Grizzly H0593 Quick start guide

H0593 Parts Breakdown and List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 PH0592002 AIR INLET 25 PH0592025 HOUSING BAND
3 PH0592003 VALVE BODY 26 PH0592026 MOTOR HOUSING
4 PH0592004 LEVER 27 PH0592027 BEARING
5 PH0592005 LEVER PIN 28 PH0592028 BEVEL GEAR
6 PH0592006 VALVE BUSHING 29 PH0592029 SPINDLE
7 PH0592007 VALVE STEM 30 PH0592030 WOODRUF KEY
8 PH0592008 O-RING 31 PH0592031 HOUSING CAP
9 PH0592009 VALVE SPRING 32 PH0592032 BEARING
10 PH0592010 AIR CONTROLLER 33 PH0592033 RETAINING RING
11 PH0592011 O-RING 35 PH0592035 HANDLE
12 PH0592012 VALVE SCREW 39 PH0592039 EXHAUST DEFLECTOR
13 PH0592013 GASKET 40 PH0592040 EXHAUST DEFLECTOR SCREW
15 PH0592015 BEARING 41 PH0592041 RETAINING RING
16 PH0592016 REAR END PLATE 42 PH0592042 WAVE WASHER
17 PH0592017 ROTOR BLADE 43 PH0592043 SPRING WASHER
18 PH0592018 ROTOR 44 PH0592044 SCREW
19 PH0592019 CYLINDER PIN 45 PH0592045 WAVE WASHER
20 PH0592020 CYLINDER 46 PH0592046 O-RING
21 PH0592021 FRONT END PLATE 47 PH0592047 LOCK NUT
22 PH0592022 BEARING 48 PH0592048 7" SANDING PAD
23 PH0592023 BEARING 49 PH0592049 PIN-TYPE SPANNER WRENCH
24 PH0592024 PINION 50 PH0592050 FLAT WRENCH 19MM
