Graco GTP10 Series User manual

311304H
Instructions - Parts List
GTP10 Pump
For pumping gasoline, diesel fuel, and kerosene. Do not use to pump other fluids including
water.
Models 260000 through 260017, 260019, 260024, 260580, and 260581
10 gpm (38 lpm), 12 VDC (CSA C/US listed motor)
Models 260020 and 260021, 10 gpm (38 lpm), 24 VDC
Models 260022 and 260023, 12 gpm (45 lpm), 230 VAC
Models 260025 through 260028
12 gpm (45 lpm), 115 VAC (CSA C/US listed motor)
10 psi (0.07 MPa, 0.7 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
CSA mark applies only to 12 VDC
and 115 VAC motors for Class I, Div
I, Group D Hazardous Locations
EN

Models
2311304H
Models
Part No. Hose Nozzle
12 VDC, 10 gpm (38 lpm), 12.5 amps
260000 260069 - 12 ft (3.66 m) grounded 260079 - manual, leaded/diesel
260001 260069 - 12 ft (3.66 m) grounded 260082 - automatic, regular/diesel
260002 260069 - 12 ft (3.66 m) grounded 260078 - manual, unleaded
260003 260069 - 12 ft (3.66 m) grounded 260083 - automatic, unleaded
260004 260526 - 4 ft (1.22 m) UL listed assembly
260523 - 8 ft (2.44 m) UL listed assembly 260078 - manual, unleaded
260005 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260006 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260007 260524 - 6 ft (1.83 m) UL listed assembly 260078 - manual, unleaded
260008 260524 - 6 ft (1.83 m) UL listed assembly 260078 - manual, unleaded
260009 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260010 260522 - 10 ft (3.05 m) UL listed assembly 260078 - manual, unleaded
260011 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260012 260523 - 8 ft (2.44 m) UL listed assembly 260078 - manual, unleaded
260013 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260014 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260015 260523 - 8 ft (2.44 m) UL listed assembly 260078 - manual, unleaded
260016 270521 - 12 ft (3.66 m) UL listed assembly
260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260017 260525 - 5 ft (1.52 m) UL listed assembly 260078 - manual, unleaded
260019 None None
260024 None None
260580 260573 - 12 ft (3.66 m) grounded 260079 - manual, leaded/diesel
260581 260573 - 12 ft (3.66 m) grounded 260082 - automatic, regular/diesel
24 VDC, 10 gpm (38 lpm), 7 amps
260020 260069 - 12 ft (3.66 m) grounded 260079 - manual, leaded/diesel
260021 260069 - 12 ft (3.66 m) grounded 260082 - automatic, regular/diesel
230 VAC, 12 gpm (45 lpm), 1 amps
260022 260069 - 12 ft (3.66 m) grounded 260078 - manual, unleaded
260023 260069 - 12 ft (3.66 m) grounded 260083 - automatic, unleaded
115 VAC, 12 gpm (45 lpm), 2 amps
260025 260069 - 12 ft (3.66 m) grounded 260079 - manual, leaded/diesel
260026 260069 - 12 ft (3.66 m) grounded 260082 - automatic, regular/diesel
260027 260069 - 12 ft (3.66 m) grounded 260078 - manual, unleaded
260028 260069 - 12 ft (3.66 m) grounded 260083 - automatic, unleaded

Models
311304H 3

Warnings
4311304H
Warnings
The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Addi-
tional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appear-
ing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual,
refer back to these pages for a description of the specific hazard.
WARNING
FIRE AND EXPLOSION HAZARD
When flammable fluids are present in the work area, such as gasoline and windshield wiper fluid, be
aware that flammable fumes can ignite or explode. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources, such as cigarettes and portable electric lamps.
• Keep work area free of debris, including rags and spilled or open containers of solvent and gasoline.
• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.
• Ground all equipment in the work area.
• Use only grounded hoses.
• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment
until you identify and correct the problem.
• Keep a fire extinguisher in the work area.
ELECTRIC SHOCK HAZARD
Improper grounding, setup, or usage of the system can cause electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before servicing
equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating
area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic
fumes, burns, and hearing loss. This equipment includes but is not limited to:
• Protective eyewear
• Clothing and respirator as recommended by the fluid and solvent manufacturer
• Gloves
• Hearing protection
PRESSURIZED EQUIPMENT HAZARD
Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the eyes or on skin and
cause serious injury.
• Follow Pressure Relief Procedure in this manual, when you stop dispensing and before cleaning,
checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immediately.

Warnings
311304H 5
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request MSDS forms from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco
replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your Graco distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
BURN HAZARD
Equipment surfaces and fluid that’s heated can become very hot during operation. To avoid severe
burns, do not touch hot fluid or equipment. Wait until equipment/fluid has cooled completely.
WARNING

Installation
6311304H
Installation
When unpacking pump, check for shipping damage.
Report any shipping damage to delivering carrier imme-
diately.
Mounting Pump
1. Apply PTFE thread tape (provided with the pump) to
large thread of bung adapter (9) (2 in. X 1 ½ in.
reducer fitting). Install bung adapter to fuel tank.
2. Assemble suction tube sections by applying ¼ in. to
½ in. wide bead of PVC cement (PN: 260086; white
tube provided with the pump) around the entire
inside diameter of the coupler (see FIG. 1). While
sliding the tube into the couplers turn the tube at
least one full revolution until the tube bottoms out on
the coupler (see FIG. 2, FIG. 3, and FIG. 4). This will
allow the cement to coat the entire surface for the
best possible seal. Allow cement to set for 5 min-
utes minimum before installing pump into tank.
CAUTION
Do not use a curb pump automatic shut-off nozzle
with this pump. Use of a curb pump automatic nozzle
may cause priming problems, reduced output flow,
and motor overheating. If an automatic shut-off nozzle
is required, use Graco part number 260082 (regular)
or 260083 (unleaded) or Catlow, Inc. part number
NCLF-1 (regular) or NCNLF-1 (unleaded).
CAUTION
• Ensure tank being used is clean and free of welding
slag
• Ensure the tank is vented to allow air into the tank
as the fuel is being pumped out. Failure to provide a
vent will cause priming problems
For tanks deeper than 36 in. (914 mm) you will
need a standard 1 in. (25 mm) pipe with 1 in. npt
threads on one end. Suction tubes longer than 60
in. (1.52 m) require a foot valve (Graco Part No.
260217) at the bottom of the tube to prevent loss of
prime.
FIG. 1
FIG. 2
FIG. 3
FIG. 4

Installation
311304H 7
3. Cut the suction tube so that it is 2 in. (55 mm) from
the bottom of the tank when installed in the tank.
4. Insert gasket (7f) into union nut (1k). If using Graco
supplied PVC suction tube it is not necessary to
apply thread tape before assembly, just screw into
pump inlet (1j). If using metal suction tube (not sup-
plied with pump) then apply thread tape provided
with pump to NPT threads before assembling to
pump inlet (1j).
5. Insert suction tube attached to pump through bung
adapter (9) into tank. Position pump as desired and
tighten union nut (1k) on bung adapter (9).
Mounting Hose and Nozzle
1. Apply thread tape provided with pump to both ends
of hose assembly. Screw ¾” NPT end of 90° union
swivel (15) to one end of hose (see fig. 5).
2. Screw nozzle onto other end of hose and tighten.
3. Start swivel end of 90° union swivel (15) onto ¾”
nipple (14) on pump outlet (see FIG. 5). Orient the
hose/nozzle assembly to desired position and
tighten swivel fitting.
It is important that the swivel end of the 90° union
swivel (15) is assembled to the ¾” outlet nipple (14)
for proper sealing (see FIG. 6). If the pump has diffi-
culty priming, it is easy to remove the swivel and
pour fluid into the pump outlet cavity when assem-
bled this way.
FIG. 5
FIG. 6

Installation
8311304H
Electrical Installation
12 VDC and 24 VDC
To install wiring for a negative ground system:
1. Ensure pump switch is OFF.
2. To remove electrical cover (2a), remove four bolts
(2c).
3. Strip 3 in. (76 mm) of outside insulation from power
cable (6c) from end opposite of fuse.
4. Strip 3/8 in. (10 mm) of insulation from red and black
wires.
5. Slide strain relief (6b) over end of power cable (6c)
on the end just stripped. Male thread of strain relief
should be toward stripped end.
6. Insert power cable through conduit thread in electri-
cal cover (2a). Connect wires from power cable to
wires from the motor using wire nuts (2e): red to red
and black to black.
7. Screw strain relief (6b) into electrical cover (2a).
8. Position power cable (6c) so the large diameter of
power cable extends through strain relief (6b).
9. Tighten nut on strain relief to form a seal around the
power cable.
10. Reinstall electrical cover (2a) on the pump.
11. Remove 1/2 in. (13 mm) of insulation from wires on
the fuse holder end of the power cable.
12. Attach battery clamps (6a) with red sleeve to red
wire and black sleeve to black wire. Wire must be
crimped to the battery clamp firmly to get a good
electrical connection.
13. Connect red wire with fuse holder inline to positive
battery terminal. Connect black wire to negative bat-
tery terminal.
Electrical Installation
115 VAC and 230 VAC
1. Ensure pump switch is OFF and electrical power is
disconnected.
2. Install conduit and user-supplied power cord to
pump.
3. Strip 3 in. (76 mm) from power cord jacket and 1/2
in. (13 mm) from individual conductor insulation.
4. To remove electrical cover (2a), remove four bolts
(2c).
5. Remove 1/2 in. (13 mm) of insulation from power
wires inside pump electrical terminal cavity.
6. Insert electrical power wire through conduit opening
in back of pump.
7. Using wire nuts (2e), connect wires: green to green,
white to white, and black to black.
8. Replace electrical cover.
If you are installing models 260580 or 260581 skip
this section. These pumps have been factory wired
Power cable can be cut to shorter length if 18 feet
(5.5 m) is not required. Cut to proper length and
proceed with steps 3 and 4.
On 115 VAC and 230 VAC pumps, electrical con-
nections must be made by a licensed electrician per
requirements of local, state, and national codes
regarding class 1, group D installations. Only rigid
conduit with threaded connections should be used.
Conduit opening in pump must be sealed with
waterproof, fuel-resistant sealant. Failure to comply
with this warning could result in injury from electrical
shock.

Operation
311304H 9
Priming Pump
All pump models should prime within 5 seconds after
pump is turned on up to a height of 36 in. (91 mm).
Pumps installed at height up to 5 ft. (1.52 m) may have
difficulty priming. Follow procedure below to initiate
prime. Pumps installed at suction height above 5 ft.
(1.52 m) will have difficulty in holding prime. It is recom-
mended that check valve (Graco part no. 260217) be
added to the bottom of the suction tube to help maintain
prime.
If prime in not achieved in 30 seconds after turning the
pump on use the following procedure to initiate prime;
1. Remove 90° Union Swivel (15) from ¾” Inlet Nipple
(14).
2. Pour fluid being pumped into pump outlet until com-
pletely filled.
3. Re-assemble Union Swivel (15) back onto nipple
(14). Turn pump on. The pump should gain prime in
under 5 seconds.
4. If pump still does not gain prime check for any major
leaks in the system. If no leaks are found then the
pump is mechanically defective and should be
reported to Graco Product Service for disposition.
It is important that the swivel end of the 90° union
swivel (15) is assembled to the ¾” outlet nipple (14)
for proper sealing (see fig. 6). Also, if the pump has
difficulty priming it is easy to remove the swivel and
pour fluid into the pump outlet cavity when assem-
bled this way.
If prime is lost
1. First make sure there are no fluid leaks from the
pump outlet out to the fuel nozzle. Any leaks after
the outlet will allow air to push the fluid column back
to the tank and prime will be lost.
2. If no leaks are detected on the outlet side of the
pump, remove the pump from the tank and inspect
the suction tube and pump inlet for leaks.
3. If the system is leak free and the suction height
guidelines are followed the pumping system should
not lose prime.
Operation
On/Off switch lever (8d) is located under nozzle holder.
Remove nozzle before turning pump on.
1. Move switch lever (8d) on.
2. Insert nozzle into tank and actuate nozzle lever to
dispense fuel.
3. Immediately after fueling turn switch lever (8d) off.
Maintenance
1. Clean inlet strainer (3b) after every 50 hours of
operation.
2. To remove inlet strainer (3b), remove four screws
(3c) and strainer cover (3a). Remove and clean
strainer.
3. If strainer is excessively dirty, clean tank to protect
pump and the equipment being fueled.
4. After cleaning strainer, replace strainer and cover.
Make sure cover seal (3d/7e) is in place.
All guidelines and procedures are based on pump-
ing diesel fuel. If pumping gasoline priming may be
more difficult due to the lift of gasoline dependent
on Reid's vapor pressure of the gasoline and it's
temperature. The lower the vapor pressure and
temperature, the higher the possible lift.
Before servicing, turn pump off and open the
nozzle to relieve pressure.
CAUTION
Do not operate pump dry. Do not run pump for more
than 5 minutes with nozzle closed. Do not operate
pump for more than 30 minutes continuously in 1 hour.

Troubleshooting
10 311304H
Troubleshooting
Problem Cause Solution
Motor runs but pump will not prime. Motor rotation wrong. (12 VDC and
24 VDC units only.)
Check wiring instructions for possible
problems.
Missing relief valve o-ring seal
(4c/7a).
Remove gear cover (1b) inspect seal
(4c/7a), replace if missing or
damaged.
Sheared drive key (1f/7c). Remove cover (1b) and inspect key
(1f/7c/10b), replace if worn or
sheared.
Dirt under relief poppet (4a) or seal
(4c/7a).
Remove cover (1b) and inspect,
clean or replace if damaged.
Strainer seal (3d/7e) leaking. Inspect and replace if damaged.
Suction height too high to prime. See Priming Pump, page 9.
Worn or damaged gears. Remove cover (1b) and inspect
gears. Replace if worn or damaged.
Fuel level low. Refill tank.
Cover seal (1e7b/10c) damaged. Replace if worn or damaged.
Inlet strainer (3b) clogged. Remove and clean or replace.
Air leak in suction tube. Inspect all joints in suction tube.
Make sure all joints in suction tube
are sealed. and that there are no
cracks from over-tightening
Air lock in system. This may occur if filter or meter or
automatic shut-off nozzle is used. If
this occurs, fill pump and meter with
fuel through top of pump.
Motor does not run at proper speed. Check electric connections. Check
supply voltage for proper voltage
level.
Unit pumps but output flow is low. Clogged inlet strainer (3b). Clean or replace.
Air leak in suction tube. Check to make sure all joints in suc-
tion tube are sealed and that there
are no cracks.
Suction tube too close to tank
bottom.
Suction tube must have a 2 in.
(51 mm) minimum clearance.
Tank empty. Refill tank.
Tank not vented. Tank must be vented to atmosphere.
Worn or damaged gears. Remove cover (1b) and inspect
gears. Replace if worn or damaged.
Damaged motor. Replace motor.
Clogged suction tube, hose, or
nozzle.
Inspect and clean.
