Gravitron GEM5002 User manual

User Manual - Copyright © GRAVITRON LTD 2021
Operation and Maintenance Manual
Swing Boats

Swing Boats
Page 2 of 13
User Manual - Copyright © GRAVITRON LTD 2021
TABLE OF CONTECT
PAGE NO.
SECTION A –Introduction
3
A1 Target Readership
3
A1.1 Controllers
3
A1.2 Operators
3
A1.3 Attendants
3
A2 Scope of this Document
3
A3 Limitations & Disclaimer
3
A4 Revisions & Updates
3
SECTION B –About Gravitron Ltd and Contact Details
4
B1 About GRAVITRON LTD
4
B2 Contact Details
4
B3 Company Details
4
SECTION C –About Gravitron Ltd and Contact Details
5
C1 Product
5
C1.1 Model Name/Number
5
C1.2 Serial Number
5
C1.3 Date of Manufacture
5
C1.4 Technical Specifications
5
SECTION D –Transportation, Construction and Installation.
7
D1 Transport
7
D2 Construction & Installation
7
D3 Dismantling
7
D3.1 Disposal of hazardous materials
7
SECTION E –Operating Instructions (Information on Safe Use)
7
E1 Understanding Gravitron Ltd Swing Boat Ride
7
E1.1 The Boats
7
E1.2 The ride Frame
7
E1.3 The Surrounding Area
7
E2 Notices & Signs
7
E2.1 Signs Displayed at Entrance
7
E2.2 Notices for Users
8-9
E3 Safe Operation of the Swing Boat Ride
10
E3.1 Normal Functioning
10
E3.2 Capacity
10
E3.3 Potentially Dangerous User Behaviour
10
E3.4 Safe Passenger Access
11
E3.5 Safe & Unsafe Operating Practices
11
E3.6 Unsafe Equipment Procedures
11
SECTION F –Maintenance Routines
11
F1 Monthly Maintenance Records
11
F2 Continuous Monitoring
11
F2.1 Swing Boat Assembly
11
F3 Annual Third Party Inspection
11
F4 Daily Maintenance & Cleaning
12
F4.1 Cleaning
12
F4.2 Daily Maintenance
12
SECTION G –Warranty
12-13
G1.1 Date of Commencement of Warranty
13

Swing Boats
Page 3 of 13
User Manual - Copyright © GRAVITRON LTD 2021
SECTION A
Introduction
THESE INSTRUCTIONS ARE A GUIDE FOR OPERATORS WHO MUST SATISFY THEMSELVES AS TO
THE SAFE CONDITION OF ALL EQUIPMENT AT ALL TIMES.
A1 Target Readership
This document is written for Controllers, Operators and Attendants of the Swing Boat Ride.
A copy of this manual must be read by and available to all personnel involved in the running of the
Swing Boat Ride.
A1.1 Controllers
For the purposes of this document Controllers are understood to be people or companies who own or
otherwise have control of the Swing Boat Ride. They will have ultimate responsibility for the safe
running of the Swing Boat Ride, but may only have limited day-to-day input in the running and
operations.
A1.2 Operators
For the purposes of this document Operators are understood to be the people in immediate charge of
the Swing Boat Ride. They have a duty for the safe day-to-day running of the Swing Boat Ride.
A1.3 Attendants
For the purposes of this document Attendants are understood to be people who assist in the
operation of the Swing Boat Ride. They have responsibility for specific aspects the safe day-to-day
running of the Swing Boat Ride. They have a duty to take reasonable care for their own and others’
safety and to follow instructions.
A2 Scope of this Document
This document is an operations manual for use with Swing Boat Ride. It addresses the Operator’s
general responsibilities for the safe day-to-day running and maintenance of the Swing Boat Ride.
This manual also covers the specific operational procedures to be followed by Attendants under the
Operator’s supervision.
A3 Limitations & Disclaimer
This manual contains the policies and procedures governing the safe operation of the Swing Boat
Ride. These guidelines and recommendations are based on GRAVITRON experience and may or
may not be appropriate for every operational situation.
The Controller is solely responsible for setting the policies and procedures needed to operate their
business according to the laws, regulations and customs within the legal jurisdiction of operation.
The Controller is also solely responsible for the effects of these business policies and procedures and
the statements and actions of their employees while in the controllers employ. The Controller should
consult a relevant professional assistance whenever appropriate and the business activities dictate.
A4 Revisions & Updates
From time to time GRAVITRON may find it necessary to supply revisions or updates to this
document. GRAVITRON will endeavour to supply these to the Controller in a timely manner, which is
acceptable to the Controller. To achieve this it is imperative for GRAVITRON to be notified of any
change of contact details.

Swing Boats
Page 4 of 13
User Manual - Copyright © GRAVITRON LTD 2021
SECTION B
about GRAVITRON Ltd & Contact Details
B1 about GRAVITRON Ltd
GRAVITRON are experienced in the design and manufacture of electric vehicles, rides, drive systems
and attractions for the leisure, service and automotive industries and provide a complete service from
initial inception to final installation and commissioning of a project.
B2 Contact Details
Support & Information
Tel: [phone]
Email: [e-mail]
B3 Company Details
Gravitron is a trading name of GRAVITRON Ltd
Unit 5 & 6 Monkton House Business Park
Walrow Road
Highbridge
Somerset
TA9 4QY
VAT No: 104 633 60

Swing Boats
Page 5 of 13
User Manual - Copyright © GRAVITRON LTD 2021
SECTION C
About the Swing Boat Ride
C1 Product
Little Gems - Swing Boat Ride
C1.1 Model Name/Number
Traditional Swing Boat Ride
GEM5002
C1.2 Serial Number G5002 –BU-071013-01
C1.3 Date of Manufacture
February 2014
C1.4 Technical Specifications
a) General
Materials
Frame
Steel box section 100mm x 50mm x 3mm
Boat sides
PE300 Plastic 25mm
Boat base
Perforated steel sheet 3mm
Seat
Perforated steel sheet 3mm
Mounting step
aluminium
Boat support stays
12mm steel bar
Overall Dimensions
Base Length
4.25 M
Base Width (static)
3.00M
Base Width (operational)
5.00M
Height
3.05 M
Weight (Main Structure)
428kg
Finishes & Colours
A Frame Main Frame
Powder coated Red
A Frame cross braces
Powder coated Yellow
Boat: sides
PE300 Yellow

Swing Boats
Page 6 of 13
User Manual - Copyright © GRAVITRON LTD 2021
Boat: base and seat
Powder coated Red
Steps
Powder coated Red
Boat support stays
Powder coated Red
b) The Ride
The ride is a traditionally styled 4 boat swing boat ride designed to accommodate a maximum
of one adult and one child per boat in the seated position. Modern materials have been used
to create a safer, stronger and more durable product.
Specification
No. of Boats
4 (Four)
Description
Four boat swing boat ride.
Maximum number of users at any one time
8 (Eight)
Maximum Boat loading
One adult and one child (approx.: 180kg)
c) Outer Railing Recommendation
Outer Railings are not supplied by GRAVITRON Ltd
The outer railings should be designed to manage the flow of people through the ride and
control the queuing. Consideration should be given to marshalling area for embarking and
disembarking from the swing boats and procedures to avoid swing boats in motion during
these procedures
Specification
Design
NA
Service gate
NA
Construction
NA
Dimensions
Height
NA
Total length of railings
NA
Maximum aperture between bars
NA

Swing Boats
Page 7 of 13
User Manual - Copyright © GRAVITRON LTD 2021
SECTION D
Transport, Construction, Installation & Dismantling
D1 Transport
This ride can be transported to other locations.
D2 Construction & Installation
GRAVITRON Ltd is contracted to provide a full construction and installation service for this ride (omitting the
outer rails/queuing system)
D3 Dismantling
The dismantling and reassembly of this attraction is not recommended. GRAVITRON should be
commissioned to relocate the ride if required.
When the attraction has reached the end of its lifespan and must be removed GRAVITRON recommends
responsible disposal and/or recycling of all component materials. Appropriate checks should be made with the
local authority’s environmental department.
D4 Disposal of hazardous materials
It is the duty of the Controller to ensure that any hazardous substances are disposed of in accordance with the
laws, regulations and customs of the appropriate legal jurisdiction.
SECTION E
Operating Instructions (Information on Safe Use)
E1 Understanding the Operating Procedure
To understand how best to operate the Swing Boats it is necessary to have an overview of the different
components that make up the attraction. The Swing Boats ride is made up of the following:
E1.1 the Boats
There are 4 Swing Boats each with the capacity to take one adult and one child seated facing towards each
other. Access to the boats in the static position is by a single step situated to the side of the Swing Boat.
E1.2 the Ride Frame
The 4 boats are supported and hung from a metal ‘A’ frame assembly that is securely bolted to the concrete
base of the ride area.
E1.3 surrounding area
The Swing Boat ride is designed to be surrounded by a ‘Pickett’ style fence which is positioned in such a
manner that any person or persons in the vicinity are unable to come into contact with the swing boats in
operation.
The Swing Boat ride has a foot print area of 3M x 4.25M in the static mode and 5M x 4.25M in the full
operational mode.
It is recommended that the ‘Pickett’ style fencing be positioned a minimum distance of 2M at any point from
the Swing Boat operational area. It is essential that the ‘Pickett’ fence is of a substantial design so as to be
able to withstand persons falling against it without collapsing.
E2 Notices & Signs
There should be signs placed in appropriate positions to enable all staff, riders and spectators to observe the
rules and procedures of the safe operation of the Swing Boat attraction.

Swing Boats
Page 8 of 13
User Manual - Copyright © GRAVITRON LTD 2021
It is recommended that the following signs are displayed in the locations described:
E2.1 Signs Displayed at Entrance
The following signs should be clearly displayed at or on the approach to the customer entrance of the Swing
Boats.
a) Assumption of Risk
A conspicuous warning sign should be posted at the entrance to the swing boats advising the
public of risks and the dangers of the swinging boats.
People use this ride at their OWN RISK
By using this ride people assume all risk of injury
b) Limitations to Use
A notice should be displayed before or at, the entrance advising the public of limitations of
use which may exclude them from being able to participate.
Person or persons under the influence of intoxicants
Maximum of 2 children per boat or 1 adult and 1 child
E2.2 Notices for Users
The signs should include but not be limited to the following information:
a) Operational Procedure
With the following signs clearly displayed to users, there is no requirement for instructional briefings:
Please remain seated whilst in the swing boat
Appropriate signs should be clearly visible to slide users in the embarkation area
Be aware of moving swing boats
b) Safety
Appropriate signs should be clearly visible to swing boat users before they enter the embarkation
area.

Swing Boats
Page 9 of 13
User Manual - Copyright © GRAVITRON LTD 2021
Please embark in an orderly manner
Keep arms & legs inside the boats
AT ALL TIMES
You must remain seated at all times
NEVER attempt to stand on, or climb on the boats
c) Height Restrictions
Specific height and age restrictions should be displayed clearly for the users to see. (At the entrance
to the ride).
Minimum height restriction: .9 Meters
Maximum height restriction: 2.1 Meters
Maximum weight restriction: 180 Kilograms
No Smoking
Appropriate no smoking signs should be clearly visible
Strictly NO SMOKING in any part of this ride
d) Intoxicants
Appropriate signs should be clearly visible to riders
Persons perceived by attendants to be under the influence
of intoxicants will not be allowed to use the ride

Swing Boats
Page 10 of 13
User Manual - Copyright © GRAVITRON LTD 2021
e) Exclusion
Appropriate signs should be clearly visible to ride users
The ride operator reserves the right to
refuse to allow anyone to use the ride
Failure to follow all rules and instructions may result in
Injury to yourself and others.
E3 Safe Operation of the Swing Boats
The swing boats should only be operated following an inspection to ensure the safety of the ride.
E3.1 Normal Functioning
Before the first operation of the day the DAILY MAINTENANCE ROUTINE must be carried out.
a) Normal Operational Cycle
The following operational cycle is a step-by-step guide:
1. Users approach the Swing Boat ride and are guided through to the embarkation area.
2. The embarkation area is located through an opening in the Pickett fence and is a
contained area close to the swing boats but sufficiently far removed so as to prevent
person(s) coming into contact with a moving boat.
3. It is recommended that no boat be operated whilst users are embarking or
disembarking from any of the boats.
4. If any boats are unoccupied and boats are in operation then embarkation to the static
boats should only be undertaken at the conclusion of a ride or by causing the
occupied boats to come to a halt.
5. Similarly disembarkation procedure should mirror embarkation procedure.
6. The operator should note that whilst the Swing boat is an old style simplistic
attraction the close proximity of a heavy swinging object to person or persons has to
be addressed with serious safety in mind at all times.
E3.2 Capacity
Below are the maximum capacities for the Swing Boats
Boats:
Maximum of one adult and one child per boat
E3.3 Potentially Dangerous User Behaviour
Any use of the boats other than in the manner outlined as safe operational procedure could be potentially
dangerous. This might include, but is not limited to the following:

Swing Boats
Page 11 of 13
User Manual - Copyright © GRAVITRON LTD 2021
Standing on the boat
Climbing up the boat supports or A Frame
Not keeping arms and legs within confines of the boat perimeter
Using the boats with more than 2 persons at a time
Loitering in the embarkation area
E3.4 Safe Passenger Access
Access to the Swing Boats must ensure there is always adequate space between users and moving boats.
E3.5 Safe and Unsafe Operating Practices
There are no additional safe or unsafe operating practices.
E3.6 Unsafe Equipment Procedures
Routine maintenance as outlined in SECTION F of this manual will ensure the equipment remains in a safe
state of repair at all times.
If any part of the ride becomes unsafe during use the ride MUST BE CLOSED IMMEDIATELY, until it has
been made safe.
SECTION F
Maintenance Routines
Regular maintenance will ensure the life of the product.
F1 Monthly Maintenance Records
A maintenance schedule, completed to date, must be maintained for the Swing Boats. This record should be
used to enter the details of any work carried out on this ride. The description of the work should be as
comprehensive and detailed as possible.
It is in the interest of the Operator that all maintenance sheets are completed on a regular basis.
F2 Continuous Monitoring
It is important to visually check the swing boats, during operation times, to ensure that a safe situation exists.
F2.1 Swing Boat Assembly
It is the responsibility of the Operator to ensure that the Swing Boat ride is in a safe condition prior to use and
at all times during use.
Slide should be checked visually for:
Loose nuts & bolts etc.
Damage to Boats
Damage to frame
The Operator must ensure that the swing boats are continuously monitored and controlled by sufficient
personnel (as would be deemed necessary by best practice).

Swing Boats
Page 12 of 13
User Manual - Copyright © GRAVITRON LTD 2021
IF ANY OF THE ABOVE FAULTS OCCUR, THE RIDE MUST BE NOT BE USED UNTIL THE FAULT IS
CORRECTED.
F3 Annual Third Party Inspection
It is paramount that the swing boat ride is fully inspected annually to ensure that the whole structure is fit for
purpose for the new season. We recommend that this inspection is carried out by a fully qualified third party
company. GRAVITRON can provide this service, please contact 01278 804610 for more details.
F4 Daily Maintenance & Cleaning
It is the responsibility of the Controller to ensure that the ride is kept safe by regular cleaning and maintenance.
F4.1 Cleaning
Essential daily cleaning must include, but is not limited to:
Cleaning the boat interior
Cleaning the floor in the queuing areas
F4.2 Daily Maintenance
Daily maintenance must be carried out by a suitably trained person. Essential daily maintenance must
include, but is not limited to:
Routine visual inspection
Manually examine the ride to ensure no fitments have become unsecure
F
IF IN DOUBT ABOUT ANY PROBLEM OR ADJUSTMENT TO THE SWINGBOATS,
CONTACT GRAVITRON Ltd ON 01278 804610
SECTION G
G1 Warranty
The Swing boat is manufactured by GRAVITRON, is warranted against defects in the materials and
workmanship for a period of one year from the date of installation acceptance, under normal use and service.
During the warranty period, GRAVITRON will repair or replace components which prove to be defective.
In the event of a defect photographs must be taking as soon as the defect is identified and sent along with a
full description of the issue to GRAVITRON (please ensure that this evidence is dated). Our engineers will
assess the information and decide on a course of action which may involve a site inspection or direct
maintenance call out.
The cost of the visit will initially be met by GRAVITRON. If the defect proves not to be a design/manufacture
or material the cost of the visit will be met by Butlins.
Limitation of Warranty
The foregoing express warranty shall not apply to defects resulting from improper or inadequate maintenance
by Buyer or User.

Swing Boats
Page 13 of 13
User Manual - Copyright © GRAVITRON LTD 2021
These falls outside the warranty: Unauthorised modifications to the wiring or components or misuse,
operation outside of the environment specifications for the product, or improper site preparation or
maintenance.
TO THE EXTENT PERMITTED BY LAW, THIS WARRENTLY AND REMEMDIES SET FORTH ABOVE ARE
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS WHETHER
ORAL OR WRITTEN, STATUTORY, EXPRESS, OR IMPLIED.
G1.1 Date of Commencement of Warranty (1 year Warranty)
01 June 2015
