Grizzly G0478 Quick start guide

G0478 10" Hybrid Table Saw -49-



 

































 
 




  










 


















 

 
Parts Breakdown

-50- G0478 10" Hybrid Table Saw






 






 
































  
 


Parts Breakdown

G0478 10" Hybrid Table Saw -51-
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.
Safety Labels
115
116
117
118
119
120
121
122

-52- G0478 10" Hybrid Table Saw
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0478001 CABINET 35 P0478035 MOTOR
2 P0478002 PLASTIC FOOT 35-1 P0478035-1 MOTOR FAN COVER
3 P0478003 MOTOR COVER 35-2 P0478035-2 MOTOR FAN
4 P0478004 DOOR RELEASE LEVER 35-3 P0478035-3 CAPACITOR COVER
5 P0478005 THREADED ROD M6-1 35-4 PC30 CAPACITOR 30M 250V
6 P0478006 RUBBER BUSHING 35-5 PC400D CAPACITOR 400M 125VAC
7 P0478007 BRACKET 35-6 P0478035-6 WIRING BOX
8 P0478008 HANDWHEEL 36 P0478036 BLADE GUARD
9 P0478009 HANDLE 3/8 X 110MM 37 P0478037 TORSION SPRING
10 P0478010 LOCK KNOB 1/2-12 38 P0478038 SUPPORT ARM
11 P0478011 TILT LEADSCREW NUT 39 P0478039 SPLITTER
12 P0478012 LONG SHAFT 40 P0478040 ANTI-KICK PLATE
13 P0478013 POINTER BRACKET 41 P0478041 SPLITTER BRACKET
14 P0478014 ELEVATION LEADSCREW 42 P0478042 SPLITTER ROD
15 P0478015 SLEEVE 43 P0478043 MITER GAUGE HANDLE
16 PW03 FLAT WASHER #10 44 P0478044 MITER GAUGE BODY
17 P0478017 POINTER 45 P0478045 POINTER
18 P0478018 LOCK SLEEVE 46 P0478046 LOCATING PLATE
19 P0478019 LOCK ROD 47 P0478047 MITER BAR
20 PN07 HEX NUT 10-24 48 P0478048 SPECIAL WASHER 1/4
21 P0478021 LOCK HANDLE 49 P0478049 SOLID EXTENSION WING
22 P0478022 DUST COLLECTING PLATE 50 P0478050 TABLE INSERT
23 P0478023 ARBOR FLANGE 51 P0478051 TABLE
25 P0478025 MOTOR PLATE 52 P0478052 SWITCH BRACKET
26 P0478026 ARBOR BRACKET SHAFT 53 P0478053 MAGNETIC SWITCH 110V
27 P0478027 MAIN ARBOR 53A P0478053A MAGNETIC SWITCH 220V
28 P0478028 FR TRUNNION BRACKET 53-1 P0478053-1 CONTACTOR 110V
29 P0478029 MAIN TRUNNION 53-2 P0478053-2 RELAY 110V
30 P0478030 BELT 150J X 12 53-3 P0478053-3 FRONT COVER
31 P0478031 ARBOR PULLEY 53-4 P0478053-4 STOP BUTTON
32 P0478032 MOTOR PULLEY 53-5 P0478053-5 START BUTTON
33 P0478033 ARBOR BRACKET 53-6 P0478053-6 BACK COVER
34 P0478034 UPPER STOP 54 P0478054 CORD SLEEVE
Parts List

G0478 10" Hybrid Table Saw -53-
REF PART # DESCRIPTION REF PART # DESCRIPTION
56 PWRCRD110S POWER CORD 110V, SHORT 89 P0478089 NYLON NUT 5/8-11
57 PRP64M ROLL PIN 3 X 18 90 PW07 FLAT WASHER 5/16
58 PW06 FLAT WASHER 1/4 91 P0478091 SHORT PIN 6 X 33
59 P0478059 NYLON NUT M6-1 92 P0478092 LONG PIN 6 X 47
60 P0478060 STRAIN RELIEF 93 P0478093 RETAINER
61 PS79 PHLP HD SCR 5/16-18 X 5/8 94 P0478094 SPACER
62 PW08 FLAT WASHER #8 95 PSB03 CAP SCREW 5/16-18 X 1
63 PS24 PHLP HD SCR 8-32 X 3/8 96 PRP07M ROLL PIN 6 X 20
64 PB32 HEX BOLT 5/16-18 X 5/8 97 PW01 FLAT WASHER 1/2
65 PTLW07M EXT TOOTH WASHER 8MM 98 PN13 HEX NUT 1/2-13
66 PS04 PHLP HD SCR 1/4-20 X 1/2 99 PN02 HEX NUT 5/16-18
67 P0478067 FLANGE NUT TW 5/8-12 100 PN14 HEX NUT 8-32
68 PFS13M FLANGE SCR 10-24 X 9/16 101 PS17 PHLP HD SCR 8-32 X 1/2
69 PK14M KEY 5 X 5 X 18 102 PSS11 SET SCREW 1/4-20 X 1/4
70 P0478070 SPECIAL BOLT 1/4-20 X 40 103 PRP14M ROLL PIN 3 X 6
71 P0478071 COMPRESSION SPRING 104 PFH19 FLAT HD SCR 1/4-20 X 3/8
72 PW07 FLAT WASHER 5/16 105 PSS46 SET SCREW 10-24 X 3/16
73 PB03 HEX BOLT 5/16-18 X 1 106 PFH21 FLAT HD SCR 10-24 X 3/4
74 PLW01 LOCK WASHER 5/16 107 PSS38 SET SCREW 5/16-18 X 5/8
75 PR01M EXT RETAINING RING 10MM 109 PSB03 CAP SCREW 5/16-18 X 1
76 P0478076 COMPRESSION SPRING 110 PB90 HEX BOLT 7/16-14 X 1-1/4
77 PW10M FLAT WASHER 14MM 111 PLW05 LOCK WASHER 7/16
78 PRP28M ROLL PIN 5 X 40 113 P0478113 DADO INSERT
79 PS04 PHLP HD SCR 1/4-20 X 1/2 114 P0478114 ARBOR WRENCH 12 X 23
80 PR06M EXT RETAINING RING 16MM 115 PLABEL-40 BLADE GUARD LABEL
81 P0478081 WAVY WASHER 16MM 116 PLABEL-14 ELECTRICITY LABEL
82 PR06M EXT RETAINING RING 16MM 117 PLABEL-39 RESPIRATOR LABEL
83 PN02 HEX NUT 5/16-18 118 PLABEL-33 UNPLUG TABLE SAW LABEL
84 PB04 HEX BOLT 5/16-18 X 3 119 P0478119 MODEL NUMBER LABEL
85 PSS11 SET SCREW 1/4-20 X 1/4 120 P0478120 MACHINE ID LABEL
86 P6202 BALL BEARING 6202 121 PLABEL-12 READ MANUAL 2"W X 3 5/16"
87 PR05M EXT RETAINING RING 15MM 122 PLABEL-11 SAFETY GLASSES 2" X 3 5/16"
88 PW14 FLAT WASHER 5/8
Parts List
