Grundfos 1000 Series User manual

GRUNDFOS INSTRUCTIONS
NBE, NBSE, NKE, TPE, TPED
Series 2000 and 1000
Installation and operating instructions

Table of contents
2
NBE, NBSE, NKE, TPE, TPED
English (US)
Installation and operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Français (CA)
Notice d'installation et de fonctionnement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Español (MX)
Instrucciones de instalación y operación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Annexe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Anexo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

3
English (US)
English (US) Installation and operating instructions
Original installation and operating instructions
CONTENTS
Page
1. Limited warranty 4
2. General information 4
2.1 Symbols used in this document 4
2.2 Other important notes 4
2.3 Abbreviations and definitions 5
2.4 Radio communication 5
2.5 Battery 5
3. Receiving the product 5
3.1 Transporting the product 5
3.2 Inspecting the product 5
4. Mechanical installation 5
4.1 Handling the product 5
4.2 Mounting the product 6
4.3 Cable entries 6
4.4 Ensuring motor cooling 6
4.5 Outdoor installation 6
4.6 Drain holes 6
5. Electrical installation 6
5.1 Protection against electric shock, indirect contact 7
5.2 Cable requirements 7
5.3 Mains supply 7
5.4 Additional protection 8
5.5 Connection terminals 9
5.6 Signal cables 11
5.7 Bus connection cable 11
6. Operating conditions 12
6.1 Maximum number of starts and stops 12
6.2 Alternating operation of twin-head pumps 12
6.3 Ambient temperature 12
6.4 Installation altitude 12
6.5 Humidity 13
6.6 Motor cooling 13
7. User interfaces 13
8. Standard control panel 13
8.1 Setpoint setting 14
9. Advanced control panel 15
9.1 Home display 16
9.2 Startup guide 16
9.3 Menu overview for advanced control panel 17
10. Grundfos GO 20
10.1 Communication 20
10.2 Menu overview for Grundfos GO 21
11. Description of functions 24
11.1 Setpoint 24
11.2 Operating mode 24
11.3 Set manual speed 24
11.4 "Set user-defined speed" 24
11.5 "Control mode" 24
11.6 "Proportional-pressure setup" 28
11.7 Analog inputs 29
11.8 Built-in Grundfos sensor 30
11.9 Pt100/1000 inputs 30
11.10 Digital inputs 31
11.11 Digital inputs/outputs 32
11.12 "Signal relays 1 and 2" (Relay outputs)33
11.13 Analog output 33
11.14 "Controller" ("Controller settings") 34
11.15 Operating range 36
11.16 External setpoint function 36
11.17 Limit-exceeded function 38
11.18 "Pulse flowmeter setup" 39
11.19 "Ramps" 39
11.20 "Standstill heating" 39
11.21 Motor bearing monitoring 40
11.22 "Service" 40
11.23 "Number" (Pump number)40
11.24 "Radio communication" (Enable/disable radio comm.) 40
11.25 Language 40
11.26 "Date and time" (Set date and time)40
11.27 "Unit configuration" (Units)40
11.28 "Buttons on product" (Enable/disable settings)41
11.29 Delete history 41
11.30 Define Home display 41
11.31 Display settings 41
11.32 "Store settings" (Store actual settings)41
11.33 "Recall settings" (Recall stored settings)41
11.34 "Undo" 41
11.35 "Pump name" 41
11.36 "Connection code" 42
11.37 Run start-up guide 42
11.38 Alarm log 42
11.39 Warning log 42
11.40 Assist 42
11.41 Assisted pump setup 43
11.42 Setup, analog input 43
11.43 "Multipump setup" (Setup of multi-pump system)43
11.44 Description of control mode 46
11.45 Assisted fault advice 46
12. Selection of control mode 47
13. Bus signal 48
14. Priority of settings 49
15. Grundfos Eye 50
16. Signal relays 51
17. Installing a communication interface module 52
18. Identification of functional module 53
19. Identification of control panel 54
20. Changing the position of the control panel 54
21. Servicing the product 55
21.1 Motor 55
21.2 Pump 55
22. Cleaning the product 55
23. Megging 55
24. Technical data, single-phase motors 56
24.1 Supply voltage 56
24.2 Leakage current 56
25. Technical data, three-phase motors 56
25.1 Supply voltage 56
25.2 Leakage current, AC 56
26. Inputs and outputs 57
27. Other technical data 58
27.1 Torques 58
27.2 Sound pressure level 59
28. Factory settings 60
29. Disposing of the product 60
Read this document before installing the product.
Installation and operation must comply with local
regulations and accepted codes of good practice.

English (US)
4
1. Limited warranty
Products manufactured by Grundfos Pumps Corporation
(Grundfos) are warranted to the original user only to be free of
defects in material and workmanship for a period of 24 months
from date of installation, but not more than 30 months from date
of manufacture. Grundfos' liability under this warranty shall be
limited to repairing or replacing at Grundfos' option, without
charge, F.O.B. Grundfos' factory or authorized service station,
any product of Grundfos manufacture. Grundfos will not be liable
for any costs of removal, installation, transportation, or any other
charges that may arise in connection with a warranty claim.
Products which are sold, but not manufactured by Grundfos, are
subject to the warranty provided by the manufacturer of said
products and not by Grundfos' warranty.
Grundfos will not be liable for damage or wear to products caused
by abnormal operating conditions, accident, abuse, misuse,
unauthorized alteration or repair, or if the product was not
installed in accordance with Grundfos' printed installation and
operating instructions and accepted codes of good practice. The
warranty does not cover normal wear and tear.
To obtain service under this warranty, the defective product must
be returned to the distributor or dealer of Grundfos' products from
which it was purchased together with proof of purchase and
installation date, failure date and supporting installation data.
Unless otherwise provided, the distributor or dealer will contact
Grundfos or an authorized service station for instructions. Any
defective product to be returned to Grundfos or a service station
must be sent freight prepaid; documentation supporting the
warranty claim and/or a Return Material Authorization must be
included if so instructed.
Grundfos will not be liable for any incidental or consequential
damages, losses, or expenses arising from installation, use, or
any other causes. There are no express or implied warranties,
including merchantability or fitness for a particular purpose, which
extend beyond those warranties described or referred to above.
Some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages and some jurisdictions do
not allow limitations on how long implied warranties may last.
Therefore the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights and you may
also have other rights which vary from jurisdiction to jurisdiction.
Products which are repaired or replaced by Grundfos or
authorized service center under the provisions of these limited
warranty terms will continue to be covered by Grundfos warranty
only through the remainder of the original warranty period set
forth by the original purchase date.
2. General information
These installation and operating instructions are a supplement to
the installation and operating instructions for the corresponding
standard pumps NB, NBS, NK, TP, TPD. For instructions not
mentioned specifically in this manual, see the installation and
operating instructions for the standard pump.
The NBE, NBSE, NKE, TPE, TPED pumps are fitted with
frequency-controlled permanent-magnet motors for single-phase
or three-phase mains connection.
2.1 Symbols used in this document
2.1.1 Warnings against hazards involving risk of death or
personal injury
The text accompanying the three hazard symbols DANGER,
WARNING and CAUTION is structured in the following way:
2.2 Other important notes
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious personal injury.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious personal injury.
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
A blue or grey circle with a white graphical symbol
indicates that an action must be taken.
A red or grey circle with a diagonal bar, possibly with
a black graphical symbol, indicates that an action
must not be taken or must be stopped.

5
English (US)
2.3 Abbreviations and definitions
2.4 Radio communication
This product incorporates a radio module for remote control
which is a class 1 device and can be used anywhere in the EU
member states without restrictions.
For use in USA and Canada, see Appendix.
This product can communicate with Grundfos GO and other
products of the same type via the built-in radio module.
In some cases, an external antenna may be required. Only
Grundfos-approved external antennas may be connected to this
product, and only by a Grundfos-approved installer.
2.5 Battery
Pumps fitted with the advanced functional module, FM 300,
incorporate a Li-ion battery. The Li-ion battery complies with the
Battery Directive (2006/66/EC). The battery does not contain
mercury, lead and cadmium.
3. Receiving the product
3.1 Transporting the product
3.2 Inspecting the product
Before you install the product, do the following:
• Check that the product is as ordered.
• Check that no visible parts have been damaged.
If parts are damaged or missing, contact your local Grundfos
sales company.
4. Mechanical installation
4.1 Handling the product
Observe local regulations setting limits for manual lifting or
handling. The motor weight is stated on the nameplate.
AI Analog input.
AL Alarm, out of range at lower limit.
AO Analog output.
AU Alarm, out of range at upper limit.
CIM Communication interface module.
Current
sinking
The ability to draw current into the terminal and
guide it towards ground (earth) in the internal
circuitry.
Current
sourcing
The ability to push current out of the terminal and
into an external load which must return it to ground
(earth).
DI Digital input.
DO Digital output.
ELCB Earth leakage circuit breaker.
FM Functional module.
GDS Grundfos Digital Sensor.
Factory-fitted sensor in some Grundfos pumps.
GENIbus Proprietary Grundfos fieldbus standard.
GFCI Ground fault circuit interrupter.
USA and Canada.
GND Ground (Earth).
Grundfos
Eye Status indicator light.
LIVE Low voltage with the risk of electric shock if the
terminals are touched.
OC Open collector:
Configurable open-collector output.
PE Protective earth.
PELV
Protective extra-low voltage.
A voltage that cannot exceed ELV under normal
conditions and under single-fault conditions, except
ground (earth) faults in other circuits.
RCD Residual-current device
SELV
Safety extra-low voltage.
A voltage that cannot exceed ELV under normal
conditions and under single-fault conditions,
including ground (earth) faults in other circuits.
NBE,
NBSE,
NKE, TPE
Single-head pump without factory-fitted
differential-pressure sensor.
TPED Twin-head pump without factory-fitted
differential-pressure sensor.
NBE,
NBSE,
NKE, TPE,
TPED
Series 2000
Single-head pump (NBE, NBSE, NKE, TPE) and
twin-head pump (TPED) with factory-fitted
differential-pressure sensor.
WARNING
Falling objects
Death or serious personal injury
- Secure the product during transportation to prevent
it from tilting or falling down.
CAUTION
Crushing of feet
Minor or moderate personal injury
- Wear safety shoes when moving the product.
CAUTION
Back injury
Minor or moderate personal injury
- Use lifting equipment.
CAUTION
Crushing of feet
Minor or moderate personal injury
- Wear safety shoes and attach lifting equipment to
the motor eyebolts when handling the product.
Do not lift the product by the terminal box.

English (US)
6
4.2 Mounting the product
Secure the pump to a solid foundation by bolts through the holes
in the flange or the base plate.
4.3 Cable entries
See the size of the cable entries in section 27. Other technical
data.
4.4 Ensuring motor cooling
Leave at least 2 inches (50 mm) between the end of the fan cover
and a wall or other fixed objects. See fig. 1.
Fig. 1 Minimum distance, D, from the motor to a wall or other
fixed objects
4.5 Outdoor installation
If you install the motor outdoors, provide the motor with a cover
and open the drain holes to avoid condensation on the electronic
components. See figures 2 and 3.
The cover must be sufficiently large to ensure that the motor is
not exposed to direct sunlight, rain or snow. Grundfos does not
supply covers. We therefore recommend that you have a cover
built for the specific application. In areas with high humidity, we
recommend that you connect the motor permanently to the mains
supply and activate the built-in standstill heating function. See
section 11.20 "Standstill heating", page 39.
Fig. 2 Examples of covers, not supplied by Grundfos
4.6 Drain holes
When the motor is installed in moist surroundings or areas with
high humidity, the bottom drain hole must be open. The enclosure
class of the motor will then be lower. This helps prevent
condensation in the motor as the motor becomes self-venting,
and it allows water and humid air to escape.
The motor has a plugged drain hole on the drive side. You can
turn the flange 90 ° to both sides or 180 °.
Fig. 3 Drain holes
Ensure that the drain hole in the motor flange is open and is
facing downwards.
5. Electrical installation
If the power supply cable is damaged, it must be replaced by the
manufacturer, the manufacturer's service partner or a similarly
qualified person.
The user or the installer is responsible for the installation of
correct grounding (earthing) and protection according to local
regulations. All operations must be carried out by a qualified
electrician.
Carry out the electrical connection according to local regulations.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
CAUTION
Crushing of feet
Minor or moderate personal injury
- Secure the product to a solid foundation by bolts
through the holes in the flange or the base plate.
In order to maintain the UL mark, additional
requirements apply to the equipment. See Appendix.
TM05 5236 3512
When fitting a cover to the motor, observe the
guidelines in section 4.4 Ensuring motor cooling.
TM05 3496 3512
In order to maintain the UL mark, additional
requirements apply to the equipment. See Appendix.
D
TM07 3800 5220
Pos. Description
1 Drain hole for vertically mounted motor
2, 3 Drain hole for horizontally mounted motor
DANGER
Electric shock
Death or serious personal injury
- Switch off the power supply to the motor and to the
signal relays. Wait at least 5 minutes before you
make any connections in the terminal box. Make
sure that the power supply cannot be accidentally
switched on.
DANGER
Electric shock
Death or serious personal injury
- Check that the supply voltage and frequency
correspond to the values stated on the nameplate.
30º
3
2
1

7
English (US)
5.1 Protection against electric shock, indirect contact
Protective-earth conductors must always have a yellow and
green, PE, or yellow,green and blue, PEN, colour marking.
5.1.1 Protection against mains voltage transients
The motor is protected against mains voltage transients in
accordance with EN 61800-3.
5.1.2 Motor protection
The motor requires no external motor protection. The motor
incorporates thermal protection against slow overloading and
blocking.
5.2 Cable requirements
5.2.1 Cable cross-section
1 x 200-230 V
3 x 200-240 V
3 x 380-500 V
5.2.2 Conductors
Type
Stranded or solid copper conductors.
Temperature rating
Temperature rating for conductor insulation: 140 °F (60 °C).
Temperature rating for outer cable sheath: 167 °F (75 °C).
5.3 Mains supply
5.3.1 Single-phase supply voltage
• 1 x 200-230 V - 10 %/+ 10 %, 50/60 Hz, PE.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
The wires in the motor terminal box must be as short as possible.
Excepted from this is the separated ground (earth) conductor
which must be so long that it is the last one to be disconnected in
case the cable is inadvertently pulled out of the cable entry.
For maximum backup fuse, see section 24.1 Supply voltage.
Fig. 4 Example of a mains-connected motor with mains
switch, backup fuse and additional protection
Fig. 5 Mains connection, single-phase motors
WARNING
Electric shock
Death or serious personal injury
- Connect the motor to protective earth and provide
protection against indirect contact in accordance
with local regulations.
DANGER
Electric shock
Death or serious personal injury
- Always comply with local regulations as to cable
cross-sections.
Power Conductor
type
Cross section
[hp] [kW] [AWG] [mm2]
0.33 - 2.0 0.25 - 1.5 Solid 16-12 1.5 - 2.5
Stranded 16-12 1.5 - 2.5
Power Conductor
type
Cross section
[hp] [kW] [AWG] [mm2]
1.5 - 2.0 1.1 - 1.5 Solid 16-8 1.5 - 10
Stranded 16-8 1.5 - 10
3.5 - 7.5 2.5 - 5.5 Solid 14-8 2.5 - 10
Stranded 14-8 2.5 - 10
Power Conductor
type
Cross section
[hp] [kW] [AWG] [mm2]
0.33 - 3.0 0.25 - 2.2 Solid 16-8 1.5 - 10
Stranded 16-8 1.5 - 10
4.0 - 14.75 3.0 - 11 Solid 14-8 2.5 - 10
Stranded 14-8 2.5 - 10
DANGER
Electric shock
Death or serious personal injury
- Use the recommended fuse size. See sections
24.1 Supply voltage and 25.1 Supply voltage.
If you want to supply the motor through an IT
network, make sure that you have a suitable motor
variant. If you are in doubt, contact Grundfos.
TM05 4034 1912TM05 3494 1512
GFCI, type B

English (US)
8
5.3.2 Three-phase supply voltage
Three-phase motors are available for the voltages below:
• 3 x 380-500 V - 10 %/+ 10 %, 50/60 Hz, PE
• 3 x 200-240 V - 10 %/+ 10 %, 50/60 Hz, PE.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
The wires in the motor terminal box must be as short as possible.
Excepted from this is the separated ground (earth) conductor
which must be so long that it is the last one to be disconnected in
case the cable is inadvertently pulled out of the cable entry.
In order to avoid loose connections, ensure that the terminal
block for L1, L2 and L3 is pressed home in its socket when the
supply cable has been connected.
For maximum backup fuse, see section 25.1 Supply voltage.
Only the following motors can be supplied through an IT network:
• Motors with speed of 1450-2000/2200 rpm and up to 2.0 HP
(1.5 kW)
• Motors with speed of 2900-4000 rpm or 4000-5900 rpm and up
to 3 HP (2.2 kW).
Fig. 6 Example of a mains-connected motor with mains
switch, backup fuses and additional protection
Fig. 7 Mains connection, three-phase motors
5.4 Additional protection
The residual-current circuit breaker must be marked with the
following symbol:
The total leakage current of all the electrical equipment in the
installation must be taken into account. You find the leakage
current of the motor in sections 24.2 Leakage current and
25.2 Leakage current, AC.
This product can cause a direct current in the protective earth
conductor.
Overvoltage and undervoltage protection
Overvoltage and undervoltage may occur in case of unstable
power supply or a faulty installation. The motor is stopped if the
voltage falls outside the permissible voltage range. The motor
restarts automatically when the voltage is again within the
permissible voltage range. Therefore, no additional protection
relay is required.
Overload protection
If the upper load limit is exceeded, the motor automatically
compensates for this by reducing the speed and stops if the
overload condition persists.
The motor remains stopped for a set period. After this period, the
motor automatically attempts to restart. The overload protection
prevents damage to the motor. Consequently, no additional motor
protection is required.
Overtemperature protection
The electronic unit has a built-in temperature sensor as an
additional protection. When the temperature rises above a certain
level, the motor automatically compensates for this by reducing
the speed and stops if the temperature keeps rising. The motor
remains stopped for a set period. After this period, the motor
automatically attempts to restart.
Protection against phase unbalance
Three-phase motors must be connected to a power supply with a
quality corresponding to IEC 60146-1-1, class C, to ensure
correct motor operation at phase unbalance. This also ensures
long life of the components.
If you want to supply the motor through an IT
network, make sure that you have a suitable motor
variant. If you are in doubt, contact Grundfos.
Corner grounding is not allowed for supply voltages
above 3 x 480 V, 50/60 Hz.
TM05 3942 1812TM05 3495 1512
L1
L2
L3
L2
L1
L3
PE
GFCI, type B
DANGER
Electric shock
Death or serious personal injury
- Only use residual-current circuit breakers (ELCB,
GFCI, RCD) of type B.
The motor is protected against transients from the
power supply according to EN 61800-3. In areas with
high lightning intensity, we recommend external
lightning protection.

9
English (US)
5.5 Connection terminals
The descriptions and terminal overviews in this section apply to
both single-phase and three-phase motors.
For maximum torques, see section 27.1 Torques.
5.5.1 Connection terminals, advanced functional module, FM
300
The advanced module has these connections:
• three analog inputs
The factory-fitted analogue differential-pressure DPI sensor
for TPE Series 2000 is connected to one of these inputs.
• one analog output
• two dedicated digital inputs
• two configurable digital inputs or open-collector outputs
• input and output for Grundfos Digital Sensor
Not applicable for NBE, NBSE, NKE, TPE, TPED pumps. The
factory-fitted digital differential-pressure DPS sensor for NBE,
NBSE, NKE, TPE, TPED Series 2000 is connected to this
input.
• two Pt100/1000 inputs
• two LiqTec sensor inputs
• two signal relay outputs
• GENIbus connection.
See fig. 8.
•Inputs and outputs
All inputs and outputs are internally separated from the
mains-conducting parts by reinforced insulation and
galvanically separated from other circuits.
All control terminals are supplied by protective extra-low
voltage, PELV, thus ensuring protection against electric shock.
•Signal relay outputs
– Signal relay 1:
LIVE:
You can connect supply voltages up to 250 VAC.
PELV:
The output is galvanically separated from other circuits.
Therefore, you can connect the supply voltage or protective
extra-low voltage to the output as desired.
– Signal relay 2:
PELV:
The output is galvanically separated from other circuits.
Therefore, you can connect the supply voltage or protective
extra-low voltage to the output as desired.
• Mains supply, terminals N, PE, L or L1, L2, L3, PE.
* If you use an external supply source, make sure that there is a
connection to GND.
Fig. 8 Connection terminals, FM 300
Digital input 1 is factory-set to be start-stop input
where open circuit results in stop. A jumper has been
factory-fitted between terminals 2 and 6. Remove the
jumper if digital input 1 is to be used as external
start-stop or any other external function.
DANGER
Electric shock
Death or serious personal injury
- Make sure that the wires to be connected to the
connection groups below are separated from each
other by reinforced insulation in their entire
lengths.
TM05 3509 3512
3
15
8
26
23
25
24
7
21
20
22
B
Y
6
5
2
4
10
A
+24 V*
1
14
9
12
17
19
11
18
+24 V*
+
+24 V* OC DI
+24 V*/5 V*
+24 V*
+
++
+24 V*/5 V*
+24 V*
+24 V*
+
+
+24 V*/5 V*
+24 V*
+5 V*
AI2
GDS RX
GDS TX
GND
GENIbus A
GENIbus B
+5 V
+24 V
+24 V
GND
GENIbus Y
GND
+5 V
DI1
AI1
DI3/OC1
LiqTec
AI3
GND
DI2
LiqTec
GND
AO
Pt100/1000
Pt100/1000
DI4/OC2
GND
+24 V* OC DI
GND
NC
C2
NO
NC
C1
NO
+5 V*

English (US)
10
Terminal Type Function
NC Normally closed
contact Signal relay 1
LIVE or PELV
C1 Common
NO Normally open
contact
NC Normally closed
contact Signal relay 2
PELV only
C2 Common
NO Normally open
contact
18 GND Ground (Earth)
11 DI4/OC2
Digital input and output,
configurable.
Open collector: Maximum 24
V resistive or inductive.
19 Pt100/1000 input
2Pt100/1000 sensor input
17 Pt100/1000 input
1Pt100/1000 sensor input
12 AO
Analog output:
0-20 mA / 4-20 mA
0-10 V
9 GND Ground (Earth)
14 AI3
Analog input:
0-20 mA / 4-20 mA
0-10 V
1 DI2 Digital input, configurable
21 LiqTec sensor
input 1
LiqTec sensor input
white conductor
20 GND Ground (Earth)
brown and black conductors
22 LiqTec sensor
input 2
LiqTec sensor input
blue conductor
10 DI3/OC1
Digital input and output,
configurable.
Open collector: Maximum 24
V resistive or inductive.
4AI1
Analog input:
0-20 mA / 4-20 mA
0.5 - 3.5 V / 0-5 V / 0-10 V
2 DI1 Digital input, configurable
5+5 V Supply to potentiometer and
sensor
6 GND Ground (Earth)
A GENIbus, A GENIbus, A (+)
Y GENIbus, Y GENIbus, GND
B GENIbus, B GENIbus, B (-)
3 GND Ground (Earth)
15 +24 V Supply
8 +24 V Supply
26 +5 V Supply to potentiometer and
sensor
23 GND Ground (Earth)
25 GDS TX Grundfos Digital Sensor
output
24 GDS RX Grundfos Digital Sensor input
7AI2
Analog input:
0-20 mA / 4-20 mA
0.5 - 3.5 V / 0-5 V / 0-10 V
Terminal Type Function

11
English (US)
5.6 Signal cables
• Use screened cables with a cross-sectional area of minimum
0.5 mm2 and maximum 1.5 mm2 for external on/off switch,
digital inputs, setpoint and sensor signals.
• Connect the screens of the cables to frame at both ends with
good connection. The screens must be as close as possible to
the terminals. See fig. 9.
Fig. 9 Stripped cable with screen and wire connections
• Always tighten screws for frame connections whether a cable
is fitted or not.
• The wires in the motor terminal box must be as short as
possible.
Connection of E-pump to Danfoss sensor
The blue wire of the pressure sensor is connected to the #4
terminal of the E-pump. The brown wire of the pressure sensor is
connected to the #8 terminal of the E-pump.
See section 5.6 Signal cables for additional details.
Fig. 10 Danfoss sensor
5.7 Bus connection cable
5.7.1 New installations
For the bus connection, use a screened 3-core cable with a
cross-sectional area of minimum 0.5 mm2 and maximum 1.5
mm2.
If the motor is connected to a unit with a cable clamp which is
identical to the one on the motor, connect the screen to this cable
clamp.
If the unit has no cable clamp, leave the screen unconnected at
this end. See fig. 11.
Fig. 11 Connection with screened 3-core cable
5.7.2 Replacing a motor
• If you have used a screened 2-core cable in the existing
installation, connect the cable as shown in fig. 12.
Fig. 12 Connection with screened 2-core cable
• If you have used a screened 3-core cable in the existing
installation, follow the instructions in section 5.7.1 New
installations.
TM02 1325 4402 TM05 1533 2911
TM05 3973 1812TM02 8842 0904
A
Y
B
A
Y
B
1
2
3
1
2
3
Motor
A
Y
B
A
Y
B
1
2
1
2
Motor

English (US)
12
6. Operating conditions
6.1 Maximum number of starts and stops
The number of starts and stops via the power supply must not
exceed four times per hour.
When switched on via the power supply, the pump starts after
approximately 5 seconds.
If a higher number of starts and stops is desired, use the input for
external start-stop when starting or stopping the pump.
When started via an external on/off switch, the pump starts
immediately.
6.2 Alternating operation of twin-head pumps
On twin-head pumps, the duty and backup pumps must be
alternated on a regular basis, i.e. once a week, to ensure an even
distribution of the operating hours on both pumps. The pumps
alternate automatically. See section 11.43 "Multipump setup"
(
Setup of multi-pump system ).
If twin-head pumps are used for pumping domestic hot water, the
duty and backup pumps must be alternated on a regular basis,
i.e. once a day, to avoid blocking of the backup pump due to
deposits such as calcareous deposits. As default, the pumps
alternate automatically. See section 11.43 "Multipump setup"
(
Setup of multi-pump system ).
6.3 Ambient temperature
6.3.1 Ambient temperature during storage and transportation
Minimum: -22 °F (-30 °C)
Maximum: 140 °F (60 °C).
6.3.2 Ambient temperature during operation
The motor can operate with the rated power output, P2, at 122 °F
(50 °C), but continuous operation at higher temperatures reduces
the expected product life. If the motor is to operate at ambient
temperatures between 122 and 140 °F (50 and 60 °C) (for 3 x
380-500 V), or 104 and 122 °F (40 and 50 °C) (for 1 x 200-230 V
or 3 x 200-240 V), select an oversized motor. Contact Grundfos
for further information.
6.4 Installation altitude
Installation altitude is the height above sea level of the installation
site. The motors can be installed up to 11,482 feet (3500 m)
above sea level.
Motors installed up to 3280 feet (1000 m) above sea level can be
loaded 100 %.
Fig. 13 Motor output power in relation to altitude
In order to maintain the galvanic isolation and ensure correct
clearance according to EN 60664-1:2007, you must adapt the
supply voltage to the altitude:
Fig. 14 Supply voltage for three-phase motor in relation to
altitude
Fig. 15 Supply voltage for single-phase motor in relation to
altitude
1 x 200-230 V 3 x 200-240 V 3 x 380-500 V
Minimum -4 °F (-20 °C) -4 °F (-20 °C) -4 °F (-20 °C)
Maximum 122 °F (50 °C) 104 °F (40 °C) 122 °F (50 °C)
Motors installed more than 3280 feet (1000 m) above
sea level must not be fully loaded due to the low
density and consequent low cooling effect of the air.
TM07 1696 2118TM07 1697 2118TM07 1698 2118
0
0
60
80
90
70
100
500 1000 1500 2000 2500 3000 3500 [m]
2000 4000 6000 8000 10000 [ft]
Altitude
P2 [%]
500
480
460
440
420
380
400
0
[m]
0 500 1000 1500 2000 2500 3000 3500 4000
2000 4000 6000 8000 10000 11000 [ft]
Supply voltage [V]
Altitude
0
[m]0 500 1000 1500 2000 2500 3000 3500 4000
2000 4000 6000 8000 10000 11000 [ft]
200
210
220
230
240
250
Supply voltage [V]
Altitude

13
English (US)
6.5 Humidity
Maximum humidity: 95 %.
If the humidity is constantly high and above 85 %, one of the drain
holes in the drive-end flange must be open. See section 4.6 Drain
holes.
6.6 Motor cooling
To ensure cooling of motor and electronics, observe the following:
• Position the motor in such a way that adequate cooling is
ensured. See section 4.4 Ensuring motor cooling.
• The temperature of the cooling air must not exceed 122 °F (50
°C) (for 3 x 380-500 V), or 104 °F (40 °C) (for 1 x 200-230 V or
3 x 200-240 V).
• Keep cooling fins and fan blades clean.
7. User interfaces
You can make the pump settings by means of the following user
interfaces:
Control panels
• Standard control panel.
See section 8. Standard control panel.
• Advanced control panel.
See section 9. Advanced control panel.
Remote controls
• Grundfos GO.
See section 10. Grundfos GO.
If the power supply to the pump is switched off, the settings are
stored.
8. Standard control panel
Fig. 16 Standard control panel
WARNING
Hot surface
Death or serious personal injury
- Only touch the buttons on the display as the
product may be very hot.
WARNING
Electric shock
Death or serious personal injury
- If the control panel is cracked or perforated,
replace it immediately. Contact the nearest
Grundfos sales company.
Pump variant Fitted as
standard Option
NBE, NBSE, NKE, TPE, TPED - ●
NBE, NBSE, NKE, TPE, TPED
Series 2000 --
TM05 4848 3512
Pos. Symbol Description
1
Grundfos Eye
Shows the operating status of the pump.
See section 15. Grundfos Eye for further
information.
2 - Light fields for indication of setpoint.
3 Up and down. Changes the setpoint.
4
Allows radio communication with Grundfos
GO and other products of the same type.
When you try to establish radio
communication between the pump and
Grundfos GO or another pump, the green
indicator light in Grundfos Eye on the pump
flashes continuously. Press on the pump
control panel to allow radio communication
with Grundfos GO and other products of the
same type.
5
Makes the pump ready for operation as well
as starts and stops the pump.
Start
If you press the button when the pump is
stopped, the pump only starts if no other
functions with higher priority have been
enabled. See section 14. Priority of settings.
Stop
If you press the button when the pump is
running, the pump always stops. The "Stop"
text next to the button is on.
1
2
3
4
5
Stop

English (US)
14
8.1 Setpoint setting
Set the desired setpoint of the pump by pressing or . The
light fields on the control panel indicates the setpoint set.
8.1.1 Pump in differential-pressure control mode
The following example applies to a pump in an application where
a pressure sensor gives a feedback to the pump. If you retrofit the
sensor to the pump, set it manually as the pump does not
automatically register a connected sensor.
Figure 17 shows that the light fields 5 and 6 are activated,
indicating a desired setpoint of 3 m with a sensor measuring
range from 0 to 6 m. The setting range is equal to the sensor
measuring range.
Fig. 17 Setpoint set to 3 m, differential-pressure control
8.1.2 Pump in constant-curve control mode
In constant-curve control mode, the pump performance lies
between the maximum and minimum curve of the pump. See fig.
18.
Fig. 18 Pump in constant-curve control mode
Setting to maximum curve:
•Press continuously to change over to the maximum curve
of the pump. The top light field flashes. When the top light field
is on, press for 3 seconds until the light field starts flashing.
• To change back, press continuously until the desired
setpoint is indicated.
Example
Pump set to maximum curve.
Figure 19 shows that the top light field is flashing, indicating
maximum curve.
Fig. 19 Maximum-curve duty
Setting to minimum curve:
•Press continuously to change over to the minimum curve of
the pump. The bottom light field flashes. When the bottom light
field is on, press for 3 seconds until the light field starts
flashing.
• To change back, press continuously until the desired
setpoint is indicated.
Example
Pump set to minimum curve.
Figure 20 shows that the bottom light field is flashing, indicating
minimum curve.
Fig. 20 Minimum-curve duty
8.1.3 Start-stop of pump
Start the pump by pressing or by continuously pressing until
the desired setpoint is indicated.
Stop the pump by pressing . When the pump is stopped, the
"Stop" text next to the button is on. You can also stop the pump by
continuously pressing until none of the light fields are on.
You can also stop the pump with the Grundfos GO or via a digital
input set to External stop. See section 14. Priority of settings.
8.1.4 Resetting of fault indications
Reset a fault indication in one of the following ways:
• Via the digital input if it has been set to Alarm resetting.
• Briefly press or on the pump. This does not change the
setting of the pump.
You cannot reset a fault indication by pressing or if the
buttons have been locked.
• Switch off the power supply until the indicator lights are off.
• Switch the external start-stop input off and on.
• With Grundfos GO.
TM05 4894 3512TM05 4895 2812TM05 4896 2812
0
6
3
bar
[bar]
H
Q
Maximum
Minimum
H
Q
TM05 4897 2812
If you have stopped the pump by pressing and the
"Stop" text on the control panel is on, you can only
give it free to operation by pressing again.
If you have stopped the pump by pressing , you
can restart it by pressing or by using Grundfos
GO.
H
Q

15
English (US)
9. Advanced control panel
Fig. 21 Advanced control panel
Pump variant Fitted as standard Option
NBE, NBSE, NKE, TPE,
TPED ●-
NBE, NBSE, NKE, TPE,
TPED Series 2000 ●-
TM05 4849 1013
Pos. Symbol Description
1
Grundfos Eye
Shows the operating status of the pump.
For further information, see section
15. Grundfos Eye.
2 - Graphical colour display.
3 Goes one step back.
4
Navigates between main menus, displays
and digits.
When you change the menu, the display
always shows the top display of the new
menu.
Navigates between submenus.
Changes value settings.
Note: If you have disabled the possibility to
make settings with the Enable/disable
settings function, then you can enable it
again temporarily by pressing these buttons
simultaneously for at least 5 seconds. See
section 11.28 "Buttons on product"
(
Enable/disable settings ).
4
Saves changed values, resets alarms and
expands the value field.
Enables radio communication with Grundfos
GO and other products of the same type.
When you try to establish radio
communication between the pump and
Grundfos GO or another pump, the green
indicator light in Grundfos Eye flashes. A
note also appears in the pump display stating
that a wireless device wants to connect to
the pump. Press on the pump control
panel to allow radio communication with
Grundfos GO and other products of the same
type.
1
2
3
4
5
6
5
Makes the pump ready for operation and
starts, and stops the pump.
Start:
If you press the button when the pump is
stopped, the pump only starts if no other
functions with higher priority have been
enabled. See section 14. Priority of settings.
Stop:
If you press the button when the pump is
running, the pump is always stopped. When
you stop the pump via this button, the
icon appears in the bottom of the display.
6 Goes to the Home menu.
Pos. Symbol Description

English (US)
16
9.1 Home display
Fig. 22 Example of Home display
9.2 Startup guide
The pump incorporates a startup guide which is started at the first
startup. See section 11.37
Run start-up guide . After the startup
guide, the main menus appear in the display.
TM07 1699 2118
Pos. Symbol Description
1
Home
This menu shows up to four user-defined
parameters. You can select parameters
shown as shortcut icon , and when
pressing you go directly to the "Settings"
display for the selected parameter.
2-
Status
This menu shows the status of the pump and
system as well as warnings and alarms.
3-
Settings
This menu gives access to all setting
parameters. You can make detailed settings
of the pump in this menu.
See section 11. Description of functions.
4-
Assist
This menu enables assisted pump setup,
provides a short description of the control
modes and offers fault advice.
See section 12. Selection of control mode.
5Indicates that the pump has been stopped
via the button.
6Indicates that the pump is functioning as
master pump in a multipump system.
7Indicates that the pump is functioning as a
slave pump in a multipump system.
8
Indicates that the pump is operating in a
multipump system. See section
11.43 "Multipump setup" (
Setup of
multi-pump system
).
9
Indicates that the possibility to make settings
has been disabled for protective reasons.
See section 11.28 "Buttons on product"
(
Enable/disable settings ).
Setpoint
50 psi
Operating mode
Normal
Actual controlled value
49 psi
Control mode
Const. pressure
Status Settings Assist
1 2 3 4
56789
Home

17
English (US)
9.3 Menu overview for advanced control panel
9.3.1 Main menus
Home
NBE,
NBSE,
NKE,
TPE,
TPED
NBE,
NBSE,
NKE,
TPE,
TPED
Series
2000
Multipump
system
●● ●
Status
NBE,
NBSE,
NKE,
TPE,
TPED
NBE,
NBSE,
NKE,
TPE,
TPED
Series
2000
Multipump
system
Operating status ●● ●
Operating mode, from ●● ●
Control mode ●● ●
Pump performance ●● ●
Actual controlled value ●● ●
Resulting setpoint ●● ●
Speed ●● ●
Acc. flow and specific energy ●● ●
Power and energy consumption ●● ●
Measured values ●● ●
Set date and time ●● ●
Analog input 1 ●● ●
Analog input 2 ●● ●
Analog input 3 ●● ●
Pt100/1000 input 1 ●● ●
Pt100/1000 input 2 ●● ●
Analog output ●● ●
Warning and alarm ●● ●
Actual warning or alarm ●● ●
Warning log ●● ●
Alarm log ●● ●
Operating log ●● ●
Operating hours ●● ●
Trend data ●● ●
Fitted modules ●● ●
Date and time ●● ●
Product identification ●● ●
Motor bearing monitoring ●● ●
Multi-pump system -- ●
System operating status -- ●
System performance -- ●
System input power and energy -- ●
Pump 1, multi-pump system -- ●
Pump 2, multi-pump system -- ●
Pump 3, multi-pump system -- ●
Pump 4, multi-pump system - - ●

English (US)
18
Settings
NBE,
NBSE,
NKE,
TPE,
TPED
NBE,
NBSE,
NKE,
TPE,
TPED
Series
2000
Multipump
system Section Page
Setpoint ●● ●11.1
Setpoint 24
Operating mode ●● ●11.2
Operating mode 24
Set manual speed ●● ●11.3
Set manual speed 24
"Set user-defined speed" ● ● ● 11.4 "Set user-defined speed" 24
Control mode ●● ●11.5 "Control mode" 24
Analog inputs ●● ●
11.7
Analog inputs 29
Analog input 1, setup ●● ●
Analog input 2, setup ●● ●
Analog input 3, setup ●● ●
Built-in Grundfos sensor - ● ●*11.8 Built-in Grundfos sensor 30
Pt100/1000 inputs ●● ●
11.9
Pt100/1000 inputs 30Pt100/1000 input 1, setup ●● ●
Pt100/1000 input 2, setup ●● ●
Digital inputs ●● ●
11.10
Digital inputs 31Digital input 1, setup ●● ●
Digital input 2, setup ●● ●
Digital inputs/outputs ●● ●
11.11
Digital inputs/outputs 32Digital input/output 3, setup ●● ●
Digital input/output 4, setup ●● ●
Relay outputs ●● ●
11.12 "Signal relays 1 and 2" (
Relay outputs )33Relay output 1 ●● ●
Relay output 2 ●● ●
Analog output ●● ●
11.13
Analog output 33Output signal ●● ●
Function of analog output ●● ●
"Controller settings" ● ● ● 11.14 "Controller" ("Controller settings") 34
Operating range ●● ●11.15
Operating range 36
Setpoint influence ●● ●
External setpoint function ●● ● 36
"Predefined setpoints" ● ● ● 11.16.2 "Predefined setpoints" 38
Monitoring functions ●● ●
Motor bearing monitoring ●● ●11.21
Motor bearing monitoring 40
Motor bearing maintenance ●● ●
Bearings replaced (
Motor bearing
maintenance
)40
Limit-exceeded function ●● ●11.17
Limit-exceeded function 38
"Special functions" ● ●
"Pulse flowmeter setup" ● ● ● 11.18 "Pulse flowmeter setup" 39
"Ramps" ● ● ● 11.19 "Ramps" 39
"Standstill heating" ● ● ● 11.20 "Standstill heating" 39
Communication ●● ●
Pump number ●● ●11.23 "Number" (
Pump number )40
Enable/disable radio comm. ● ● ● 11.24 "Radio communication"
(Enable/disable radio comm.) 40
General settings ●● ●
Language ●● ●11.25
Language 40
Set date and time ●● ●11.26 "Date and time" (
Set date and time )40
Units ●● ●11.27 "Unit configuration" (
Units )40
Enable/disable settings ●● ●
11.28 "Buttons on product" (
Enable/disable
settings
)41
Delete history ●● ●11.29
Delete history 41
Define Home display ●● ●11.30
Define Home display 41

19
English (US)
Display settings ●● ●11.31 Display settings 41
Store actual settings ●● ●11.32 "Store settings" (
Store actual settings )41
Recall stored settings ●● ●
11.33 "Recall settings" (
Recall stored
settings
)41
Run start-up guide ●● ●11.37
Run start-up guide 42
* Applies only to a multipump system with NBE, NBSE, NKE, TPE, TPED Series 2000 pumps.
Settings
NBE,
NBSE,
NKE,
TPE,
TPED
NBE,
NBSE,
NKE,
TPE,
TPED
Series
2000
Multipump
system Section Page
Assist
NBE,
NBSE,
NKE,
TPE,
TPED
NBE,
NBSE,
NKE,
TPE,
TPED
Series
2000
Multipump
system Section Page
Assisted pump setup ●● ●11.41
Assisted pump setup 43
Setup, analog input ●● ●11.42
Setup, analog input 43
Setting of date and time ●● ●
11.43 "Multipump setup" (
Setup of multi-pump
system
)43
Setup of multi-pump system ● ● ● 11.43 "Multipump setup" (
Setup of multi-pump
system
)43
Description of control mode ●● ●11.44
Description of control mode 46
Assisted fault advice ●● ●11.45
Assisted fault advice 46

English (US)
20
10. Grundfos GO
The pump is designed for wireless radio or infrared
communication with Grundfos GO.
Grundfos GO enables setting of functions and gives access to
status overviews, technical product information and actual
operating parameters.
Grundfos GO offers the following mobile interfaces (MI).
Fig. 23 Grundfos GO communicating with the pump via radio
or infrared connection, IR
10.1 Communication
When Grundfos GO initiates communication with the pump, the
indicator light in the middle of Grundfos Eye flashes green. See
section 15. Grundfos Eye.
Furthermore, on pumps fitted with an advanced control panel a
text appears in the display saying that a wireless device is trying
to establish connection. Press on the pump in order to
establish connection with Grundfos GO or press to reject
connection.
Establish communication using one of these communication
types:
• radio communication
• infrared communication.
10.1.1 Radio communication
Radio communication can take place at distances up to 30 m.
The first time Grundfos GO communicates with the pump, you
must enable communication by pressing or on the pump
control panel. Later when communication takes place, the pump
is recognized by Grundfos GO and you can select the pump from
the "List" menu.
10.1.2 Infrared communication
When communicating via infrared light, Grundfos GO must be
pointed at the pump control panel.
TM06 6256 0916
Pos. Description
1
Grundfos MI 301:
Separate module enabling radio or infrared
communication. You can use the module in
conjunction with an Android or iOS-based smart
device with Bluetooth connection.
+
1
