Grande Home WS123 User manual

Installation Instruction
WS123 WR123

1. Tools used: gradienter, screwdriver, silicone gun, silicone, spanner, electric
drill, 9 aiguille, triangle ruler, hammer.

get leg fixed after adjustiing
2. Adjust the shower tray to make sure the upper surface of the track is vertical with the wall. The upper side of the shower tray
shall be level and all the legs shall reach the floor.
get leg fixed after adjusting

3. Install shower bar and aluminum profile.
M4*25 screw

4. Install aluminum profile and shampoo holder.
M4 nut
M4*25 screw

5. Install glass clip
M6X10 screw

6. Install glass hinge for side fixed glasses
M6X10 screw
left side fixed glass right side fixed glass
M6X10 screw

7. Install glass clip for fixed glass to connect bathtub and top cover.
M6X10 screw
left fixed glass right fixed glass
M6X10 screw

8. Install magnetic cylinder l for top glass cover.
left top glass cover right top glass cover
M6X10 screw
M6X10 screw

9.Install magnetic cylinder and door handle for movable glass.
M6X10 double-ended screw
magnetic cylinder

10. Install left glass panel.
ST5*20 tapping screw

11. Install left side fixed glasses.
ST5*20 tapping screw

12. Install behind column.
ST4*20 tapping screw

ST5*20 tapping screw
13. Install right glass panel

14. Install rightside fixed glasses.
ST5*20 tapping screw

ST5*20 tapping screw
ST4*12 tapping screw
15. Install inside part of front column.

16. Install ceiling shower.
ST3.5*35 tapping screw

17. Get water pipe and electric wire connected according to number. Install front part of column.
ST4*12 tapping
screw

18. Install top cover.

19. Install top glass cover.
M6X10 screw
