Grixx GROHBTBK01 User manual

Grixx User Guide
1
User Guide
Black: GROHBTBK01
Blue: GROHBTBL01

Grixx User Guide
2
Congratulations on your purchase!
Dear Grixx product owner,
Thank you for your trust in Grixx and the purchase of the wireless
overband headphones.
These comfortable lightweight wireless headphones enable you to
listen to your favourite music during all kinds of activities, wire-free.
The integrated microphone allows you to easily switch from listening
to music and answering phone calls.
They can also be used as wired headphones in combination with the
included 3.5mm jack audio cable.
As an owner of a Grixx product you are entitled to our warranty,
which is available to you for 2 years after your purchase. For any
questions or problems please contact [e-mail]. We are
happy to help you and solve any issues.
Enjoy many hours of listening to your favorite music, books, podcasts
and calls with friends or family with this product.
Happy Times!

Grixx User Guide
3
Content
Welcome 2
About these instructions 4
Important safety warnings 4
Specifications 4
In the box 4
Buttons & indicators 5
Charging 5
Battery low 5
Pairing 6
Functions 6
Cleaning 6
Caution 7
General instructions 7
Exclusion of liability 7
Environmental information 8
Disposal 8
Compliance 9
Social compliance 9
About Grixx 10

Grixx User Guide
4
About these instructions
Read these instructions carefully and please observe and heed all references made in these
instructions to guarantee a long life and reliable use of the device. Please keep these instructions at
hand and pass them on to other users of the device.
Important safety warnings
•Choking Hazard - Warning
This product may contain small parts which may be a choking hazard to children under 3; keep small
parts away from children.
•Warning
Listening to music at full volume for an extended period of time may damage your hearing.
Please be cautious with volume levels.
Specifications
Driver unit Dynamic 40mm
Driver material Ferrite (ceremic)
Bluetooth version 5.0
Wireless range 10 mtr
Battery type Lithium 400mAh
Battery life 9 -10 hours
Standby time up to 200 hours
Charging time 1.5 –2.5 hours
Frequency response range 20Hz-20KHz
Impedance 32Ჲ
Sound level 110 ± 3dB
Sensitivity 117 ± 3dB
Channel matching Yes
Harmonic distortion ≦5% THD
Rated Power 8mW
Maximum power 12mW
Mic sensitivity -38 ± 3 dB
Mic frequency 70 Hz - 10 kHz
Mic directivity Omni Directional
Remote control Yes
Weight 150gr
In the box
•Headphones
•3.5mm Audio Jack cable
•Micro USB cable

Grixx User Guide
5
Buttons & indicators
1Power / Pair / Answer
2Volume down / Previous track
3Play / Pause
4Volume up / Next track
5Microphone
635mm Audio Jack input port
7Micro USB charging port
8LED indicator
Charging
First time charging: Before using these wireless headphones,
the battery needs to be fully charged.
Use the micro USB cable to connect the headphones to your
PC or charger.
•Red light on: Charging in progress.
•Red light off: Charging finished.
lt will take about 1.5 to 2.5 hours to fully charge the battery.
Turn on/off the headphones
•Turn on
Press the power button (1) about 2-3 seconds and release it when the blue light flashes.
•Turn off
Press the power button (1) about 2-3 seconds and release when the light stops flashing.
Battery low
lf the battery runs low, you will hear a voice prompt “Battery Low”.

Grixx User Guide
6
Pairing headphones with Bluetooth devices
Use the Bluetooth pair (power on/off) button
Press and hold the button for 3 seconds to enter paring mode.
The LED indicator flashes red and blue alternately
You will hear a voice prompt “Power on Bluetooth mode”.
Activate Bluetooth on your phone and set it to search for new devices.
Select “Grixx Headphones”; the LED indicator stops flashing red and blue once success fully paired.
You will hear a voice prompt “Connected”.
Press and hold the button for about 3 seconds to turn the headphones off. You will hear a voice
prompt “Power off”.
Functions
•Answer call
Short press the power button
•Reject call
Long press the power button
•End call
Short press the power button
•Redial last call
Double press the power button
•Previous track
Short press - << button
•Next track
Short press >> + button
•Volume down
Long press - << button
•Volume up
Long press >>+ button
•Pause/play
Short press to pause/play the music
Wired functions
Via 3.5mm Jack, the call functions are disabled.
Connect the headphones to a 3.5mm audio jack connector on your mobile device or PC using the
supplied cable, you can enjoy the music through your headphones.
Cleaning the headphones
Use a dry cleaning cloth to wipe away dust and oil.
Do not use aerosol sprays, solvents, or abrasives.
Use a damp cloth with soap to clean headband cushions and sliders.
Do not use a damp cloth on the ear cups or ear cup mesh—use a dry cleaning cloth instead.

Grixx User Guide
7
Caution
•Do not dismantle the product without expertise, this may damage the products or cause fire.
•Do not place the LED indicator directly in front of your eyes.
•Do not use in a hot humid environment.
•Do not put the product in water.
•Obstacles, such as walls, may reduce the Bluetooth range.
•Do not dispose the battery to fire, as it may cause explosion.
•To avoid breaking the cable, pull the plug - not the cable - when removing them from the
charging source.
•Wrap the cable up carefully and neatly –do not fold - when you are not using them so it doesn't
get bunched up and break.
General instructions
Failure to follow the safety instruct ion s can lead to dangerous situations or personal in jury.
Make sure to read the entire manual.
•Do not use this unit for anything other than its intended use.
•Do not use the product if it has been dropped or damaged in any way.
•Keep the unit out of reach of children.
•Do not disassemble the device into its component parts and do not try to repair it yourself. It
does not contain any parts requiring maintenance and the guarantee expires in this case.
•Do not use the device when it shows visible damage or has become moist.
Exclusion of liability
The firmware and/or hardware may be changed at any time without prior notice. For this reason it is
possible that parts of these instructions, technical data and images in this documentation differ
slightly from the product in your possession. All points described in these instructions only serve the
purpose of clarification and must not inevitably correspond to a certain situation. Legal claims cannot
be made on the basis of these instructions.

Grixx User Guide
8
Environmental information
All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate
into two materials: cardboard and plastic. The whole product packaging consists of materials which
can be recycled and reused if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials and old equipment.
This symbol on packaging signifies that the producer has made a financial contribution towards the
recovery and recycling of packaging.
Disposal of your old product
Your product is designed and manufactured with high quality materials and components, which can
be recycled and reused.
The battery is recyclable, do not dispose of the battery in fire as it may cause explosion.
This symbol on a product means that the product is covered by European Directive 2012/19/EU and
cannot be disposed of with normal household waste. We strongly advise you to take your product to
an official collection point. Inform yourself about the local separate collection system for electrical
and electronic products. Follow local rules and never dispose of the product with normal household
waste. Correct disposal of old products helps prevent negative consequences for the environment
and human health.

Grixx User Guide
9
Compliance
Compliant with CE
This symbol means that the product is compliant with health, safety, and environmental protection
standards for products sold within the European Economic Area. The product is manufactured in
accordance with provisions imposed by EMC (Electromagnetic Compatibility) and RoHS (Restriction
of Hazardous Substances) Directives. To minimize the environmental impact and take more
responsibility to the earth we live on, the product complies with the restriction of SVHC (Substances
of Very High Concern) and REACH (Registration, Evaluation, Authorization, and Restriction of
Chemicals) regulated by the European Union.
Social Compliance
Grixx endorses the importance of equal and good working conditions for everyone within the
production chain. That is why the manufacturer of this product is BSCI and /or SA8000 certified. This
means that this product is designed and produced in a community that adheres to ethical
sustainability and endeavors to protect the health, safety, and rights of the employees and
environment in which they operate.
The producer follows the rules based, among others, on the United Nations' International Labor
Organization (ILO) 'code of conduct' and the Human Rights Declaration. The main principles affiliated
with the social compliance include:
•No discrimination
•No child labor
•Legal minimum wages
•Protection on the number of hours people have to work
•No forced labor
•Safe working environment
•Measures against corruption
Having the Grixx product manufactured in compliance with social sustainability values, where high
standards are required of the supplier, helps contribute to the people involved in production of the
product being treated fair, with dignity and respect.
For more information go to https://www.amfori.org/

Grixx User Guide
10
About Grixx
Grixx offers a complete range of mobile accessories that enable users to optimize the use of their
mobile device. Each product offers great value for money and is developed and produced with
respect for the environment, people and working conditions.
The range contains –amongst others –headphones, powerbanks, (wireless) chargers, sync & charge
cables and many more!
For more information and more products please go to www.grixx.eu.
Grixx and the Grixx logo are registered trademarks of Leli Group Holding B.V.; Leli Group Holding B.V.
is the warrantor in relation to this product.
