GRAUPNER GR-12L HoTT User manual

EN
No. S1012
6 channel 2.4 GHz HoTT receiver
GR-12L HoTT
Manual
Copyright © Graupner/SJ GmbH
Copyright © Graupner

2 / 20 S1012_GR-12L_DE_V1sh

3 / 20
S1012_GR-12L_DE_V1sh
Index
IntrŽĚƵĐƟŽŶ ......................................................................................4
Service centre ...................................................................................4
Intended use.....................................................................................5
Target group....................................................................................5
Package content................................................................................5
Technical data ...................................................................................6
S1012 GR-12L HoTT........................................................................6
ŽŶŶĞĐƟŽŶtable ............................................................................6
Symbol descripƟŽŶ...........................................................................7
Safety notes ......................................................................................7
For your safety by handling the transmiƩer and the receiver.......8
For your safety by handling the baƩeries ......................................8
InstallaƟŽŶ ........................................................................................9
ŽŶŶĞĐƟŽŶƐ ......................................................................................9
Power supply.................................................................................10
Binding.............................................................................................10
Receiver reset...............................................................................11
SeƫŶŐĂŶĚĚŝƐƉůay of the receiver seƫŶŐƐ..................................12
Display "RECEIVER".......................................................................12
Display "MIXER"............................................................................14
Display "CH REVERSE"...................................................................15
Firmware update ............................................................................16
SIMPLIFIED DECLARATION OF CONFORMITY................................18
Manufacturer................................................................................18
Notes on environmental protĞĐƟŽŶ..............................................19
Care and maintenance ...................................................................19
Warranty cŽŶĚŝƟŽŶƐ.......................................................................19

Graupner in Internet For the service centes outside the avobe countries plese refer to
our website www.graupner.com
Deutschland, Österreich, Niederlande
D-Power Modellbau
Sürther Straße 92-94
50996 Köln
Deutschland
www.d-power-modellbau.com
France
Fresh RC
ĞŶƚƌĞϭϱZƵĞDĂƌƟŶ>ƵƚŚĞƌ<ŝŶŐϯϴϰϬϬ^ĂŝŶƚͲDĂƌƟŶͲĚΖ,ğƌĞƐ
FRANCE
ǁǁǁŇĂƐŚƌĐĐŽŵ
Italia
:ŽŶĂƚŚĂŶ^Z>
sŝĂĚĞůůΖ/ŶĚƵƐƚƌŝĂϭϬϮϬϯϮ&ĂƌĂŝŶ^ĂďŝŶĂͲWĂƐƐŽŽƌĞƐĞ;Z/Ϳ/ƚĂůLJ
www.jonathan.it
Robbe Modellsport
Industriestraße 10
4565 Inzersdorf im Kremstal
Österreich
www.robbe.com
4 / 20 S1012_GR-12L_DE_V1sh
IntrŽĚƵĐƟŽŶ
Thank you very much for purchasing a Graupner S1012 GR-12L
receiver.
ReadthismanualcarefullytoachievethebestresultswithyourHoTT
systemandĮrstofalltosafelycontrolyourmodels.Ifyouexperience
any trouble during operaƟŽŶ take the insƚƌƵĐƟŽŶƐ to help or ask
your dealer or Graupner Service Centre.
Due to technical changes, the informaƟŽŶ may be changed in this
manualwithoutpriorŶŽƟĐĞ Bealwaysupdatedbycheckingperiod-
icallyonourwebsite,www.graupner.com to bealwaysuptodatew-
ith the prŽĚƵĐƚƐĂŶĚĮƌmwares.
This product complies with naƟŽŶĂů and European legal require-
ments.
To maintain this cŽŶĚŝƟŽŶ and to ensure safe operaƟŽŶ you must
read and follow this user manual and all the safety notes before
usingtheproductandyouhavetorespectthosenotesalsoforfuture
use!
Note
This manual is part of that product. It contains important informa-
ƟŽŶ concerningoperaƟŽŶ andhandling.KeeptheseinsƚƌƵĐƟŽŶƐ for
future reference and give it to third person in case you gave the
product.
Service centre

5 / 20
S1012_GR-12L_DE_V1sh
Intended use ThereceiveronlybeusedforthepurposeƐƉĞĐŝĮĞĚ bythemanufac-
turer for operaƟŽŶ of remote control models without passengers.
Any other type of use is impermissible and may damage the system
and cause ƐŝŐŶŝĮcant property damage and/or personal injury. No
warranty or liability is therefore oīered for any improper use not
covered by these provisions.
/ŶĂĚĚŝƟŽŶ it is explicitly pointed out that you must inform yourself
aboutthelawsandregulaƟŽŶƐ applicableatyourrĞƐƉĞĐƟvestĂƌƟŶŐ
point before stĂƌƟŶŐ the remote control operaƟŽŶ Such cŽŶĚŝƟŽŶƐ
may diīer from state to state, but this must be followed in every
case.
Note
ReadthroughthisenƟremanualbeforeyouaƩempttoinstalloruse
the transmiƩer.
Target group The item is not a toy. It is not suitable for children under 14. The
installaƟŽŶ and operaƟŽŶ of the receiver must be performed by
experienced modellers. If you do not have suĸĐŝĞnt knowledge
aboutdealingwithradio-controlledmodels,pleasecontactanexpe-
rienced modeler or a model club.
Package content
ͻReceiver S1012 GR-12L HoTT
ͻManual

6 / 20 S1012_GR-12L_DE_V1sh
Technical data
^ϭϬϭϮ'ZͲϭϮ>,ŽTT
Antenna 1 x wire 145 mm
of which Antenna 30 mm
OperaƟŶŐvoltage (2.5) 3.6 ... 8.4V
Frequency range 2400 ... 2483.5 MHz
ModulaƟŽŶ 2.4GHz FHSS
Number of controls 6
Current consumpƟŽŶĂƉƉrox. 70mAh
Temperature range -15 … +70°C
Dimensions approx. 36 x 21 x 10mm
Weight approx. 7g
ŽŶŶĞĐƟŽŶtable
CH 5 SERVO and updates / SENSOR / BATT-V
CH6 SERVO / SUMD / SBUS / SP2048

7 / 20
S1012_GR-12L_DE_V1sh
Symbol descripƟŽŶ
Always observe the informaƟŽŶ indicated by these warning signs.
PĂƌƟĐƵůĂƌůLJ those which are ĂĚĚŝƟŽŶĂůůLJ marked with the words
CAUTION or WARNING.
!
ThesignalwordWARNINGindicatesthepotenƟĂů forseriousinjury,
the signal word CAUTION indicates possibility of lighter injuries.
The signal word Note indicates potenƟĂůŵĂůĨƵŶĐƟŽŶƐ
AƩenƟŽŶ indicates potenƟĂůĚĂŵĂges to objects.
Safety notes
!
These safety insƚƌƵĐƟŽŶƐ are intended not only to protect the prod-
uct,butalsoforyourownandotherpeople’ssafety.Thereforeplease
rĞĂĚƚŚŝƐƐĞĐƟŽŶvery carefully before using the product!
ͻDonotleavethepackagingmateriallyingaround,thiscouldbea
dangerous toy for children.
ͻPersons, including children, with reduced physical, sensory or
mental cĂƉĂďŝůŝƟĞƐ or lack of experience or knowledge, or not
capabletousesafelythereceivermustnotusethereceiverwith-
out supervision or insƚƌƵĐƟŽŶby a responsible person.
ͻOperaƟŽŶ anduseofradio-controlledmodelsneedstobelearnt!
If you have never driven such a model, then start extra carefully
and make sure to be familiar with the rĞĂĐƟŽŶƐ of the model to
the remote control commands. Proceed responsibly.
ͻFirst,alwaysperformarangeandĨƵŶĐƟŽŶ testontheground(to
doso,holdyourmodelƟŐht),beforeyouuseyourmodel.Repeat
the test with running motor and with short throƩůĞďƵrsts.
ͻOnly use the components and spare parts that we recommend.
Always use matching, original Graupner plug-in cŽŶŶĞĐƟŽŶƐ of
the same design and material.
ͻMakesurethatalloftheplug-incŽŶŶĞĐƟŽŶƐ areƟŐht.Whendis-
cŽŶŶĞĐƟŶŐƚŚĞƉůƵŐͲŝŶcŽŶŶĞĐƟŽŶƐĚŽŶŽƚƉƵůůƚŚĞcables.
ͻProtect the receiver from dust, dirt, moisture and foreign parts.
It must be protected from vibraƟŽŶ as well as excessive heat or
cold. The models may only be operated remotely in normal out-
side temperatures such as from-10°C to +55°C.
ͻAlways use all your HoTT components only with the latest Įƌŵ-
ware version.
ͻIf you have quesƟŽŶƐ which cannot be answered by the operat-
ing manual, please contact us or another edžƉĞƌƚŝŶƚŚĞĮĞůĚ

8 / 20 S1012_GR-12L_DE_V1sh
For your safety by handling the transmiƩer and the receiver
!
WARNING
Also while programming the transmiƩer, make sure that a con-
nected motor cannot accidentally start. Disconnect the fuel sup-
ply or drive baƩery beforehand.
!
CAUTION
Avoid every kind of short-circuit in all sockets of the transmiƩer!
Risk of Įre! Use only the suitable connectors. In no case the elec-
tronic component of the transmiƩer or of the receiver may be
changedorŵŽĚŝĮĞĚ Duetolicensingreasons,anyreconsƚƌƵĐƟŽŶ
and/ŽƌŵŽĚŝĮcaƟŽŶŽĨƚŚĞƉroduct is prohibited.
Note
During transport protect the model and the transmiƩer from dam-
ages.
For your safety by handling the baƩeries
!
CAUTION
ͻProtect the baƩeries from dust, dirt, moisture, heat and vibra-
ƟŽŶƐKŶůLJƵƐĞŝŶĚry locaƟŽŶƐ
ͻDo not use any damaged baƩery.
ͻBaƩeries may not be heated, burned, short-circuited.
ͻIf handled improperly, there is a danger of Įre, explosion, irri-
taƟŽŶĂŶĚďƵƌŶƐ
ͻLeaked electrolyte is causƟĐ and should not be touched or
come into contact with your eyes. In case of emergency, rinse
with a large quanƟƚLJŽĨwater and consult a Med. Doctor.
ͻStock the baƩeries in dry and fresh cŽŶĚŝƟŽŶƐ
ͻDispose of the baƩery in the proper disposal centers.

9 / 20
S1012_GR-12L_DE_V1sh
InstallaƟŽŶ
The receiver must be protected against dust, exhaust gases, splash
water, etc. in the model. When you install your receiver, make sure
thatitisnotexcessivelyĂŝƌƟŐhttopreventitfromoverheaƟŶŐ during
operaƟŽŶ
Servo cables may not be wound around antennas or run next to
them. Make sure that the cables cannot ƐŚŝŌ to lie directly adjacent
to antĞŶŶĂƐĚƵƌŝŶŐŇŝŐht.
In the case of carbon Įďre fuselage, at least the last 35 mm of the
antennas shall be routed from the fuselage.
ŽŶŶĞĐƟŽŶƐ
Connectthedevicesthathavetobeconnectedtothereceivertothe
row of sockets on one end of the receiver. The servo cŽŶŶĞĐƟŽŶƐ of
the Graupner-HoTT receiver are numbered.
The polarity of the plug-in system cannot be reversed. Do not apply
force.
Note
Forthe'ZͲϭϮ> HoTTreceiver,inserttheconnectorswiththebrown
or black cable upwards.

10 / 20 S1012_GR-12L_DE_V1sh
Power supply In principle, a baƩery can be connected to any free socket. By V- or
Y-cable also with any remote control component. If the power sup-
ply is provided by more than one baƩery, it is important to ensure
thatthebaƩerieshavethesamenominalvoltageandratedcapacity.
It is not allowed to connect diīerent baƩery types or rechargeable
baƩeries with too diīerent charge states to the receiver, as short-
circuit-like eīects can occur. For safety reasons, voltage stabilizers
such as PRX-5A receiver power supplies (No. 4136) should be con-
nected between baƩeries and receiver.
AƩenƟŽŶ
When ƐĞůĞĐƟŶŐ and cŽŶŶĞĐƟŶŐ a power supply, be aware that
althoughtheoperaƟŶŐ rangeof thereceiverrangesfromϯϲ to8.4
V. However, prĂĐƟcallyallofthe previouslymarketedservos,speed
controllers,gyros,etc.aswellasmanywhichareoīeredtodayhave
a permissible operaƟŶŐvoltage range of 4.8 to 6 V.
Binding To establish a cŽŶŶĞĐƟŽŶ with the transmiƩer, the Graupner HoTT
receivermustĮrstbe"bound"toatleastonemodelmemoryin"its"
Graupner HoTT transmiƩer. This process is generally called "bind-
ing".
Binding step-by-step
1. Prepare the transmiƩer to be bound according to its insƚƌƵĐƟŽŶƐ
for binding.
2. Switch on the receiver power supply.
The LED of a GR-12L HoTT receiver lights up red.
3. Press and hold the SET buƩon on the receiver unƟů the LED starts
tŽŇĂƐŚfor about 3 seconds aŌer approx. 3 seconds.
ƵƌŝŶŐƚŚŝƐƟŵĞůĂpse, the receiver is in bind mode.
4. Within this ƟŵĞ lapse start the transmiƩer-side binding accord-
ing to the insƚƌƵĐƟŽŶƐŽĨƚŚĞƚƌĂŶƐŵŝƩer.
5. If the red LED of the GR-12L HoTT receiver goes out, the binding
process has been completed successfully.
Your transmiƩer/receiver cŽŵďŝŶĂƟŽŶŝƐƌĞĂĚLJfŽƌŽƉĞƌĂƟŽŶ

11 / 20
S1012_GR-12L_DE_V1sh
If the red LED of the GR-12L HoTT lights up again constantly, the
"Binding" has failed. Change the ƉŽƐŝƟŽŶƐ of the associated
antennas and try the enƟƌĞƉƌŽcedure again.
Receiver reset To reset the receiver, press and hold its SET buƩon while turning on
the power to the receiver:
If the reset was triggered with the transmiƩer switched oīor with
anunboundreceiver,theredLEDofthereceiverGR-12LHoTT starts
tŽŇĂƐŚaŌer about 3 seconds. The buƩon will now be released.
If the reset is performed with a not bound receiver, you can then
start a binding process at anLJƟŵĞ
If a reset has already been performed on an already-bound receiver
andtheassociatedmodelmemoryisĂĐƟveintheswitched-ontrans-
miƩer, then the red LED of the receiver GR-12L HoTT should go out
and thus signal a correct cŽŶŶĞĐƟŽŶ to the transmiƩer. Otherwise
the process has to be repeated.
Notes
ͻThrough a RESET >> of the seƫŶŐƐ in the receiver are brought
to the factory seƫŶŐƐ with the excepƟŽŶ of the HoTT synchro-
nizaƟŽŶŝnformaƟŽŶ
ͻIf a reset is performed accidentally, all of these seƫŶŐƐ that
were made using the "Telemetry" menu in the receiver should
be restored.
ͻReseƫŶŐ is ƉĂƌƟĐƵůĂƌůLJ recommendable when you want to
switchareceivertoadiīerentmodel.Thismakesiteasytokeep
seƫŶŐƐǁŚŝĐŚĚŽŶŽƚŵatch from being transferred.

12 / 20 S1012_GR-12L_DE_V1sh
SeƫŶŐĂŶĚĚŝƐƉůay of the receiver seƫŶŐƐ
The receiver-side menus can be viewed and someƟŵĞƐ changed
using a suitable HoTT transmiƩer or the SMART-BOX. You can ĮŶĚ
out how to open the menus of a receiver in the "Telemetry" ƐĞĐƟŽŶ
ofthecorrespondingmanual aswell as a detaileddescripƟŽŶ ofthe
receiver menus on the rĞƐƉĞĐƟve product page at www.graupner.
com on the Internet.
Note
Thevaluesshown in the followingdisplayillustraƟŽŶƐ always show
the standard values.
Display "RECEIVER"
>ZDVO>T
ͻIf "SERVO" or "SENSOR" is visible in the "CH5 FUNCTION" line
described below, the operaƟŶŐ voltage of the receiver is moni-
tored via the limit value set in the vĂůƵĞĮĞůĚŽĨΗ>ZDVOLT".
ͻIf"BATT-V"isvisibleinthe"CH5FUNCTION"linedescribedbelow,
theoperaƟŶŐ voltageofthedrivebaƩeryconnectedvia"BATT-V"
is monitored via the limit value set in the value ĮĞůĚ of "ALARM
VOLT".
Inbothcases,theactualvoltageisshowninthetransmiƩĞƌΖƐ display
in the "Receiver voltagĞΗĮĞůĚ
If the voltage drops under the set limit value, a transmiƩer-side
alarmtakesplaceintheformofanacousƟĐ signal(intervalbeeplong
/ short).
Adjustment range: 2,5 … 22,5 Volt in 0,1 Volt steps.
>ZDdDW
This opƟŽŶ monitors the receiver temperature. If the set limit is
exceeded, a transmiƩer-side alarm takes place in the form of a con-
ƟŶƵŽƵƐďĞĞƉ
Adjustment range: 30 … 80°C
PERIOD
Inthisline,specifytheperiodsfortheindividualchannelpulses.This
seƫŶŐŝƐƚransferred for all control channels.
If your system is used exclusively with digital servos, you can set a
cycle ƟŵĞ (frame rate) of 10 ms. If your system includes some or
usesexclusivelyanalogue servos,alwaysselect20 ms since theana-
logueservosmaybeoverloadedandrespondby"jiƩering"or"growl-
ing".
Adjustment range: 10 or 20ms
{lsltl{y
zl{{punGMGkh{hG}pl~
zluzvy
kpzwshGymGz{h{|z
zlslj{Ghuuv|ujl
yGkh{hGGGGGGGvu
hshytGzl{{pun
Gyljlp}lyGGGYUW\
hshytG{ltwaGGGGG]\¶j
hshytG}vs{aGGGGGZU^}
jo\Gm|uj{pvuazly}v
wlypvkaGGGGGGGGGYW
yzzpGjoGaGGGGvmm
jo]Gm|uj{pvuazly}v
mUylzl{GaGGGGGu

13 / 20
S1012_GR-12L_DE_V1sh
CH5 FUNCTION
ͻSERVO
Port"5"issuitableforoperaƟŶŐ RCcomponentsandforreceiver
updates.
ͻSENSOR
Port 5 is suitable for the operaƟŽŶŽĨtelemetry sensors.
ͻBATT V
AŌerswitchingasdescribedbefore,aDCvoltageoīmax.25,5V
can be displayed instead of the receiver voltage. This way it is
possibletomonitorthemainbaƩeryvoltagewithoutusingexter-
nal sensors. The ESCs S3082 and S3083 have this switch already
included.
s + –
50 mm
100nF
2k7Ω
22kΩ
max. 25,5 V =
100 mm –
+
Attention
Never connect a power supply with an output voltage higher than
8,4VdirectlytoacŽŶŶĞĐƟŽŶ portofthe receiver!Thereceiverand
all connected devices would be immediately destroyed.
CH6 FUNCTION
ͻSERVO
ThecŽŶŶĞĐƟŽŶ 5issuitablefortheoperaƟŽŶ ofRCcomponents.
ͻSUMD
At cŽŶŶĞĐƟŽŶϱĂĚŝŐŝtal sum signal is provided.
ͻSBUS
Digital sum signal in SBUS format.
ͻSP2018 .rtkepSeht,lortnocthgilfagnitcennocrofelbatiussi6tropehT
2048 signal can handle. e.g. 48377.
RSSI CH
As soon as "SUMD", "SBUS" or "SP2048" is selected instead of
"SERVO"inthe"CH6FUNCTION"linedescribedabove,changingthe
valueĮĞůĚ of thisopƟŽŶ from "OFF" to "CHxx" will change the num-
ber of channels contained in the selected sum signal. At the same
ƟŵĞ the servo signal of the highest numbered channel is replaced
by an RSSI signal.

14 / 20 S1012_GR-12L_DE_V1sh
With this RSSI signal and a ŇŝŐht control board with OSD, e.g. No.
48377, the signal strength of the receiver can be displayed in video
goggles or monitors.
Adjustment range: OFF, CH8, CH12, CH16
F.RESET
AŌer changing the value ĮĞůĚ to "Yes" and then pressing or tapping
on the ENT key, or equivalent, a factory reset of the receiver is per-
formed.
Display "MIXER"
GyGmyllGtply
thz{lyGjoaGGGGGGGGGW
zsh}lGjoaGGGGGGGGGGW
{yh}lsˀaGGGGGGGGXWWL
{yh}lsRaGGGGGGGGXWWL
tplyaGGGGGGGGGGGGGX
{yptaGGGGGGGGGGGGGWL
Up tŽĮve mixers can be programmed in the receiver.
MIXER
In the "MIXER" line, select one of mixers 1 … 5.
ThefollowingseƫŶŐƐ inthisdisplayonlyrelatetothemixersselected
in the "MIXER" line.
MASTER CH
In this line the MASTER CH (signal source or source channel) has to
be selected.
^ĞůĞĐƟŽŶrange: (CH)1 … (CH)6
If no mixer has to be set, select "0".
^>AVE CH
In this line, select the SLAVE CH (signal source or source channel) to
which the signal of the MASTER CH (source channel) is prŽƉŽƌƟŽŶ-
ally mixed.
The level of mixing is determined by the percentages entered in the
"TRAVEL–" and "TRAVEL+" lines.
^ĞůĞĐƟŽŶrange: (CH)1 … (CH)6
If no mixer has to be set, select "0".
TRIM
Analogous to the trimming of the control ĨƵŶĐƟŽŶƐ 1 ... 4, the neu-
tral ƉŽƐŝƟŽŶ of the mixer in the range of ± 30% can be trimmed in
this line.
TRAs>ʹн
With the seƫŶŐƐ of these two lines, the percentage of mixing is
ƐƉĞĐŝĮĞĚ in relaƟŽŶ to the MASTER signal separately for both direc-
ƟŽŶƐ

15 / 20
S1012_GR-12L_DE_V1sh
Display "CH REVERSE"
GjoGyl}lyzl
joYGaGGGGGGGGGu
joZGaGGGGGGGGGu
jo\GaGGGGGGGGGu
jo]GaGGGGGGGGGu
joXGaGGGGGGGGGu
jo[GaGGGGGGGGGu
In this display, the dirĞĐƟŽŶ of rotaƟŽŶ of each of the servos con-
nected to the receiver outputs 1 ... 6 can be set individually: select
the desired line; press or tap on the ENTER key or equivalent, then
changetheseƫŶŐ valuefrom"Normal"to"Reverse"orviceversain
ƚŚĞĂĐƟve vĂůƵĞĮĞůĚ

16 / 20 S1012_GR-12L_DE_V1sh
Firmware update Firmware updates of the receiver are performed via the telemetry
portofthereceiverusingaPCrunningWindows7...10.Youwillalso
need a USB interface, No. 7168.6, and adapter lead, No. 7168.6A or
7168.S, which are available separately.
The programs and ĮůĞƐ required can be found in the Download area
for the corresponding products at www.graupner.com.
Connect the adapter lead to the USB interface. The polarity of the
plug-in system cannot be reversed. Note the small chamfers on the
sides. Do not use force, the plug should click into place easily.
Connect the other end of the adapter lead to the socket of the
receiverGR-12LHoTTlabelledwith"-+5T".Thepolarityoftheplug-in
system cannot be reversed. Do not apply force. The plug should be
fully inserted.
InĂĚĚŝƟŽŶ thiscŽŶŶĞĐƟŽŶ hastobesetto"SERVO"fortheduraƟŽŶ
of the update process.
The update is carried out via the "HoTT device" program ƐĞĐƟŽŶ of
the program "Firmware_Upgrade_gr_Studio". Please follow the
notes of the ƐŽŌware. The further procedure is also described in
detail in the manual contained in the data package. You can also
download these from the download page of the product at
www.graupner.com.

17 / 20
S1012_GR-12L_DE_V1sh

18 / 20 S1012_GR-12L_DE_V1sh
D-Power Modellbau
Inhaber: Horst Derkum
Sürther Straße 92-94
50996 Köln
Deutschland
www.d-power-modellbau.com
Robbe Modellsport
'ĞƐĐŚćŌƐĨƺŚƌĞƌDĂƩŚĞǁtŚŝƚĞ
Industriestraße 10
4565 Inzersdorf im Kremstal
Österreich
www.robbe.com
Vertrieb Deutschland, Österreich, Niederlande
Manufaturer / Manufakturer
GRAUPNER Co. Ltd
Post Code: 14557
202-809, 18, Bucheon-ro 198beon-gil, Bucheon-si,
Gyeonggi-do, South Korea
ĞŶƚƌĞϭϱZƵĞDĂƌƟŶ
Luther King 38400
^ĂŝŶƚͲDĂƌƟŶͲĚΖ,ğƌĞƐ
FRANCE
ǁǁǁŇĂƐŚƌĐĐŽŵ
ŽŶƚĂĐƚƐƵƉƉŽƌƚΛŇĂƐŚƌĐĐŽŵ
Phone : [phone]
France
Flash RC
sŝĂĚĞůůΖ/ŶĚƵƐƚƌŝĂϭ
02032 Fara in Sabina-
Passo Corese (RI) Italy
www.jonathan.it
Contact
ŚƩƉƐƐŚŽƉũŽŶĂƚŚĂŶŝƚŝƚĐŽŶƚĂĐƚ
Italia
Jonathan SRL

19 / 20
S1012_GR-12L_DE_V1sh
Notes on environmental protĞĐƟŽŶ
If this symbol is on the product, insƚƌƵĐƟŽŶƐ for use or packaging, it
indicates that the product may not be disposed with normal house-
holdwaste once it hasreachedthe end ofits servicelife. Itmustbe
turnedovertoarecyclingcŽůůĞĐƟŽŶ pointforelectricandelectronic
apparatus.
Individual markings indicate which materials can be recycled. You
makeanimportantconƚƌŝďƵƟŽŶ toprotĞĐƟŽŶ oftheenvironmentby
ƵƟůŝnjŝŶŐ fĂĐŝůŝƟĞƐ for reuse, material recycling or other means of
edžƉůŽŝƟŶŐŽbsolete equipment.
Care and maintenance The product does not need any maintenance. Always protect it
against dust, dirt and moisture.
Cleantheproductonlywithadrycloth(donotusedetergent!)lightly
rub.
Warranty cŽŶĚŝƟŽŶƐ
grants from the date of purchase of this product for a period of 24
months. The warranty applies only to the material or operaƟŽŶĂů
defects already exisƟŶŐ when you purchased the item. Damage due
tomisuse,wear,overloading,incorrectaccessoriesorimproperhan-
dling are excluded from the guarantee. The legal rights and claims
are not aīected by this guarantee. Please check exactly defects
before a claim or send the product, because we have to ask you to
pay shipping costs if the item is free from defects.
TheseoperaƟŶŐ insƚƌƵĐƟŽnareexclusivelyforinformaƟŽŶ purposes
and are subject to change without prior ŶŽƟĮcaƟŽŶ The current
version can be found on the Internet at www.graupner.com on t-
threlevant product page. In ĂĚĚŝƟŽŶ the company Graupner has
no responsibility or liability for any errors or inaccuracies that may
appear in consƚƌƵĐƟŽŶŽƌŽƉĞraƟŽŶŵĂŶƵĂůƐ
Not liable for prinƟŶŐĞƌrors.
P
