Greenheck APEX-200 User manual

STEP 1: Unpack and Inspect Parts
Tools Recommended for Assembly
• Battery drill (electric or pneumatic preferred)
•5⁄16 in. Nut runner
•9⁄16 in. Nut runner
• Open or Closed 9⁄16 in. wrench
• Awl — for hole alignment
PART # 462831
February 2003
Part Description QTY P/N Length
Roof Curb Kit
12 in. high 1 852212
1. End Channel 2 708908 92.00 in.
2. Supply End Outer Channel 2 708909 42.75 in.
3. Supply End Inner Channel 2 708911 45.12 in.
4. Exhaust Side Channel 2 708912 72.87 in.
5. End Base Outer Channel 2 708914 61.25 in.
6. End Base Inner Channel 2 708913 57.00 in.
7. Center Channel 4 708910 92.00 in.
Duct Adapter
8. Adapter End Channel 3 711252 88.25 in.
9. Adapter Side Channel 4 711253 36.75 in.
Hardware Kit (for curb & duct adapter)
3⁄8-16 x 3⁄4Serrated Flange Bolts 40 415459
3⁄8-16 x 3⁄4Serrated Flange Nuts 40 415457
Screws, SMS (A) 12 x 0.625 (IHH) 35 415180
®
Roof Curb and Duct Adapter
Model: APEX-200
ASSEMBLY INSTRUCTIONS

2
STEP 2: Assemble Duct Adapters
Hardware Required: (16) Screws, SMS (A) 12 x 0.625 (IHH)
(4) Adapter Side Channel
(3) Adapter End Channel
(1) Center Channel
Instructions: • See Figures 1 & 2 for positioning the Adapter Side and End Channels.
• Align the holes and fasten as shown.
Figure 1:Exhaust Duct Adapter Assembly Figure 2: Supply Duct Adapter Assembly
STEP 3: Assemble Supply End Section
Hardware Required: (12) 3⁄8-16 x 3⁄4Serrated Flange Bolts
(12) 3⁄8-16 x 3⁄4Serrated Flange Nuts
(4) Screw, SMS (A) 12 x 0.625 (IHH)
(1) End Channel
(2) Supply End Outer Channel
(2) Supply End Inner Channel
(1) Supply Duct Adapter Assembly (See Step 2)
Instructions: • Position Channels as shown in Figure 3.
• Align the holes and fasten as illustrated below.
9
8
9
8
7
8
9
9
3
2
3
2
1
Figure 5
End and side
channels fasten
together as shown.
Figure 4
Side and center
channels fasten
together as shown.
Figure 3: Supply End Section
Supply Duct Adapter

3
Figure 6 : Exhaust Center Section
Exhaust Duct Adapter
4
4
STEP 4: Assemble Exhaust Center Section
Hardware Required: (1) Exhaust Duct Adapter
(2) Exhaust Side Channels
(8) Screws, SMS (A) 12 x 0.625 (IHH)
Instructions: • See Figure 6 for positioning the Exhaust Duct Adapter and Exhaust Side
Channels.
• Align the holes and fasten as shown.
5
6
7
6
5
1
Figure 7:Exhaust Center and End Base Sections
STEP 5: Assemble End Base Section
Hardware Required: (18) 3⁄8-16 x 3⁄4Serrated Flange Bolts
(18) 3⁄8-16 x 3⁄4Serrated Flange Nuts
(1) End Channel
(2) End Base Outer Channel
(2) End Base Inner Channel
(2) Center Channel
(1) Exhaust Center Section (See Step 4)
Instructions: • Position Channels as shown in Figure 7.
• Align the holes and fasten as illustrated below.

IOM APEX Curb FS
Rev. 1, February 2003
STEP 6: Final Assembly
Hardware Required: (6) 3⁄8-16 x 3⁄4Serrated Flange Bolts
(6) 3⁄8-16 x 3⁄4Serrated Flange Nuts
(1) Center Channel
(1) Exhaust Center and End Base Assembly (See Step 5)
(1) Supply End Section (See Step 3)
Instructions: • Position Channels as shown in Figure 8.
• Align the holes and fasten as illustrated below.
Figure 8: Final Assembly
Curb Dimensions
7
283.50
92.00
