Gree GPC07AK-K5NNA1A User manual

Service Manual
Change for life
GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI

Service Manual
Table of Contents
Part Ⅰ: Technical Information.......................................................... 12
1. Summary .................................................................................................. 12
2. Specications........................................................................................ 14
3. Outline Dimension Diagram........................................................... 20
4. Refrigerant System Diagram ......................................................... 23
5. Electrical Part......................................................................................... 24
5.1 Wiring Diagram ......................................................................................... 24
5.2 PCB Printed Diagram................................................................................ 25
6. Function and Control......................................................................... 26
6.1 Introduction of control panel...................................................................... 26
6.2 Remote Controller Introduction ................................................................ 27
6.3 Introduction of Basic Mode Function......................................................... 31
Part Ⅱ: Installation and Maintenance ......................................... 33
7. Notes for Installation and Maintenance................................... 33
8. Installation Precaution...................................................................... 35
9. Installation............................................................................................... 37
9.1 Installation Wire Hook ............................................................................... 37
9.2 Removing Collected Water ....................................................................... 37
9.3 Installation in a double-hung sash window................................................ 39
9.5 Installation and Disassembly of heat Discharge Pipe ............................... 42
9.6 Operation test............................................................................................ 43
10. Maintenance......................................................................................... 44
10.1 Safety Principle of Maintenance.............................................................. 44
10.2 Preparation before Maintenance............................................................. 44
10.3 Maintenance Cautions ............................................................................ 45
10.4 Error Code............................................................................................... 47
10.5 Malfunction Detection Flowchart............................................................. 49
10.6 Maintenance Method for Common Malfunction ...................................... 54
11. Exploded View and Parts List..................................................... 56
12. Removal Procedure ......................................................................... 69
Appendix:...................................................................................................... 73
Appendix 1: Reference Sheet of Celsius and Fahrenheit ............................... 73
Appendix 2: List of Resistance for Temperature Sensor ................................. 74
Table of Contents

1
Technical Information
Service Manual
Please read this manual carefully before installing and operating the GREE Hydrocarbon Air– Conditioner unit.
Careless installation and operation could cause severe injuries to operators, workers and damage to the air-conditioner unit
itself.
Keep this manual in a location for easy access as it is needed for reference during installation, maintenance, service and
operation of the unit.
This manual does not cover all aspects of installation, maintenance and service of the chiller units; if additional information is
needed, contact the GREE Costumer Service or Sales Ofce.
General Information
Warning and cautions appear at appropriate locations throughout this manual book.
Abbreviations Used Within this Manual:
INTRODUCTION
Abbreviation Clear Words
OFDN Oxygen free and dry nitrogen
PPE Personnel protective equipment
LFL Lower ammability level
UFL Upper ammability level
HC Hydrocarbon
ATTENTION

2Technical Information
Service Manual
Notices
Please pay careful attention to these safety instructions, to avoid risks to people and property. Before starting work on maintenance
read this manual thoroughly and pay particular attention to the relevant chapters.
Regardless of further requirements of the country, in which the equipment will be installed: assembly, rst start up, technical service,
maintenance and repair and as well as dismantling and disposal have to be carried out by authorised personnel only.
During every operation strictly follow the instructions within this manual. Pay attention to the specific rules of air conditioning,
electrics and refrigerant handling of the country within which the equipment is installed.
Key sections and/or sentences are highlighted with specic icons and symbols to the right side of the page. Please pay particular
attention to this information.
Information window highlighting
important content of the specic
section or additional information
to consider.
This sign will indicate that you are
handling a ammable substance
and the surrounding environment
can possibly contain it.
This is a general warning sign.
The Label is used to indicate that
the ammable refrigerant is
present within the application and
service equipment.
Images that indicate something
what you should strictly avoid.
Specic bans!
Specic commandments!
Instructions for rst aid!
Fire protection!
Carefully read the
instructions!
General Safety Instructions
The Symbols Used in this Manual are as Follows
This is a specific
remark and
points out the
importance of a
specific section

3
Technical Information
Service Manual
HC R290 is a ammable refrigerant and can form explosive mixtures in low concentrations. To
minimise the risk of re or explosion, the system must be installed in a room with a minimum oor
area.
Unless there are further requirements, standards and legislation of the country within
which the equipment is installed may apply. Any technicians that works on GREE
hydrocarbon air– conditioners must be competent in the safe handling of flammable
refrigerants, in addition to being in possession of knowledge and skills to maintain best
refrigeration installation and servicing practices.
There are already training activities in place for engineers, technicians and sales staff
to provide professional knowledge and skills for the handling of HC refrigerants and
refrigeration systems operating with HCs.
Get trained and have your
“HC Refrigeration Professional” certication!
Having a
malfunction
while
commissioning,
immediately
disconnect the
system from
mains!
Pay attention to
the room size for
indoor unit
installation!
For specific in-
formation refer
page XXX of this
manual.
Minimum Room Size
Get your Best
Practices
knowledge and
skills update for
HC refrigerants
and be
certificated for
these jobs!
The Symbols Used in this Manual are as Follows
ONLY original
GREE (OEM)
spare-parts are
permitted for
Service and Re-
pair!
Working on components with safety-relevant functions jeopardise the safe operation of the
installation. In case it is necessary to replace components, only use approved parts from GREE
Electric, the Original Equipment Manufacturer(OEM) or Gree released or authorised components.
The system contains the refrigerant R-290 (propane). This condition requires special safety
precautions to be observed. Maintenance for the system is strictly prohibited.At the installation
site, no matter what kind of activities are executed, smoking is strictly prohibited!
Likewise, ensure the installation site is well ventilated. For further details as far as it concerns the
handling of the refrigerant R-290 (propane) .
Electric operations (installation, repair, modication, maintenance, adjustment) have to be fullled
by trained and authorised personnel only. When dealing with electrical issues, the specific
rules of the country within which the equipment is installed must be followed, in addition to the
instructions within this manual.
When working on the equipment or parts of it, the system has to be deenergised (by master
switch, circuit breaker or separate cut-out) and made safe against restart of the system. Do not
reconnect the system to the electric circuit until all work is done and all connections are tested.
If handled unsafely or unprofessionally, severe electric shocks can occur. Consider the wiring
diagram and follow the instructions of this manual very carefully whilst working on electrical parts.
Wrong connections or incorrect grounding may lead to severe injuries and mortal danger.
Ground the system according to the particular requirements of the country within which the
equipment is installed.
Connect all the wires properly and durably. Loose cables may lead to overheating or re
Proceed
according the
manuals
Instructions!

4Technical Information
Service Manual
Knowledge of the basic SI standard units for temperature, pressure, mass, density, energy.
Understanding of the basic theory of refrigeration systems including the functions of the main components in the system (compressor,
evaporator, condenser, thermostatic expansion valves).
Understanding how to read a refrigerant ow chart and an electrical circuit diagram.
The determination of non condensable gases in the refrigeration system and how to eliminate them.
The importance of the use of oxygen free dry nitrogen (OFDN) for system ushing, leak test and strength test.
The elimination of humidity from the refrigeration system and how to recover or vent HC refrigerant from a system.
Usage of tables and diagrams (log p/h diagram, saturation tables of a refrigerant, diagram of a single compression refrigeration cycle)
and interpretation of these tables and diagrams.
Knowledge of the basic operation of the following components in a refrigeration system and their role and importance for refrigerant
leakage prevention and identication:
Carry out a pressure and leak test to check the strength and the tightness of the system.
Usage of a vacuum pump.
Evacuation of the system to remove air and moisture according to standard practice.
Knowledge of potential leakage points of refrigeration, air-conditioning and heat pump equipment. Making a visual and manual
inspection of the whole system.
Carry out a check for leakage of the system using an indirect method and/or one of the direct methods.
Direct leak detection methods:
1. Fixed leakage detection systems
2. Portable electronic gas detectors
3. Ultraviolet (UV) indication uids
4. Weak soapy water solution (bubble test) also in combination with OFDN
5. New installation tightness test for leakage detection procedure e.g. H2/N2
6. Operational system tightness test for leakage detection procedure
Indirect refrigerant detection methods:
1. Visual
2. Manual checks
· Temperature and pressure controls
· Sight class and moisture indicators
· Defrost controls, reverse cycle operation
· System protectors
· Measuring devices such as the pressure gauge manifold
· Thermometer
· Leak detector
· Refrigerant charging devices
· Vacuum pump
· Oxygen free dry nitrogen cylinder and pressure regulator
Fault nding – analysis and repair.
· Knowledge of ammable refrigerants
· Risk analysis for the application of ammable refrigerant and properties of
ammable refrigerants
· Electrical circuit assessment and repair
Basics in RAC
Checks before putting in operation, after a long period of
nonuse, after maintenance or repair intervention or during
operation.
Checks for Leakage
Read More!
SAFETY CODE
OF PRACTICE
FOR REFRIGE-
RATING SYS-
TEMS
UTILISING A2 &
A3 REFRIGE-
RANTS
ISBN
1 872719 15 5

5
Technical Information
Service Manual
HC R290 Refrigerant Lssues
Basics
HC R-290 (propane) is an odourless and colourless gas of the group of hydrocarbons.
HC R-290 is heavier than air and at high concentrations can cause
narcotic effects and eventually asphyxiation.
R-290 is highly ammable within the range of 2,1% and 9,5% by volume, or 38
g/m3 to 170 g/m3 in air. The auto-ignition temperature is about 470°C.
Since R-290 is an odourless and colourless gas, it is difcult to perceive that it is
present (as with most other refrigerants).
Propane is often used as a fuel such as for heating or barbecues. However, for
use on refrigeration systems, fuel-grade propane is not suitable since it contains
high levels of impurities, which would damage the refrigeration system and may
not provide the desired refrigerating capacity or efciency.
Please notice that the unit is filled with propane. Details to this refrigerant are found in chapter “refrigerant”. Propane is highly
ammable and leads to explosion under certain conditions. Inappropriate treatment of the unit involves the risk of severe damages
of people and material.
The structural formula of HC R-290 (propane)
HC R-290 refrig-
erant has a high
grade of purity.
Propane as a
cooking gas is
not useful for
refrigeration
purpose!
Important Refrigerant Properties and
Parameters:
Molecular formula C3H8
Melting point [°C] -188
Boiling point under atmospheric pressure [°C] -42
Molar mass [g mol -1] 44,10
Critical temperature [ °C] 96,8
Critical pressure [bar] 42
Practical limit [g/m3 ] 8
Lower ammability level LFL [g/m3 ] 38
Lower ammability level LFL [ %] 2,1
Upper ammability level UFL [ g/m3] 171
Upper ammability level UFL [ %] 9,5
Ignition temperature [ °C] 470
Read More!
Guidlines for the
safe use of hydro-
carbon refrige-
rants
GIZ—PROKLIMA
http://www.gtz.de/
proklima

6Technical Information
Service Manual
2 % 10 %
Oxygen 0 % to 100 %
HC R-290
Refrigerant
Flammability
Safety Data
Hazard Identication
Three components are needed simultaneously for causing re:
For ignition, the concentration of HC in air has to be between the lower and upper
ammable limits. If the concentration is below the lower ammability limit (LFL) of about
2% by volume in air, there is not enough HC for combustion. If the concentration is
above the upper ammability limit (UFL) of about 10% there is insufcient oxygen for
combustion.
Possible ignition sources are:
1. A flame, for example from brazing torch, halide torch leak lamp, match or
lighter, cigarette
2. A spark from an electrical component
3. Static electricity
4. Hot surfaces
· Extremely ammable (F+).
· Readily forms an explosive air-vapour mixture at ambient temperatures.
· Vapour is heavier than air and may travel to remote sources of ignition (e.g.
along drainage systems, into basements etc).
· Liquid releases generate large volumes of ammable vapour (approx 250:1)
· Cold burns (frostbite) will result from skin / eye contact with liquid.
· Liquid release or vapour pressure jets present a risk of serious damage to
the eyes.
· Abuse involving inhalation of high concentrations of vapour, even for short
periods, which can produce unconsciousness or may prove fatal. Inhalation
may cause irritation to the nose and throat, headache, nausea, vomiting,
dizziness and drowsiness. In poorly ventilated areas unconsciousness or
asphyxiation may result.
By way of illustration please compare to the schematic view:
1. Oxygen
2. Ignition source
3. The ammable concentration of HC
To ignite HC R-
290, three (3)
components
must exist at the
same time at
work area
to cause the
refrigerant
burning!
1 kg of liquid HC
R-290 refrigerant
creates about
250 litres of gas
Beside the flam-
mability, most
other safety
properties are
similar to other
refrigerants!
Rely always on
best service
practices in
refrigeration!

7
Technical Information
Service Manual
First Aid Measures
Fire Fighting Measures
Extinguishing Media:
DO NOT USE WATER JET
Inhalation:
Remove the affected person to fresh air. If breathing has stopped, administer
articial respiration. Give external cardiac massage if necessary. If the person is
breathing but unconscious, place them in the recovery position. Obtain medical
assistance immediately.
Skin:
In case of cold burns: ush with water to normalize temperature. Cover the burns
with sterile dressings Do not use ointments or powders. Obtain medical assistance
immediately.
Eyes:
Cold burns should be ushed with water to normalise temperature, cover the eye
with a sterile dressing and obtain medical assistance immediately.
HC R-290 is delivered, stored, and used at temperatures above their ash point. Avoid all naked ames, sparks, cigarettes
etc.
· In case of re, immediately alert re brigade
· Ensure an escape path is always available from any re
· If gas has ignited do not attempt to extinguish but stop gas ow and allowto burn out.
· Use water spray to cool heat-exposed containers, and to protect surroundingareas and personnel effecting the shut off
· Every precaution must be taken to keep containers cool to avoid the possibilityof a boiling liquid expanding vapour
explosion (BLEVE)
In case of a large re:
Release must be stopped and container cooled by water spray.
Water mist should be used to assist approach to the source of the re.
Large res should only be handled by Fire Brigade.
Small re:
Use dry powder extinguisher

8Technical Information
Service Manual
DO NOT USE WATER JET
Special protective equipment for re ghters:
In conned spaces use self-contained breathing apparatus
Hazardous combustion products:
Incomplete combustion may form carbon monoxide.
Immediate emergency action:
· Clear people away from the area to a safe place
· Do not operate electrical equipment unless “Ex”-rated
· Summon the emergency services
· Treat or refer casualties if necessary
Further action (when release is made safe):
· Extinguish all naked lights – avoid creating sparks
· Position re ghting equipment
· Cover drains and disperse vapour with water spray.
Note: vapour may collectin conned spaces.
Further actions:
· Stop release
· Use dry powder or carbon dioxide extinguishers
· Cool containers exposed to re by using water / mist spray.
Due to the flammability of R-290 and the risk of fire or explosion during servicing,
special safety rules must be followed during operation. In order to avoid damage for
people and property, particular requirements are listed hereafter.
Before servicing the unit, the surrounding area were the work will be done must be
clear of safety hazards to ensure safe working. Nevertheless it is required to carry out
a risk assessment in order to minimise the risk of ignition of R-290.
1. Any employees and other present persons must be informed about the service and the way the service is done, rst.
2. It is recommended to isolate the working environment in order to keep out any unauthorised personnel.
3. It is useful to set up signs such as „no smoking“ or „access denied“.
4. It is prohibited to store any combustible goods within the working environment.
5. Within two (2) metres radius, ignition sources are not allowed in the working area.
6. Fire extinguisher (dry powder) must be easily accessible at any time.
7. During service work, proper ventilation of the environment must be ensured.
Accidental Release Measures
Accidental Release Measures
The following safety measures must be followed:

9
Technical Information
Service Manual
Sign plate to protect and mark the working area.
Appropriate detectors, suitable for hydrocarbons, must be available and operational all the time. Appropriate tools and
appliances must be available and ready for operation.
Any employees need to be instructed extensively about the safety measures and the possible safety hazard.
The HC leak de-
tector is indeed
a Personal
Protective
Equipment
(PPE)
device!
While servicing the unit it is recommended for the whole period of work — before,during
and after — to monitor the gas concentration in the air within the work environment. By
monitoring the air within the work environment the danger of a possible formation of
ammable atmosphere can be detected early.
Doing the monitoring, ensure that the gas detectors are suitable for hydrocarbon detection.
Never use open re or a device with an ignition source for the detection of gas or for leak
detection.
Gas Detection
The HC leak de-
tector is indeed
a PPE device!
Before operation of the gas detector the instruction manual must be read carefully. In case of
any questions refer to the detector manufacturer. Furthermore ensure the detector is correctly
calibrated. Instructions for calibration can be found in the instruction manual of the detector or
upon request from the manufacturer.
A possible re-calibration must be done within an area which is free of refrigerants.
In case of a positive detection by the detector any work must be stopped immediately. Any
open ames or ignition sources must be extinguished or removed. In addition to a suitable and
approved HC gas detectors, portable gas detectors can be used.
Such a detector can be clipped to clothing or placed on the floor within the working area.
It should be switched on for the duration of the work, and set to alarm at 15% of the lower
flammability level (LFL), to warn that flammable concentration may be nearby. In this way,
technicians can be alerted whenever an inadvertent release of ammable refrigerant occurs,
and can immediately act upon the relevant emergency procedures.
Portable HC Gas Detector

10 Technical Information
Service Manual
Pressure—Temperature Chart
HC Refrigerant R-290
Temperature Absolute pressure Gauge pressure
°C °F kPa bar PSI kPa(g) bar(g) PSI(g)
-40 -40 111,12 1,11 16,12 11,12 0,11 1,61
-39 -38,2 116,00 1,16 16,83 16,00 0,16 2,32
-38 -36,4 121,05 1,21 17,56 21,05 0,21 3,05
-37 -34,6 126,27 1,26 18,31 26,27 0,26 3,81
-36 -32,8 131,66 1,32 19,10 31,66 0,32 4,59
-35 -31 137,23 1,37 19,90 37,23 0,37 5,40
-34 -29,2 142,97 1,43 20,74 42,97 0,43 6,23
-33 -27,4 148,90 1,49 21,60 48,90 0,49 7,09
-32 -25,6 155,02 1,55 22,48 55,02 0,55 7,98
-31 -23,8 161,33 1,61 23,40 61,33 0,61 8,89
-30 -22 167,83 1,68 24,34 67,83 0,68 9,84
-29 -20,2 174,54 1,75 25,31 74,54 0,75 10,81
-28 -18,4 181,44 1,81 26,32 81,44 0,81 11,81
-27 -16,6 188,56 1,89 27,35 88,56 0,89 12,84
-26 -14,8 195,89 1,96 28,41 95,89 0,96 13,91
-25 -13 203,43 2,03 29,51 103,43 1,03 15,00
-24 -11,2 211,19 2,11 30,63 111,19 1,11 16,13
-23 -9,4 219,18 2,19 31,79 119,18 1,19 17,29
-22 -7,6 227,39 2,27 32,98 127,39 1,27 18,48
-21 -5,8 235,84 2,36 34,21 135,84 1,36 19,70
-20 -4 244,52 2,45 35,46 144,52 1,45 20,96
-19 -2,2 253,44 2,53 36,76 153,44 1,53 22,26
-18 -0,4 262,61 2,63 38,09 162,61 1,63 23,58
-17 1,4 272,03 2,72 39,45 172,03 1,72 24,95
-16 3,2 281,70 2,82 40,86 181,70 1,82 26,35
-15 5 291,62 2,92 42,30 191,62 1,92 27,79
-14 6,8 301,81 3,02 43,78 201,81 2,02 29,27
-13 8,6 312,27 3,12 45,29 212,27 2,12 30,79
-12 10,4 323,00 3,23 46,85 223,00 2,23 32,34
-11 12,2 334,00 3,34 48,44 234,00 2,34 33,94
-10 14 345,28 3,45 50,08 245,28 2,45 35,58
-9 15,8 356,85 3,57 51,76 256,85 2,57 37,25
-8 17,6 368,70 3,69 53,48 268,70 2,69 38,97
-7 19,4 380,85 3,81 55,24 280,85 2,81 40,73
-6 21,2 393,29 3,93 57,04 293,29 2,93 42,54
-5 23 406,04 4,06 58,89 306,04 3,06 44,39
-4 24,8 419,09 4,19 60,78 319,09 3,19 46,28
-3 26,6 432,45 4,32 62,72 332,45 3,32 48,22
-2 28,4 446,13 4,46 64,71 346,13 3,46 50,20
-1 30,2 460,13 4,60 66,74 360,13 3,60 52,23
0 32 474,46 4,74 68,82 374,46 3,74 54,31
1 33,8 489,11 4,89 70,94 389,11 3,89 56,44
2 35,6 504,10 5,04 73,11 404,10 4,04 58,61
3 37,4 519,43 5,19 75,34 419,43 4,19 60,83
4 39,2 535,10 5,35 77,61 435,10 4,35 63,11
5 41 551,12 5,51 79,93 451,12 4,51 65,43
6 42,8 567,49 5,67 82,31 467,49 4,67 67,80
7 44,6 584,22 5,84 84,74 484,22 4,84 70,23
8 46,4 601,31 6,01 87,21 501,31 5,01 72,71
9 48,2 618,77 6,19 89,75 518,77 5,19 75,24
10 50 636,60 6,37 92,33 536,60 5,37 77,83

11
Technical Information
Service Manual
HC Refrigerant R-290
Temperature Absolute pressure Gauge pressure
11 51,8 654,81 6,55 94,97 554,81 5,55 80,47
12 53,6 673,40 6,73 97,67 573,40 5,73 83,17
13 55,4 692,38 6,92 100,42 592,38 5,92 85,92
14 57,2 711,75 7,12 103,23 611,75 6,12 88,73
15 59 731,51 7,32 106,10 631,51 6,32 91,59
16 60,8 751,68 7,52 109,02 651,68 6,52 94,52
17 62,6 772,25 7,72 112,01 672,25 6,72 97,50
18 64,4 793,24 7,93 115,05 693,24 6,93 100,55
19 66,2 814,64 8,15 118,16 714,64 7,15 103,65
20 68 836,46 8,36 121,32 736,46 7,36 106,82
21 69,8 858,71 8,59 124,55 758,71 7,59 110,04
22 71,6 881,39 8,81 127,84 781,39 7,81 113,33
23 73,4 904,51 9,05 131,19 804,51 8,05 116,69
24 75,2 928,07 9,28 134,61 828,07 8,28 120,10
25 77 952,07 9,52 138,09 852,07 8,52 123,58
26 78,8 976,53 9,77 141,64 876,53 8,77 127,13
27 80,6 1001,45 10,01 145,25 901,45 9,01 130,75
28 82,4 1026,83 10,27 148,93 926,83 9,27 134,43
29 84,2 1052,68 10,53 152,68 952,68 9,53 138,18
30 86 1079,00 10,79 156,50 979,00 9,79 141,99
31 87,8 1105,79 11,06 160,38 1005,79 10,06 145,88
32 89,6 1133,08 11,33 164,34 1033,08 10,33 149,84
33 91,4 1160,85 11,61 168,37 1060,85 10,61 153,87
34 93,2 1189,12 11,89 172,47 1089,12 10,89 157,97
35 95 1217,88 12,18 176,64 1117,88 11,18 162,14
36 96,8 1247,16 12,47 180,89 1147,16 11,47 166,38
37 98,6 1276,94 12,77 185,21 1176,94 11,77 170,70
38 100,4 1307,24 13,07 189,60 1207,24 12,07 175,10
39 102,2 1338,07 13,38 194,07 1238,07 12,38 179,57
40 104 1369,42 13,69 198,62 1269,42 12,69 184,12
41 105,8 1401,31 14,01 203,25 1301,31 13,01 188,74
42 107,6 1433,73 14,34 207,95 1333,73 13,34 193,44
43 109,4 1466,71 14,67 212,73 1366,71 13,67 198,23
44 111,2 1500,23 15,00 217,59 1400,23 14,00 203,09
45 113 1534,31 15,34 222,54 1434,31 14,34 208,03
46 114,8 1568,96 15,69 227,56 1468,96 14,69 213,06
47 116,6 1604,18 16,04 232,67 1504,18 15,04 218,17
48 118,4 1639,97 16,40 237,86 1539,97 15,40 223,36
49 120,2 1676,34 16,76 243,14 1576,34 15,76 228,63
50 122 1713,30 17,13 248,50 1613,30 16,13 233,99
51 123,8 1750,86 17,51 253,94 1650,86 16,51 239,44
52 125,6 1789,02 17,89 259,48 1689,02 16,89 244,98
53 127,4 1827,79 18,28 265,10 1727,79 17,28 250,60
54 129,2 1867,17 18,67 270,81 1767,17 17,67 256,31
55 131 1907,17 19,07 276,62 1807,17 18,07 262,11
56 132,8 1947,80 19,48 282,51 1847,80 18,48 268,01
57 134,6 1989,07 19,89 288,49 1889,07 18,89 273,99
58 136,4 2030,98 20,31 294,57 1930,98 19,31 280,07
59 138,2 2073,54 20,74 300,75 1973,54 19,74 286,24
60 140 2116,75 21,17 307,01 2016,75 20,17 292,51

12 Technical Information
Service Manual
GPC07AK-K5NNA1A
GPC09AK-K5NNA1A
1. Summary
Part Ⅰ: Technical Information
GPC07AK-K5NNA3A
GPC09AK-K5NNA3A
GPC07AK-K5NNA2A
GPC09AK-K5NNA2A

13
Technical Information
Service Manual
YB1F2(XFAN)
Remote Controller:
FAN
AUTO
OPER
AIR
HEALTH
FILTER
TURBO
ON/OFF
X-FAN
HOUR
HUMIDITY
ON/OFF
MODE
FAN
X-FAN
TURBO
TEMP TIMER
SLEEP LIGHT
GPC07AK-K5NNA3A
GPC09AK-K5NNA3A
Model Product Code Remote Controller
GPC07AK-K5NNA1A CK010033800
YB1F2(XFAN)
GPC09AK-K5NNA1A CK010033900
CK010033901
GPC07AK-K5NNA2A CK010033301
CK010033300
GPC09AK-K5NNA2A
CK010033200
CK010033201
CK010033202
CK010033203
GPC07AK-K5NNA3A CK010031800
CK010031801
GPC09AK-K5NNA3A
CK010032100
CK010032101
CK010032102
CK010032104

14 Technical Information
Service Manual
Parameter Unit Value
Model GPC09AK-K5NNA3A GPC07AK-K5NNA3A
Product Code CK010032100/CK010032101/
CK010032102/CK010032104 CK010031800/CK010031801
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity W 2600 2100
Heating Capacity W / /
Cooling Power Input W 1000 805
Heating Power Input W / /
Cooling Power Current A 4.4 3.5
Heating Power Current A / /
Rated Input W 1150 950
Rated Current A 5.5 4.3
Air Flow Volume(H/M/L) m3/h 320/290/260 320/290/260
Dehumidifying Volume L/h 1.43 1
EER W/W 2.6 2.6
COP W/W / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for the
Discharge Side MPa 3 3
Permissible Excessive Operating Pressure for the
Suction Side MPa 1.5 1.5
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse current A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC18~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 53/51/49 52/50/48
Sound Power Level (H/M/L) dB (A) 64/63/62 63/62/61
Dimension (WXHXD) mm 315X770X395 315X770X395
Dimension of Carton Box (LXWXH) mm 460X355X866 460X355X866
Dimension of Package (LXWXH) mm 463X358X881 463X358X881
Net Weight kg 27 24.5
Gross Weight kg 31 28.5
Refrigerant R290 R290
Refrigerant Charge kg 0.22 0.16
2. Specications

15
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXD-B160T130C QXD-A121L130B
Compressor Oil 5GSD-TB or equivalent 5GSD-TB or equivalent
Compressor Type Rotary Rotary
L.R.A. A 19 12
Compressor RLA A 3.2 2.7
Compressor Power Input W 726 586
Overload Protector HPA-018 HPA-012
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) rpm 1300/1235/1155 1225/1140/1025
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.5
Fan Motor Capacitor μF 4.5 4
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 380X25.4X228.6 380X25.4X228.6
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185 Φ185
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Rows-n Gap mm 2-1.5+1-1.4 2-1.5,1-1.4
Coil Length (LXDXW) mm 383X266.7X22.8+334X266.7X11.4 383X266.7X22.8+334X266.7X11.4
Fan Motor Speed rpm 1300/1235/1155 1225/1140/1025
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.5
Fan Motor Capacitor μF 4.5 4

16 Technical Information
Service Manual
Parameter Unit Value
Model GPC09AK-K5NNA2A GPC07AK-K5NNA2A
Product Code CK010033200/CK010033201/
CK010033202/CK010033203 CK010033300/CK010033301
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity W 2600 2100
Heating Capacity W / /
Cooling Power Input W 1000 805
Heating Power Input W / /
Cooling Power Current A 4.4 3.5
Heating Power Current A / /
Rated Input W 1150 950
Rated Current A 5.5 4.3
Air Flow Volume(H/M/L) m3/h 320/290/260 320/290/260
Dehumidifying Volume L/h 1.43 1
EER W/W 2.6 2.6
COP W/W / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for the
Discharge Side MPa 3 3
Permissible Excessive Operating Pressure for the
Suction Side MPa 1.5 1.5
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse current A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC18~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 53/51/49 52/50/48
Sound Power Level (H/M/L) dB (A) 64/63/62 63/62/61
Dimension (WXHXD) mm 315X770X395 315X770X395
Dimension of Carton Box (LXWXH) mm 460X355X866 460X355X866
Dimension of Package (LXWXH) mm 463X358X881 463X358X881
Net Weight kg 27 24.5
Gross Weight kg 31 28.5
Refrigerant R290 R290
Refrigerant Charge kg 0.22 0.16

17
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXD-B160T130C QXD-A121L130B
Compressor Oil 5GSD-TB or equivalent 5GSD-TB or equivalent
Compressor Type Rotary Rotary
L.R.A. A 19 12
Compressor RLA A 3.2 2.7
Compressor Power Input W 726 586
Overload Protector HPA-018 HPA-012
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) rpm 1300/1235/1155 1225/1140/1025
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.5
Fan Motor Capacitor μF 4.5 4
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 380X25.4X228.6 380X25.4X228.6
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185 Φ185
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Rows-n Gap mm 2-1.5+1-1.4 2-1.5,1-1.4
Coil Length (LXDXW) mm 383X266.7X22.8+334X266.7X11.4 383X266.7X22.8+334X266.7X11.4
Fan Motor Speed rpm 1300/1235/1155 1225/1140/1025
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.5
Fan Motor Capacitor μF 4.5 4

18 Technical Information
Service Manual
Parameter Unit Value
Model GPC09AK-K5NNA1A GPC07AK-K5NNA1A
Product Code CK010033900/CK010033901 CK010033800
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity W 2600 2100
Heating Capacity W / /
Cooling Power Input W 1000 805
Heating Power Input W / /
Cooling Power Current A 4.4 3.5
Heating Power Current A / /
Rated Input W 1150 950
Rated Current A 5.5 4.3
Air Flow Volume(H/M/L) m3/h 320/290/260 320/290/260
Dehumidifying Volume L/h 1.43 1
EER W/W 2.6 2.6
COP W/W / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for the
Discharge Side MPa 3 3
Permissible Excessive Operating Pressure for the
Suction Side MPa 1.5 1.5
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse current A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC18~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 53/51/49 52/50/48
Sound Power Level (H/M/L) dB (A) 64/63/62 63/62/61
Dimension (WXHXD) mm 315X770X395 315X770X395
Dimension of Carton Box (LXWXH) mm 460X355X866 460X355X866
Dimension of Package (LXWXH) mm 463X358X881 463X358X881
Net Weight kg 27 24.5
Gross Weight kg 31 28.5
Refrigerant R290 R290
Refrigerant Charge kg 0.22 0.16
