Graco 244811 User manual

309368
Rev. H
First choice when
quality counts.t
INSTRUCTIONS
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
Direct-Drive Pressure Washers
2730
Model 244811, Series B with Briggs & Stratton 6.5 HP Motor
2700 psi (186 bar, 18.6 MPa) Operating Pressure
3000 psi (210 bar, 21.0 MPa) Maximum Working Pressure
2730
Model 244812, Series B with Honda 6.5 HP Motor
2700 psi (186 bar, 18.6 MPa) Operating Pressure
3000 psi (210 bar, 21.0 MPa) Maximum Working Pressure
3030
Model 244813, Series B
3000 psi (210 bar, 21.0 MPa) Operating Pressure
3300 psi (227.5 bar, 22.75 MPa) Maximum Working Pressure
3340
Model 244814, Series B
3300 psi (227.5 bar, 22.75 MPa) Operating Pressure
3600 psi (248 bar, 24.8 MPa) Maximum Working Pressure
3540
Model 244815, Series B
3500 psi (241 bar, 24.1 MPa) Operating Pressure
3800 psi (262 bar, 26.2 MPa) Maximum Working Pressure
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440--1441
ECOPYRIGHT 2001 GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
3300 Pressure Washer
Model 244814 Shown

2309368
Table of Contents
Symbols 2......................................
Warnings 3......................................
Component Identification 4........................
Pressure Relief Procedure 7.......................
Installing and Changing Spray Tips 13..............
Parts Drawing 16.................................
Parts List 17.....................................
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow instruc-
tions.

Equipment Misuse Hazard:
Misuse of pressure washer or accessories can cause the equipment to rupture or malfunction and
result in serious injury.
DDo not alter or modify any part or factory--setting.
DCheck equipment daily. Repair or replace worn or damaged parts immediately.
DDo not exceed maximum working pressure (MWPR) of the lowest--rated system component.
DUse fluids and solvents that are compatible with the equipment wetted parts. See Specifications page
for this information.
DWear hearing protection when operating this equipment.
DDo not “blow back” fluid; this is not an air spray system.
DFollow Pressure Relief, page 7 before cleaning, checking or servicing equipment.
Injection Hazard:
Spray from gun, leaks or ruptured components can inject fluid into your body and cause serious
injury. Fluid splashed in eyes or on skin can also cause serious injury.
DFluid injected into skin might look like just a cut, but it is a serious injury. Seek immediate surgical
treatment.
DDo not point gun at anyone or any part of the body.
DDo not stop or deflect leaks with hand, body, glove, or rag.
DDo not put your hand or fingers over the spray tip.
DTIghten fluid connections before you start this equipment.
DEngage the gun safety whenever you stop spraying.
DFollow Pressure Relief Procedure, page 7 if the spray tip clogs and before you clean, check or
service this equipment.
DRepair or replace worn or damaged parts immediately.
DCheck hoses, tubes, and couplings daily. Do not repair high--pressure couplings. Replace entire
hose. Fluid hoses must have spring guards on both ends to prevent kinks and rupture.
TOXIC FLUID HAZARD:
Hazardous fluid or toxi fumes can cause serious injury or death if splashed in eyes or on skin,
inhaled, or swallowed.
DKnow specific hazards of fluids you are using and take protective measures as recommended by
the fluid and solvent manufacturer.
Fuel Hazard:
Fuel is combustible. When spilled on a hot surface it can ignite and cause a fire.
Do not fill fuel tank while engine is running or hot.
Exhaust Hazard:
Exhaust contains poisonous carbon monoxide, which is colorless and odorless. Do not operate this
equipment in a closed building.
WARNINGS
3309368

4309368
Component Identification
Gun and wand
Oil Level Site Gauge
High Pressure Hose
Connection
Hose
On/Off Engine Switch (side)
Water Pump Oil Fill
Engine Oil Fill
Pressure Unloader
Adjustment Knob
Tip Storage
Hose Rack (a)/Gun Holder (b)
(b)
(a)
Garden Hose
Connection
Pressure Gauge (not
shown)

5309368
Shipping Damage
Check the pressure washer for shipping damage. Notify the carrier immediately if there is any damage.
Setup
Connect High--Pressure Hose and Gun
Connect the high--pressure hose between the pump outlet and gun inlet.
Both of these connections are made with quick couplers.
Install Spray Tip
Install the spray tip on the wand. (Installing and Changing Spray Tips, page 13). If you are using a Sandblast-
ing Kit, see its separate manual for installation instructions.
Up to 100 ft (30 m) of 3/8” high--pressure hose may be used. Longer hoses could affect pressure
washer and chemical injector performance balance.
CAUTION
Connect to Water Supply
Connect hose with at least a 3/4--in (19 mm) ID from the water supply to the 3/4--in garden hose inlet
on the pressure washer. The supply hose should not be more than 50 ft (15 m) long.

6309368
CAUTION
Before you connect the garden hose to the pressure washer, check your local plumbing code regarding
cross--connection to the water supply. If required, install a backflow preventer.
If the inlet water pressure is over 60 psi (4.1 bar), a regulating water valve must be installed at the garden
hose connection.
Do not exceed 160_F(70_C) inlet water temperature.
NOTE: The water source must have a minimum flow rate equal to that of the pressure washer.

7309368
PRESSURE RELIEF
Follow these instructions whenever you are instructed to relieve pres-
sure, stop spraying for more than 10 minutes, check or service the
equipment, or install or clean the spray nozzle.
1. Engage trigger safety latch.
2. Turn pressure washer off.
3. Remove ignition cable from spark plug.
4. Shut off water supply. Disconnect from water.
5. Disengage trigger safety latch and trigger the gun to
relieve pressure. Then re--engage the safety latch.
Note: If you suspect that the spray tip or hose is clogged or that pressure has not been fully relieved after
following the steps above, disengage the trigger safety latch and trigger the gun to relieve pressure.

8309368
1.Check the oil level of the engine and pump.
Startup
Always use this startup procedure to ensure that the pressure washer is started safely and properly.
DAlways engage the gun trigger safety latch when you stop spraying. This reduces the risk of fluid
injection or splashing in the eyes or on the skin if the gun is bumped or triggered accidentally.
DAlways observe the CAUTIONS in this section to avoid costly damage to the pressure washer.
DIf you use the Sandblaster Kit, see the Sandblaster Kit Manual for detailed cleaning information.
.
Operation
NOTE: All Honda engine powered pressure washers are equipped with an engine low-oil sensor that shuts the
engine off if the oil level falls below a certain level. If the engine stops unexpectedly, check the oil and the fuel
levels. Check the oil level each time you add fuel.
Oil level
FIRE HAZARD
Do not refuel a hot engine. Refueling a hot engine could cause a fire. Use only fresh, clean,
regular or unleaded gasoline. Close the fuel shutoff valve during refueling.
WARNING
2. Check fuel level. Fuel level
3.Check oil level in pump. It should be half way up the sight
glass located on the front of the pump. Add pump oil as
necessary. The system is equipped with a thermal over-
load to help prevent severe damage.
Oil level
NOTE: It is important to drain and refill the pump oil after the first 50 hours of operation.

9309368
4.Turn on water supply.
5.Trigger the gun until a constant stream of water sprays from the tip indicating
the air is purged from the system.
6.Open fuel shutoff valve. Be sure the spark plug ignition
cable is pushed firmly onto the spark plug.
7.Put the switch in the ON position and the throttle at HALF
throttle.
Never run pressure washer without water. Costly damage to the pump will result. Always be sure the water
supply is completely turned on before you run the pressure washer.
CAUTION

10 309368
8.Pull the starter rope quickly to start the engine.
Pull and return the rope until the engine starts.
HINT: Placing one foot on the pressure washer
as a brace provides better leverage.
Do not allow pressure washer to idle for more than 10 minutes. This causes the recirculating water to
overheat and serious damage to pump. Turn off pressure washer if it will not be spraying at least every 10
minutes. If heated inlet water is used, reduce this time more. Do not operate pressure washer with inlet
water screen removed. This screen helps keep abrasive sediment out of pump, which could clog pump or
damage cylinders. Keep screen clean. Do not pump caustic materials; such materials could corrode pump
components.
CAUTION
NOTE: For easier starting, have one person start pressure washer while another triggers gun.
DIf engine is cold, start engine with choke completely closed. In cool weather, you might have to let engine
run with choke closed for first 10--30 seconds. In warm weather, open choke completely as soon as en-
gine starts.
DIf engine is warm, start engine with choke completely open or partially closed. When engine starts open
choke completely.
OPEN
HALF
CLOSED

11309368
Trigger Safety Latch
Always engage the safety latch when you stop spraying.
engaged
disengaged
WARNING
Always engage the trigger safety latch when you stop spraying even for a moment. The
engaged, safety latch prevents the fun from being triggered accidentally by hand or when
dropped or bumped. Be sure the latch is pushed fully down, or it will not prevent the gun from
being triggered.
WARNING

12 309368
1.Follow Pressure Relief Procedure (page 7).
Chemical Injector Operation
2.Insert chemical filter (attached with clear tubing to
chemical injector) into the container of chemical.
Insert brass coupler into chemical injector.
3.Install the black, large--orifice, chemical tip. (Instal-
ling and Changing Spray Tips page 13).
The large orifice of the chemical tip causes a drop in
pressure that actuates the chemical injector. Changing
back to a small orifice spray tip deactivates the chemi-
cal injector and produces high pressure for rinsing.
The chemical filter can be left in the chemical container
during high--pressure use. To regulate the flow rate of
the chemical, turn the chemical adjustment knob on the
injector.

13309368
Spray tips have 4-- or 5--digit numbers on them.
The first two digits are the spray angle. Tip
holding holes are provided on the chassis.
1.Perform Pressure Relief Procedure (page 7).
2.Point the gun and wand away from you and anyone else.
3.Without holding your hand over the spray tip (A), pull back the
quick coupler ring (B). Remove the current tip, install a differ-
ent one. Then push the ring back on.
Installing and Changing Spray Tips
Spray Tip
Number
Spray Pattern Fan Angle
00XXX
15XXX
25XXX
40XXX
Chemical
0_blaster (red)
15_(yellow)
25_(green)
40_(white)
XX_(black)
NOTE: The chemical injector tip is brass and has a large opening and a black plastic cap.
B
A
To avoid blowing the O-ring out of the quick coupler due to the high pressure in the system, never operate
the pressure washer without a tip securely mounted in the quick coupler.
CAUTION

14 309368
DAfter each use, wipe all surfaces of the
pressure washer with a clean, damp cloth.
DBefore you store the pressure washer
overnight or transport it, disconnect the water
supply, and turn off the fuel supply valve.
Shutdown, Flushing, and Storage

15309368
SDo not store unit outside where it can be exposed to rain, dirt or adverse weather condi-
tions.
SDo not expose pressure washer to freezing temperatures or allow water to freeze in
pressure washer components, causing the pump to lock--up. If this happens let pump
thaw naturally in WARM ENVIRONMENT. DO NOT attempt to to speed up this process
by pouring warm water on pump. This could cause further damage.
Long Term (more than 30 days)/Winter Storage
ENGINE:
1. Run engine until gas is gone or stabilize the fuel and run it through the fuel system and carbu-
retor.
2. Drain water out of pressure washer hose.
3. Turn fuel system to OFF position.
Pump:
1. Attach one end of a 4 or 5--foot section of hose to pump inlet and other end in an antifreeze
solution approximately 1--foot off the ground.
2. Pull pull--cord on engine until antifreeze comes out of pump outlet.
Storage Location:
1. Store pressure washer in garage, basement or other area where it is protected from freezing
temperatures.

16 309368
Parts for 2730 Pressure Washer
Model 244811, Series A
ti1309B
40
4
41
14
5
8--12
1
25
19 26
16
31
18 27
39
33* 32*
29*
34*
235*
30
28
3
23
21
20
22
17
7
38, 15
42
43
44
45

17309368
Parts for 2730 Pressure Washer
Model 244811, Series A with 6.5 HP Briggs & Stratton motor
Ref.
No.
Part
No.
Description Qty.
1 116299 1
2 244749 1
3 244767 1
4 244779 1
5 244782 1
7 804511 2
8 805535 1
9 805536 1
10 805537 1
11 805538 1
244768 1
12 805634 1
14 804275 1
15 116342 2
16 110837 4
17 111040 4
18 197428 1
19 116411 2
20 801546 2
Ref.
No.
Part
No.
Description Qty.
21 100132 2
22 101566 2
23 801504 2
25 197792 1
26 116477 2
27 244803 1
28 116460 1
29 244741 1
30 116557 1
31 116558 1
32 804037 1
33 804402 1
34 804011 1
35 804033 1
38 116563 2
39 244821 1
40 198012 1
41 804582 1
42 15B910 1
43 244746 1
44 801112 1
45 287643 1

18 309368
Parts for 2730 Pressure Washer
Model 244812, Series A, with Honda 6.5 HP Motor
38, 15
7
26
19
17
16
20
21
23
3
5
4
8--12
22
2
27
18
28
*32
30
*33
31
*34
25
14
* internal replacement parts
*35
1
39
40
41
29*
42
43
44
45

19309368
Parts for 2730 Pressure Washer
Model 244812, Series A with Honda 6.5 HP Motor
Ref.
No.
Part No. Description Qty.
1 116298 1
2 244749 1
3 244767 1
4 244779 1
5 244782 1
7 804511 2
8 805535 1
9 805536 1
10 805537 1
11 805538 1
244768 1
12 805634 1
14 804275 1
15 116342 2
16 110837 4
17 111040 4
18 197428 1
19 116411 2
20 801546 2
Ref.
No.
Part No. Description Qty.
21 100132 2
22 101566 2
23 801504 2
25 197792 1
26 116477 2
27 244803 1
28 116460 1
29 244741 1
30 116557 1
31 116558 1
32 804037 1
33 804402 1
34 804011 1
35 804033 1
38 116563 2
39 244821 1
40 198012 1
41 804582 1
42 15B910 1
43 244746 1
44 801112 1
45 287643 1

20 309368
Parts for 3030/3340/3540 Pressure Washer
Model 244813, Series A with Honda 9 HP Motor†
Model 244814, Series A, with Honda 11 HP Motor
Model 244815, Series A, with Honda 13 HP Motor
4
5
14
39, 15
26
19
7
17
16
22
23
21
20
2
27
18
8--12
28
25
*32
30
*33
31
* internal replacement parts
*34
38
3
1
*35
40
41
42
29*
43
44
45
46
