Green-Box Technology HDMI-E102T User manual

HDMI Expander-Cat5
Digital
Media Product
User Manual
HDMI-E102T
HDMI-E102TR
HDMI-E104C
HDMI-E108C

User Manual
2
3
One-Port HDMI Transmitter : HDMI-E102T
One-Port HDMI Transceiver : HDMI-E102TR
4-Port HDMI Transceiver with One Local Input
8-Port HDMI Transceiver with One Local Input
TABLE OF CONTENTS
Package Contents
Introduction
Key Features
Panel Description
Installation and Operation
Specication
4
5
7
8
10
19
(C) 2007 Green-Box Technology Co., Ltd.,
All Rights Reserved
Reserves in the hardware, packaging and
accompanying documentation.

User Manual
4
5
/ Introduction
The Cat5 HDMI Expander system consists of Transmitter, Transceiver and
Receiver. The system can extend HDMI signals over Cat5/5e/6 FTP cable.
By cascading Transceivers, it is possible to extend the HDMI signals with
almost unlimited capacity. The Cat5 HDMI Expander system is a great
solution for digital signage, public information display, and large scale
demonstration, where crystal-clear, high-resolution digital video needs to be
shown.
By taking the advantage of cost efficient Cat5/5e/6 FTP cable, the Cat5
HDMI Expander can simplify installation. With its unlimited cascading
capacity, you can extend digital video displays almost anywhere. The
Transmitter and Transceiver units are tted with magnetic pads, enabling
them to be quickly attached to metal surfaces. A screw xing plate is also
included for permanent installations.
/ Package Contents
A. HDMI-E102T : One Port HDMI Expander Transmitter
1. HDMI-E102T x 1
2. HDMI Cable x 1
3. Power Adaptor DC5V x 1
4. User Manual
B. HDMI-E102TR : One Port HDMI Expander Transceiver
1. HDMI-E102TR x 1
2. Power Adaptor DC5V x 1
3. User Manual
C. HDMI-E104C: 4-Port HDMI Transceiver
1. HDMI-E104C x 1
2. HDMI Cable x 1
3. HDMI-HR Receiver x 1
4. Power Adaptor DC5V, 3A x 1
D. HDMI-E108C: 8-Port HDMI Transceiver
1. HDMI-E108C x 1
2. HDMI Cable x 1
3. HDMI-HR Receiver x1
4. Power Adaptor DC5V, 3A x 1
HDMI-E102TR
One-Port HDMI Transceiver
HDMI Cable (for Player)
HDMI-HR
HDMI-RJ45 Receiver

User Manual
6
7
/ Key Features
1. Unlimited cascading of HDMI over Cat5/5e/6 FTP cable
2. The system consists of Transmitter, Transceiver and Receiver.
Transmitter has a HDMI local connection and extends the HDMI signal
over Cat5/5e/6 FTP cable.
3. Transceiver has a HDMI input port (RJ-45 or HDMI type), 4/8 HDMI
RJ-45 output ports and cascading function to extend the HDMI signal
over Cat5/5e/6 FTP cable.
4. Video Amplier Bandwidth: 1.65GHz
5. Maximum distance between Transmitter and Transceiver is determined
by display resolution and FTP cable type and quality. Typical distances
are: < 80m. for 480p, < 70m. for 720p/1080i, < 30m. for 1080p.
(Distances are based on FTP cable skew < 15ns/100m).
6. Maximum distance between Transceiver and HDMI-HR Receiver
determined by display resolution and FTP cable type and quality.
Typical distances are: < 30m. for 480p/720p/1080i, < 15m. for 1080p.
(Distances are based on FTP cable skew < 15ns/100m).
7. HDMI Input/Output Connector: HDMI digital signal
8. EQ control to adjust the video quality
9. LED status to indicate HDMI activity
10.Magnetic pad and attachable metal plate on each device for easy
installation
HDMI –E104C
4-Port HDMI Transceiver
HDMI –E108C
8-Port HDMI Transceiver

User Manual
8
9
2. HDMI-E104C and HDMI-E108C Transceiver
3. HDMI Cable and Cat5 HDMI-RJ45 Receiver
/ Panel Description
1. HDMI-E102T Transmitter and HDMI-E102TR Transceiver
❶❸❷
❹
❺ Link Indicator of Local Monitor (MI)
❻ HDMI Output for Local Monitor (MI)
❼ HDMI Input (Use HDMI connector)
❽ RJ-45 HDMI Input
❾ Link Indicator
❿ Power Indicator
❶ Video EQ Control
❷ Power Jack
❸ RJ-45 HDMI Output
❹ EQ Indicator
LED ON : Auto EQ
LED Off : Manual
❻ ❼ ❽
❺
To HDMI Player To HDMI Input of Transmitter
❹
❶❸❷ ❻
❺❹
❹
❿❾
❶ ❸❷
❼ EQ Indicator
LED ON : Auto EQ
LED Off : Manual
❽ HDMI Output
❾ HDMI Input
❿ Video EQ Control
❶ EDID Activity
❷ Link of Local Monitor
❸ Power Indicator
❹ Power Jack
❺ RJ-45 HDMI Output
❻ RJ-45 System Link Out
❻ ❽❺❹ ❿❾
HDMI-HR
HDMI-RJ45 Receiver
❶ ❸❷
❻ ❽❺❹ ❿❾
❼ ❼
HDMI Cable (for Player)
HDMI Output
RJ-45 HDMI Iutput

User Manual
10
11
(7) LINK OUT: HDMI signal can be extended/cascaded over “LINK
OUT” port by Cat5/5e/6 FTP cable, please refer to “Selection and
Preparation of Cat5/5e/6 cable.” The signal can be received by
following three ways (A), (B) and (C):
A. HDMI-HR: The HDMI distance can be extended is: < 30m. for
480p/720p/1080i, or < 15m. for 1080p. (Distance is based on FTP
cable skew < 15ns/100m).
B. “LINK IN” of HDMI-E102TR: Typical cascaded distance is: < 80m. for
480p, < 70m. for 720p/1080i, or < 30m. for 1080p. (Distance is based
on FTP cable skew < 15ns/100m). The installation of HDMI-E102TR
is described in next section.
C. “HDMI IN” of HDMI-E104C/HDMI-E108C: To connect to the HDMI
connector, a HDMI-HR Receiver is required. Typical cascaded
distance is: < 80m. for 480p, < 70m. for 720p/1080i, or < 30m. for
1080p. (Distance is based on FTP cable skew < 15ns/100m).
/ Installation and Operation
1. Install HDMI-E102T Transmitter:
(1) First Time Set-up: Please turn off the HDMI output device and
monitors.
(2) Device Connection: Connect local HDMI monitor (M1) to the “HDMI/
M1 OUT” of the transmitter and take the HDMI cable, plug one end
to “HDMI IN” port of transmitter and the other end of the cable to the
HDMI output port of HDMI output device.
(3) Connect the power adaptor to the “DC5V” and plug into the power
outlet.
(4) System Turned On: Turn on your HDMI output device and monitor to
conrm the function of display. The “M1 LINK” LED of the transmitter
should turn on orange to reflect the connection of a local HDMI
monitor.
(5) Other Monitors: Please make sure the other HDMI monitors used in
Transceiver can also display the video resolution broadcasted.
(6) EQ Adjustment: In most of the cases, you can adjust the EQ control
to Auto mode by rotate the EQ to the left side and the “EQ” and ”
Auto” LEDs will turn on blue. If you see some dynamic dots or unclear
image on the HDMI monitor, it reflects the HDMI signal received by
Transmitter need to be adjusted. Then you can adjust the EQ control
for better image display, it will turn the EQ into manual mode, the “EQ”
and ”Auto” LED will turn off to indicate the manual EQ mode.
HDMI
Player
HDMI Transmitter
Power Adaptor
HDMI
Connection of HDMI Transmitter
Three Ways of Extending HDMI Signal from HDMI Transmitter
Power Adaptor
HDMI
Cat5/5e/6 Cable (Long Distance)
HDMI Transceive HDMI Transmitter HDMI Player
HDMI
HDMI
HDMI
A B C
HDMI
Multi-Port HDMI
Transceiver
X 8
Power Adaptor
Power Adaptor
Cat5/5e/6 Cable (Short Distance)
Cat5/5e/6 Cable
(Short Distance)

User Manual
12
13
2. Installation of HDMI-E102TR Transceiver:
(1) Monitor Connection: Connect HDMI monitor’s HDMI cable to
Transceiver and turn on the monitor.
(2) Device Connection: Plug power adaptor to HDMI-E102TR, the “PWR”
LED and “M1 LINK” will turn ON, the other “LINK” LED should turn off,
since there is no input of video signal from “LINK IN” port.
(3) HDMI Cascading: The RJ-45 “LINK IN” port is designed to receive
the HDMI signal from Transmitter over Cat5/5e/6 FTP cable, follow
previous section to install Transmitter and extend the HDMI signal
here.
(4) EQ Adjustment : In most of the cases, you can adjust the EQ control
to Auto mode by rotate the EQ to the left side and the “EQ” and ”
Auto” LEDs will turn on blue. After connecting the expander system, if
you see some dynamic dots or unclear image on the HDMI monitor, it
reects the HDMI signal received by Transmitter need to be adjusted.
Then you can adjust the EQ control for better image display, it will turn
the EQ into manual mode, the “EQ” and ”Auto” LED will turn off to
indicate the manual EQ mode.
(5) LINK OUT : The function of “LINK OUT” port on Transceiver will act
the same as Transmitter’s. It can extend/cascade HDMI signal to (A)
HDMI-HR Receiver, (B) another one-port HDMI Transceiver or (C)
4/8-port HDMI Transceiver as following illustration.
HDMI
Player
HDMI TransmitterHDMI Transceiver
Cat5/5e/6
Power Adaptor Power Adaptor
HDMI HDMI
HDMI Transceiver
Power Adaptor
HDMI
Connection of HDMI Transceiver
Power Adaptor
HDMI
Cat5/5e/6 Cable (Long Distance)
HDMI Transceive HDMI Transceive
HDMI signal
received from
Expander
System
HDMI
HDMI
HDMI
A B C
HDMI
Multi-Port HDMI
Transceiver
X 8
Power Adaptor
Power Adaptor
Cat5/5e/6 Cable
(Short Distance)
Three Ways of Extending HDMI Signal from HDMI Transmitter

User Manual
14
15
3. Installation of HDMI-E104C / HDMI-E108C Multi-port Transceiver:
(1) These two models have the same function and are only different in the
amount of RJ-45 HDMI output.
(2) Monitor Connection: Connect HDMI monitor’s HDMI cable to Multi-port
Transceiver’s “HDMI/LOCAL OUT” port and turn on the monitor.
(3) Device Connection: Plug power adaptor to Multi-port Transceiver,
the front panel’s “POWER” LED and “LOCAL LINK” will turn ON, the
“ACTIVE” LED will turn ON till Transceiver has received active HDMI
signal.
(4) HDMI Sources: The “HDMI IN” can receive HDMI signal from (A)
standard HDMI output device or (B) HDMI-E102T / HDMI-E102TR /
HDMI-E104C / HDMI-108C by using a HDMI-RJ45 Receiver.
(5) EQ Adjustment: In most of the cases, you can adjust the EQ control
to Auto mode by rotate the EQ to the left side and the “EQ” and ”
Auto” LEDs will turn on blue. After connecting the expander system, if
you see some dynamic dots or unclear image on the HDMI monitor, it
reects the HDMI signal received by Transmitter need to be adjusted.
Then you can adjust the EQ control for better image display, it will
turn the EQ into manual mode, the “EQ” and ”Auto” LED will turn off
to indicate the manual EQ mode.
(6) LINK OUT: The function of “LINK OUT” port on Multi-port Transceiver
is used to cascade HDMI signal to (A) one-port HDMI Transceiver or
(B) another 4/8-port HDMI Transceiver as following illustration.
Multi-port HDMI Transceiver
Power Adaptor
HDMI
Connection of Multi-port HDMI Transceiver
Cat5/5e/6 Cable (Long Distance)
HDMI Transceive
Standard HDMI Output Devices:
> HDMI Splitter/Selector
> Video game console
> Media PC, computers
> Set top boxes
> DVR,DVD player, and soon
HDMI
HDMI
Multi-Port HDMI
Transceiver
X 8
Power Adaptor
Cat5/5e/6 Cable
(Short Distance)
HDMI Cable
HDMI Transmitter
Multi-Port HDMI Transceiver
Connecting of HDMI Sources
Power Adaptor
HDMI
Cat5/5e/6 Cable (Long Distance)
HDMI Transceive
HDMI Output
Sources
HDMI
HDMI
HDMI A B
Multi-Port HDMI
Transceiver
X 8
Power Adaptor
Power Adaptor
Two Ways of Cascading HDMI Signal by Multi-port HDMI Transmitter
Multi-Port HDMI
Transceiver
Cat5/5e/6 Cable
(Short Distance)

User Manual
16
17
(7) Connecting Monitors: 4/8 HDMI monitors can be connected to the
“RJ-45 HDMI OUT” ports by adapting a HDMI-HR Receiver.
(8) Additional System Expansion: The “RJ-45 HDMI OUT” port can also
be used as link out port for more system expansions.
4. Selection and Preparation of Cat5/5e/6 FTP cable:
(1) Selection: Most makes and versions of current Cat5/5e/6 cables will
work with the DVI-E102T Transmitter and DVI-E102TR Transceivers.
However since the quality and characteristics of Cat5/5e/6 cable
varies it has been found that some perform better than others, even if
they cost lower. The major factor inuencing the transmitting distance
is the skew property of the cables. Skew represents the difference in
propagation delay between the fastest and slowest set of wire pairs.
A lower skew will mean a longer video transmitting distance.
(2) Skew Property: A Cat5/5e/6 cable with a skew lower than 15ns/100m
should enable a cascading length of <80m. at 480p resolution, <70m.
at 720p/1080i resolution and <30m. at 1080p resolution. Some cable
types may not have a known skew so it is best to test for maximum
practical distances before starting the installation.
(3) For some installations where the potential for interference exists the
FTP type of Cat5/5e/6 cable is recommended.
(4) The RJ-45 terminations to the Cat5/5e/6 cable must be made to the
EIA 568B specications.
(5) Connecting the Cat5/5e/6 FTP cable: Plug one end of the cable
to the Transmitter’s “LINK IN/OUT” port and the other end to the
Transceiver’s RJ-45 “LINK IN/OUT” port. The monitor connected to
the Transceiver should now display and the “LINK” or “ACTIVE” LED
should turn green to indicate the HDMI signal activation. Adjust the
“EQ” control for best quality HDMI display.
Multi-port HDMI Transceiver
Power Adaptor
HDMI
Connecting 8 HDMI Monitors
HDMI
Cat5/5e/6 Cable
(Short Distance)
X 8
1 2 3 4 5 6 7 8
JACK POSITION
PAIR 1PAIR 2 PAIR 4
PAIR 3
The EIA/TIA defination of 568B in the pin assignment is
(1) orange white, (2) orange, (3) green white, (4) blue,
(5) blue white, (6) green, (7) brown white, and (8) brown

User Manual
18
19
/ Specification
/ Remarks
1. Please read this operation manual carefully before installing the system.
2. Please use high quality Cat5/5e/6 cable for optimum results.
3. To prevent potential power damage do not use 2-wire extension cord.
Ensure AC outlets at PCs and displays are on the same phase and have
correct and common grounding.
4. Limited Warranty:
(1) In no events shall the vendor’s liability for direct or indirect, special,
incidental or consequential damages, loss of prot, loss of business,
or financial loss which hay be caused by the use of the product
exceeds the price paid for the product.
(2) The vendor makes no warranty or representation, expressed or
implied with respect to the contents or use of this documentation,
and especially disclaims its quality, performance, merchantability, or
tness for any particular purpose.
(3) The vendor also reserves the right to revise or update the product or
documentation without obligation to notify any user of such revisions
or updates. For further information, please contact your direct vendor.
HDMI
Player
HDMI TransmitterHDMI TransceiverHDMI Transceiver
Cat5/5e/6 Cat5/5e/6Cat5/5e/6
Power Adaptor Power Adaptor Power Adaptor
HDMI HDMI HDMI
Connection Diagram of HDMI Expander
5. Installing More Transceivers and Displays:
(1) Using additional Transceivers and Cat5/5e/6 FTP cable it is possible
to extend the system almost indefinitely to remote HDMI displays.
For a large group of cascaded Transceivers, please ensure common
grounding is maintained to minimize ground-loops and interference.
(2) A HDMI splitter or distribution amplier may be used at each HDMI
output to drive additional local HDMI displays.
Model
Cat5 HDMI
Transmitter
HDMI-E102T
Cat5 HDMI Transceiver
HDMI-E102TR HDMI-E104C HDMI-E108C
Input HDMI Female x 1 RJ-45 x 1 HDMI Female x 1 HDMI Female x 1
Output HDMI Female x 1
RJ-45 x 1
HDMI Female x 1
RJ-45 LINK Out x 1
HDMI Female x 1
RJ-45 HDMI Out x 4
RJ-45 LINK Out x 1
HDMI Female x 1
RJ-45 HDMI Out x 8
RJ-45 LINK Out x 1
Max Distance
and Resolution
480p with each cascading length < 80m, 720p/1080i with each cascading length < 70m
1080p with each cascading length < 30m
Video Control EQ x 1
Signal Type HDMI
Power Consumption DC5V , 750mA DC5V , 750mA DC5V 1.8A DC5V, 2.5A
Housing Metal
Dimension
(LxWxH) mm Compact Size, 62 x 113 x 29 1U Height, 240x180x44
