Grillo G131 User manual

02007 - 17
GRILLO G131
OPERATOR'S MANUAL
MANUALE DELL'OPERATORE
MANUEL D'UTILISATION
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
MANUAL DE INSTRUÇÕES
ΕΓΧΕΙΡΊ ΙΟ Ο ΗΓΙΏΝ

SUMMARY
Safety rules
Instructions :
Warnings 5
Identification and servicing 7
Technical specifications 8
Putting the machine into service 8
Instructions for use 9
Maintenance and lu rication 12
Implements 14
Illustrations 95
EC Declaration of conformity - Noise and vi rations levels
INDICE
Norme antinfortunistiche
Istruzioni :
Avvertenze 17
Identificazione e assistenza 19
Caratteristiche tecniche 20
Messa in opera della macchina 20
Istruzioni d’uso 21
Manutenzione e lu rificazione 24
Accessori 26
Figure 95
Certificato di conformità CE - Rumorosità e livelli di vi razione
INDEX
Règles de sécurité
Instructions :
Mises en garde 30
Identification et assistance 32
Caractéristiques techniques 33
Mise en service de la machine 33
Mode d’emploi 34
Maintenance et lu rification 38
Outils 40
Illustrations 95
Certificat de conformité CE - Niveaux sonores et de vi ration
INHALTSÜBERSICHT
Sicherheitsvorschriften
Anleitung:
Sicherheitsrelevante Hinweise 44
Identifikation der Maschine und Kundendienst 46
Technische Daten 47
In etrie nahme der Maschine 47
Betrie sanleitung 48
Wartung und Schmierung 52
Zu ehöre 53
A ildungsverzeichnis 95
EG-Konformitätserklärung - Geräuschemission und Vi rationspegel
ÍNDICE
Normas de seguridad
Instrucciones:
Advertencias 58
Identificación y asistencia 60
Características técnicas 61
Puesta en servicio de la máquina 61
Modo de empleo 62
Mantenimiento y lu ricación 66
Equipos 67
Indice de ilustraciones 95
Certificado de conformidad CE - Niveles de ruido y vi ración
INDICE
Normas de segurança
Instruções:
Recomendações de precaução de acidentes 71
Identificação e assistência 73
Características técnicas 74
Activação da máquina 74
Instruções de uso 75
Manutenção e Lu rificação 76
Alfaias 77
Índice de ilustrações 95
Certificado de conformidade CE - Nível de Ruído – Vi ração
κανονισμοί πρόληψης ατυχημάτων
οδηγίες:
προειδοποιήσεις 81
Αναγνώριση και Υποστήριξη 83
προδιαγραφές 84
Εφαρμογή του μηχανήματος 84
οδηγίες χειρισμού 85
Συντήρηση και λίπανση 89
εξαρτήματα 90
Τα σχήματα 95
Πιστοποιητικό Συμμόρφωσης - Χαμηλά επίπεδα θορύβου και κραδασμών επίπεδα
- i -

SAFETY SYMBOLS - SIMBOLOGIA PER LA SICUREZZA - SYMBOLOGIE POUR LA SECURITE –
SICHERHEITSSYMBOLE- SIMBOLOGÍA DE SEGURIDAD
OPEN MANUAL- means that ou must read the operator's manual ver carefull .
MANUALE APERTO - significa che dovete leggere attentamente il manuale di uso e manutenzione.
MANUEL OUVERT – signifie qu'il faut lire avec attention le présent manuel.
OFFENES HANDBUCH – bedeutet, dass Sie die Gebrauchs- und Wartungsanleitung aufmerksam durchlesen müssen.
MANUAL ABIERTO – es decir que ha que leer mu atentamente el manual del operador.
CAUTION! - means that ou have to pa particular attention to the operation ou have to carr out, in particular if there is the
indication “DANGER”.
ATTENZIONE! - significa che dovete porre particolare attenzione all’operazione che dovete effettuare, in particolare se vi è anche
l’indicazione di “Pericolo”.
ATTENTION! - signifie qu'il faut faire particulière attention dans l'opération que vous allez faire, en particulier s'il a aussi
l'indication “DANGER”.
VORSICHT! - bedeutet, dass Sie besondere Aufmerksamkeit beim Durchführen des Vorgangs haben müssen, insbesondere wenn
auch der Hinweis “GEFAHR” aufgeführt ist.
ATENCIÓN! - es decir que ha que poner ma or atención en la operación a ejecutar si, en particular cuando ha también la
indicación “Peligro”.
INTERDICTION, YOU MUST NOT DO THAT! - means that it is absolutel forbidden to carr out the operations reported under this
s mbol because the could lead to mortal danger.
DIVIETO, NON FARE! - significa che non dovete assolutamente fare le operazioni riportate sotto questo simbolo, potrebbe
comportare un pericolo mortale.
INTERDICTION, NE PAS FAIRE! - signifie qu'il est absolument interdit d' effectuer les opérations reportées sous cette indication,
car elles pourraient conduire au danger de mort.
VERBOT, strengstens untersagt! - bedeutet, dass der Vorgang unter diesem S mbol absolut nicht durchgeführt werden darf, da er
zur einer lebensgefährlichen Situation führen könnte.
PROHIBICIÓN, NO LO HAGAN! - es decir que no ha que hacer absolutamente las operaciones bajo este símbolo, podría
comportar un peligro mortal.
NOTE, ou have to pa particular attention to the note put next to this s mbol
NOTA, dovete porre particolare attenzione alla nota posta accanto a questo simbolo.
NOTE, il faut faire attention particulière à la note mise à côté de ce s mbole.
ANMERKUNG, besondere Aufmerksamkeit muss auf die Anmerkungen neben diesem S mbol gelenkt werden.
NOTA, ha que poner atención particular en la nota puesta a lado de este símbolo.
You must not repair nor lubricate the machine with moving parts or with the engine put on.
Non riparare o lubrificare la macchina con organi in movimento o motore acceso
Ne pas réparer ou lubrifier la machine avec des parties en mouvement ou à moteur en marche.
Niemals bei bewegenden Objekten oder bei laufendem Motor Reparationen oder Einschmierungen durchführen.
No reparar ni lubrificar la máquina con órganos en movimiento o motor en marcha.
You must not smoke, light matches or lift flames, trigger frames nor cause sparks.
Vietato fumare, accendere fiammiferi o fiamme, lasciare fiamme libere o creare scintille.
Il est interdit de fumer, allumer des allumettes ou du feu, laisser des flammes libres ou de causer des étincelles.
Es ist untersagt zu Rauchen, Streichhölzer oder Feuer anzuzünden, Flammen auslösen oder Funken verursachen.
Prohibido fumar, encender cerillas o fuego, dejar llamas o crear chispas.
Use personal protective equipement
Utilizzare mezzi di protezione individuali
Utilisez l'équipement de protection individuelle
Individuelle Schutzausrüstung benutzen
Utilizar dispositivo de proteccion individual

GENERAL SECURITY RULES
NORME DI CARATTERE GENERALE SULLA SICUREZZA
SICHERHEITSHINWEISE
RÈGLES GÉNÉRALES DE SÉCURITÉ
NORMAS DE CARÁCTER GENERAL SOBRE LA SEGURIDAD
NORMAS DE CARÁCTER GENERAL ACERCA DA SEGURANÇA
ay attention to symbol DANGER! It points out all most dangerous operations according to the situation. All safety rules are important and therefore must be strictly
observed. Always keep this handbook within the reach, read it carefully and learn how to use the equipment in a safe way. Let nobody, not provided with necessary
information, work with the equipment.
Fare attenzione al simbolo PERICOLO! Esso indica la presenza delle principali situazioni di pericolo. Tutte le norme antinfortunistiche contente sono importanti e
vanno rispettate. Tenere sempre questo manuale a portata di mano, leggerlo attentamente ed imparare ad usare l’attrezzatura in modo sicuro. Non permettere che
qualcuno operi con questa attrezzatura senza aver ricevuto istruzioni esaurienti.
Attention au symbole DANGER! Il indique la présence des principales situations de danger. Toutes les normes contenues pour la prévention des accidents sont
importantes et doivent tre respectées scrupuleusement. Garder toujours ce manuel à la portée de la main, le lire attentivement et apprendre à utiliser ce matériel
en toute sécurité. Ne pas permettre que d’autres personnes utilisent ce matériel sans avoir reçus des instructions exhaustives.
Achtung - die mit dem ymbol GEFAHR! gekennzeichneten Hinweise weisen auf potentielle Gefahrensituationen hin. Alle sicherheitsrelevanten Hinweise in diesem
Handbuch sind sehr wichtig und müssen unbedingt befolgt werden. Bewahren ie dieses Handbuch stets griffbereit auf, lesen ie es aufmerksam durch, und
lernen ie, die Maschine und die gesamte Ausrüstung sicher zu benutzen. Die Maschine darf nur von Personen benutzt werden, die vorher entsprechend
unterwiesen wurden.
Preste atención al símbolo ¡PELIGRO! Indica la presencia de situaciones importantes de peligro. Todas las normas de prevención de accidentes detalladas son
importantes y deben respetarse estrictamente. Conserve este manual al alcance de la mano, léalo atentamente y aprenda a utilizar el equipamiento de modo
seguro. No permita que otras personas operen con este equipamiento sin haber recibido instrucciones exhaustivas.
Take special care not to touch hot parts of the engine.
Prestate particolare attenzione a non entrare in contatto con parti surriscaldate
del motore.
Veiller tout particulièrement à ne pas toucher des éléments surchauffés du
moteur.
Achtung – keine heißen Motorteile berühren!
No tocar partes recalentadas del motor.
Tome muito cuidado para não entrar em contacto com as partes aquecidas do
motor.
Engine exhaust fumes can cause sickness or death. If it is necessary to run an
engine in an enclosed area, use an exhaust pipe extension to remove the
fumes. Always try to work in a well ventilated area.
I gas di scarico possono causare malanni o morte. Se è necessario mettere in
moto un motore in uno spazio chiuso, usare una prolunga tubo di scarico per far
uscire il fumo. Lavorare in una zona ben ventilata.
L’exhalation des gaz d’échappement peut tre cause d’intoxication ou de mort.
S’il est vraiment nécessaire d’allumer le moteur à l’intérieur, appliquer au tuyau
d’échappement un autre tuyau extensible pour permettre la sortie des gaz. Il est
toujours mieux de travailler en plein air.
Auspuffgase können Übelkeit oder Tod verursachen. Wenn es notwendig ist,
einen Motor in einem geschlossenen Raum laufen zu lassen, benützen Sie eine
Verlängerung, um das Auspuffgas abzuleiten. Versuchen Sie immer in einem
gut belüfteten Raum zu arbeiten.
Los gases de escape pueden provocar enfermedades o muerte. De tener que
poner en marcha un motor en un espacio cerrado, usar una prolongación del
tubo de escape para que salga el humo. Trabajar en una zona bien ventilada.
Os gases de escape podem causar danos ou morte. Caso seja necessário
fazer com que o motor funcione num espaço fechado, utilize uma extensão
para o tubo de escape que os fumos sejam expulso para o exterior. Trabalhe
numa área bem ventilada.
Caution! Never touch moving pulleys or belts. They can be very dangerous.
Never do maintenance with engine running.
Attenzione! Non toccare mai pulegge o cinghie in movimento, creano gravi
danni alla persona. Non fare manutenzione col motore in moto.
Attention! Ne jamais toucher ni poulies ni courroies en mouvement, elles
peuvent provoquer des accidents aux personnes. Ne pas faire l’entretien quand
le moteur est en marche.
Vorsicht! Nie laufende Riemenscheiben oder Treibriemen anfassen, da es
gefährlich ist. Nie bei laufendem Motor Instandhaltung machen.
¡Atención! No tocar jamás poleas o correas en movimiento, porque pueden
crear graves daños a la persona. No efectuar el mantenimiento con el motor en
marcha.
Atenção! Nunca toque nas polias ou correias em movimento devido ao alto
risco de ferimentos. Nunca faça a manutenção da máquina com o motor ligado.

A burst which separates the tyre from the rim parts can cause serious injury or
death.
La separazione fra pneumatico e cerchione, causata dall’esplosione del
pneumatico, può provocare serie ferite o addirittura la morte.
La séparation entre le pneu et la jante, provoquée par l’explosion d’une roue
peut causer des dommages, blessures ou la mort.
Die Trennung der Räder von den Felgen durch Explosion kann schwere
Verletzungen oder den Tod verursachen.
La separación entre el neumático y la llanta producida por la explosión del
neumático puede provocar graves herida e incluso la muerte.
A separação entre o pneumático e o aro, provocada pela explosão do
pneumático, pode causar graves ferimentos ou até mesmo a morte.
Handle fuel with care, it is highly flammable: Do not refuel machine while
smoking, when machine is near an open flame or sparks, or when the engine is
running. Stop the engine.
Maneggiare il carburante con cura, è altamente infiammabile; non fate
rifornimento mentre fumate, o vicino a fiamme o scintille, o quando il motore è
acceso.
Manier avec soin le carburant car c’est très inflammable. Ne pas remplir le
réservoir si vous tes en train de fumer ou pendant que la machine est près du
feu ou d’étincelles ou encore pendant que la machine travaille. Arr ter le
moteur.
Treibstoff vorsichtig handhaben, da er sehr entzündbar ist: beim Tanken nicht
rauchen. Nicht tanken, wenn die Maschine in der Nähe von Flammen oder
Funken ist oder wenn der Motor läuft. Immer den Motor abschalten.
Manejar el combustible con cuidado porque es sumamente inflamable; no
repostar mientras se fuma o cerca de llamas o chispas, o cuando el motor está
encendido.
Manuseie o carburante com cuidado, pois este è altamente inflamável; não
fume durante o abastecimento da máquina ou enquanto o motor estiver ligado,
não o aproximado de chama ou de faíscas.
Prevent battery explosions: keep sparks, lighted matches and open flames
away from the top of the battery. Battery gas can explode.
Per prevenire l’esplosione della batteria, tenete scintille, fiammiferi accesi e
fiamme lontani dalla stessa. Il gas della batteria può esplodere.
Prévenir l’explosion de la batterie: tenir les étincelles, les allumettes et le feu
loin de la batterie. Le gaz de la batterie peut exploser.
Vorbeugung der Batterie-Explosion. Entfernen Sie Funken, Zündhölzer und
Flammen von der Batterie. Das Batteriegas kann explodieren.
Para prevenir la explosión de la batería, mantener chispas, cerillas encendidas
y llamas lejos de la misma. El gas de la batería puede explotar.
Para prevenir explosão da bateria ter centelhas, fósforos acendido e chamas
longe da mesma. O gás da bateria poderia explodir.
WARNING! SHARP PARTS. Keep hands and feet away. Do not operate the
mower over gravel or foreign bodies which may be sucked up and ejected by
the blades, generating a danger. Keep people away. Remove the key and read
the instruction manual before attempting to carry out any maintenance or
repairs to the machine.
ATTENZIONE! ORGANO TAGLIENTE. Tenere lontano mani e piedi. Non
lavorare col rasaerba sopra alla ghiaia o corpi estranei che possono essere
aspirati e centrifugati dalle lame risultando molto pericolosi, tenere lontano le
persone. Togliere la chiave e leggere le istruzioni prima di effettuare qualsiasi
operazione di manutenzione e riparazione.
ATTENTION! ORGANE TRANCHANT. Éloigner les mains et les pieds. Ne pas
utiliser la tondeuse sur le gravier ou sur des corps qui peuvent tre aspirés et
centrifugés par les lames et devenir très dangereux. Les personnes doivent se
trouver à une certaine distance. Enlever la clé et lire les instructions avant toute
opération de maintenance et de réparation.
ACHTUNG! SCHARFE KLINGEN. Hände und Füße fernhalten. Beim Mähen
nicht über Schotter, Steine oder andere Fremdkörper fahren, da diese durch die
Drehbewegung der Messer angesaugt und weggeschleudert werden können
(Verletzungsgefahr). Nicht in der Nähe von anderen Personen mähen. Vor
jedem Wartungs- bzw. Reparatureingriff den Startschlüssel abziehen und die
Gebrauchsanleitung durchlesen.
¡PELIGRO! ÓRGANO CORTANTE. Mantener alejados los pies y las manos.
No limpiar la herramienta con el motor en marcha. ¡Peligro! Expulsión de
objetos: mantener alejadas a las personas. Atención: quitar la llave y leer las
instrucciones antes de efectuar cualquier operación de mantenimiento o
reparación.
ATENÇÃO! Órgão cortante. Ficar longe com pés e mãos. Não trabalhar com a
máquina sobre cascalho ou objetos que podem ser aspirados e centrifugados
gerando perigo, manter-se longe das pessoas.
Tirar a chave de ignição e ler as instruções antes de efetuar qualquer operação
de reparo ou serviço.

Warning! Cutting edges, keep your hands and feet away.
Do not clean the attachment when the engine is running.
Attenzione! Organo tagliente, tenere lontano piedi e mani.
Non pulire l'attrezzo col motore in moto.
Attention! Organe tranchant, ne pas approcher main et pieds.
Ne pas nettoyer le moteur quand le moteur est en marche.
Achtung! Schneidende Klinge, Hände und Füße fernhalten.
Niemals bei laufendem Motor reinigen.
DANGER! READ THE INSTRUCTION MANUAL. KEEP SAFETY DISTANCES.
PERICOLO! LEGGERE IL MANUALE D’ISTRUZIONE. TENERE LONTANO LE
PERSONE.
DANGER! LIRE LE MANUEL D’INSTRUCTIONS. RESPECTER LES
DISTANCES DE SÉCURITÉ
GEFAHR! DIE GEBRAUCHS ANLEITUNG DURCHLESEN. NICHT IN DER
NÄHE VON ANDEREN PERSONEN MÄHEN.
PELIGRO! LEER LAS INSTRUCCIONES. MANTENER ALEJADAS LAS
PERSONAS.
PERIGO! LER O MANUAL DE INSTRUÇÕES. MANTER AS PESSOAS
AFASTADAS.
Before using the machine, it is mandatory to put on the appropriate individual
safety devices: body protection, protection gloves, security shoes, ear
protection.
Prima di utilizzare la macchina, è obbligatorio indossare gli appositi dispositivi di
sicurezza individuali: protezione del corpo, guanti di protezione, calzature di
sicurezza, protezione dell’udito.
Avant d’utiliser la machine, il est obligatoire de mettre les dispositifs individuels
de sécurité appropriés: protection du corps, gants de protection, chaussures de
sécurité, protection de l’ouïe.
Vor dem Gebrauch der Maschine ist es vorgeschrieben, die geeignete
persönlichen Schutzkleidung anzuziehen: Körperschutz, Schutzhandschuhe,
Sicherheitsschuhe, Gehörschutz.
Antes de utilizar la máquina es obligatorio ponerse los dispositivos individuales
de seguridad apropiados: protección del cuerpo, guantes de protección,
calzado de seguridad, protección del oído.

Translation of the original instructions
WALKING TRACTOR
G131
Dear Customer,
Thank you for choosing our walking tractor. We are sure that the performance of your new machine
will fully meet your requirements. To ensure optimum performance and maintenance, read this
manual carefully and follow its instructions. This will allow you to get the best results and protect
your investment. This manual should always be kept with the machine.
GENERAL DESCRIPTION AND INTENDED USE
The walking tractor is a single-a le self-propelled machine complete with a rotary tiller for tilling
soil. These machines are used primarily to prepare the soil (elimination of weed, surface tilling of
the soil) and used in gardening, for small ground work, refinement work and orchard inter-rows.
The machine is built on a frame and fitted with a diesel engine driving both wheels and PTO. A
rotary tiller is usually connected to the PTO. But other implements can be connected too, such as
snow throwers, cutter bars, rotary cutters, snow blades, ploughs, brushes and sprayer pumps. The
G131 is a pedestrian-controlled machine, the operator steers the machine via the handle-bar
where the controls are mounted.
CAUTION! Before starting the engine, read this caref lly. The following
warnings are very important in ens ring safety!
WARNINGS
Caution is the main safeguard in preventing accidents. We urge you to read the warnings that
follow when using the walking tractor and before starting any work at all. Improper use of the
walking tractor and its equipment can be dangerous. To reduce the risks to the minimum, observe
the necessary precautions set out below:
1) Read the whole of this manual before using your walking tractor. Be thoroughly familiar with the
controls and the proper use of the machine before starting.
2) Pay special attention to the safety warnings and labels.
3) The rotating tiller is e tremely dangerous; never insert hands or feet nder the tiller!
4) Before other people are allowed to use the machine, make sure they are informed about the
safety regulations and how to properly use this equipment.
5) Ensure children and animals are kept at a safe distance of about 15 metres. Do not allow people
to come closer to the walking tractor when it is being used.
6) Do not use the machine when physically fatigued or under the influence of alcohol or drugs that
could impair the operator's physical and mental capacities.
7) Thoroughly check the ground before using the walking tractor and remove any object that could
damage the tines (e.g. stones) or that could be caught up and flung down, therefore becoming
highly dangerous. (e.g. branches, stones).
8) Always wear s itable clothing and footwear. It is recommended to wear safety footwear,
safety goggles, ear pl gs and gloves, long tro sers. Do not wear clothing or accessories
that co ld get trapped in the controls or in the tiller (e.g. loose tro sers, scarves…).
9) Pay close attention when working on slopes. Always work across the slope and never
upwards/downwards. Pay greater attention when changing direction on slopes and never work on
e cessively steep ground.
10) Never allow the machine to be used by anyone under 16 years of age.
11) Pay close attention when operating the machine in reverse, make sure that there are no
obstacles behind you. In case of danger release the handlebar and the machine will stop
immediately.
12) It is dangerous to sharply activate the levers with the engine at ma imum r.p.m.
13) Do not operate the engine in a confined space where dangerous carbon mono ide fumes can
5

Translation of the original instructions
collect.
14) CAUTION: Petrol is highly inflammable. Store fuel in containers especially designed for this
purpose. Refuel outdoors and away from any open flames or sparks. Never smoke when refuelling.
Stop the engine before refuelling and never refuel with the engine running. Never remove the tap
of the fuel tank or add fuel when the engine is hot.
15) Avoid spillages and clean up all spills straight away.
16) Store fuel in containers especially designed for this purpose.
17) Make sure you work preferably in natural light or good artificial light.
18) Never use the walking tractor to crush building, metallic and plastic material nor roots and
trunks or any sort of garbage.
19) Do not use the machine to transport people, animals or objects.
20) Never disable safety devices.
21) Always stop the engine before making any adj stment or cleaning.
22) Never allow anyone to check the machine with engine r nning.
23) The user is always responsible for injuries or damages caused to third parties and for any risk
they could run.
24) Damaged tines must always be replaced and never repaired.
25) Always use genuine Grillo spare parts.
26) Before starting any work with the machine, check that all the accident prevention systems with
which it is equipped with are in perfect working order. They must never be disabled or tampered
with.
27) Before starting work, check that the nuts and bolts securing the tiller and tines are perfectly
secured.
28) Never operate the machine without safety protective devices in place (such as mudguards and
engine bonnets).
29) Never clean the tiller with the engine running.
30) Never use the machine barefoot.
31) Never change the ma RPM engine settings nor any other engine settings.
32) Allow the engine to cool before storing in any enclosure.
33) CAUTION: To reduce the risk of fire, keep the engine, the e haust pipe and the e haust
manifolds free from grass, leaves, dust, etc…
34) Drain the fuel only outdoors.
35) Do not run with the walking tractor.
36) Hold your feet away when starting the machine.
37) Do not lift or transport the machine with the engine running.
38) Do not store the machine with f el in the tank where petrol vapo rs co ld reach an open
flame or so rce of ignition.
39) Grillo walking tractors has been designed with the sole purpose of being used with original
Grillo attachments of with attachments designed by other manufacturers e pressively authorized
by Grillo. Non original attachments as well as attachments produced and/or modified by non-
authorized manufacturers must never been connected to the walking tractor. If you have any
question or doubt please contact the nearest Grillo authorized dealer.
Any improper se will void the warranty and the man fact rer will not be held responsible
for any damage that occ rs thereafter.
CAUTION!
We recommend the use of ear plugs/protection should the walking tractor be used for a prolonged
time. Use acoustic protections compliant with the current law (see picture below – Fig. A).
Fig. A
6

Translation of the original instructions
IDENTIFICATION AND SERVICING
The vehicle’s serial number is provided with an
ID plate showing the serial number, located on
the gearbo . Always state the serial number
when ordering spare parts.
AFTER-SALES SERVICE
This handbook provides instructions for use of the cultivator and for correct basic servicing which
the user can carry out personally. For all procedures not described in this manual, contact your
local dealer.
SPARE PARTS
Always use original spare parts, as they are the only ones to offer complete safety and
interchangeability. Always state the serial number when ordering. For engine parts, refer to the
specific handbook.
GUARANTEE
The guarantee is given in compliance with the current law. The Grillo dealer will supply the client
with a copy of the registration card of the machine, which they will print from the Grillo website. For
the engine, the guarantee of the relative manufacturers apply.
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced. Contact
your local dealer. Our address is:
GRILLO S.p.A.
Via Cervese 1701 - 47521 CESENA (FC) - ITALY
Tel. 0039 / 0547 / 381333 - Fa 0039 / 0547 / 632011
Web site: www.grillospa.it - E-mail: [email protected]
7

Translation of the original instructions
TECHNICAL SPECIFICATIONS G131
ENGINE:
LOMBARDINI 3 LD 510 with electric starter. Light kit also available.
MACHINE
Cl tch: active disc clutch.
Gearbox: oil-bath gears; 4 forward speeds and 2 reverse (walking tractor version) - 2 forward
speeds and 2 reverse (sickle bar version).
Speeds in km/h (mph) with engine at 3000 rpm are the following:
Gears Speeds with tyres 5.00-12 Speeds with tyres 6.5/80-12
1st
2nd
3rd
4th
1st REVERSE
2nd REVERSE
1,2
2,4
3,4
7,1
1,7
3,5
1,3
2,5
3,5
7,3
1,8
3,6
PTO: upper synchronized PTO (on demand) - lower PTO at 1028 rpm clockwise with engine at
3000 rpm.
Reverse Speed Interference: a safety device which prevents the engagement of the reverse
speed if the PTO is engaged (machine in walking tractor version).
Wheels: Tires 5.00-12 and 6.5/80-12 and steel wheels 46 12 cm.
Differential gear: with lock device on the handlebar.
Handlebar: reversible with height and side adjustment.
Rotary tiller: standard 70 cm, adjustable at 55 cm and 85 cm.
Weight: with rotary tiller and diesel engine 215 kg.
Attachments: rotary tiller and wheel e tensions, steel wheels, rotary tiller wheel, plough frame,
single furrow plough, turn-wrest plough, adjustabel furrower or furrower behind the rotary tiller,
potato lifter, cutting bar, towed trailer, brakes kit, wheel weights, all purpose flail, snow balde,
pivonting brush, snow thrower, stone burier, rotary plough, power harrow.
PUTTING THE MACHINE INTO SERVICE
1) Check that the machine has not been damaged during transport.
2) Remove the machine from its packaging, paying attention not to damage levers and wires.
Using a lifting machine of appropriate lifting capacity (min. 300 kg). Before leaning the machine
onto the ground mount the wheels and make sure the fi ing nuts are firmly tightened (fig. 2, n. 6).
3) The machine is delivered with the handlebar positioned in sickle-bar version (bent over the
engine). To put the handlebar in walking tactor version press the lever (fig. 1, n. 2) and slowly turn
the handlebar 180° clockwise, paying attention not to damage the wires. Then insert the control
levers (fig. 1, n. 3 – 12 – 13 15).
Important: the control levers delivered standard with the machine are those necessary for the
walking tractor version. If the machine is to be used in sickle-bar version the appropriate lever kit is
needed.
4) Before mounting the attachment thoroughly grease the machine PTO flange. Then mount the
attachment (e.g. rotary tiller, cutting bar…) and tightly fasten the fi ing nuts (fig. 3, n. 7).
5) Add engine oil – always refer to the attached instruction manual. The engine oil cap is located
under the engine hood.
6) Check the gearbo oil level (cap – fig. 4, n. 16). Use 80W90 oil (international ref. API GL5, US
MIL-L- 2105D).
7) Add oil into the air filter, use the same oil as for the engine (fig. 1, n. 10).
8

Translation of the original instructions
8) Check the tyre pressure following the table below:
TYRE PRESSURE
5.00-12 2 PLY RATING 1,5 BAR
6.5/80-12 2 “ “ 1,5 BAR “
9) Check the battery voltage. It must not be below 12,5 volt. If necessary recharge using a battey
recharger set at 12V on slow charge for two hours
IMPORTANT! During assembly take care not to get the polarity of the battery reversed.
10) Fill the tank with fuel using a funnel provided with a fine filter.
11) Check liquid levels with the machine set in horizontal position.
INSTRUCTIONS FOR USE
STARTING THE ENGINE
Before starting the engine:
- check the engine oil level (fig. 2, n. 20) and the gearbo oil level (fig. 4, n. 16); the oil level must
be between the two notches.
- check that all screws and nuts are well tightened, especially those fi ing the blades and the
attachments to the walking tractor.
- check that all levers are in idle/neutral position.
- check that the air filter is clean and that the oil is at the right level (fig. 1, n. 10).
- check the oil in the rotary tiller gearbo (fig. 5).
Full the tank with fuel (fig. 2, n. 5) using a funnel with a very fine filter.
STARTING THE DIESEL ENGINE
To start the engine turn the starting key on the handlebar clockwise (fig. 1, n. 9).
STARTING THE MACHINE
Below the decals positioned on the gearbo housing where the levers are mounted. These decals
show how to engage the speeds in both the walking tractor and sickle-bar version.
9

Translation of the original instructions
WALKING TRACTOR VERSION:
SPEED
POS. A + RID 1° FORWARD
POS. B + RID 2° FORWARD
POS. A + VEL 3° FORWARD
POS. B + VEL 4° FORWARD
POS. A + RM 1° REVERSE
POS. B + RM 2° REVERSE
SICKLE-BAR VERSION:
SPEED
POS. A + RM 1° FORWARD
POS. B + RM 2° FORWARD
POS. A + RID 1° REVERSE
POS. B+ RID 2° REVERSE
To start the machine, choose the speed using the lever on the gearbo on the right side of the
handlebar (fig. 1, n. 13), then choose either the fast or slow gear using the outer lever located ne t
to the previous one (fig. 1, n. 3). The machine will start moving by pressing the grey safety lock
device (fig. 1, n. 21) and subsequently pressing the red clutch lever (fig. 1, n. 1).
IMPORTANT: Before pressing the cl tch red lever to start the machine always check which
gear is engaged, if the forward gear or the reverse gear (see label fig. 1).
If the gear does not immediately engage, do not strain the lever: engage and disengage the clutch
repeatedly and very slightly until the gear is engaged.
When releasing the red lever (fig. 1, n. 1) the machine stops immediately while the engine keeps
on running and the red clutch levercomes back into vertical position.
STARTING WORK (walking tractor version)
Push forward the grey PTO lever (fig. 1, n. 15) until it is locked to engage the rotary tiller. If the tiller
does not immediately engage, do not strain the lever: engage and disengage the clutch repeatedly
and very slightly until the tiller is engaged.
CAUTION: When the tiller is on never p t yo r hands and feet nder the hood and do not
open the tiller door. This door m st be kept adherent to the gro nd to ens re a safe se of
this machine.
NOTE: to avoid problems to the clutch during the functioning of the machine, please keep the red
lever firmly depressed. Important: Do not use the machine whilst only partially depressing the red
lever.
To disengage the rotary tiller pull the PTO lever (fig. 1, n. 15).
REVERSE GEAR (walking tractor version)
To engage the reverse gear in walking tractor version, pull the outer red lever (fig. 1, n. 3) which is
located on the right side of the handlebar. If the gear does not immediately engage, do not strain
the lever: engage and disengage the clutch repeatedly and very slightly until the gear is engaged.
IMPORTANT: Before pressing the cl tch red lever to start the machine always check which
gear is engaged, if the forward gear or the reverse gear (see label fig. 1).
10

Translation of the original instructions
CAUTION: for safety reasons on all Grillo walking tractors it is not possible to engage
reverse gear when the rotary tiller is on. The PTO m st always be disengaged before
engaging the reverse gear. IN CASE OF DANGER RELEASE THE RED CLUTCH LEVER (fig.
1, n. 1) BOTH THE MACHINE AND THE ROTARY TILLER WILL IMMEDIATELY STOP.
HANDLEBAR ADJUSTMENT
To adjust the height of the handlebar unlock the appropriate lever (fig. 1, n. 11), raise or lower the
handlebar and then release the lever to lock its position. To turn the handlebar use the lever (fig. 1,
n. 2), turn the handlebar to right or to the left and then release the lever to lock its position.
DIFFERENTIAL LOCK
G131 is equipped with the differential on the wheels a le. A black lever (fig. 1, n. 12) is placed on
the left side of the handlebar, that is used to lock (by turning the lever downwards) and unlock (by
turning the lever upwards) the differential. The differential is normally unlocked when working to
make steering easier. It is recommended to engage the differential lock when working on slopes
and on uneven soils to improve the machine adherence to the ground.
WHEEL AXLE LOCK
The walking tractor can be towed by hand by unlocking the transmission wheel a le. To unlock the
wheel a le turn the lever located at the base of the handlebar (fig. 4, n. 19 - follow the instructions
on the label placed beside the lever). Once the machine has been towed, bring the lever back into
working position.
ATTENTION: It is highly dangero s to work on slopes with the wheel axle nlocked.
HOW TO SWITCH THE DIESEL ENGINE OFF
Press the switch-off lever located on the left side of the handlebar (fig. 1, n. 22).
IMPORTANT: once the engine has been switched off, turn the starting key anti-clockwise to
disconnect the battery (fig. 2, n. 23). Should the ignition key remain ON with the engine off, the
battery will run down.
FINISHING WORK
Once work has been finished, switch the engine off, remove the ignition key, set the gear lever in
idle position and disengage the PTO.
ATTENTION: on slopes never leave the machine in idle position. If it is necessary to park the
machine on slopes always engage the 1st gear (fig. 1, n. 13).
ATTENTION: never leave the machine unguarded or in a place where children or ine perienced
people could have easy access to it.
TIPS FOR EFFICIENT USE
1) Never leave the machine e posed to bad weather condition.
2) Never force the reverse gear: If the gear does not engage immediately, do not force the lever
but press and release it repeatedly until the gear engages.
3) Never strain the engine: if smoke comes o t of the exha st, slow down.
4) Adjust the central knife (fig. 20) according to the kind of soil (hard/soft).
TROUBLESHOOTING
The following is a list of inconveniences which may occur during the use of the walking tractor,
which the operator himself can remedy.
1) if the diesel engine does not start check:
– that the fuel tank vent hole is not blocked;
– that the fuel tank is at least half full.
2) If the engine is on but the machine does not move forward:
- check that the wheel a le lever (fig. 4, n. 19) is in working position.
- check that the gear is engaged.
11

Translation of the original instructions
- check that the red clutch lever is fully pressed down and that the clutch spring is compressed.
Should this not be the case, use the clutch cable adjusting screw (fig. 1, n. 8).
4) if the diesel engine cannot be switched off:
– check that the lever to switch off the diesel engines located on the left side of the handlebar (fig.
1, n. 22) is fully pressed down.
– check that the electric wire to switch off is correctly connected to the engine.
IN CASE OF LONG IDLE PERIODS
Should the machine not be used for a long time:
- fully empty the fuel tank.
- thoroughly clean both the engine and the walking tractor. Lubricate the handlebar support.
- remove the battery and store it into a dry place and recharge it at least once a month (fig. 2, n.
23).
MAINTENANCE AND LUBRICATION
CAUTION!
- Before performing any cleaning, maintenance or repair operation always wear s itable
clothing and working gloves.
- When the machine or part of it is lifted to carry o t maintenance operations, always
remember to se s itable fixing tools s ch as holders and safety locks.
- When carrying o t maintenance operations and/or when the machine is tilted witho t
safety locks or s pports, never leave it ng arded in places where inexperienced people
and children co ld have easy access to it.
- Protect the environment: caref lly dispose of sed oils and any other poll tant prod ct!
- Effective maintenance and correct l brication help to keep the machine f lly efficient.
Notice: to check oil levels always keep the machine in horizontal position.
ENGINE OIL
Carefully follow the directions in the manual. However it is necessary to check oil level every 4
working hours and replace it every 100 hours (fig. 2, n. 20). Use engine oil 15W40.
AIR FILTER
Check both the oil level and the cartridge every 8 hours or even more frequently in a very dusty
environment (fig. 1, no. 10).To replace the oil or restore the level use the engine oil.
GEARBOX OIL
Check the oil level every 50 working hours (fig. 4, n. 16) and if necessary add gearbo oil 85W90
(quantity 3,3 kg). Replace oil once a year. To drain the old oil unscrew the cap (fig. 3, n. 18).
TILLER GEARBOX OIL
Check oil level every 100 hours by unscrewing the screw on the tiller gearbo cover (fig. 5). Check
that oil reaches the edge of the hole. If necessary add the same oil as for the gearbo . Replace the
oil once a year (quantity 0.4 kg). The observance of these rules helps to keep all the mechanical
parts of your machine fully efficient.
12

Translation of the original instructions
GENERAL MAINTENANCE
The walking tractor G131 does not require special maintenance. However, to keep it at its highest
performance the following operations are recommended:
– Check that all screws and nuts are tightened; particularly those fi ing the tines, those of the
engine and of the rotary tiller at the flange.
– Lubricate the clutch and throttle wires.
– Lubricate the sliding bearing of the handlebar locking pin.
– Remove any leaves and grass that may have deposited on the engine front grid.
– Often check oil levels and clean the air filter frequently.
– Grease the machine coupling 2 or 3 times a year, by disconnecting the rotary tiller from the
flange.
END OF SEASON MAINTENANCE
Carefully wash the walking tractor, replace the oil in both the engine, the gearbo oil and the rotary
tiller, clean the air filter. Sharpen the hoes and grease them. Replace them if worn. IMPORTANT:
The hoes of Grillo walking tractors are made of a special steel s bjected to heat treatments.
Never weld the hoes if broken or cracked, beca se they co ld break and be fl ng away
becoming therefore highly dangero s for people and objects aro nd.
MAINTENANCE SUMMARY TABLE
PROCEDURE EVERY 8
HOURS
AFTER 20
HOURS
EVERY 50
HOURS
EVERY
100
HOURS
EVERY 200
HOURS
Engine oil check the level ●
change ● ●
Air filter
check ●
replace ٭
Cutter bar
check blade
attachment ●
grease ●
Check that the engine intake grid is
clean ●
Gearbo oil
check the level ●
replace ●
Check that blades are well-
sharpened and well-fi ed ● ●
Lubricate with grease ● ●
● recommended procedure
٭ proced re to be carried o t if necessary
13

Translation of the original instructions
IMPLEMENTS
IMPORTANT
When connecting each implement to the attachment flange make sure both sides are perfectly
aligned. First hand-tighten the bolts then use a wrench to make them press on the flanging (fig. 3,
n. 7).
ROTARY TILLER
The rotary tiller is used to break the surface layer of the ground in order to increase its permeability
and at the same time to get rid of weeds. Till in first speed if the soil is hard and tough or in second
speed in soft, sandy soil. Working depth can be adjusted by lifting or lowering the central knife
positioned under the rotary unit. To increase the working depth move the central knife upwards. It
is recommendable to start tilling with the knife in the lowest position, and then to raise it if greater
depth is required (fig. 20).
Note: On hard soils the machine may jump forward. In this case set the central knife in the first
hole (fig. 20). Check that hoes are mounted properly.
CAUTION: In walking tractor version it is not possible to engage the reverse gear if the PTO
is engaged. Never disable the safety system.
CAUTION: Keep yo r hands and feet away from the rotary tiller hood when the engine is
r nning, rotation of the tiller is highly dangero s. Before performing any kind of operation
on the tiller (e.g. replacing hoes), ALWAYS SWITCH OFF THE ENGINE.
ROTARY TILLER SUPPORT WHEEL
It is very useful while transferring the machine, because it keeps the rotary tiller off the ground,
making transfer easier and less tiring (fig. 8).
CAUTION: Keep yo r hands and feet away from the rotary tiller hood when the engine is
r nning, rotation of the tiller is highly dangero s. Before connecting or removing the
s pport wheel, ALWAYS SWITCH OFF THE ENGINE.
PLOUGHS
Ploughs designed for this walking tractor have been especially developed to obtain good ploughing
without straining the operator. The models available are a single-share plough and an 180roll-
over plough (fig. 11). The latter is especially suitable when working backwards and forwards, such
as along rows of vines or fruit-trees. The depth of the furrow obtained may vary from 10 to 15 cm
depending on the terrain. Better results are obtained by fitting the 6,5/80-12 tyres and if necessary
the wheel-weights which increase the wheel grip (fig. 10).
FURROWER BEHIND THE ROTARY TILLER
This tool is mounted at the rear of the tiller and works in tandem with it. The furrower is designed to
produce irrigation and seed drills (fig. 26). For the coupling mount the bushing (fig. 9).
CAUTION: Keep yo r hands and feet away from the rotary tiller hood when the engine is
r nning, rotation of the tiller is highly dangero s. Before connecting or removing the
s pport wheel, ALWAYS SWITCH OFF THE ENGINE.
ADJUSTABLE FURROWER
The adjustable furrower (fig. 12 – combined with the frame for attachments) is specially designed
for preparing furrows for sowing and irrigation. It is mounted using the frame for attachments like a
plough on the back of the gearbo . The furrow width can be regulated from a minimum of 10 cm to
a ma imum of 30 cm, by changing the position of the two wings. The depth can be varied from 10
to 20 cm. When working on particularly hard soils, till before furrowing. Better results can be
achieved by fitting the 6.5/80-12 tyres and the wheel e tensions (fig. 6).
14

Translation of the original instructions
TOWED TRAILER
The towed trailer is very useful for short transfers (fig. 19). It is easy to handle, compact and very
quickly hitched to the walking tractor. The trailer can be attached directly to the machine by hitching
it to the special towing bar (fig. 9) leaving the tiller in place. Ma . load: 400 kg on even ground. Do
not se the trailer on slopes greater than 5%. Passengers are not allowed. The trailer cannot
be sed on p blic roads.
TOW BAR
The towing bar is needed to attach the trailer to the machine without removing the rotary tiller. This
attachment must be fastened to the towing hook on the walking tractor (fig. 9).
WHEEL-WEIGHTS
These are mounted on the wheel rims and fi ed with two of the four nuts which fi the wheels
themselves. They increase the weight of the machine and thus its adherence to the ground, and
their use is recommended when working with the plough, the adjustable furrower, and even the
rotary tiller and the trailer if special performances are required (fig. 10).
WHEEL EXTENSIONS
These help to widen the machine track and increase its stability on crosswise slopes. They must
be fi ed between the wheels and the hubs. The track is widened by 6 cm on each side (fig. 6).
WIDE STEEL WHEELS
These wheels (fig. 7) are recommended when working on very hard soils with the rotary tiller. The
cross bars placed around the wheels dig into the ground, giving the machine a firm grip and
preventing the wheels from skidding. Wide steel wheels can also be used when tyres or narrow
steel wheels normally skid or sink in damp or recently tilled ground. The use of wide steel wheels is
recommended, although only in these cases. Otherwise tyres are generally recommended given
that, if special grip is not required, they grant the machine even more traction and act as an elastic
buffer between the machine and the ground.
CUTTING BAR
The cutting bar (fig. 14) which can be attached to the walking tractor has a central control. Its
strength and high performance make it the best way of mowing small pieces of land when it is not
convenient to purchase a sickle mower which would remain unused for most of the year, while a
walking tractor can be used with other implements. The cutting bar is attached to the walking
tractor implement frame instead of the rotary tiller and fi ed using the two nuts of the rotary tiller.
The handlebar must be turned 180 over the engine. Before turning the handlebar remove the four
control levers and replace them with those of the appropriate kit for cutting bar. It is recommended
to engage the 2nd gear when using this machine with the cutting bar (see the speed table in sickle-
bar version in the paragraph INSTRUCTIONS FOR USE of the present manual). Important: if the
rotary tiller is connected again, the safety system has to be bro ght back to its original
working condition. Grillo bears no responsibility in case of non-compliance with this r le.
Maintenance: grease the cross pins every 8 working hours through the grease nipples on the
swinging crank. Grease the cutting bar swinging bushing every 50 working hours through the
grease nipple under the swinging protection. Keep the blade ledger plates properly adjusted. They
must be neither too tight, so that they block the blade, nor too loose so that there is too much
clearance between them and the blades. To adjust the ledger plates in both directions loosen the
locking bolts and adjust the pressure screw. The ledger plates should be replaced when worn even
if they are still able to apply pressure against the blades. Adjust the free-play between the blade
and the strip by loosening the screws fi ing the plates pressing the strip and moving the strip
forward until it touches the bar which supports the nailed blade section. Then re-tighten the
pressing plates. To remove the blade take off the L-shaped blade coupling by loosing the two
screws and slip off the blade. Take care to tighten the fi ing screws of the coupling after
assembling the blade again. Always use sharp blades: the machine will be subject to less strain
and its working life will be longer. Clean the cutting bar after every working day, removing any
remaining pieces of grass or earth; frequently that all screws are tight.
15

Translation of the original instructions
SNOW THROWER
This implement (fig. 18) has been especially designed for this particular walking tractor. It is very
useful for clearing snow from yards, driveways, etc. It consists of a turbine rotary unit enclosed in a
special case open at the front, which rotates at high speed, collecting the snow and throwing it
along a pipe. The pipe angle can be adjusted to throw the snow in any direction to a distance of 8 –
10 metres. The snow thrower is fi ed to the implement flange using two nuts. The snow thrower is
80 cm large and can clear snow up to 40 cm. Wheel weights or wheel chains should be used to
obtain a better performance. If the snow is very wet, keep the ejection pipe turned forward to avoid
obstructions at the outlet. The two side skids must be adjusted so that they just skim level ground
(asphalted streets) or keep the snow thrower high if the ground is uneven. The snow-thrower has
to be attached to the implement flange with the handlebar in sickle-bar version, with the
appropriate lever kit for snow thrower and with the lever to operate the snow chute (fig. 18)
Important: if the rotary tiller is connected again, the safety system has to be bro ght back
to its original working condition. Grillo bears no responsibility in case of non-compliance
with this r le.
Maintenance: when work is over, remove any snow left in the snow thrower so it cannot freeze
and block the turbine. Often check the oil level in the central bo . Do not clean the attachment
when the engine is r nning. Attention, danger! Never to ch the snow thrower while it is
working.
ALL PURPOSE FLAIL
The all purpose flail (fig. 15) is 68 cm wide and it's fitted with a roller with swinging Y-tines. It is
used to cut tall grass, tough stalks and small shrubs into fine pieces; it can also twigs etc. after
pruning. Used with mower blades instead of the y tines, it gives e cellent results on smooth lawns.
The all purpose flail has to be connected to the implement flange using the quick coupling. The
handlebar must be turned 180° over the engine (to carry out this procedure follow the instructions
outlined above for the cutting bar).
Attention, danger! The roller of the all p rpose flail is highly dangero s. Never p t hands or
feet nder the all p rpose flail. Never clean the attachment when the engine is r nning.
Important: if the rotary tiller is connected again, the safety system has to be bro ght back
to its original working condition. Grillo bears no responsibility in case of non-compliance
with this r le.
TILTING FRONT BLADE – 125 cm
This highly resistant device is ideal for removing snow and levelling mounds of soil or gravel. It can
be be tilted to the right and left (fig. 17). The handlebar must be turned 180 over the engine (to
carry out this procedure follow the instructions outlined above for the cutting bar)
PIVOTING BRUSH – 120 cm
This brush (fig. 16) can be attached to the machine following the mower bar's instructions. It is very
useful to clean roads and squares. It can also be used to clean up 10-12 cm high fresh snow and it
can be steered left or right to make drifts. It can be be tilted to the right and left. The handlebar
must be turned through 180 over the engine (to carry out this procedure follow the instructions
outlined above for the cutting bar). To engage the brush the safety system preventing the reverse
gear and the PTO from being engaged at the same time (which is then necessary with the rotary
tiller) has to be deactivated.
Important: if the rotary tiller is connected again, the safety system has to be bro ght back
to its original working condition. Grillo bears no responsibility in case of non-compliance
with this r le.
WARNINGS FOR TRANSPORT
Walking tractors cannot be used on public roads. If the machine is to be transported on a lorry or a
trailer, lower the handlebar, engage the 1st gear, fasten the walking tractor to the lorry/trailer using
ropes or belts. If a lifting machine is used to lift the walking tractor from the ground into the
lorry/trailer make sure its lifting capacity its suitable for the walking tractor.
16
