Grind’n Brew™Series
Dual Bean Grinderbrewers
Model 20H
(Airpot sold separately)
Model 21H
(Decanter sold separately)
Digitally controlled Dual Bean Grind’n Brew™ Brewer
System. Brewer will maintain brew temperature to ±1ºF
throughout brew cycle. Brew temperature, brew volume
(full and half batch), grind portions (right and left
hopper, full and half batch), operator defined
pre-infusion/pulse brewing, energy savings and Low
Temp/No Brew are programmable from the front display.
Bean Usage
Counter
25
1

Features:
•Dual Bean Grind’n Brew™ System - 3-Function capability: Grind only; Brew
only; Grind’n Brew™, full and half brew capabilities.
Digitally controlled with Technology.
•Space-saving design eliminates the need for both grinder and brewer.
•Bean Usage Counter - Controller records volume of beans used from the hoppers.
•Grind Time - Grind time for half and full batch, right and left hopper can be
set from front of brewer.
•Shutter mechanism keeps water vapor separated from grind head.
•Precise Brew Temperature - The brewer will hold the brew temperature to
+/- 1°F during the complete brew cycle.
•Brew Volume - Can be set by ‘teach’ mode to eliminate trial-and-error set-up.
•Pulse brewing/pre-infusion - Allows the brew sequence to extract up to 20%
more dissolved solids per batch of coffee. Programmable: number of pulses,
pulse-on time and pulse-off time. Changing the pulse sequence does not
affect the brew volume.
•Low Temp/No Brew - Allows the brew cycle to begin only when the water has
reached the optimum brew temperature.
•Programming Lock-Out - The brewer settings can be “locked” to prevent
tampering.
•Energy Savings/Coffee Old - The warmers, on 21H series models, can be
programmed to shut off up to 240 minutes from the last brew cycle.
Dual Bean Grinderbrewers
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
© Grindmaster Corporation, 2000
PRINTED IN USA 0607 Form # AM-291-06
Specifications Model 20H/20HE Model 20HQ Model 21H/21HE Model 21HQ
Volts / Watts / Amps 20H: 120V / 1710W / 15A
20HE: 230V / 3214W / 14A
120/208-240V /
2674/3650W / 20A
21H: 120V / 1810W / 15A
21HE: 230V / 3306W / 14.4A
120/208V-240V /
2749/3660W / 20A
No. of Bean Hoppers 2 2 2 2
Hopper Size 6-1/2 lbs. (2.93 kg) each 6-1/2 lbs. (2.93 kg) each 6-1/2 lbs. (2.93 kg) each 6-1/2 lbs. (2.93 kg) each
Brew Capacity 74 oz. (2.2L) 74 oz. (2.2L) 64 oz. (1.9L) 64 oz. (1.9L)
Dimensions
(H x W x D)
37-1/2” x 9-1/2” x 24-1/4”
(94 cm x 24 cm x 61 cm)
37-1/2” x 9-1/2” x 24-1/4”
(94 cm x 24 cm x 61 cm)
32-3/4” x 9-1/2” x 24-1/4”
(82 cm x 24 cm x 61 cm)
32-3/4” x 9-1/2” x 24-1/4”
(82 cm x 24 cm x 61 cm)
Ship Dimensions
(H x W x D)
38-1/4” x 15-1/2” x 29-3/4”
(96 cm x 39 cm x 74 cm)
38-1/4” x 15-1/2” x 29-3/4”
(96 cm x 39 cm x 74 cm)
38-1/4” x 15-1/2” x 29-3/4”
(96 cm x 39 cm x 74 cm)
38-1/4” x 15-1/2” x 29-3/4”
(96 cm x 39 cm x 74 cm)
Weight 90 lbs. (40.5 kg) 90 lbs. (40.5 kg) 90 lbs. (40.5 kg) 90 lbs. (40.5 kg)
Ship Weight 95 lbs. (42.75 kg) 95 lbs. (42.75 kg) 95 lbs. (42.75 kg) 95 lbs. (42.75 kg)
Listings UL, CUL, UL San.,
RoHS (E model only) UL, CUL, UL San UL, CUL, UL San., RoHS (E model only) UL, CUL, UL San.
Specifications are subject to improvement or change without notice.
Front view - 21H
Front view - 20H
