Gravely 5000 Series Manual

PART NUMBERtS): 5000 SERIES
~GRAVEL'l
e NAME: 5000 SERIES TRACTo-R-
SETUP
INSTRUCTIONS
These instructions give the procedure for assembling the 5000Series tractor. All reference to right side, left
side, front and rear are given from the operator's position.
The wheel assemblies are not with the tractor. Get wheel assemblies as needed.
I
41.0
HOW TO TIGHTEN THE BOLTS
Tighten the bolts used to assemble the 5000
Series
tractor to the torque given in the bolt
torque specifications unless shown differently.
1.
Remove the nut and the bolt that fastens the
instrument panel to the support tube on the
right side of the tractor. See figure 2.0-1.
BOL T TORQUE SPECIFICATIONS
BOLT SIZE
FOOT POUNDS NEWTON METERS
(ft. Ibs.) (N.m)
1/4"
79.5
5/16"
14 19
3/8"
25
34
7/16"
40
54
/
e
1/2"
60 82
9/16" 83
113
,
5/8"
120 163
3/4"
200
271
NOTE: The handlebar that has "FWD" and "REV"
on the decal is the right side handlebar.
The handlebar that has the "GEAR
SHIFT" on the decal is the left side
handlebar.
I
{
1
2.0 HOW TO ASSEMBLE THE TRACTOR
A WARNING: Use caution when removing the
straps that hold the tractor to
the pallet.
INOTE:
If the tractor has an electric starter,
remove
the battery. Give service to the
battery as shown in the Battery Service
instructions included with the battery.
2.
3.
1 - Bolt
2 - Instrument Panel
3 -
Support Tube
Figure 2.0-1
Put the handle bar for the right side into the
support tube.
Fasten
the handlebar in position with the
Form No. 31722 (6-79)
To oon"'nu. I". program of qu.llty end d •• lgn
~
mprov.m.nt:, "h. manuf.ctur.r r ••• rv •• "h. right:
cheng •• p.clflca"'on., d •• 'gn •• nd prlc ••
'thou" no"'c. and Incurring obllge"'on.
HP'tt ~.= " UH'ft. r:NT, U,;~C.
4444 Morrison Road Denv r. CO 8::'219
Betwoon Federal and Sheridan
Colorado Toll Freo 1 - 800 -792-3200
Denver Metro Ar a(3 )934- 488
Printed In U.S.A.
BrentChalmers.com

bolt and nut that was removed in step 1. See
figure 2.0-2.
Figure 2.0-2
1 -
Control Rod
2 - Control Lever
3 - Clevis Pin
Figure 2.0-4
4.
5.
Remove the nut and bolt from the support
tube on the left side. Put the other handlebar
into the support and fasten the handlebar in
position with the bolt and nut.
Install
the control rod that is straight on the
control rod extension on the right side. See
figure 2.0-3.
1 -
Control Rod
2 - Control Rod Extension
3 -
Jam Nut
7.
8.
Tighten the jam nut on the control rod ex-
tension against the control rod.
Install
the control rod that has the bend on
the control rod extension on the left side.
See
figure 2.0-5.
1 - Control Rod
2 - Control Rod Extension
'3 - Jam Nu't \
l
Figure 2.0-3
6.
Connect the control rod to the control lever
with the clevis pin. Fasten the clevis pin in
position with the cotter pin. See figure 2.0-4.
)
9.
Figure 2.0-5
-
Connect the control rod to the control lever_
with the clevis pin. Fasten the clevis pin in.
position with the cotter pin. See figure 2.0-6.
BrentChalmers.com

, I
I
1
1 - Control Rod
2 - Control Lever
3 - Clevis Pin
Figure 2.0-6
10. Fasten
the throttle control lever to the
handlebar on the left side with the 10-24 x
1-1/2" machine screws and the 10-24 lock
nuts. See figure 2.0-7.
1-
Throttle Control Lever
2 - Machine Screws
Figure 2.0-7
AWARNING: Connect the battery cable for
the positive "+" terminal first.
13. Check the level of the lubricant in the engine
and the transmission.
14. Adjust the air pressure in the tires to 18 psi
(1.3
kg/cm
2
).
3.0 HOW TO INSTALL THE REMOTE AIR
CLEANER
NOTE: All tractors are not equipped with a
remote air cleaner.
1. Fasten the air cleaner bracket to the
instrument panel with the three 3/8" x 1"
bolts and the 3/8" lock nuts. See figure 3.0-1.
1-
Instrument Panel
2 -
Air Cleaner Bracket
3 - Bolts
Figure 3.0-1
11.
Install the wheel assemblies on the wheel
hubs.
12. If the tractor has an electric starter, install
the battery.
2.
Fasten the air cleaner housing bracket and
the air cleaner support to the air cleaner
bracket with the 3/8" x 1-1/8" bolts and the
3/8" lock nuts. See figure 3.0-2.
BrentChalmers.com

1 - Air Cleaner Housing Bracket
2 -
Air Cleaner Support
3 - Hose
4 -
Air Cleaner Housing
Figure 3.0-2
3. Fasten the air cleaner support to the air
cleaner housing with the four washers and
1/4" lock nut.
4. Fasten the hose to the bottom of the air
cleaner
housing with the hose clamp.
4.0
HOW TO INSTALL THE QUICK HITCH PIN
NOTE: All tractors are not equipped with aquick
hitch pin.
1 -
Quick Hitch Pin
2 -
Attachment Adapter
3 - Bolts
4 - Lock Washers
Figure 4.0-1
5.0
HOW TO ADJUST THE DIRECTION
CONTROL CLUTCH
1. Loosen the jam nuts on each side of the e
actuating lever. See figure 5.0-1.
1 - Jam Nuts
2 - Large
Spring
3 - Actuating Lever
Figure 5.0-1
Fasten
the quick hitch pin to the attachment
adapter with the four 3/8" x 2-1/4" bolts and the
lock washers. See figure 4.0-1.
i
2. Use
your hand to push the actuating leverall
the way
toward the rear.
~.
BrentChalmers.com

3. Adjust the inside jam nut on the front side of
the lever so that the direction control lever
will be 15 degrees beyond the vertical
position. towards the rear of the tractor.
4. Tighten the outside jam nut against the
inside jam nut. Do not move the inside jam
nut.
5. To adjust the forward clutch, push the
direction control lever all the way forward.
Make sure the direction control lever goes
into a holding position.
6. Adjust the inside jam nut until there is a
clearance of .010" (.254 mm) between the
coils of the large spring.
7. Tighten the outside jam nut against the
inside jam nut. Do not move the inside jam
nut.
6.0 HOW TO ADJUST THE GEAR SHIFT
CLUTCH
1. Loosen the jam nuts on each side of the
actuating lever. See figure 6.0-1.
1 -
Jam Nuts
I2 - Springs
3 - Actuating Lever
Figure 6.0-1
2. Push the gear shift lever forward to the
"HIGH" position.
3. Adjust the inside jam nut behind the
actuating lever until there is aclearance of
.010" (.254 mm) between the coils of the
spring.
4. Tighten the outside jam nut against the
inside jam nut. Do not move the inside jam
nut.
5. Pull the gear shift lever backward to the
"LOW" position.
6. Adjust the inside jam nut in front of the
actuating lever until there is a clearance of
.010" (.254 mm) between the coils of the
spring.
7. Tighten the outside jam nut against the
inside jam nut. Do not move the inside jam
nut.
BrentChalmers.com

HUE p~ T, f C.
4444 Morrison Road 0nvcr, CO 00219
B· t "Jeen Federr.>I and She rid .n
Colorado Toll Free 1 - eoo -792-::;::;0
DG. IJ· rMetro Ar (3) 934- 8
