Grizzly H6190 User manual

Introduction
This Air Screwdriver features 1,200 RPM free
speed, 3–16 in/lbs maximum torque, 90 PSI, 4
CFM average air consumption, 1⁄4" NPT air inlet
and includes two double ended No. 2 Phillips
head drivers and male quick connect fitting.
Inventory
A. Industrial Air Screwdriver ........................... 1
B. 1⁄4" NPT Air Fitting ....................................... 1
C. Phillips Head Drivers .................................. 2
Operation
Screw the 1⁄4" NPT Air Fitting on the air inlet of
the screwdriver. Pull the knurled collar back into
the screwdriver body and insert the Phillips head
driver into the socket. Twist the adjustment dial to
set the torque to your desired setting.
MODEL H6190
INDUSTRIAL AIR
SCREWDRIVER
INSTRUCTION SHEET
Figure 1. Model H6190.
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: [phone].
COPYRIGHT © MAY, 2006 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#PC8257 PRINTED IN TAIWAN
INJURY HAZARD!
Always disconnect tool from
air to prevent unexpected
operation during service!
EXPLOSION HAZARD!
Never exceed 90 PSI!
EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection during
use of this tool!
This Industrial Air Screwdriver MUST have 3-4
drops of oil directly dropped into the air fitting
before each use as shown in Figure 2.

H6190 Parts Breakdown and List
 
  








 






  













  

 

 



REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH6190001 HANGER 27 PH6190027 BEARING
2 PH6190002 INLET BUSHING 28 PH6190028 BEARING SPACER
4 PH6190004 THROTTLE SPRING 29 PH6190029 CLUTCH
5 PH6190005 VALVE BALL 30 PH6190030 CAM CLUTCH BALL
6 PH6190006 O-RING 31 PH6190031 BALL SEAT
7 PH6190007 EXAUST COVER 32 PH6190032 GEAR CASE
8 PH6190008 THROTTLE HANDLE 33 PH6190033 COMPRESSION SPRING
9 PH6190009 BARREL 34 PH6190034 SPRING RECEIVER
10 PH6190010 CHANGE VALVE BUSHING 35 PH6190035 CAM RIDER
11 PH6190011 CHANGE VALVE SPRING 36 PH6190036 PILOT SHAFT
12 PH6190012 CHANGE VALVE 37 PH6190037 COMPRESSION SPRING
13 PH6190013 PIN 38 PH6190038 COMPRESSION SPRING
14 PH6190014 BEARING 39 PH6190039 SPINDLE
15 PH6190015 PIN 40 PH6190040 CAM RIDER BALL
16 PH6190016 END PLATE 41 PH6190041 CAM RIDER BALL
17 PH6190017 CYLINDER 42 PH6190042 SPRING RECEIVER
18 PH6190018 ROTOR 43 PH6190043 CLUTCH COVER
19 PH6190019 ROTOR BLADE 44 PH6190044 PIN
20 PH6190020 END PLATE 45 PH6190045 ADJUSTABLE DIAL
21 PH6190021 BEARING 46 PH6190046 EXT RETAINING RING
23 PH6190023 INTERNAL GEAR 47 PH6190047 WASHER
24 PH6190024 FREE GEAR 48 PH6190048 COMPRESSION SPRING
25 PH6190025 GEAR FRAME 49 PH6190049 PIT STOPPER WASHER
26 PH6190026 GEAR FRAME 50 PH6190050 EXT RETAINING RING
