Grandhall OB2610ALP User manual

NOTETOASSEMBLER/INSTALLER:
Leavethismanualwiththeconsumer.
NOTETOCONSUMER:
Keepthismanualforfuturereference.
RECORDYOURSERIAL# __________________
(seesilverCSAlabelonmainbodyofgrill)
Ÿ
Ÿ
IMPORTANT:
Ÿ
Failuretocomplywiththeseinstructionscould
resultinafireorexplosionthatcouldcause
seriousbodilyinjury,deathorpropertydamage.
Whetherthisgrill wasassembled byyouor
someoneelse,youmustreadthisentiremanual
beforeusing yourgrilltoensurethe grillis
properlyassembled,installedandmaintained.
Use yourgrill atleast3feetaway fromany
wall orsurface. Useyourgrill atleast 3feet
away fromcombustibleobjectsthatcan meltor
catchfiresuchasvinylorwoodsiding,fencesand
overhangsorsourcesofignition including pilot
lightson waterheatersand liveelectricalappli-
ances.
THISGASAPPLIANCEISDESIGNEDFOROUT-
DOORUSEONLY.
Never useyourgasgrillinagarage,porch,
shed,breezewayoranyotherenclosedarea.
Never obstructthe flowofventilation air
around yourgasgrill housing.
Never disconnectthe gasregulatororanygas
fitting while yourgrillislit.Alitgrill canignite
leakinggasand causeafireorexplosionwhich
couldresultinpropertydamage,personalinjury
ordeath.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
WARNING
! !
Ÿ
Manual #P80151123A-Date:2011/01/11
LiquidPropaneGas(LPG)Grill
ModelsOB2610ALP,OB3210ALP&OB3210BLP
NaturalGas(NG)Grill
ModelsOB2610ANG,OB3210ANG&OB3210BNG
Operator'sManual
FREEHELP
FROMTHEGRILLEXPERTS
GrandHallistheexpertonthisproductand
trained tohelpyou with:
visitwww.grandhall.com orcall:
1-877-934-7455
Monday-Friday8:00am-4:30pmCST
AssemblyQuestions
GrillOperation
ReplacementofDamagedorMissingparts
Ÿ
Ÿ
Ÿ
OB3210ALP/NG
(ForBuilt-inModel)
OB3210BLP/NG
(ForCabinetModel)
OB2610ALP/NG
(ForBuilt-inModel)

2
TableofContents
PrimarySafetyWarnings...........................1-3
Pre-AssemblyInstructions...............................3
PartDiagramsandLists.........................4-13
AssemblyInstructions..............................14-25
LPGasTankInstallation............................26
Use&CareInstructions:
•GasSafetyand LeakTests.............27-29
NaturalGasConnection.............................30
•LightingInstructions..................................31
•Troubleshooting..........................................32
• CorrectTransformerand LightUse........33
CleaningandMaintenance...........................34
CookingGuide.........................................A1-A4
FrequentlyAsked Questions.................A5-A6
WarrantyTerms.............................Back Cover
Grand Hallanddesign®,DS Grilland design®,
Crossray™LateralInfraredBurnerTechnology,Com-
mand Flame®, SmoothStart® ElectronicIgnition System,
CeramicSavorPlates®,Sear-zzler®, StainlessClad
Therma-Core®Cooking Grids,Grand Caféand design®,
Grand Markand design®, Grand Chefand design®,
Grand Royaleand design®, GlobeCaféand design®,
UrbanCaféand design®, Smokeless Grill and design®.
TheCrossrayBurnerSystembyGrand Hall iscovered
byAustralianPatentNo.2006100635,Chinese PatentNo.
960361,EuropeanPatentNo.1886606,French Patent
0607231,GermanPatentNo.20 2006 012 212.5,U.K
PatentGB2440714,and U.S.Patent7,475,632.
Registered and unregistered Trademarks heldby
Grand Hall include the following:
PatentsheldbyGrand Hall include the following:
©2008 Grand Hall.All RightsReserved.
WARNING
! !
Thisappliance,when installed,mustbe
electricallygrounded inaccordancewith
localcodesor,inthe absenceoflocal
codes,withthe NationalElectricalCode,
ANSI/NFPA 70, orthe Canadian Electrical
Code,CSA C22.1.
Keep anyelectricalsupplycordand the fuel
supplyhoseawayfromanyheated surface.
Donotstoreoruse gasolineorother
flammableliquidsorvaporsinthevi-
cinityofthisoranyotherappliances.
AnLPcylindernotconnectedforuse
shall notbestoredinthevicinityof
thisoranyotherappliance.
1.
2.
WARNING
! !
DANGER
!!
1.
2.
3.
4.
Ifyousmell gas:
Shutoff gas totheappliance.
Extinguishanyopenflame.
Openlid.
Ifodorcontinues,keepawayfrom
theappliance andimmediatelycall
yourgas supplieroryourfiredepart-
ment.
WARNING
! !
•LPGmodelsmustbeusedwithLiquidPropane
Gasandtheregulatorassemblysupplied.Natu-
ralGas modelsmustbe usedwithNaturalGas
only.Anyattempttoconvert thegrill fromonefuel
typetoanotherisextremelyhazardous andwill
voidthewarranty.
Keepgas regulatorhoseaway fromhotgrill
surfaces and dripping grease.Avoidunneces-
sarytwisting ofhose.Visuallyinspecthose prior
toeach use forcuts,cracks,excessivewearor
otherdamage.Ifthehose appearsdamageddo
notuse thegas grill.Call 1-877-934-7455 fora
certifiedreplacementhose.
CaliforniaProposition 65
Combustionbyproductsproducedwhenusingthis
productcontainchemicalsknowntothe Stateof
Californiatocausecancer,birthdefects,orother
reproductiveharm.
Brass componentsonthegrill, such as hosefit-
tings,propanecylindervalves(soldseparately)and
burnervalvestems,containleadwhichisknownto
theStateofCaliforniatocause cancer,birthdefects,
orotherreproductiveharm.
Neveruse charcoal orlighterfluidinthisgas grill.
Failuretocomplywiththese instructionscould
resultinagrease fireorexplosion thatcouldcause
seriousbodilyinjury,deathorpropertydamage.
TheGreaseTraymustbe visuallyinspectedbefore
each grill use.RemoveanygreaseandwashGrease
Traywithamildsoapandwarmwatersolution.
Failuretocomplywiththeseinstructions could
resultinagrease fireorexplosionthatcould
cause seriousbodilyinjury,deathorproperty
damage.
•
•
•
•
Thisapplianceshallnotbeusedunderover-
head combustibleconstruction.
WARNING
!!
•
•
•

3
Pre-AssemblyInstructionsForYourSafety
Tobeginyour“restaurantquality”grilling,becomefamiliar
withall ofthecooking elementsofyourGrand Hall Grill light-
ingandoperatinginstructions.
MOREFLAVORFULFOODas theintense heatsears
the foodandlocksinthejuiceswhilealso cookingit
fasterwhichusuallymeans moresucculence.
FEWER FLAREUPS as thehigherinfraredheatvapor-
izesmoredrippingswhichalsoaddsnaturalflavoring
toyourfood.
MORE EFFICIENCYAND CONVENIENCE as thehigher
heatmeansshortercooking times,morefuelefficiency
andeasieryearround grilling.
Grill Installation Codes
The installationmustconformwithlocalcodesor,inthe
absence oflocalcodes,witheithertheNationalFuelGas
Code,ANSIZ223.1/NFPA54,NaturalGasandPropance
InstallationCode,CSAB149.1,orPropaneStorageand
HandlingCode,B149.2.
•
•
•
PRE-ASSEMBLY
Readandperformthefollowingpre-assemblyinstruc-
tions:
ToolsRequiredforAssembly:
protectiveworkgloves
protectiveeyewear
Youwill need assistance fromanotherpersonto
handlethegrillheadandotherlarge, heavyparts.
Open Lidofshippingcarton.Removetop sheetof
cardboardandpackingmaterials. Laycardboard
sheet onfloorand use as aworksurface toprotect
floorand grillpartsfromscratches.
You may slice the carton front cornerswithautility
knife to layopenthecartonfrontpanel.Thisallows
youto raise theLidandremovethecomponents
packedinside,making iteasiertolift.
Use theHardware andPart Diagramstoensureall
items areincludedandfreeofdamage.
Do not assembleor operate thegrill ifitappears dam-
aged.If therearedamaged or missingpartswhen
youunpack theshippingboxor youhavequestions
duringtheassemblyprocess call: 1-877-934-7455
M-F8AM-4:30PMCST forassistance.
PhillipsHeadscrewdriver
USPatented No.: 7,475,632
European PatentNo.1886606
AustraliaPatentNo.: 2006100635
GermanyPatent No.: 202006012212.5
FrancePatentNo.: 0607231
UKPatentNo.: GB2440714
China PatentNo.: 960361
CSALabel
locatedonthe
bowlrearpanel
Congratulationsonyourselectionofoneofthe finestout-
doorkitchenappliances available.YourGrill isequippedwith
theuniqueCrossrayInfraredCooking System®byGrand
Hall, whichoffersrestaurantstylegrillingperformance.
Infraredgrillingtechnologycooksthefooddirectly(andnot
theairaround it) which offersmanyadvantages overconven
tionalgrilling systems:
WARNING: Greasecangetveryhot. Alwayshandlethe Grease
Tray withaflameretardantBBQmitt.Beforeremovingthe
Tray,alwaysbe surethatthegrill hasproperlycooled.Be
awarethatthetraydoes containgrease andbe extremely
carefulwhenremoving thetraytopreventspillage.Failureto
followtheseinstructionscouldcause seriousbodilyinjuryor
propertydamage.
Never coverorwraptheCooking Grids,bottom
oftheGrill Bowl,orGrease Traywithaluminum
foil oranyothermaterialthatwill absorbgrease.
! !
WARNING
CAUTION !
ToreducethechanceofFLASHBACKFIREyoumustclean
theBurnerTubes atleastonceamonthinsummerand
fall or whenever spidersareactiveinyour area, and if your
grill has notbeenusedforanextendedperiod oftime.
!

Hardware Parts List for Models OB2610ALP/NG &OB3210ALP/NG
Hardware Diagramfor Models OB2610ALP/NG &OB3210ALP/NG
*OneBattery/AA and FourBattery/AAA includedintheHardwarePack.
PanHeadScrew
3/16"x3/8"
Qty.9(ForOB2610ALP&OB3210ALPModels)
Qty.7(ForOB2610ANG&OB3210ANGModels)
Part#S182G03061
4
PART#
PARTDESCRIPTION
QTY
PURPOSEOFPART
P06006078A HardwarePack 1 Foruseinassemblyof ModelOB3210ALP, OB2610ALP,
OB3210ANG&OB2610ANG
S182G03061 Pan Head Screw3/16"x3/8" 2 InstalltheControlBox
S182G03061 Pan Head Screw3/16"x3/8" 2 InstalltheTransformerBracket
S182G03061 Pan Head Screw3/16"x3/8" 2 InstalltheBracketwithLPRegulator
(ModelOB3210ALP,OB2610ALPOnly)
S182G03061 Pan Head Screw3/16"x3/8" 3 InstalltheTankTraySetontotheBottomPanel
(ModelOB3210ALP,OB2610ALPOnly)
S182G03061 Pan Head Screw3/16"x3/8" 3 InstalltheBracketwithNGRegulator
(ModelOB3210ANG,OB2610ANGOnly)

Hardware Diagramfor Models OB3210ANG
Hardware Parts List for Models OB3210BLP/NG
Hardware Diagramfor Models OB3210BLP/NG
CountersunkFlatHead
Screw3/16"x3/8"
Qty.4
Part#S142G0306A
PanHeadScrew
3/16"x3/8"
Qty.28
Part#S182G03061
Bolt
3/16"x3/8"
Qty.6
Part#S185G03061
Wrench
Qty.1
Part#P05515015L
PanHeadScrew
3/16"x1/2"
Qty.2
Part#S182G03081
PART#
PARTDESCRIPTION
QTY
PURPOSEOFPART
P06006080A
HardwarePack
1
Foruseinassemblyof ModelOB3210BLP/NG
S182G03061
PanHeadScrew3/16"x3/8"
4
InstallCabinetBottomPanel
S182G03061
PanHeadScrew3/16"x3/8"
2
InstallCabinetRearPanel
S185G03061
Bolt 3/16"x3/8"
6
InstallPartitionPaneltoCabinet Panels
S182G03061
PanHeadScrew3/16"x3/8"
3
InstallTankHolder
S182G03061
PanHeadScrew3/16"x3/8"
8
InstallGrill BowltoCabinet
S182G03061
PanHeadScrew3/16"x3/8"
2
InstallControlBox
S182G03061
PanHeadScrew3/16"x3/8"
2
InstallTransformerBracket
S182G03061
PanHeadScrew3/16"x3/8"
3
InstallNGRegulatorAssemblyBracket
S182G03081
PanHeadScrew3/16"x1/2"
2
InstallSide Shelf
S182G03061
PanHeadScrew3/16"x3/8"
4
InstallUpperDoor Bracket
S142G0306A
CountersunkFlat HeadScrew3/16"x3/8"
4
InstallLowerDoor Bracket
P05515015L
Wrench
1
Adjust CartLeg
5

Parts Diagramfor Models OB2610ALP/NG-Grill
6
52
1
2
3
5
6
9
10
11
19
4
7
86
12
14 15
13
17
16
16
18
21
20
22
34
30
31
32
35
38
39
20
21 22
23
23
24
2425
26
27A
27B
28B
28A
29B
29A
33A
33B
36
37
40
41
42
61
43
44
45
46
47
48
49
50
51
53
54
63

PartsList forModelsOB2610ALP/NG-Grill
7
KEY DESCRIPTION OB2610ALP/NGPART# QTY
1LidAssembly P0014633AA 1
2TemperatureGauge P00601381A 1
3 LidHandleBracket,Left P00307058E 1
4 LidHandleBracket,Right P00308058E 1
5 LidHandle P00215037H 1
6ProtectivePad P05518002I 4
7 LidAssemblyBracket, Left P03320007C 1
8 LidAssemblyBracket, Right P03320008C 1
9 LidTrimPlate P0014635QJ 1
10 CookingRack/Secondary P015140222 1
11 CookingGrid P01615038H 4
12 ElectricWireSet P02627013A 1
13 ElectricWireProtector P055330043 1
14 ConnectionHose- Long P03702037D 1
15 ConnectionHose- Short P03702039D 1
16 LidHinge withNut P05501136L 2
17 BowlSidePanel, Left P0076113EC 1
18 BowlSidePanel, Right P0076213EC 1
19 Bowl P0071389EC 1
20 GreaseShield,Upper P06902133C 2
21 GreaseShield,Lower P06902135C 2
22 Infrared BurnerAssembly P02005028B 2
ExtensionFitting withOrifice(LPG) P06539030A 2
ExtensionFitting withOrifice(NG) P06539031A 2
24 ThermocoupleProtector P03343023C 2
25 ThermocoupleBracket P03327082C 1
26 ThermocoupleBracket P03327083C 1
27A Electrode,Front P02618058A 1
27B Electrode,Rear P02618059A 1
28A Thermocouplefor GasValve, Front P05305055B 1
28B Thermocouplefor GasValve, Rear P05305061B 1
29A Thermocouplefor LEDLight,Front P05305066B 1
29B Thermocouplefor LEDLight,Rear P05305065B 1
30 ControlPanelHeatShieldBracket P0300615FD 1
31 ControlPanelHeatShield P0300723AA 1
GasValve/ManifoldAssembly(LPG) Y0060677 1
GasValve/ManifoldAssembly(NG) Y0060678 1
33A LEDLightwithWire-A P02615159A 1
33B LEDLightwithWire-B P02615167A 1
34 BowlFrontTrimPlateAssembly P02913627S 1
35 ControlPanel P02913633X 1
36 ControlKnobSeat P03439014A 2
37 ControlKnob P03436053V 2
38 SwitchforLEDLight P05360001B 1
39 SwitchCover for Light P05382004P 1
40 ElectricIgnitor,2-Port P02502392C 1
41 BowlPanel,Rear/Lower P0073743BC 1
BowlPanel,Rear/Upper(LPG) P0073745BC 1
BowlPanel,Rear/Upper(NG) P0073746BC 1
43 Lamp,12V,10W P05352012B 1
44 LampCover P05352013E 1
45 GreaseTrayHeatShield P06903069C 1
46 GreaseTray P02717813C 1
23
32
42

PartsList forModelsOB2610ALP/NG-Grill
8
KEY DESCRIPTION OB2610ALP/NGPART# QTY
47 GreaseTrayBracket Y0270027 1
48 GreaseTrayHandle P0272012CC 1
49 GreaseTraySlideSet P05516140M 2
50 LampWireSetProtector P055330103 1
51 ControlBox P05545006M 1
52 LED LightController P05357021B 1
53 ControlBoxBracket P03343022C 1
54 Hose,12 FT,NG P03703001A 1
55 RegulatorHoseConnector(LPG) P03901046D 1
56 RegulatorwithHose(LPG) P03603049A 1
57A RegulatorwithHose(NG) Y0080039 1
57B RegulatorBracket(NG) P033110415 1
58 Transformer P05374015B 1
59 TransformerBracket P03328057A 1
60 TankTraySet(LPG) Y0340050 1
61 TrimPanel, Rear P07515025R 1
62 Lighting Stick P05507140M 1
63 LampWireSet P05352015B 1
Operator'sManual P80151123A 1

Parts Diagramfor Models OB3210ALP/NG &OB3210BLP/NG-Grill
9
60B
39
40
41
44
44
46
46
50
52
53
61
62
64
45
58
34D
34C
21
43
63
59
42
9
7
3
2
5
12
13 1415
4
6
8
17
16
60A
65
18
38 37
3634A35
34B 33
323120
57
47
23
22
30C
28A
25 28B
30D
24
2730B
19
30A
29B
28B
26
29A
28A
1
21
6
10
11
48
51
55
54
56
49
20

Parts List for Models OB3210ALP/NG &OB3210BLP/NG-Grill
10
KEY DESCRIPTION OB3210ALP/NGPART#OB3210BLP/NGPART# QTY
1LidAssembly P0014734AA P0014734AA 1
2TemperatureGauge P00601381A P00601381A 1
3LidHandleBracket, Left P00307058E P00307058E 1
4LidHandleBracket, Right P00308058E P00308058E 1
5LidHandle P00215036H P00215036H 1
6ProtectivePad P05518002I P05518002I 4
7LidAssemblyBracket, Left P03320007C P03320007C 1
8LidAssemblyBracket, Right P03320008C P03320008C 1
9LidTrimPlate P0014735QJ P0014735QJ 1
10 CookingRack/Secondary P015160282 P015160282 1
11 CookingGrid P01615038H P01615038H 5
12 ElectricWireSet P02627014A P02627014A 1
13 ElectricWireProtector P055330043 P055330043 1
14 ConnectionHose-Long P03702037D P03702037D 2
15 ConnectionHose-Short P03702038D P03702038D 2
16 LidHingewithNut P05501136L P05501136L 2
17 BowlSide Panel,Left P0076113EC P0076113EC 1
18 BowlSide Panel,Right P0076213EC P0076213EC 1
19 Bowl P0071388EC P0071388EC 1
20 GreaseShield, Upper P06902131C P06902131C 2
21 GreaseShield, Lower P06902132C P06902132C 2
22 InfraredBurnerAssembly P02005027B P02005027B 4
Extension Fitting withOrifice (LPG) P06539032A P06539032A 4
Extension Fitting withOrifice (NG) P06539033A P06539033A 4
24 CrossLightingChannel P02212377A P02212377A 2
25 ThermocoupleProtector P03343017C P03343017C 4
26 ThermocoupleBracket P03327082C P03327082C 2
27 ThermocoupleBracket P03327083C P03327083C 2
28A Electrode,Front P02618056A P02618056A 2
28B Electrode,Rear P02618057A P02618057A 2
29A ThermocoupleforGasValve P05305054B P05305054B 2
29B ThermocoupleforGasValve P05305055B P05305055B 2
30A ThermocoupleforLED Light, LeftFront P05305056B P05305056B 1
30B ThermocoupleforLED Light, LeftRear P05305057B P05305057B 1
30C ThermocoupleforLED Light P05305058B P05305058B 1
30D ThermocoupleforLED Light P05305059B P05305059B 1
31 ControlPanelHeat ShieldBracket P0300616FD P0300616FD 1
32 ControlPanelHeat Shield P06904056C P06904056C 1
GasValve/ManifoldAssembly(LPG) Y0060679 Y0060679 1
GasValve/ManifoldAssembly(NG) Y0060680 Y0060680 1
34A LEDLight withWire- A P02615155A P02615155A 1
34B LEDLight withWire- B P02615156A P02615156A 1
34C LEDLight withWire- C P02615157A P02615157A 1
34D LEDLight withWire- D P02615158A P02615158A 1
35 BowlFrontTrimPlateAssembly P02915341S P02915341S 1
36 ControlPanel P02915553X P02915553X 1
37 ControlKnob Seat P03439014A P03439014A 4
38 ControlKnob P03436053V P03436053V 4
39 SwitchforLEDLight P05360001B P05360001B 1
40 SwitchCoverforLight P05382004P P05382004P 1
41 ElectricIgnitor, 4-Port P02502384C P02502384C 1
42 BowlPanel, Rear/Lower P0073740BC P0073740BC 1
BowlPanel, Rear/Upper(LPG) P0073741BC P0073741BC 1
BowlPanel, Rear/Upper(NG) P0073742BC P0073742BC 1
44 Lamp,12V,10W P05352012B P05352012B 2
45 LampWireSet P05352014B P05352014B 1
46 LampCover P05352013E P05352013E 2
23
33
43

PartsList forModelsOB3210ALP/NG&OB3210BLP/NG-Grill
Important: UseonlyGrand Hall replacementparts.TheuseofanypartthatisnotaGrand Hall replacementpartcanbe
dangerousand will alsovoid yourproductwarranty.Keep thisOperator'sManualforconvenientreferralandforpart
replacement.
Fortherepairorreplacementpartsyouneed:
Call 1-877-934-7455 M-F8:00AM-4:30PMCST
Toobtain thecorrectreplacementpartsforyourgasgrill,pleaserefertothepartnumbersin thispartslist. The
following informationisrequiredtoensureyoureceivethecorrectparts:
1.Modeland SerialNumber(see CSA labelongrill)
2.PartNumber
3.PartDescription
4.Quantityofpartsneeded
11
KEY DESCRIPTION OB3210ALP/NGPART# OB3210BLP/NGPART# QTY
47 GreaseTrayHeatShield P06903069C P06903069C 1
48 GreaseTray P02717793C P02717793C 1
49 GreaseTrayBracket Y0270026 Y0270026 1
50 GreaseTrayHandle P0272011CC P0272011CC 1
51 GreaseTraySlide Set P05516140M P05516140M 2
52 LampWireSet Protector P055330103 P055330103 2
53 LampWireSet Protector Bracket P03328079C P03328079C 1
54 ControlBox P05545006M P05545006M 1
55 LEDLightController P05357022B P05357022B 1
56 ControlBoxBracket P03343022C P03343022C 1
57 Hose, 12 FT,NG P03703001A P03703001A 1
58 RegulatorHoseConnector(LPG) P03901046D N/A 1
59 RegulatorwithHoseAssembly(LPG) P03603049A P03603049A 1
60A RegulatorwithHose(NG) Y0080039 Y0080039 1
60B RegulatorBracket(NG) P033110415 P033110415 1
61 Transformer P05374015B P05374015B 1
62 Transformer Bracket P03328057A P03328057A 1
63 TankTraySet (LPG) Y0340050 Y0340050 1
64 TrimPanel,Rear P07515023R P07515023R 1
65 LightingStick P05507140M P05507140M 1
Operator'sManual P80151123A P80151123A 1

Parts Diagramfor Models OB3210BLP/NG-Cabinet
12
1A
2A
3A
12
12
11
98A
9
7A
6
4A
5
14A
13A
1B
2B
4B
13B
14B 6
10 3B
15 12
12
8B
5
7B
9
17
19
20
21
21

13
Important: Use onlyGrand Hall replacementparts.Theuse ofanypart thatisnotaGrand Hall replace-
mentpart canbedangerousand will alsovoidyourproductwarranty.KeepthisOperator'sManualfor
convenientreferraland forpart replacement.
To obtainthecorrectreplacementpartsforyourgas grill,please refertothepart numbersinthisparts
list. Thefollowing information isrequiredtoensureyou receivethecorrectparts:
1.Modeland SerialNumber(see CSA labelon grill)
2.Part Number
3.Part Description
4.Quantityofpartsneeded
Fortherepairorreplacementpartsyouneed:
Call 1-877-934-7455M-F8:00AM-4:30PMCST
Parts List for Models OB3210BLP/NG-Cabinet
KEY DESCRIPTION OB3210BLP/NGPART# QTY
1A Side Shelf, Right P01107048B 1
1B Side Shelf, Left P01106052B 1
2A
Side ShelfTrimPlate, Right
P07503028A
1
2B Side ShelfTrimPlate, Left P07503023A 1
3A RightCabinetPanel,Left P07617050B 1
3B LeftCabinetPanel,Right P07618050B 1
4A RightCabinetPanel,Right P07618051B 1
4B LeftCabinetPanel,Left P07617051B 1
5Folding Bracket A P03303147D 2
6Folding Bracket B P03303148D 2
7A BottomPanel, Right P01001093D 1
7B BottomPanel, Left P01001095D 1
8A RightCabinetPanel,Rear P07702123B 1
8B LeftCabinetPanel,Rear P07702125B 1
9PartitionPanel P01001096D 3
10 DoorAssembly,Left P04302058A 1
11 DoorAssembly,Right P04203059A 1
12 DoorMagnet P05523056L 4
13A DoorBracket,Right/Upper P03313045D 1
13B DoorBracket,Left/Upper P03313046D 1
14A DoorBracket,Right/Lower P03313047D 1
14B DoorBracket,Left/Lower P03313048D 1
15 LevelAdjuster P05322041B 8
17 Outer Partition Panel P01004058D 1
19 BowlPanel,Rear/Lower P0075812BC 1
20 EndCap, Leg P06802008G 8
21 DoorHinge Y0550002 2
Operator'sManual P80151123A 1

14
AssemblyInstructionsforOB3210BLP/NG
CAUTION :Whileitispossibleforone person toassemblethisgrill,obtainassistancefromanotherperson
whenhandlingsomeofthe larger,heavierpieces.
Unfold Left and RightCabinet
Opencarton and removeallpackingmaterials.
Unfoldtheleft cabinetasshown.
Repeatthestepforthe rightcabinet.
1
2Install Left &RightBottomPanel
Install Left BottomPanelontoleft cabinetusing 2PanHeadScrews3/16"X3/8"and tightensecurely.
(as shownbelow)
Repeatthestepforrightcabinet.
3
PanHeadScrew
3/16"x3/8"
Qty.4
Part#S182G03061
PanHeadScrew
3/16"x3/8"
Qty.2
Part#S182G03061
Install Left &RightRear Panel
Place the LeftRearPaneloverthe installed boltoftheleftcabinet.(seeFig.1)
SecuretheLeftRearPaneltoleftcabinetuse1PanHead Screw3/16"x3/8".(seeFig.2)
Repeatthestepforrightcabinet.
Fig.1 Fig.2
PULL
PULL
LeftBottomPanel
LeftRearPanel

4
15
Install Partition Panel
PlacePartition Panelovertheboltsofleft cabinetand rightcabinet. (theboltsarealreadyinstalled)
(see Fig.3&Fig.4)
Fig.3
Fig.4
Partition Panel
Bolt
3/16"x3/8"
Qty.6
Part#S185G03061
Install Outer Partition Panel
Install 6Bolts3/16"x3/8"toleft and rightcabinet, thenplacetheOuterPartition Panel
overthebolts.(as shownbelow)
5
Left
Right
OuterPartition Panel

7-1 Install Grill Bowl and TankHolder (TankHolder isonlyforLPModel)
6Makesureall cooking componentsareremovedfromtheGrill Bowl.Lift and position theGrill Bowl
overtheSupport Brackets.
Note: MakesuretheControlBoxwiregoes through the"U"shapedholeon rightcabinet.(as shown)
Alignthe holesontheGrillBowlwiththe holesontheSupportBracketsusing8Pan HeadScrews
3/16"x3/8"andtighten securely.
Install Tank HolderontotheLeft BottomPanelusing 3PanHeadScrews3/16"x3/8"and tighten
securely.(onlyforLPmodel)
PanHeadScrew
3/16"x3/8"
Qty.8
Part#S182G03061
16
PanHeadScrew
3/16"x3/8"
Qty.3
Part#S182G03061
(onlyforLPmodel)
TankHolder ControlBox
SupportBracketsx4
(onlyforLPModel)
7-1 Install Transformer BracketontotheRightCabinetPartition Panel(refer tostep8) 7Install TransformerBracketontothePartition Panelusing 2PanHeadScrews3/16"X3/8"and tightensecurely
as shownbelow.
TransformerBracket
Partition Panel(forrightcabinet)
PanHeadScrew
3/16"x3/8"
Qty.2
Part#S182G03061
"U"shaped hole
Grill Bowl
Grill Lid
Partition Panel

Install Control Box,Partition Panel, Tansformer and Batteries
Install ControlBox: Align theholes intheControlBoxbracketwiththeholes intherightcabinetusing 2PanHead
Screws3/16"x3/8"and tightensecurely. (see Fig. 1)
Install Partition Panel: PlacePartition PanelwithTransformerBracketovertheboltsoftheright
cabinet.(similartostep4)
Install Transformer: Install TransformerontotheTransformerBracketbyputting thefourpre-assembledscrews
on theTransformerintothefourholes on theTransformerBracket. Press theTransformerdownwarduntil
thescrewsrestinplace.(see Fig.2)
InstallTransformer-PlugintoTransformer-Socketandtighten securely.(SeeFig.3)
PlugtheTransformerintothe powersource.Pushthe LampSwitchontheControlPaneltoturnontheGrill
lamps.
InstallBatteries: Place1AAbatteryintothe slotofthe ControlPaneland4AAAbatteriesintotheslotof
the ControlBoxasshowbelow.Positionthecaps ontotheslots,andtighten securely.
Note:The positive poleoftheAAbatterymustfacetowardsthecap.FortheAAAbatteries,2batteriesmust
have thepositivepolefacingtowardsthecap and2batteriesmusthavethe negativepolesfacingaway from
the caps.)
8
17
Note: Press theSwitch Button toturnon theLED Light
Controllerbeforeusing thegrill.Press itagaintoturn
off theLED LightControllertosavebatterypower
whenthegrill isnotinuse.
Switch Button OFF Switch Button ON
CapofLED
Lightcontroller
PanHeadScrew
3/16"x3/8"
Qty.2
Part#S182G03061
AAA Batteries
Slot
ControlBox
Fig.2
Transformer-plug
Transformer-socket
CapofLED
Lightcontroller
Fig.3
Fig.1
-+
-
AA Battery
LampSwitch
ControlPanel
+
IgnitorSlot
IgnitorCap
Transformer
AC-plug

18
9B
RemoveRegulatorHose Connector
Install NGRegulator(onlyforOB2610ANG, OB3210ANGand OB3210BNG)
InstallNGRegulatorBracketontoleftcabinetusing3Pan HeadScrews3/16"x3/8".
Connectthe NGConnectingHosetotheGasmanifold.(seeFig.3)
PanHeadScrew
3/16"x3/8"
Qty.3
Part#S182G03061
RemovetheRegulatorHose Connectorfromthe
LPRegulatorHose.(see Fig.1)
ConnecttheLPRegulatorHose totheGas
manifold.(seeFig.2)
Remove Hose Connectorand Install LPRegulator(onlyforOB3210BLPModel)
9A
Makesurethe slotis
aligned withthe screws.
PanHeadScrew
3/16"x1/2"
Qty.2
Part#S182G03081
Install CabinetRight&Left SideShelf
10 Place the RightSideShelf overtheboltsonthe CabinetRearPanel. Thenslide theRightSide Shelffrom
the backtothe front.
SecuretheRightSide ShelftoGrillBowlRightPanelusing 1PanHead Screw3/16"x1/2".
RepeatStepsfortheLeftSide Shelf. 2
Fig.1 Hose
HoseConnector
LPRegulator
LP
Regulator
GasManifold
Regulator
Hose
Hose
Hole
NG
Regulator
NGRegulator
Bracket
GasManifold
Connecting
Hose
Hose
Hole
Fig.2
Fig.3
1

19
Install Upper &Lower DoorBracketand Doors
11 Install 2UpperDoorBracketsontoleft and rightcabinetusing 4PanHeadScrews3/16"x3/8"and tighten
securely.(seeFig.1)
Install 2LowerDoorBracketsontoleft and rightcabinetusing 4Countersunk FlatHeadScrews3/16"x3/8"
and tightensecurely.(see Fig.2)
Note:TheUpper&LowerDoorBracketfortheleft sideismarkedwithan"L".TheUpper&LowerDoorBracketfor
therightsideismarkedwithan"R".
IftheCabinetSetsarenotlevelwitheach other, use thewrench toadjusttheleveladjusterson the
bottomofthecabinetsidepanels.(see Fig.3)
•Turntheadjustersclockwise toraise theheightoftheGrill.
•Turntheadjusterscounterclockwise tolowertheheightoftheGrill.
FOR YOUR SAFETY: DO NOTTILT yourGrill atanytime.
Match theDoorUpperholetotheUpperDoorBracketshaft. (see Fig.4)Slideorpress the
spring on thebottomofthedoortoposition theDoorintotheLowerBracket.
PanHeadScrew
3/16"x3/8"
Qty.4
Part#S182G03061
CountersunkFlatHead
Screw3/16"x3/8"
Qty.4
Part#S142G03061
Wrench
Qty.1
Part#P05515015L
Fig.4
Fig.1
Fig.2 Fig.3
Lower
Raise
DoorUpperHole
UpperDoor
Bracketshaft
LowerDoorBracket

Replace Rear Lower Bowl Panel(onlyforOB3210B Model)
12A Unscrewsand removetheRearLowerBowl Panel and theRearTrimPanel fromtheback oftheGrill Bowl.
(see Fig.1)
Install thenewRearLowerBowlPanelontotheback oftheGrill Bowlusing thesamescrewsandtightensecurely.
(see Fig.2) (do not reinstall theRearTrimpanel)
Fig.1
Fig.2
RearTrimPanel
RearLowerBowlPanel RearLowerBowlPanel
Pull outtheGrease TrayBracket. PlacetheGrease TrayintotheGrease TrayBracket. (as showbelow)
PushtheGrease TrayBracketback intoposition.
12B Grease Tray
Grease TrayBracket
GreaseTray
20
