Greenway Home Products GWF7 User manual

Use & Care Guide
Guide d’utilisation et d’entretien
Guía de uso y mantenimiento
GWF7 REV03
Filtration System
For Water Dispensers
Système
de Filtration
Pour les Distributeurs D'eau
Sistema
de Filtración
Para Dispensadores de Agua
CAUTION: Before using the
water filtration system, read this
manual and follow all safety
rules and operating instructions.
MISE EN GARDE : Avant
d'employer le système de filtration
d'eau, lisez ce manuel et suivez
toutes les règles de sécurité et les
consignes d'utilisation.
PRECAUCIÓN: Antes de usar el
sistema de filtración, lea este
manual y siga todas las reglas
de seguridad e instrucciones de
funcionamiento.

YOUR GREENWAY®WATER FILTRATION SYSTEM
1
TOP COVER
PRE-FILTER
UPPER
CHAMBER
FILTER BODY
WHITE
CHAMBER RING
LOWER
CHAMBER
FLOAT
Thank you for purchasing the Greenway®Water Filtration System for
water dispensers.
We have carefully engineered your filtration system to produce
great-tasting, healthier water directly into your water dispenser without
the hassles of lifting heavy bottles of water or returning the empties ...
all at a fraction of the cost of bottled water.
Please read the enclosed operating instructions carefully and retain this
booklet for future reference.

2
OPERATING INSTRUCTIONS
Getting your Water Dispenser Ready for the Greenway®Water
Filtration System
IMPORTANT: The Greenway®Water Filtration System is designed to fit
all Greenway®water dispensers and most other brand names.
Depending on your water dispenser, you may have to remove
the bottle support collar and/or piercing valve from your dispenser in
order for the filtration system to fit. (See FIGURE A, page 5.)
CAUTION! Once the filtration system is placed on the water dispenser
it should fit level and secure. The float mechanism that fits inside the
water dispenser must NEVER be obstructed and be allowed to operate
freely!
GETTING STARTED
Wash all parts in warm soapy water before initial use. Rinse and dry
thoroughly. THE PARTS ARE NOT DISHWASHER SAFE!
IMPORTANT
• DO NOT WASH the multi-stage filter or pre-filtration parts.
• Soak the multi-stage filter in cold tap water for 30 minutes
before using.
• FLUSH the filter under the tap for 30 seconds and shake gently.
ELECTRONIC FILTER CHANGE REMINDER
To turn on the electronic filter change reminder, press the “reset”
button until 180D flashes on the display. The counter will begin to
count down the days from 180 and will be decreased by 1 day every
24 hours until the display reads 0000D. It will then be time to replace
your filter. The same procedure applies for resetting the filter change
reminder after a filter has been changed.
Greenway®Long Life Multi-Stage
Replacement Filter:
GWF3
Available online at
www.greenwayhp.com

3
OPERATING INSTRUCTIONS
FIGURE A
FIGURE B
Lower Chamber Assembly (FIGURE A)
Attach the float into the threaded float base
at the bottom of the lower chamber. Place
the assembled lower chamber on the water
dispenser. Place white chamber ring on top
of the lower chamber.
Upper Chamber Assembly (FIGURE B)
1. With clean hands, completely submerge
filter under cold water by holding it down
until the filter no longer releases air
bubbles. Let soak for 30 minutes.
2. Align the two ports at the bottom of the
pre-filter with the holes in the upper
chamber of the filtration system and snap
it into place. (Take care to align locking
tabs with the centre hole.)
3. Align the post at the center of the top
screen of the filter body with the center
port on the pre-filter and twist the filter
body on the base of the upper chamber of
the filtration system.
4. You can now place your filtration system
on top of your water dispenser and enjoy
cleaner, great-tasting water!
Securely tighten the filter to the housing to make a tight seal for
improved filtration and to reduce the possibility of a leak.

Filling the Filtration System
1. Remove the top cover.
2. Pour cold tap water into the upper chamber. (For best results
always use "COLD" tap water) CAUTION – NEVER USE HOT
WATER! NEVER REMOVE THE WATER FILTRATION SYSTEM TO
FILL AT THE SINK, ALWAYS USE A PITCHER TO FILL!
3. Use the guide on the side of the chamber so you don’t overfill. TO
AVOID LEAKING, DO NOT EXCEED THE 7 L (1.8 gal) MAX.
4. Replace the top cover.
5. For best results, add water regularly to ensure the multi-stage filter
is immersed in the lower chamber at all times between the "MIN”
and “MAX" levels indicated on the lower chamber.
CAUTION! Never use water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the
filtration system.
Helpful Tips
1. Keep your water filtration system in a dry place and out of
direct sunlight.
2. Do not add water when the lower chamber is full to avoid water
overflowing. Use the guide on the side of the lower chamber and
add water to the upper chamber only when needed. DO NOT
EXCEED THE "MAX" LEVEL ON THE LOWER CHAMBER GUIDE!
3. For best filtration results, the multi-stage filter should remain
immersed between the “MIN” and “MAX” levels indicated on the
lower chamber.
4. Never use hot water for filtering or soaking.
5. Your Greenway®Long Life Multi-Stage Filter will last up to 6 months
and filter over 800 litres (211 gallons) of water.
6. The top cover has a filter replacement reminder that will indicate
when it is time to change your filter, (see Electronic Filter Change
Reminder on page 2).
7. When replacing the multi-stage filter, you should rinse out the
entire water filtration system.
8. Use only Greenway®approved Long Life Multi-Stage Filters (GWF3).
Follow the replacement instructions on the filter carton.
9. Always fill the upper chamber of the water filtration system using a
pitcher of water while it is on top of your water dispenser. Never
remove the water filtration system or upper chamber to fill.
4
MAINTENANCE, CLEANING, STORAGE

5
“QUICK” TIPS
FIGURE A
FIGURE B
Cleaning the Water Filtration System
The outside of the water filtration system can be wiped with a damp
cloth at any time.
When the multi-stage filter is being replaced you should rinse out the
top and bottom sections of the upper and low chamber.
After replacing the multi-stage filter, ensure to thoroughly rinse out the
top and bottom chambers.
IMPORTANT: ALL PARTS ARE NOT DISHWASHER SAFE!
1. Soak the multi-stage filter in cold tap
water for 30 minutes before using.
2. Remove the bottle support on your water
dispenser by turning counter-clockwise
and lifting it up. The water filtration system
will not operate with a piercing valve and
the float mechanism must be
unobstructed. (FIGURE A)
3. Please ensure the float valve is securely in
place by screwing it into the bottom of the
lower chamber. DO NOT OVER TIGHTEN.
(FIGURE B)

FREQUENTLY ASKED QUESTIONS
6
FIGURE C
7 L
6 L
5 L
4 L
3 L
2 L
1 L
MAX
MIN
4. ALWAYS fill the upper chamber with cold
tap water using a pitcher (not supplied).
Never remove the upper chamber of the
water filtration system from the water
dispenser when filling.
DO NOT OVERFILL.
(FIGURE C)
5. Use the measuring guides on the side of
the water filtration system and add water
to the upper chamber when needed.
Keep the water level in the lower
chamber between the “MIN” and “MAX”
levels so the multi-stage filter is immersed
at all times.
Q How long will it take for the water to filter through?
AIt takes approximately 20 to 30 minutes to process the initial batch
of 5 litres of water. It will get quicker as you add water while
keeping the multi-stage filter moist in the lower chamber between
the “MIN” and “MAX” levels. Dispensing water from the dispenser,
while pouring in water to be filtered will increase the
processing time.
Q. There appears to be some carbon dust in my water when
getting started, What should I do with this?
AWhen a new filter is installed, it is common to have carbon particles
in the first batch of filtered water. Every time you replace your filter,
discard the first 4 glasses from each dispensing tap or button.
This does not need to be repeated every time you refill the
filtration system.
Q. The water filtration system does not fit my water dispenser?
AThe Greenway®Water Filtration System is designed to fit all
Greenway®water dispensers and most other major brands. Most
dispensers have a bottle support that has to be removed. If you
are having difficulty removing the bottle support, it is possible there
is no bottle support to be removed. Please contact the
manufacturer of your water dispenser or refer to your water
dispenser owner’s manual.

When not using the water filtration system for more than a week or
when going on vacation, please ensure the lower chamber is full and
the filter immersed in water, as the multi-stage filter will dry out. Always
drain out any residual water when ready to start using it again. If the
water filtration system has not been used for an extended period of
time, please replace the multi-stage filter and rinse out top and
bottom chambers.
GOING AWAY ON VACATION
TROUBLESHOOTING
Water is
leaking out
1. The water filtration
system is not sitting
straight or the float
mechanism is obstructed.
2. The float seal is not
inserted correctly or is
not sealing due to residue
or charcoal particles.
Make sure the water
filtration system is sitting
flat on the water
dispenser (make sure the
bottle support collar or
the spike has been
removed).
Ensure the float seal
is inserted correctly
and any residue is
wiped away.
Water will
not filter
1. The lower chamber is
full of water which is
causing it to overflow.
2. Pre-filtration system
is blocked.
3. Multi-stage filter
is blocked.
Drain out some of
the water.
Do not add water to
the upper chamber if
the lower chamber is full.
Replace pre-filtration
system.
Replace with new
Greenway®Long Life
Multi-Stage Filter.
Problem Possible Cause Suggested Solution
7
