Grizzly H6151 Quick start guide

-4- H6151-54 Heat Sealing Machines
1
7
4
8
9
13
10
11
12
15
16
17
18
20
32 14
35
36
37
37
38
39
30
21
22
23
25
26
27
28
20 24
30
31
40
39
41
42
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH6151001 HANDLE KNOB 23 PH6151023 HEATER TRANSFORMER
2 PH6151002 PLATEN ARM 24 PH6151024 WIRE CONNECTOR
3 PH6151003 PLATEN SPRING 25 PH6151025 MICROSWITCH
4 PH6151004 PLATEN 26 PH6151026 SWITCH BRACKET
5 PH6151005 SILICON RUBBER STRIP 27 PH6151027 SWITCH INSULATION
6 PS01M PHLP HD SCR M4-.7 X 18 28 PH6151028 SWITCH LEVER SPRING
7 PH6151007 HINGE 30 PH6151030 HEATER TERMINAL ASSEMBLY
8 PH6151008 HINGE BRACKET 31 PH6151031 GROUNDING WIRE
9 PH6151009 SEALER BASE 32 PH6151032 COVER PLATE
10 PH6151010 METAL PLATE 35 PH6151035 RUBBER FOOT AND SCREW
11 PH6151011 LOWER TEFLON ELEMENT 36 PSS81M SET SCREW M3-.5 X 5
12 PH6151012 UPPER TEFLON CLOTH 37 PS12M PHLP HD SCR M3-.5 X 6
13 PH6151013 STRAIN RELIEF 38 PFH57M FLAT HD SCR M3-.5 X 8
14 PH6151014 POWER CORD 39 PS17M PHLP HD SCR M4-.7 X 6
15 PH6151015 HEATING ELEMENT 40 PS18M PHLP HD SCR M4-.7 X 25
16 PH6151016 PILOT LAMP 41 PS59M PHLP HD SCR M3-.5 X 14
17 PH6151017 TIMER KNOB 42 PS07M PHLP HD SCR M4-.7 X 8
18 PH6151018 CONTROL PANEL ASSEMBLY 43 PSB04M CAP SCREW M6-1 X 10
20 PH6151020 SWITCH LEVER 47 PLW09M LOCK WASHER 3MM
21 PH6151021 WIRE CONNECTOR 48* PTLW01M EXT TOOTH WASHER 4MM
22 PH6151022 INTERNAL WIRING
23
56
12
10
43
47 48*
* Part not shown in breakdown
H6151 Parts Breakdown & List
