Granit BT 400 User manual

Operating Instructions
BATTERY & ELECTRICAL SYSTEM
ANALYZER
5070011165
These operating instructions must be read thoroughly before use and followed. These
operating instructions must be retained for future reference.
Translation of the original operating instructions

Operating Instructions
5070011165
2
Table of contents
About these operating instructions and symbol descriptions .................................... 3
2Safety and accident prevention rules ................................................................... 3
2.1 Important .................................................................................................. 3
2.2 Personal Safety Precautions ........................................................................... 4
2.3 Preparing to test ........................................................................................... 4
Performance description ..................................................................................... 4
3.1 Operation & Use............................................................................................ 4
Glossary..........................................................................................................12
5EU Declaration of Conformity .............................................................................14
6UKCA Declaration of Conformity .........................................................................15
Disposal ..........................................................................................................16
Warranty.........................................................................................................16
Addresses .......................................................................................................16
Legal notice .....................................................................................................16

Operating Instructions
5070011165
3
About these operating instructions and symbol
descriptions
Incorrect operation can lead to serious injury or death.
Incorrect operation or negligence may result in personal injury,
damage to the equipment or faulty measurements.
Instructions and tips for operation.
Numbers in illustrations (1, 2, 3 ...) refer to the corresponding numbers in brackets
(1), (2), (3) ... in the text next to the item numbers in the tables.
Instructions for which the order must be followed are numbered (1, 2, 3, ...).
Lists are marked with bullet points (●, ●, ...).
2 Safety and accident prevention rules
2.1 Important
For testing 12 volt batteries, and for testing 12 and 24 volt charging
systems.
Suggested operation range 0℃(32℉) to 50℃(122℉) in ambient
temperature.
1. WARNING: This product can expose you to chemicals including
arsenic, which is known to the State of California to cause cancer.
For more information, go to www.P65Warnings.ca.gov.
2. Working in the vicinity of a lead acid battery is dangerous.
Batteries generate explosive gases during normal battery
operation. For this reason, it is of utmost importance, if you have
any doubt, that each time before using your tester, you read
these instructions very carefully.
3. To reduce risk of battery explosion, follow these instructions and
those published by the battery manufacturer and manufacturer of
any equipment you intend to use in the vicinity of the battery.
Observe cautionary markings on these items.
4. Do not expose the tester to rain or snow.

Operating Instructions
5070011165
4
2.2 Personal Safety Precautions
1. Someone should be within range of your voice or close enough to come to your aid
when you work near a lead acid battery.
2. Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing
or eyes.
3. Wear safety glasses and protective clothing.
4. If battery acid contacts skin or clothing, wash immediately with soap and water. If acid
enters eye, immediately flood eye with running cold water for at least ten minutes
and get medical attention immediately..
5. NEVER smoke or allow a spark or flame in vicinity of battery or engine.
6. Be extra cautious to reduce risk of dropping a metal tool onto the
battery. It could spark or short-circuit the battery or other electrical parts
and could cause an explosion.
7. Remove personal metal items such as rings, bracelets, necklaces and
watches when working with a lead acid battery. It can produce a short
circuit current high enough to weld a ring or the like to metal causing a
severe burn.
2.3 Preparing to test
1. Be sure area around battery is well ventilated while battery is being tested.
2. Clean battery terminals. Be careful to keep corrosion from coming in contact with
eyes.
3. Inspect the battery for cracked or broken case or cover. If battery is damaged, do
not use tester.
4. If the battery is not sealed maintenance free, add distilled water in each cell until
battery acid reaches level specified by the manufacturer. This helps purge excessive
gas from cells. Do not overfill.
5. If necessary to remove battery from vehicle to test, always remove ground terminal
from battery first. Make sure all accessories in the vehicle are off to ensure you do
not cause any arcing.
Performance description
3.1 Operation & Use
Each time you connect the tester to a battery, the tester will run a quick
cable verification to ensure a proper connection through the output
cables to sensors in the clamp jaws. If the connection checks out OK,
the tester will proceed to the Home Screen. If the connection is poor,
the display will show “CHECK CABLE”. In this case, check cable
connections for visible signs of damage, as you may need to re-connect
the clamps to the battery or replace the cable end.

Operating Instructions
5070011165
5
BEFORE TESTING:
1. Before you test a battery in a vehicle, turn off the ignition, all accessories and loads.
Close all the vehicle doors and the trunk lid.
2. Make sure the battery terminals are clean. Wire brush them if necessary. Clamp the
black load lead to the vehicle negative battery terminal. Clamp the red load lead to the
vehicle positive battery terminal. Please clamp on the lead part of the terminal only.
Clamping on the iron part of the terminal will lead to wrong test results.
Main Menu:
SYSTEM
ANALYZER
You will view the following screens by pressing ◄/ ►to switch
between all functions and settings.
BATTERY TEST
XX.XX V
Press «ENTER» to do battery test.
SYSTEM TEST
XX.XX V
Press «ENTER» to do system test.
IN-VEHICLE TEST
XX.XX V
Press «ENTER» to change language.
LANGUAGE
SELECT
Press «ENTER» to change language
BRIGHTNESS
Press «ENTER» to start adjusting brightness of the screen.

Operating Instructions
5070011165
6
Battery Test:
1. Select BATTERY TEST. Press «ENTER».
BATTERY TEST
XX.XX V
2. Press the ◄►to select REGULAR/STD or START/STOP battery.
REGULAR/STD
START/STOP
REGULAR/STD BATTERY:
FLOODED, AGM FLAT PLATE, AGM SPIRAL, VRLA/GEL
START/STOP BATTERY:
AGM FLAT PLATE, EFB
3. Press the ◄►key to select the battery type:
BATTERY TYPE:
AGM FLAT PLATE
4. Press «ENTER» to confirm choice.
5. Press the ◄►key to select the battery rating: CCA/SAE, EN,
JIS, DIN, IEC, & CA/MCA.
SELECT RATING:
CCA/SAE
6. Press «ENTER» to confirm choice.
7. Press the ◄►key to input the battery capacity.
CCA/SAE: 40~2000
EN: 40~1885
DIN: 25~1120
IEC: 30~1320
JIS: By Battery Type No.
CA/MCA: 50~2400
SELECT CAPACITY:
560CCA/SAE

Operating Instructions
5070011165
7
8. Press the ◄►key to confirm temperature.
ABOVE 32°F/0°C?
YES/NO
9. Press <<Enter>> to begin the test.
*Return Feature: Before the test is started, the user can always return to the previous
setting page by pressing <<ENTER>> for 2 seconds.
SURFACE CHARGE NOTICE:
The battery will hold a surface charge if the engine has been running
or after the battery has been charged. The tester may prompt you to remove the
surface charge.
A Follow the instructions indicating when to turn the headlights on and off or apply a
load into the battery.
IN VEHICLE:
SURFACE CHARGE IN
VEHICLE?YES
TURN
HEADLIGHTS ON
FOR 15 SECS
OUT OF VEHICLE:
SURFACE CHARGE IN
VEHICLE?NO
TESTING
B. The tester will resume testing after it detects that the surface
charge is removed.
TESTING
10. Test the battery for few seconds.
11. Press the ◄►key to select battery fully charged or not if
tester asks. Press «ENTER» to confirm choice.
IS BATTERY
CHARGED?
YES/NO
12. When the test is completed, the display shows the actual volts and the actual CCA
and internal resistance. {Press the ◄►key to read: SOH (STATE OF HEALTH) and
SOC (STATE OF CHARGE)}.
13. One of the six test results will be displayed:

Operating Instructions
5070011165
8
RRECHARGE & RETEST
Battery is discharged, the battery condition cannot be
determined until it is fully charged. Recharge & retest
the battery.
RECHARGE & RETEST
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
BAD & REPLACE
The battery will not hold a charge. It should be
replaced immediately
BAD & REPLACE
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
BAD CELL & REPLACE
The battery has at least one cell short circuit. It
should be replaced immediately.
BAD CELL & REPLACE
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
GOOD & PASS
*The battery is good and capable of holding a charge.
GOOD & PASS
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
GOOD & RECHARGE
*The battery is good but needs to be recharged.
GOOD & RECHARGE
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
CAUTION
*The battery may be serviced but decrease the capability of
starting the engine gradually. The battery may fail under
extreme climate conditions. There may be a poor connection
between the vehicle and the battery affect the charging
function. Please pay attention to the battery for replacement
consideration and charging system checking
CAUTION
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ

Operating Instructions
5070011165
9
LOAD ERROR
The tested battery is bigger than 2000CCA/SAE or
200AH. Or the clamps are not connected properly.
Please fully charge the battery and retest after
LOAD ERROR
excluding both previous reasons. If reading is the same, the battery should be
replaced immediately.
14. SOC & SOH Display: Press directional keys to see SOC & SOH:
GOOD & PASS
SOC: xx.xx V
■■■■■■■■■□90%
GOOD & PASS
SOH: xxxx CCA/SAE
■■■■■■■■■□90%
15. Press «ENTER» return to MAIN MENU or remove the test clamps from the battery
posts after completion of testing batteries to end test
SYSTEMTEST
1. Select “SYSTEM TEST” from the main menu.
SYSTEM TEST
xx.xx V
2. Turn off all vehicle accessory loads such as light, air
conditioning, radio, etc. before starting the engine.
TURN OFF LOADS
START ENGINE
3. When the engine is started, one of the three results will
be displayed along with the actual reading measured
CRANKING VOLTS NORMAL
The system is showing normal draw. Press «ENTER» to
perform the charging system test
CRANKING VOLTS
xx.xx V NORMAL
CRANKING VOLTS LOW
The cranking voltage is below normal limits, troubleshoot the
starter with manufacturers recommended procedure.
CRANKING VOLTS
xx.xx V LOW
CRANKING VOLTS NOT DETECTED
The cranking voltage is not detected.
CRANKING VOLTS
NOT DETECTED

Operating Instructions
5070011165
10
4. Press «ENTER» to begin charging system test
PRESS ENTER FOR
CHARGING TEST
MAKE SURE ALL
LOADS ARE OFF
5. Press the «ENTER» key, one of the three results will be displayed along with the
actual reading measured..
HIGH CHARGING VOLTS WHEN TEST AT IDLE
The voltage output from the alternator to the battery exceeds
the normal limits of a functioning regulator. Check to ensure
there is no loose connection and the ground connection is
normal. If there is no connection issue, replace the regulator.
ALT. IDLE VOLTS
xx.xx V HIGH
Since most alternators have the regulator built-in, this will require you to replace the
alternator. The normal high limit of a typical automotive regulator is 14.7 volts +/-
0.05. Check manufacturer specifications for the correct limit, as it will vary by vehicle
type and manufacturer.
CHARGING SYSTEM NORMAL WHEN TEST AT IDLEDas The
system is showing normal output from the alternator. No
problem is detected.
ALT. IDLE VOLTS
xx.xx V NORMAL
LOW CHARGING VOLTS WHEN TEST AT IDLE
The alternator is not providing sufficient current to the
battery. Check the belts to ensure the alternator is rotating
with engine running. If the belts are slipping or broken,
ALT. IDLE VOLTS
xx.xx V LOW
replace the belts and retest. Check the connections from the alternator to the battery.
If the connection is loose or heavily corroded, clean or replace the cable and retest. If
the belts and connections are in good condition, replace the alternator.
6. Press «ENTER» for the charging system with
accessory loads. Turn on the blower to high (heat), high
beam headlights, and rear defogger. Do not use cyclical
loads such as air conditioning or windshield wipers
TURN ON LOADS
PRESS ENTER
7. When testing older model diesel engines, the users
need to run up the engine to 2500 rpm for 15 secs.
RUN ENGINE UP TO
2500/MIN 15SEKEC
8. Press «ENTER» to read the ripple from the charging system to the battery. One of
the three testing results will be displayed along with the actual testing measured.

Operating Instructions
5070011165
11
RIPPLE DETECTED NORMAL
Diodes function well in the alternator / starter
RIPPLE DETECTED
xx.xx V NORMAL
NO RIPPLE DETECTT
Ripple is not detected
NO RIPPLE DETECT
PRESS ENTER
EXCESS RIPPLE DETECTED
One or more diodes in the alternator are not functioning or
there is stator damage. Check to ensure the alternator
mounting is sturdy and that the belts are in good shape and
functioning properly. If the mounting and belts are good,
replace the alternator.
RIPPLE DETECTED
xx.xx V HIGH
9. Press the «ENTER» key to continue the charging system with accessory loads. One
of the three results will be displayed along with the actual testing measured.
CHARGING SYSTEM HIGH WHEN TEST WITH ACCESSORY
LOADS
The voltage output from the alternator to the battery
exceeds the normal limits of a functioning regulator.
ALT. LADEVOLTS
xx.xx V HIGH
Check to ensure there are no loose connections and that the ground connection is
normal. If there are no connection issues, replace the regulator. Since most alternators
have the regulator built-in, this will require you to replace the alternator
CHARGING SYSTEM LOW WHEN TEST WITH ACCESSORY
LOADS
The alternator is not providing sufficient current for the
system’s electrical loads and the charging current for the
battery. Check the belts to ensure the alternator is rotating
ALT. LOAD VOLTS
xx.xx V LOW
with the engine running If the belts are slipping or broken, replace the belts and retest
Check the connections from the alternator to the battery. If the connection is loose or
heavily corroded, clean or replace the cable and retest. If the belts and connections are
in good working condition, replace the alternator
CHARGING SYSTEM NORMAL WHEN TEST WITH ACCESSORY
LOADS
The system is showing normal output from the alternator. No
problem detected.
ALT. LOAD VOLTS
xx.xx V NORMAL

Operating Instructions
5070011165
12
10. Press «ENTER» when charging system test is
completed. Turn all accessory loads and engine off.
Press «ENTER» to read the system test results.
TEST OVER. TURN OFF
LOADS & ENGINE
ALT. LOAD VOLTS
xx.xx V NORMAL
RIPPLE VOLTAGE
xx.xx V NORMAL
CRANKING VOLTAGE
xx.xx V NORMAL
ALT. IDLE VOLTS
xx.xx V NORMAL
IN-VEHICLE TEST
This is a combination test of both battery test & system test. Please refer to above testing
procedures or follow the instructions on the display of the tester
Glossary
What is a GEL battery?
A gel battery is a lead-acid electric storage battery that:
is sealed using special pressure valves and should never be opened.
is completely maintenance-free.*
uses thixotropic gelled electrolyte.
uses a recombination reaction to prevent the escape of hydrogen and oxygen gases
normally lost in a flooded lead-acid battery (particularly in deep cycle applications).
is non-spillable, and therefore can be operated in virtually any position. However,
upside-down installation is not recommend-ed.
*Connections must be retorqued and the batteries should be cleaned periodically.
What is an AGM battery?
An AGM battery is a lead-acid electric storage battery that:
is sealed using special pressure valves and should never be opened.
is completely maintenance-free.*
has all of its electrolyte absorbed in separators consisting of a sponge-like mass of
matted glass fibers.
uses a recombination reaction to prevent the escape of hydrogen and oxygen gases
normally lost in a flooded lead-acid battery (particularly in deep cycle applications).
is non-spillable, and therefore can be operated in virtually any position. However,
upside-down installation is not recommended.
*Connections must be retorqued and the batteries should be cleaned periodically.

Operating Instructions
5070011165
13
What is a VRLA battery?
Valve Regulated Lead Acid Battery –This type of battery is sealed Maintenance Free with a
“Bunce” Valve or Valves in the top of them that opens when a preset pressure is realized
inside the battery and let’s the excess gas pressure out. Then the valve resets itself.
What is a SLI battery?
These initials stand for Starting, Lighting and Ignition, which are the three basic functions
which a battery has to perform on all normal vehicles. Batteries given this description will
have been specifically designed for service on cars and trucks within a voltage controlled
electrical system. Those SLI batteries which are intended for heavy haulage vehicles fitted
with large diesel motors may often be called COMMERCIAL batteries. They have to be much
more powerful and more robust than batteries intended for cars.
What is STATE OF HEALTH?
It means how much battery capacity is left (%) comparing with the marked original battery
capacity.
What is STATE OF CHARGE?
It means how many percent of the battery is actually charged.
What is CCA (COLD CRANKING AMPS)?
The current in amperes which a new fully charged battery can deliver for 30 seconds
continuously without the terminal voltage falling below 1.2volts per cell, after it has been
cooled to 0OF and held at that temperature. This rating reflects the ability of the battery to
deliver engine starting currents under winter conditions.
What is AMPERE-HOUR?
The unit of measurement of electrical capacity. A current of one ampere for one hour implies
the delivery or receipt of one ampere-hour of electricity. Current multiplied by time in hours
equals ampere-hours.

Operating Instructions
5070011165
14
5 EU Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
hereby declares on its sole responsibility that the BATTERY & ELECTRICAL SYSTEM
ANALYZER
Type/series identification: 5070011165
conforms to the provisions of
2014/30/EU Electromagnetic Compatibility Directive (EMC Directive)
The product was developed in accordance with the following standards:
EN 61326-1:2013
Authorised person for documentation:
Mr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
The serial number and model year are shown on the type plate of the equipment.
Heeslingen, 07/04/2022
Translation of the original Conformity Declaration
__________________________________
Holger Wachholtz, board

Operating Instructions
5070011165
15
6 UKCA Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
declares under their sole responsibility that the BATTERY & ELECTRICAL SYSTEM
ANALYZER
Type/series identification: 5070011165
conforms to the provisions of
Electromagnetic Compatibility Regulations 2016
The product was developed in accordance with the following standards:
BS EN 61326-1:2013
CISPR11:2015 Group1 Class B
Authorised person for documentation:
Mr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
The serial number and model year are shown on the type plate of the equipment.
Heeslingen, 07.04.2022
Original UKCA Declaration of Conformity
__________________________________
Holger Wachholtz, board

Operating Instructions
5070011165
16
Disposal
On a product, the symbol of a dustbin with a cross through it means that the product
cannot be disposed of with the household waste. In the case of batteries or rechargeable
batteries/accumulators containing mercury (Hg), cadmium (Cd) or lead (Pb), the chemical
symbol is shown under the crossed-out dustbin symbol. The end user has an obligation to
return the batteries or rechargeable batteries/accumulators. These can be handed in free
of charge to the retailer or at any collection point. Electronic devices and rechargeable
batteries/accumulators should be handed in separately to each other. Make sure that the
batteries or accumulators are in a discharged state or, if necessary, protected against
short circuits. When purchasing products, try to ensure that the products have a long
service life. to minimise the amount of waste produced. If your electric or electronic device
contains personal data, you are responsible for deleting it.
Incorrect disposal of batteries or rechargeable batteries/accumulators can, because of the
substances they contain, harm the environment and human health. Special care should be
taken when handling lithium batteries. Products should be checked to see if they can be
re-used, for example, by being repaired, before you dispose of them.
!!! Always observe local disposal regulations!!!
Warranty
The warranty terms of Wilhelm Fricke SE, as can be found in the sales documents and the
current version of the Terms and Conditions, apply.
In case of questions, please contact the company’s customer service line.
Addresses
Sales/customer service/ Tel.: +49 (4281) 712 712
Spare parts sales: Fax: +49 (4281) 712 700
Postal and shipping address: Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Legal notice
Translation of the original operating instructions for the BATTERY & ELECTRICAL SYSTEM ANALYZER
Manufacturer: Wilhelm Fricke SE - DE-27404 Heeslingen
1st Edition May 2022
©2022 Wilhelm Fricke SE
Reproduction in whole or in part is prohibited without the written consent of the Wilhelm Fricke SE company.
All product names mentioned in these operating instructions are trademarks of their respective companies.
Printed on paper made from chlorine and acid-free bleached pulp.
This manual suits for next models
1
Table of contents
Other Granit Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands

Emerson
Emerson Micro Motion HPC010P installation manual

TechnipFMC
TechnipFMC Sening MultiLevel instruction manual

Igema
Igema NA7-45 Installation and operating instruction

Sanwa
Sanwa M53 instruction manual

Rohde & Schwarz
Rohde & Schwarz FPL1000 Series user manual

PickData
PickData SEM Three quick start guide
