Grundfos KPL User manual

GRUNDFOS INSTRUCTIONS
KPL, KPG and KWM
15-1060 Hp, 60 Hz, ANSI
Installation and operating instructions

English (US)
2
English (US) Installation and operating instructions
Original installation and operating instructions
CONTENTS
Page
1. Limited warranty
Products manufactured by GRUNDFOS PUMPS CORPORATION
(Grundfos) are warranted to the original user only to be free of
defects in material and workmanship for a period of 24 months
from date of installation, but not more than 30 months from date
of manufacture. Grundfos' liability under this warranty shall be
limited to repairing or replacing at Grundfos' option, without
charge, F.O.B. Grundfos' factory or authorized service station,
any product of Grundfos' manufacture. Grundfos will not be liable
for any costs of removal, installation, transportation, or any other
charges which may arise in connection with a warranty claim.
Products which are sold but not manufactured by Grundfos are
subject to the warranty provided by the manufacturer of said
products and not by Grundfos' warranty. Grundfos will not be
liable for damage or wear to products caused by abnormal
operating conditions, accident, abuse, misuse, unauthorized
alteration or repair, or if the product was not installed in
accordance with Grundfos' printed installation and operating
instructions.
To obtain service under this warranty, the defective product must
be returned to the distributor or dealer of Grundfos' products from
which it was purchased together with proof of purchase and
installation date, failure date, and supporting installation data.
Unless otherwise provided, the distributor or dealer will contact
Grundfos or an authorized service station for instructions. Any
defective product to be returned to Grundfos or a service station
must be sent freight prepaid; documentation supporting the
warranty claim and/or a Return Material Authorization must be
included if so instructed.
GRUNDFOS WILL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, LOSSES, OR EXPENSES
ARISING FROM INSTALLATION, USE, OR ANY OTHER
CAUSES. THERE ARE NO EXPRESS OR IMPLIED
WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, WHICH EXTEND BEYOND
THOSE WARRANTIES DESCRIBED OR REFERRED TO
ABOVE.
Some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages and some jurisdictions do
not allow limit actions on how long implied warranties may last.
Therefore, the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights and you may
also have other rights which vary from jurisdiction to jurisdiction.
1. Limited warranty 2
2. General information 3
2.1 Target groups 3
2.2 Hazard statements 3
2.3 Notes 3
3. Receiving the product 3
4. Installation requirements 3
4.1 Safety information and preparation 3
4.2 Lifting the product 4
4.3 Mechanical installation of KPG 11
4.4 Electrical connection 12
4.5 Frequency converter operation 14
5. Starting up the product 15
5.1 Preparations for starting up 15
5.2 Startup 17
6. Handling and storing the product 17
6.1 Handling the product 17
6.2 Storing the product 17
7. Product introduction 18
7.1 Applications 18
7.2 General description 18
8. Identification 19
8.1 Type key 19
8.2 Nameplate 19
9. Protection and control functions 20
9.1 Sensors 20
9.2 Pump control 22
10. Servicing and maintaining the product 23
10.1 Safety instructions and requirements 23
10.2 Maintenance 23
10.3 Spare parts 25
10.4 Contaminated pumps 25
11. Fault finding 26
12. Technical data 27
12.1 Operating conditions 27
12.2 Dimensions and weights 27
12.3 Water level requirements 27
13. Disposing of the product 29
Read this document before installing the product.
Installation and operation must comply with local
regulations and accepted codes of good practice.

3
English (US)
2. General information
This booklet gives instructions for installation, operation and
maintenance of Grundfos KPL, KPG and KWM pumps.
2.1 Target groups
These installation and operating instructions are intended for
professional installers.
2.2 Hazard statements
The symbols and hazard statements below may appear in
Grundfos installation and operating instructions, safety
instructions and service instructions.
The hazard statements are structured in the following way:
2.3 Notes
The symbols and notes below may appear in Grundfos
installation and operating instructions, safety instructions and
service instructions.
3. Receiving the product
Make sure that the pump cannot roll or fall over.
4. Installation requirements
4.1 Safety information and preparation
When the pump is completely submerged, it is sufficiently cooled
by the surrounding liquid.
In addition to the pump, the following items are required and must
be ordered separately.
• A cable suspension system for securing the cables.
• Control equipment, e. g. MP 204.
• KPL and KWM: A column pipe with a seat ring and integrated
anti-rotation brackets on which the pump is standing. The seat
ring can be supplied with the pump as an installation
accessory.
• KPG: A gate with a flange connection that corresponds to the
outlet flange of the KPG.
DANGER
Indicates a hazardous situation which, if not avoided,
will result in death or serious personal injury.
WARNING
Indicates a hazardous situation which, if not avoided,
could result in death or serious personal injury.
CAUTION
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
Observe these instructions for explosion-proof
products.
A blue or grey circle with a white graphical symbol
indicates that an action must be taken.
A red or grey circle with a diagonal bar, possibly with
a black graphical symbol, indicates that an action
must not be taken or must be stopped.
If these instructions are not observed, it may result in
malfunction or damage to the equipment.
Tips and advice that make the work easier.
- Pump installation in pits must be carried out by
specially trained persons.
- Work in or near pits must be carried out according
to local regulations.
- For safety reasons, all work in pits must be
supervised by a person outside the pit.
DANGER
Electric shock
Death or serious personal injury
- It must be possible to lock the main switch in
position 0. Type and requirements as specified in
National Electric Code (NEC), or NFPA 70.
CAUTION
Crushing hazard
Minor or moderate personal injury
- Wear personal protective equipment when working
on the product.
CAUTION
Biological hazard
Minor or moderate personal injury
- Flush the pump thoroughly with clean water and
rinse the pump parts after dismantling.
Pits for submersible drainage and effluent pumps
may contain drainage or effluent with toxic and/or
contagious substances.
- Wear appropriate personal protective equipment
and clothing.
- Observe the local hygiene regulations in force.

English (US)
4
4.2 Lifting the product
Carelessness during lifting or transportation may cause personal
injury or damage to the pump.
If the pump is tilted more than 10 ° in any direction from its normal
position (BS EN 809:1998+A1:2009), the pump may lose its
stability.
Lifting points
When lifting the pump, use the right lifting points to keep the
pump balanced.
Fig. 1 KPL and KWM: lifting points
Lifting point, top
KPL and KWM: use the lifting bracket as the top lifting point. See
fig. 4.
KPG: use two top lifting points. See fig. 5.
Lifting point, centre (KPG)
When installing KPG pumps horizontally, use the lifting points on
the outlet casing. See fig. 6.
Lifting point, bottom
Use the pump inlet casing as the bottom lifting point. Lift by a
lifting strap or a lifting chain secured around the pump inlet. See
fig. 7 and fig. 10.
Fig. 2 KPL and KWM: anti-rotation brackets
Fig. 3 KPG: anti-rotation brackets
DANGER
Crushing hazard
Death or serious personal injury
- Always check the lifting bracket or lifting eyes and
the chain for corrosion or wear before lifting.
- Always lift the pump by its lifting bracket or lifting
eyes or by a fork-lifttruck. See fig. 1 - 10.
DANGER
Crushing hazard
Death or serious personal injury
- Always use certified lifting equipment.
- Note that the cable suspension system is not
certified lifting equipment.
- All lifting equipment must be rated for the purpose
and checked for damage before lifting the pump.
The lifting equipment rating must not be exceeded.
- The weight of the specific pump is stated on the
nameplate.
DANGER
Electric shock
Death or serious personal injury
- Never lift the pump by the power cables.
DANGER
Crushing hazard
Death or serious personal injury
- Make sure the lifting bracket or lifting eye bolts and
the strap is tightened before lifting the pump.
TM05 9208 3313TM05 9209 3313TM07 4685 2219
Lifting point, top
Lifting point, bottom

5
English (US)
4.2.1 Lifting with single or double wire
Lifting with single wire
Fig. 4 KPL and KWM: lifting with single wire
Fig. 5 KPG: lifting with single wire (for transport)
Fig. 6 KPG: lifting with single wire connected to both lifting eyes (for
installation)
Lifting with double wire
Fig. 7 KPL and KWM: lifting with double wire, step 1
Fig. 8 KPL and KWM: lifting with double wire, step 2
Fig. 9 KPG: lifting with double wire, step 1
Fig. 10 KPG: lifting with double wire, step 2
Mechanical installation of KPL and KWM
Observe the maximum cable bending radius. See 12.2.1 Bending
radius of cables.
Prior to installation, check the oil level in the oil chamber. See
section 10.2.3 Checking and changing the oil.
TM05 9207 3313TM07 4686 2219TM07 4799 2219
During installation, the KPG motor top is inserted into
the gate flange. Therefore, only the lifting method in
Fig. 6 can be used for installation.
The lifting eyes in the outlet casing are close to the
centre of gravity, so the pump can be lifted in
horizontal position without using the lifting eyes on
the motor top.
TM05 9208 3313TM05 9208 3313TM07 4687 2219TM07 4688 2219
DANGER
Electric shock
Death or serious personal injury
- Before installation, switch off the power supply and
lock the main switch in position 0.
- Before working on the pump, switch off any
external voltage connected to the pump.
Observe all safety regulations at the installation site,

English (US)
6
4.2.2 Requirement for free space below the pump
The following table indicates the column pipe diameter (∅D) and
the minimum free space allowed (C) under the pump. For further
information on installation, see fig. 11 and fig. 12.
Fig. 11 KPL: installation dimensions
Fig. 12 KWM: installation dimensions
4.2.3 Installing the anchor bolts
As part of the construction work, the anchor bolts must be
installed before the concrete is poured. If this cannot be
accomplished, mark out and install the anchor bolts during the
installation of the column pipe.
KPL KWM
∅D
[in. (mm)]
C
[in. (mm)]
∅D
[in. (mm)]
C
[in. (mm)]
20
(500)
10
(250) --
24
(600)
12
(300)
24H
(600H)
12
(300)
24M
(600M)
12
(300)
28
(700)
14
(350)
28H
(700)
14
(350)
28M
(700)
14
(350)
32
(800)
16
(400)
32H
(800H)
16
(400)
32M
(800M)
16
(400)
36
(900)
18
(450)
36H
(900)
18
(450)
36M
(900)
18
(450)
40
(1000)
20
(500)
40H
(1000H)
20
(500)
40M
(1000M)
20
(500)
48
(1200)
24
(600)
48
(1200)
24
(600)
56
(1400)
28
(700)
56
(1400)
28
(700)
60
(1500)
30
(750) --
64
(1600)
32
(800)
64
(1600)
32
(800)
72
(1800)
36
(900) --
TM05 5306 3812TM05 5597 3812
D
C
Under-floor
installation
D
C
Under-floor
installation

7
English (US)
4.2.4 Pit construction
Fig. 13 Schematic view of pit design
TM03 9470 4007
Screen
Max. 10 °
TM03 9471 4212
D
DD
D
D/2 D/2
D/2
4D
2D

English (US)
8
* Flow velocity V:
0.7 m/sec. for storm- and wastewater containing particles.
0.3 m/sec. for screened storm- and wastewater without particles.
Dimensions
* D = pipe diameter DN
TM07 3747 2219
V*
D
V*
V*
V*
V*
V*
2D
2D 10°
D [ D
TM03 9473 4212
V*
V*
D
D
D
D
D
D
L
D
B
W
C
C
Max. 20 °
C
C
BT
4D+T
A
D*
[in. (mm)]
A
[mm]
B
[mm]
C
[mm]
W
[mm]
L
[mm] T
20 (DN 500) 79 (2000) 39 (1000) 10 (250) 79 (2000) 79 (2000)
Depending on construction,
contact Grundfos
24 (DN 600) 94 (2400) 47 (1200) 12 (300) 94 (2400) 94 (2400)
28 (DN 700) 110 (2800) 55 1400) 14 (325) 110 (2800) 110 (2800)
32 (DN 800) 126 (3200) 63 (1600) 16 (400) 126 (3200) 126 (3200)
36 (DN 900) 142 (3600) 71 (3800) 18 (450) 142 (3600) 142 (3600)
40 (DN 1000) 157 (4000) 79 (2000) 20 (500) 157 (4000) 157 (4000)
48 (DN 1200) 189 (4800) 94 (2400) 24 (600) 189 (4800) 189 (4800)
56 (DN 1400) 220 (5600) 110 (2800) 28 (700) 220 (5600) 220 (5600)
60 (DN 1500) 236 (6000) 118 (3000) 30 (750) 236 (6000) 236 (6000)
64 (DN 1600) 252 (6400) 126 (3200) 32 (800) 252 (6400) 252 (6400)
72 (DN1800) 285 (7200) 142 (3600) 35 (900) 285 (7200) 285 (7200)

9
English (US)
4.2.5 Installing the column pipe
1. Fit a waterproof sealing between the mounting flange and the
concrete support. See fig. 14.
Fig. 14 Position of the waterproof sealing
2. Slowly lower the column pipe into the pit using overhead lifting
equipment.
3. Make sure that the column pipe is vertical and fastened to the
concrete.
4. Tighten the anchor bolt nuts to ensure that the column pipe
cannot move.
4.2.6 Installing the KPL and KWM pump
Make sure that the pump is aligned with the anti-rotation brackets
and cannot rotate when the impeller runs.
1. Make sure that the sealing O-ring is clean and located in the
groove on the bottom of the inlet casing (KPL) or outlet casing
(KWM). The O-ring seals between the pump and the seat ring
to preventing backflow.
2. Slowly lower the pump into the column pipe using the
overhead lifting equipment. If necessary, use an intermediate
lifting ring.
3. Carefully guide the pump into position at the bottom of the
column pipe, so the pump does not tilt in any way on the stop
vanes at the bottom of the column pipe.
4. Lift the pump 1 inch (2 to 3 cm) and turn it counter-clockwise
until the anti-rotation brackets touch the nearest adjacent stop
vanes.
4.2.7 Installing the cable suspension system in the column
pipe
Follow these instructions and secure the cables properly:
1. Clamp the wire rope and all cables together. Make sure there
is 20 inches (0.5 m) distance between the clamps adapted to
the weight of the cables. See fig. 15.Fasten the wire rope to
the eye at the top of the column pipe.
2. Adjust the turnbuckle between the wire rope and the eye of
the beam. Make sure there is no slack in the cable
suspension, the cables are fixed to it and cannot move during
operation.
3. Lead the cables through the cable bushing of the column pipe.
4. Run the cables to the external terminal box. Make sure that
the cable bushing is fitted correctly and prevents water from
entering.
5. Fit the top cover on the upper part of the column pipe using a
waterproof gasket, then tighten the bolts. Make sure that the
cover prevents water from entering.
TM05 5307 3612
Wrong direction of rotation results in damage to the
pump.
- Check the direction of rotation before the
installation. See section 5.1.1 Checking the
direction of rotation.
- The use of a phase detection equipment, such as
the MP 204, protects the pump from starting if the
phase sequency is changed.
The pump is secured by its own weight against the
anti-rotation brackets. No additional fastening is
required.
Turbulence optimization is not possible if the pump is
mounted in an oversize column pipe.
Waterproof
sealing
If the pump is configured for side discharge, locate
the cable inlet opposite the water outlet.
Disruption in the direction of water flow may cause
damage to the cable.
To avoid cable damage, do not position the cable
inlet in the column pipe near the water outlet.
DANGER
Crushing hazard
Death or serious personal injury
- Do not put your hands or any tools into the pump
inlet or outlet after the pump has been connected
to the power supply, unless the main switch has
been locked in position 0.

English (US)
10
Cable suspension system
Figure 15 indicates a principle sketch only - the cable suspension system may be adapted to the specific pump type.
Fig. 15 Securing the cables to the lifting wire
A cable suspension system is mandatory to avoid
cable damage during operation.
TM05 5940 4212
D
Turnbuckle
Sensor cable
Power cable
Intermediate lifting ring
(on request)
Wire rope
Lifting wire, detail D
Wire rope
View A - A
Cable clamps, distance
Max. 20 inch
(0.5 m)

11
English (US)
4.3 Mechanical installation of KPG
Observe the maximum cable bend radius. See 12.1.4 Operating
mode.
Prior to installation, check the oil level in the oil chamber. See
section 10.2.3 Checking and changing the oil.
4.3.1 Pit construction
DANGER
Electric shock
Death or serious personal injury
- Before installation, switch off the power supply and
lock the main switch in position 0.
- Before working on the pump, switch off any
external voltage connected to the pump.
Observe all safety regulations at the installation site.
TM07 4713 2319
0
M
2
3
3.5
KUM-A
1
G.P.I
0.5
1.5
2.5
0
M
2
3
3.5
KUM-A
1
G.P.I
0.5
1.5
2.5
B1
D
CA1 A1
0
M
2
3
3.5
KUM-A
1
G.P.I
0.5
1.5
2.5
B2
A2
D
Model Outlet diameter
inch [mm
1 gate + 1 pump 1 gate + 2 pumps
A1
inch [mm]
B1
inch [mm]
C
inch [mm]
A2
inch [mm]
B2
inch [mm]
KPG.20 20" (DN 500) 49 1250 77 1950 35 900 75 1900 35 900
KPG.24 24" (DN 600) 55 1400 83 2100 35 900 87 2200 39 1000
KPG.28 28" (DN 700) 59 1500 87 2200 35 900 94 2400 43 1100
KPG.32 32" (DN 800) 71 1800 98 2500 35 900 110 2800 51 1300
KPG.36 36" (DN 900) 75 1900 102 2600 35 900 118 3000 55 1400
KPG.40 40" (DN 1000) 83 2100 110 2800 35 900 130 3300 63 1600
KPG.48 48" (DN 1200) 102 2600 130 3300 35 900 157 4000 79 2000
KPG.56 56" (DN 1400) 118 3000 146 3700 35 900 189 4800 94 2400

English (US)
12
4.3.2 Installing the KPG pump
• Lift the pump horizontally by the lifting eyes on the outlet
casing to install it in the gate. See fig. 6.
• Use certified lifting equipment only.
Proceed as follows:
1. Make sure the cables are not damaged during the installation.
2. Make sure the lifting eye bolts are correctly installed and
tightened before lifting the pump.
3. Lower the pump in front of the gate and make surethat the
centre line of the pump is level with the centre line of the
flange on the pump gate.
4. Make sure the rubber gasket at the gate flange is correctly
positioned.
5. Position the motor on the gate flange.
6. Slide the pump onto the gate flange.
7. When the pump is in place and the holes in the pump and
gate flanges are aligned, bolt the two flanges together.
8. Secure the cables to a flexible cable tray.
– Make sure the cables can adapt to the different positions of
the gate without being damaged.
– The cables are heavy. Make sure the stress on the cables is
taken by a flexible cable tray.
4.4 Electrical connection
The supply voltage and frequency are marked on the nameplate.
Make sure that the motor is suitable for the power supply
available at the installation site.
Connect the pump to an external main switch ensuring all-pole
disconnection with a contact separation according to EN 60240-1,
5.3.2.
Connect P1, P2 and P3 in series with the thermal protectors and
moisture sensors. See section 4.4.2 Wiring diagrams.
4.4.1 Wire colours
Fig. 16 Wire colours, direct-online-starting, two power cables
The use of 8-core and 11-core cables are specified according to
the sensor options. See figures 1 to 4 starting on page 30.
4.4.2 Wiring diagrams
Fig. 17 Direct-online-starting, one power cable
DANGER
Crushing hazard
Death or serious personal injury
- Do not put your hands or any tools into the pump
inlet or outlet after the pump has been connected
to the power supply, unless the main switch has
been locked in position 0.
Make sure the electrical connection complies with
the local regulations.
The pump must be connected to a motor-protective
circuit breaker, such as MP 204.
A phase sequence relay is recommended,to avoid
the pump to restart if the phase sequence of the
power supply is changed by mistake.
TM03 9460 4007TM05 6180 4512
Primary power cable
Secondary power cable
Sensor cable
U1 (red)
W1 (black)
V1 (white)
Ground (earth)
(yellow/ green)
Ground (earth)
(yellow/ green)
V2 (white)
W2 (black)
U2 (red)
Ground (earth)
(yellow/ green)
1 to 7 (10) (white)
V1
W1
U1
M
~3
PE
Control cable L1 L2 L3 PE

13
English (US)
Fig. 18 Direct-online-starting, two power cables
Fig. 19 Direct-online-starting, three power cables
Fig. 20 Star-delta starting, one power cable
Fig. 21 Star-delta starting, four power cables
TM05 6181 4512TM05 6182 4512
V1
W1
U1
PE
M
~3
V2
W2
U2
PE
Control cable L1 L2 L3 PE
V1
W1
U1
PE
M
~3
V2
W2
U2
PE V3
W3
U3
PE
Control cable L1 L2 L3 PE
TM05 6183 4512TM06 9878 3517
The ground (earth) lead is a green cable marked
yellow/green and labelled "PE".
V1
W1
U1
PE
M
~3
V2
W2
U2
Control cable L1 L2 L3 PE
M
~3
U1 W1
V1 PE
U2 W2
V2 PE
U3 W3
V3 PE
U4 W4
V4 PE
Control cable L1 L1 L3 PE

English (US)
14
4.5 Frequency converter operation
All KPL, KPG and KWM pumps can be connected to a frequency
converter if an output filter is installed between the converter and
the motor. In case a filter is not installed, please contact
Grundfos.
Pumps can be connected ideally to a Grundfos CUE, - or a soft
starter, depending on choice.
When pumps are connected to a frequency converter pay
attention to the motor insulation system.
The minimum frequency depends on the type of application and
the design of the discharge piping. Always consider the following
when determining the minimum frequency:
• mass of the water above the propeller
• the force required to keep valves open
• the velocity reaction forces.
These factors vary from case to case. The minimum frequency
has to produce the necessary torque and force from the impeller
and propeller to overcome the above mentioned factors.
In environments with high content of sand, for example water
treatment plants, a self-cleaning velocity of at least 1 m/s must be
ensured in the column's largest diameter.
Ramp down over 30 seconds is recommended to the
minimum frequency of positive flow.
The thermal protection of the motor must be connected.
The peak voltage and dU/dt must be in accordance with the table
below. The values stated are maximum values supplied to the
motor terminals. The cable influence has not been taken into
account. See the frequency converter data sheet regarding the
actual values and the cable influence on the peak voltage and
dU/dt.
Set the frequency converter U/f ratio according to the motor data.
Local regulations and standards must becomplied with.
4.5.1 CUE or VFD
The optional CUE or VFD, which is either a Grundfos variable-
frequency converter or a general variable frequency converter,
offers better pump protection and a more steady flow through the
pipe system.
In addition, Grundfos CUE and VFD offer these features:
• anti-blocking
• automatic energy optimization
• specific-energy test
• output frequency
• monitoring of:
•voltage*
•current*
•phase sequence*
•power*
•energy*
•torque*
• reverse start
Note: Reverse start results in damage to the pump and column
pipe.
• run flushing
• stop flushing
• PID control.
* These functions are only available with Grundfos CUE.
Maximum repetitive peak
voltage
[V]
Maximum dU/dt UN 400 V
[V/μ sec.]
850 2000

15
English (US)
5. Starting up the product
The pump can be started by either direct-on-line starting, star-
delta starting, soft starter or frequency converter. For the wiring of
the start-stop circuit, see fig. 22 or 23.
Fig. 22 Direct-on-line starting
Fig. 23 Star-delta starting
5.1 Preparations for starting up
• Turn the propeller or impeller by hand to make sure the
propeller or impeller can rotate freely. See fig. 25.
• Make sure that the supply voltage and frequency correspond
to the values stated on the nameplate. If not, do not start the
pump.
• Make sure that the outer cable sheath is intact, so water
cannot penetrate to the terminal box. If the original power
cables are refitted, cut off a short piece to ensure that the
cable entry sealing sleeve does not clamp around the cable.
• Make sure that the cable entry bushing and the washers
correspond to the outside diameter of the power cables. When
preparing the power cable conductors for connection to the
pump and the terminal box, ensure that the ground (earth)
conductor is at least 2.2 inches (50 mm) longer than the other
conductors. This is substantialin case a cable is pulled out
unintentionally, so the ground (earth) conductor connection is
the last to be disconnected.
• Check the direction of the rotation. See section 5.1.1 Checking
the direction of rotation.
TM05 9167 4113TM05 9168 4113
3~
U1 V1 W1
123
L2L1 L3
L2L1 L3
U1 V1 W1
123
U2 V2 W2
456
U1 V1 W1
123
L2L1 L3
U2 V2 W2
456
DELTA
STAR
DANGER
Rotating elements
Death or serious personal injury
- Before manual startup or changeover to automatic
control, make sure that no persons are working on
or near the pump.

English (US)
16
5.1.1 Checking the direction of rotation
Check the direction of rotation before the startup.
Method 1 - Free-standing pump
Proceed as follows:
1. Place the pump on a plain surface.
2. Secure the pump by using the lifting chain and a crane to
preventit from tilting. The pump must rest on the ground
without any load on the crane. See fig. 24.
Fig. 24 Pump secured with a crane
3. Start the pump and let it run for a few seconds.
4. Observe the jerk of the pump. If the pump jerks
counterclockwise, the direction of rotation is correct. See fig.
25.
If the direction of rotation is wrong, interchange two phases in the
power cable.
Method 2 - Pump installed in a column pipe
• Make sure the column pipe is not filled with water.
• Make sure the pump is installed correctly. See section
4.2.6 Installing the KPL and KWM pump.
Proceed as follows:
1. Check the electrical connections with a phase detector to
make sure the connections are correct.
2. Start the pump and let it run for a few seconds.
3. Observe the jerk of the pump. If the pump jerks
counterclockwise, the direction of rotation is correct. See fig.
25.
If the direction of rotation is wrong, interchange two phases in the
power cable.
Fig. 25 Direction of jerk and rotation
DANGER
Electric shock
Death or serious personal injury
- In case the pump is running with wrong direction of
rotation, do not touch the pump or the cables.
KPL and KWM: Wrong direction of rotation leads to
damage to the pump and the column pipe.
Always check the direction of rotation before the pipe
is filled with liquid.
DANGER
Crushing hazard
Death or serious personal injury
- Never stand under or next to the pump when it is
hanging from a crane.
TM06 9724 3017
The jerk of large pumps can be powerful.
TM03 9466 3612
Direction of jerk
Direction of rotation

17
English (US)
5.2 Startup
Proceed as follows:
1. Lock the main switch in position 0.
2. Check the oil level in the oil chamber.
3. Make sure that the monitoring units are operating
appropriately.
4. Make sure that the pump is submerged in the liquid.
5. Open the isolating valves, if fitted.
6. Check the setting of the level switches.
7. Unlock the main switch, start the pump and check the pump
operation for abnormal noise or vibrations.
When started, the pump jerks counterclockwise.
8. After startup, establish the actual pump duty point.
6. Handling and storing the product
6.1 Handling the product
• Make sure that the lifting equipment is appropriate.
See section 4.2 Lifting the product.
• Always lift the pump by its lifting bracket/eye or by a forklift
truck, if the pump is fixed on a pallet.
• Observe the maximum cable bending radius. See
12.2.1 Bending radius of cables.
6.2 Storing the product
For periods of storage, the pump must be protected against
moisture and heat. After a period of storage, inspect the pump
before putting it back into operation. See also section
12.1.8 Storage temperature.
6.2.1 Storing in the pit (dry or wet)
The pump is frost-proof as long as it is operating or submerged in
the liquid. If the pit has been pumped dry, and the pump has been
exposed to the atmosphere, allow the pump to stand submerged
in the liquid for a short period before starting it up. This eliminates
the possibility of a frozen propeller or impeller. Never use an open
flame to thaw out the pump.
If the pump is submerged in liquid, operate it for 30 seconds
every month.
6.2.2 Storing in dry conditions
During storage, pay attention to the condition of the shaft seals
and the cable entries. Clean the pump at regular intervals and
spray it with corrosion-inhibiting oil. Always store the pump
protected and do not exposeit to direct sunlight.
DANGER
Automatic startup
Death or serious personal injury
- Before manual starting or changeover to automatic
control, make sure that no persons are working on
or near the pump.
Do not start the pump before checking the direction
of rotation.
Always operate the pump in accordance with
established routines with scheduled checks. Ensure
that the pump and equipment settings cannot be
changed by unauthorized persons.
In case of abnormal noise or vibrations, stop the
pump immediately. Do not restart the pump until the
cause of the fault is identified and eliminated.
Leave the cable end protectors and sensor cables on
the power until making the electrical connection.
The free cable ends must never be exposed to
moisture or water.
If the pump is stored dry, rotate the propeller or
impeller by hand at least bi-monthy to prevent the
shaft seals from seizing up.
If the propeller or impeller cannot be turned by hand,
contact an authorized service workshop.

English (US)
18
7. Product introduction
7.1 Applications
The pumps are designed for pumping storm- and wastewater in a
wide range of municipal and industrial applications:
• flood and stormwater control
• drainage and irrigation
• raw-water intake
• transfer of liquids in large-scale municipal sewage treatment
plants
• circulation of large quantities of water in water theme parks,
etc.
• circulation of water in fish farms
• water level control in coastal and low-lying areas
• filling and emptying water from dry docks and harbour.
7.2 General description
KPL pumps are submersible axial-flow propeller pumps.
Fig. 26 KPL pump
KWM pumps are submersible mixed-flow pumps.
Fig. 27 KWM pump
KPG pumps are gate pumps for submersible installation.
Fig. 28 KPG pump
TM05 5309 3812TM05 5620 3912
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
TM07 4689 2219
Pos. Description
1KPL, KWM: Lifting bracket
KPG: Lifting eyes
2 Power supply cables
3 Cable entries
4 Submersible motor
5 Turbulence optimizer (outlet sealing parts)
6 Outlet casing
7 Anti-rotation bracket
8 Inlet casing
1
4
1
3
6
8

19
English (US)
8. Identification
8.1 Type key
Fix the extra nameplate supplied with the pump at the installation
site or keep it in the cover of this booklet.
Example of KPL: KPL. 56.175.16.T.60.9.E.46
Example of KPG: KPG.5 6.175.16.T.60.9.E.46
Example of KWM: KWM. 56.600.12.T.60.865.M.46
* Special variant, contact Grundfos.
Note: Not all variants are available for all pump types / sizes.
8.2 Nameplate
Fit the extra nameplate supplied with the pump at the installation
site.
Fig. 29 Nameplate
* The values shown for duty-point head and duty-point flow rate
are standard. Other values are available on request.
Code Description Explanation
KPL Submersible axial-flow
pump
Pump typeKWM Submersible mixed-flow
pump
KPG Submersible axial-flow
gate pump
56 56"= 56 inches Column pipe diameter [in]
175 Output power P2
175 = 175 Hp Power [Hp]
600 600
16 16-pole Number of poles
12 12-pole
T Three-phase motor Number of phases
60 60 Hz Frequency
99 KPL, KPG
propeller number
865 Impeller number KWM: impeller number
M KWM - Medium head Pump range and
pressure
EKPL and KPG- Extra-low
head
46 460 V Voltage
Z Custom-built variant
TM05 7248 1613
Pos. Description
1 Type designation
2 Serial number
3 Product number
4 Maximum ambient temperature
5*
Duty-point head
Best-efficiency-point head
Maximum head
6*
Duty-point flow rate
Best-efficiency-point flow rate
Maximum flow rate
7 Maximum installation depth
8 Enclosure class according to IEC 60529
9 Number of poles
10 Frequency
11 Rated speed
12 Voltage and current, delta connections
13 Voltage and current, star connection
14 Input power
15 Shaft power
16 Power factor
17 Insulation class
18 Production code, year and week
19 Pump weight
gpmft
ft
Hp
Ibs
Hp
Model:
Serial No:
prod.No:
H:
Motor: P
DOL V A
Tmax: F
Q:
IP68
Hz n: min
Y- V A
P1: P2:
&RVĭ Insul.class:
year week wt:
Made in South Korea
1
3
2
5
7
9
4
8
6
11
10
15
17
19
12
13
14
16
18
1
2
3
5
7
9
12
13
14
16
18
4
6
8
11
10
15
17
19

English (US)
20
9. Protection and control functions
9.1 Sensors
The table shows the difference between standard product and
factory product variant (FPV) and the number of sensors. FPV
sensors can be chosen individually.
* Three Pt100 sensors are installed in the pump at the factory,
but only one sensor is connected as standard. All 3 stator
thermal sensors cannot be connected, if the bearing sensors
are also connected.
Fig. 30 KPL: switches and sensors
Fig. 31 KWM: switches and sensors
Fig. 32 KPG: switches and sensors
Key for figures 30, 31 and 32:
Sensor Type
Number of sensors
Standard FPV
Stator thermal protection Bi-metal 3 3
Stator thermal protection Pt100 1 3*
Terminal box moisture sensor Switch 1 1
Motor housing moisture sensor Switch 1 1
Bearing thermal protection
(lower) Pt100 1 1
Bearing thermal protection
(upper) Pt100 1 1
Water-in-oil sensor (WIO) Analog 1
Vibration sensor Analog 1
TM05 9557 4013
2 or 4
1
2
2
3
3
5
TM05 9558 4013
TM07 4690 2619
Pos. Description
1 Vibration sensor
2 Thermal sensor
3 Moisture switch
4 Thermal switch
5 Water-in-oil sensor (WIO)
2 or 4
5
1
2
2
3
3
2 or 4 2233
