Gree SEER13 Series Operating manual

Household Unit Technical Service Manual
1
Household Unit
Technical Service Manual
SEER13:
HW(R)18-D/HNF(R)18-D HW(R)24-D/HNF(R)24-D
HW(R)30-D/HNF(R)30-D HW(R)36-D/HNF(R)36-D
HW(R)42-D/HNF(R)42-D HW(R)48-D/HNF(R)48-D
HW(R)60-D/HNF(R)60-D
SEER10~12:
HW(R)18M-D HW(R)24M-D
HW(R)30M-D HW(R)36M-D
HW(R)42M-D HW(R)48M-D
HW(R)60M-D

Household Unit Technical Service Manual
2
Contents
Chapter 1 General Information
1.1 Model Identification
1.2 Product Features
1.3 External View
1.3.1 External View of Outdoor Unit
1.3.2 External View of Indoor Unit
1.4 Dimensional Size and Installation Space
1.4.1 Overall Dimension
1.4.1.1 Overall Dimension of Outdoor Unit
1.4.1.2 Overall Dimension of Indoor Unit
1.4.2 Installation Requirements
1.4.2.1 Installation Space of Outdoor Unit
1.4.2.2 Installation of Indoor Unit
1.4.3 Handling of Outdoor Unit
1.4.4 Power Requirements
1.4.5 Selection of Installation Location
1.5 Range of Working Temperature
1.6 Adjustment of Refrigerant Charge
1.7 Working Principle and System Diagram
1.8 Performance Specifications
1.8.1 SEER13 Specifications and Technical Data
1.8.2 SEER10～12 Specifications and Technical Data
Chapter 2 Electrical and Control
2.1 Outdoor Side Wiring Diagram
2.2 Indoor Side Wiring Diagram
Chapter 3 Run Test and Fault Analysis
3.1 Checklist of Operating Conditions
3.2 Fault Analysis

Household Unit Technical Service Manual
3
3.2.1 Fault Analysis Flow
3.2.2 Fault Analysis
Chapter 4 Care and Maintenance
4.1 Explosion View and Parts List for Model SEER13
4.1.1 Explosion View and Parts List for HW(R)18-D & HW(R)24-D
4.1.2 Explosion View and Parts List for HW(R)30-D
4.1.3 Explosion View and Parts List for HW(R)36-D & HW(R)42-D
4.1.4 Explosion View and Parts List for HW(R)48-D & HW(R)60-D
4.1.5 Explosion View and Parts List for HNF(R)18-D, HNF(R)24-D, HNF(R)30-D, HNF(R)36-D,
HNF(R)42-D, HNF(R)48-D & HNF(R)60-D
4.2 Explosion View and Parts List for Model SEER10~12
4.2.1 Explosion View and Parts List for HW(R)18M-D, HW(R)24M-D, HW(R)30M-D &
HW(R)36M-D
4.2.2 Explosion View and Parts List for HW(R)42M-D, HW(R)48M-D & HW(R)60M-D
4.3 Parts Removal Procedures
4.4 Care and Maintenance
4.4.1 Maintenance of Heat Exchanger
4.4.2 Maintenance at the Start of Service Season
4.4.3 Maintenance at the End of Service Season
4.4.4 Cautions
4.5 Important Repairs
4.5.1 Add compressor oil
4.5.2 Replace the compressor
4.5.3 Treatment of Leakage in System Pipeline
4.5.4 Vacuuming of System Pipeline after Repair
4.5.5 Determination of Refrigerant Charge after Repair

Household Unit Technical Service Manual
4
Chapter 1 General Information
1.1 Model Identification
Model Definition:
Definition Unit Indoor Unit Function Cooling Mode Cooling Capacity
Expression HN-Indoor unit
HW-Outdoor unit
With fan-F
No fan-None
Cooling-only - None
Heat pump-R
Heat pump + auxiliary
heating -Rd
Air cooled – None
Water cooled - S
Nominal cooling
capacity
(×1000Btu/h)
Definition Special Functions Refrigerant Design S/N Power Supply Code
Expression Fixed frequency – None
Variable frequency - P
R22-None
R407-N Arrayed in A, B, C… Identical to QJ/GD24.02.2 – Model
Nomenclature Rules for Export
Products
Model Illustration:
1) HWR60-D represents the heat pump outdoor unit of U.S household central conditioner with a cooling
capacity of 60000Btu/h (ton), in which “D” indicates the power supply: single-phase, 220V, 60Hz.
2) HNF36/A-C represents the single-cooling indoor unit with fan of U.S household central conditioner, with
a cooling capacity of 36000Btu/h (3 ton), in which “/A” indicates the first modification design and “C”
indicates the power supply: single-phase, 220V, 50Hz.
1.2 Product Features
U.S household unit is also named compressor condensing unit. HW series U.S household unit is a type of
general outdoor air conditioning unit. Combined with the HNF series indoor unit (Air handler), it can form into
duct-type household central air conditioning system according to the user’s needs. It is suitable to deluxe
multi-room houses with a large area, e.g. villa, complex building. And it is also suitable to small- and medium
plaza, office spaces and workshops.
◇ Simple Structure and Small Size: The plating part consists of 4 components only, i.e. cover plate,
chassis, side plate and condenser connection plate. The size is small down to 610mmX610mm (L X W).
◇ Easy Installation: The unit can be directly placed outdoors and fixed with anchor bolts.
◇ Beautiful Appearance and High Strength: Te full set of plating parts are formed by molding. The
appearance is beautiful and plastic sprayed for enhanced corrosion resistance.
◇ Highly Efficient and Energy Saving: Application of high-quality compressor. The evaporator employs
hydrophilic filming aluminum and inner-threaded copper pipe to enhance the heat exchange efficiency.
This has increased the seasonal energy-efficiency ratio high up to 13.
◇ Safe and Reliable Operation: The unit is CSA & UL certified and proven in numerous tests.
◇ High Quality of Indoor Air: The unit may be connected to multiple air outlets for even distribution of
the temperature and humidity in the room. And fresh air duct is embedded for connection of fresh air to
Power Ratings
Desi
g
n S/N
Refrigerant
Special Functions
Coolin
g
Capacit
y
Coolin
g
Mode
Functions
Indoor Unit
U.S Household Central Air Conditioning Unit

Household Unit Technical Service Manual
5
enhance indoor air quality.

Household Unit Technical Service Manual
6
1.3 External View
1.3.1 External View of Outdoor Unit
1.3.2 External View of Indoor Unit

Household Unit Technical Service Manual
7
1.4 Dimensional Size and Installation Space
1.4.1 Overall Dimension
1.4.1.1 Overall Dimension of Outdoor Unit
A
B
出风
进风
进风
接液管
接气管
进风
进风 底部视图
C
C
D
D
Model SEER13:
Unit: mm
Model HW(R)18-D
HW(R)24-D
HW(R)30-D
HW(R)36-D
HW(R)42-D
HW(R)48-D HW(R)60-D
A 610 710 710 762
B 604 718 830 830
C 394 494 494 494
D 451 551 551 551
Model SEER10~12:
Unit: mm
Model HW(R)18M-D
HW(R)24M-D
HW(R)30M-D HW(R)36M-D HW(R)42M-D
HW(R)48M-D
HW(R)60M-D
A 610 610 610 710 710
B 604 718 830 718 830
C 394 394 394 494 494
D 451 451 451 551 551
Ai
r
Outlet
A
ir Intake
A
ir Intake
A
ir Intake
A
ir Intake
To gas pipe
To liquid pipe
Bottom View

Household Unit Technical Service Manual
8
1.4.1.2 Overall Dimension of Indoor Unit
Unit: mm
1.4.2 Installation Requirements
1.4.2.1 Installation Space of Outdoor Unit
地面
楼面
8
Model
HNF18-D
HNF24-D
HNF30-D
HNF36-D
HNF42-D
HNF48-D
HNF60-D
A 430 520 520
B 535 535 680
C 1040 1180 1180
Floor
Ground

Household Unit Technical Service Manual
9
1.4.2.2 Installation of Indoor Unit
For HNF series U.S household unit, three installations are available at your option:
1.4.3 Handling of Outdoor Unit
To handle the unit, be sure to use two ropes of enough length to lift from four directions. To avoid deviation
from the center of unit, the angle between the lifting ropes must be less than 40o. Please refer to below:
40¡ ã
危险
1.4.4 Power Requirements
◇ The power capacity shall be enough high and the section area of the cable shall be enough big. For
detail, please consult your dealer or professional engineer.
◇ The air conditioning unit must be securely earthed. The earth wire shall be connected to the special
earthing device of the construction. Never connect the earth wire to the gas pipe, water pipe, lightning
arrestor or telephone earth wire.
◇ The circuit must be installed by professional technicians in accordance with the national cabling rules.
◇ In the fixed circuit, leakage protection switch and air switch of enough power capacity must be installed.
Upward Blow Installation Level Blow Installation Downward Blow Installation
DANGER
Below 40℃

Household Unit Technical Service Manual
10
1.4.5 Selection of Installation Location
◇ The compressor condensing unit must be installed on the stable and firm supporting plane outside the
construction.
◇ The compressor condensing unit shall be installed as close as possible to the indoor unit, thus to
decrease the length and bends of the cooling pipe.
◇ Avoid installing the unit beneath the window or between the constructions; otherwise the normal
operating noise may invade into the room.
◇ Select a well-ventilated place where the inlet and outlet air will not be blocked.
◇ Do no install in a place subject to polluting air, e.g. flammable and explosive substances, heavy dusts,
salt fog, etc.
1.5 Range of Working Temperature
Indoor Unit Outdoor Unit
Dry Bulb Temp.
()
Wet Bulb Temp.
()
Dry Bulb Temp.
()
Wet Bulb Temp.
()
Max. COOL Mode Operation 26.7 19.4 46.1 23.9
Min. COOL Mode Operation 21 15 21 -
Max. HEAT Mode Operation 26.7 - 23.9 18.3
Min. HEAT Mode Operation 20 - -5 -6
1.6 Adjustment of Refrigerant Charge
The charge before shipment is suitable a pipe length of 6m. If the pipe is longer than 6m, add refrigerant as
specified below:
Outer Diameter of Liquid Pipe (mm) Additional Refrigerant Charge for Every 1.5m of Liquid
Pipe (g)
9.5 87
12.7 115
1.7 Working Principle and System Diagram
Cooling Cycle: The compressor absorbs the low-temperature and low-pressure refrigerant steam from the
evaporator and compresses it into high-temperature high-pressure gas before discharging it into the
condenser. Within the condenser, the refrigerant gas exchanges heats with the outdoor air and transfers the
heats to the air. Then, it is condensed to high-temperature and high-pressure refrigerant liquid. After
reduction of temperature and pressure via throttling device, the refrigerant is changed to low-pressure
low-temperature gas and liquid phases. Then, it enters into the evaporator for heat exchange and turns into
low-temperature low-pressure gas refrigerant after absorbing the heats from the air. The refrigerant gas from
the evaporator is again absorbed into the compressor for compression. This cycle is so repeated and the
cooled air is continuously blown into the air conditioning area under the force of the fan.
Heating Cycle: The heating cycle is reverse to the cooling cycle. Via –4way valve, the refrigerant changes
its flow direction in the system. That is, the high-temperature high-pressure refrigerant gas from the
compressor directly enters into the indoor side heat exchanger for condensing. In the heat exchanger, the
high-temperature high-pressure refrigerant exchanges the heats with the air and becomes liquid refrigerant
after discharging the heats. Via the throttling device, the liquid refrigerant enters into the outdoor side heat
changer for vaporization. After that, the low-temperature low-pressure refrigerant gas again enters into the
