Axor Citterio M
Lav Mixer 34010XX1
Small Lav Mixer 34016XX1
Lav Mixer less Drain 34017XX1
Tall Lav Mixer 34120XX1
Tall Lav Mixer less Drain 34127XX1
Bidet Mixer 34210XX1

3
Installation Considerations
For best results, Hansgrohe recom-
mends that this unit be installed by
a licensed, professional plumber.
Please read over these instructions
thoroughly before beginning instal-
lation. Make sure that you have
all tools and supplies needed to
complete the installation.
This faucet can be used with a
continuous flow water heater if the
flow pressure is at least 20 psi.
•
•
•
Technical Information
Recommended water pressure 14.7 - 72.5 psi
Max. water pressure 145 psi
Recommended hot water temp. 120� - 140� F*
Max. hot water temp 165�F*
Hole size in mounting surface 1 3/8"
Max. mounting surface depth 1 5/8"
Flow rate 2.2 gpm
Cartridge with high temperature limit stop
3/8" supply hoses - requires 3/8" compression fitting
(not included)
*Please know and follow all applicable local plumbing codes when setting
the temperature on the water heater.
34120XX1 34127XX1

4
Installation
Install the drain pull rod*.
Position the faucet and sealing gasket on the mounting
surface.
Install the fiber washer, friction washer, and mounting
nut.
Tighten the mounting nut by hand.
Tighten the tensioning screws.
*Drain and pull rod not included with models
34017XX1 or 34027XX1.

5
Connect the hot and cold supply hoses to the stops with
3/8" compression fittings (not included).
Use two wrenches, as shown, to prevent the hoses from
twisting.
Set the high temperature limit stop, if desired.
Install the pop-up drain.
Set the High Temperature Limit Stop (optional)
Use a 3 mm Allen wrench to push the screw cover
through the handle.
Use the Allen wrench to loosen the handle screw 2
complete revolutions.
Remove the handle.
Retrieve the screw cover.
Remove the flange.
Remove the high temperature limit stop.
Replace the high temperature limit stop so that the pin on
the cartridge is in the desired slot on the limit stop.
3 mm
2 x
