Grandstream Networks HandyTone-486 User manual

User Manual
HandyTone-486
Analog Telephone Adaptor
User Manual 1.0 Version
Grandstream Networks, Inc.
www.grandstream.com

HandyTone-486 User Manual Grandstream Networks, Inc.
2
Table of Contents
1WELCOME......................................................................................................... 3
2INSTALLATION ................................................................................................. 4
3WHAT IS INCLUDED IN THE PACKAGE ......................................................... 5
3.1 SAFETY COMPLIANCES .................................................................................... 5
4PRODUCT OVERVIEW...................................................................................... 6
4.1 KEY FEATURES ............................................................................................... 6
4.2 HARDWARE SPECIFICATION ............................................................................. 7
5BASIC OPERATIONS........................................................................................ 8
5.1 GET FAMILIAR WITH KEY PAD AND VOICE PROMPT............................................. 8
5.2 MAKE PHONE CALLS ....................................................................................... 9
5.2.1 Calling phone or extension numbers ...................................................... 9
5.2.2 Direct IP calls.......................................................................................... 9
5.3 CALL FEATURES............................................................................................ 11
5.3.1 Call Features Table .............................................................................. 11
5.3.2 PSTN Pass Through............................................................................. 12
5.4 LED LIGHT PATTERN INDICATION ................................................................... 12
6CONFIGURATION GUIDE............................................................................... 13
6.1 CONFIGURING HANDYTONE 486 WAN IP THROUGH VOICE PROMPT ................ 13
6.1.1 DHCP Mode ......................................................................................... 13
6.1.2 STATIC IP Mode................................................................................... 13
6.2 CONFIGURING HANDYTONE 486 WITH WEB BROWSER..................................... 13
6.2.1 Access the Web Configuration Menu.................................................... 13
6.2.2 Configuration Menu .............................................................................. 14
6.2.3 Saving the Configuration Changes....................................................... 24
6.2.4 Rebooting the HandyTone 486 from remotely...................................... 24
6.3 CONFIGURATION THROUGH A CENTRAL SERVER .............................................. 24
7SOFTWARE UPGRADE.................................................................................. 26
7.1 UPGRADE WITH TFTP ................................................................................... 26

HandyTone-486 User Manual Grandstream Networks, Inc.
3
1 Welcome
Congratulations on becoming an owner of HandyTone-486. You made an excellent choice
and we hope you will enjoy all its capabilities.
Grandstream's award-wining HandyTone-486 is an all-in-one VoIP integrated access device
that features superb audio quality, rich functionalities, high level of integration, compactness
and ultra-affordability. The HandyTone-486 is fully compatible with SIP industry standard and
can interoperate with many other SIP compliant devices and software on the market.
Grandstream HandyTone-486 has been awarded the Best of Show product in 2004 Internet
Telephony Conference and Expo.

HandyTone-486 User Manual Grandstream Networks, Inc.
4
2 Installation
HandyTone-486 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed
to be a total solution for networks providing VoIP services.
The HandyTone-486 VoIP functionalities are available via a regular analog telephone.
The following photo illustrates the appearance of a HandyTone-486.
Top View Side Views
Interconnection Diagram of the HandyTone-486:
Fax
Cordless Phone
Analog Phone
Internet ADSL/Cable
Modem Ethernet
PSTN
PC PCPC
LAN
WAN
LINE PHONE
BUTTON
RED LED
GREEN LED
RJ45
10M Ethernet
LAN - WAN
RJ11
Telephone
(Phone)
+5V/1200mA
RJ11
Phone Line
(Line)

HandyTone-486 User Manual Grandstream Networks, Inc.
5
3 What is Included in the Package
The HandyTone-486 package contains:
1) One HandyTone-486
2) One universal power adaptor
3) One Ethernet cable
3.1 Safety Compliances
The HandyTone-486 is compliant with various safety standards including FCC/CE and C-tick.
Its power adaptor is compliant with UL standard. The HandyTone-486 should only operate
with the universal power adaptor provided in the package.
Warning: Please do not attempt to use a different power adaptor. Using other power
adaptor may damage the HandyTone-486 and will void the manufacturer warranty.
Caution: Changes or modifications to this product not expressly approved by
Grandstream, or operation of this product in any way other than as detailed by this
User Manual, could void your manufacturer warranty.
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose without the
express written permission of Grandstream Networks, Inc..

HandyTone-486 User Manual Grandstream Networks, Inc.
6
4 Product Overview
4.1 Key Features
•Supports SIP 2.0(RFC 3261), TCP/UDP/IP, RTP/RTCP, HTTP, ICMP, ARP/RARP,
DNS, DHCP (both client and server), NTP, PPPoE, STUN, TFTP, etc.
•Built-in router, NAT, Gateway and DMZ port forwarding
•Powerful digital signal processing (DSP) to ensure superb audio quality; advanced
adaptive jitter control and packet loss concealment technology
•Support various vocoders including G.711 (alaw and u-law), G.723.1 (5.3K/6.3K),
G.726 (40K/32K/24K/16K), as well as G.728, G.729A/B, and iLBC.
•Support Caller ID/Name display or block, Hold, Call Waiting/Flash, Call Transfer, Call
Forward, in-band and out-of-band DTMF, Dial Plans, etc.
•Support fax pass through
•Support Silence Suppression, VAD (Voice Activity Detection), CNG (Comfort Noise
Generation), Line Echo Cancellation (G.168), and AGC (Automatic Gain Control)
•Support standard encryption and authentication (DIGEST using MD5 and MD5-sess)
•Support for Layer 2 (802.1Q VLAN, 802.1p) and Layer 3 QoS (ToS, DiffServ, MPLS)
•Support automated NAT traversal without manual manipulation of firewall/NAT
•Support device configuration via built-in IVR, Web browser or central configuration file
through TFTP
•Support firmware upgrade via TFTP
•Ultra compact (wallet size) and lightweight design, great companion for travelers
•Compact, lightweight Universal Power adapter.

HandyTone-486 User Manual Grandstream Networks, Inc.
7
4.2 Hardware Specification
The table below describes the difference among these models.
Model HandyTone-486
LAN interface 1xRJ45 10Base-T
WAN interface 1xRJ45 10Base-T
FXS telephone port 1xFXS
PSTN port 1x life line port
Button 1
LED Green and red color
Universal Switching
Power Adaptor
Input: 100-240VAC 50-60 Hz
Output: +5VDC, 1200mA,
UL certified
Dimension 70mm (W)
130mm (D)
27mm (H)
Weight 0.6lbs (0.3kg)
Temperature 40 - 130oF
5 – 45oC
Humidity 10% - 90%
(non-condensing)
Compliance

HandyTone-486 User Manual Grandstream Networks, Inc.
8
5 Basic Operations
5.1 Get Familiar with Key Pad and Voice Prompt
HandyTone-486 has stored a voice prompt menu for quick browsing and simple
configuration.
To enter this voice prompt menu, simply press the button or *** from the analog phone.
Menu Voice Prompt User’s Options
Main Menu “Enter a Main Option” Enter ‘*’ to menu_01
Enter 00-06, 99 menu option
01 “DHCP Mode”,
“Static IP Mode”
Enter ‘9’ to toggle the selection
02 “IP Address “ + IP address It will prompt you with the current WAN IP
address.
Enter 12 digit new IP address if in Static IP
Mode
03 “Subnet “ + IP address Same as menu 02
04 “Gateway “ + IP address Same as menu 02
05 “DNS Server “ + IP address Same as menu 02
06 “TFTP Server “ + IP address Same as menu 02
47 “Direct IP Calling” When entered, you will prompt a dialtone,
then enter 12 digit IP address
This menu can be also entered by
pressing the button again
86 “Voice Messages Pending”
“No Voice Messages”
Enter 9 to dial pre-configured phone
number to retrieve VM
99 “RESET” Enter ‘9’ to confirm the RESET
Enter MAC address to restore factory
default setting
“Invalid Entry” Automatically return to Main Menu
Notes:
•Once the button is pressed, it enters the voice prompt main menu. If the button is
pressed again, while it is already in the voice prompt menu state, it jumps to “Direct IP
Calling” option and dial tone plays in this state
•‘*’ functions similar to ‘↓’ key of BT-100 phone to select the next menu option
•‘#’ returns back to main MENU
•‘9’ is similar to ENTER key in many cases to confirm an option
•All entered digit sequences have known lengths - 2 digits for menu option and 12 digits
for IP address. Once all digits are accumulated, it automatically processes them.
•Key entry cannot be deleted but the phone may prompt error once it is detected

HandyTone-486 User Manual Grandstream Networks, Inc.
9
5.2 Make Phone Calls
5.2.1 Calling phone or extension numbers
There are currently two methods to make a extension number call:
a) Dial the numbers number directly and wait for 4 (default) seconds.
b) Dial the numbers directly, and press # (assuming that “use #” as dial key is selected
in web configuration).
Other functions available during the call are call-waiting/flash, call-transfer, and call-
forwarding.
5.2.2 Direct IP calls
Direct IP calling allows 2 phones, that is, a HandyTone with a analog phone and another
VoIP Device, to talk to each other in an ad hoc fashion without a SIP proxy. VoIP calls can be
made between two phones if:
•both HandyTone ATA and other VoIP Device(i.e., another HandyTone ATA or other
HandyTone ATA) have public IP addresses, or
•both HandyTone ATA and other VoIP Device(i.e., another HandyTone ATA or other
HandyTone ATA) are on the same LAN using private or public IP addresses, or
•both HandyTone ATA and other VoIP Device(i.e., another HandyTone ATA or other
HandyTone ATA) can be connected through a router using public or private IP
addresses.
To make a direct IP calling, first pick up the analog phone or turn on the speakerphone on the
analog phone, then follow Section 4.1 with voice prompt 47, followed by the 12-digit target IP
address. If there is a user part, again follow Section 4.1 with voice prompt 47, and then the
encoded user part, followed by *3 (encoding for “@”) and then followed by the 12-digit target
IP address. Destination ports can also be specified using *4 (encoding for “:”) followed by the
encoded port number.

HandyTone-486 User Manual Grandstream Networks, Inc.
10
The follow is a table of the encoding scheme for the most commonly used characters:
F
00 0
01 1
02 2
03 3
04 4
05 5
06 6
07 7
08 8
09 9
*0 . (dot character)
*1 _ (underscore character)
*2 - (hyphen character)
*3 @
*4 : (column character)
21 A
22 B
23 C
31 D
32 E
33 F
41 G
42 H
43 I
51 J
52 K
53 L
61 M
62 N
63 O
71 P
72 Q
73 R
74 S
81 T
82 U
83 V
91 W
92 X
93 Y
94 Z
