INTRODUCTION
CrystalView EX HDMI Manual 1
Disclaimer
While every precaution has been taken in the preparation of this manual, the manufacturer assumes no
responsibility for errors or omissions. Neither does the manufacturer assume any liability for damages resulting
from the use of the information contained herein. The manufacturer reserves the right to change the
specifications, functions, circuitry of the product, and manual content at any time without notice.
The manufacturer cannot accept liability for damages due to misuse of the product or other circumstances
outside the manufacturer’s control. The manufacturer will not be responsible for any loss, damage, or injury
arising directly or indirectly from the use of this product. (See limited warranty.)
System Introduction
Thank you for choosing the CrystalView EX HDMI extender from Rose Electronics for your KVM console
extension needs. The CrystalView EX HDMI system consists of a Transmitter unit and a Receiver unit. The
Transmitter unit connects to your computer’s HDMI and USB Type A connectors using the provided HDMI and
USB cables. The Receiver unit connects to your workstation. The Transmitter and Receiver units are
connected by industry standard CAT5e or better cable. This provides access to your computer from up to 330
feet away (100m).
The CrystalView EX HDMI extender supports both USB 1.1 and low to moderate bandwidth USB 2.0
devices. It is ideal for use with industrial controls, digital signage, connecting cameras for security systems,
and USB device printing, scanning and storage.
If support for additional USB devices is needed, up to 4 USB hubs in a single chain can be connect to the
Receiver ports, to a maximum of 30 USB devices.
The CrystalView EX HDMI supports all major operating systems including Windows®, MAC®, and Linux®
USB printers, scanners, web cameras, USB hard drives, flash drives, MP3 players and more can easily be
connected to the Receiver unit.
Since there are a number of factors that affect the operation of the CrystalView EX HDMI, there may be some
devices that are not compatible with this product.
Features
■Supports CAT5e/6/7 cable distances up to 330 feet (100m)
■Supports uncompressed HDMI video with resolutions up to 1080p, 1920 x 1200, and 4K@30Hz with no
loss of signal quality
■USB Host support – xHCI (USB3.0), EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)
■Supports high-speed USB devices (USB 2.0, up to 40Mbps), full-speed devices (USB 2.0 and 1.1, up to 12
Mbps), and low-speed devices (USB 2.0 and 1.1, at 1.5 Mbps)
■3 USB ports available on the Receiver unit
■Standard USB hubs can be used (up to 4 per chain), to increase the number of USB devices connected to
a maximum 30
■HDCP pass-through
■A full 500 mA of current is available at each USB port on the Receiver
■Plug-and-Play installation, no configuration or set-up needed.

CrystalView EX HDMI Manual 2
Package Contents
■The package contents consist of the following:
■1 x Transmitter unit and 1 x Receiver unit
■2 x 5V power adapters for Transmitter (1) and Receiver (1)
■USB Type A to Type B cable (6 ft)
■HDMI cable (male to male- 5 ft)
■Product Manual
Additional installation items that are required, but are not included in the package:
■USB compatible computer with HDMI video output
■1 x CATx cable (Transmitter to Receiver – Point-To-Point)
■USB 1.1 or 2.0 compatible peripheral devices
Additional cables are usually ordered separately. If the package contents are not correct, contact Rose
Electronics or your reseller so the problem can be quickly resolved.

MODELS
CrystalView EX HDMI Manual 3
CrystalView EX HDMI Models
The CrystalView EX HDMI comes in a single model as shown below.
Figure 1.Transmitter Front Panel
Indicators

Power

Link

USB

Video
Figure 2. Transmitter Rear Panel
Connectors

HDMI In

USB Type B

Link

Power (+5V)

Config
Figure 3. Receiver Front Panel
Indicators

Power

Link

USB

Video
Figure 4. Receiver Rear Panel
Connectors

HDMI Out

3 x USB Type A

Link

Power (+5V)

Config
Table 1. CrystalView EX HDMI Models

CrystalView EX HDMI Manual 4
Transmitter and Receiver Front Panel Indicators
Indicator Color Description
Power Green

On: Ready

Off: No Power
Link Green

On: Valid link between Transmitter and Receiver

Off: No Link
USB Green

On: Transmitter enumerated on host computer

Off: Computer and Transmitter not communicating

Blinking: Host computer is in USB Suspend Mode
Video Green

On: HDCP content is being transmitted

Blinking: Non-HDCP content is being transmitted

Off: No video transmission
Table 2. CrystalView EX HDMI Transmitter and Receiver Indicators
Transmitter Rear Panel Connectors
Connector Description
HDMI In HDMI video input from host computer
USB Type B USB connection to host computer
Link (RJ45) Connection to Receiver unit using CAT5e or better cable
Config Reserved for Rose Electronics’ use only
Power +5V power adapter with locking connector
Table 3. Transmitter Rear Panel Connectors
Receiver Rear Panel Connectors
Connector Description
HDMI Out HDMI video output to the monitor
USB Type A x 3 Connection to up to 3 remote USB devices
Link (RJ45) Connection to Transmitter unit using CAT5e or better cable
Config Reserved for Rose Electronics’ use only
Power +5V power adapter with locking connector
Table 4. Receiver Rear Panel Connectors

INSTALLATION AND OPERATION
CrystalView EX HDMI Manual 5
System Installation
Prior to installing the CrystalView EX HDMI, prepare the layout of the computer, the Transmitter, the Receiver,
and the equipment that will be connected to the Receiver. The Transmitter and Receiver units should be in
locations that are easily accessible. The CAT5e cable should be routed away from equipment or environments
that can cause interference with the data transmission between the Transmitter and Receiver.
The CrystalView EX HDMI is installed in a “Point-To-Point” configuration. This is done by connecting a CATx
cable (up to 330 ft / 100m) directly from the Transmitter’s RJ45 port to the Receiver’s RJ45 port.
The completed installation will appear as in the figure below.
Figure 5. CrystalView EX HDMI Installation
Transmitter Installation
3. Locate the Transmitter unit near the computer.
4. Connect the supplied USB Type A/B cable to the Transmitter unit’s USB Type B port and to an
available USB Type A port (1.1 or 2.0) on the computer.
5. Connect the supplied HDMI cable to the Transmitter unit’s HDMI port and to the HDMI video port on the
computer
6. Connect a CATx cable (not supplied) from the Transmitter’s RJ45 port to the Receiver’s (RJ45)
connector.
7. Connect the supplied 5V power adapter to an AC outlet and to the Transmitter’s power port.

CrystalView EX HDMI Manual 6
Receiver Installation
1. Locate the Receiver unit near the monitor and USB devices.
2. Using a HDMI cable, connect a HDMI monitor to the HDMI out connector on the Receiver’s rear panel.
3. Connect USB devices to the 3 USB Type A ports on the rear panel of the Receiver. Normally these
USB ports are connected to a USB keyboard, USB mouse, and a USB Hub.
4. Connect the CATx cable (not supplied) from the Transmitter’s RJ45 port to the Receiver’s RJ45
connector.
5. Connect the supplied 5V power adapter to an AC outlet and to the Receiver’s power port.
Note: CATx cable – It is recommended that only solid-core CAT5e or better, UTP/STP cabling be used to
connect the Transmitter and Receiver units together. The CAT5e cabling must have straight-through
conductors with no crossovers and terminated with 8 conductor RJ45 connectors at each end. The maximum
CATx cable length is 330 feet (100 meters).
Installation Verification
The Power, Link, Video, and USB LEDs on the Transmitter and Receiver units will provide information
regarding the installation, cabling, video, and other items. Verify that the LEDs are registering properly as
shown in Table 2.
If the Link LED is off, the CATx cable between the Transmitter and Receiver is not properly connected.
The Power LED should be solid green. If it is off, the system is not powered properly.
Windows users can confirm that the USB functionality of CrystalView EX HDMI by opening Device Manager.
Expand the entry for Universal Serial Bus controllers by clicking the “ + “ sign. If the EX HDMI has been
installed correctly, you should find it listed as a “generic hub”.
OS X users can open the System Profiler to confirm that CrystalView EX HDMI USB has been installed
correctly. In the left hand column under Hardware, select “USB” and inspect the right hand panel. If the EX
HDMI has been installed correctly, you should find it listed as a “Hub” under the USB High-Speed Bus/USB
Bus.
Connecting USB Devices
USB hubs connected to the Receiver unit allow more USB 1.1 and 2.0 equipment to be connected, up to a
maximum of 30 USB devices. Normally the three USB Type A connectors on the Receiver are connected to a
USB Keyboard, USB mouse, and a USB hub. Installing your USB devices is no different than installing them
directly to a computer’s USB port.
1. Install any software required to operate the USB device according to the manufacturer’s instructions
2. Connect the USB device to the Receiver’s USB ports or to a hub connected to the Receiver
3. Verify that the operating system has recognized the USB device and installed any drivers needed to
operate the USB device
4. Test the USB device
Each USB Type A port on the Receiver unit can supply up to 500ma to a USB device or USB hub. When
connecting additional USB devices through a USB hub, consider the total current needed to operate the hub
and all the devices connected to it. If the total power requirement is greater than 500ma, use a self-powered
hub.
The CrystalView EX HDMI is compatible with a wide variety or graphic cards, monitors, USB devices, and
operating systems.

CrystalView EX HDMI Manual 7
System Operation
The operation of the CrystalView EX HDMI is no different than operating your computer with your keyboard,
monitor, mouse, and USB devices directly connected to it, except that the computer can be located up to 330
feet away. All computer activities can be performed as though you were directly connected to the computer.

TROUBLESHOOTING
CrystalView EX HDMI Manual 8
Troubleshooting
The following table provides troubleshooting tips. The topics are arranged in the order in which they should
be executed, in most situations. If you are unable to resolve the problem after following these instructions,
please contact Technical Support for further assistance.
PROBLEM CAUSE SOLUTION
All LEDs on the Transmitter
are off.
The Transmitter is not
receiving power from the
power adapter

Ensure that the power adapter is properly
connected to the Transmitter.

Check that the power adapter is connected to a
live source of electrical power
All LEDs on Receiver are off. The Receiver is not receiving
power from the power
adapter.

Ensure that the power adapter is properly
connected to the Receiver.

Check that the power adapter is connected to a
live electrical source.
Link LEDs on Transmitter and
Receiver are off.
There is no connection
between the Transmitter and
Receiver.

Ensure a CAT5e/6/7 cable is connected between
the Transmitter and Receiver. Ensure CAT5e UTP
or preferably STP cabling with conductor RJ45
connectors is used.

Connect a short CAT5e/6/7 patch cord between
the Transmitter and Receiver to determine if the
original CATx cable is defective.

Ensure the CAT5e/6/7 cable is as straight as
possible (i.e. not coiled).
Link LED on Transmitter is on,
USB LED on Transmitter is
off.

The host computer is not
powered on.

The Transmitter is not
connected to the
computer.

The computer does not
support USB hubs.

The unit is
malfunctioning.

The USB cable is
defective.

Disconnect all USB devices from the Receiver.

Disconnect the Transmitter from the computer.

Disconnect the Transmitter and Receiver from
the power adapters.

Reconnect the USB device(s) to the Receiver.

Reconnect the Transmitter to the computer.

Reconnect the Transmitter to the power adapter.

Reconnect the Receiver to the power adapter.

If the USB LED continues to stay off, contact
Technical Support.
Table 5.CrystalView EX HDMI Troubleshooting Part 1

CrystalView EX HDMI Manual 9
PROBLEM CAUSE SOLUTION
All LEDs on both the Receiver
and Receiver are on, but the
USB device does not operate
correctly or is detected as an
“Unknown Device” in the
operating system.

The USB device is
malfunctioning.

The computer does not
recognize the USB device.

The application software
for the device is not
operating.

The CrystalView EX HDMI
is malfunctioning.

Disconnect the CrystalView EX HDMI from the
computer.

Connect the USB device directly to the USB port
on the computer.

If the device does not operate properly, consult
the user documentation for the USB device.

Update your system BIOS, chipset or USB Host
controller drivers from your
System/Motherboard manufacturer’s website.

Make sure the operating system has all the
latest updates installed.

If the USB device operates properly when
directly connected to the computer, connect
another device (of a different type) to
CrystalView EX HDMI. Connect the CrystalView
EX HDMI to the computer.

If the second USB device does not operate, the
CrystalView EX HDMI may be malfunctioning.
Contact Technical Support for assistance.

If the second device does operate properly, the
first device may not be compatible with the
CrystalView EX HDMI. Contact technical support
for issues.
Blinking Video on the Sink
(Monitor)

A poor quality or
damaged CAT5e/6/7
cable is being used.

The cabling is twisted.

Remove all loops in the CAT5e/6/7 cable.

Confirm extender operation with a CAT5e/6/7
patch cable.
Video frames are being
dropped

The CrystalView EX HDMI
is not compatible with the
HDCP source and/or
display device.

Contact Technical Support.
Video LED is off.

One or both of the HDMI
cables are not connected,
are of poor quality or are
malfunctioning.

The display or source is
not supported.

The CrystalView EX HDMI
is malfunctioning.

Confirm extender operation with HDMI cables
that are less than 78” (2m) in length and have
connection between each connectors’ shield.

Confirm extender operation with a CAT5e/6/7
patch cable.

Contact Technical Support.
Table 6. CrystalView EX HDMI Troubleshooting Part 2

PRODUCT SAFETY
CrystalView EX HDMI Manual 10
Safety
The CrystalView EX HDMI extender has been tested for conformance to safety regulations and requirements,
and has been certified for international use. Like all electronic equipment, the CrystalView EX HDMI should be
used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read
and follow these safety instructions.
■Follow all instructions and warnings marked on this Unit.
■Except where explained in this manual, do not attempt to service this Unit yourself.
■Do not use this Unit near water.
■Assure that the placement of this Unit is on a stable surface or rack mounted.
■Provide proper ventilation and air circulation.
■Keep power cord and connection cables clear of obstructions that might cause damage to them.
■Use only power cords, power adapter and connection cables designed for this Unit.
■Use only a grounded (three-wire) electrical outlet.
■Use only the power adapter provided with the CrystalView EX HDMI.
■Keep objects that might damage this Unit and liquids that may spill, clear from this Unit. Liquids and foreign
objects might come in contact with voltage points that could create a risk of fire or electrical shock.
■Operate this Unit only when the cover is in place.
■Do not use liquid or aerosol cleaners to clean this Unit. Always unplug this Unit from its electrical outlet
before cleaning.
Unplug this Unit from the electrical outlet and refer servicing to a qualified service center if any of the following
conditions occur:

The power cord or connection cables are damaged or frayed.

The Unit has been exposed to any liquids.

The Unit does not operate normally when all operating instructions have been followed.

The Unit has been dropped or the case has been damaged.

The Unit exhibits a distinct change in performance, indicating a need for service.

SERVICE AND MAINTENANCE
CrystalView EX HDMI Manual 11
Maintenance and Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance,
you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center.
This Return Authorization number must appear on the outside of the shipping container.
See Limited Warranty for more information.
When returning a Unit, it should be double-packed in the original container or equivalent, insured and shipped
to:
Rose Electronics
Attn: RA__________
10707 Stancliff Road
Houston, Texas 77099 USA
Technical Support
If you are experiencing problems, or need assistance in setting up, configuring or operating your product,
consult the appropriate sections of this manual. If, however, you require additional information or assistance,
please contact the Rose Electronics Technical Support Department at:
Phone: [phone]
E-mail: T[email protected]
Web: www.rose.com
Technical Support hours are from: 8:00 am to 6:00 pm CST (USA), Monday through Friday.
Please report any malfunctions in the operation of this Unit or any discrepancies in this manual to the Rose
Electronics Technical Support Department.

APPENDICES
CrystalView EX HDMI Manual 12
Appendix A- Specifications
Physical Specifications
Dimensions (W x D x H) 4.4 in x 6.9 in x 1.8 in (112 mm x 175 mm x 30 mm)
Cable Distance 330 feet (100 meters) over Cat5e/6/7 UTP or STP solid-core cable. Solid core
CAT6a/7 STP recommended for best performance
Video
Resolution High definition 1080p, 1920x1200, and 4K@30Hz, with 36 bit color depth
Latency Less than 1 ms
USB
USB device support

High-speed devices (up to 40Mbps - USB 2.0)

Full speed devices (up to 12 Mbps - USB 2.0/1.1)

Low speed devices (up to 1.5 Mbps - USB 2.0/1.1)
USB hub support Up to 4 USB hubs per single chain
USB host support xHCI (USB3.0) EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)
Max USB devices supported 30 USB devices
Power
DC power adapters Transmitter
and Receiver

Input: Grounded 100/240 V AC, 50-60 Hz

Output: Grounded 5V DC, 3A (15 W)
Power available to USB devices
at Receiver unit 500 mA each port
Connectors
Transmitter
Video 1 x HDMI In
USB 1 x USB Type B female
Link 1 x RJ45
Receiver
Video 1 x HDMI Out
USB 3 x USB Type A female
Link 1 x RJ45
Environmental Conditions
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -4°F to 158°F (-20°C to 70°C)
Relative Humidity 20% to 80% no condensation
Compliance FCC Part 15 Class A, CE Class A, ICES-003 Class A CE EN 55024, RoHS2 (CE)

CrystalView EX HDMI Manual 13
Appendix B- Part Numbers
Part Number Description
CRK-1DTXT-HD6 CrystalView EX HDMI
CAB-USBAB005 USB Cable
CAB-HDMIMM005 HDMI Cable
TRF-05D400FSUB-1.7 +5V,3A power adapter
RM-CRV-EX/19 Rack Mount Kit (holds 2 units, side-by-side)
RM-CRVEX/CP Blanking Plate for Rack Mount Kit
RM-UD/CRV-EX Under Desk Bracket

WWW.ROSE.COM
▪
[e-mail]
▪
[phone]
Rose Electronics
▪10707 Stancliff Road ▪Houston, Texas 77099
Rose USA (281) 933
-7673 ▪Rose Europe [phone]
Rose Asia +65
6324 2322 ▪Rose Australia [phone]
WWW.ROSE.COM
