GROUND EFX Stryker Lite MX300 User manual

Model # MX300
DIGITAL METAL
DETECTOR
602 Fountain Parkway
Grand Prairie, TX 75050
800.847.8269
“Ground EFX”and“Stryker Lite”are TM trademarks of WGI Innovations, LTD.
“Sport Responsible” is a TM trademark of WGI Innovations, LTD. User’s Manual

2
Table of Contents
Terms …………………………………… 3-4
Contents …………………………….… 5-6
Assembly ……………………………… 7-10
LCD Navigation Display ………………… 11
CategoryValue……………………………12
How it Works ………………………… 13-16
Detector Modes ……………………… 17-18
HowtoDetect…………………………19-20
GPS ………………………………… . . . 21-22
Warning ………………………………… 23
Courtesy ………………………………… 24
AudioFeatures……………………………25
ToneRecognition…………………………26
TroubleShooting…………………………27
Warranty/Services ……………………… 28
FCCStatement……………………………29

3 4
TERMS TO KNOW
The terms below are standard words found within this manual and the
detector.
DISCRIMINATION
Discriminating allows you to choose the metals you want to detect and
the ones you want to “eliminate” or not look for. Discrimination makes it
easier to avoid trash or other undesirable objects. Once it detects a metal
it will categorize it to one of the metals you chose to detect for.
IRON
Iron is the most common metal used. It has been used since ancient times
because of how abundant it is. Ferrous metals are made up of iron. Ob-
jects that are ferrous metals are; nails, bolts, stainless steel and cast iron.
PINPOINT
A narrow detection that tells you the exact location of the object that
is buried.
PULL-TABS
Also known as “pop tops.” Discarded pull-tabs come from beverage cans.
They can be all dierent shapes and sizes. They are primarily made of alu-
minum, which can be bothersome to many treasure hunters.
GROUND GRAB
All soils contain minerals. Signals from ground minerals interfere with the
signals from metal objects. If metal is detected in this mode it will make
a sound. It doesn’t detect any of earth’s natural minerals so you can get a
more accurate reading on what you nd.
TWO DIGIT IDENTIFIER
The two digit number identies the buried obect with a specic number
to give you a more accurate idea of what you have found. With each pass
over the object, the distance between the object and the coil, and the
angle of the coil can change the two digit number.

5 6
CONTENTS
Coil
Bracket
Bottom Rod
Lock Bracket
Top Rod
Battery
Compartment
LCD Display
Handle
Unit
Arm cu
with strap
Stand
Wire
Headphone Jack
Pinpoint
Trigger

Connect The Rods
Connect the Top Rod to the Bottom Rod
by sliding the Top Rod with the Locking
Bracket end down. Note: The groove on the
Top Rod needs to face away from you. Align
grooves to one another to ensure rods stay
in place.
Slide the Top Rod to the desired length and
tighten the Locking Bracket by turning it to the Left.
1
2
7 8
ASSEMBLY
Assembling the coil unit
Unscrew the bracket from the bottom rod.
Fit the bottom rod inside the coil and re-
place the bracket. Then tighten but do not
over tighten. NOTE: The large hole faces
down. This is where the cable will enter the
rod.
Connecting the Wiring
Take the Cable Pull and
place it down the Rods.
Screw the end of the Cable
Pull to the end of the wire.
Place the connector in the
opening. Then pull the
hoop at the top to pull the
cable through the rods.
Connecting the Handle Unit
Disconnect the Cable Pull and connect the
wire head to the handles cable. Be careful
to align the white indicator arrow on the
wire head with the alignment arrow on the
handle units cable head to ensure proper
connection.
NOTE: Screw the silver piece to ensure the
cable is locked in place.
3
4

9 10
ASSEMBLY
After the wire is locked in place, check
the handle unit to ensure the latch is in
unlocked. Then place the rod all the way
back into the handle unit and pull the
latch to lock the rod into place. Make
sure everything is secured into place
before use.
Batteries
1
To open the Battery Compartment
door, unscrew the the two screws. Pull
the door towards you and up to take the
door o.
Insert 6 AA batteries according to the
markings within the compartment. Cau-
tion: Never mix old and new batteries. Nev-
er mix alkaline, carbon-zinc or recharge-
able batteries.
2
++
++
++
-
--
--
-
Place the battery compartment back and
screw in the screws.
3
5
Adjusting the display
To adjust the display, tilt the display for-
ward or back to your desired placement.
It should stay throughout use. The dis-
play may need additional adjustment in
very bright or very dark environments.

11 12
LCD NAVIGATION DISPLAY CATEGORY VALUE
The Category Value accurately provides specic categories to help identify a
buried object. Coins will most likely have a similar value with each pass with the
coil due to their round shape. Gold and silver can actually be detected in various
category values due to their metallic qualities. Smaller gold or silver objects will
have a dierent value than larger gold or silver objects. Trash objects can give
o a dierent value each time you pass over it. The angle of the detector can
aect the identication of an object as well. If you decide to test the detector
by waving a coin over the coil, wave it with the at side parallel to the coil; this
position is how you will nd most buried coins.
4
10-39
40-54
55-59
60-64
65-74
75-79
80-84
85-99

13 14
HOW IT WORKS
LEFT ARROW Button
DOWN ARROW Button
POWER Button
RIGHT ARROW
Button
UP ARROW Button
Ground Grab
- Press to enter“Ground Grab” Mode
Discrimination
- Press to enter“Discrimination” Mode
- Press to eliminate metal starting
from left to right 10-99
- Press or wait for 2-3 seconds to detect in
current settings
(This mode uses your last Settings to detect)
Pin Point
- Hold the trigger down to enter“Pin Point”
Mode
Settings
- Press“VOL” to change volume setting
- Press while Volume is selected to
change Volume
- To save changes wait for 2-3 sec or press
the button
- Press“SENS” to change Sensitivity setting
- While Sensitivity is selected press
to change Sensitivity
- To save changes wait for 2-3 sec or press
the button
SAVE and
ENTER Button
DELETE Button
GPS Button
GROUND
GRAB
Button
DISCRIMINATION
Button
NOTCH Button
LIGHT Button
SENSITIVITY
Button
VOLUME Button
COIN Mode Button
JEWELRY
Mode Button
ALL METAL
Mode Button
CUSTOM
Mode Button’s
PINPOINT
Trigger

GPS: SAVE - WAYPOINT
- Press to enter“GPS”Mode which defaults to the Save/Waypoint List
- Press to move Up and Down the Save/Waypoint List
SAVE: Press on Save
Press to move between letters
Press to change selected letter
Press to Save and you will see on the display “Save Ok” and then
returned to Save/Waypoint options or press to cancel the current
settings and return the Save options
You will then be returned to Save/Waypoint options
Waypoint: Press on a saved Location to activate GPS function
Press to the saved waypoint you would like to go to
On selected waypoint press and it will show you the Yard metter
that tells you how far it is to the desired location
To delete a waypoint press, hold down the button for 3 seconds to
Delete selected location
Press to switch to another Waypoint
- Press the button to exit out of the“GPS”Mode or press the “POWER” button to turn it
o.
15 16
HOW IT WORKS
Notch Settings
- Press to enter custom mode to detect the metal of your choosing
*It will be set to whatever was selected last
- Press to detect all metals
- Press to detect only those metals found in jewelry
- Press to detect only those metals found in coins
- Press to deselect certain metals to customize detecting
- To save changes wait for 2-3 sec or press the button
LED Light
- Press to turn the light on.
- Press again to turn the light o.

17 18
DETECTOR MODES
Ground Grab
All soils contain minerals. Signals from ground minerals interfere with the signals from
metal objects. All soils dier, and can dier greatly, in the type and amount of ground
minerals present. This detector incorporates ground balancing algorithms which elimi-
nate interference caused by the ground minerals found in most soils. We therefore rec-
ommend that you use GROUND GRAB to most accurately calibrate the detector to the
specic ground conditions where you are hunting.
This process will maximize the detector’s target identication accuracy and depth detec-
tion capability.
The Steps is as follows:
1. Find a patch of ground which is free of metal. Use the DISCRIMINATION mode, with no targets discriminated out.
2. Hold the detector with the search coil about 6 inches above the ground ,then press G Grab button to activate ground
grab process, then lower the coil down to within 2 inches o the ground.
3. Repeat to lift up and lower down the search coil for several times until the LCD shows“GRAB OK”.
If‘GRAB ER’appears, maybe the ground is too dirty with metal trash or just wet salt soil. Find another clean place ground
grab again till it is grab ok. Ground grab results is crucial to the performance of PP mode.
Discrimination
Pick the discrimination mode you want to detect in. Keep the coil parallel to the ground
moving it from left to right with a stable speed. Out of the metals highlighted it will cat-
egorize the metal detected so you are aware of what metal is buried. It will inform you
in two ways; 1. by highlighting the metal detected and 2. a tone response.
Discrimination identication accuracy can be inuenced by moisture and temperature.
The coil sweeping speed can also aect discrimination, generally faster sweeping mo-
tion has a higher sensitivity.
Pinpointing
Pinpoint does a narrow search that will give you the exact location of a buried object. It will identify an object by a signal
and tone response. Hold the trigger to activate the pinpoint function. Once activated, sweep the coil over the target
area in an “X” pattern. Make a visual note of the place on the ground where the strongest signal is identied. Then dig
in the center of the“X.” When the trigger is released the metal detector will return back to
the previous mode. NOTE: Normally,the detector takes about 5 minutes to stabilize after it
powers on, it is not recommended to do pinpointing during this period of time. The sensi-
tivity of detector will drift over time. If sensitivity drifts upward,the detector will sound o
spontaneously. If sensitivity drifts downward,the detector will become less sensitive. Drift
is exacerbated by the environment condition change especially the temperature change.
so, in case the sensitivity drifts , you can try Ground Grab again.
Notch Modes
When in Notch there are four options:
All Metals: Use this mode if you are looking for a wide range of objects. It is designed to
nd all metal objects.
Coin: When using this mode it will show you the metals found in coins. It is designed to nd
all types of coins and eliminate trash objects such as iron and foil.
Jewelry: When in this mode it will show you the metals common in jewelry. It is designed
to nd jewelry such as rings, bracelets, watches and necklaces.
Custom: Use this mode if you want to choose the specic metals to search for . It is designed
for you to nd certain metal objects that you programmed it to.
When an object is detected it will highlight the name of the metal found as well as use a tone
that identies the metal.
GPS
The GPS mode allows you to save certain locations that you are wanting to return to later. The
farthest it will read you from your saved location is 999 yds. The closer you get to the saved spot
the lower the number will go, 000 yds means you’ve reached your spot. NOTE:While in use, please
keep the control box away from metal objects or magnetic materials because those objects aect
the accuracy of its internal compass.

19 20
HOW TO DETECT
Power ON by pushing the “POWER” button.
Touch “SENS” or “ VO L” button to change the Sensitivity and Vol-
ume (default is 6/4). Press “ENTER” to save the changes made.
You can touch either “ALL METAL”, “JEWELRY”, “COIN”, “NOTCH”
or “DISCRIM” to enter into corresponding mode.
Press the “G GRAB” button to activate Ground Grab Mode. Dis-
play will show“Grab ok”when ground grab is completed. If“Grab
ER” shows, there may be a metal object underground, nd an-
other clean area nearby to retry ground grab.
While in Discrimination Mode keep the coil
parallel to the ground moving it from left to
right with a stable speed. If it nds some-
thing it will highlight the metal found and
give o a certain tone (refer to page 27).
When a metal is detected hold the trigger
to activate Pinpoint function. Sweep the coil
over the target in an “X” pattern. While in Pin-
Point it will show you the depth of the metal
found. So you can accurately know how far
down to dig.
Dig object out.
Once the object is found, ll the hole back up to the way you
found it.

21 22
GPS
To save a location press the “GPS” button.
The option Save should be on the display,
push“ENTER”. Use the arrow keys to change
or add letters to name the location. Press
the “ENTER” button to save.
To go back to a saved location press the
“GPS” button to enter GPS mode. Scroll
down to Waypoint and then push the left
or right button to scroll through saved loca-
tions. When you nd the location you want
press the “ENTER” button.
The GPS will show you which direction to go
and how many yards to the location.
The arrow and yards will change the closer
or further away you get to the location.
Once you have found the spot, the yards will
read 000 and the arrow will be gone.

23 24
WARNING
All metal detector’s may discover objects that can cause personal injury if
struck. For example; power lines, explosives, gas lines, etc. When search-
ing for treasure, rst observe these precautions:
Do not use detector where you think there might be electrical lines or
pipes buried below the surface.
Do not use detector in a military area where bombs or other explosives
were once buried.
Avoid striking any lines that are or could be electrically powered.
Keep away from pipelines they could be carrying ammable gas or liquid.
1
If you find that the compass is not so ac-
curate, or sometimes direct the wrong
way, please rotate it 3-5 circles like this:
NOTE: Keep the LCD Display horizontal.
TIPS
2
In order to get the maximum accuracy of the compass, we suggest
rotating it 3-5 times in a circle to calibrate at the beginning of the
GPS mode when you change to a new environment.

25 26
AUDIO FEATURES
Headphone Jack
Use for less disturbance
to others around you
as well as to drown out
distractions so you can
hear the tones better.
• Fill holes
• Obey NO TRESPASSING signs
• Respect private and public property
• Obey all laws
• Do not cause any willful damage to property
• Do not destroy property
• Pick up after yourself, do not leave trash
COURTESY

27 28
TROUBLESHOOTING
PROBLEM SOLUTION
Won’t turn ON,
there is no sound
Check to ensure that you are using
new batteries.
Check to see if the batteries were
placed in the correct positions.
Check the connection of the wire
from the rod to the handle unit.
Abnormal/erratic
Sounds
Outdoor use only.
Stay away from power lines, benches,
wire fences and other metal detectors
that can cause false readings.
Reduce the sensitivity level.
Abnormal/erratic
Sounds
Check that the Mode you wanted is
selected.
The All-metals mode allows you to
search for all metals so you will not
miss the one you are looking for.
TONE RECOGNITION
There are eight tones indicatng 8 dierent metals (iron, foil, nickel, P-Tab,
S-Cap, Zinc, Dime and Quarter)that will help you to identify the material
the detector has found

29 30
FCC STATEMENT
Product Name: Metal Detector
Trade Name: Ground EFX
Model# MX300
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
criteria: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
Warning: Changes or modications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment o and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
DISCLAIMERS
WGI Innovations, LTD. is not responsible for damage, expense or injury caused by the unauthorized use of,
alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products.
WARRANTY
For the warranty to be in eect, you MUST completely ll out and mail the warranty card along with your
proof of purchase toWGI Innovations within (14) days after the date of purchase. As an alternative to mail, you
may also visit our website and register your product at www.groundefx.com (you are still required to mailWGI
Innovations your proof of purchase before the warranty is placed in eect.) Follow the onscreen directions to
complete the process.
WGI Innovations, LTD will replace all workmanship defects free of charge for ONE (1) YEAR after the date of
purchase as long as your warranty is in eect.
This warranty DOES NOT COVER damage, expense or injury caused by unauthorized repairs, alterations, im-
proper connection, shipping, abuse, theft, accident, neglect or collateral loss.
When returning product(s) for service you MUST obtain a Return Merchandise Authorization (RMA) number
from WGI Innovations, LTD. Please include name, UPS address (No P.O. Box), telephone number, RMA number
and a complete description of the problem on all enclosed correspondence. When possible, pack product
carefully in original carton. Customers are responsible for any shipping cost to WGI Innovations. WGI Innova-
tions will pay the shipping cost of replacement product to the customer. We are not responsible for damage
incurred in returning items for repair.
For product service send to:
WGI Innovations
602 Fountain Parkway
Grand Prairie, TX 75050
[phone]
Thank you for your purchase!
CUSTOMER SERVICE
WGI Innovations, LTD. stands behind every product we manufacture for a one year product workmanship
warranty and a strong commitment to customer service. If you are in need of customer service for missing
parts or need assistance with the operation or assembly of your product, we encourage you to call one of our
customer service representatives and let us assist you with your WGI Innovations product.
DISCLAIMER
WGI Innovations, LTD. reserves the right to make changes to product features, functionality and physical de-
sign at its sole discretion. As a result, such changes may not be reected in this version of the manual.
