Greenheck SP-B Installation and operating instructions

®
READ AND SAVE THESE INSTRUCTIONS
Model SP-B
Model CSP-B
Ceiling Exhaust and Inline Fans
PN 455480
Installation, Operation and Maintenance Manual
Prepare the Fan
1. If power assembly (motor and wheel) is not installed in housing, insert the electrical plug
into fan socket, then slide wheel end of power assembly into fan housing. Attach by using
two sheet metal screws provided, as shown in figure 1.
2. If fan is to be used in a fire resistive membrane ceiling, a ceiling radiation damper must be
used. If the ceiling radiation damper is already mounted to the fan from the factory,
proceed to next step. To mount the ceiling radiation damper to fan, make sure grille
attachment tabs are facing down. Then place the inlet part of the fan into the ceiling
radiation damper collar, and use self-tapping sheet metal screws #10x1/2in. (by others) to
screw through the damper collar and into the fan housing, as shown in figure 2. If the
fan/light combination is being used, make sure ceiling radiation damper has an electrical
plug in it. The electrical plug must be inserted into the fan. Make sure the electrical wire
will not interfere with
damper operation, as
shown in figure 3.
Wires from lighted grille
Wires to ceilin
g
fa
n
Do not allow
interference in
this area
Fig. 1
Fig. 2
Fig. 3
Qty 8 sheet metal
screw #10x 1/2in.
(by others)
Install the Fan
1. For best performance, choose a
location with the shortest possible
duct run and minimum number of
elbows. Do not mount near cooking
equipment, as shown in figure 4.
2. Attach adjustable mounting brackets to fan,
but leave the screws
loose until proper
height is
determined, as
shown in figure 5.
For fan and fan/light
combinations cut a
14 1/8 by 11 3/4 inch
hole in the ceiling.
For fan/CRD
combinations cut a
14 3/8 by 12 1/4 inch
hole in the ceiling.
a. For frame construction, position unit between
joists. Position brackets such that bottom
edge of housing will be flush with finished
ceiling, and tighten the adjustable mounting
brackets, as shown in figure 6.
b. For hanging installations, use Greenheck’s
optional vibration isolator kit Part Number VI
Kit. Using the fan’s standard adjustable
mounting brackets and 10 by 32 threaded rod
- by others, hang unit as shown in figure 7.
Fig. 4
WARNING !
To reduce the risk of fire, electric shock, or injury to
persons, observe the following:
• If a speed controller is used, this fan should only be
used with fan speed control, manufactured by KB
Electronics, Inc.
• Before servicing or cleaning unit, switch power off at
service panel and lock service disconnecting means
to prevent power from being switched on
accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent
warning device, such as a tag, to the service panel.
• Installation work and electrical wiring must be done
by qualified person(s) in accordance with all
applicable codes and standards, including fire-rated
construction.
• The combustion airflow needed for safe operation of
fuel burning equipment may be affected by this
unit's operation. Follow the heating equipment
manufacturer’s guideline and safety standards such
as those published by the National Fire Protection
Association (NFPA), and the American Society for
Heating, Refrigeration and Air Conditioning
Engineers (ASHRAE), and the local code authorities.
• When cutting or drilling into wall or ceiling, do not
damage electrical wiring or other hidden utilities.
• This unit is suitable for use directly over a tub or
shower with a GFI branch circuit wiring.
• Ducted fans must always be vented to the outdoors.
• For general ventilating use only. Do not use to
exhaust hazardous or explosive materials and
vapors
• These fans are not recommended for cooking
exhaust applications. They are designed primarily
for low temperature, clean air applications only.
Figure 4 shows the minimum distance these fans
should be placed in relation to cooking equipment.
• Fan/Light
combination not to be installed in a ceiling
thermally insulated to a value greater than R40.
Do not install
fan in this area
45º45º
Brackets can be
arranged to adapt
to most mounting
conditions
1. Adjust to be flush
with finished ceiling
Fan Ceiling
2. Tighten
Fig. 7
Fig. 5
Fig. 6

Warranty
Greenheck warrants this equipment to be free from
defects in material and workmanship for a period of
three years from the purchase date. Any units or
parts which prove to be defective during the
warranty period will be replaced at our option when
returned to our factory, transportation prepaid.
Greenheck will not be responsible for any
installation or removal costs.
General Maintenance Suggestions
Model SP/CSP ceiling exhaust fans require very
little maintenance. But since small problems over
time left unchecked could lead to loss of
performance or early motor failure, we do
recommend that the unit be inspected periodically
(once or twice a year).
The fan motor and wheel should be checked for
dust and dirt accumulations. Dirt buildup can lead
to loss of performance and motor overheating.
Cleaning can be accomplished by brushing off any
dust that may have accumulated. Even filtered
units can accumulate build up and should be
checked when cleaning filters.
The motor should be checked for lubrication at this
time. Lubricate only those motors which have an oil
hole provided. A few drops of all purpose oil (SAE
20) will be sufficient.
GREENHEC
K
P.O. BOX 410 SCHOFIELD, WISCONSIN 54476-0410
PH. 715-359-6171
www.greenheck.com
®
SP/CSP models shown are
UL and cUL listed E 33599
SP-B & CSP-B IOM FS
Rev 7 September 2003
Copyright © 2003 Greenheck Fan Corp.
Installation Recommendations
Install the Fan - continued
Wire the Fan
Attach the Grille
3. Slide ductwork over the fan’s discharge collar and securely attach it with sheet metal screws. Make sure the screws do not
interfere with damper operation. Check damper to make sure it opens freely.
1. Remove wiring cover and wire nuts. If
fan/light combination is being used,
make sure the fan plug is connected
to the fan receptacle and the light
plug is connected to the light
receptacle as shown in figure 8. Then
wire unit to the correct installation
type, as shown in figure 9a, 9b, and
9c.
2. Push all wiring into the unit’s cover
and replace wiring cover.
H o t ( B l ac k )
T o s w i t c h
o r p o w e r
T o p o w e r
s u pp l y
T o g r o un d
G r o un d ( G r ee n )
M o t o r
C o mm o n ( W h i t e )
115 / 277 v o l t
Light
Fan
Fan Outlet (top)
Light Outlet (bottom)
H o t ( B l ac k )
T o s w i t c h
T o p o w e r
s u pp l y
T o g r o un d
G r o un d ( G r ee n )
C o mm o n ( W h i t e )
115 v o l t li g h t
L i g h t
H o t ( B l ac k )
T o p o w e r
s u pp l y
H o t ( B l ac k )
M o t o r
C o mm o n ( W h i t e )
220 / 230 / 240 v o l t
1. If lighted grille is being used, plug wire into fan
socket.
If lighted grille and ceiling radiation damper are
being used, plug wire from lighted grille into
ceiling radiation damper socket. Do not plug
wire directly into the fan socket. Make sure the
wire does not interfere with the ceiling radiation
damper operation.
2. Attach grille with two screws provided. Make
sure not to over tighten, over tightening will
damage grille.
3. Slide attachment screw covers over the
attachment screws, as shown in figure 9.
4. If lighted grille is being used, install light bulb(s)
into light socket(s). For incandescent lights, use
maximum 100 watt bulb – not included. For
fluorescent lights, use only Greenheck’s Part
Number 382854, provided, 13 watt flicker
resistant light bulbs.
5. If lighted grille is being used, snap lens into
place, by pushing on the outside edges of lens,
as shown in figure 10. To remove lens, use
small screw driver and pry
on one side of
lens.
6. Turn on
power and
check fan and
light operation.
Fig. 9
Fig. 8
Fig. 9a
Fig. 9c
Fig. 9b
Squeeze tabs to
insert/remove lens
Fig. 10
