Grizzly H6191 User manual
Introduction
This Industrial Air Screwdriver features 8,500
RPM free speed, forward and reverse directions,
10–60 in/lbs adjustable torque, 90 PSI, 4 CFM
average air consumption, 1⁄4" NPT air inlet and
includes a single double ended No. 2 Phillips
head driver and male quick connect fitting.
Inventory
A. Industrial Air Screwdriver ........................... 1
B. 1⁄4" NPT Air Fitting ....................................... 1
C. Phillips Head Driver .................................... 1
D. Hanger ........................................................ 1
Operation
Screw the 1⁄4" NPT Air Fitting on the air inlet of the
screwdriver. Push the Phillips head driver into the
socket to lock in place. Twist the adjustment dial
to set the torque to your desired setting.
MODEL H6191
INDUSTRIAL AIR
SCREWDRIVER
INSTRUCTION SHEET
Figure 1. Model H6191.
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
COPYRIGHT © JULY, 2006 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#PC8462 PRINTED IN TAIWAN
INJURY HAZARD!
Always disconnect tool from
air to prevent unexpected
operation during service!
EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection during
use of this tool!
This Industrial Air Screwdriver MUST have 3-4
drops of oil directly dropped into the air fitting
before each use as shown in Figure 2.
DO NOT exceed 90 PSI air
pressure! Personal injury or
damage to tool could occur.
H6191 Parts Breakdown and List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH6191001 FRONT HOUSING 25 PH6191025 O-RING
2 PH6191002 BUSHING 26 PH6191026 VALVE STEM
3 PH6191003 STEEL BALL COLLAR 27 PH6191027 COMPRESSION SPRING
4 PH6191004 STEEL BALL 28 PH6191028 O-RING
5 PH6191005 ANVIL 29 PH6191029 PIN
6 PH6191006 THRUST WASHER 30 PH6191030 PIN
7 PH6191007 COLLAR 31 PH6191031 REVERSE VALVE
8 PH6191008 PIN 32 PH6191032 SWITCH LEVER
9 PH6191009 HAMMER DOG 33 PH6191033 PIN
10 PH6191010 HAMMER SEAT 34 PH6191034 SPRING
11 PH6191011 CAM 35 PH6191035 AIR REGULATOR
12 PH6191012 WASHER 36 PH6191036 SCREW
13 PH6191013 TOP ADJUSTER 37 PH6191037 WASHER
14 PH6191014 BALL BEARING 38 PH6191038 AIR INLET
15 PH6191015 FRONT PLATE 39 PH6191039 HOOK
16 PH6191016 ROTOR BLADE 40 PH6191040 RETAINER
17 PH6191017 ROTOR 41 PH6191041 WASHER
18 PH6191018 CYLINDER 42 PH6191042 BALL RETAINER
19 PH6191019 PIN 43 PH6191043 STEEL BALL
20 PH6191020 REAR END PLATE 44 PH6191044 COMPRESSION SPRING
21 PH6191021 BALL BEARING 45 PH6191045 RETAINER WASHER
22 PH6191022 HOUSING 46 PH6191046 1/4" NPT AIR FITTING*
23 PH6191023 O-RING 47 PH6191047 PHILLIPS HEAD DRIVER #2*
24 PH6191024 BUSHING * NOT SHOWN IN PARTS BREAKDOWN DRAWING
