85480
VIP PARTY POD
INSTRUCTION MANUAL

2
CONTENTS
Specs......................................................................3
Parts Diagram ........................................................4
Assembly................................................................5
TOOLS NEEDED
• NO TOOLS NEEDED
WARRANTY
Steel components, excluding any finishes, are
warranted for three (3) years from date of original
purchase. Walkboards, excluding any finishes are
warranted for one (1) year from date of original
purchase. We will repair, without charge, any defect
due to faulty material or workmanship. These
warranties do not cover failures due to abuse,
misuse, improper installation, accidental damage
or when repairs or modifications have been made
or attempted to be made by anyone other than
Granite Industries. Any defective products that
meet warranty specifications and Granite Industries
approval, may be returned to the factory to be
repaired or replaced free of charge. (Granite
Industries will pay to ship replacement item(s) to the
customer; however the customer is responsible for
shipment of products to the factory.) This remedy
is the sole remedy in contact, tort or otherwise,
and Granite Industries is not liable for incidental,
consequential or special damages. These warranties
give you specific legal rights, and you may have
other rights which vary from state to state. Should
you have any questions, contact Granite Industries
(Proof of purchase may be required).
Customer Service
877-447-2648
M-F, 8am - 5pm EST

3
SPECS
Overall Dimensions: W: 7’ D: 5’ H: 44”
Weight: 205 lb Capacity: 1,500 lb

4
ITEM NO QTY PART NO DESCRIPTION
1 1 MI-12-6618 End Frame
2 4 22014 Base Plate
3 3 35303 9 x 17 Blacktop Walkboard
4 4 MI-12-6619 End Frame with Access
5 1 MI-12-6620 Brace
6 4 06003 2” Snap Pin
7 8 06010 1/2” Wing Nut
8 2 PI-04-0036 1 1/4” Cap Plug
9 4 PI-04-0072 1 1/2” Cap Plug
PARTS DIAGRAM
Quantity of components may vary on model configuration.
VIP Pod with one access panel shown above.

5
3
2
COMPONENTS
ITEM NO QTY DESCRIPTION
1 1 End Frame
2 4 Base Plate
3 3 9 x 17 Blacktop Walkboard
4 4 End Frame with Access
5 1 Brace
6 4 2” Snap Pin
7 8 1/2” Wing Nut
Stand the end panels upright.
VIP PARTY POD ASSEMBLY
1
Insert the base plate into the open end on an
end panel. Secure in place with a snap pin.
Slide one of the guardrails on, connecting
the two end panels together. The curved
side of the guardrail should go to the
outside of your pod.
4
Secure in place with the wing nuts.

6
76
Repeat this step for all required walkboards.
5
Place the walkboard over the bottom bar of
the end panels.
Install the second guardrail, just as you did
the first. Making sure the curved side is to
the outside of the pod.
Secure in place with wing nuts.
Check Point.
Your pod should look like this.
Your Party Pod is complete and ready for use.
