GreenWorks Pro IV80A00 User manual

Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-855-345-3934
www.GreenworksTools.com
DC 80V Lithium-Ion Battery Power Inverter
FOR MODELS: IV80A00
INPUT: DC 80V, 6A
OUTPUT: AC 120V/60HZ, 300W

2
Contents .............................................................................................................................. 2
Product Specications ......................................................................................................... 2
Important Safety Instructions............................................................................................... 3
Protective Features of the Inverter........................................................................................ 5
Working Principles....................................................................................................................6
Operation............................................................................................................................. 7
Environmentally Safe Battery Disposal................................................................................... 8
Troubleshooting ................................................................................................................... 9
Warranty ............................................................................................................................ 10
PRODUCT SPECIFICATIONS
DC 80V POWER INVERTER
Output Voltage............................................................................ 120 Volt AC RMS 80Hz
Output USB .................................................................................................. 5VDC, 2.4A
Max. Efciency ...................................................................................................... .>90%
Rated Input Current.........................................................................................................6A
Input Voltage Range. ..............................................................................45 to 64 volt DC
Low Voltage Shutdown ....................................................................................42 volt DC
Operation Temperature........................................................-10℃to 40℃at 100% loading
CONTENTS

3
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION,
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ AND UNDERSTAND
ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR
GREENWORKS’S BATTERY MANUFACTURER GUIDELINES. FAILURE TO DO SO COULD
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
To ensure reliable service, your power inverter must be installed and used properly. Please read
the installation and operating instructions thoroughly prior to installation and use. Pay particular
attention to the WARNING and CAUTION statements in this manual. The CAUTION statements
advise against certain conditions and practices that may result in damage to your inverter. The
WARNING statements identify conditions or practices that may result in personal injury. Read All
Instructions Before Using This Power Inverter!
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, EXPLOSION OR INJURY:
• Do not connect to AC distribution wiring.
• Remove appliance plug from outlet strip or turn off inverter before working on the appliance.
Multiple outlet power strips with switches and circuit breakers only interrupt power to the “hot”
receptacle terminals. The “neutral” terminals remain powered with respect to the “ground”
terminals.
• This is not a toy - keep away from children.
• DO NOT install object into air vents.
WARNING:
Reverse polarity connection will cause the unit to malfunction and may permanently damage the
inverter.
CAUTIONS:
• Grounding the neutral will damage the inverter. Do not operate this inverter if it is wet. Do not
install in engine compartment – please install in a well ventilated area.
• This inverter is not tested for use with medical devices.
WARNING:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause
undesired operation.
CAUTIONS:
Changes or modications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.

4
IMPORTANT SAFETY INSTRUCTIONS
POWER SOURCE REQUIREMENTS
The power source must be able to supply the necessary current to operate the load. The
Greenworks™ 80-volt battery is the only DC source, this inverter cannot connect to other DC
sources.
WARNING:
Keep ventilation when using batteries.
Cannot mount the power inverter on other position, can just install on the Greenworks™ battery pack.
CONNECTION TO LOAD
The inverter is equipped with a AC power receptacle. Plug the cord from the equipment you
wish to operate into an AC receptacle. The green LED indicator light turns on to indicate that the
inverter is functioning. Make sure the combined load requirement of your equipment does not
exceed inverter’s output rating (300W).
The inverter is engineered to be connected directly to standard electrical and electronic
equipment in the manner described above.
Do not connect the power inverter to household or RV AC distribution wiring.
Do not connect the power inverter to any AC load circuit in which the neutral conductor is
connected to ground (earth) or to the negative of the DC (battery) source.
OPERATING ENVIRONMENT
For best operating results, the inverter should be placed on at surface, such as the ground, car
oor, or other solid surface. The inverter should only be used on a at surface, such as a dry
ground, car oor, table, patio, or other solid, dry and at surface.
DRY- Do not allow water and/or other liquids to come into contact with the power inverter.
COOL – Do not place the inverter on or near a heating vent or any piece of equipment which is
generating heat above room temperature. Keep the inverter away from direct sunlight, if at all
possible.
SAFE – Do not use the inverter near ammable materials or in any locations that may
accumulate ammable fumes of gases.

5
PROTECTIVE FEATURES OF THE INVERTER
Your inverter monitors the following potentially hazardous conditions:
OVER TEMPERATURE PROTECTION – If the temperature inside the inverter is too high, the
unit will automatically shut down. Allow the unit to cool for at least 15 minutes before restarting
after a heat-related shutdown. Unplug unit while cooling.
LOW BATTERY VOLTAGE PROTECTION - This condition is not harmful to the inverter but
could damage the power source. The inverter automatically shuts down when input voltage drops
to 42 volts. When the condition is corrected, the unit may be restarted.
OVER VOLTAGE PROTECTION – The inverter will automatically shut down when the input
voltage exceeds 64 volts DC.
OVERLOAD PROTECTION – The inverter will automatically shut down when the continuous
draw exceeds rated watts.
SHORT CIRCUIT PROTECTION – The inverter will shut down. Remove the short circuit and
restart the inverter after 5minutes.

6
WORKING PRINCIPLES
HOW YOUR INVERTER WORKS
The inverter converts low voltage DC (Direct Current) from a Greenworks™ 80V lithium battery
to standard 120 volt AC (Alternating Current) household power.
PRINCIPLE OF OPERATION
The inverter converts power in two stages:
• The rst stage is a DC to DC conversion process that raises the low voltage DC at the inverter
input to high volts DC.
• The second stage is the actual inverter stage that converts the high voltage DC into AC.
The DC-to-DC converter stage uses modern high frequency power conversion techniques
that have replaced the bulky transformers found in less technologically-advanced models. The
inverter stage uses advanced power MOSFET transistors in a full bridge conguration.
THE OUTPUT WAVEFORM
The AC output waveform of the IV80A00-series inverter is known as “modied sine wave”. It is
a waveform that has characteristics similar to the sine wave shape of utility power. This type of
waveform is suitable for most AC loads, including linear and switching power supplies used in
electronic equipment, transformers, and motors. (See Figure 1).
The modied sine wave produced by the IV80A00-series inverter has an RMS (root mean
square) voltage of 120 volts, which is the same as standard household power. Most AC
voltmeters (both digital and analog) are sensitive to the average value of the waveform rather
than the RMS value. They are calibrated for RMS voltage under the assumption that the
waveform measured will be a pure sine wave. These meters will not read the RMS voltage of a
modied sine wave correctly. They will read about 20 to 30 volts low when measuring the output
of the inverter. For accurate measurement of the output voltage of this unit, use a true RMS
reading voltmeter.
Fig. 1

7
OPERATION INSTRUCTIONS
NOTE: This product requires no assembly.
1. Insert the battery pack (A) into the power inverter.
2. Press the switch (B) to ON position.
3. Connect the USB (C) or plug (D) to the receptacle.
Note: To remove the battery pack, press the battery release button (E) on the power inverter.
WARNING:
Shut off the power source, or disconnect the battery when the power interter is not in use.
The LED lights indicate the working condition of the power inverter as follows:
Work condition Green Red
Normal
High-voltage protection
Overload protection red light is on after you start the machine
Battery error red light is on once you start the machine
Low battery voltage
Short-circuit protection red light will ash in intervals of 4
Low-voltage protection red light will ash in intervals of 5
Temperature protection red light will ash in intervals of 6
B
C
A
D
E

8
ENVIRONMENTALLY SAFE BATTERY DISPOSAL
The following toxic and corrosive materials are in the batteries used in this tool battery pack:
Li-ion, a toxic material.
WARNING:
All toxic materials must be disposed of in a specied manner to prevent contamination of the
environment. Before disposing of damaged or worn out Lithium-ion battery packs, contact
your local waste disposal agency, or the local Environmental Protection Agency for information
and specic instructions. Take the batteries to a local recycling and/or disposal centre, certied
for Li-ion disposal.
WARNING:
If the battery pack cracks or breaks, with or without leaks, Do not attempt to charge or use the
battery. Dispose of the battery and replace with a new battery pack. DO NOT ATTEMPT TO
REPAIR THE BATTERY.
To avoid injury and risk of re, explosion, or electric shock, and to avoid damage to the
environment:
• Cover the battery's terminals with heavy-duty adhesive tape.
• DO NOT attempt to remove or destroy any of the battery pack components.
• DO NOT attempt to open the battery pack.
• If a leak develops, the released electrolytes are corrosive and toxic. DO NOT get the solution in
the eyes or on skin, and do not swallow it.
• DO NOT place these batteries in your regular household trash.
• DO NOT incinerate.
• DO NOT place them where they will become part of any waste landll or municipal solid waste
stream.
• Take them to a certied recycling or disposal centre.
• Have servicing performed by a qualied repair person using only identical replacement parts. This
will ensure that the safety of the product is maintained.

9
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Inverter will not turn on
The power needed to
start AC appliances
may be as much as 2
to 8 times its continu-
ous wattage require-
ments.
Read the information panel on each AC ap-
pliance carefully to accurately determine the
tool’s input wattage.
“BUZZING” sound in
audio systems.
The power supply in
the electronic device
does not adequately
lter the modied sine
wave produced by the
inverter.
Use a higher quality sound system that
incorporates a higher quality power amplied
supply.
Television interference.
The inverter is shielded
to minimize interfer-
ence with TV signals.
The problem may not
be with the inverter.
However, in some
instances, some inter-
ference may still be
visible, particularly with
weak TV signals.
Position the inverter as far as possible from
the television, the antenna and the antenna
cables. Use an extension cable, if necessary.
Adjust the orientation of the inverter, the
antenna cables and the TV power cord to
minimize interference.
Make sure that the antenna feeding the
television provides an adequate (“snow free”)
signal and that high quality, shielded antenna
cable is used.
Do not operate appliances and TV at the
same time in order to maintain maximum
efciency

10
WARRANTY
Greenworks™ hereby warranties this product, to the original purchaser with proof of purchase,
for a period of four (4) years against defects in materials, parts or workmanship. Greenworks™,
at its own discretion will repair or replace any and all parts found to be defective, through normal
use, free of charge to the customer. This warranty is valid only for units which have been used
for personal use that have not been hired or rented for industrial/commercial use, and that have
been maintained in accordance with the instructions in the owners’ manual supplied with the
product from new.
ITEMS NOT COVERED BY WARRANTY:
1. Any part that has become inoperative due to misuse, commercial use, abuse, neglect,
accident, improper maintenance, or alteration; or
2. The unit, if it has not been operated and/or maintained in accordance with the owner's
manual; or
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants, blade sharpening;
5. Normal deterioration of the exterior finish due to use or exposure.
HELPLINE:
Warranty service is available by calling our toll-free helpline, at 1-855-345-3934.
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power equipment unit or attachment are the
responsibility of the purchaser. It is the purchaser’s responsibility to pay transportation charges
for any part submitted for replacement under this warranty unless such return is requested in
writing by Greenworks™.
USA address:
Greenworks™ Tools
P.O. Box 1238
Mooresville, NC 28115
Canadian address:
Greenworks™ Tools Canada Inc.
P.O. Box 93095, Newmarket, Ontario
L3Y 8K3
