2040RDA-FR, 2040RDA-16FR
Fiber Ready Distribution
AmpliÞers
Introduction
The 2040RDA-FR and 2040RDA-16FR Fiber Ready Distribution Amplifiers
provides one electrical input by either eight or sixteen non-inverting elec-
trical outputs for distributing SD, HD, and DVB-ASI signals. The module
also handles optical/electrical fiber conversion with optional low power
single mode SFP (Small-form Factor Pluggable)/LC 1310nm optical trans-
ceiver (input/output) or dual transmitter submodules. This provides both
optical inputs and outputs depending on the type of submodule installed
in the rear module.
Auto-detection and reclocking capability are available at all SD (standard
definition) and HD (high definition) data rates. The reclocking circuit can
be bypassed to distribute signals down to 4 Mbps.
The 2040RDA-FR and 2040RDA-16FR features include:
•2040RDA-FR: Eight BNC electrical outputs, one BNC electrical input, or
• 2040RDA-16FR: Sixteen BNC electrical outputs, one BNC electrical
input,
• Single mode fiber optic submodule option for dual transmitter (2 out-
puts) or transceiver (1 input/1 output),
•Module and SFP submodule are both hot-swappable,
•Automatic data rate detection,
•Reclocks at 143 Mb/s, 177 Mb/s, 270 Mb/s, 360 Mb/s, 540 Mb/s, or
1485 Mb/s,
•Distributes transport streams in bypass mode,
•Auto-adjust rise/fall times to meet either the SD or HD standard, and
• Supports networked control and monitoring in frames with 2000NET
module.

8 2040RDA-FR/16FR Instruction Manual
Installation
Installation
Installation of a 2040RDA-FR or 2040RDA-16FR module set is a process of:
• Setting on-board jumpers on the front media module for modules not
using remote control or to set module defaults,
•Placing the 2040RDA-FR-R or 2040RDA-16FR-R rear module in a frame
slot,
• Installing the fiber optic SFP submodule (optional),
• Placing the front media module in the corresponding front slot, and
•Cabling signal ports.
Front Module Onboard Jumper Settings
The 2040RDA-FR and 2040RDA-16FR modules have four onboard jumpers
that can be configured for determining the following functions:
• Jumper JP1 – sets control mode for Local only or Remote and Local.
•Jumper JP2 and JP3 – set the input format for the module and/or optic
output enables.
• Jumper JP4 – sets module for bypass or reclocking function.
Factory Defaults
The local settings made on J2, J3, and J4 are the defaults for the module.
Changing any local jumper setting while the module is powered up or
removed and plugged back into the frame will immediately reset the
module to the current local jumper settings. This will also occur when
removing or installing an optic submodule.
Selecting the
Recall Fact. Defaults
button on the Recall Factory Defaults web
page (page 34) will return the module to these local settings.
Remote Control Jumper
When the jumper is placed across pins 1 and 2 of jumper block JP1, module
settings are changed from the on-board jumpers only; remote control is
locked out. To have both Local and Remote access, set the jumper across
pins 2 and 3.

2040RDA-FR/16FR Instruction Manual 9
Installation
Figure 1. Module Configuration Jumpers
8269_06r1
Jumper across pins 1–2
to lock out remote control.
Jumper across pins 2–3
to enable remote and
local control.
LOC LOC&
REM
Jumper across pins 1–2
selects automatic reclocking.
Jumper across pins 2–3
bypasses reclocking function.
Remote Control Lockout
Auto/Bypass Reclocking
JP1
AUTO BPSS
JP4
Set JP2 and JP3 for input
according to module
silkscreen.
10
Input Select
JP2
10
JP3

10 2040RDA-FR/16FR Instruction Manual
Installation
Input/Output Select Jumpers
Set jumpers JP2 and JP3 to 0 (pins 2-3) or 1 (pins 1-2) to select the
input/output type and/or optic output enable according to the silkscreen
on the front module shown in Figure 2.
These jumper settings can be overridden by remote control. When this con-
dition occurs, the front edge yellow REM OVR LED will light (refer to
Table 1 on page 21).
Note The DRL Dual Receiver function is not used at this time.
Figure 2. 2040RDA-FR and 2040RDA-16FR Front Module Silkscreen
Auto/Bypass Jumper
In Local mode, the module will operate in Auto or Bypass mode.
When set to
Auto
mode, the module will automatically reclock the incoming
signal to 143 Mb/s, 270 Mb/s, 360 Mb/s, 540 Mb/s, or 1.485 Gb/s rates
(ASI 270 signals). If the input signal cannot lock to one of these rates, the
reclocking will be bypassed automatically.
When set to
Bypass
mode, the reclocking will be bypassed completely.
Set jumper JP4 for auto-reclocking (AUTO pins 1-2) or to bypass reclocking
(BPSS pins 2-3). This jumper setting can be overridden by remote control.
When the module is in Bypass, the front edge LD LED will be off (refer to
Table 1 on page 21).

2040RDA-FR/16FR Instruction Manual 11
Installation
Module Placement in the 2000 Frame
There are twelve slot locations in both the front and rear of a Kameleon
3 RU frame to accommodate 2000 Series modules. The 2040RDA-FR and
2040RDA-16FR modules set consists of a front media module and a rear
module for the 2040RDA-FR or a dual height rear module for the
2040DRA-16FR that requires two module slots.
Each 2040RDA-FR or 2040RDA-16FR front media module plugs into the
front of the 2000 frame mid-plane. The rear module plugs into the corre-
sponding rear slot to provide the input and output interface connectors.
Stacked BNCs on the 2040RDA-16FR passive rear module require two rear
slots. The fiber optic SFP submodule option installs in the connector cage
on the top right of the rear module.
A 3 RU 2000T3 frame fully stuffed with 2040RDA-FR front and rear
modules will accommodate up to twelve module sets as shown in Figure 3.
A 1 RU 2000T1 frame will accommodate up to 4 module sets.
Figure 3. 2040RDA-FR 3 RU Frame, Rear View
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
Mid-frame motherboard
with power and
communication buses
Rear media module slots 1– 6Rear media module slots 7– 12
8360_02

12 2040RDA-FR/16FR Instruction Manual
Installation
A 3 RU 2000T3 frame fully stuffed with 2040RDA-16FR front and rear
modules will accommodate up to six module sets as shown in Figure 4. A
1 RU 2000T1 frame will accommodate up to 2 module sets.
Figure 4. 2040RDA-16FR 3 RU Frame, Rear View
The 2040RDA-FR and 2040RDA-16FR front and rear modules and fiber
optic submodules can be plugged in and removed from a Kameleon 2000
Series frame with power on. When power is applied to the module, LED
indicators reflect the initialization process (see Power Up on page 21).
To install a 2040RDA-FR module set in the frame:
1.
Locate a vacant slot in slot 1-12 in the rear of the 1 RU or 3 RU frame (3
RU frame shown in Figure 3).
2.
Insert the rear module into a vacant rear slot in the frame as illustrated
in Figure 5.
Mid-frame motherboard
with power and
communication buses
Use rear media module slots 1, 3, and 5Use rear media module slots 7, 9, and 11
8269_04
Slot 5
Slot 3
Slot 7
Slot 9
Slot 11
Slot 1

2040RDA-FR/16FR Instruction Manual 13
Installation
Figure 5. Installing 2040RDA-FR Rear Module
To install a 2040RDA-16FR module set in the frame:
1.
Locate a vacant slot in slot 1, 3, 5, 7, 9, or 11 of the rear of the 3 RU frame
(Figure 4). The rear module uses two slots.
2. Insert the rear module into vacant rear slot 1, 3, 5, 7, 9, or 11 of the frame
as illustrated in Figure 6.
Figure 6. Installing 2040RDA-16FR Rear Module
To continue installation of 2040RDA-FR and 2040RDA-16FR modules set in
the frame:
1.
Verify that the module connector seats properly against the midplane.
2.
Using a crossblade screwdriver, tighten the two screw locks to secure
the module in the frame.
Alignment post
and receptacle
Screw locks
(both sides)
8360_11
2000 frame (rear view) Board edge guides
(both sides)
2040RDA-FR-R Passive Rear Module Fiber optic
connector cage
Input
Alignment post
and receptacle
Screw locks
(both sides)
8269_03
2000 frame (rear view) Board edge guides
(both sides)
2040RDA-16FR-R Passive Rear Module
Fiber optic
connector cage
Input

14 2040RDA-FR/16FR Instruction Manual
Installation
3.
To install the optional SFP submodule in the 2040RDA-FR, refer to
Figure 7. The SFP submodule is hot-pluggable and may be installed or
removed with power applied to the module.
4.
To install the optional SFP submodule in the 2040RDA-16FR, refer to
Figure 8. The SFP submodule is hot-pluggable and may be installed or
removed with power applied to the module.
The module type is identified by name on the label or can be identified
by the direction of the two arrow indicators on the label.
Note Installing or removing the optical submodule while the module is powered up
will reset the module to a default state—that of the jumper settings currently
set for JP2, JP3, and JP4 (see Factory Defaults on page 8).
5. With the handle in the up position, slide the metal casing, label side up,
into the cage connector on the top right of the rear module.
Note When installed properly, the front end of the submodule will line up with the
BNCs. Do not try to force it in further.
Figure 7. Installing SFP Submodule on 2040RDA-FR
Figure 8. Installing SFP Submodule on 2040RDA-16FR
8360_09
Label
Handle in
up position
Arrow Indicators
2040RDA
-FR
J3
8269_11
Label
Handle in
up position
Arrow Indicators

2040RDA-FR/16FR Instruction Manual 15
Installation
6.
For the 2040RDA-FR locate the front slot 1-12 in the frame
corresponding to the rear module circuit board. The 3 RU frame front
view is illustrated in Figure 9.
Figure 9. 2000 Series 3 RU Frame, 2040RDA-FR Frame Slots
7.
For the 2040RDA-16FR locate the front slot 1, 3, 5, 7, 9, or 11 in the frame
corresponding to the rear module circuit board. The 3 RU frame front
view is illustrated in Figure 10. Module slots where the 2040RDA-16FR
should be installed for a fully stuffed 2000 frame are highlighted in
gray.
Note 2040RDA-16FR modules are not limited to these slots. The dual height rear
and corresponding front module can be placed in any location as long as
there is enough space.
Figure 10. 2000 Series 3 RU Frame, Front Slots
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(1)
Install Front Media modules
into slots 1-12
8360_12
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(1)
Install Front Media modules
into slots 1, 3, 5, 7, 9, and 11.
8269_19

16 2040RDA-FR/16FR Instruction Manual
Installation
8.
With the component side up, insert the front media module in the
corresponding front slot (see Figure 11).
9.
Verify that the module connector seats properly against the midplane
and rear module connector.
10.
Press firmly on both ejector tabs to seat the module.
Figure 11. Installing Front Media Module
2040RDA-16FR
Alignment post and receptacle
8269-10
2000 Frame (front view)
Board edge
guides
Board edge
guides

2040RDA-FR/16FR Instruction Manual 17
Installation
Cabling
All cabling to the 2040RDA-FR or 2040RDA-16FR module sets is done on
the corresponding Single Height 2040RDA-FR or Dual Height
2040RDA-16FR rear module at the back of the 2000 frame.
Cabling of the rear module depends on what SFP option is installed as fol-
lows:
•2040RDA-FR or 2040RDA-16FR with no SFP Optical submodule option
(electrical only) (page 17)
• 2040RDA-FR or 2040RDA-16FR with 1310NM-DTL (Dual Optical
Transmitter) option (page 19)
• 2040RDA-FR or 2040RDA-16FR with 1310NM-TRL (Optical Trans-
ceiver) option (page 20)
2040RDA-FR or 2040RDA-16FR with No SFP Option
The 2040RDA-FR or 2040RDA-16FR can input one electrical SD/HD/ASI
input with either eight or sixteen electrical outputs. On-board jumpers JP2
and JP3 on the circuit board have no effect and can be set for any configu-
ration. Refer to Figure 12 for an illustration of the input and output BNCs
for 2040RDA-FR or refer to Figure 13 for an illustration of the input and
output BNCs for 2040RDA-16FR.
Figure 12. 2040RDA-FR Rear Module Input/Output Connectors
Figure 13. 2040RDA-16FR Rear Module Input/Output Connectors
J6J7J8J9J10
2040RDA
-FR
J5 J3J4 J2 J1
Input
SFP Submodule
connector cage
8360_01
Outputs BNC J1, J3-J9
J6J7J8
J9
2040
RDA-16
J5 J3J4 J2 J1
J15J16J17
Input
J14 J12J13 J11 J10
SFP Submodule
connector cage
8269_02
Outputs J1 – J8
Outputs J9 – J16

18 2040RDA-FR/16FR Instruction Manual
Installation
Electrical Input
Connect an electrical SD, HD, or ASI video input to BNC J10 on the
2040RDA-FR or BNC J17 on the 2040RDA-16FR. The 2040RDA-FR and
2040RDA-16FR will accept any of the serial digital component video
signals conforming to the following formats:
•SMPTE 259M (143 Mb/s, 177 Mb/s, 270 Mb/s, and 360 Mb/s)
•SMPTE 292M (1.485 and 1.485/1.001 Gb/s)
•SMPTE 344M (540 Mb/s)
•4Mbps to 1.5 Gb/s
•SMPTE 310M (MPEG up to 38.78 M/bps)
• DVB-ASI
Electrical Outputs
On the 2040RDA-FR the input signal is distributed to 8 output BNCs.
Connect video output devices to outputs J1 and J3 through J9 provided on
the 2040RDA-FR rear module (Figure 12 on page 17).
On the 2040RDA-16FR the input signal is distributed to 16 output BNCs.
Connect video output devices to outputs J1 through J8 and J9 through J16
provided on the 2040RDA-16FR rear module (Figure 13 on page 17).

2040RDA-FR/16FR Instruction Manual 19
Installation
2040RDA-FR or 2040RDA-16FR with Dual Optical Transmitter
With the Dual Optical Transmitter installed the module can operate in the
following modes:
• Electrical input to eight electrical outputs and two optical outputs on
the 2040RDA-FR, or
•Electrical input to sixteen electrical outputs and two optical outputs on
the 2040RDA-16FR.
Electrical Input
Connect an SD, HD, orASI video input to BNC J10 on 2040RDA-FR or BNC
J17 on 2040RDA-16FR as described in Electrical Input on page 18.
Electrical and Optical Outputs
The input signal is distributed to eight or sixteen electrical output BNCs.
Connect video output devices to outputs J1 and J3 through J9 provided on
the 2040RDA-FR (Figure 12 on page 17) or J1 through J8 and J9 through J16
provided on the 2040RDA-16FR rear module (Figure 13 on page 17).
The output signal can also be accessed from both optical outputs from the
SFP submodule, Optic 1 (left) and Optic 2 (right), shown in Figure 14. Set
on-board jumpers JP2 and JP3 to enable or disable one or both of the optical
outputs as described in Input/Output Select Jumpers on page 10. With the
submodule handle in the up position, connect optical cables to one or both
outputs.
Figure 14. Dual Transmitter Optical Outputs
8269_13
Optic 1 (output) Optic 2 (output)

20 2040RDA-FR/16FR Instruction Manual
Installation
2040RDA-FR or 2040RDA-16FR with Optical Transceiver
With the Optical Transceiver SFP option installed the module supports the
following modes:
• Electrical input to eight or sixteen electrical outputs and two optical
outputs, or
•Optical input to eight or sixteen electrical outputs and one optical
output.
Electrical or Optical Input
To use the electrical input, connect an SD, HD, or ASI video input to BNC
J10 on the 2040RDA-FR or BNC J17 on the 2040RDA-16FR as described in
Electrical Input on page 18. Set on-board jumper JP3 to the Coax input as
described in Input/Output Select Jumpers on page 10.
For an optical input, connect the fiber cable to the Optic 2 input (right), as
shown in Figure 15. Set on-board jumper JP3 to enable the optic input as
described in Input/Output Select Jumpers on page 10.
Electrical and Optical Outputs
The input signal is distributed to eight or sixteen electrical output BNCs.
Connect video output devices to outputs J1 and J3 through J9 provided on
the 2040RDA-FR rear module (Figure 12 on page 17) or J1 through J8 and
J9 through J16 provided on the 2040RDA-16FR rear module (Figure 13 on
page 17).
The output signal can also be accessed from the Optic 1 (left) connector
shown in Figure 15. Enable or disable this output with on-board jumper JP2
as described in Input/Output Select Jumpers on page 10. With the submodule
handle in the up position, connect an optical cable to this output.
Figure 15. Dual Transceiver Optical Input and Output
8269_14
Optic 1 (output) Optic 2 (input)
