Grohe Axor 17010XX1 User manual

Axor Carlton
17010XX1
Installation Instructions / Warranty

2
Technical Specification
Hole size in mounting surface
Minimum 1-3/8” Maximum 1-5/8”
Maximum mounting surface depth 1-1/4”
Flow rate 2.2 GPM
Maximum operating pressure 145 PSI
Recommended operating pressure 22 - 72.5 PSI
Recommended hot water temp 120o- 140oF*
M3 cartridge with BolticTM handle screw
*Some governing bodies require that the water heater be set to 120o F or
less. Please know and follow all local codes when setting the temperature
on the water heater.
Installation Considerations
•For best results, Hansgrohe recommends installation by a licensed professional plumber.
•Large differences in pressure between the hot and cold supplies should be balanced.
•The supply hoses on this faucet require supply stops with 3/8” compression fittings (not included).
•This faucet has a high temperature limit stop. It ships from the factory on the maximum setting, but may
be reset to a lower temperature if desired.
Axor Carlton Single Control Lavatory Faucet
17010XX1

3
Install the faucet
Place the faucet and sealing ring on top of the
mounting surface.
Install the mounting flange over the stud. Thread
the collar onto the stud until the mounting flange is
firmly against the bottom of the mounting surface.
mounting
flange
stud
collar
sealing ring
Secure the supply lines to the stop valves with
the 3/8” compression fittings (not included).
Use two wrenches to insure that supply hoses
do not twist.
For proper operation of the faucet, hot
should be on the left, and cold should be on
the right.
Install the drain.
Re-set the high temperature limit stop (if desired). Install the handle.
Turn on the water and check for leaks at all connections.

4
Install the pop-up drain
Remove the plunger assembly.
Unscrew the drain outlet flange from the tee.
Unscrew the tailpiece from the tee. Wrap
the threads with two layers of Teflon tape
and replace.
Install the white, flexible sealing gasket to the
flange. Place it in the sink outlet.
From under the sink, install the black mack
gasket, white friction ring and retainer nut
to the flange. Do not tighten the nut against
the bottom of the sink at this time.
Thread the tee and tailpiece to the flange.
The pivot must face the faucet. If necessary,
turn the drain assembly.
Tighten the retainer nut.
Place the plunger assembly in the drain.
Install the horizontal rod so that the end goes
through the loop in the bottom of the height
adjuster.
Install and hand tighten the pivot ball nut.
Attach the swivel connector to the end of the
horizontal rod.
Attach the swivel connector to the end of the
vertical rod. Position as desired and tighten
with a small, flathead screwdriver.
plunger
flange
sealing gasket
mack gasket
friction ring
retainer nut
horizontal rod
height adjuster
pivot ball nut
swivel connector
vertical rod
tee
tailpiece

5
Re-set the High Temperature Limit Stop (optional)
Close the drain OR cover it with a wash cloth.
Use a 4 mm Allen wrench to push the screw cover
into the handle. Retrieve the screw cover when
the handle is removed.
Use the 4mm Allen wrench to loosen the handle
screw 4 complete revolutions. Remove the handle
and put it in a safe place.
Replace the high temperature limit stop so
that the pin on the cartridge is in the desired
slot on the limit stop. Note: the temperatures
given in the diagram assume a water
heater temperature of 140oF, a cold water
temperature of 50oF and a water pressure of
45 PSI.
Remove the decorative nut cover and put it in a
safe place.
Remove the handle screw from the stem of the
cartridge. Remove the high temperature limit stop.
Replace the decorative nut cover. Replace the handle screw. Use the Allen wrench to turn the
screw 4 revolutions.
Replace the handle. Finish tightening the handle screw. Turn on the water and test the faucet.

6
User Instructions
•Push the handle up to turn the water on.
•Pivot the handle to the left for hotter water, to the right for cooler water.
•Push the handle down to turn the water off.
Replacement Parts
Troubleshooting

7
Cleaning Recommendation for Hansgrohe Products
Modern sanitary faucetry and shower fixtures consist of very different materials to comply with the needs of the market with
regard to design and functionality.
To avoid damage and returns, it is necessary to consider certain points when cleaning:
Cleaning materials for faucets and shower products:
Acids are necessary ingredients of cleaning materials for removing lime. However, please pay attention to the following points
when cleaning faucets and shower products:
•Use only cleaning materials intended for the application.
•Never use cleaning materials which contain hydrochloric, formic, or phosphoric, or acetic acid, as these can cause
considerable damage.
•Do not mix one cleaning material with another.
•Do not use abrasives, such as cleaning powders, sponge pads, or microfiber cloths.
Cleaning Instructions for Faucets and Shower Products:
Please follow the cleaning material manufacturer’s instructions. In addition, please note the following:
•Clean your faucets and shower products as and when required.
•Follow the label instructions. Do not allow any cleaner to remain on the product for longer than necessary.
•Regular cleaning will prevent scale buildup and water spotting.
•When using spray cleaners, spray first onto a sponge or cloth. Do not spray directly onto the faucet or shower product
as drops could enter openings or gaps and cause damage.
•After cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
Residues of liquid soaps, shampoos, and shower foams can also cause damage, so rinse with clean water after using.
Please note:
•If the surface is already damaged, the effect of cleaning materials will cause further damage.
•Components with damaged surfaces must be replaced, otherwise, this could cause injury.
•Damage caused by improper treatment will not be covered by our warranty.
