GRASS VALLEY Fibre Channel Switch User manual

Fibre Channel Switch
Installation Manual
071-8212-00
APRIL 2003
the most watched worldwide

2Fibre Channel Switch 16 April, 2003
Copyright Copyright © 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Printed in
the United States of America.
This document may not be copied in whole or in part, or otherwise reproduced except as
specifically permitted under U.S. copyright law, without the prior written consent of Thomson
Broadcast and Media Solutions, Inc., P.O. Box 59900, Nevada City, California 95959-7900
Trademarks Grass Valley, Profile, and Profile XP are either registered trademarks or trademarks of
Thomson Broadcast and Media Solutions, Inc. in the United States and/or other countries.
Other trademarks used in this document are either registered trademarks or trademarks of the
manufacturers or vendors of the associated products. Thomson Broadcast and Media
Solutions, Inc. products are covered by U.S. and foreign patents, issued and pending.
Additional information regarding Thomson Broadcast and Media Solutions, Inc. trademarks
and other proprietary rights may be found at www.thomsongrassvalley.com.
Disclaimer Product options and specifications subject to change without notice. The information in this
manual is furnished for informational use only, is subject to change without notice, and should
not be construed as a commitment by Thomson Broadcast and Media Solutions, Inc. Thomson
Broadcast and Media Solutions, Inc. assumes no responsibility or liability for any errors or
inaccuracies that may appear in this publication.
U.S. Government
Restricted Rights
Legend
Use, duplication, or disclosure by the United States Government is subject to restrictions as set
forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause
at DFARS 252.277-7013 or in subparagraph c(1) and (2) of the Commercial Computer
Software Restricted Rights clause at FAR 52.227-19, as applicable. Manufacturer is Thomson
Broadcast and Media Solutions, Inc., P.O. Box 59900, Nevada City, California 95959-7900
U.S.A.
Revision Status
Rev Date Description
April 16, 2003 Initial release. 071-8212-00

16 April, 2003 Fibre Channel Switch 3
Contents
Welcome..............................................................................................................................7
How to use the manuals..................................................................................................8
Support for your Fibre Channel switch............................................................................8
Installing a Switch in a Profile Video Network......................................................................9
Profile System Software Requirements.........................................................................10
PDR Series Fibre Channel firmware and driver requirements......................................11
Loading PDR Series firmware..................................................................................11
Loading Fibre Channel Server firmware...................................................................12
Configuring Fibre Channel on your PDR Series systems.............................................12
Configuring your Fibre Channel switch .........................................................................14
Enter administrator mode.........................................................................................14
Configure Ethernet LAN settings..............................................................................14
Verify firmware version.............................................................................................15
Port and switch configuration...................................................................................16
Connecting devices to the switch..................................................................................19
Cable lengths ...........................................................................................................19
Fabric topology.........................................................................................................19
Compatible Fibre Channel Devices..........................................................................19
Monitoring your switch with NetCentral..............................................................................20
SNMP configuration ......................................................................................................21
Setting port aliases........................................................................................................23
Monitoring Status ..........................................................................................................24
Troubleshooting with NetCentral...................................................................................26
Maintenance procedures ...................................................................................................27
Resetting the switch to factory defaults.........................................................................27
Resetting the switch manually.......................................................................................27

Contents
4Profile XP Service Manual 16 April, 2003

16 April, 2003 Fibre Channel Switch 5
Grass Valley Product Support
To get technical assistance, check on the status of problems, or report new problems,
contact Grass Valley Product Support via e-mail, the Web, or by phone or fax.
Web Technical Support
To accesssupport information on the Web, visit theproductsupport Web page on the
Grass Valley Web site. You can download software or find solutions to problems by
searching our Frequently Asked Questions (FAQ) database.
World Wide Web: http://www.thomsongrassvalley.com/support/
Technical Support E-mail Address: [e-mail].
Phone Support
Use the following information to contact product support by phone during business
hours. Afterhours phone support is available for warranty and contract customers.
USA and Americas (includes Latin America and Canada)
Europe and UK
Asia Pacific
Authorized Support Representative
A localauthorizedsupport representative may be availablein your country. To locate the
support representative for your country, visit theproduct support Web page on theGrass
Valley Web site.
Profile Users Group
You can connect with other Profile XP Media Platform users to ask questions or share
advice, tips, and hints. Send e-mail to [e-mail] to join the
community and benefit from the experience of others.
Telephone [phone] (Toll Free)
[phone] (Direct Dial Toll Call)
Fax [phone]
UKRegional
Service
Location
Tel [phone]
Fax [phone] Italy Tel [phone] Fax [phone]
France Tel [phone]
Fax [phone] Germany Tel [phone] Fax [phone]
Australia Tel [phone]
Fax [phone] India Tel [phone] Fax [phone]
China Tel [phone]
Fax [phone] Japan Tel [phone] Fax [phone]
Hong Kong Tel [phone]
Fax [phone] South East Asia Tel [phone] Fax [phone]

Product Support
6Fibre Channel Switch 16 April, 2003

16 April, 2003 Fibre Channel Switch 7
Welcome
You can use your 8-, 16-, or 8 to 64-port QLogic SANbox2 Fibre Channel switch to
create fabrics for Grass Valley Media Area Networks (SCSI protocol) and Video
Networks (Internet Protocol). This manual supplements the information provided by
the QLogic SANbox2 Switch manuals that you received with your switch.
Please refer to the following QLogic manuals, included on the SANsurfer Tool Kit
CD-ROM, when installing and configuring your QLogic SANbox2 Switch.
•SANbox2 Fibre Channel Switch Installer’s/User’s Manual - This is your primary
reference on the installation and initial setup of your specific model of QLogic
switch. It also provides maintenance and repair information.
•SANbox2 Switch Management User’s Manual - This manual describes the switch
management software application that allows you to monitor and administer your
QLogic SANbox2 Switch.
NOTE:IfyouareinstallingtheQLogicSANbox2Switchina MediaArea Network,
please refer to your Media Area Network Instruction Manual for detailed
installation and configuration information.

8Fibre Channel Switch 16 April, 2003
How to use the manuals
The following table describes how to use the documentation set that accompanies
your QLogic SANbox2 Switch and other Grass Valley products.
NOTE: Carefully read and understand all procedures before attempting any
operation with your switch. Procedures such as replacing modules in the 8 to
64-port switch can produce unexpected results if you do not follow the published
procedures exactly.
Support for your Fibre Channel switch
Your QLogic SANbox2 Switch is sold, supported, and serviced by Grass Valley.
If you have any questions about your QLogic SANbox2 Switch, or if you need any
help or service for the switch, please contact your local Grass Valley Support
representative listed at the front of this manual
NOTE: Do not contact QLogic directly for support of your QLogic SANbox2
Switch.
For information on... See...
Installing the switch in a
Profile Video Network “Installing a Switch in a Profile Video Network” beginning on page 9 of this manual.
SANbox2 Fibre Channel Switch Installer’s/User’s Manual
SANbox2 Switch Management User’s Manual
Installing the switch in a
Media Area Network Media Area Network Instruction Manual SANbox2 Fibre Channel Switch Installer’s/User’s Manual
SANbox2 Switch Management User’s Manual
Configuring the Fibre Channel
switch for NetCentral monitoring “Monitoring your switch with NetCentral” beginning on page 20 of this manual.
SANbox2 Fibre Channel Switch Installer’s/User’s Manual
SANbox2 Switch Management User’s Manual

Installing a Switch in a Profile Video Network
16 April, 2003 Fibre Channel Switch 9
Installing a Switch in a Profile Video Network
Compared to a Fibre Channel hub, the Fibre Channel switch improves the
performance of your Fibre Channel installation by:
• Increasing the bandwidth between any two Fibre Channel devices by eliminating
the shared bandwidth of a Fibre Channel Arbitrated Loop.
• Improving the scalability of your Video Network. By managing your inter-switch
links, you can increase the size of your network without the shared bandwidth
concerns of a large loop.
The following figure shows the Profile Fibre Channel switch in a simple IP fabric
environment.
The sections that follow describe the installation and use of the QLogic SANbox2
Switch in a Profile Video Network environment. Topics include:
• Installing the required Profile System Software version.
• Loading the required Profile Fibre Channel firmware onto the Profile PDR Series
Fibre Channel card, and ensuring that other Fibre Channel devices on the fabric are
using compatible firmware.
You do not need to change the Fibre Channel firmware or drivers on Profile XP
systems.
• Configuring the Profile system to work with a switch (fcconfig -s on). This step is
not required on a Profile XP.
• Avoiding loop configurations in a fabric (switched) environment.
0246810 12 14
1357911 13 15
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G
A
C
T
L
O
G

10 Fibre Channel Switch 16 April, 2003
Profile System Software Requirements
The following table lists the minimum Profile System Software version required for
operation with a QLogic SANbox2 Switch. Earlier versions do not support this Fibre
Channel switch.
Please refer tothe Profile Release Notes for instructions on how to installyourProfile
System Software, as well as information on the new features that are included in the
release.
Profile Model Minimum Profile System Software Version
PDR100 Not supported
PDR200 2.5.23
PDR300 2.5.23
PDR400 3.2.8
PVS Series 5.2.X

PDR Series Fibre Channel firmware and driver
16 April, 2003 Fibre Channel Switch 11
PDR Series Fibre Channel firmware and driver requirements
Early versions of the firmware for the PDR Series Fibre Channel board (1.4, 1.7.X)
supported the Fibre Channel Arbitrated Loop, but would not function with a Fibre
Channel switch. More recent versions of thefirmware supportoperation witha switch
and interoperation with other Fibre Channel board manufacturers, but have not been
optimized for use in a loop.
To operate in a fabric environment, one which uses switches, you must use Fibre
Channel board firmware that is compatible with the switch. You may use the same
firmware in a loop environment, but you may encounter operational limitations that
are not present with earlier versions of the firmware.
Generally, Fibre Channel firmware versions numbered 3.0 or higher, or identified as
switch compatible, or interoperable, all support operation with the Fibre Channel
switch.
NOTE: All versions of Profile XP Fibre Channel boards have the required
firmware for operation with the Profile Fibre Channel Switch. Do not perform the
following procedure on a Profile XP system.
Loading PDR Series firmware
Once you have installed Profile System Software version 2.5 or higher, you can load
a switch-compatible version of firmware onto your Profile Fibre Channel board. You
must load this firmware before connecting your Profile system to the QLogic
SANbox2 Switch. You must also use this version of firmware if you wish to connect
your Profile system to any other device that is equipped with Fibre Channel board
from a supplier other than Grass Valley.
NOTE: Do not perform this procedure on a Profile XP system.
To load the switch-compatible firmware on your Profile Fibre Channel board:
1. Close any applications that may be running on the system.
2. At a command line, type vdrsvc -start and then press Enter. This starts the PDR
Access Service if it is not already started.
3. Choose Start | Programs | PDR Debug Tools | Update FC Switch Microcode. A
window appears.
4. The program asks if you want to continue. Type Y.
5. The program now reads the new image of the firmware from
c:\profile\etc\sfcucode.img. The program automatically copies the old firmware to
the file c:\profile\etc\sfcucode.old.
6. Restart the disk recorder in order for the firmware update to take effect.

12 Fibre Channel Switch 16 April, 2003
Loading Fibre Channel Server firmware
If you wish to connect a Profile Fibre Channel Server to a QLogic SANbox2 Switch,
you must load switch-compatible firmware on all the Fibre Channel boards installed
in your server. You must also install the appropriate Fibre Channel drivers that can
use all the features of the new firmware.
NOTE: A Profile Fibre Channel Server consists of an SGI O200 or O2000 system
equipped with Fibre Channel boards purchased from Grass Valley. If your Fibre
Channel boards were purchased obtained from another source, please ask your
supplier about compatibility with the QLogic SANbox2 Switch.
To load switch-compatible firmware on your Fibre Channel Server boards:
1. Contact Grass Valley support to obtain the location of the latest firmware, then
download the files from that location.
2. Place the files in the /temp/drivers on the destination SGI server.
3. Followtheinstructionsin theGenroccoFibreChannelAdapterInstallationManual
to load the firmware onto each of the Fibre Channel boards.
4. Followtheinstructionsin theGenroccoFibreChannelAdapterInstallationManual
to install the appropriate driver on the system.
5. Reboot the SGI server.
Configuring Fibre Channel on your PDR Series systems
Once you’ve installed the required version of Profile System Software and loaded the
appropriate firmware and drivers on all the devices you are connecting to the switch,
you must configure each Profile Video File Server or Profile Fibre Channel Server for
operation in a Fibre Channel fabric environment.
NOTE: Profile XP Media Platforms are pre-configured for operation in a fabric
(switched) Fibre Channel Environment. You must not perform this procedure on a
Profile XP system.
To configure your Profile Fibre Channel server or any device other than your Profile
system, refer to the installation manual for that device for instructions.

Configuring Fibre Channel on your PDR Series
16 April, 2003 Fibre Channel Switch 13
To configure your Profile system for use in a Fibre Channel environment, follow the
instructions in the Profile User Manual. In addition to these instructions, you must
also set Fibre Channel Switch Mode ON. You can do this in one of two ways:
• Type the following command from the Command Prompt: fcconfig -s on.
OR
• In Configuration Manager, select Switch Compatibility Mode in the Fibre Channel
Configuration dialog box.
NOTE: You do not need to set the Fibre Channel hardware address of Profile
systems connected to the Fibre Channel switch. These addresses are assigned
dynamically in a fabric environment.

14 Fibre Channel Switch 16 April, 2003
Configuring your Fibre Channel switch
Your QLogic SANbox2 Switch must be configured so that you can control and
monitor it in your LAN environment. As you make these settings, you should also
verify that all the other switch and port settings are appropriate for operation in a
Grass Valley Fibre Channel fabric. The following instructions describe how to verify
and assign these settings using a serial port connection. The same commands can also
be used in a Telnet session over the Ethernet port.
NOTE: You can use the SANbox Manager software application described in the
SANbox2 Switch Management User’s Manual to establish Ethernet LAN, SNMP,
and basic switch and port settings. However, you must use the Command Line
Interface through either the serial or Ethernet port to set or verify the Advanced
settings.
Enter administrator mode
You must be in administrator mode to make changes to your QLogic SANbox2
Switch settings. To enter this mode:
1. Establish serial connection to the QLogic SANbox2 Switch using a null-modem
cable and Windows HyperTerminal or an equivalent serial communication tool.
Refer to the SANbox2 Fibre Channel Switch Installer’s/User’s Manual for
connection information.
2. In the serial communication window, press Enter to establish communications,
then log in to the switch with username admin and password password, all in
lowercase characters.
3. Type the following command to enter the administrator mode, which allows you
modify settings.
sb5_8port #> admin start
Configure Ethernet LAN settings
You must assign an Ethernet IP address, a subnet mask, and a default gateway to
configure your QLogic SANbox2 Switch for operation in your Ethernet local area
network.
1. In administrator mode, type the following command at the prompt:
sb5_8port (admin) #> set setup system
2. As you step through each of the following configuration items, assign your local
settings as needed, or press Enter to accept the defaults.
A list of attributes with formatting and current values will follow.
Enter a new value or simply press the ENTER key to accept the current value.
If you wish to terminate this process before reaching the end of the list
press 'q' or 'Q' and the ENTER key to do so.
Eth0NetworkAddress (dot-notated IP Address) [192.168.5.216]
Eth0NetworkMask (dot-notated IP Address) [255.255.255.0]
Eth0GatewayAddress (dot-notated IP Address) [192.168.5.1]
Eth0NetworkDiscovery (1=Static, 2=Bootp, 3=Dhcp, 4=Rarp) [Static]

Configuring your Fibre Channel switch
16 April, 2003 Fibre Channel Switch 15
AdminTimeout (dec value 0-1440 minutes, 0=never) [30]
TempMonitoringWarning (dec value 0-100 degrees Celsius) [65]
TempMonitoringFailure (dec value 0-100 degrees Celsius) [70]
TempFailurePortShutdown (True / False) [False]
SecurityEnabled (True / False) [False]
LocalLogEnabled (True / False) [True]
RemoteLogEnabled (True / False) [False]
RemoteLogHostAddress (dot-notated IP Address) [10.0.0.254]
Do you want to save and activate this system setup? (y/n): [n] y
Verify firmware version
You can use the show switch command to view switch information and confirm that
the active firmware version is correct. The minimum qualified image is:
• 1.5.0.8 or higher
Contact your Grass Valley representative to determine the current required version.
To view the current version information:
1. In administrator mode type the following command at the prompt,:
sb5_8port (admin) #> show switch
2. View the switch information, an example of which is shown here. Note that the
ActiveSWImage specifies which SWImageVersion is being used. In this case, it’s
image 2.
Switch Information
------------------
SymbolicName sb5_8port
SwitchWWN 10:00:00:c0:dd:01:a6:47
SwitchType Sanbox2-8C
PROMVersion V1.4.0.2-0 (Thu Mar 13 21:27:06 2003)
CreditPool 0
DomainID 100 (0x64)
FirstPortAddress 640000
FlashSize - MBytes 128
LogLevel Critical
MaxPorts 8
NumberOfResets 17
ReasonForLastReset PowerUp
SWImageVersion (1) - build date V1.4.0.39-0 (Tue Jan 21 08:11:16 2003)
SWImageVersion (2) - build date V1.5.0.8-0 (Thu Mar 13 21:27:06 2003)
ActiveConfiguration default
ActiveSWImage 2
AdminState Online
AdminModeActive True
BeaconOnStatus False
OperationalState Online
PrincipalSwitchRole False

16 Fibre Channel Switch 16 April, 2003
BoardTemp (1) - Degrees Celsius 22
BoardTemp (2) - Degrees Celsius 27
SwitchDiagnosticsStatus Passed
SwitchTemperatureStatus Normal
3. If the correct firmware version is loaded but not active, use the fallback command
to make it active.
4. If the correct firmware version is not loaded, refer to the SANbox2 Fibre Channel
Switch Installer’s/User’s Manual information on how to install firmware.
Port and switch configuration
You must ensure that all the Fibre Channel ports are correctly configured for
operation with Grass Valley equipment. With these settings, you can use any port in
a SCSI or IP fabric without any further configuration.
1. In administrator mode type the following command at the prompt to enter the
configuration mode:
sb5_8port (admin) #> config edit
2. In configuration mode, type the following command at the prompt to view the
configuration of all the ports on the switch.
sb5_8port (admin-config) #> set config ports
3. Modify the settings as needed. The following example shows the required settings.
A list of attributes with formatting and current values for the port
specified at the command line or port #0 will follow.
Each value that is changed will be set for ALL PORTS.
If you wish to terminate this process before reaching the end of the
list press 'q' or 'Q' and the ENTER key to do so.
Configuring ALL ports (displaying values from port number: 0)
----------------------------------------------------------
AdminState (1=Online, 2=Offline, 3=Diagnostics, 4=Down) [Online]
LinkSpeed (1=1Gb/s, 2=2Gb/s, 3=Auto) [Auto]
PortType (TL / GL / G / F / FL / Donor) [GL]
TLPortMode (1=TLTargetMode, 2=TLInitiatorMode) [TLTargetMode]
ISLSecurity (Any / Ours / None) [Any]
ALFairness (True / False) [False]
ARB_FF (True / False) [False]
InteropCredit (decimal value, 0-255) [0]
ExtCredit (dec value, increments of 11, non-loop only) [0]
FANEnable (True / False) [True]
LCFEnable (True / False) [False]
MFSEnable (True / False) [True]
MFS_TOV (decimal value, 10-20480 msec) [10]
MSEnable (True / False) [True]
NoClose (True / False) [False]

Configuring your Fibre Channel switch
16 April, 2003 Fibre Channel Switch 17
IOStreamGuard (Enable / Disable) [Disabled]
VIEnable (True / False) [False]
CheckAlps (True / False) [False]
Finished configuring attributes.
This configuration must be saved (see config save command) and
activated (see config activate command) before it can take effect.
To discard this configuration use the config cancel command.
4. In configuration mode, typethe followingcommand at the promptconfigure global
switch settings:
sb5_8port (admin-config) #> set config switch
5. Type the following command to configure advanced settings:
sb5_8port (admin-config) #> set advanced on
6. Modify the settings as needed. The following example shows the required settings.
Pay particular attention to the Multiframe Sequencing Mode (sometimes called
Tachyon Mode) MFSMode setting, which must be Hard.
NOTE: Each QLogic SANbox2Switch must have a unique DomainID for the local
fabric. You should specify these values individually for each switch and not
allowing the switches to select their own DomainID values. Setting DomainIDLock
to True prevents the switch from changing the DomainID when a new switch is
added to fabric.
A list of attributes with formatting and current values will follow. Enter a
new value or simply press the ENTER key to accept the current value. If you
wish to terminate this process before reaching the end of the list
press 'q' or 'Q' and the ENTER key to do so.
AdminState (1=Online, 2=Offline, 3=Diagnostics) [Online]
BroadcastEnabled (True / False) [True]
InbandEnabled (True / False) [True]
DefaultDomainID (decimal value, 1-239) [100]
DomainIDLock (True / False) [True]
SymbolicName (string, max=32 chars) [sb5_8port]
R_T_TOV (decimal value, 1-1000 msec) [100]
R_A_TOV (decimal value, 100-100000 msec) [2000]
E_D_TOV (decimal value, 10-20000 msec) [1000]
FS_TOV (decimal value, 100-100000 msec) [5000]
DS_TOV (decimal value, 100-100000 msec) [5000]
MFSMode (Hard / Soft) [Hard]
PrincipalPriority (decimal value, 1-255) [254]
ConfigDescription (string, max=64 chars) [SANbox2-8 FC Switch]
Finished configuring attributes.
This configuration must be saved (see config save command) and
activated (see config activate command) before it can take effect.

18 Fibre Channel Switch 16 April, 2003
To discard this configuration use the config cancel command.
7. Type the following command to save your configuration.
sb5_8port (admin-config) #> config save
8. Type the following command to activate your configuration.
sb5_8port (admin-config) #> config activate
9. Type the following commands to view the threshold advanced settings:
sb2_16port #> admin start
sb2_16port (admin) #> config edit
sb2_16port (admin-config) #> set config threshold
10.Verify that the ThesholdMonitoringEnabled setting is False, or modify it if needed.
A list of attributes with formatting and current values will follow.
Enter a new value or simply press the ENTER key to accept the current value.
If you wish to terminate this process before reaching the end of the list
press 'q' or 'Q' and the ENTER key to do so.
ThresholdMonitoringEnabled (True / False) [True] False
q
Finished configuring attributes.
This configuration must be saved (see config save command) and
activated (see config activate command) before it can take effect.
To discard this configuration use the config cancel command.
11.Save and activate the configuration with the following commands:
sb2_16port (admin-config) #> config save
sb2_16port (admin) #> config act
12.Confirm activation of the configuration when prompted.
You must make various SNMP settings so that you can monitor your switch with
NetCentral. Referto “Monitoringyour switch with NetCentral” on page 20 for SNMP
configuration information.
If you are installing your QLogic SANbox2 Switch in a Grass Valley Media Area
Network, refer to the Media Area Network Instruction Manual for specific
configuration information.

Connecting devices to the switch
16 April, 2003 Fibre Channel Switch 19
Connecting devices to the switch
Follow the instructions in the SANbox2 Fibre Channel Switch Installer’s/User’s
Manual to connect your Profile systems and other devices to the Fibre Channel
switch. You should also take note of the following guidelines when setting up your
fabric environment.
Cable lengths
Use the appropriate cable types and GBICs (Gigabit Interface Converters) or SFPs
(Small Form-factor Pluggable Transceiver) for the length of your Fibre Channel
connections. In general, distances under 5 meters can be connected with copper
cables. Distances from 5 to 500 meters require the use of fiber-optic cable.
Fabric topology
Your choices in switch interconnections can greatly affect the cost, redundancy, and
throughput of your Fibre Channel fabric. The number and connection strategy of
inter-switch links defines your fabric’s capabilities.
Refer to the SANbox2 Fibre Channel Switch Installer’s/User’s Manual for detailed
information on fabric topology.
NOTE: You must not connect a Fibre Channel Arbitrated Loop to a Fibre Channel
Switch port. Grass Valley does not support loops in a fabric environment.
Compatible Fibre Channel Devices
The QLogic SANbox2 Switch has been qualified for operation with the following
devices.
• Profile XP Media Platform (Video Network and Media Area Network)
• Profile PDR Video Server (Video Network)
• PFC500 RAID storage
• PFR500 RAID storage
• NewsEdit Digital News Production system
• SANValley Video Gateway
• SGI Origin server
• Avid Newscutter
The QLogic SANbox2 Switch has not been qualified for operation with the following
devices. Do not connect them to a QLogic SANbox2 Switch.
• Brocade Fibre Channel Switch
• Profile PDR100 Professional Disk Recorder

20 Fibre Channel Switch 16 April, 2003
Monitoring your switch with NetCentral
You can use NetCentral, a Grass Valley SNMP Manager, to monitor the state of your
Fibre Channel switch. The information presented in NetCentral allows you to verify
the normal operation of yourswitch and to detect any problems that may occur. If you
set one or more appropriate SNMP trap destination addresses on your switch, you can
also be alerted immediately when problems occur on the switch.
The following sections describe how to configure your switch for operation with
NetCentral, and provide a brief guide on how to troubleshoot switch problems using
NetCentral. Please refer to the NetCentral User Guide for information on how to
install and use NetCentral.
