In ad-
dition, it is possible to temporarily deactivate/activate the TxPDO by setting/deleting
the highest ranking bit within the corresponding PDO COB Identifier [1800,01].
The description of the status bits is shown in the following table:
2.2.5.2 Heartbeat
The heartbeat mode is supported. Whenever a heartbeat time > 0 is set in the CAN
menu, the device status is transmitted under identifier (0x700 + node address) every
time the heartbeat timer has expired.
Value No. format Value range Description
Code unsigned 16 0...0xffff Code bits 0 .. 15
Status unsigned 8 ./. Status bits, see following table
Table 6 Variables of PDO_1
Bit no. Value Description
70x80 Positioning pulse active (equivalent to the LED
„POS“)
60x40 Transponder modulation detected (equivalent to the
LED „CD“)
50x20 Transponder codes are decoded (equivalent to the
LD „DATA“)
40x10 Not used
30x08 Not used
20x04 Not used
10x02 Not used
00x01 The check sum of the EEProm parameters is wrong
Table 7 Status bits
Node status Code
stopped 0x04
preoperational 0x7f
operational 0x05
Table 8 Coding of the Node status

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 12
2.2.5.3 Description of the Service Data Objects (SDOs)
The service data object is used to access to the object index. An SDO is always trans-
mitted with a confirmation, i. e. each reception of the message is acknowledged. The
identifiers for read and write access are:
Read access: 0x600 + node address,
Write access: 0x580 + node address.
The SDO telegrams are described in the CiA®standard DS-301. The error codes in
case of faulty communication are listed in the following table:
2.2.5.4 Object Directory
All objects relevant for the device are included in the CANopen® Object Directory.
Each entry is indicated by a 16 bit index. Sub-components are indicated by a 8 bit sub
index. RO indicates read only entries. The object index is subdivided into the following
areas:
Overview of the object directory:
Name Number Description
SDO_ABORT_UNSUPPORTED 0x06010000 non-supported access to an object
SDO_ABORT_NOT_EXISTS 0x06020000 object not implemented
SDO_ABORT_READONLY 0x06010002 write access to a read-only object
SDO_ABORT_SIGNATURE 0x08000020 The signature ’load’ or ’save’ was not used for load-
ing or saving parameters. On the deletion of the
transponder code the signature „c“ was not used.
Table 9 SDO telegram error codes
Index Subindex Access Description EEProm
0x1000 0RO Device Type
0x1001 0RO Error Register
0x1008 0RO Device Name
0x1009 0RO Hardware Version
0x100A 0RO Software Version
0x1010 0RO Number of entries of Save
Parameter
1RW Store all
Table 10 CANopen®Directory: Communication specific entries in the range from
0x1000 to 0x1FFF (part 1 of 2)

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 13
0x1011 0RO Number of entries of Restore
Default Parameter
1RW Restore Default all
0x1017 0RW Producer Heartbeat Time X
0x1018 0RO Number of entries of Identity
Object
1RO Vendor ID
2RO Product Code
3RO Revision
0x1800 0RO Number of entries of Transmit
PDO_1
1RW COB-ID
2RO Transmission Type
3RW Inhibit Time X
5RW Event Time X
0x1A00 0RO Number of Objects mapped to
Transmit PDO_1
1RO Specification of Appl. Object 1
2RO Specification of Appl. Object 2
Index Subindex Access Description EEProm
0x2000 0RO Number of Manufacture Parame-
ters
1RW Program transponder with 16 Bit
Code
2WO Delete last transponder code (in
order to make Posi Pulse fire
again for the same code)
0x2001 0RO Number of Parameters
1RW Node Baud Rate X
2RW Node ID X
3RW Node Config X
Table 11 CANopen®Directory: Manufacturer specific entries at 0x2000
Index Subindex Access Description EEProm
Table 10 CANopen®Directory: Communication specific entries in the range from
0x1000 to 0x1FFF (part 2 of 2)

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 14
Explanation of the entries:
0x6000 0RO Number of 8 Bit Inputs
1RO Status bits (see Table 7 on page 11)
0x6100 0RO Number of 16 Bit inputs
1RO Transponder code bits 0..15
Table 12 CANopen®Directory: Standardised device profile area in the range from
0x6000 to 0x6400
Index Sub Ind. Name Type Attr. Map Default Description
0x1000 00 Device Type Unsigned 32 RO No 0x00010191 Digital Inputs - DS
401
Table 13 CANopen®Directory: Device Type
Index Sub Ind. Name Type Attr. Map Default Description
0x1001 00 Error Register Unsigned 8 RO No 0x00 Error Register
Table 14 CANopen®Directory: Error Register
Index Sub Ind. Name Type Attr. Map Default Description
0x1008 00 Manufacturer
Device Name
Visible
String
RO No „7145“ Device Name
Table 15 CANopen®Directory: Manufacturer Device Name
Index Sub Ind. Name Type Attr. Map Default Description
0x1009 00 Hardware Version Visible
String
RO No „3-A1“ Hardware version no.
Table 16 CANopen®Directory: Hardware Version
Index Sub Ind. Name Type Attr. Map Default Description
0x100A 00 Software Version Visible
String
RO No „1.08“ Software version no.
Table 17 CANopen®Directory: Software Version

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 15
By writing the signature ’save’ or the backwards form ’evas’ in ASCII Code (hex-Code:
0x65766173) onto subindex 1, the currently set parameters are permanently saved. A
successful recording procedure is acknowledged after about 120 ms by a TxSDO (1st
Byte = 0x60). The saving process is performed after that acknowledgement. During
that process CAN telegrams can not be received or transmitted.
By writing the signature ’load’ or the backwards form ’daol’ in ASCII Code (hex-Code:
0x64616F6C) onto subindex 1, the corresponding default parameters are loaded. A
reset should be carried out to make the antenna use them.
In case of ’Restore All’, the Node ID is also set to 1 and the baud rate to 125 Kbaud.
In order to deactivate this function set the Producer Heartbeat Time to 0.
Index Sub Ind. Name Type Attr. Map Default Description
0x1010 00 Save Parameters Unsigned 8 RO No 0x01 No. of sub indices
01 Save All Unsigned 32 RW No 0x00000001 Save All is possible
Table 18 CANopen®Directory: Save Parameter
Index Sub Ind. Name Type Attr. Map Default Description
0x1011 00 Restore Parame-
ters
Unsigned 8 RO No 0x04 No. sub indices
01 Restore All Unsigned 32 RW No 0x00000001 Restore All is possi-
ble
Table 19 CANopen®Directory: Restore Default Parameter
Index Sub Ind. Name Type Attr. Map Default Description
0x1017 00 Producer Heart-
beat Time
Unsigned 16 RW No 1000 Heartbeat time in ms
(approx.)
Table 20 CANopen®Directory: Producer Heartbeat Time
Index Sub Ind. Name Type Attr. Map Default Description
1018 00 Identity Object Unsigned 8 RO No 0x03 No. of sub indices
01 Vendor ID Unsigned 32 RO No 0x00000202 Manufacturer no. as
specified by the CiA®
02 Product Code Unsigned 32 RO No 0x00071453 HG no. 71453
03 Revision Unsigned 32 RO No 0x00000001 Version 1.00
Table 21 CANopen®Directory: Identity Object

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 16
By setting sub index 1 to a 16 bit code this code will be programmed into a transpon-
der within the range of reception.
By writing the signature "c" in ASCII code (hex code: 0x63) to sub index 2 the last
stored transponder code is „deleted“. Afterwards a transponder with the same code
can again generate a positioning pulse.
Index Sub Ind. Name Type Attr. Map Default Description
1800 00 TxPDO_1 Param-
eter
Unsigned 8 RO No 0x05 No. of sub indices
01 COB ID Unsigned 32 RW No 0x180 +
Node ID
PDO_1 valid,
ID = 0x180 + Node ID
02 Transmission
Type
Unsigned 8 RO No 255 Asynchronous,
event-driven
03 Inhibit Time Unsigned 16 RW No 100 Shortest period
between transmis-
sions in μs
05 Event Time Unsigned 16 RW No 10 Cycle time in ms
Table 22 CANopen®Directory: Transmit PDO_1 Parameter
Index Sub Ind. Name Type Attr. Map Default Description
0x1A00 00 number of
mapped objects
Unsigned 8 RO No 0x02 No. of sub indices
01 1st mapped
object
Unsigned 32 RO No 0x61000110 Mapped to index
0x6100,01 with a
length of 16 Bit
(Code 0..15)
02 2nd mapped
object
Unsigned 32 RO No 0x60000108 Mapped to index
0x6000,01 with a
length of 8 Bit (Sta-
tus)
Table 23 CANopen®Directory: Mapping TxPDO_1
Index Sub Ind. Name Type Attr. Map Default Description
0x2000 00 number of
manufacture
parameters
Unsigned 8 RO No 0x02 No. of sub indices
01 Prog_
Transponder
Unsigned 16 RW No 0Transponder code
that is to be pro-
grammed
02 Clear_Code Unsigned 8 WO No ./. Delete last transpon-
der code
Table 24 CANopen®Directory: Manufacture Parameters

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 17
2.2.5.5 Manufacture Parameters - Node Parameters
Index Sub Ind. Name Type Attr. Map Default Description
0x2001 00 Number of
Parameter
Unsigned 8 RO No 0x03 No. of sub indices
01 Node Baud rate Unsigned 8 RW No 0x04 125 Kbaud *)
02 Node ID Unsigned 8 RO No ./. Node address as set
with the turn-
switches (see 2.2.6
on page 18)
03 Node Config Unsigned 8 RW No 0x01 Start in „operational“
state
Highbyte first **)
*)
**)
Table 27 CANopen® Directory: Manufacture Parameters - Node Parameters
Index Sub Ind. Name Type Attr. Map Default Description
0x6000 00 number of 8 bit
inputs
Unsigned 8 RO No 0x01 No. of 8 bit inputs
01 8 bit digital input Unsigned 8 RO Yes ./. Status
Table 28 CANopen® Directory: 8 Bit Digital Inputs (transmitted in TxPDO 1)
Input / output value Baud rate [kBaud]
720
650
4 (Default) 125
3 250
2 500
1 800
0 1000
Table 25 CANopen® Directory: Node Parameters / Coding of
baud rates
Value Description
xxxx.xxx0 Start in „pre-operational“ state
xxxx.xxx1 Start in „operational“ state
xxxx.xx0x High byte first
xxxx.xx1x Low byte first
Table 26 CANopen® Directory: Values of Node Config Bytes

Components and Operation HG 71453-A
English, Revision 03, Date: 12.07.2011 18
2.2.6 Node Address
Two hex turn-switches protected by seal plugs can be used to adjust the CANopen®
address (please refer to Figure 4 on page 8). Open the seal plugs, then use a screw-
driver to set the address in the range from 01 to 7F. Close the seal plugs afterwards.
In order to use the new address the antenna has to be switched off and turned on
again.
2.2.7 RS 232 - Interface
For this interface the transmission parameters are fixed: 38400, 8 data bit, even parity,
continuous output, ASCII-coded. Transponders can be programmed via the serial in-
terface (see section 4.2 on page 24).
So long as sufficient power voltage is supplied the following data will be output once
a transponder code is read (using a 5 ms pattern).
-16 Bit transponder code as a decimal number between 0..65535
-Status of LED CD
-Status of LED DATA
-Status of LED POS
The data is output ASCII coded, the data sets are separated by a comma. Data lines
are ended with a <CR LF> . Data of this format can be recorded with Hyperterm and
then be saved as a so-called CSV file. Those data files can easily be modified with a
spread sheet application like e.g. Microsoft Excel.
By hitting on the keyboard the monitor program is started.
2.2.8 Positioning Pulse
The positioning pulse is triggered as soon as the center of the antenna is crossed. It‘s
duration is 100 ms. Once this pulse is triggered the corresponding output is switched
to 24 V with a current limitation of 20 mA. Please refer to chapter 1.4.3 „Signals and
Timing“ on page 7 for the timing of the Positioning Pulse.
Index Sub Ind. Name Type Attr. Map Default Description
0x6100 00 number of 16 bit
digital inputs
Unsigned 8 RO No 0x01 No. of 16 bit inputs
01 16 bit digital input Unsigned 16 RO Yes ./. 16 bit transponder
code
Table 29 CANopen® Directory: 16 Bit Digital Inputs

Mounting and Setup HG 71453-A
English, Revision 03, Date: 12.07.2011 19
3 Mounting and Setup
3.1 Testing a Transponder
It is possible to test the transponders with a reading antenna and a connected PC (see
section 4.2 on page 24).
3.2 Mounting a Transponder
Figure 5 Mounting proposal and metal-free area around the transponder HG 71325
Range and positioning accuracy will be influenced by
-Metal parts lying on the ground (sheet metals)
-Reinforcement laid close to the transponder
-Induction loops, e.g. formed by structural steel
NOTE! Individual metal rods have only little influence and may hurt the
metalfree area partially (see figure Figure 5 on page 19).
There is no influence on the positioning accuracy caused by
-Environmental influences as snow, ice and water
-Contaminations as oil, tar etc.
Please pay attention to the following mounting instructions for tran-
sponder HG 71325
-Keep a minimum distance of 500 mm between the transponders.
-Keep a minimum distance to metal parts (see figure Figure 5 on page 19). The
influence on positioning accuracy and range depends on the size and the range
of the metal parts.
-The minimum distance between conductors with a diameter smaller than 6 mm
has to be 2 mm.
Approx. 150 mm
Cover / Protection area
Protective casing
E.g. air cushion foil
or plastics spring
Metal-free area
Distance between two transponders >= 500 mm
singular installed wires
Approx. 100 mm
Approx. 50 mm
Transponder
2 mm
(ø <= 6 mm)

Mounting and Setup HG 71453-A
English, Revision 03, Date: 12.07.2011 20
-To protect the transponder use either a covering cap or apply an epoxy resin layer
(thickness approximately 1 cm). The drill hole mouth should be wide enough so
that the cover cannot press on the transponder.
Which end of the transponder is turned upwards is insignificant for the range or the
function.
3.2.1 Mounting in very solid Ground (e. g. concrete)
-No additional protective casing necessary.
-Upright alignment required (otherwise a position error will be generated).
-Mould the transponder (e.g. with a two component epoxy resin).
3.2.2 Mounting in Tough Material (e. g. tar)
-Protection tube necessary (e. g. made of fiber-reinforced plastic material).
Choose the diameter accordingly to the maximum the load.
-Arrange the transponders upright (otherwise a position error will occur) in foamed
material.
3.3 Reading Antenna
3.3.1 Mounting Drills
Figure 6 Mounting of the identifying antenna: Position and size of the drilling holes
To achieve a maximum range (> 50 mm) of the reading distance, it is recommended
to mount a 10 mm plastic plate or a 10 mm distance bolt between the steel or alumin-
ium rack and the reading antenna. When using distance bolts a sufficiently large shim
has to be placed under the reading antenna‘s casing.
NOTE! If several antennas are used within one installation they have to
be mounted with a minimum distance of 1500 mm between
each other.
HG 71453-A
ø5.3 mm
156.5 mm
Position of the
ferrite rod
