GREE ELECTRIC DC Inverter U-match Series User manual

Owner's Manual
Original Instructions
Air Conditioners
DC Inverter U-match Series Duct Type Unit
Models:
Indoor Unit
Outdoor Unit
GUD35PS/A-S
GUD50PS/A-S
GUD71PS/A-S
GUD35P/A-S
GUD50P/A-S
GUD71P/A-S
GUD35W/A-S
GUD50W/A-S
GUD71W/A-S
GUD100PHS/A-S
GUD100PH/A-S
GUD100W/A-S
GUD125PHS/A-S
GUD125PH/A-S
GUD125W/A-S GUD125W/A-X
GUD140PHS/A-S
GUD140PH/A-S
GUD140W/A-S GUD140W/A-X
GUD160PHS/A-S
GUD160PH/A-S
GUD160W/A-S GUD160W/A-X

To Users
Thank you for selecting Gree’s product. Please read this instruction
manual carefully before installing and using the product, so as to master
and correctly use the product. In order to guide you to correctly install
and use our product and achieve expected operating effect, we hereby
instruct as below:
(1) This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsibility for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
(2) In order to ensure reliability of product, the product may
consume some power under stand-by status for maintaining
normal communication of system and preheating refrigerant
and lubricant. If the product is not to be used for long, cut off
the power supply; please energize and preheat the unit in
advance before reusing it.
(3) Please properly select the model according to actual using
environment, otherwise it may impact the using convenience.
(4) This product has gone through strict inspection and operational
test before leaving the factory. In order to avoid damage due to
improper disassembly and inspection, which may impact the
normal operation of unit, please do not disassemble the unit by
yourself. You can contact with the special maintenance center
of our company if necessary.
(5) When the product is faulted and cannot be operated, please

contact with our maintenance center as soon as possible by
providing the following information.
1) Contents of nameplate of product (model, cooling/heating
capacity, product No., ex-factory date).
2) Malfunction status (specify the situations before and after
the error occurs).
(6) All the illustrations and information in the instruction manual are
only for reference. In order to make the product better, we will
continuously conduct improvement and innovation. We have
the right to make necessary revision to the product from time to
time due to the reason of sales or production, and reserve the
right to revise the contents without further notice.
(7) Indoor unit must not be installed in a laundry.
(8) If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
(9) Gree Electric Appliances Inc. of Zhuhai assumes no
responsibility for personal injury, property loss or equipment
damage caused by improper installation and commissioning,
unnecessary maintenance, or not following relevant national
rules and regulations, industrial standards and requirements in
this instruction manual.
(10) The final right to interpret for this instruction manual belongs to
Gree Electric Appliances Inc. of Zhuhai.

Exception Clauses
Manufacturer will bear no responsibilities when personal injury or
property loss is caused by the following reasons:
(1) Damage the product due to improper use or misuse of the
product;
(2) Alter, change, maintain or use the product with other equipment
without abiding by the instruction manual of manufacturer;
(3) After verification, the defect of product is directly caused by
corrosive gas;
(4) After verification, defects are due to improper operation during
transportation of product;
(5) Operate, repair, maintain the unit without abiding by instruction
manual or related regulations;
(6) After verification, the problem or dispute is caused by the
quality specification or performance of parts and components
that produced by other manufacturers;
(7) The damage is caused by natural calamities, bad using
environment or force majeure.

Contents
1 Safety Notices (Please be sure to abide) .......................................1
2 Product Introduction........................................................................6
2.1 Overall Layout ..........................................................................6
2.2 Operating Range ......................................................................7
2.3 Standard Accessories ...............................................................7
3 Installation ........................................................................................8
3.1 Installation Preparation .............................................................8
3.2 Unit Installation .......................................................................17
3.3 Electrical Installation ...............................................................38
3.4 Check after Installation............................................................51
3.5 Test Running ..........................................................................51
4 Operation specification .................................................................52
5 Maintenance ...................................................................................53
5.1 Failures Not Caused by Faults of the AC .................................53
5.2 Error Code..............................................................................55
5.3 Unit Maintenance....................................................................57
5.4 After-sales Services ................................................................59

DC Inverter U-match Series Duct Type Unit
1
1 Safety Notices (Please be sure to abide)
SPECIAL WARNING:
(1) Do not pierce or burn.
(2) Do not use means to accelerate the defrosting process or to
clean, other than those recommended by the manufacturer.
(3) Be aware that refrigerants may not contain an odor.
PROHIBITED: This sign indicates that the operation must be
prohibited. Improper operation may cause severe damage or
death to people.
WARNING: If not abide strictly, it may cause severe damage to
the unit or the people.
NOTICE: If not abide strictly, it may cause slight or medium
damage to the unit or the people.
OBSERVED: This sign indicates that the items must be
observed. Improper operation may cause damage to people or
property.
WARNING!
This product can’t be installed
at corrosive, inflammable or
explosive environment or the place with special requirements,
such as kitchen. Otherwise, it will affect the normal operation or
shorten the service life of the unit, or even cause fire hazard or
serious injury. As for above s
pecial places, please adopt
special air conditioner with anti-corrosive or anti-explosion
function.

DC Inverter U-match Series Duct Type Unit
2
Please read this operating manual carefully before operating the
unit.
Before using the air conditioner, please read the instruction
manual.
Before installing the air conditioner, please read the instruction
manual.
Before repairing the air conditioner, please read the instruction
manual.
The figures in this manual may be different with the material
objects, please refer to the material objects for reference.
PROHIBITED
(1) The air conditioner should be grounded to avoid electric shock. Do not connect
the ground wire to gas pipe, water pipe, lightning arrester or telephone wire.
(2) The appliance shall be stored in a well-ventilated area where the room size
corresponds to the room area as specified for operation.
(3) The appliance shall be stored in a room without continuously operating open
flames (for example an operating gas appliance) and ignition sources (for
example an operating electric heater).
(4) A
ccording to federal/state/local laws and regulations, all packages and
transportation materials, including nails, metal or wooden parts, and plastic
packing material, must be treated in a safe way.
WARNING
(1) Please install according to this instruction m
anual. Installation must be
performed in accordance with the requirement of NEC and CEC by authorized
personnel only.
(2) Any person who is involved with working on or breaking into a refrigerant
circuit should hold a current valid certificate from an industry-accredited
assessment authority, which authorizes their competence to handle
refrigerants safely in accordance with an industry, recognized assessment
specification.
(3)
Servicing shall only be performed as recommended by the equipment
manufacturer.

DC Inverter U-match Series Duct Type Unit
3
WARNING
(4) The appliance shall be installed in accordance with national wiring regulations.
(5) The fixed wires connecting to the appliance must be configured with all-pole
disconnection device under voltage grade III according to wiring rules.
(6) Air conditioner should be stored with protective measures against mechanical
damage caused by accident.
(7) If the installation space for air conditioner pipe is too small, adopt a protective
measure to prevent the pipe from physical damage.
(8) During installation, use the specialized acces
sories and components,
otherwise water leakage, electric shock or fire hazard may occur.
(9) Please install the air conditioner in a secure place that can withstand the
weight of air conditioner. Insecure installation may cause the air conditioner
falling down and lead to injury.
(10) Be sure to adopt independent power circuit. If the power cord is damaged, it
must be repaired by the manufacturer, service agent or other professional
agents.
(11)
The air conditioner can be cleaned only after it is turned off and
power-disconnected, otherwise electric shock may occur.
(12) The air conditioner is not intended to be cleaned or maintained by children
without supervision.
(13) Do not alter the setting of pressure sensor or other protective devices. If the
protective devices are short-circuited or changed against rules, fire hazard or
even explosion may occur.
(14) Do not operate the air conditioner with wet hands. Do not wash or sprinkle
water on the air conditioner, otherwise malfunction or electric shock will occur.
(15) Do not dry the filter with naked flame or an air blower; otherwise the filter will
be out of shape.
(16) If the unit is to be installed in a small space, please adopt protective measures
to prevent the concentration of refrigerant from exceeding the allowable safety
limit; excessive refrigerant leakage may lead to explosion.
(17) When installing or re-installing the air conditioner, please keep the refrigerant
circuit away from substances other than the specified refrigerant, such as air.
Any presence of foreign substances will cause abnormal pressure change or
even explosion, resulting in injury.
(18) Only professionals are allowed to carry on daily maintenance.
(19) Before contacting any wire, make sure power is cut off.
(20) Do not let any inflammable objects near the unit.

DC Inverter U-match Series Duct Type Unit
4
WARNING
(21) Do not use organic solvent to clean the air conditioner.
(22) If you need to replace a component, please ask a professional to repair with a
component supplied by the original manufacturer so as to ensure the unit’s
quality.
(23) Improper operation may get the unit broken, hit by electric shock or cause fire.
(24) Do not make the air conditioner wet or electric shock may be lead, Ensure that
the air conditioner will not be cleaned by water rinsing under any
circumstance.
NOTICE
(1) Do not put a finger or other objects into the air inlet or air return grill.
(2) Please adopt safety protection measures before touching the refrigerant pipe;
otherwise your hands may be hurt.
(3) Please arrange the drain pipe according to the instruction manual.
(4) Never stop the air conditioner by directly cutting off the power.
(5) Please select the proper copper pipe according to the requirement for pipe
thickness.
(6) Indoor unit can only be installed indoors while outdoor unit can be installed
either indoors or outdoors. Never install the air conditioner in the following
places:
1) Places with oil smoke or volatile liquid: plastic parts may deteriorate and fall
off or even cause water leakage.
2) Places with corrosive gas: copper pipe or the welding parts may be corroded
and cause refrigerant leakage.
(7) Adopt proper measures to protect the outdoor unit from small animals because
they may damage the electric components and cause malfunction of the air
conditioner.
(8) Before cleaning, please make sure the unit is stopped. Cut the circuit breaker
and remove the power socket, otherwise, electric shock may occur.
(9) Do not wash the air conditioner with water, otherwise fire hazard or electric
shock may occur.
(10) When cleaning the filter, please be careful of your steps. If you need to work
high above the ground, please be extremely careful.

DC Inverter U-match Series Duct Type Unit
5
OBSERVED
(1) If wired control is to be used, it should be connected first before powering up
the unit, otherwise the wired control may not be able to use.
(2) When installing the indoor unit, keep it away from television, wireless waves,
and fluorescent.
(3) Only use soft dry cloth or slightly wet cloth with neutral detergent to clean the
casing of the air conditioner.
(4) Before operating the unit under low temperature, connect it to power for 8
hours. If it is stopped for a short time, for example, one night, do not cut off the
power (This is to protect the compressor).

DC Inverter U-match Series Duct Type Unit
6
2 Product Introduction
2.1 Overall Layout
NOTICE:
(1) The connection pipe, drain pipe, power cord, and duct for this
unit should be prepared by the user.
(2) The unit is standard equipped with rectangular duct.

DC Inverter U-match Series Duct Type Unit
7
2.2 Operating Range
Cooling
Heating
Outdoor temperature DB(°C)
-15~48
-15~24
Indoor temperature DB/WB(°C)
(Maximum)
32/23 27/-
2.3 Standard Accessories
Indoor Unit Accessories
No. Name Appearance Q'ty Usage
1 Wired
Controller 1 To control the indoor unit
2 Insulation 1 To insulate the gas pipe
3 Insulation 1 To insulate the liquid pipe
4 Fastener 8 To fasten the sponge
5 Nut with
Washer
4 To fix the hook on the cabinet of the
unit
6 Nut 4 To be used together with the hanger
bolt for installing the unit
7 Washer 4 To be used together with the hanger
bolt for installing the unit
8 Sponge 2 To insulate the drain pipe
10 Nut 1 To connect gas pipe
11 Nut 1 To connect liquid pipe
Outdoor Unit Accessories
No. Name Appearance Q'ty Usage
1 Drain Plug 1 or 3 To plug the unused drain hole
2
Drainage
Connector
or
1
To connect with the hard PVC drain
pipe

DC Inverter U-match Series Duct Type Unit
8
3 Installation
3.1 Installation Preparation
3.1.1 Selection of Installation Location
WARNING
①The unit must be installed where strong enough to withstand the weight of the
unit and fixed securely; otherwise the unit would topple or fall off.
②
Install the air conditioner at a place where the inclination is less than 5°.
③
Do not install the unit at a place with direct sunlight.
④
Do not install where there is the danger of combustible gas leakage.
⑤
Do not install the unit near heat source of heat, steam, or flammable gas.
Selection of Installation Location for Indoor Unit (Select a
location pursuant to the following condition).
(1) Air inlet and outlet of the indoor unit should be away from
obstacles to make sure the unit’s air flow can reach the entire
room. Do not install the unit in a kitchen or a laundry.
(2) Select a location that can withstand 4 times the unit weight
without increasing operating noise and vibration.
(3) The installation location must be level.
(4) The indoor piping length and wiring length should be within the
allowable range.
(5) Select a place that can easily drain condensate and connect to
the drain system of the air conditioner.
(6) If hoisting screw bolts are to be used, check whether the
installation location is safe enough. If not safe, reinforce the
location before installation.
(7) Indoor unit, power cord, connecting wires and communication

DC Inverter U-match Series Duct Type Unit
9
cords should be at least 1m from television and radio. This is to
prevent image interference or noise (Even at a distance of 1m,
a very strong electric wave may still generate noise).
Selection of Installation Location for Outdoor Unit (Select a
location pursuant to the following condition).
(1) Noise and air flow produced by the outdoor unit will not disturb
the neighbors.
(2) Select a location that is safe and away from animals and plants.
If not, please add safety fences to protect the unit.
(3) Install at a place with good ventilation. Make sure the outdoor
unit stays at a well-ventilated place with no obstacles nearby
that may obstruct the air inlet and outlet.
(4) The installation location should be able to withstand the weight
and vibration of outdoor unit and allow the installation to be
carried out safely.
(5) Avoid installing at a place with leakage of inflammable gas, oil
smoke or corrosive gas.
(6) Keep it away from strong wind because strong wind will affect
the outdoor fan and lead to insufficient air flow volume and thus
affecting the unit’s performance.
(7) Install the outdoor unit at a place that is convenient for it to be
connected to the indoor unit.
(8) Away from any object that may get the air conditioner
generating noise.
(9) Install the outdoor unit at a place where condensate can be
easily drained.

DC Inverter U-match Series Duct Type Unit
10
3.1.2 Unit Dimension
WARNING
①Install the indoor unit in a location which can withstand a load of at least five
times the weight of the main unit and which will not amplify sound or vibration.
②If the installation location is not strong enough, the indoor unit may fall and
cause injuries.
③If the job is done with the panel frame only, there is a risk that the unit will come
loose. Please take care.
(1) Indoor unit:
NOTICE
Drilling of ceiling opening and installation of air conditioner must be performed by
professionals!
Unit: mm
Dimensions
Model
A B C D E F G
GUD35P/A-S 760 415 700 200 450 474 768
GUD35PS/A-S
GUD50P/A-S 1060 415 1000 200 450 474 1068
GUD50PS/A-S
GUD71P/A-S 1360 415 1300 220 450 474 1368
GUD71PS/A-S

DC Inverter U-match Series Duct Type Unit
11
Dimensions
Model
A B C D E F G
GUD100PH/A-S
1040 500 1000 300 700 754 1092
GUD100PHS/A-S
GUD125PH/A-S
1040 500 1000 300 700 754 1092
GUD125PHS/A-S
GUD140PH/A-S
1440 500 1400 300 700 754 1492
GUD140PHS/A-S
GUD160PH/A-S
1440 500 1400 300 700 754 1543
GUD160PS/A-S
(2) Outdoor unit:
Model: GUD35W/A-S, GUD50W/A-S, GUD71W/A-S, GUD100W/A-S.
A
F
D
E
G
C
B

DC Inverter U-match Series Duct Type Unit
12
Model:GUD125W/A-S,GUD140W/A-S,GUD160W/A-S,GUD125W/A-X,
GUD140W/A-X,GUD160W/A-X.
A
B
C
D
E
G
Unit: mm
Dimensions
Model
A B C D E F G
GUD35W/A-S 818 378 596 550 348 887 302
GUD50W/A-S
818
378
596
550
348
887
302
GUD71W/A-S 892 396 698 560 364 952 340
GUD100W/A-S 920 427 790 610 395 1002 370
GUD125W/A-S
940
530
820
610
486
/
460
GUD125W/A-X
940
530
820
610
486
/
460
GUD140W/A-S 940 530 820 610 486 / 460
GUD140W/A-X
940
530
820
610
486
/
460
GUD160W/A-S
940
530
820
610
486
/
460
GUD160W/A-X 940 530 820 610 486 / 460

DC Inverter U-match Series Duct Type Unit
13
3.1.3 Diagram of Unit Installation Space and Location
(1) Diagram of installation space and location for outdoor unit
(Notice: for best performance of the outdoor unit, make sure its
installation space conforms to the following installation
dimensions).
1) When one outdoor unit is to be installed.
A~E Hb Hd H
(mm)
a
b
c
d
e
B
—
≥100
A,B,C,
—
≥300
≥100
≥100
B,E
—
≥100
≥1000
A,B,C,E
—
≥300
≥150
≥150
≥1000
D
—
≥1000
D,E
—
≥1000
≥1000
B,D
Hb<Hd
Hd>H
≥100
≥1000
Hb>Hd
Hd<H
≥100
≥1000
B,D,E
Hb<Hd
Hb≤1/2 H
≥250
≥2000
≥1000
1/2 H<Hb≤H
≥250
≥2000
≥1000
Hb>H
Prohibited
Hb>Hd
Hd≤1/2 H
≥100
≥2000
≥1000
1/2 H<H
d
≤H
≥200
≥2000
≥1000
H
d
>1/2 H
Prohibited

DC Inverter U-match Series Duct Type Unit
14
2) When two or more outdoor units are to be installed side by
side.
A~E Hb Hd H
(mm)
a
b
c
d
e
A,B,C
—
≥300
≥300
≥1000
A,B,C,E
—
≥300
≥300
≥1000
≥1000
D
—
≥2000
D,E
—
≥2000
≥1000
B,D
Hb<Hd
Hd>H
≥300
≥2000
Hb>Hd
H
d
≤1/2 H
≥250
≥2000
1/2 H<Hd≤H ≥300 ≥2500
B,D,E
Hb<Hd
Hb≤1/2 H
≥300
≥2000
≥1000
1/2 H<H
b
≤H
≥300
≥2500
≥1000
Hb>H Prohibited
Hb>Hd
Hd≤1/2 H
≥250
≥2500
≥1000
1/2 H<H
d
≤H
≥300
≥2500
≥1000
Hd>1/2 H Prohibited

DC Inverter U-match Series Duct Type Unit
15
3) When outdoor units are installed in rows.
≥ 200
≥
4000
≥ 200
≥ 2000
≥400
≥400
≥
4500
≥
2000
≥
600
H
b
H
b
H
b
H
(mm)
Hb≤1/2 H
b≥250
1/2 H<H
b
≤H
b≥300
H
b
>H
Prohibited
