Gree GPC07AH-K3NNC3D User manual

Service Manual
GREE ELECTRIC APPLIANCES,INC.OF ZHUHAI
Change for Life
Service Manual
GPC07AH-K3NNC3D
GPC08AH-K3NNC3D
GPC09AH-K3NNC3D
GPC08AH-K3NNC4A
GPC08AH-K3NNC4B
GPC07AH-K3NNC4B
GPC07AH-K3NNC4D
GPC08AH-K3NNC4D
GPC08AH-K3NNC5A
GPC09AH-K3NNC5A
GPC07AH-K3NNC5B
GPC08AH-K3NNC5B
GPC08AH-K3NNC5C
GPC09AH-K3NNC5C
GPC07AH-K3NNC5D
GPC08AH-K3NNC5D
GPC09AH-K3NNC5D
(Refrigerant R410A)
Models:

Service Manual
Table of Contents
Part Ⅰ: Technical Information............................................................ 1
1. Summary .................................................................................................... 1
2. Specications.......................................................................................... 2
3. Outline Dimension Diagram........................................................... 20
4. Refrigerant System Diagram ......................................................... 23
5. Electrical Part......................................................................................... 24
5.1 Wiring Diagram ......................................................................................... 24
5.2 PCB Printed Diagram................................................................................ 27
6. Function and Control......................................................................... 31
6.1 Introduction of control panel...................................................................... 31
6.2 Remote Controller Introduction ................................................................. 32
6.3 Introduction of Basic Mode Function......................................................... 35
Part Ⅱ: Maintenance ............................................................................ 37
7. Notes Maintenance ............................................................................. 37
8. Install.......................................................................................................... 40
8.1 Install Drainage Pipe................................................................................. 40
8.2 Install Window Frame................................................................................ 40
8.3 Installation and Disassembly of Heat Discharge Pipe............................... 41
8.4 Operation test............................................................................................ 43
8.5 Drainage way ............................................................................................ 43
8.6 Clean and Maintenance ............................................................................ 44
9. Maintenance ........................................................................................... 45
9.1 Error Code................................................................................................. 45
9.2 Malfunction Detection Flowchart............................................................... 47
9.3 Maintenance Method for Common Malfunction ........................................ 53
10. Exploded View and Parts List .................................................... 55
11. Removal Procedure.......................................................................... 70
Appendix:...................................................................................................... 81
Appendix 1: Reference Sheet of Celsius and Fahrenheit ............................... 81
Appendix 2: List of Resistance for Temperature Sensor ................................. 82
Appendix 3: Resistance Value Table of Humidity Sensor ............................... 85
Table of Contents

1
Technical Information
Service Manual
GPC08AH-K3NNC4A
GPC07AH-K3NNC4B
GPC08AH-K3NNC4B
GPC07AH-K3NNC4D
GPC08AH-K3NNC4D
GPC07AH-K3NNC3D
GPC08AH-K3NNC3D
GPC09AH-K3NNC3D
GPC08AH-K3NNC5A
GPC09AH-K3NNC5A
GPC07AH-K3NNC5B
GPC08AH-K3NNC5B
GPC08AH-K3NNC5C
GPC09AH-K3NNC5C
GPC07AH-K3NNC5D
GPC08AH-K3NNC5D
GPC09AH-K3NNC5D
YX1F
1. Summary
Part Ⅰ: Technical Information
Remote Controller:
Models:
ON/OFF MODE
FAN SWING
SLEEP TIMER
+
-
AUTO
COOL
DRY
FAN
HEAT
T-ON T-OFF
SWING
SLEEP
LOCK
SPEED

2Technical Information
Service Manual
2. Specications
Parameter Unit Value
Model GPC08AH-K3NNC4A GPC08AH-K3NNC5A
Product Code CK01001431 CK01001471
CK01001476
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 8000 8000
Heating Capacity Btu/h / /
Cooling Power Input W 890 890
Heating Power Input W / /
Cooling Power Current A 3.95 3.87
Heating Power Current A / /
Rated Input W 1100 1100
Rated Current A 5.10 5.50
Air Flow Volume(H/M/L) m3/h 350/300/250 350/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.99 8.99
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 12-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 56/54/52 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62 66/64/62
Dimension (WXHXD) mm 300X800X355 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 559X349X820
Dimension of Package (LXWXH) mm 565X355X850 562X352X835
Net Weight kg 23 23.5
Gross Weight kg 28 28.5
Refrigerant R410A R410A
Refrigerant Charge kg 0.39 0.39

3
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
Xi’an Qing’an Refrigeration Equipment
Co., Ltd
Xi’an Qing’an Refrigeration Equipment
Co., Ltd
Compressor Model YZG-A082Y2T2 YZG-A082Y2T2
Compressor Oil POE(RB68EP) POE(RB68EP)
Compressor Type Rotary Rotary
L.R.A. A 17.00 17.00
Compressor RLA A 3.50 3.50
Compressor Power Input W 730 730
Overload Protector B135-140-241E B135-140-241E
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

4Technical Information
Service Manual
Parameter Unit Value
Model GPC09AH-K3NNC5A GPC09AH-K3NNC3D
Product Code CK01001484 CK010023000
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 9000 9000
Heating Capacity Btu/h / /
Cooling Power Input W 1000 1010
Heating Power Input W / /
Cooling Power Current A 4.44 4.44
Heating Power Current A / /
Rated Input W 1250 1250
Rated Current A 5.8 5.8
Air Flow Volume(H/M/L) m3/h 350/300/250 330/300/250
Dehumidifying Volume L/h 0.95 0.95
EER Btu/w.h 9.00 8.91
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m212-18 12-18
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure
for the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure
for the Suction Side MPa 1 1.7
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 56/54/52 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62 66/64/62
Dimension (WXHXD) mm 300X807X375 300X790X345
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X825
Dimension of Package (LXWXH) mm 565X355X850 565X355X840
Net Weight kg 27 27
Gross Weight kg 32 31
Refrigerant R410A R410A
Refrigerant Charge kg 0.48 0.48

5
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR
C0.LTD. / GREE
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-B102T130 QXA-B102T130A
Compressor Oil POE(RB68EP) RB68EP
Compressor Type Rotary Rotary
L.R.A. A 19 19.1
Compressor RLA A 3.9 3.9
Compressor Power Input W 850 830
Overload Protector UP3-21 HPA-318
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

6Technical Information
Service Manual
Parameter Unit Value
Model GPC07AH-K3NNC4B GPC07AH-K3NNC5B
Product Code CK010018500 CK010018600
CK010018601
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 7000 7000
Heating Capacity Btu/h / /
Cooling Power Input W 790 790
Heating Power Input W / /
Cooling Power Current A 3.50 3.50
Heating Power Current A / /
Rated Input W 950 950
Rated Current A 4.00 4.00
Air Flow Volume(H/M/L) m3/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.86 8.86
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 64/62/60 64/62/60
Dimension (WXHXD) mm 300X800X355 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.43 0.43

7
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A071L130A QXA-A071L130A
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
L.R.A. A 13.50 13.50
Compressor RLA A 2.80 2.80
Compressor Power Input W 615 615
Overload Protector B120-135A-241E B120-135A-241E
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

8Technical Information
Service Manual
Parameter Unit Value
Model GPC08AH-K3NNC4B GPC08AH-K3NNC5B
Product Code CK010018800 CK010018900
CK010018901
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 8000 8000
Heating Capacity Btu/h / /
Cooling Power Input W 900 900
Heating Power Input W / /
Cooling Power Current A 4.00 4.00
Heating Power Current A / /
Rated Input W 1100 1100
Rated Current A 4.60 4.60
Air Flow Volume(H/M/L) m3/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.89 8.89
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 64/62/60 64/62/60
Dimension (WXHXD) mm 300X800X355 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.43 0.43

9
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A081L130 QXA-A081L130
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
L.R.A. A 15.50 15.50
Compressor RLA A 3.30 3.30
Compressor Power Input W 730 730
Overload Protector B130-140B-241E B130-140B-241E
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

10 Technical Information
Service Manual
Parameter Unit Value
Model GPC08AH-K3NNC5C GPC09AH-K3NNC5C
Product Code CK010019800 CK010019900
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 8000 9000
Heating Capacity Btu/h / /
Cooling Power Input W 975 1100
Heating Power Input W / /
Cooling Power Current A 4.2 4.8
Heating Power Current A / /
Rated Input W 1100 1250
Rated Current A 4.60 5.80
Air Flow Volume(H/M/L) m3/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.21 8.18
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 56/54/52 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62 66/64/62
Dimension (WXHXD) mm 300X807X375 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 23.5 27
Gross Weight kg 28.5 32
Refrigerant R410A R410A
Refrigerant Charge kg 0.39 0.48

11
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A086R130 QXA-B102T130
Compressor Oil RB68EP POE(ZE-GLES RB68EP)
Compressor Type Rotary Rotary
L.R.A. A 15.5 19
Compressor RLA A 3.5 3.9
Compressor Power Input W 730 850
Overload Protector B155-150-241E UP3-21
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

12 Technical Information
Service Manual
Parameter Unit Value
Model GPC07AH-K3NNC3D GPC08AH-K3NNC3D
Product Code CK010020900 CK010021000
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 7000 8000
Heating Capacity Btu/h / /
Cooling Power Input W 790 900
Heating Power Input W / /
Cooling Power Current A 3.5 4.2
Heating Power Current A / /
Rated Input W 950 1130
Rated Current A 4.0 4.6
Air Flow Volume(H/M/L) m3/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.86 8.89
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1.7
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 65/63/61 65/63/61
Dimension (WXHXD) mm 300X790X345 300X790X345
Dimension of Carton Box (LXWXH) mm 562X352X825 562X352X825
Dimension of Package (LXWXH) mm 565X355X840 565X355X840
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.48 0.46

13
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A071L130B QXA-A083A130
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
L.R.A. A 15 15
Compressor RLA A 2.8 3.5
Compressor Power Input W 615 740
Overload Protector UP3-B0 UP3-A0
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

14 Technical Information
Service Manual
Parameter Unit Value
Model GPC07AH-K3NNC4D GPC08AH-K3NNC4D
Product Code CK010021100 CK010021200
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 7000 8000
Heating Capacity Btu/h / /
Cooling Power Input W 790 900
Heating Power Input W / /
Cooling Power Current A 3.5 4.2
Heating Power Current A / /
Rated Input W 950 1130
Rated Current A 4.0 4.6
Air Flow Volume(H/M/L) m3/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.86 8.89
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1.7
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 65/63/61 65/63/61
Dimension (WXHXD) mm 300X800X355 300X800X355
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.48 0.46

15
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A071L130B QXA-A083A130
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
L.R.A. A 15 15
Compressor RLA A 2.8 3.5
Compressor Power Input W 615 740
Overload Protector UP3-B0 UP3-A0
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

16 Technical Information
Service Manual
Parameter Unit Value
Model GPC07AH-K3NNC5D GPC08AH-K3NNC5D
Product Code
CK010021300
CK010021301
CK010021302
CK010021400
CK010021401
Power
Supply
Rated Voltage V ～220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 7000 8000
Heating Capacity Btu/h / /
Cooling Power Input W 790 900
Heating Power Input W / /
Cooling Power Current A 3.5 4.2
Heating Power Current A / /
Rated Input W 950 1130
Rated Current A 4.0 4.6
Air Flow Volume(H/M/L) m3/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.86 8.89
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m210-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side MPa 1 1.7
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp oC 16~30 16~30
Ambient Temp (Cooling) oC 16~35 16~35
Ambient Temp (Heating) oC / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 65/63/61 65/63/61
Dimension (WXHXD) mm 300X807X375 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.48 0.46

17
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A071L130B QXA-A083A130
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
L.R.A. A 15 15
Compressor RLA A 2.8 3.5
Compressor Power Input W 615 740
Overload Protector UP3-B0 UP3-A0
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /

18 Technical Information
Service Manual
Parameter Unit Value
Model GPC09AH-K3NNC5D
Product Code CK010023800
Power
Supply
Rated Voltage V ～220-240
Rated Frequency Hz 50
Phases 1
Cooling Capacity Btu/h 9000
Heating Capacity Btu/h /
Cooling Power Input W 1010
Heating Power Input W /
Cooling Power Current A 4.44
Heating Power Current A /
Rated Input W 1250
Rated Current A 5.8
Air Flow Volume(H/M/L) m3/h 330/300/250
Dehumidifying Volume L/h 0.95
EER Btu/w.h 8.91
COP Btu/w.h /
SEER /
HSPF /
Application Area m212-18
Climate Type T1
Isolation I
Moisture Protection IPX0
Permissible Excessive Operating Pressure
for the Discharge Side MPa 3.8
Permissible Excessive Operating Pressure
for the Suction Side MPa 1.7
Throttling Method Capillary
Defrosting Method /
Fuse A 3.15
Operation Temp oC 16~30
Ambient Temp (Cooling) oC 16~35
Ambient Temp (Heating) oC /
Sound Pressure Level (H/M/L) dB (A) 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62
Dimension (WXHXD) mm 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835
Dimension of Package (LXWXH) mm 565X355X850
Net Weight kg 27
Gross Weight kg 31
Refrigerant R410A
Refrigerant Charge kg 0.48
