Granit 580580479 User manual

Operating Instructions
Digital pasture fence voltage tester
580580479
These operating instructions must be read thoroughly before use and followed. These
Operating Instructions must be retained for future reference.
Translation of the original operating instructions

Operating Instructions for Digital Fence Tester
580580479
2
Table of contents
1 About these operating instructions and symbol descriptions ...................................... 3
2 Safety and accident prevention rules ..................................................................... 3
2.1 General safety instructions ............................................................................. 3
2.2 Specific safety instructions ............................................................................. 4
2.3 Personnel qualifications.................................................................................. 5
3 Intended use ...................................................................................................... 5
4 Technical data..................................................................................................... 5
5 Operation ........................................................................................................... 6
5.1 Initial start up............................................................................................... 6
5.2 Voltage test .................................................................................................. 7
6 Maintenance and care .......................................................................................... 7
7 Storage and transport .......................................................................................... 8
8 Disposal ............................................................................................................. 8
9 EG Declaration of Conformity ................................................................................ 9
10 Warranty........................................................................................................10
11 Addresses ......................................................................................................10
12 Legal Notice....................................................................................................10

Operating Instructions for Digital Fence Tester
580580479
3
1About these operating instructions and symbol
descriptions
The information in these Operating Instructions is labelled as follows:
Incorrect operation can lead to serious injury or death.
Incorrect operation or negligence may result in personal injury or
damage to property.
Instructions and tips for operation.
Numbers in illustrations (1, 2, 3 ...) refer to the corresponding numbers in brackets
(1), (2), (3) ... in the text next to the item numbers in the tables.
Instructions for which the order must be followed are numbered (1, 2, 3, ...).
Lists are marked with bullet points (●, ●, ...).
2Safety and accident prevention rules
2.1 General safety instructions
These operating instructions were prepared so that you can work safely with the
equipment.
Read these Operating Instructions thoroughly before use. Pay particular attention to the
safety instructions.
These Operating Instructions are intended for people with basic technical understanding
of the use of equipment such as that described here.
If you have no experience with such equipment, you should first get assistance from
experienced persons.
Keep all supplied documents with the equipment for future reference if required. Keep the
purchase receipt for any warranty claims.
If you lend or sell the equipment, supply all documentation with it.
Observe the operating and maintenance instructions found in this manual.
Defective equipment must be repaired promptly in order to minimize the extent of damage
and avoid endangering the safety of the equipment.
The system components may only be used and operated under the conditions laid down
in these operating instructions.
Retrofits, changes or modifications to the equipment are strictly prohibited. They require
consultation with and written approval by the manufacturer.

Operating Instructions for Digital Fence Tester
580580479
4
If during operation (residual) hazards and risks become apparent which are not described
in this manual, the operator is obliged to report this to the manufacturer.
2.2 Specific safety instructions
The equipment may only be used by trained persons. Observe the regulations of the
employer’s liability insurance association for health and safety at work for all activities.
To prevent electric shock, the precautionary measures must be observed when working
with voltages higher than 35 V DC or 16 V rms. AC. According to DIN VDE, these values
represent the limit of the voltages that can still be touched. The values are valid for
agricultural applications.
The equipment may only be touched at the designated handling areas, and the display
elements may not be covered.
Maintenance work that is not described in this documentation may only be carried out by
trained service technicians.
If the equipment is modified or altered, its operational safety is no longer guaranteed.
The earth spike must not be used with the battery compartment open.
When inserting the earth spike, do not touch any live parts.
Check the batteries before use and replace them if necessary.
If batteries are leaking, stop using the equipment until it has been checked by our
customer service.
The battery liquid (electrolyte) is strongly alkaline and electrically conductive. Risk of
burns! If battery fluid comes into contact with skin or clothing, the affected areas must be
rinsed thoroughly with plenty of water immediately. If battery fluid gets into the eyes,
rinse them immediately with plenty of water and consult a doctor.
Do not operate the equipment in rooms where there is a risk of explosion.
Do not operate the equipment in an aggressive atmosphere.
Protect the equipment from permanent direct sunlight.
The equipment is used only to indicate the voltage range and is not suitable for
measurement purposes.
Test the functionality of the voltage tester immediately before and after each use. The
voltage tester must not be used if the function of one or more displays on the voltage
tester fails or if the functionality of the equipment cannot be clearly determined.
Failure to observe the following safety instructions can lead to serious
accidents with severe material damage and personal injury!

Operating Instructions for Digital Fence Tester
580580479
5
2.3 Personnel qualifications
Persons using this equipment must be familiar with the 5 safety rules (1 Disconnect, 2 Secure
against reconnection, 3 Check that no voltage is present, 4 Earth and short-circuit, 5 Cover
live adjacent parts) and use the voltage tester in accordance with safe working practices.
Furthermore, be aware of the hazards that may arise when working with electrical equipment
in a humid environment. Take preventive measures to protect against direct contact with live
parts.
3Intended use
The equipment may only be used for DC voltage measurement on pasture fences in the
measuring range from 1,000 to 12,000 V.
Do not use the equipment in potentially explosive atmospheres, in wet conditions or in high
humidity. Unauthorised modifications to the equipment are prohibited.
4Technical data
Parameters
Value
Voltage display
1.0 = 1,000V to 12.0 = 12,000V AC/DC
Voltage test
Automatic
Display tolerance
-30 % to 0 % of the displayed value
Display delay
< 0.1 s LED
Frequency range
50/60 Hz
Power consumption
0.1 W
Current consumption
0.01 A
Maximum permissible measuring time for voltages
30 s
Rest period between voltage measurements
10 minutes
LED display off
> 8 V DC
Operating temperature
-10 °C to +55 °C
Rel. air humidity
Max. 85 %
Overvoltage category
CAT III - 600 V
Protection class
IPX2
Dimensions (length x width x height)
Ø 175 x 25 70 mm
Button cell
1 x 9.0 V AAA
Weight
240 g
Safety regulations
EN 55032:2015
EN 55035:2017
EN 61000-3-2:2014
EN 61000-3-3:2013

Operating Instructions for Digital Fence Tester
580580479
6
5Operation
An electric shock can lead to death or serious injury! The
equipment may only be used by instructed persons who observe
all safety instructions.
Electric shock due to insufficient insulation. Always check the
equipment for damage and proper functioning before each use. If
you discover any damage, stop using the equipment.
Do not use the equipment if the equipment or your hands are
damp or wet!
Do not use the equipment if the battery compartment or housing
is open.
Electric shock by touching live parts. Do not touch live parts.
Protect adjacent live parts by covering them or switching them
off.
Before each measurement, test the function of the equipment at
a known voltage source.
5.1 Initial start up
Remove the battery cover.
Insert the battery (1 x 9 V AAA battery) into the battery compartment with the correct
polarity.
Close the battery compartment with the cover removed.
Before each voltage test, check that the equipment functions reliably with a known
voltage source.

Operating Instructions for Digital Fence Tester
580580479
7
5.2 Voltage test
1. Insert the earth spike (4) into the ground.
2. Hold the test probe (1) against the fence wire
3. Press the push button (3) permanently to perform a measurement.
4. Read the measured value on the display (2). e.g. 6.0 = 6,000 V
When taking the measurement, only touch the push-button of the
equipment and never touch the ground spike, the supply cable,
the ground or any part of the electric fence.
Otherwise there is a risk of electrocution with life-threatening
consequences.
A doctor must always be consulted after electrocution.
People with active implants, e.g. pacemakers, etc. should not
carry out the voltage measurement.
Discuss the procedure with your doctor before carrying it out.
If the safety of the user cannot be guaranteed, the equipment
must be switched off and secured against unintentional use.
The fence voltage should be at least 2.0 = 2,000V in order to
ensure the safety of the fence.
For measured values above 12,000 V (12.0)
the display shows “HI”!
6Maintenance and care
The measuring instrument does not require any special maintenance when operated as
intended.
If a malfunction occurs, stop the current measurement immediately and have the equipment
checked by an expert before it is used again.
•Maintenance and repair work may be performed only by qualified personnel.
•Use only original spare and wear parts
•Maintenance, cleaning and troubleshooting work is only permitted when the batteries are
removed and the unit is not live.

Operating Instructions for Digital Fence Tester
580580479
8
•Fasteners must be regularly checked for tightness, and tightened as necessary.
•Clean the equipment with a damp, soft, lint-free cloth. Make sure that no moisture
penetrates into the housing. Do not use any sprays, solvents, cleaning agents containing
alcohol or abrasive cleaners, but only clear water to moisten the cloth.
Failure to comply with the maintenance instructions may result in
serious personal injury and impaired use.
The use of abrasive cleaning agents or high-pressure cleaners and
water jets may damage the surface of the cabinet and display.
7Storage and transport
Always check the condition of the equipment before storing it and carry out maintenance
work before shutting it down so that your testing equipment is ready for use again quickly.
8Disposal
The separate, environmentally friendly disposal of materials encourages recycling of
materials. Therefore, after expiry of the normal service life, the equipment itself and all related
components, including the packaging, should be disposed of at a recyclables collection point.
Packaging, equipment and accessories are made of recyclable materials and should be
disposed of accordingly.
If the unit is no longer serviceable, make sure it is unusable before disposal.
If you do not have the necessary technical knowledge, hire a
specialist to dismantle and dispose of the unit.
VERLETZUNGSGEFAHR!
!!! Always observe local disposal regulations !!!

Operating Instructions for Digital Fence Tester
580580479
9
9EG Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
hereby declares on its sole responsibility that the digital pasture fence voltage tester
Type/series identification: 580580479
is in conformity with the provisions of
2014/30/EU Directive on electromagnetic compatibility
2011/65/EU Directive on the restriction of the Use of Certain Hazardous
Substances in Electronic and Electrical Equipment (RoHS)
The product was developed in accordance with the following standards:
EN 55032:2015
EN 55035:2017
EN 61000-3-2:2014
EN 61000-3-3:2013
Technical documentation is kept by:
Mr. Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
The serial number and model year are shown on the type plate of the equipment.
Heeslingen, 03.12.2020
Translation of the original declaration of conformity
________________________________________
Holger Wachholtz, Board

Operating Instructions for Digital Fence Tester
580580479
10
10 Warranty
The warranty terms of Wilhelm Fricke SE, as can be found in the sales documents and the
current version of the Terms and Conditions, apply.
In case of questions, please contact the company’s customer service line.
11 Addresses
Sales/customer service/ Tel.: [phone]
Spare parts sales: Fax: [phone]
Postal and shipping address: Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
12 Legal Notice
Translation of the original operating instructions for the digital fence tester
Manufacturer: Wilhelm Fricke SE - DE-27404 Heeslingen
1st Edition July 2020
©2020 Wilhelm Fricke SE
Reproduction in whole or in part is prohibited without the written consent of the Wilhelm Fricke SE company.
All product names mentioned in these Operating Instructions are trademarks of their respective companies.
Printed on paper made from chlorine and acid-free bleached pulp.
