Grizzly H0584 Quick start guide

H0584 Parts Breakdown and List









 






  


 







 






REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH0584001 THROTTLE LEVER 22 PH0584022 CYLINDER PIN
2 PRP73M ROLL PIN 4 X 30 23 PH0584023 CYLINDER O-RING
3 PH0584003 VALVE PIN 24 PH0584024 CYLINDER
4 PH0584004 VALVE BODY 25 PH0584025 CYLINDER PIN
5 PH0584005 O-RING 26 PH0584026 REAR PLATE
6 PH0584006 THROTTLE VALVE 27 P6200 BALL BEARING 6200ZZ
7 PH0584007 VALVE SPRING 28 PH0584028 MOTOR GASKET
8 PH0584008 MOTOR HOUSING 29 PH0584029 PAD COVER
9 PR36M EXT RETAINING RING 7MM 30 PSB23M CAP SCREW M4-.7 X 12
10 PH0584010 O-RING 31 PH0584031 COTTON RING
11 PH0584011 REGULATOR 32 PH0584032 CRANK SHAFT
14 PH0584014 AIR ADAPTOR 33 PH0584033 KEY
14-1 PH0584014-1 PLASTIC HOSE 34 PH0584034 SCREW
14-2 PH0584014-2 DUST BAG 35 PH0584035 LOWER WEIGHT
15 PSB50M CAP SCREW M5-.8 X 10 36 P6202 BALL BEARING 6202ZZ
17 P6200 BALL BEARING 6200ZZ 37 PH0584037 SPECIAL WRENCH
18 PH0584018 FRONT PLATE 38 PH0584038 RANDOM SHAFT
19 PH0584019 ROTOR 39 PR29M INT RETAINING RING 32MM
20 PH0584020 VANE SPRING 40 PH0584040 SANDING PAD
21 PH0584021 VANE
