Grizzly T31616 User manual

For questions or help with this product contact Tech Support at [phone] or [e-mail]
MODEL T31616
VARIABLE-SPEED
AIR MOVER
INSTRUCTIONS
Introduction
This variable-speed air mover offers two built-in
outlets to connect multiple units, and sits in four
different positions for ease of placement.
COPYRIGHT © SEPTEMBER, 2019 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#CS20628 PRINTED IN CHINA V1.09.19
Specifications
• Motor ......................... 120V, 1-Ph, 60 Hz, 1A
• Maximum Total Current Rating ............... 15A
• Speed ................................... 900-1500 RPM
• Maximum Airflow ........................... 300 CFM
Operation
Figure 1. Air circulation.
Air Inlet
(1 of 2)
Air Outlet
1. Place air mover at desired position with air
inlets and outlet unobstructed and on a level
surface (see Figure 1).
2. Make sure variable-speed dial is OFF (see
Figure 2), then plug into a GFCI-protected
outlet.
Figure 2. Power components.
Variable-Speed
Dial
Power
Cord
120 VAC Outlet
(1 of 2)
• To avoid electric shock, do not handle
plug or machine with wet hands and do
not expose to rain or place directly in wet
area.
• Disconnect power before servicing,
cleaning, or when machine is not in use.
• Only plug power cord into a grounded
outlet.
• Keep hair, loose clothing away from fan.
• Do not modify machine in any way.
• Do not use if cord/plug becomes dam-
aged—only replace with Ground Fault
Circuit Interrupter plug (GFCI).
• Do not run cord under carpeting or where
it may be tripped over.
• Not meant for outdoor use.
• To avoid fire, do not use in area with
flammable or combustible liquids/fumes.
• Prevent unauthorized use by children or
untrained users.

-2- T31616 Variable-Speed Air Mover (Mfd. 9/19+)
3. Turn speed dial to desired speed setting to
turn air mover ON.
Note:If air mover stops operating while still
connected to power and with speed dial
turned ON, circuit overload may be tripped.
To reset, make sure air mover is dry, vents
are unobstructed, and that it is not overheat-
ing, then press reset button (see Figure 3).
4. Follow Steps 1–3 to connect additional air
mover devices to two built-in outlets (see
Figure 2). Disconnect from power when not
in use.
Note:Do not exceed 12A of current draw
between two built-in outlets, i.e., 6A max. is
limit for each receptacle.
Reset
Button
Figure 3. Reset button location.
