v. 0.4
1
2 3
ush box
fastening
ring
are available on the website: www.grenton.pl
The general Warranty Terms & Conditions are available on the
manufacturer’s website at: www.grenton.pl/gwarancja
ADDITIONAL INFORMATION
Full instruction, technical specication and declaration of conformity
The touch panel replaces
traditional light switches.
PROPERTIES
WIRING DIAGRAM
•each button can execute up to four independent functions
•features a built-in temperature sensor
•each button can signal correctness of activation or errors: ShowOK and ShowError functions
•
Connect the module according to the above diagram.
After connecting the module with other modules in the system, add the module
In order to do this, follow these steps:
1. Connect the CLU module using the ETHERNET port to the computer on which
2. Open existing project or create a new one in GRENTON OBJECT MANAGER program.
3. Run the CLU DISCOVERY procedure.
4. Add found modules to the project.
MODULE INSTALLATION
TECHNICAL SPECIFICATIONS
DC supply 5 - 24 V
max. current input 7 mA (at 24 V)
weight
dimensions (H/W/D)
operating temperature range O to +40°C
clik!
TF -Bus
200 g
160/80/18 mm
GRENTON TOUCH PANEL 4B
TPA-208-T-0X
TOUCH PANEL
